Philips 55OLED803, 65OLED803 User Manual

www.philips.com/TVsupport

OLED803 series

User Manual

55OLED803 65OLED803

1 Setting Up 4

1.1 Read Safety 4

1.2 TV Stand and Wall Mounting 4

1.3 Tips on Placement 4

1.4 Power Cable 4

1.5 Antenna Cable 5

2 Remote Control 6

2.1 Key overview 6

2.2 Pair Your Remote Control to TV 7

2.3 Voice search 7

2.4 IR Sensor 8

2.5 Batteries 8

2.6 Cleaning 8

3 Switching On and Off 9

3.1 On or Standby 9

3.2 Keys on TV 9

4 Channels 10

4.1 Channel Lists 10

4.2 Channel List sorting 10

4.3 Watching channels 10

4.4 Favourite Channels 13

4.5 Text / Teletext 14

4.6 Interactive TV 15

5 Channel Installation 16

5.1 Antenna Installation 16

5.2 Channel List Copy 18

6 Connect Devices 20

6.1 About Connections 20

6.2 Home Theatre System - HTS 21

6.3 Smartphones and Tablets 21

6.4 Blu-ray Disc Player 21

6.5 DVD Player 22

6.6 Bluetooth 22

6.7 Headphones 22

6.8 Game Console 23

6.9 USB Hard Drive 23

6.10 USB Keyboard 24

6.11 USB Flash Drive 24

6.12 Photo Camera 24

6.13 Camcorder 25

6.14 Computer 25

7 Connect your Android TV 26

7.1 Network and Internet 26

7.2 Google Account 28

7.3 Philips App Gallery 28

8 Apps 30

8.1 About Apps 30

8.2 Google Play 30

8.3 App Gallery 31

8.4 Start or Stop an App 31

8.5 Lock Apps 31

8.6 Manage Apps 33

8.7 Storage 33

9 Internet 34

9.1 Start Internet 34

9.2 Options on Internet 34

10 TV Menu 35

10.1 About TV Menu 35

10.2 Open TV Menu 35

11 Sources 36

11.1 Switch to a device 36

11.2 Options for a TV Input 36

11.3 Device Name and Type 36

11.4 Rescan Connections 36

12 Networks 38

12.1 Network 38

12.2 Bluetooth 38

13 Settings 39

13.1 Picture 39

13.2 Sound 43

13.3 Ambilight Settings 44

13.4 Eco Settings 46

13.5 General Settings 46

13.6 Clock, Region, and Language Settings 48

13.7 Android Settings 49

13.8 Universal Access Settings 49

13.9 Lock Settings 49

14 Videos, Photos and Music 51

14.1 From a Computer or NAS 51

14.2 Favourites Menu 51

14.3 Most Popular Menu and Last Played Menu 51

14.4 From a USB Connection 51

14.5 Play your Videos 51

14.6 View your Photos 52

14.7 Play your Music 53

15 TV Guide 55

15.1 What You Need 55

15.2 TV Guide Data 55

15.3 Using the TV Guide 55

16 Recording and Pause TV 57

16.1 Recording 57

16.2 Pause TV 58

17 Smartphones and Tablets 60

17.1 Philips TV Remote App 60

17.2 Google Cast 60

17.3 AirPlay 60

17.4 MHL 60

18 Games 61

18.1 What You Need 61

18.2 Gamepads 61

18.3 Play a Game 61

19 Ambilight 62

19.1 Ambilight Style 62

19.2 Ambilight Off 62

19.3 Ambilight Settings 62

19.4 Lounge Light Mode 63

20 Top Picks 64

20.1 About Top Picks 64

20.2 Now on TV 64

20.3 TV on Demand 64

20.4 Video on Demand 65

20.5 Freeview On Demand 65

21 Home Menu 67

21.1 About the Home Menu 67

21.2 Open the Home Menu 67

21.3 Restricted Profile 67

22 Netflix 68 23 Software 69

23.1 Update Software 69

23.2 Software Version 69

23.3 Automatic Software Update 69

23.4 Open Source Software 70

23.5 Open Source License 70

23.6 Announcements 70

24 Specifications 71

24.1 Environmental 71

24.2 Power 71

24.3 Operating System 71

24.4 Reception 71

24.5 Display Type 71

24.6 Display Input Resolution 72

24.7 Connectivity 72

24.8 Dimensions and Weights 72

24.9 Sound 72

24.10 Multimedia 72

25 Help and Support 74

25.1 Register your TV 74

25.2 Using Help 74

25.3 Troubleshooting 74

25.4 Online Help 76

25.5 Support and Repair 77

26 Safety and Care 78

26.1 Safety 78

26.2 Screen Care 79

27 Terms of Use 80

27.1 Terms of Use - TV 80

27.2 Terms of Use - Smart TV 80

27.3 Terms of Use - Philips App Gallery 80

28 Copyrights 81

28.1 MHL 81

28.2 HDMI 81

28.3 Dolby Audio 81

28.4 DTS-HD Premium Sound ™ 81

28.5 Wi-Fi Alliance 81

28.6 Kensington 81

28.7 Other Trademarks 81

29 Disclaimer regarding services and/or software offered by third parties 83

Index 84

Setting Up

1.1

Read Safety

TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

Read the safety instructions first before you use the TV.

To read the instructions, in Help, press the colour key  Keywords and look up Safety Instructions.

1.2

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

1.3

Tips on Placement

• Position the TV where light does not shine directly on the screen.

• Dim lighting conditions in the room for best Ambilight effect.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

• When wall mounted, position the TV up to 15 cm away from the wall.

Note: Please keep the TV away from dust-producing

sources such as stoves. It is suggested to clean the dust regularly to avoid getting dust into the TV.

1.4

• 55OLED803

VESA MIS-F 300x300, M6 (min.: 10mm, max.:15mm)

• 65OLED803

VESA MIS-F 300x300, M6 (min.: 10mm, max.:15mm) Preparation

First remove the 4 plastic screw caps out of the threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESA-compliant bracket, go about 10mm deep inside the threaded bushes of the TV.

Caution

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The

Power Cable

• Insert the power cable into the POWER connector on the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

For more information, in Help, press the colour key  Keywords and look up Switching On for more information on switching the TV on or off.

1.5

Antenna Cable

Insert the antenna plug firmly into the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Remote Control

2.1

Key overview

Top

1 -  Standby / On

To switch the TV on or back to Standby.

2 - VOICE microphone 3 -  LIST

To open or close the channel list. 4 -  AMBILIGHT

To select one of the Ambilight style. 5 -  TV GUIDE

To open or close the TV Guide. 6 -  SETTINGS

• To open the quick settings menu.

• To pair the remote control to the TV.

7 -  TOP PICKS To open the menu with recommended programmes, Video on Demand (Rental Videos) or Online TV (Catch Up TV). If available.

1 -  TV Menu To open the TV Menu with typical TV functions.

2 -  SOURCES To open or close the Sources menu.

3 -  INFO To open or close programme info.

4 -  BACK

• To switch back to the previous channel you selected.

• To return to previous menu. 5 -     Colour keys

Direct selection of options. 6 -  EXIT

To switch back to watching TV. 7 -  OPTIONS

To open or close the options menu. 8 - OK key

To confirm a selection or setting. 9 - Arrow / navigation keys

To navigate up, down, left or right. 10 -  HOME

To open the Home menu.

8 -  VOICE To start speaking your voice search.

Middle

Bottom

1 -  To open the Netflix App directly.

2 -  Volume

To adjust the volume level.

When you started the initial TV installation, the TV invited you to long press the PAIR key, and by doing so, the pairing was done.

Note: 1 - Once the remote control has entered pairing

mode successfully, the blue LED indicator ring around the microphone on the front side of the remote control starts blinking. 2 - The remote control must be kept close to the TV (within 1m distance) during pairing in order to ensure success. 3 - If the TV does not launch the voice search field when press VOICE, pairing was unsuccessful. 4 - It is advisable to wait until the set has fully started up and launched all background processes before pairing mode is entered as the toast message containing further instructions may appear too late, thereby negatively impacting the pairing procedure.

Pairing or pairing again

If the pairing with the remote control was lost, you can pair the TV with the remote control again.

3 - Number keys To select a channel directly.

4 - SUBTITLE To switch Subtitles on, off or on during mute.

5 - Playback and Record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to start recording 6 -  Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext.

7 -  Mute To mute the sound or to restore it.

8 - TEXT To open or close Text/Teletext.

2.2

Pair Your Remote Control to TV

This remote control uses both Bluetooth and IR (infrared) to send its commands to the TV.

• You can use this remote control via IR (infrared) for most operations.

• To use advanced operation like voice search and remote control keyboard, you need to pair (link) the TV with the remote control.

You can simply long press the PAIR key (approximate for 3 seconds) for pairing.

Alternatively, go  Settings > All settings > Wireless

and network > Remote control > Pair remote control, then follow the on-screen instructions.

A message appears when the pairing is successful.

Remote Control Software  Settings > All settings > Wireless and

network > Remote control > Current software info

Once the remote control is paired, you can check the current remote control software version.

 Settings > All settings > Wireless and

network > Remote control > Update remote control software

Check available remote control software for updates.

2.3

Voice search

You can search for videos, music or anything else on the Internet by simply using your voice. You can speak into the microphone on the remote control.

You need to pair the remote control to the TV before use voice search.

To use Voice... 1 - Press and hold VOICE on remote control, the

blue light on the remote control lights up and the search field opens, the microphone is active. 2 - Speak out what you are looking for with clear pronunciation. You can speak for 10 seconds before

the microphone switches off. It might take some time for the results to appear. 3 - In the list of search results, you can select the item you want.

Set the language you like to use with voice interaction

 Settings > All settings > Android settings > Preferences > Speech

2.4

IR Sensor

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

 Warning

Do not put any objects in front of IR sensor of the TV, it may block the IR signal.

2.5

Batteries

If the TV does not react on a key press on the remote control, the batteries might be empty.

To replace the batteries, open the battery compartment on the keyboard side of the remote control.

1 - Use a small coin or other small, blunt object and press the rectangular shaped release button to open the battery lid. 2 - Replace the old batteries with 2 type AA-LR6-1.5V batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and slide it back until it clicks.

• Remove the batteries if you are not using the remote control for a long time.

• Safely dispose of your old batteries according to the end of use directions.

2.6

Cleaning

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

3.2

Switching On and Off

3.1

On or Standby

Make sure the TV is connected to the mains AC power. Connect the supplied power cord to the AC in connector at the back of the TV. The indicator light at the bottom of the TV lights up.

Switch on

Press  on the remote control to switch the TV on. Alternatively, press  HOME. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu.

2 - Press left or right to select  Volume,  Channel or  Sources. Select  Demo, to start

a demo movie. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to start the demo movie. 4 - The menu will disappear automatically.

To switch the TV on standby, select  and press the joystick key.

In standby mode, the TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

Channels

4.1

Channel Lists

Search for a Channel

You can search for a channel to find it in a long list of channels.

About Channel Lists

After a channel installation, all channels appear on the channel list. Channels are shown with their name and logo if this information is available.

With a channel list selected, press the arrows  (up) or  (down) to select a channel, then press OK to watch the selected channel. You only tune to the channels in that list when using   or   keys.

Channel icons

After an Automatic Channel Update of the channel list, newly found channels are marked with a  (star). If you lock a channel, it will be marked with a  (lock).

Radio stations

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel. A Cable (DVB-C) channel installation usually places radio stations from channel number 1001 onwards.

This TV can receive digital television standard DVB. TV may not work properly with some operators of digital television, non-compliance with requirements of the standard in full.

Open a Channel List

Next to the list with all channels, you can select a filtered list or you can select one of the favourite lists you created.

To open the current channel list…

1 - Press , to switch to TV. 2 - Press OK to open the current channel list. 3 - Press  BACK to close the channel list.

To search for a channel…

1 - Press . 2 - Press OK to open the current channel list. 3 - Press  OPTIONS. 4 - Select Select Channel List and press OK. 5 - Select Filter Antenna Channels and press OK. 6 - Select Search Channel and press OK to open

a text field. You can use the remote control keyboard (if available) or the on-screen keyboard to enter text. 7 - Enter a number, a name or part of a name and select Apply and press OK. The TV will search for matching channel names in the list you selected.

Search results are listed as a channel list - see the list name at the top. The search results disappear once you select another channel list or close the list with search results.

4.2

Channel List sorting

You can do channel list sorting with all channels. You can set the channel list to show only TV channels or only Radio stations. For Antenna channels you can set the list to show the Free-to-Air or the Scrambled channels.

To set a filter on a list with all channels…

1 - Press . 2 - Press OK to open the current channel list. 3 - Press  OPTIONS. 4 - Select Select Channel List and press OK. 5 - Select Filter Antenna Channels and press OK. 6 - In the Options menu, select the filter you want

and press OK to activate. The name of the filter appears as part of the channel list name on top of the channel list. 7 - Press  (left) to go back one step or press  to close the menu.

To select one of the channel lists… 1 - With a channel list open on screen,

press  OPTIONS.

2 - Select Select Channel List and press OK. 3 - In the list menu, select one of the available

channel lists and press OK. Alternatively, you can select the list name at the top

of the channel list and press OK to open the list menu.

4.3

Watching channels

Tune to a Channel

Parental Rating

To start watching TV channels, press . The TV tunes to the channel you last watched.

Switch Channels

To switch channels, press   or  . If you know the channel number, type in the number with the number keys. Press OK after you entered the number to switch immediately.

If the information is available from the Internet, the TV shows the current programme name and details followed by the next programme name and details.

Previous channel

To switch back to the previously tuned channel, press  BACK.

You can also tune to channels from a Channel List.

Lock a Channel

Lock and Unlock a Channel

To prevent children from watching a channel, you can lock a channel. To watch a locked channel, you must enter the 4 digit Child Lock PIN code first. You cannot lock programmes from connected devices.

To lock a channel…

To prevent children from watching a programme not suitable for their age, you can set an age rating.

Digital channels can have their programmes age rated. When the age rating of a programme is equal to or higher than the age you have set as age rating for your child, the programme will be locked. To watch a locked programme, you must enter the Parental Rating code first.

To set an age rating…

1 - Press , select All Settings and press OK. 2 - Select Child Lock > Parental Rating and

press OK. 3 - Enter a 4-digit Child lock code. If you did not set a code yet, select Set Code in Child Lock. Enter a 4-digit Child lock code and confirm. Now you can set an age rating. 4 - Back in Parental Rating, select the age and press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.

To switch off the parental age rating, select None. However, in some countries you must set an age rating.

For some broadcasters/operators, the TV only locks programmes with a higher rating. The parental age rating is set for all channels.

1 - Press . 2 - Press OK to open the channel list. If necessary

change the channel list.

3 - Select the channel you want to lock. 4 - Press  OPTIONS and select Lock

Channel and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it. A locked channel is marked with a  (lock). 6 - Press  (left) to go back one step or press  BACK to close the menu.

To unlock a channel…

1 - Press . 2 - Press OK to open the channel list. If necessary

change the channel list.

3 - Select the channel you want to unlock. 4 - Press  OPTIONS and select Unlock

Channel and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it. 6 - Press  (left) to go back one step or

press  BACK to close the menu. If you lock or unlock channels in a channel list, you

only have to enter the PIN code just once until you close the channel list.

For more information, in Help, press the colour key  Keywords and look up Child Lock for more information.

Channel Options

Open Options

While watching a channel, you can set some options. Depending on the type of channel you are watching

(analogue or digital) or depending on the TV settings you made, some options are available.

To open the options menu…

1 - While watching a channel, press  OPTIONS. 2 - Press  OPTIONS again to close.

Subtitles

Switch On

Digital broadcasts can have subtitles for their programmes.

To show the subtitles… Press SUBTITLE. You can switch subtitles On or Off. Alternatively

you can select Automatic.

Automatic

If language information is part of the digital broadcast and the broadcasted programme is not in your language (the language set on TV), the TV can show subtitles automatically in one of your preferred subtitle languages. One of these subtitle languages must also be part of the broadcast.

You can select your preferred subtitle languages in Subtitle Language.

Subtitles from Text

If you tune to an analogue channel, you need to make the subtitles available for each channel manually.

1 - Switch to a channel and press TEXT to open Text.

2 - Enter the page number for subtitles, usually 888. 3 - Press TEXT again, to close Text.

Audio Language

Preferred Audio Language

A digital broadcast can offer several audio languages (spoken languages) for a programme. You can set a preferred primary and secondary audio language. If audio in one of these languages is available, the TV will switch to the audio language.

To set the primary and secondary audio language…

1 - Press , select All Settings and press OK. 2 - Select Region and Language and

select Languages > Primary Audio or Secondary Audio.

3 - Select the language you need and press OK. 4 - Press  (left) to go back one step or

press  BACK to close the menu.

If you select On in the Subtitle menu when watching this analogue channel, subtitles will be shown if available.

To know if a channel is analogue or digital, switch to the channel and open Information in  OPTIONS.

Subtitle Language

Preferred Subtitle Languages

A digital broadcast can offer several subtitle languages for a programme. You can set a preferred primary and secondary subtitle language. If subtitles in one of these languages are available, the TV will show the subtitles you selected.

To set the primary and secondary subtitle language…

1 - Press , select All Settings and press OK. 2 - Select Region and

Language > Languages > Primary Subtitles or Secondary Subtitles.

3 - Select the language you need and press OK. 4 - Press  (left) to go back one step or

press  BACK to close the menu.

Select a Subtitle Language

If none of the preferred subtitle languages are available, you can select another subtitle language if available. If no subtitle languages are available, you cannot select this option.

To select a subtitle language when none of your preferred languages are available…

1 - Press  OPTIONS. 2 - Select Subtitle Language and select one of the

languages as subtitles temporarily.

Select an Audio Language

If none of the preferred audio languages are available, you can select another audio language if available. If no audio languages are available, you cannot select this option.

To select an audio language when none of your preferred languages are available…

1 - Press  OPTIONS. 2 - Select Audio Language and select one of the

languages as audio temporarily.

Programme Info View programme details

To call up the details of the selected programme…

1 - Tune to the channel. 2 - Press  OPTIONS, select Programme Info and

press OK. 3 - To close this screen, press OK.

Alternatively, you can directly press  INFO to access the information of now and next programmes. On Programme Info, press the colour key  SCHEDULED to enter the scheduled

recording list, or repeatedly press  (right) to enter the TV Guide.

Mono / Stereo

You can switch the sound of an analogue channel to Mono or Stereo.

To switch to Mono or Stereo…

1 - Tune to an analoge channel. 2 - Press  OPTIONS, select Mono/Stereo and

press  (right).

3 - Select Mono or Stereo and press OK. 4 - Press  (left) to go back one step or

press  BACK to close the menu.

4.4

Favourite Channels

About Favourite Channels

In a favourite channel list, you can collect the channels you like.

You can create 4 different lists of favourite channels for easy channel zapping. You can name each Favourites List individually. Only in a Favourites List you can reorder channels.

With a Favourites List selected, press the arrows  (up) or  (down) to select a channel, then press OK to watch the selected channel. You only tune to the channels in that list when using   or   keys.

Add a Range of Channels

To add a consecutive range of channels to a Favourites List in one go, you can use Select Range.

To add a range of channels… 1 - Open the Favourites List where you want to add a

range of channels. 2 - Press  OPTIONS, select Select Range and press OK. 3 - In the list at the left select the first channel of the range you want to add and press OK. 4 - Press  (down) to select the last channel of the range you want to add. The channels are marked at the left. 5 - Press OK to add this range of channels and confirm.

You can also start creating a Favourites List from

Select Range.

Rename a Favourites List

Create a Favourites List

To create a favourite channels list…

1 - Press , to switch to TV. 2 - Press OK to open the current channel list. 3 - Press  OPTIONS. 4 - Select Create Favourites List and press OK. 5 - In the list at the left, select a channel you want as

a favourite and press OK. Channels come in the list at the right in the order you add them. To undo, select the channel in the list at the left and press OK again. 6 - If necessary, you can go on selecting and adding channels as favourites. 7 - To finish adding channels, press  BACK.

The TV will ask to rename the Favourites List. You can use the on-screen keyboard.

1 - Use the on-screen keyboard to delete the current name and enter a new name. 2 - When done, select Close and press OK.

You can only rename a Favourites List. To rename a Favourites List…

1 - Open the Favourite List you want to rename. 2 - Press  OPTIONS, select Rename Favourites

List and press OK.

3 - Use the on-screen keyboard to delete the current name and enter a new name.

4 - When done, select Close and press OK. 5 - Press  BACK to close the channel list.

Remove a Favourites List

You can only remove a Favourites List. To remove a Favourites List…

1 - Open the Favourites List you want to remove. 2 - Press  OPTIONS, select Remove Favourites

List and press OK.

3 - Confirm to remove the list. 4 - Press  BACK to close the channel list.

The TV will switch to the newly created Favourites List.

You can add a range of channels in one go or start a Favourites List by duplicating the channel list with all channels and removing the channels you do not want.

The channels in the Favourites List are renumbered.

Reorder Channels

Only in a Favourites List you can change the sequence of channels (reorder).

To change the sequence of channels…

1 - Open the Favourites List you want to reorder. 2 - Press  OPTIONS, select Reorder

Channels and press OK.

3 - In the Favourites List, select the channel you want to reorder and press OK.

4 - With the  (up) or  (down) keys move the channel where you want it.

5 - Press OK to confirm the new location. 6 - You can reorder channels with the same method

until you close the Favourites List with the  BACK key.

Favourites List on TV Guide

You can link the TV Guide for your Favourite List.

1 - While watching a TV channel, press  LIST >  OPTIONS > Select channel List.

2 - Select a Favourites List and press OK. 3 - Press  TV GUIDE to open it.

With the TV Guide you can view a list of the current and scheduled TV programmes of your favourite channels. Along with your favourite channels, the first 3 most used channels from the broadcasters’ default list will be appended after your favourite channels for your preview. You need to add these channels into your favourite list to enable its operation (refer to "TV Guide" chapter).

On each page of TV Guide, there is a "Did you know" grid inserted on your favourite channel list. The "Did you know"-channel provides useful tips to improve the way you use your TV.

4.5

Text / Teletext

The TV makes a list of the last 10 Text pages you opened. You can easily reopen them again in the Favourite Text pages column.

1 - In Text, select  (heart) in the top left corner of the screen to show the column of favourite pages. 2 - Press  (down) or  (up) to select a page number and press OK to open the page. You can clear the list with the option Clear Favourite

Pages. Search Text

You can select a word and scan Text for all occurences of this word.

1 - Open a Text page and press OK. 2 - Select a word or number with the arrow keys. 3 - Press OK again to jump immediately to the next

occurence of this word or number. 4 - Press OK again to jump to the subsequent occurence. 5 - To stop searching, press  (up) until nothing is selected.

Text from a connected device

Some devices that receive TV channels can also offer Text. To open Text from a connected device . . .

1 - Press  SOURCES, select the device and press OK. 2 - While watching a channel on the device, press  OPTIONS, select Show Device Keys and select the  key and press OK.

3 - Press  BACK to hide the device keys. 4 - To close Text, press  BACK again.

Digital Text (UK only)

Text Pages

To open Text/Teletext press TEXT, while you are watching TV channels. To close Text, press TEXT again.

Select a Text page

To select a page . . .

1 - Enter the page number with the number keys. 2 - Use the arrow keys to navigate. 3 - Press a colour key to select a colour-coded

subject at the bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The subpage numbers are shown on a bar next to the main page number. To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text. To open T.O.P. Text pages within Text, press  OPTIONS and select T.O.P. Overview.

Favourite pages

Some digital broadcasters offer dedicated Digital Text or interactive TV on their digital TV channels. This includes normal Text using the number, colour and arrow keys to select and navigate.

To close Digital Text, press  BACK. * The teletext can only be reached when the channels

are installed directly on the TV’s internal tuner and the set is on TV mode. If a set-top box is being used, the teletext will be unavailable via TV. In that case, the set-top box’s teletext can be used instead.

Text Options

In Text/Teletext, press  OPTIONS to select the following…

• Freeze page To stop the automatic rotation of subpages.

• Dual screen / Full screen To show the TV channel and Text alongside each other.

• T.O.P. overview To open T.O.P. Text.

• Enlarge To enlarge the Text page for comfortable reading.

• Reveal To unhide hidden information on a page.

• Cycle subpages To cycle subpages when these are available.

• Hide/Show Favourite Pages To hide or show the list of favourite pages.

• Clear Favourite Pages To clear the list of favourite pages.

• Language To switch the group of characters that Text uses to display correctly.

• Text 2.5 To activate the Text 2.5 for more colours and better graphics.

Broadcasters use various interactive TV systems : HbbTV (Hybrid Broadcast Broadband TV) or iTV (Interactive TV - MHEG). Interactive TV is sometimes referred to as Digital Text or Red button. But each system is distinct.

Visit the broadcaster's Internet website for more information.

What You Need

Interactive TV is only available on digital TV channels. To enjoy the full benefits of Interactive TV, you need a high-speed (broadband) Internet connection to the TV.

HbbTV

Text Setup

Text language

Some digital TV broadcasters have several Text languages available. To set your primary and secondary Text language . . .

1 - Press , select All Settings and press OK. 2 - Select Region and Language and

press  (right) to enter the menu.

3 - Select Language > Primary Text or Secondary Text and press OK.

4 - Select your preferred Text languages. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Text 2.5

If available, Text 2.5 offers more colours and better graphics. Text 2.5 is activated as a standard factory setting. To switch off Text 2.5…

1 - Press TEXT. 2 - With Text/Teletext open on screen,

press  OPTIONS.

3 - Select Text 2.5 > Off and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

4.6

If a TV channel offers HbbTV pages, you must first switch on HbbTV in the TV settings to view the pages.

 Settings > All settings > General settings > Advanced > HbbTV > On.

Use iTV

Open iTV pages

Most channels that offer HbbTV or iTV invite you to press the colour key  (red) or OK key to open their interactive programme.

Navigate iTV pages

You can use the arrow and colour keys, the number keys and the  BACK key to navigate the iTV pages. You can use the  (Play),  (Pause) and  (Stop) keys to watch videos within iTV pages.

Digital Text (UK only)

To open Digital Text, press TEXT. To close, press  BACK .

Close iTV pages

Most iTV pages inform you which key to use to close. To force an iTV page to close, switch to the next TV channel and press  BACK.

Interactive TV

About iTV

With interactive TV, some digital broadcasters combine their normal TV programme with information or entertainment pages. On some pages, you can respond to a programme or vote, do online shopping or pay for a video-on-demand programme.

HbbTV, MHEG, . . .

Channel Installation

5.1

Antenna Installation

Update Channels

4 - Select Search for Channels and press OK. 5 - Select Start and press OK. 6 - Select Update Digital Channels,

select Next and press OK. 7 - Select Start and press OK to update the digital channels. This can take a few minutes. 8 - Press  (left) to go back one step or press  BACK to close the menu.

Automatic Channel Update

If you receive digital channels, you can set the TV to automatically update these channels.

Once a day, at 6 AM, the TV updates the channels and stores new channels. New channels are stored in the Channels List and are marked with a  . Channels without a signal are removed. The TV must be in standby to automatically update channels. You can switch off Auromatic Channel Update.

To switch off the automatic update…

1 - Press , select All Settings and press OK. 2 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK.

3 - Enter your PIN code if necessary. 4 - Select Automatic Channel Update and

press OK.

5 - Select Off and press OK. 6 - Press  (left) to go back one step or

press  BACK to close the menu. When new channels are found or if channels are

updated or removed, a message is shown at TV start up. To avoid this message to appear after every channel update, you can switch it off.

To switch off the message…

1 - Press , select All Settings and press OK. 2 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK.

3 - Enter your PIN code if necessary. 4 - Select Channel Update Message and press OK. 5 - Select Off and press OK. 6 - Press  (left) to go back one step or

press  BACK to close the menu.

Reinstall Channels

Reinstall All Channels

You can reinstall all channels and leave all other TV settings untouched.

If a PIN code is set, you will need to enter this code before you can reinstall channels.

To reinstall channels…

1 - Press , select All Settings and press OK. 2 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK.

3 - Enter your PIN code if necessary. 4 - Select Search for Channels and press OK. 5 - Select Start and press OK. 6 - Select Reinstall Channels, select Next and

press OK. 7 - Select the country where you are now and press OK.

8 - Select Next and press OK. 9 - Select the type of installation you want, Antenna

(DVB-T) or Cable (DVB-C) and press OK.

8 - Select Next and press OK. 11 - Select the type of channels you want, Digital

and Analogue Channels or Only Digital Channels and press OK.

8 - Select Next and press OK. 13 - Select Start and press OK to update the

digital channels. This can take a few minutes. 14 - Press  (left) to go back one step or press  BACK to close the menu.

Reinstall TV

In certain countries, the Automatic channel update is done while watching TV or on any moment when the TV is in standby.

Manual Channel Update

You can always start an channel update yourself. To start a channel update manually…

1 - Press , select All Settings and press OK. 2 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK. 3 - Enter your PIN code if necessary.

You can redo a full TV installation. The TV is completely reinstalled.

To redo a full TV installation…

1 - Press , select All Settings and press OK. 2 - Select General Settings > Reinstall TV and

press OK.

3 - Enter your PIN code if necessary. 4 - Select Yes and press OK to confirm. 5 - The TV will reinstall completely. All settings will

be reset and installed channels will be replaced. The installation can take a few minutes. 6 - Press  (left) to go back one step or

press  BACK to close the menu.

DVB Settings

Network Frequency Mode

Reception Quality

You can check the quality and signal strength of a digital channel. If you have your own antenna, you can reposition the antenna to try and improve the reception.

If you intend to use the fast Quick Scan method in Frequency Scan to search for channels, select Automatic. The TV will use 1 of the predefined network frequencies (or HC - homing channel) as used by most cable operator in your country.

If you received a specific network frequency value to search for channels, select Manual.

Network Frequency

With the Network Frequency Mode set to Manual, you can enter the network frequency value received from your cable operator here. To enter the value, use the number keys.

Frequency Scan

Select the method of searching for channels. You can select the faster Quick Scan method and use the predefined settings used by most cable operator in your country.

To check the reception quality of a digital channel…

1 - Tune to the channel. 2 - Press , select All Settings and press OK. 3 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK. Enter your PIN code if necessary.

4 - Select Digital: Reception Test and press OK. 5 - Select Search and press OK. The digital

frequency is shown for this channel. 6 - Select Search again and press OK to check the signal quality of this frequency. The test result is shown on screen. You can reposition the antenna or check the connections to possibly improve the reception. 7 - You can also change the frequency yourself. Select the frequency number one by one and use the  (up) or  (down) keys to change the value. Select Search and press OK to test the reception again. 8 - Press  (left) repeatedly if necessary, to close the menu.

If this results in having no channels installed or if some channels are missing, you can select the extended Full Scan method. This method will take more time to search for and install channels.

Frequency Step Size

The TV searches for channels in steps of 8MHz. If this results in having no channels installed or if

some channels are missing, you can search in smaller steps of 1MHz. Using the 1MHz steps will take more time to search for and install channels.

Digital Channels

If you know your cable operator is not offering digital channels, you can skip searching for digital channels.

Analogue Channels

If you know your cable operator is not offering analogue channels, you can skip searching for analogue channels.

Manual Installation

Analogue TV channels can be manually installed, channel by channel.

To install analogue channels manually…

1 - Press , select All Settings and press OK. 2 - Select Channels > Antenna/Cable Installation

or Antenna Installation and press OK. Enter your PIN code if necessary. 3 - Select Analogue: Manual Installation and press OK.

• System To set up the TV system, select System. Select your country or the part of the world where you are now and press OK.

• Search Channel To find a channel, select Search Channel and press OK. You can enter a frequency yourself to find a channel or let the TV search for a channel. Press  (right) to select Search and press OK to search for a channel automatically. The found channel is shown on screen and if the reception is poor, press Search again. If you want to store the channel, select Done and press OK.

• Store You can store the channel on the current channel number or as a new channel number.

Select Store Current Channel or Store as New Channel and press OK. The new channel number is

shown briefly. You can redo these steps until you have found all

available analogue TV channels.

5 - Select Copy to USB and press OK. You might be asked to enter the Child Lock PIN code to copy the channel list. 6 - When copying is done, unplug the USB flash drive. 7 - Press  (left) repeatedly if necessary, to close the menu.

5.2

Channel List Copy

Introduction

Channel List Copy is intended for dealers and expert users.

With Channel List Copy, you can copy the channels installed on one TV onto another Philips TV of the same range. With Channel List Copy, you avoid the time-consuming channel search by uploading a predefined channel list on a TV. Use a USB flash drive of minimum 1 GB.

Conditions

• Both TVs are from the same year range.

• Both TVs have the same hardware type. Check the hardware type on the TV type plate on the back of the TV.

• Both TVs have compatible software versions.

Current channel version

To check the current version of the channel list…

1 - Press , select All Settings and press OK. 2 - Select Channels, select Channel List Copy,

select Current Version and press OK.

3 - Press OK to close. Current software version

To check the cuurent version of the TV software…

1 - Press , select All Settings and press OK. 2 - Select Update Software and press  (right) to

enter the menu.

3 - Select Current Software Info and press OK. 4 - The version, release notes and creation date are

shown. Also, the Netflix ESN Number is shown if available. 5 - Press  (left) repeatedly if necessary, to close the menu.

Now you can upload the copied channel list onto another Philips TV.

Channel List Version

Check the current version of the channel list...

1 - Press , select All Settings and press OK. 2 - Select Channels and press  (right) to enter

the menu.

3 - Select Channel List Copy and select Current Version, then press OK.

4 - Press  (left) repeatedly if necessary, to close the menu.

Upload a Channel List

To not Installed TVs

Depending on whether your TV is already installed or not, you must use a different method to upload a channel list.

To a TV that is not yet installed

1 - Plug in the power plug to start the installation and select language and country. You can skip the channel search. Finish the installation. 2 - Plug in the USB flash drive that holds the channel list of the other TV. 3 - To start the channel list upload, press , select All Settings and press OK.

4 - Select Channels > Channel List Copy > Copy to TV and press OK. Enter your PIN code if

necessary. 5 - The TV notifies you if the channel list is copied to the TV successfully. Unplug the USB flash drive.

To Installed TVs

Copy a Channel List

To copy a channel list… 1 - Switch on the TV. This TV should have channels

installed.

2 - Plug in a USB flash drive. 3 - Press , select All Settings and press OK. 4 - Select Channels > Channel List Copy and

press OK.

Depending on whether your TV is already installed or not, you must use a different method to upload a channel list.

To an already installed TV

1 - Verify the country setting of the TV. (To verify this setting, see chapter Reinstall All Channels. Start this procedure until you reach the country setting. Press  BACK to cancel the installation.) If the country is correct continue with step 2. If the country is not correct, you need to start a

reinstallation. See chapter Reinstall All Channels and start the installation. Select the correct country and skip the channels search. Finish the installation. When done, continue with step 2. 2 - Plug in the USB flash drive that holds the channel list of the other TV. 3 - To start the channel list upload, press , select All Settings and press OK.

4 - Select Channels > Channel List Copy > Copy to TV and press OK. Enter your PIN code if

necessary. 5 - The TV notifies you if the channel list is copied to the TV successfully. Unplug the USB flash drive.

HDMI ARC

Connect Devices

6.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

Antenna port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

HDMI ports

HDMI Quality

All of the HDMI connections on the TV have HDMI ARC (Audio Return Channel).

If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.

HDMI MHL

With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.

The HDMI 1 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).

This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your mobile device will not be charging when the TV is on standby.

Inform yourself about what passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for TV signal.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

If a device connected with HDMI is not working correctly, check if a different HDMI Ultra HD setting can solve this problem. In Help, press the colour key  Keywords and look up HDMI Ultra HD.

Copy protection

HDMI cables support HDCP 2.2 (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

HDMI CEC - EasyLink

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

Connect HDMI CEC-compatible devices to your TV, you can operate them with the TV remote control.

EasyLink HDMI CEC must be switched on on the TV and the connected device.

Switch on EasyLink

 Settings > All settings > General settings > EasyLink > EasyLink > On.

send the sound of the TV picture to the Home Theatre System.

Audio to video synchronisation (sync)

Operate HDMI CEC-compatible devices with TV remote control

 Settings > All settings > General settings > EasyLink > EasyLink remote control > On.

Note:

• EasyLink might not work with devices from other brands.

• The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink. Example HDMI CEC branding names are property of their respective owners.

6.2

Home Theatre System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the Digital Out Format of the TV to Stereo.

Press  for All

Settings > Sound > Advanced > Digital Out Format .

No sound

If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an HDMI ARC connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections.

6.3

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Connect with HDMI

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to

Smartphones and Tablets

To connect a smartphone or tablet to the TV, you can use a wireless or wired connection.

Wireless

For a wireless connection, on your smartphone or tablet download the Philips TV Remote App from your favourite app store.

Wired

For a wired connection, use the HDMI 1 MHL connection on the back of the TV.

6.4

Blu-ray Disc Player

Use a High speed HDMI cable to connect the Bluray Disc player to the TV.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

In Help, press the colour key  Keywords and

look up EasyLink HDMI CEC for more information.

6.5

DVD Player

Use an HDMI cable to connect the DVD player to the TV.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

For more information on EasyLink, in Help, press the colour key  Keywords and look up EasyLink HDMI CEC.

and press OK. 5 - Select Start and press OK. Follow the instuctions on screen. You will pair the device with the TV and the TV will store the connection. You might need to unpair a paired device first if the maximum number of paired devices was reached.

6 - Select the type of device and press OK. 7 - Press  (left) repeatedly if necessary, to close

the menu. * Your TV doesn't support Bluetooth

subwoofer/speakers/headphones. ** HDMI connection is required for sound bar, speaker

and other audio device.

Y Pb Pr - Component Video is a high quality connection.

The YPbPr connection can be used for High Definition (HD) TV signals.

6.6

Bluetooth

Pairing a Device

Read the user manual of the device for specific information on pairing and on wireless range. Make sure the Bluetooth setting on TV is switched on.

Select a Device

To select a wireless device…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press OK. 3 - Select Bluetooth > Search for a device and

press OK. 4 - In the list, select the wireless device and press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.

Remove a Device

You can connect or disconnect a wireless Bluetooth device. You can also remove a wireless Bluetooth device. If you remove a Bluetooth device, the device will be unpaired.

To remove or disconnect a wireless device…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press OK. 3 - Select Bluetooth > Remove Bluetooth

device and press OK.

4 - In the list, select the wireless device and press OK.

5 - Select Disconnect or Remove and press OK. 6 - Select OK and press OK to confirm. 7 - Press  (left) repeatedly if necessary, to close

the menu.

Once a wireless gamepad is paired, you can use it. When a device is paired, you do not need to pair it again unless you remove the device.

To pair a bluetooth device with the TV… 1 - Switch on the bluetooth device and place it within

range of the TV.

2 - Press , select All Settings and press OK. 3 - Select Wireless and Networks and

press  (right) to enter the menu. 4 - Select Bluetooth > Search Bluetooth Device,

6.7

Headphones

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

To adjust the volume…

1 - Press , select Headphone Volume and press OK. 2 - Press the arrows  (up) or  (down) to adjust the value. 3 - Press  (left) repeatedly if necessary, to close the menu.

6.8

Game Console

HDMI

For best quality, connect the game console with a High speed HDMI cable to the TV.

Y Pb Pr

Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.

6.9

USB Hard Drive

What You Need

If you connect a USB Hard Drive, you can pause or record digital TV broadcasts (DVB broadcasts or similar).

press  (Pause). Trying to pause will start the formatting.

Follow the instructions on screen. When the USB Hard Drive is formatted, leave it

connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

Minimum Disk Space

• To Pause To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 4GB disk space.

• To Record To pause and record a broadcast, you need a minimum of 250GB disk space.

For more information on how to install a USB Hard Drive, in Help, press the colour key  Keywords and look up USB Hard Drive,

installation.

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

Formatting

Before you can pause or record a broadcast, or store apps, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive. If you want to record broadcasts with TV Guide data from the Internet, you must setup the Internet connection first before you install the USB Hard Drive.

Warning

* Connect the USB Hard Drive with size less than 2TB. To format a USB Hard Drive… 1 - Connect the USB Hard Drive to one of the USB

connections on the TV. Do not connect another USB device to the other USB ports when formatting. 2 - Switch on the USB Hard Drive and the TV.

3 - Select Recordings if you want to perform Pause TV and Recordings, otherwise, select Apps to store apps. Follow the instructions on screen.

4 - All files and data will be removed after formatting. 5 - When the USB Hard Drive is formatted, leave it

connected permanently.

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width

6.11

For more information, in Help, press the colour key  Keywords and look up Pause TV, Recording, or Apps.

6.10

USB Keyboard

Connect

Connect a USB keyboard (USB-HID type) to enter text on your TV.

Use one of the USB connections to connect.

Configure

Install the keyboard

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to

enter the menu. 3 - Select USB Keyboard Settings, and press OK to start the keyboard setup.

Special Keys

USB Flash Drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press  SOURCES and select USB.

To stop watching the USB flash drive content, press  EXIT or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher. You cannot play a native Ultra HD video on any of the USB connections.

Keys for entering text

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard layouts, if a secondary layout is set, press the Ctrl + Spacebar keys simultaneously.

Keys for apps and Internet pages

• Tab and Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

For more information on watching or playing content from a USB flash drive, in Help, press the colour key  Keywords and look up Photos, Videos and Music.

6.12

Photo Camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.

If the contents list does not appear automatically, press  SOURCES , and select USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

Ultra HD on USB

For more information on viewing photos, in Help, press the colour key  Keywords and look up Photos, Videos and Music.

6.13

Camcorder

6.14

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Ideal Setting

If you connect a computer, we advice you to give the connection, on which the computer is connected, the correct device type name in the Source menu. If you then switch to Computer in the Source menu, the TV is set to the ideal Computer setting automatically.

For best quality, use an HDMI cable to connect the camcorder to the TV.

To set the TV to the ideal setting…

1 - Press , select All Settings and press OK. 2 - Select Picture and press  (right) to enter the

menu.

3 - Select Advanced > Computer, and press OK. 4 - Select On or Off, and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Connect your Android TV

7.1

Network and Internet

devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Go to the router, press the WPS button and return to the TV within 2 minutes.

2 - Select Connect to make the connection. 3 - A message will be shown when the connection is

successful.

Make the Connection - WPS with PIN Code

Home Network

To enjoy the full capabilities of your Philips Android TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.

Connect to Network

Wireless Connection

What You Need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

Make the Connection Make the Connection - Wireless

 (TV menu) >  Settings > Wireless and Networks > Wired or Wi-Fi > Connect to Network > Wireless.

1 - In the list of found networks, select on your wireless network. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select Add New Network to enter the network name yourself. 2 - Depending on the type of router, enter your encryption key - WEP, WPA or WPA2. If you entered the encryption key for this network before, you can select OK to make the connection immediately. 3 - A message will be shown when the connection is successful.

 (TV menu) >  Settings > Wireless and Networks > Wired or Wi-Fi > Connect to Network > WPS with PIN Code.

If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Write down the 8-digit PIN code shown on screen and enter it in the router software on your PC. Consult the router manual on where to enter the PIN code in the router software.

2 - Select Connect to make the connection. 3 - A message will be shown when the connection is

successful.

Problems Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

Make the Connection - WPS

 (TV menu) >  Settings > Wireless and Networks > Wired or Wi-Fi > Connect to Network > WPS.

If your router has WPS, you can directly connect to the router without scanning for networks. If you have

In Help, press the colour key  Keywords and look up Troubleshooting for more information.

+ 60 hidden pages

Philips 55OLED803, 65OLED803 User Manual

Contents
