Philips 55BDL4031D User Guide

32BDL4031D 43BDL4031D 49BDL4031D 55BDL4031D

V1.00

www.philips.com/welcome

User Manual (English)

Safety Instructions

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those specied in this documentation may result in exposure to

shock, electrical hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your display:

Operation:

• Keep the display out of direct sunlight and away from stoves or any other heat sources.

• Remove any object that could fall into ventilation holes or prevent proper cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• When positioning the display, make sure the power plug and outlet are easily accessible.

• When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation.

• Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center.

• Do not subject the display to severe vibration or high impact conditions during operation.

• Do not knock or drop the display during operation or transportation.

• The eye bolt is for usage in short-time maintenance and installation. We suggest not to use the eye bolt for more than 1 hour. Prolong usage is prohibited. Please keep a clear safety area under the display while using the eye bolt.

Maintenance:

• To protect your display from possible damage, do not put excessive pressure on the LCD panel. When moving your display, grasp the frame to lift; do

not lift the display by placing your hand or ngers on the LCD panel.

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power is off. However, never use organic solvent, such as, alcohol, or ammonia-based liquids to clean your display.

• To avoid the risk of shock or permanent damage to the set, do not expose the display to dust, rain, water or an excessively moist environment.

• If your display becomes wet, wipe it with dry cloth as soon as possible.

• If a foreign substance or water gets in your display, turn the power off immediately and disconnect the power cord. Then remove the foreign substance or water, and send the unit to the maintenance center.

• Do not store or use the display in locations exposed to heat, direct sunlight or extreme cold.

• In order to maintain the best performance of your display and ensure a longer lifetime, we strongly recommend using the display in a location that falls within the following temperature and humidity ranges.

- Temperature: 0-40°C 32-104°F

- Humidity: 20-80% RH

• LCD panel temperature need to be 25 degrees Celsius at all time for better luminance performance.

IMPORTANT: Always activate a moving screen saver program when you leave your display unattended. Always activate a periodic screen refresh application if the unit will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging” or “ghost imaging”, on your screen. This is a well-known phenomenon in LCD panel technology. In most cases, the “burned in” or “after-imaging” or “ghost imaging” will disappear gradually over a period of time after the power has been switched off.

WARNING: Severe “burn-in” or “after-image” or “ghost image” symptoms will not disappear and cannot be repaired. This is also not covered under the terms of your warranty.

Service:

• The casing cover should be opened only by qualied service personnel.

• If there is any need for repair or integration, please contact your local service center.

• Do not leave your display under direct sunlight.

If your display does not operate normally, having followed the instructions set out in this document, please contact a technician or your local service center.

Stability Hazard.

The device may fall, causing serious personal injury or death. To prevent injury, this device must be securely attached to the oor/wall in accordance with

the installation instructions.

Read and follow these instructions when connecting and using your display:

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth when the power is off. However, never use alcohol, solvents or ammonia-based liquids.

• Consult a service technician if the display does not operate normally when you have followed the instructions in this manual.

• The casing cover should be opened only by qualied service personnel.

• Keep the display out of direct sunlight and away from stoves or any other heat sources.

• Remove any object that could fall into the vents or prevent proper cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• Keep the display dry. To avoid electric shock, do not expose it to rain or excessive moisture.

• When turning off the display by detaching the power cable or DC power cord, wait for 6 seconds before re-attaching the power cable or DC power cord for normal operation..

• To avoid the risk of shock or permanent damage to the set do not expose the display to rain or excessive moisture.

• When positioning the display, make sure the power plug and outlet are easily accessible.

• IMPORTANT: Always activate a screen saver program during your application. If a still image in high contrast remains on the screen for an extended period of time, it may leave an ‘after-image’ or ‘ghost image’ on the front of the screen. This is a well-known phenomenon that is caused by the shortcomings inherent in LCD technology. In most cases the afterimage will disappear gradually over a period of time after the power has been switched off. Be aware that the after-image symptom cannot be repaired and is not covered under warranty.

CAUTION

DOUBLE POLE/NEUTRAL FUSING

EU Declaration of Conformity

This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to

Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU), RoHS directive (2011/65/EU).

This product has been tested and found to comply with the harmonized standards for Information Technology Equipment, these harmonized standards

published under Directives of Ofcial Journal of the European Union.

ESD Warnings

When user close to the monitor may cause the equipment discharge and reboot to the display of main menu.

Warning:

This equipment is compliant with Class A of EN55032/CISPR 32. In a residential environment this equipment may cause radio interference.

iii

Federal Communications Commission (FCC) Notice (U.S. Only)

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

Use only an RF shielded cable that was supplied with the display when connecting this display to a computer device.

To prevent damage which may result in re or shock hazard, do not expose this appliance to rain or excessive moisture.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Envision Peripherals Inc. 490 N McCarthy Blvd, Suite #120 Milpitas, CA 95035 USA

Polish Center for Testing and Certication Notice

The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.

The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value

no larger than 16 amperes (A).

To completely switch off the equipment, the power supply cable must be removed from the power supply socket, which should be located near the equipment and easily accessible.

A protection mark “B” conrms that the equipment is in compliance with the protection usage requirements of standards PN-93/T-42107 and PN-89/

E-06251.

Electric, Magnetic and Electromagnetic Fields (“EMF”)

1. We manufacture and sell many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.

2. One of our leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products.

3. We are committed to develop, produce and market products that cause no adverse health effects.

4. We conrm that if its products are handled properly for their intended use, they are safe to use according to scientic evidence available today.

5. We play an active role in the development of international EMF and safety standards, enabling us to anticipate further developments in standardization for early integration in its products.

Information for U.K. only

WARNING - THIS APPLIANCE MUST BE EARTHED.

(B)

(A)

Important:

This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows:+

1. Remove fuse cover and fuse.

2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI approved type.

3. Ret the fuse cover.

If the tted plug is not suitable for your socket outlets, it should be cut off and an appropriate 3-pin plug tted in its place.

If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5A.

NOTE: The severed plug must be destroyed to avoid a possible shock hazard should it be inserted

into a 13A socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured in accordance with the following code:

BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN & YELLOW - “EARTH” (“E”)

1. The GREEN & YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E” or by the Earth symbol or coloured GREEN or GREEN & YELLOW.

2. The BLUE wire must be connected to the terminal which is marked with the letter “N” or coloured BLACK.

3. The BROWN wire must be connected to the terminal which marked with the letter “L” or coloured RED.

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead

- not simply over the three wires.

North Europe (Nordic Countries) Information

Placering/Ventilation

VARNING:

FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.

Placering/Ventilation

ADVARSEL:

SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE.

Paikka/Ilmankierto

VAROITUS:

SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA.

Plassering/Ventilasjon

ADVARSEL:

NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ.

China RoHS

根据中国大陆《电器电子产品有害物质限制使用管理办法》，以下部分列出了本产品中可能包含的有害物质的名称和含量。

有害物质

部件名称

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

外壳 ○ ○ ○ ○ ○ ○

液晶显示屏 × ○ ○ ○ ○ ○

电路板组件* × ○ ○ ○ ○ ○

电源适配器 × ○ ○ ○ ○ ○

电源线/连接线 × ○ ○ ○ ○ ○

遥控器 X ○ ○ ○ ○ ○

本表格依据SJ/T 11364 的规定编制。

*: 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。

上表中打“×”的部件，应功能需要，部分有害物质含量超出GB/T 26572规定的限量要求，但符合欧盟RoHS 法规要求（属于豁免部分）。

备注：上表仅做为范例，实际标示时应依照各产品的实际部件及所含有害物质进行标示。

環保使用期限

此標識指期限(十年)，電子電氣產品中含有的有害物質在正常使用的條件下不會發生外泄或突變，電子電氣產品用戶使用該電子電氣產品不會對環境造成嚴重污染或對其人身、財產造成嚴重損害的期限。

《废弃电器电子产品回收处理管理条例》提示性说明

为了更好地关爱及保护地球，当用户不再需要此产品或产品寿命终止时，请遵守国家废弃电器电子产品回收处理相关法律法规，将其交给当地具有国家认可的回收处理资质的厂商进行回收处理，不当利用或者处置可能会对环境和人类健康造成影响。

娤⌈ 㨢᳸$䵥ᵥ⍿Ʋ◦䏝㯹䉭❁ᳫ濕媣ᵥ⍿⊭侻󰵹廞ノ㒞䵽䏳ⴰㄮƲ◦店䢋⾃⁳᳉濕⊭侻斾堿䏦ヵ ⪷ⴰㄮ悅⊔⃅⩜⊭圊䕂㉨㑻Ʋ

限用物質及其化學符號

單元

鉛

(Pb)

汞

(Hg)

鎘

(Cd)

六價鉻

(Cr+6)

多溴聯苯

(PBB)

多溴二苯醚

(PBDE)

塑料外框 ○ ○ ○ ○ ○ ○

後殼 ○ ○ ○ ○ ○ ○

液晶面板－ ○ ○ ○ ○ ○

電路板組件－ ○ ○ ○ ○ ○

底座 ○ ○ ○ ○ ○ ○

電源線－ ○ ○ ○ ○ ○

其他線材－ ○ ○ ○ ○ ○

遙控器－ ○ ○ ○ ○ ○

喇叭（選配）－ ○ ○ ○ ○ ○

風扇（選配）－ ○ ○ ○ ○ ○

備考1.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考2.〝－〞係指該項限用物質為排除項目。

警語 : 使用過度恐傷害視力。

注意事項 :

(1) 使用30分鐘請休息10分鐘。

(2) 未滿2歲幼兒不看螢幕，2歲以上每天看螢幕不要超過1小時。

警告使用者 :

此為甲類資訊技術設備 , 於居住環境中使用時 , 可能會造成射頻擾動 , 在此種情況下 , 使用者會被要求採取某些適當的對策。

Turkey RoHS:

Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur

Ukraine RoHS:

Обладнання відповідає вимогам Технічного регламенту щодо обмеження використання деяких небезпечних речовин в електричному та електронному обладнанні, затвердженого постановою Кабінету Міністрів України від 3 грудня 2008 № 1057

vii

End-of-Life Disposal

Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of.

Please nd out about the local regulations on how to dispose of your old display from your local Philips dealer.

(For customers in Canada and U.S.A.)

This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional information on recycling contact www.eia.org (Consumer Education Initiative)

Waste Electrical and Electronic Equipment-WEEE

Attention users in European Union private households

This marking on the product or on its packaging illustrates that, under European Directive 2012/19/EU governing used electrical and

electronic appliances, this product may not be disposed of with normal household waste. You are responsible for disposal of this equipment through a designated waste electrical and electronic equipment collection. To determine the locations for dropping off such

waste electrical and electronic, contact your local government ofce, the waste disposal organization that serves your household or the

store at which you purchased the product.

Attention users in United States:

Please dispose of according to all Local, State and Federal Laws. For the disposal or recycling information, contact: www.mygreenelectronics.com or www.eiae.org.

End of Life Directives-Recycling

Your new Public Information Display contains several materials that can be recycled for new users.

Please dispose of according to all Local, State, and Federal laws.

ENERGY STAR is a program run by the U.S. Environmental Protection Agency (EPA) and U.S. Department of Energy (DOE) that promotes energy efciency.

This product qualies for ENERGY STAR in the “factory default” settings and this is the setting in which power savings will be achieved.

Changing the factory default picture settings or enabling other features will increase power consumption that could exceed the limits necessary to qualify for ENERGY STAR rating.

For more information on the ENERGY STAR program, refer to energystar.gov.

Restriction on Hazardous Substances statement (India)

This product complies with the “E-Waste (Management) Rules, 2016” CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical and Electronic

Equipment and their components or consumables or parts or spares do not contain Lead, Mercury, Cadmium, Hexavalent Chromium, polybrominated biphenyls and polybrominated diphenyl ethers beyond a maximum concentration value of 0.1% by weight in homogenous materials for lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers and of 0.01% by weight in homogenous materials for cadmium. except of exemptions set in Schedule 2 of the Rule.

E-Waste Declaration for India

This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment . The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about E -waste please visit http://www.india.philips.com/about/sustainability/recycling/index.page and to know where you can drop off your waste equipment for recycling in India please contact on below given contact details.

Helpline number: 1800-425-6396 (Monday to Saturday, 9 a.m. to 5:30 pm)

E-mail: india.callcentre@tpv-tech.com

viii

Batteries

Após o uso, as pilhas deverão ser entregues ao estabelecimento comercial

e/ou baterias

rede de assistência técnica autorizada.

For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in accordance with legislation.

Please contact your local authority for details on the collection and recycling schemes.

For Switzerland: The used battery is to be returned to the selling point.

For other non-EU countries: Please contact your local authority for correct method of disposal of the used battery.

According to EU directive 2006/66/EC, the battery can’t be disposed improperly. The battery shall be separated to collect by local service.

Information for EAC

Month and year of manufacturing please refer information in Rating label.

Name and location of manufacturer

Importer and information

ООО “Профтехника” Адрес: 3-й Проезд Марьиной рощи, 40/1 офис 1. Москва, 127018, Россия

Наименование организации: ООО “Профтехника” Адрес: 3-й Проезд Марьиной рощи, 40/1 офис 1. Москва, 127018, Россия Контактное лицо: Наталья Астафьева, +7 495 640 20 20 nat@profdisplays.ru

Table Of Contents

1. Unpacking and Installation .......................................................1

1.1. Transportation and Unpacking.............................................1

1.2. Package Contents ........................................................................2

1.3. Installation Notes .........................................................................2

1.4. Installing or removing the table stand (optional) .....3

1.5. Mounting on a Wall ....................................................................5

1.6. Mounting in Portrait Orientation ....................................... 7

1.7. Operating Instructions of Edge Alignment Kit ............8

2. Parts and Functions ...................................................................9

2.1. Control Panel .................................................................................9

2.2. Input/Output Terminals ..........................................................10

2.3. Remote Control ........................................................................ 13

3. Connecting External Equipment.......................................... 15

3.1. Connecting External Equipment (DVD/VCR/

VCD) ...............................................................................................15

3.2. Connecting a PC ....................................................................... 15

3.3. Connecting Audio Equipment ...........................................16

3.4. Connecting Multiple Displays in a Daisy-chain

Conguration .............................................................................. 16

3.5. IR connection .............................................................................. 17

3.6. IR Pass-through Connection ............................................... 18

4. Operation ................................................................................. 19

4.1. Watch the Connected Video Source ............................ 19

4.2. Change Picture Format ......................................................... 19

5. OSD Menu ............................................................................... 19

5.1. Navigating the OSD Menu ................................................19

5.2. OSD Menu Overview ........................................................... 19

6. Input Mode ............................................................................... 29

7. Pixel Defect Policy .................................................................. 31

7.1. Pixels and Sub-Pixels ...............................................................31

7.2. Types of Pixel Defects + Dot Denition .................... 31

7.3. Bright Dot Defects ...................................................................31

7.4. Dark Dot Defects.....................................................................32

7.5. Proximity of Pixel Defects ...................................................32

7.6. Pixel Defect Tolerances .........................................................32

7.7. MURA ............................................................................................. 32

8. Cleaning and Troubleshooting .............................................. 33

8.1. Cleaning ..........................................................................................33

8.2. Troubleshooting ......................................................................... 34

9. Technical Specications ......................................................... 36

1. Unpacking and Installation

1.1. Transportation and Unpacking

Notice for transportation

• Always keep the carton in a vertical position. Do NOT place the carton in any other direction.

• Do NOT place any object on the carton. • Do NOT apply shock/vibration to the product.

• Move the carton by stacker. • Do NOT drop the product. Strong impacts may

damage the components inside.

Before installing the display

• This product is packed in a carton, together with the standard accessories.

• Any other optional accessories will be packed separately.

• Move the display by at least two (2) adults.

• After opening the carton, ensure that the contents are complete and in good condition.

1.2. Package Contents

Please verify that you received the following items with your package content:

• LCD display

• Quick start guide

• Remote Control and AAA batteries

• Power cord

• RS232 cable

• RS232 daisy chain cable

• Logo

• Edge Alignment Kit-1: 2PCS

• Edge Alignment Kit-2: 1PCS

• Thumb Screw: 8PCS

* The supplied power cord varies depending on destination.

Power Cord

RS232 Cable

Quick start guide

NORMAL

FORMAT

SOURCE

INFOLIST

OPTIONSADJUST

VOL

ID SET ENTER

Remote Control

and AAA Batteries

RS232 Daisy Chain Cable

Logo Edge Alignment Kit-2 x 1Edge Alignment Kit-1 x 2Thumb Screw x 8

* Items may differ in different locations * Display design and accessories may differ from the images shown..

NOTES:

• For all other regions, apply a power cord that conforms to the AC voltage of the power socket and has been approved by and complies with the

safety regulations of the particular country (Type H05W-F, 2G or 3G, 0.75 or 1 mm2 should be used).

• Keep the packaging materials appropriately after unpacking the product.

1.3. Installation Notes

• Only use the power cable provided with this product. If an extension cord is required, please consult your service agent.

• The product should be installed on a at surface, or the product may tip over. Leave a space between the rear of the product and the wall for proper ventilation. Do not install the product in a kitchen, bathroom or a place exposed to moisture, failure to do so may shorten the life of the internal parts.

• Do not install the product where it is 3000m and higher in altitude. Failure to do so may result in malfunctions.

1.4. Installing or removing the table stand (optional)

Step 1- Place on the table

Take off the protective sheet which was wrapped around the display when it was packaged. Lay the protective sheet on the table, beneath the screen surface so as not to scratch the screen face.

Step 2- Fix the tube to the display (using M6xL41 screws)

Please refer to the following drawing to identify the position of screws.

32BDL4031D: Fasten the longest screw(M6x41.0mm) into Hole#1 and Hole#7 of tube to secure it to the display.

Step 3- Set up the stand (using thumb screws)

M6xL41 screws

Thumb screws

Longer portions should face the front

Table stand

To remove the table stands:

1. Power off the display.

2. Spread a protective sheet on a at surface.

3. Place the display face-down on the protective sheet.

4. Remove screws using a screwdriver and place them in a safe place for reuse.

Installing or removing the table stand (optional)

Step 1- Place on the table

Take off the protective sheet which was wrapped around the display when it was packaged. Lay the protective sheet on the table, beneath the screen surface so as not to scratch the screen face.

Step 2- Fix the tube to the display (using M6xL41 screws)

Please refer to the following drawing to identify the position of screws.

55BDL4031D: Fasten the longest screw(M6x41.0mm) into Hole#3 and Hole#13 of tube to secure it to the display. 49BDL4031D: Fasten the longest screw(M6x41.0mm) into Hole#4 and Hole#14 of tube to secure it to the display. 43BDL4031D: Fasten the longest screw(M6x41.0mm) into Hole#5 and Hole#15 of tube to secure it to the display.

Step 3- Set up the stand (using thumb screws)

M6xL41 screws

Thumb screws

Longer portions should face the front

Table stand

To remove the table stands:

1. Power off the display.

2. Spread a protective sheet on a at surface.

3. Place the display face-down on the protective sheet.

4. Remove screws using a screwdriver and place them in a safe place for reuse.

1.5. Mounting on a Wall

To mount this display on a wall, a standard wall-mounting kit (commercially available) is required. It is recommended that you use a mounting interface that complied with TUV-GS and /or UL1678 standard in North America.

32BDL4031D 43BDL4031D

Protective Sheet

VESA Grid

Table

VESA Grid

Table

49BDL4031D 55BDL4031D

Protective Sheet

VESA Grid

Protective Sheet

Table

1. Prepare a at and horizontal surface that is larger than the display and spread a thick protective sheet on it to facilitate your operation without scratching the screen.

2. Ensure you have all accessories for all types of mounting (wall mount, ceiling mount, table stand, etc).

3. Follow the instructions that came with the base mounting kit. Failure to follow the correct mounting procedures could result in damage to the equipment, or injury to the user or installer. The product warranty does not cover the damage caused by improper installation.

4. For the wall-mounting kit, use the M6 mounting screws (with a length 10 mm longer than the thickness of the mounting bracket) and tighten them securely.

5. The equipment and its associated mounting facilities still remain secure during the test. Use only the UL listed Wall Mount Bracket with a minimum

weight/load of the weight of the unit without base.

1.5.1. VESA Grid

32BDL4031D

43BDL4031D

49BDL4031D

55BDL4031D

200(H) x 200(V) mm

400(H) x 400(V) mm

1.5.2. Weight of the unit

32BDL4031D

43BDL4031D

49BDL4031D

55BDL4031D

6.15 kg

10.4 kg

14.8 kg

18.0 kg

+ 33 hidden pages
