Register your product and get support at
www.philips.com/welcome
42PFG6519
47PFG6519
55PFG6519
User Manual
Contents
1 My new TV 4
1.1 Smart TV 4
1.2 App gallery 4
1.3 Rental videos 4
1.4 Social networks 4
1.5 Ambilight+hue 4
1.6 Skype 5
1.7 Pause TV and recordings 5
1.8 Gaming 5
1.9 EasyLink 5
2 Setting up 6
2.1 Read safety 6
2.2 TV stand and wall mounting 6
2.3 Tips on placement 6
2.4 Power cable 6
2.5 Antenna cable 6
3 Network 8
3.1 Wireless network 8
3.2 Wired network 9
3.3 Network settings 9
4 Connections 11
4.1 Tips on connections 11
4.2 EasyLink HDMI CEC 12
4.3 Set-top box - STB 13
4.4 Home Theater System - HTS 13
4.5 Blu-ray Disc player 14
4.6 DVD player 15
4.7 Game console 15
4.8 USB Hard Drive 15
4.9 USB keyboard or mouse 16
4.10 USB flash drive 17
4.11 Photo camera 17
4.12 Camcorder 17
4.13 Computer 17
4.14 Headphones 18
5 Turn on 19
5.1 On or Standby 19
5.2 Keys on TV 19
5.3 Word mark brightness 19
6 Remote control 20
6.1 Key overview 20
6.2 IR sensor 21
6.3 Batteries 21
6.4 Cleaning 21
7 TV channels 22
7.1 Watching TV channels 22
7.2 Channel installation 25
8 Home menu 27
9.4 Receiving TV guide data 28
10 Sources 30
10.1 Sources list 30
10.2 From standby 30
10.3 EasyLink 30
11 Timers and clock 31
11.1 Sleeptimer 31
11.2 Clock 31
11.3 Switch off timer 31
12 3D 32
12.1 What you need 32
12.2 The 3D glasses 32
12.3 Care of the 3D glasses 32
12.4 Watch 3D 32
12.5 Optimal 3D viewing 32
12.6 Health warning 33
13 Games 34
13.1 Play a game 34
13.2 Two-player games 34
14 Your photos, videos and music 35
14.1 From a USB connection or network computer 35
14.2 Wi-Fi Miracast 36
15 Pause TV 38
16 Recording 39
16.1 What you need 39
16.2 Record a program 39
16.3 Watch a recording 39
17 Skype 41
17.1 About Skype 41
17.2 What you need 41
17.3 Start with Skype 41
17.4 Skype menu 42
17.5 My profile 42
17.6 Contacts 43
17.7 Calling on Skype 44
17.8 Skype credit 45
17.9 Skype settings 45
17.10 Sign out 47
17.11 Quit Skype 47
17.12 Terms of use & Privacy Policy 47
18 Smart TV 48
18.1 About Smart TV 48
18.2 What you need 48
18.3 Setup Smart TV 48
18.4 Smart TV Apps 48
18.5 Multi view 50
18.6 Reset Smart TV 50
9 TV guide 28
9.1 What you need 28
9.2 Using the TV guide 28
9.3 Recordings 28
19 Settings 51
19.1 Setup menu 51
19.2 Picture 51
19.3 Sound 54
2
19.4 Ambilight 56
19.5 Universal Access - Key beep 59
20 Specifications 60
20.1 Environmental 60
20.2 Reception 60
20.3 Display 60
20.4 Power 61
20.5 Dimensions and weights 61
20.6 Connectivity 61
20.7 Multimedia 61
21 Software 63
21.1 Software update 63
21.2 Software version 63
21.3 Open source software 63
21.4 Open-source license 63
22 Troubleshooting and support 69
22.1 Troubleshooting 69
22.2 Register 70
22.3 Help 70
22.4 Online help 70
22.5 Consumer Care / Repair 71
23 Safety and care 72
23.1 Safety 72
23.2 Screen care 73
24 Terms of use, copyrights and licenses 74
24.1 Terms of use 74
24.2 Copyrights and licenses 74
Index 77
3
1
Start Smart TV and add the video store App to the Smart TV
start page.
My new TV
1.1
Smart TV
Connect this
a new world of television. You can make a wired connection to
your router or you can link up wirelessly with Wi-Fi.
With the TV connected to your home network, a smartphone
can show a photo on TV, you can play videos stored on your
computer or control the TV with your tablet.
With your TV connected to the Internet, you can watch a rental
video from an online video store, read the online TV guide or
record your favorite TV show on a USB Hard Drive.
The Smart TV Apps add to the fun with all sorts of
entertainment and convenient services.
In
Help
information.
1.2
Philips Smart LED TV
, press
Keywords
to the Internet and discover
and look up
Smart TV
for more
Open the video store App, create your personal account, select
the movie and press play.
No fuss with downloading, you can watch the
movie immediately.*
In
, press
Help
more information.
* Depending on the video streaming service of the selected
video store.
1.4
Keywords
and look up
Rental videos
for
Social networks
No need to get up to check your friend's messages on your
computer.
Open Smart TV, select your
message back from your couch.
social network
page and send a
App gallery
Open the
collection of tailored websites for TV.
Find the App for YouTube videos, a national newspaper, an
online photo album, Facebook, Twitter, etc.
There are Apps for renting videos from an online video store
and Apps for watching programs you missed.
If the App gallery does not have what you are looking for, try
the World Wide Web and surf the Internet on TV.
In
Help
information.
1.3
App gallery
, press
in Smart TV to browse the Apps, the
Keywords
and look up
App gallery
for more
Rental videos
To watch a
Simply rent the latest movie from your regional online
video store.
rental video
, you don't need to leave your home.
Smart TV supports the popular social networks Facebook and
Twitter.
In
information.
1.5
Help
, press
Keywords
and look up
App gallery
for more
Ambilight+hue
With
Ambilight+hue
follow the Ambilight colors of the TV.
The Philips hue lamps will expand the Ambilight effect across the
room. If you don’t have any Philips hue lamps yet, buy the
Philips hue Starter Kit
and install the bulbs and bridge. You can buy extra Philips hue
bulbs separately.
, you can set up your
(includes a hue bridge and 3 hue bulbs)
Philips hue
lamps to
4
1.6
Skype
or schedule a recording of an upcoming program.
In
, press
Help
Recording
1.8
Keywords
for more information.
and look up
Pause TV
or
Gaming
If you select your game console in the Home menu, the TV
automatically switches to the settings ideal for gaming.
If you play a multi-player game with split screens, you can set the
TV to show each screen as a full screen simultaneously.
Each player can focus on his own game to play.
With
Skype™
You can call and see your friends from anywhere in the world.
To make a video call, you need a camera with a built-in
microphone and a good connection to the Internet. Some
Philips TVs have a camera and microphone built in.
In
Help
information.
1.7
you can make video calls on your TV for free.
, press
Keywords
and look up
Skype
for more
Pause TV and recordings
The TV uses 3D technology to show both screens. To play a
two-player game with two different full-screen pictures, you'll
need a pair of 3D glasses for each player.
In
Two player games
1.9
Help
, press
Keywords
for more information.
and look up
Game console or
EasyLink
With
EasyLink
ray Disc player, with the remote control of the TV.
EasyLink uses HDMI CEC to communicate with the connected
devices.
you can operate a connected device, like a Blu-
If you connect a
broadcast from a digital TV channel.
Pause your TV and answer that urgent phone call or simply take
a break during a sports game, while the TV stores the broadcast
on the USB Hard Drive. You can start watching again later.
With a USB Hard Drive connected, you can also record digital
broadcasts. You can record while you are watching a program
USB Hard Drive
, you can pause and record a
5
In
, press
Help
information.
Keywords
and look up
EasyLink
for more
2
2.3
Setting up
2.1
Read safety
Read the safety instructions first before you use the TV.
In Help, go to
2.2
Safety and care
TV stand and wall mounting
TV stand
You can find the instructions for mounting the TV stand in the
Quick Start Guide that came with the TV. In case you lost this
guide, you can download it from www.philips.com.
Use the product type number of the TV to look for the Quick
Start Guide to download.
Wall mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the wall mount .
. .
• For 55-inch TVs: VESA MIS-F 400x400, M6
• For 47-inch TV: VESA MIS-F 400x200, M6
• For 42-inch TV: VESA MIS-F 400x200, M6
>
Safety
.
Tips on placement
• Position the TV where light does not shine directly on the
screen.
• Dim lighting conditions in the room for best Ambilight effect.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal screen
size. When seated, your eyes should be level with the center of
the screen.
2.4
Power cable
• Insert the power cable into the
back of the TV.
• Make sure the power cable is securely inserted in the
connector.
• Make sure that the power plug, in the wall socket, is accessible
at all times.
• When you unplug the power cable, always pull the plug, never
pull the cable.
POWER
connector on the
To attach the bracket securely, use screws of the length
indicated in the drawing.
Caution
Wall mounting the TV requires special skills and should only be
performed by qualified personnel. The TV wall mounting should
meet safety standards according to the TV's weight. Also read
the safety precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for improper
mounting or any mounting that results in accident or injury.
Although this TV has a very low standby power consumption,
unplug the power cable to save energy if you do not use the TV
for a long period of time.
In
, press
Help
information about turning the TV on or off.
Keywords
and look up Turning on for more
6
2.5
Antenna cable
Insert the antenna plug firmly into the
back of the TV.
You can connect your own antenna or an antenna signal from
an antenna distribution system. Use an IEC Coax 75 Ohm RF
antenna connector.
ANTENNA
socket at the
7
3
Network
3.1
Wireless network
What you need
To connect the TV wirelessly to the Internet, you need a
wireless router. Use a high-speed (broadband) connection to
the Internet.
Network devices
The TV can connect to other devices in your wireless network,
like your computer or smartphone. You can use a computer
with Microsoft Windows or Apple OS X.
File sharing
On this TV, you can open photos, music and videos stored on
your computer. Use a recent version of media server software
like Philips MediaManager*, Windows Media Player 11,
Twonky™ or similar.
Install the media server software on your computer and set it up
to share your media files with the TV. Read the manual of the
media server software for more information. This software must
be running on your computer to view or play your files on TV.
* You can download the Philips MediaManager software from
the Philips support site www.philips.com/support
Make the connection
Follow steps 1 to 9.
- Make sure that the router of your wireless network is
Step 1
turned on.
- Press and select
Step 2
- Select
Step 3
- Select
Step 4
- Select
Step 5
- Select
Step 6
have a router with WPS (Wi-Fi Protected Setup), you can select
. Select your choice and press OK.
WPS
Connect to network
Connect
Wireless
Scan
and press OK.
and press OK.
to scan for your wireless network. If you
and press OK.
Setup
and press OK.
•
Scan
Select
router). The TV might find several wireless networks in your
proximity.
•
WPS
If your router has WPS, you can directly connect to the router
without scanning. Go to the router, press the WPS button and
return to the TV within 2 minutes. Then press
the connection.
If you have devices in your wireless network that use the WEP
security encryption system, you cannot use WPS.
If you must use the
instead of WPS.
Step 7
network and press OK.
If your network is not in the list because the network name is
hidden (you turned off the SSID broadcast of the router), select
Manual entry
Step 8
your encryption key (WEP, WPA or WPA2). If you have
entered the encryption key for this network before, you can
select
If your router supports WPS or WPS PIN, you select
WPS PIN
•
Standard
Select
passphrase, or security key) manually. You can use the keyboard
on the remote control to enter the encryption key. Once you
have entered the key, press
•
WPS PIN
To make a secured WPS connection with a PIN code, select
WPS PIN
shown and enter it in the router software on your PC. Return to
the TV and press
to enter the PIN code in the router software.
Step 9
successful.
Network configuration
If the connection fails, you can check the DHCP setting of the
router. DHCP should be set to On.
Alternatively, if you are an advanced user and want to install
your network with Static IP addressing, set the TV to Static IP.
To set the TV to Static IP, press and select
OK
configuration
you can set the IP address and other necessary settings in
IP configuration
to scan for your wireless network (your wireless
Scan
Connect
WPS PIN code
- From the list of networks found, select your wireless
to enter the network name yourself.
- Depending on the type of router, you can now enter
to make the connection immediately.
Next
or
Standard
Standard
and press OK. Write down the 8-digit PIN code
- A message will be shown when the connection is
. Select your choice and press OK.
to enter the encryption key (password,
Connect
. Consult the router manual on where
to connect, select
Connect
.
and press
Setup
. Select
Network settings
>
Static IP
in the same menu.
>
Network settings
. With Static IP selected in the menu,
>
to make
Scan
,
WPS
Network
Static
8
Network problems
Connect the router
Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi 802.11b/g/n
devices in your proximity might disturb the wireless network.
• Make sure that the firewalls in your network allow access to
the TV's wireless connection.
• If the wireless network does not work properly in your home,
try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the router
connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for information on
indoor range, transfer rate and other factors of signal quality.
• Use a high-speed (broadband) Internet connection for your
router.
3.2
Wired network
What you need
To connect and setup the router follow steps 1 to 5.
1 - Connect the router to the TV with a network cable
(Ethernet cable**).
2 - Make sure that the router is turned on.
3 - Press and select
4 - Select
5 - Select
The TV constantly searches for the network connection. A
message will be shown when the connection is successful.
Network configuration
If the connection fails, you can check the DHCP setting of the
router. DHCP should be set to On.
Alternatively, if you are an advanced user and want to install
your network with Static IP addressing, set the TV to Static IP.
To set the TV to Static IP, press and select
press OK.
Select
configuration
you can set the IP address and other necessary settings in
IP configuration
**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet
cable.
Connect to network
and press OK.
Wired
Network settings
>
Static IP
in the same menu.
and press OK.
Setup
and press OK.
and
Setup
>
Network settings
. With Static IP selected in the menu,
>
Network
Static
You need a network
Use a router with a high-speed (broadband) connection to the
Internet.
File sharing
On this TV, you can open photos, music and videos stored on
your computer. Use a recent version of media server software
like Philips MediaManager*, Windows Media Player 11,
Twonky™ or similar.
Install the media server software on your computer and set it up
to share your media files with the TV. Read the manual of the
media server software for more information. This software must
be running on your computer to view or play your files on TV.
* You can download the Philips MediaManager software from
the Philips support site www.philips.com/support
In
Help
software, supported
software.
, press
Keywords
to connect the TV to the Internet.
router
and look up
for an overview of supported media server
Media server
3.3
Network settings
To open the Network settings . . .
1 - Press and select
2 - Select
•
View network settings
All current network settings are shown here. The IP and MAC
address, signal strength, speed, encryption method, etc.
•
Network settings
- Network type
Sets the network to Wired or Wireless.
- Network configuration
Sets the network configuration to DHCP or Static IP.
•
Wi-Fi media playback
To receive multimedia files from smartphones or tablets, set the
DMR to On.
•
Static IP configuration
If Static IP is selected, you can set all necessary static IP settings
here.
Network settings
and press OK.
Setup
and press OK.
9
•
Wi-Fi Miracast
For more information on Wi-Fi Miracast,
press
Keywords
•
Reset Wi-Fi Miracast group
and look up
Wi-Fi Miracast™
.
Clear the list of connected and blocked devices that are used
with Miracast.
•
Wi-Fi smart screen
For more information on Wi-Fi smart screen,
press
Keywords
•
TV network name
and look up
Wi-Fi smart screen
.
If you have more than one TV in your network, you can rename
the TVs here.
•
Netflix settings
Adjust Netflix settings.
•
Clear Internet memory
With Clear Internet Memory, you clear all Internet files stored
on your TV. You clear your Philips Smart TV registration and
parental control settings, video store app logins, Smart TV app
favorites, and Internet bookmarks and history. Interactive MHEG
applications save cookies to your TV. These files are also
cleared.
10
4
Connections
4.1
Tips on connections
Connectivity guide
Always connect a device to the TV with the highest quality
connection available. Also, use good quality cables to ensure a
good transfer of picture and sound.
If you need help to connect several devices to the TV, you can
visit the Philips TV connectivity guide. The guide offers
information on how to connect and which cables to use.
Go to
www.connectivityguide.philips.com
If your devices are connected with HDMI and have EasyLink, you
can operate them with the TV remote control. EasyLink HDMI
CEC must be turned On on the TV and the connected device.
For more information on using EasyLink, press
and look up
DVI to HDMI
Use a DVI to HDMI adapter if your device only has a DVI
connection. Use one of the HDMI connections and add an
Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on
the back of the TV.
Copy protection
DVI and HDMI cables support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal that
prevents copying content from a DVD disc or Blu-ray Disc. Also
referred to as DRM (Digital Rights Management).
EasyLink CEC
.
Keywords
Antenna
If you have a Set-top box (a digital receiver) or Recorder,
connect the antenna cables to run the antenna signal through
the Set-top box and/or Recorder first before it enters the TV. In
this way, the antenna and the Set-top box can send possible
additional channels to the Recorder to record.
HDMI
HDMI CEC
HDMI ARC
All of the HDMI connections on the TV have HDMI ARC
(Audio Return Channel).
If the device, typically a Home Theater System (HTS), also has
the HDMI ARC connection, connect it to any of the HDMI
connections on this TV. With the HDMI ARC connection, you
do not need to connect the extra audio cable that sends the
sound of the TV picture to the HTS. The HDMI ARC
connection combines both signals.
You can use any HDMI connection on this TV to connect the
HTS but ARC is only available for 1 device/connection at a time.
In case you prefer to turn off ARC on the HDMI connections,
press and select
Select
TV settings
Setup
>
Sound
and press OK.
>
Advanced
>
HDMI ARC
.
Video-Audio LR
CVBS - Composite Video is a high quality connection. Next to
the CVBS signal, add the Audio Left and Right signals for sound.
HDMI connections provide the best picture and sound quality.
HDMI cables combine video and audio signals. Use an HDMI
cable for high-definition (HD) and TV signals. For best signal
quality, use a high-speed HDMI cable, and do not use HDMI
cables longer than 5 m.
EasyLink HDMI CEC
11
Audio Out - Optical
Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully
compatible with EasyLink.
Audio Out - Optical is a high quality sound connection. This
optical connection can carry 5.1 audio channels. If your device,
typically a Home Theater System (HTS), has no HDMI ARC
connection, you can use this connection with the Audio In Optical connection on the HTS. The Audio Out - Optical
connection sends the sound from the TV to the HTS.
You can set the type of the audio out signal to fit the audio
capabilities of your Home Theater System.
For more information, press
Out settings
If the sound does not match the video on screen, you can adjust
the audio to video synchronization.
For more information, press
to video sync
.
.
Keywords
Keywords
and look up
and look up
Audio
Audio
Example HDMI CEC branding names are property of their
respective owners.
Operate devices
To operate a device connected to HDMI and set up with
EasyLink, select the device - or its activity - in the list of TV
connections. Press
an HDMI connection and press OK.
Once the device is selected, the TV remote control can control
the device. However and
other TV keys are not forwarded to the device.
If the key you need is not on the TV remote control, you can
select the key in the Options menu.
Press
the screen, select the device key you need and press OK.
Some very specific device keys might not be available in the
Controls menu.
OPTIONS
SOURCES
and select
, select a device connected to
OPTIONS
Controls
keys and some
in the menu bar. On
4.2
EasyLink HDMI CEC
EasyLink
With EasyLink you can operate a connected device with the TV
remote control. EasyLink uses HDMI CEC (Consumer
Electronics Control) to communicate with the connected
devices. Devices must support HDMI CEC and must be
connected with an HDMI connection.
EasyLink setup
The TV comes with EasyLink turned on. Make sure that all
HDMI CEC settings are properly set up on the connected
EasyLink devices. EasyLink might not work with devices from
other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on different
brands. Some examples are: Anynet, Aquos Link, Bravia Theatre
Note: Only devices that support
function will respond to the TV remote control.
EasyLink remote control
EasyLink settings
The TV comes with all EasyLink settings turned on. You can turn
off any EasyLink setting independently.
EasyLink
To turn off EasyLink completely . . .
1 - Press and select
2 - Select
3 - Select
4 - Press , repeatedly if necessary, to close the menu.
EasyLink Remote Control
If you want devices to communicate but you don't want to
operate them with the TV remote control, you can turn off
EasyLink remote control separately.
In the EasyLink settings menu, select
and select
Pixel Plus link
Some devices, a DVD or Blu-ray Disc player, might have their
own picture quality processing. To avoid bad picture quality
caused by interference with the TV processing, the picture
TV settings
and press OK.
Off
.
Off
and press OK.
Setup
>
General settings
>
EasyLink
EasyLink Remote Control
.
12
processing of these devices should be disabled. The TV comes
with Pixel Plus link turned on and disables the picture quality
processing of recent Philips devices connected to the TV.
To turn off Pixel Plus link, in the EasyLink settings menu, select
Pixel Plus link
Auto turn off devices
You can set the TV to turn off the connecting HDMI-CEC
compliant devices if they are not the active source. The TV turns
the connected device to standby after 10 minutes of inactivity.
and select
Off
.
4.4
Home Theater System - HTS
Connect HTS
Use an HDMI cable to connect a Home Theater System (HTS)
to the TV. You can connect a Philips Soundbar or an HTS with a
built-in disc player.
HDMI ARC
4.3
Set-top box - STB
Use 2 antenna cables to connect the antenna to the Set-top box
(a digital receiver) and the TV.
Next to the antenna connections, add an HDMI cable to
connect the Set-top box to the TV.
If your Home Theater System has an HDMI ARC connection,
you can use any HDMI connection on the TV to connect. With
HDMI ARC, you do not need to connect the extra audio cable.
The HDMI ARC connection combines both signals.
All HDMI connections on the TV can offer the Audio Return
Channel (ARC) signal, but once you have connected the Home
Theater System, the TV can only send the ARC signal to this
HDMI connection.
If the Home Theatre System has no HDMI ARC connection,
add an optical audio cable to send the sound of the TV picture
to the Home Theater System.
Switch off timer
Switch off this automatic timer if you only use the remote
control of the set-top box. This prevents the TV from turning off
automatically after 4 hours without a key press on the TV
remote control.
To turn off the Switch off timer, press and select
press OK.
Select
TV settings
set the slider bar to
>
General settings
.
Off
>
Switch off timer
Setup
and
and
Audio to video synchronization (sync)
If the sound does not match the video on screen, you can set a
delay on most Home Theater Systems with a disc player to
match the sound with the video.
For more information, press
to video sync
13
.
Keywords
and look up
Audio
Audio Out settings
Audio Out delay
With a Home Theater System (HTS) connected to the TV, the
picture on the TV and the sound from the HTS should be
synchronized.
Automatic audio to video sync
With recent Philips Home Theater Systems, the audio to video
sync is done automatically.
Audio sync delay
For some Home Theater Systems you may need to adjust the
audio sync delay to synchronize the audio to the video. On the
HTS, increase the delay value until there is a match between
picture and sound. A delay value of 180ms may be required.
Read the user manual of the HTS. With a delay value set up on
the HTS, you need to turn off Audio Out delay on the TV.
To turn off the Audio Out delay . . .
1 - Press and select
2 - Select
.
delay
3 - Select
4 - Press , repeatedly if necessary, to close the menu.
TV settings
and press OK.
Off
Setup
>
and press OK.
>
Sound
Advanced
>
Audio Out
1 - Press and select Setup and press OK.
2 - Select
format
3 - Select
4 - Press , repeatedly if necessary, to close the menu.
Audio Out leveling
Use the Audio Out leveling setting to level the volume
(loudness) of the TV and the Home Theater System when you
switch over from one to another. Volume differences can be
caused by differences in sound processing.
To level the difference in volume . . .
1 - Press and select
2 - Select
Leveling
3 - If the volume difference is large, select
difference is small, select
4 - Press , repeatedly if necessary, to close the menu.
Audio Out leveling affects both the Audio Out - Optical and
HDMI ARC sound signals.
TV settings
.
Multichannel
TV settings
.
>
or
Setup
>
Sound
Stereo
Sound
Less
>
Advanced
.
and press OK.
>
Advanced
.
>
Audio Out
>
Audio Out
. If the volume
More
Problems with HTS sound
Audio Out offset
If you cannot set a delay on the Home Theater System, you can
set the TV to sync the sound. You can set an offset that
compensates for the time necessary for the Home Theater
System to process the sound of the TV picture. You can set the
value in steps of 5ms. Maximum setting is -60ms. The Audio Out
delay setting should be turned on.
To synchronize the sound on the TV . . .
1 - Press and select
2 - Select
offset
3 - Use the slider bar to set the sound offset and press OK.
4 - Press , repeatedly if necessary, to close the menu.
Audio Out format
If you have a Home Theater System (HTS)
with multichannel sound processing capabilities like Dolby
Digital, DTS® or similar, set the Audio out format to
Multichannel. With Multichannel, the TV can send the
compressed multichannel sound signal from a TV channel or
connected player to the Home Theater System. If you have a
Home Theater System without multichannel sound processing,
select Stereo.
TV settings
.
Setup
>
Sound
and press OK.
>
Advanced
>
Audio Out
Setup
>
Advanced
Setup
>
Advanced
.
Stereo
>
TV
>
Audio out format
HDMI ARC
setting on the TV is turned On.
>
TV
>
HDMI ARC
.
Audio
.
Sound with loud noise
If you watch a video from a plugged in USB flash drive or
connected computer, the sound from your Home Theater
System might be distorted. This noise is heard when the audio
or video file has DTS sound but the Home Theater System has
no DTS sound processing. You can fix this by setting the
Out format
Press and select
settings
No sound
If you cannot hear the sound from the TV on your Home
Theater System, check the following . . .
• Check if you connected the HDMI cable to an
connection on the Home Theater System. All HDMI
connections on the TV are HDMI ARC connections.
• Check if the
Press and select
settings
4.5
of the TV to
>
Sound
HDMI ARC
>
Sound
Blu-ray Disc player
Use a
High speed HDMI
player to the TV.
cable to connect the Blu-ray Disc
To set the Audio Out format . . .
14
If the Blu-ray Disc player has EasyLink HDMI CEC, you can
operate the player with the TV remote control.
Video-Audio LR
Connect the game console with a composite cable (CVBS) and
an audio L/R cable to the TV.
For more information on EasyLink, press
up
EasyLink HDMI CEC
4.6
.
Keywords
and look
DVD player
Use an HDMI cable to connect the DVD player to the TV.
If the DVD player is connected with HDMI and has EasyLink
CEC, you can operate the player with the TV remote control.
For more information on EasyLink, press
look up
EasyLink HDMI CEC
.
Keywords
and
4.8
USB Hard Drive
What you need
If you connect a USB Hard Drive, you can pause or record a TV
broadcast. The TV broadcast must be a digital broadcast (DVB
broadcast or similar).
To pause
To pause a broadcast, you need a USB 2.0 compatible Hard
Drive with a minimum of 32GB of disk space.
To record
To pause and record a broadcast, you need a minimum of
250GB of disk space.
4.7
Game console
HDMI
For best quality, connect the game console with a high-speed
HDMI cable to the TV.
TV guide
Before you decide to buy a USB Hard Drive to record, you
should check if it is possible to record digital TV channels in your
country.
Press
button on the TV guide page, you can record.
For more information on how to install a USB Hard Drive, press
15
TV GUIDE
Keywords
on the remote control. If there is a Record
and look up
USB Hard Drive, installation
.
Installation
Before you can pause or record a broadcast, you must connect
and format a USB Hard Drive. If you want to record a broadcast
with TV guide data from the Internet, you need to have the
Internet connection installed on your TV before you install the
USB Hard Drive. Formatting removes all files from the USB
Hard Drive.
1 - Connect the USB Hard Drive to one of the
connections on the TV. Do not connect another USB device to
the other USB ports when formatting.
2 - Turn on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel, press
(Pause). Trying to pause will start the formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it connected
permanently.
or
Recording
Keywords
.
Warning
The USB Hard Drive is formatted exclusively for this TV, you
cannot use the stored recordings on another TV or PC. Do not
copy or change recording files on the USB Hard Drive with any
PC application. This will corrupt your recordings. When you
format another USB Hard Drive, the content on the former will
be lost. A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
For more information, press
TV
USB
and look up
Pause
Install the keyboard
To install the USB keyboard, turn on the TV and connect the
USB keyboard to one of the
the TV detects the keyboard for the first time, you can select
your keyboard layout and test your selection. If you select a
Cyrillic or Greek keyboard layout first, you can select a
secondary Latin keyboard layout.
To change the keyboard layout setting when a layout was
selected…
1 - Press and select
2 - Select
settings
Keys for channel renaming
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary layout is
set, press the
Keys for Smart TV Apps and Internet pages
• Shift+Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• + = zoom in one step
• - = zoom out one step
• * = fit the web page to the screen width
TV settings
and press OK.
Setup
>
Ctrl + Shift
connections on the TV. When
USB
and press OK.
General settings
>
keys simultaneously.
USB keyboard
USB mouse
Connect USB mouse
You can connect a USB mouse (USB-HID type) to navigate
pages on the Internet.
4.9
USB keyboard or mouse
USB keyboard
Connect a USB keyboard (USB-HID type) to enter text on your
TV.
You can connect a keyboard and a mouse to the TV.
Use one of the
connections to connect.
USB
On an Internet page, you can select and click on links more
easily.
Connect the mouse
Turn the TV on and connect the USB mouse to one of the
connections on the TV. You can also connect the USB mouse to
a connected USB keyboard.
Mouse clicks
• Left click = OK
16
USB
You can use the scroll wheel to scroll pages up and down.
For more information on how to connect a keyboard,
press
Keywords
Mouse speed
You can adjust the speed of the mouse moving on screen.
and look up
USB keyboard
.
To adjust the speed . . .
1 - Press and select
2 - Select
3 - Select
4 - Press the arrows (up) or (down) to increase or
decrease the speed.
5 - Press OK to store and close the setting.
6 - Press , repeatedly if necessary, to close the menu.
4.10
TV settings
General settings
and press OK.
Setup
and press OK.
>
Mouse settings
and press OK.
USB flash drive
You can view photos or play your music and videos from a
connected USB flash drive.
Insert a USB flash drive in one of the
TV while the TV is turned on.
connections on the
USB
If the contents list does not appear automatically, press
SOURCE
Your camera might need to be set to transfer its content with
PTP (Picture Transfer Protocol). Read the user manual of the
digital photo camera.
For more information on viewing photos, press
Keywords
4.12
, select
and look up
and press OK.
USB
Your photos, videos and music
.
Camcorder
HDMI
For best quality, use an HDMI cable to connect the camcorder
to the TV.
The TV detects the flash drive and opens a list showing its
content.
If the contents list does not appear automatically, press
SOURCE
To stop watching the USB flash drive content, press or select
another activity.
To disconnect the USB flash drive, you can pull out the flash
drive anytime.
For more information on watching or playing content from a
USB flash drive, press
videos and music
4.11
, select
and press OK.
USB
Keywords
.
and look up
Your photos,
Photo camera
To view photos stored on your digital photo camera, you can
connect the camera directly to the TV.
Use one of the
the camera after you have made the connection.
connections on the TV to connect. Turn on
USB
Video-Audio LR
Use a Video Audio L/R cable to connect the camcorder to the
TV.
17
4.13
Computer
Connect
You can connect your computer to the TV and use the TV as a
PC monitor.
With HDMI
Use an HDMI cable to connect the computer to the TV.
a movie) and press OK.
4 - Press , repeatedly if necessary, to close the menu.
Remember to set the Game or computer setting back
to
Computer
4.14
when you stop playing the game.
Headphones
You can connect a set of headphones to the connection on
the TV. The connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume . . .
With DVI to HDMI
Alternatively, you can use a DVI to HDMI adapter to connect
the PC to HDMI and an audio L/R cable (mini-jack 3.5 mm) to
AUDIO IN DVI on the back of the TV.
1 - Press and select
2 - Select
press OK.
3 - Press (up) or (down) to adjust the volume.
4 - Press , repeatedly if necessary, to close the menu.
TV settings > Sound
Setup
and press
>
OK.
Headphones volume
and
Settings
Ideal monitor setting
If your computer is added as a Computer type of device in the
Source menu (the list of connections), the TV is set to the ideal
Computer setting automatically.
If you use your computer to watch movies or use it to play
games, you might want to set the TV back to the ideal TV
watching or gaming setting.
To set the TV to the ideal setting manually . . .
1 - Press and select
2 - Select
style
3 - Select
TV settings
and press OK.
Game
and press
Setup
>
(for gaming) or select
>
Advanced
OK.
>
Computer
Activity
(for watching
18
5
Turn on
5.1
On or Standby
Make sure you have plugged in the main power on the back of
the TV before you turn on the TV.
If the red indicator light is off, press the Joystick on the right side
on the back of the TV to put the TV in standby - the red
indicator will light up.
With the TV in standby, press on the remote control to turn
the TV on.
Switch to standby
5.3
Word mark brightness
You can turn off or adjust the word mark lighting.
To adjust or turn off…
1 - Press and select
2 - Select
brightness
3 - Select
the lighting of the word mark.
4 - Press , repeatedly if necessary, to close the menu.
TV settings
and press OK.
Maximum, Medium, Minimum
and press OK.
Setup
>
General settings
>
Word mark
or select
to turn off
Off
To switch the TV to standby, press on the remote control.
Turn Off
To turn the TV Off, press the Joystick on the right of the TV on
the back. The red indicator light is off. The TV is still connected
to the main power but consumes a minimum of energy.
To turn off the TV completely, disconnect the power plug.
When disconnecting the power plug, always pull the power plug,
never the cord. Ensure that you have full access to the power
plug, power cord and outlet socket at all times.
5.2
Keys on TV
While the on-screen display is on, press the Joystick to display
the menu.
• Use the arrow/navigation keys to navigate up, down, left or
right.
• Press the Joystick to confirm a selection or setting.
19
6
Remote control
6.1
Key overview
Top
-
1
Standby
To turn the TV On or back to Standby.
-
2
Playback and record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to fast forward
• Record , to record now
/
On
keys
-
1
SMART TV
To open the Smart TV start page.
-
2
Color keys
Follow the on-screen instructions.
-
3
INFO
To open or close program info.
-
4
BACK
To switch back to the previous channel you selected.
To close a menu without changing a setting.
To go back to the previous Smart TV page.
-
5
HOME
To open or close the home menu.
-
6
EXIT
To switch back to watching TV.
-
7
OPTIONS
To open or close the Options menu.
- OK key
8
To confirm a selection or setting.
-
9
Arrow / navigation
To navigate up, down, left or right.
-
10
To open an extra small screen.
MULTIVIEW
keys
-
3
To select an Ambilight setting.
4
To open or close the TV guide.
5
To open the Settings menu.
6
To open or close the Picture format menu.
7
To open or close the Sources menu - the list of connected
devices.
8
To open the Popular searches page.
Ambilight
-
TV GUIDE
-
Settings
-
Picture format
-
SOURCES
-
SEARCH
Middle
Bottom
-
1
Volume
To adjust the volume level.
-
2
Number keys
To select a TV channel directly or to enter text.
-
3
CC
To turn subtitles on, off, or on during mute.
-
4
LIST
To open or close the channel list.
-
5
Channel
To switch to the next or previous channel in the channel list.
To open the next or previous page in Text or start the next or
previous chapter on a disk.
and
text keypad
-
6
Mute
To mute the sound or to restore it.
20
-
7
(Dot)
To enter digital sub-channels.
6.4
Cleaning
6.2
IR sensor
The TV can receive commands from a remote control that uses
infrared (IR) to send commands. If you use this kind of remote
control, always point it at the infrared sensor on the front of the
TV.
6.3
Batteries
If the TV does not react on a key press on the remote control,
the batteries might be empty.
Your remote control is treated with a scratch-resistant coating.
To clean the remote control, use a soft damp cloth. Never use
substances such as alcohol, chemicals or household cleaners on
the remote control.
To replace the batteries, open the battery compartment on the
keyboard side of the remote control.
1 - Slide the battery door in the direction shown by the arrow.
2 - Replace the old batteries with 2
type
AAA-R03-1.5V
the batteries line up correctly.
3 - Reposition the battery door and slide it back until it clicks.
Remove the batteries if you are not using the remote control for
a long time.
Safely dispose of your old batteries according to the end of use
directions.
For more information, press
.
use
batteries. Make sure the + and - ends of
Keywords
and look up
End of
21
7
Channel list
TV channels
7.1
Watching TV channels
Switch channels
To watch TV channels, press . The TV tunes to the TV
channel you last watched.
Alternatively, press to open the Home menu and
select
Watch TV
To switch channels, press
channel number, type in the number with the number keys.
Press OK after you entered the number to switch channels.
To switch back to the previously tuned channel, press .
and press OK.
or
. If you know the
Favorite channels
You can create a favorite channel list that only holds the
channels you want to watch. With the Favorite channel list
selected, you will only see your favorite channels when you
switch through channels.
Create your favorite channel list
1 - While watching a TV channel, press
channel list.
2 - Select the channel and press
selected channel is marked with a .
3 - To finish, press . The channels are added to the Favorites
list
To remove a channel from the Favorites list, select the channel
and press
Channel list views
In the channel lists, you can find all installed TV and radio
channels.
Channel list options
According to the channel list on screen, press
select one of the options.
Remove
.
LIST
as favorites. The
Mark
to open the
OPTIONS
to
LIST
or
to open the
.
To switch to a channel from a channel list
While watching a TV channel, press
channel lists.
In a channel list, navigate to a TV channel or radio station. With
its icon highlighted, press OK to change the TV channel or listen
to the radio station.
The channel list can have several pages with channels. To view
the next or previous page, press
To close the channel lists without switching channels,
press
Radio channels
If digital broadcasting is available, digital radio stations are
installed during installation. Switch to a radio channel just like you
switch to a TV channel. A cable channel installation usually
places radio stations from channel number 1001 onwards.
LIST
again.
Channel logos
In some countries, the TV can show the channel logos. If you do
not want these logos to appear, you can turn them off.
To turn off Channel logos . . .
1 - Press and select
2 - Select
press OK.
3 - Select
4 - Press , repeatedly if necessary, to close the menu.
Rename channels
You can rename channels in the channel list.
1 - Select the channel you want to rename in one of the channel
lists.
TV settings
and press OK.
Off
and press OK.
Setup
>
General settings
>
Channel logos
and
22
2 - Press
3 - You can enter text with the remote control keyboard or
open the on-screen keyboard.
Rename
.
The TV will ask for the code to unlock the program. For some
broadcasters / operators, the TV only locks programs with a
higher rating.
With the on-screen keyboard
• To open the on-screen keyboard, place the cursor into the
name text field and press OK.
• To delete the character in front of the cursor,
press
Backspace
• To enter a character, select the character with the arrow keys
and press OK.
• To select uppercase characters, press .
• To select numbers or special characters, press .
• When you are ready, press to close the on-screen
keyboard.
• To finish renaming, select
Lock a channel
To prevent children from watching a channel or a program, you
can lock channels or lock age rated programs.
Lock a channel
You can lock a channel to prevent children from watching it. To
watch a locked channel you need to enter the Child lock code.
You cannot lock programs from connected devices.
To lock a channel . . .
.
and press OK.
Done
Content rating
You can block programs with objectionable content.
1 - Press and select
2 - Select
.
lock
3 - If no child lock code is set, you must enter one now. Enter a
4-digit code.
4 - Set the content and press OK. The selected content is
blocked.
5 - Press , repeatedly if necessary, to close the menu.
Set or change the lock code
To set the lock code or to change the current code . . .
1 - Press and select
2 - Select
and press OK.
code
3 - If a code is set already, enter the current
and then enter the new code twice.
The new code is set.
Forgotten your code?
To override and enter a new child lock code in case you forget
it, enter 8888.
Setup
Channel settings
Setup
Channel settings
and press OK.
>
Child lock
and press OK.
>
Child lock
>
Content ratings
>
Set code
Child lock code
or
Change
1 - While watching a TV channel, press
Channel list
2 - In any list, select the channel you want to lock.
3 - Press
list, a locked channel is marked with a lock .
To unlock a channel, select the locked channel in the channel list.
Press
to enter the
Age ratings lock
To prevent children from watching a program not suitable for
their age, you can use an age rating.
Some digital broadcasters have age rated their programs. When
the age rating of a program is equal to or higher than the age
you have set as age rating for your child, the program will be
locked.
To watch a locked program you must enter the child lock code.
The parental age rating is set for all channels.
To set an age rating . . .
1 - Press and select
2 - Select
press OK.
3 - Enter a 4-digit
select
and confirm. Now you can set an age rating.
4 - Set the age and press OK.
5 - Press , repeatedly if necessary, to close the menu.
.
OPTIONS
OPTIONS
Child lock
Channel settings
Set code
and press OK. Enter a 4-digit
and select
and select
code.
Setup
Child lock code
Unlock channel
and press OK.
>
Child lock
Lock channel
. If you did not set a code yet,
to open the
LIST
. In a channel
. You will need
>
Age ratings lock
Child lock code
and
Options for channels
While watching a channel, depending on the type of channel
(analog or digital) you are watching or depending on the TV
settings you made, some options are available.
Open the options menu
While watching a channel, press
Universal Access - Key beep
When you press a button on the remote control or TV, you can
set the TV to play a beep.
For more information, press
up
Universal Access - Key beep
Closed captions
Turn
Closed captions on
OPTIONS
Keywords
.
or
Closed captions off
.
and look
with this
23
options. Select
when the sound is muted with .
Caption service
Select the correct type of closed-caption services.
For more information, press
captions
Alternate audio
For analog channels, select Main or SAP for audio language.
Audio languages
For digital broadcast, you can select an available audio language
temporarily if none of your preferred languages are available.
For more information, press
languages
On during mute
.
.
to show closed captions only
Keywords
Keywords
and look up
and look up
Closed
Audio
- Zoom
- Stretch
- Native
- Undo
Closed captioning (CC) and language
Closed captions
You can display closed captions at all times or only when the TV
is muted.
To open
Closed captions
, press CC.
Dual I-II
If an audio signal contains two audio languages but one language
— or both — has no language indication, this option is available.
DTVi Applications
Display the list of Digital TV interactive applications.
For more information, press
Status
Select
analog or digital) or a connected device you are watching.
Share
Enables the user to communicate his activity with his social
networks (such as Twitter, Facebook, or email).
iTV not shown
Keywords
and look up
to view technical information on the channel (if it is
Status
DTVi
.
Picture format
If black bars appear on top and bottom or on both sides of the
picture, you can adjust the picture format to a format that fills
the screen.
Note:
• Digital TV interactive applications are not accessible when
closed caption text is turned on.
• Not all TV programs, commercials and features include closed
captioning information. See your local TV program
listings for channels with closed captions. Captioned programs
are typically listed with service marks, such
as 'CC,' in the TV listings.
Turn on closed captions
1 - While you watch TV, press
2 - Select
Select type of closed captions
1 - While you watch TV, press
2 - Select
3 - Select the correct type of closed captions and press OK.
Closed captions
Caption service
OPTIONS
> On and press OK.
OPTIONS
.
.
.
To change the picture format . . .
1 - While watching a TV channel, press to open the
menu.
format
2 - Select a format from the list and press OK.
The following formats can be available according the picture on
screen . . .
•
Basic
- Fill screen
- Fit to screen
•
Advanced
- Last setting
- Move
Audio language
If the TV channel broadcasts multiple or dual audio languages,
you can select your preferred audio language.
1 - While you watch TV, press
2 - For digital channels, select
channels, select
selection.
3 - Select from the available languages, then press OK.
Note:
If you have selected
between:
•
: Primary audio language or
Main
•
: Secondary audio language
SAP
24
Alternate audio
Alternate audio
OPTIONS
Audio language
. Press OK to confirm your
for analog channels, select
.
. For analog
Loading...
