Philips 55BDL3005X User Guide

Download

Page 1

BDL5588XC

55BDL3005X

V1.30

www.philips.com/welcome

User Manual (English)

Page 2

BDL5588XC/55BDL3005X

Safety Instructions

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those specied in this documentation may result in exposure to

shock, electrical hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your display:

Operation:

• Keep the display out of direct sunlight and away from stoves or any other heat sources.

• Remove any object that could fall into ventilation holes or prevent proper cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• When positioning the display, make sure the power plug and outlet are easily accessible.

• When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation.

• Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center.

• Do not subject the display to severe vibration or high impact conditions during operation.

• Do not knock or drop the display during operation or transportation.

Maintenance:

• To protect your display from possible damage, do not put excessive pressure on the LCD panel. When moving your display, grasp the frame to lift; do

not lift the display by placing your hand or ngers on the LCD panel.

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power is off. However, never use organic solvent, such as, alcohol, or ammonia-based liquids to clean your display.

• To avoid the risk of shock or permanent damage to the set, do not expose the display to dust, rain, water or an excessively moist environment.

• If your display becomes wet, wipe it with dry cloth as soon as possible.

• If a foreign substance or water gets in your display, turn the power off immediately and disconnect the power cord. Then remove the foreign substance or water, and send the unit to the maintenance center.

• Do not store or use the display in locations exposed to heat, direct sunlight or extreme cold.

• In order to maintain the best performance of your display and ensure a longer lifetime, we strongly recommend using the display in a location that falls within the following temperature and humidity ranges.

- Temperature: 0-40°C 32-104°F

- Humidity: 20-80% RH

IMPORTANT: Always activate a moving screen saver program when you leave your display unattended. Always activate a periodic screen refresh application if the unit will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging” or “ghost imaging”, on your screen. This is a well-known phenomenon in LCD panel technology. In most cases, the “burned in” or “after-imaging” or “ghost imaging” will disappear gradually over a period of time after the power has been switched off.

WARNING: Severe “burn-in” or “after-image” or “ghost image” symptoms will not disappear and cannot be repaired. This is also not covered under the terms of your warranty.

Service:

• The casing cover should be opened only by qualied service personnel.

• If there is any need for repair or integration, please contact your local service center.

• Do not leave your display under direct sunlight.

If your display does not operate normally, having followed the instructions set out in this document, please contact a technician or your local service center.

Page 3

BDL5588XC/55BDL3005X

Read and follow these instructions when connecting and using your display:

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth when the power is off. However, never use alcohol, solvents or ammonia-based liquids.

• Consult a service technician if the display does not operate normally when you have followed the instructions in this manual.

• The casing cover should be opened only by qualied service personnel.

• Keep the display out of direct sunlight and away from stoves or any other heat sources.

• Remove any object that could fall into the vents or prevent proper cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• Keep the display dry. To avoid electric shock, do not expose it to rain or excessive moisture.

• When turning off the display by detaching the power cable or DC power cord, wait for 6 seconds before re-attaching the power cable or DC power cord for normal operation..

• To avoid the risk of shock or permanent damage to the set do not expose the display to rain or excessive moisture.

• When positioning the display, make sure the power plug and outlet are easily accessible.

• IMPORTANT: Always activate a screen saver program during your application. If a still image in high contrast remains on the screen for an extended period of time, it may leave an ‘after-image’ or ‘ghost image’ on the front of the screen. This is a well-known phenomenon that is caused by the shortcomings inherent in LCD technology. In most cases the afterimage will disappear gradually over a period of time after the power has been switched off. Be aware that the after-image symptom cannot be repaired and is not covered under warranty.

EC Declaration of Conformity

This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU) and RoHS directive (2011/65/EU).

This product has been tested and found to comply with the harmonized standards for Information Technology Equipment, these harmonized standards

published under Directives of Ofcial Journal of the European Union.

Warning:

This equipment is compliant with Class A of EN55032/CISPR 32. In a residential environment this equipment may cause radio interference.

Federal Communications Commission (FCC) Notice (U.S. Only)

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

Use only an RF shielded cable that was supplied with the display when connecting this display to a computer device.

To prevent damage which may result in re or shock hazard, do not expose this appliance to rain or excessive moisture.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Envision Peripherals Inc. 490 N McCarthy Blvd, Suite #120 Milpitas, CA 95035 USA

iii

Page 4

BDL5588XC/55BDL3005X

Polish Center for Testing and Certication Notice

The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.

The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).

To completely switch off the equipment, the power supply cable must be removed from the power supply socket, which should be located near the equipment and easily accessible.

A protection mark “B” conrms that the equipment is in compliance with the protection usage requirements of standards PN-93/T-42107 and PN-89/

E-06251.

Electric, Magnetic and Electromagnetic Fields (“EMF”)

1. We manufacture and sell many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.

2. One of our leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products.

3. We are committed to develop, produce and market products that cause no adverse health effects.

4. We conrm that if its products are handled properly for their intended use, they are safe to use according to scientic evidence available today.

5. We play an active role in the development of international EMF and safety standards, enabling us to anticipate further developments in standardization for early integration in its products.

Page 5

Information for U.K. only

(B)

(A)

BDL5588XC/55BDL3005X

WARNING - THIS APPLIANCE MUST BE EARTHED.

Important:

This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows:+

1. Remove fuse cover and fuse.

2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI approved type.

3. Ret the fuse cover.

If the tted plug is not suitable for your socket outlets, it should be cut off and an appropriate 3-pin plug tted in its place.

If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5A.

NOTE: The severed plug must be destroyed to avoid a possible shock hazard should it be inserted

into a 13A socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured in accordance with the following code:

BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN & YELLOW - “EARTH” (“E”)

1. The GREEN & YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E” or by the Earth symbol or coloured GREEN or GREEN & YELLOW.

2. The BLUE wire must be connected to the terminal which is marked with the letter “N” or coloured BLACK.

3. The BROWN wire must be connected to the terminal which marked with the letter “L” or coloured RED.

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead

- not simply over the three wires.

North Europe (Nordic Countries) Information

Placering/Ventilation

VARNING:

FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.

Placering/Ventilation

ADVARSEL:

SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE.

Paikka/Ilmankierto

VAROITUS:

SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA.

Plassering/Ventilasjon

ADVARSEL:

NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ.

Page 6

BDL5588XC/55BDL3005X

中国大陆RoHS

根据中国大陆《电子电气产品有害物质限制使用标识要求》，以下部分列出了本产品中可能包含的有害物质的名称和含量。

有害物质

部件名称

外壳 ○ ○ ○ ○ ○ ○

液晶显示屏 × ○ ○ ○ ○ ○

电路板组件* × ○ ○ ○ ○ ○

电源适配器 × ○ ○ ○ ○ ○

电源线/连接线 × ○ ○ ○ ○ ○

遥控器 X ○ ○ ○ ○ ○

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

本表格依据SJ/T 11364 的规定编制。 *: 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。

上表中打“×”的部件，应功能需要，部分有害物质含量超出GB/T 26572规定的限量要求，但符合欧盟RoHS 法规要求（属于豁免部分）。

备注：上表仅做为范例，实际标示时应依照各产品的实际部件及所含有害物质进行标示。

環保使用期限

此標識指期限(十年)，電子信息產品中含有的有害物質在正常使用的條件下不會發生外泄或突變，電子信息產品用戶使用該電子信息產品不會對環境造成嚴重污染或對其人身、財產造成嚴重損害的期限。

Page 7

BDL5588XC/55BDL3005X

《废弃电器电子产品回收处理管理条例》提示性说明

为了更好地关爱及保护地球，当用户不再需要此产品或产品寿命终止时，请遵守国家废弃电器电子产品回收处理相关法律法规，将其交给当地具有国家认可的回收处理资质的厂商进行回收处理，不当利用或者处置可能会对环境和人类健康造成影响。

娤⌈ 㨢᳸$䵥ᵥ⍿Ʋ◦䏝㯹䉭❁ᳫ濕媣ᵥ⍿⊭侻󰵹廞ノ㒞䵽䏳ⴰㄮƲ◦店䢋⾃⁳᳉濕⊭侻斾堿䏦ヵ ⪷ⴰㄮ悅⊔⃅⩜⊭圊䕂㉨㑻Ʋ

限用物質及其化學符號

單元

鉛

(Pb)

汞

(Hg)

鎘

(Cd)

六價鉻

(Cr+6)

多溴聯苯

(PBB)

多溴二苯醚

(PBDE)

塑料外框 ○ ○ ○ ○ ○ ○ 後殼 ○ ○ ○ ○ ○ ○ 液晶面板－ ○ ○ ○ ○ ○ 電路板組件－ ○ ○ ○ ○ ○ 底座 ○ ○ ○ ○ ○ ○ 電源線－ ○ ○ ○ ○ ○ 其他線材－ ○ ○ ○ ○ ○ 遙控器－ ○ ○ ○ ○ ○ 喇叭（選配）－ ○ ○ ○ ○ ○ 風扇（選配）－ ○ ○ ○ ○ ○

備考1.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考2.〝－〞係指該項限用物質為排除項目。

警語 : 使用過度恐傷害視力。

注意事項 :

(1) 使用30分鐘請休息10分鐘。

(2) 未滿2歲幼兒不看螢幕，2歲以上每天看螢幕不要超過1小時。

警告使用者 :

此為甲類資訊技術設備 , 於居住環境中使用時 , 可能會造成射頻擾動 , 在此種情況下 , 使用者會被要求採取某些適當的對策。

Turkey RoHS:

Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur.

Ukraine RoHS:

Обладнання відповідає вимогам Технічного регламенту щодо обмеження використання деяких небезпечних речовин в електричному та електронному обладнанні, затвердженого постановою Кабінету Міністрів України від 3 грудня 2008 № 1057.

vii

Page 8

BDL5588XC/55BDL3005X

End-of-Life Disposal

Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of.

Please nd out about the local regulations on how to dispose of your old display from your local Philips dealer.

(For customers in Canada and U.S.A.)

This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional information on recycling contact www.eia.org (Consumer Education Initiative)

Waste Electrical and Electronic Equipment-WEEE

Attention users in European Union private households

This marking on the product or on its packaging illustrates that, under European Directive 2012/19/EU governing used electrical and electronic appliances, this product may not be disposed of with normal household waste. You are responsible for disposal of this equipment through a designated waste electrical and electronic equipment collection. To determine the locations for dropping off such

waste electrical and electronic, contact your local government ofce, the waste disposal organization that serves your household or the

store at which you purchased the product.

Attention users in United States:

Please dispose of according to all Local, State and Federal Laws. For the disposal or recycling information, contact: www.mygreenelectronics.com or www. eiae.org.

End of Life Directives-Recycling

Your new Public Information Display contains several materials that can be recycled for new users.

Please dispose of according to all Local, State, and Federal laws.

Restriction on Hazardous Substances statement (India)

This product complies with the “E-Waste (Management) Rules, 2016” CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical and Electronic Equipment and their components or consumables or parts or spares do not contain Lead, Mercury, Cadmium, Hexavalent Chromium, polybrominated biphenyls and polybrominated diphenyl ethers beyond a maximum concentration value of 0.1% by weight in homogenous materials for lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers and of 0.01% by weight in homogenous materials for cadmium. except of exemptions set in Schedule 2 of the Rule.

E-Waste Declaration for India

This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment . The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about E -waste please visit http://www.india.philips.com/about/sustainability/recycling/index.page and to know where you can drop off your waste equipment for recycling in India please contact on below given contact details.

Helpline number: 1800-425-6396 (Monday to Saturday, 9 a.m. to 5:30 pm)

E-mail: india.callcentre@tpv-tech.com

Batteries

For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in accordance with legislation.

Please contact your local authority for details on the collection and recycling schemes.

For Switzerland: The used battery is to be returned to the selling point.

For other non-EU countries: Please contact your local authority for correct method of disposal of the used battery.

According to EU directive 2006/66/EC, the battery can’t be disposed improperly. The battery shall be separated to collect by local service.

viii

Page 9

Após o uso, as pilhas deverão ser entregues ao estabelecimento comercial

e/ou baterias

rede de assistência técnica autorizada.

Information for EAC

Month and year of manufacturing please refer information in Rating label.

Name and location of manufacturer ООО “Профтехника”

Адрес: 3-й Проезд Марьиной рощи, 40/1 офис 1. Москва, 127018, Россия

Importer and information Наименование организации: ООО “Профтехника”

Адрес: 3-й Проезд Марьиной рощи, 40/1 офис 1. Москва, 127018, Россия Контактное лицо: Наталья Астафьева, +7 495 640 20 20 nat@profdisplays.ru

BDL5588XC/55BDL3005X

Page 10

BDL5588XC/55BDL3005X

Table Of Contents

1. Unpacking and Installation .......................................................1

1.1. Unpacking ......................................................................................... 1

1.2. Package Contents ........................................................................1

1.3. Installation Notes .........................................................................1

1.4. Installing and Removing Table Stands (optional) ........2

1.5. Mounting on a Wall ....................................................................3

1.5.1. VESA Grid .................................................................... 3

1.6. Mounting in Portrait Position ................................................ 4

1.7. Operating Instructions of Edge Alignment Kit ............5

1.7.1. Installing Edge Alignment Kit ..............................5

1.8. Using of Edge Finishing Kit (Optional) ............................. 6

1.8.1. Installing Edge Finishing Kit ..................................6

2. Parts and Functions ...................................................................7

2.1. Control Panel .................................................................................7

2.2. Input/Output Ter minals .............................................................8

2.3. Remote Control ...........................................................................9

2.3.1. General functions ..................................................... 9

2.3.2. ID Remote Control .............................................. 10

2.3.3. Inserting the batteries in the remote

control..........................................................................11

2.3.4. Handling the remote control ..........................11

2.3.5. Operating range of the remote control ... 11

3. Connecting External Equipment.......................................... 12

3.1. Connecting External Equipment (DVD/VCR/

VCD) ...............................................................................................12

3.1.1. Using COMPONENT video input .............. 12

3.1.2. Using Video Source input .................................. 12

3.1.3. Using HDMI video input ................................... 13

3.2. Connecting a PC ....................................................................... 13

3.2.1. Using VGA input ..................................................... 13

3.2.2. Using DVI input ......................................................13

3.2.3. Using HDMI input ................................................. 14

3.2.4. Using DisplayPort input ..................................... 14

3.3. Connecting Audio Equipment ...........................................14

3.3.1. Connecting external speakers........................ 14

3.3.2. Connecting an external audio device ........ 15

3.4. Connecting Multiple Displays in a Daisy-chain

Conguration .............................................................................. 16

3.4.1. Display control connection .............................. 16

3.4.2. Digital video connection ....................................16

3.4.3. Analog video connection .................................. 17

3.4.4. IR daisy-chain Connection ................................ 17

3.5. IR connection .............................................................................. 17

3.6. IR Pass-through Connection ............................................... 18

3.7. Wire-connecting to Network ........................................... 18

4. Operation ................................................................................. 19

4.1. Watch the Connected Video Source ............................ 19

4.2. Change Picture Format ......................................................... 19

4.3. Play multimedia les via Local Area Network ..........19

4.3.1. Set up the network .............................................. 19

4.3.2. How to use DLNA-DMP ................................. 19

4.3.3. How to use DLNA-DMR from PC ............ 20

4.4. Play multimedia les from USB device ......................... 20

4.5. Play options .................................................................................. 21

4.5.1. Playing music les ..................................................21

4.5.2. Playing movie les .................................................21

4.5.3. Playing photo les .................................................21

4.6. How to use Opera browser (HTML5) .......................21

5. Change your settings ............................................................. 23

5.1. Settings ............................................................................................23

5.1.1. Picture .......................................................................... 23

5.1.2. Sound ........................................................................... 24

5.1.3. Tiling .............................................................................. 24

5.1.4. Network ..................................................................... 27

5.1.5. General settings ......................................................27

5.1.6. Advanced ................................................................... 30

5.1.7. Help ............................................................................... 30

6. USB device compatibility ....................................................... 31

7. Input Mode ............................................................................... 33

8. Pixel Defect Policy .................................................................. 34

8.1. Pixels and Sub-Pixels ...............................................................34

8.2. Types of Pixel Defects + Dot Denition .................... 34

8.3. Bright Dot Defects ...................................................................34

8.4. Dark Dot Defects.....................................................................35

8.5. Proximity of Pixel Defects ...................................................35

8.6. Pixel Defect Tolerances ......................................................... 35

8.7. MURA ............................................................................................. 35

9. Cleaning and Troubleshooting .............................................. 36

9.1. Cleaning ..........................................................................................36

9.2. Troubleshooting ......................................................................... 37

10. Technical Specications ......................................................... 39

Page 11

1. Unpacking and Installation

1.1. Unpacking

• This product is packed in a carton, together with the standard accessories.

• Any other optional accessories will be packed separately.

• Due to the size and weight of this display it is recommended for two people to move it.

• After opening the carton, ensure that the contents are complete and in good condition.

1.2. Package Contents

Please verify that you received the following items with your package content:

• LCD display

• Remote control with AAA batteries

• Power cord

• DVI cable

• RS232 cable

• Daisy chain cable

• IR sensor cable

• IR cable

• Quick start guide

• Edge Alignment Kit-1: 1PC

• Edge Alignment Kit-2: 2PCS

• Thumb Screw: 8PCS

• Edge Alignment Pin: 2PCS

* The supplied power cord varies depending on destination.

Quick start guide

BDL5588XC/55BDL3005X

Remote Control

and AAA Batteries

Power Cord

RS232 Cable

IR Sensor Cable

* Differences according to regions Display design and accessories may differ from those illustrated above.

NOTES:

• For all other regions, apply a power cord that conforms to the AC voltage of the power socket and has been approved by and complies with the safety regulations of the particular country.

• You might like to save the package box and packing material for shipping the display.

Daisy chain cable

DVI Cable

IR Cable

Edge Alignment Kit-1

Edge Alignment Kit-2

Thumb Screw

Edge Alignment Pin

1.3. Installation Notes

• Due to the high power consumption, always use the plug exclusively designed for this product. If an extended line is required, please consult your service agent.

• The product should be installed on a at surface to avoid tipping. The distance between the back of the product and the wall should be maintained for proper ventilation. Avoid installing the product in the kitchen, bathroom or any other places with high humidity so as not to shorten the service life of the electronic components.

• The product can normally operate only under 3000m in altitude. In installations at altitudes above 3000m, some abnormalities may be experienced.

Page 12

BDL5588XC/55BDL3005X

1.4. Installing and Removing Table Stands (optional)

To install table stands:

1. Ensure your display is powered off.

2. Spread a protective sheet on a at surface.

3. Grab the carrying handles and place the display face-down on the protective sheet.

4. After inserting the stand in the guide block, tighten the screws on both sides of the display.

NOTE: The longer side of the stand should face the front of the display.

Carrying handle

Thumbscrews

Guide block

Table stand

To remove table stands:

1. Power off the display.

2. Spread a protective sheet on a at surface.

3. Grab the carrying handles and place the display face-down on the protective sheet.

4. Remove screws using a screwdriver and place them in a safe place for reuse.

Longer portions face the front

Page 13

BDL5588XC/55BDL3005X

1.5. Mounting on a Wall

To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface

that complies with TUV-GS and/or UL1678 standard in North America.

Protective Sheet

VESA Grid

Tabletop standTable

1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as not to scratch the screen face.

2. Ensure you have all accessories for mounting this display (wall mount, ceiling mount, table stand, etc).

3. Follow the instructions that come with the base mounting kit. Failure to follow correct mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty does not cover damage caused by improper installation.

4. For the wall-mounting kit, use M6 mounting screws (having a length 10 mm longer than the thickness of the mounting bracket) and tighten them securely.

5. Unit without base weight= 26.5 kg. The equipment and its associated mounting means still remain secure during the test. For use only with UL Listed Wall Mount Bracket with minimum weight/load: 26.5 kg.

1.5.1. VESA Grid

BDL5588XC/55BDL3005X

Caution:

To prevent the display from falling:

• For wall or ceiling installation, we recommend installing the display with metal brackets which are commercially available. For detailed installation instructions, refer to the guide received with the respective bracket.

• To lessen the probability of injury and damage resulting from fall of the display in case of earthquake or other natural disaster, be sure to consult the bracket manufacturer for installation location.

Ventilation Requirements for enclosure locating

To allow heat to disperse, leave space between surrounding objects as shown in the diagram below.

400(H) x 400(V) mm

100 mm

100 mm 100 mm

100 mm

Page 14

BDL5588XC/55BDL3005X

1.6. Mounting in Portrait Position

This display can be installed in portrait position.

1. Remove the table stand, if attached.

2. Rotate 90 degrees anticlockwise. The “ ” logo should be bristling when facing the display at the back.

Page 15

1.7. Operating Instructions of Edge Alignment Kit

1.7.1. Installing Edge Alignment Kit

• Before install edge alignment kit, displays must be mounted to video wall frame correctly.

• Using “Thumb Screw” for easy installing.

• Using “Edge Alignment Kit-1” on adjacent four displays.

BDL5588XC/55BDL3005X

• Using “Edge Alignment Kit-2” on adjacent two displays.

• Install the “Edge Alignment Kit-2” with 2 PCS of M4 screw.

2 3

NOTE: When installing the edge alignment kit, please consult a professional technician for proper installation. We accept no liability for installations not

performed by a professional technician.

Page 16

BDL5588XC/55BDL3005X

1.8. Using of Edge Finishing Kit (Optional)

You could use the edge nishing kit to protect the display and have a better appearance.

1.8.1. Installing Edge Finishing Kit

Installing Edge Finishing Kit for 1x1 Display Conguration

Edge Finishiing Kit-Top (*1PC)

Corner(*4PCS)

Edge Finishiing Kit-Left(*1PC)

Edge Finishiing Kit-Left(*2PCS)

Screw (QTY is different depending on models)

Edge Finishiing Kit-Bottom (*1PC)

Installing Edge Finishing Kit for 2x2 Display Conguration

Edge Finishiing Kit-Top

Edge Finishiing Kit-Right(*1PC)

(*2PCS)

Connector (*4PCS)

Edge Finishiing Kit-Right (*2PCS)

Screw (QTY is different depending on models)

* For more detail information, please check the instruction guide in the package of kit.

Connector (*4PCS)

Edge Finishiing Kit-Bottom (*2PCS)

Page 17

2. Parts and Functions

2.1. Control Panel

BDL5588XC/55BDL3005X

MUTE INPUT

1 2 3 4 5 6 7 8

[ ] button

Use this button to turn the display on or put the display to standby.

[MUTE] button

Switch the audio mute ON/OFF.

[INPUT] button

Choose the input source.

• Used as [ ] button in the On-Screen-Display menu.

[ ] button

Increase the adjustment while OSD menu is on, or increase the audio output level while OSD menu is off.

[ ] button

Decrease the adjustment while OSD menu is on, or decrease the audio output level while OSD menu is off.

[ ] button

Move the highlight bar up to adjust the selected item while OSD menu is on.

Remote control sensor and power status indicator

• Receives command signals from the remote control.

• Indicates the operating status of the display without OPS:

- Lights green when the display is turned on

- Lights red when the display is in standby mode

- Lights amber when the display enters APM mode

- When {SCHEDULE} is enabled, the light blinks green and red

- If the light blinks red, it indicates that a failure has been detected

- Lights off when the main power of the display is turned off

[ ] button

Move the highlight bar down to adjust the selected item while OSD menu is on.

[MENU] button

Return to previous menu while OSD menu is on, or to activate the OSD menu when OSD menu is off.

Page 18

BDL5588XC/55BDL3005X

2.2. Input/Output Terminals

20 19

2 18

AC IN

AC power input from the wall outlet.

MAIN POWER SWITCH

Switch the main power on/off.

IR IN / 4 IR OUT

IR signal input / output for the loop-through function.

NOTES:

• This display’s remote control sensor will stop working if the jack [IR IN] is connected.

• To remotely control your A/V device via this display, refer to page 18 for IR Pass Through connection.

RS232C IN / 6 RS232C OUT

RS232C network input / output for the loop-through function.

RJ-45

LAN control function for the use of remote control signal from control center.

HDMI1 IN / 9 HDMI2 IN

HDMI video/audio input.

DVI IN

DVI-D video input.

DVI OUT / VGA OUT

DVI or VGA video output.

DisplayPort IN / 13 DisplayPort OUT

DisplayPort video input / output.

VGA IN (D-Sub)

VGA video input.

3 4

10 11

COMPONENT IN (BNC)

Component YPbPr video source input.

Y/CVBS

Video source input.

PC LINE IN

Audio input for VGA source (3.5mm stereo phone).

SPEAKER SWITCH

Internal speaker on/off switch.

AUDIO IN

Audio input from external AV device (RCA).

AUDIO OUT

Audio output to external AV device.

USB PORT

Connect your USB storage device.

SPEAKERS OUT

Audio output to external speakers.

OPS SLOT

Slot for installing the optional OPS module.

NOTES: We recommend to use Advantech ARK DS262 or Winmate

SECURITY LOCK

Used for security and theft prevention.

OMIS-OPS modules. We’ll not guarantee other OPS modules.

Page 19

2.3. Remote Control

2.3.1. General functions

BDL5588XC/55BDL3005X

[ ] POWER button

Turn the display on or put the display to standby.

[PLAY] buttons

Control playback of media les.

[ ] SOURCE button

Choose input source. Press [ ] or [ ] button to choose from

USB, Network, Internet, SmartCMS, HDMI 1, HDMI 2, DisplayPort, Card OPS, DVI-D, YPbPr, AV

Press [ ] button to conrm and exit.

[ ] HOME button

Access the OSD menu.

[ ] LIST button

No function.

[ ] [ ] [ ] [ ] NAVIGATION buttons

Navigate through menus and choose items.

[ ] button

Conrm an entry or selection.

[ ] ADJUST button

Access currently available options, picture and sound menus.

[ ] MUTE button

Press to turn the mute function on/off.

[ ] [ ] [ ] [ ] COLOR buttons

Choose tasks or options.

[Number/ ID SET/ ENTER] button

Enter text for network setting. Press to set the display ID. Refer to 2.3.2. ID Remote Control

for more detail.

[ ] FORMAT button

Change picture format.

[ ] BACK button

Return to the previous menu page or exit from the previous function.

[ ] INFO button

Display information about current activity.

[ ] OPTIONS button

Access currently available options, picture and sound menus.

[ ] [ ] VOLUME button

Adjust volume.

, or

VGA

Page 20

BDL5588XC/55BDL3005X

2.3.2. ID Remote Control

You can set the remote control ID when you want to use this remote control on one of several different displays.

Press [ID] button. The red LED blinks twice.

1. Press [ID SET] button for more than 1 second to enter the ID Mode. The red LED lights up. Press the [ID SET] button again will exit the ID Mode. The red LED lights off.

Press the digit numbers [0] ~ [9] to select the display you want to control. For example: press [0] and [1] for display No.1, press [1] and [1] for display No.11. The numbers available are from [01] ~ [255].

2. Not pressing any button within 10 seconds will exit the ID Mode.

3. If an error pressing of buttons other than the digits occured, wait 1 second after the red LED lights off and then lights up again, then press the correct digits again.

4. Press [ENTER] button to conrm. The red LED blinks twice and then lights off.

NOTE:

• Press [NORMAL] button. The green LED blinks twice, indicating the display is in normal operation.

• It is necessary to set up the ID number for each display before selecting its ID number.

Page 21

BDL5588XC/55BDL3005X

2.3.3. Inserting the batteries in the remote control

The remote control is powered by two 1.5V AAA batteries.

To install or replace batteries:

1. Press and then slide the cover to open it.

2. Align the batteries according to the (+) and (–) indications inside the battery compar tment.

3. Replace the cover.

Caution:

The incorrect use of batteries can result in leaks or bursting. Be sure to follow these instructions:

• Place “AAA” batteries matching the (+) and (–) signs on each battery to the (+) and (–) signs of the battery compartment.

• Do not mix battery types.

• Do not combine new batteries with used ones. It causes shorter life or leakage of batteries.

• Remove the dead batteries immediately to prevent them from liquid leaking in the battery compartment. Don’t touch exposed battery acid, as it can damage your skin.

NOTE: If you do not intend to use the remote control for a long period, remove the batteries.

2.3.4. Handling the remote control

• Do not subject to strong shock.

• Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately.

• Avoid exposure to heat and steam.

• Other than to install the batteries, do not open the remote control.

2.3.5. Operating range of the remote control

Point the top of the remote control toward the display’s remote control sensor(back side) when pressing a button.

Use the remote control within the range which is shown in the following table.

Operation Angle RC operational distance

θ= 0º (for H & V) ≥ 8m

θ= 20º (for H & V) ≥ 5m

θ= 45º (for H only) ≥ 2m

NOTE: The remote control may not function properly when the remote control

sensor on the display is under direct sunlight or strong illumination, or when there is an obstacle in the path of signal transmission.

Page 22

BDL5588XC/55BDL3005X

3. Connecting External Equipment

3.1. Connecting External Equipment (DVD/VCR/VCD)

3.1.1. Using COMPONENT video input

Audio Out

[AUDIO IN]

COMPONENT Out (YPbPr)

DVD / VCR / VCD

[COMPONENT IN]

(YPbPr)

3.1.2. Using Video Source input

Y/CVBS Out

DVD / VCR / VCD

[AUDIO IN]

[Y/CVBS IN]

Page 23

3.1.3. Using HDMI video input

3.2. Connecting a PC

3.2.1. Using VGA input

BDL5588XC/55BDL3005X

DVD / VCR / VCD

HDMI Out

[HDMI IN]

VGA Out

D-Sub 15 pin

3.2.2. Using DVI input

[VGA IN]

DVI Out

Audio Out

[VGA AUDIO IN]

Audio Out

[DVI IN]

[VGA AUDIO IN]

Page 24

BDL5588XC/55BDL3005X

3.2.3. Using HDMI input

3.2.4. Using DisplayPort input

HDMI Out

[HDMI IN]

DisplayPort Out

3.3. Connecting Audio Equipment

3.3.1. Connecting external speakers

[DisplayPort IN]

External speakers

Page 25

3.3.2. Connecting an external audio device

BDL5588XC/55BDL3005X

Audio In

[AUDIO OUT]

Stereo Amplifier

Page 26

BDL5588XC/55BDL3005X

3.4. Connecting Multiple Displays in a Daisy-chain Configuration

You can interconnect multiple displays to create a daisy-chain conguration for applications such as a video wall.

3.4.1. Display control connection

Connect the [RS232C OUT] connector of DISPLAY 1 to the [RS232C IN] connector of DISPLAY 2.

DISPLAY 1

[RS-232C]

[RJ-45]

[RS-232C IN]

DISPLAY 1

[RJ-45] [RS-232C OUT] [RS-232C IN]

[RS-232C OUT] [RS-232C IN]

3.4.2. Digital video connection

Connect the [DVI OUT / VGA OUT] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY 2.

DISPLAY 2

DISPLAY 1 DISPLAY 2

[DVI]

[DVI IN]

[DVI/VGA OUT] [DVI IN]

Connect the [DP OUT] connector of DISPLAY 1 to the [DP IN] connector of DISPLAY 2.

DISPLAY 1 DISPLAY 2

[DP]

[DP IN]

[DP OUT] [DP IN]

Page 27

Connect the [DVI OUT ] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY 2.

BDL5588XC/55BDL3005X

DVD / VCR / VCD

[HDMI]

[DVI IN]

DISPLAY 1 DISPLAY 2

[DVI OUT] [DVI IN]

3.4.3. Analog video connection

Connect the [DVI OUT / VGA OUT] connector of DISPLAY 1 to the [VGA IN] connector of DISPLAY 2.

DISPLAY 1 DISPLAY 2

[VGA]

[VGA IN]

[DVI/VGA OUT] [VGA IN]

3.4.4. IR daisy-chain Connection

Connect [IR Sensor Cable] to DISPLAY 1,and connect the [RS232C OUT] connector of DISPLAY 1 to the [RS232C IN] connector of DISPLAY 2.

IR Sensor Cable

[IR IN]

[RS-232C OUT]

[RS-232C IN]

DISPLAY 2DISPLAY 1

3.5. IR connection

External

IR Receiver

[IR IN]

Page 28

BDL5588XC/55BDL3005X

NOTE: This display’s remote control sensor will stop working if the [IR IN] is connected.

3.6. IR Pass-through Connection

[IR OUT]

(DVD / VCR / VCD)

Remote Control

DVD / VCR / VCD

[IR IN]

3.7. Wire-connecting to Network

If you connect this display to a home network, you can play photos, music and videos from your computer. See Play multimedia les via Local Area Network (Page 19) for more detail.

INTERNET

[RJ-45]

To setup the network:

1. Switch on the router and switch on its DHCP setting.

2. Connect the router to this display with an Ethernet cable.

3. Press [ ] HOME button on the remote control, then select

4. Select

Connect to network

5. Follow the on-screen instructions to install the network.

6. Wait for this display to nd the network connection.

7. If you are prompted, agree to the “End User Licence Agreement”.

NOTE: Connecting with a shielded CAT-5 Ethernet cable to comply with the EMC directive.

, then press [ ] button.

ROUTER

Setup

[RJ-45]

Page 29

BDL5588XC/55BDL3005X

[RJ-45]

[RJ-45] [RJ-45]

ROUTER

DISPLAY 1

DISPLAY 2

USB

Network

Internet

SmartCMS

HDMI 1

HDMI 2

Display Port

Card OPS

DVI-D

YPbPr

VGA

4. Operation

NOTE: The control button described in this section is mainly on the

remote control unless specied otherwise.

4.1. Watch the Connected Video Source

See page 12 for external equipments connection.

1. Press [ ] SOURCE button.

2. Press [ ] button.

4.2. Change Picture Format

You can change the picture format to suit the video source. Each video source has its available picture formats.

The available picture formats depend on the video source:

1. Press [ ] FORMAT button.

2. Press [ ] or [ ] button to choose a picture format, then press [ ] button.

• {Auto zoom}: Enlarge the picture to ll the screen.

• {Movie expand 16:9}: Scale 4:3 format to 16:9. Not

• {Wide screen}: Shows wide screen format content unstretched.

• {Unscaled}: Provide maximum detail for PC. Only available

• {4:3}: Display the classic 4:3 format.

• {Custom zoom}: Choose to apply customize zoom settings in

4.3. Play multimedia files via Local Area

To play les via Local Area Network, you will need:

• A wired home network, connected with a Universal Plug and Play (uPnP) router.

• Optional: A LAN cable that connects your display to your home network.

• A media server running on your computer.

• Appropriate settings on your computer rewall to allow you to run the media server.

or [ ] button to choose a device, then press [ ]

Recommended for minimal screen distortion but not for HD or PC.

recommended for HD or PC.

Not recommended for HD or PC.

when PC mode is selected in the {Picture} menu.

the Picture and edges submenu

Network

• Multiple display setup:

NOTE: If the apparatus does not return to DLNA mode due to

external electrical disturbances (e.g. electrostatic discharge), user intervention is required.

Set up media sharing

1. Install a media server on your computer to share media les. These are some media servers:

• For PC: Windows Media Player 11 (or higher) or TVersity

• For Mac: Twonky

2. Switch on media sharing on your computer using the media server. For more information on how to set up the media server, refer to the website of the media server.

4.3.2. How to use DLNA-DMP

Ensure you have connected to the network. You can press button to display the connection of the network.

HDMI 1 1080p60 26/09/2014 Friday 09:32:00

Picture format Picture style Sound style Smart power Volume Monitor group Monitor ID Model name SWVersion Serial no Temperature

Network configuration IP address Netmask Gateway Network name Ethernet MAC address

Play les from display

1. Press [ ] SOURCE button, choose Network, and press [ ] button.

Wide screen Standard Personal Off 0 1 1 XXXXXXX

1.51

25°C

DHCP & Auto IP

192.168.1.116

255.255.255.0

192.168.1.1 BDL5588XC FF:FF:FF:FF:FF:FF:

4.3.1. Set up the network

1. Connect your display and the computer to the same home network. See illustration below to connect your display to a network.

2. Switch on your computer and the router.

• Single display setup:

[RJ-45]

ROUTER

[RJ-45]

2. Now, you can see all the PC’s connected to the same router on the screen. Choose the right one.

3. Press [ ] and [ ] to choose the directory and les to play.

Page 30

BDL5588XC/55BDL3005X

Network settings

Digital Media Rendere...

Network name

Clear Internet memory


Sound

Tiling

Network

General settings

Advanced

Help

Off

Network settings

Digital Media Renderer - D...

Network name

Clear Internet memory

USB

Network

Internet

SmartCMS

HDMI 1

HDMI 2

Display Port

Card OPS

DVI-D

YPbPr

VGA

4. You can connect up to 4 displays to the same PC and play same media stream.

4.3.3. How to use DLNA-DMR from PC

1. Press [ ] HOME button, choose Network and press [ ] button.


Sound

Tiling

Network

General settings

Advanced

Help

2. Set

Digital Media Renderer DMR

Network settings

Digital Media Rendere...

Network name

Clear Internet memory

as ON.

6. Check the media formats. Then, click

streaming options....

7. Go to

Advanced sharing settings

network discovery

Choose media

, and check

Turn on

8. Now, go to the directory of your media les. Choose the media

le by right click. On the submenu from

Play To

, You can nd all

displays connected to your network. Choose the display, and click

the media le to play..

Play les

1. Press [ ] SOURCE button.

2. Choose

Network

3. Choose a le from the content browser, and press [ ] button to start playing.

4. Press the [PLAY] buttons on the remote control to control playing.

Tips:

• Choose the top bar to lter your les by type.

• Choose

Sort

elds.

• To clear the list of ofine media servers, press [ ] OPTIONS button. Then, choose button.

, and press [ ] button.

to arrange the les by album name, artist, or other

Clear ofine servers

and press [ ]

3. Set the name of your display.

4.4. Play multimedia files from USB device

1. Connect your USB device to the USB port on the display.

2. Press [ ] button.

SOURCE

button, choose

, and press [ ]

USB

4. Press [ ] HOME button, and press [ ] Then, choose

5. On your PC, go to

Choose homegroup and sharing options

Cancel

Network

Network and Sharing Center

XXXXXXX

and press [ ] button.

Done Clear

SOURCE

button.

, and click

3. The connected USB device is detected automatically for all its

playable les, which will be automatically sorted into 3 types:

Music

Movie

, and


4. Press [ ] BACK button to go up to the top layer in the screen. Press [ ] or [ ] button to choose the le type. Press [ ] button to enter its play list.

5. Choose the le you want. Press [ ] button to start playing.

Page 31

BDL5588XC/55BDL3005X

Music

Movie


USB

Network

Internet

SmartCMS

HDMI 1

HDMI 2

Display Port

Card OPS

DVI-D

YPbPr

VGA

6. Follow the on-screen instruction to control the play option.

7. Press [PLAY] buttons ( ) to control playing.

4.5. Play options

4.5.1. Playing music files

1. Choose

2. Choose one music track, and press [ ] button.

• To play all the tracks in a folder, choose one music le. Then, press [ ] to

• To skip to the next or previous track, press [ ] or [ ] button.

• To pause the track, press [ ] button. Press [ ] button again to resume playback.

To skip backward or forward 10 seconds, press [ ] or [ ]

• button.

• To search backward or forward, press [ ] or [ ] button, press repeatedly to toggle between different speeds.

• To stop the music, press [ ] button.

Music options

While you play music, press [ ] OPTIONS button, then press [ ] button to choose an option:

• {Shufe}: Enable or disable random play of tracks.

• {Repeat}: Choose {Repeat} to play a track or an album repeatedly, or choose {Play once} to play a track once.

NOTE: To view information about a song (for example, title, artist or

duration), choose the song, then press [ ] INFO button. To hide the information, press [ ] INFO button again.

4.5.2. Playing movie files

1. Choose

Music

Movie

in the top bar.

Play All

in the top bar.

• {Status}: To view information about a video (for example, played position, duration, title, or date).

4.5.3. Playing photo files

1. Choose

2. Choose a photo thumbnail, then press ] button.

Start a slideshow

If there are multiple photos in a folder, choose a photo. Then, press [ ] to

•

Play All

To skip to the previous or next photo, press [ ] or [ ] button, and then press [ ] button.

• To stop the slideshow, press [ ] button.

Slideshow options

While you play a slideshow, press [ ] OPTIONS button, then press [ ] button to choose an option:

• {Shufe}: Enable or disable random display of pictures in the

slideshow.

• {Repeat}: Choose {Repeat} to watch a slideshow repeatedly or

{Play once} to watch once.

• {Slideshow Time}: Choose the displaying time for each photo in the

slideshow.

• {Slideshow Transitions}: Choose the transition from one photo to

the next.


in the top bar.

4.6. How to use Opera browser (HTML5)

Please check the LAN wire to make sure the network is connected.

1. Press [ ]

[ ] button.

SOURCE

button, and choose

Internet

and press

2. Choose a video, and press [ ] button.

• To play all the videos in a folder, choose one video le. Then, press [ ] to

Play All

• To pause the video, press [ ] button. Press [ ] button again to resume playback.

To skip backward or forward 10 seconds, press [ ] or [ ]

• button.

• To search backward or forward, press [ ] or [ ] button, press repeatedly to toggle between different speeds.

• To stop the video, press [ ] button.

Movie options

While playing video, press [ ] OPTIONS button, then press [ ] button to choose an option:

• {Subtitles}: Choose the available subtitle settings.

• {Subtitle language}: Choose the language for subtitles if available.

• {Shufe}: Enable or disable random play of video les.

• {Repeat}: Choose {Repeat} to play the video le repeatedly or {Play once} to play the video le once.

2. Move the cursor to URL address bar. Press [ ] button and it will pop out the on-screen keyboard. You can move the cursor to

enter the URL address. After nishing the URL address, choose

Done

Page 32

BDL5588XC/55BDL3005X

History

Bookmark

Web Address：



Internet

www.google.com

http://

wwwwwwww

ggg

..cc

Done

Hide

. , @ ‘

g h i

p q r s

a b c

j k l

t u v

? ! -

d e f

m n o

w x y z

abc ABC 123 www Backspace

wwwwwww

ggggggg

ggg

..cc

3. Move the cursor to “” icon and press [ ] button.

Web Address：

www.google.com

http://www.google.com



Internet

History

Bookmark

4. Now, you can see the web page.

NOTES:

• The Opera browser does not support FLASH format.

• The browser is not a video source. It will not stay at the browser screen after you restart the display.

Page 33

BDL5588XC/55BDL3005X

5. Change your settings

Using the remote control:

SOURCE

1. Press [ ] button on the remote control to display the OSD menu.

2. Press [ ] or [ ] button to choose the item you want to adjust.

3. Press [OK] or [ ] button to enter the submenu.

4. In the submenu, press [ ] or [ ] button to toggle among items, press

[ ] or [ ] button to adjust settings. If there is a submenu, press

[OK] or [ ] button to enter the submenu.

5. Press [ ] button to return to the previous menu, or press [ ] button to exit the OSD menu.

Using the display’s control buttons

FORMAT

INFOLIST

OPTIONSADJUST

5.1.1. Picture


Sound

Tiling

Network

General settings

Advanced

Help

Picture style

Choose a predened picture setting.

Backlight

Adjust the brightness of this display’s backlight.

Colour

Adjust the colour saturation of the picture.

Sharpness

Adjust the sharpness of the picture.

Noise reduction

Choose the amount of noise reduction for the picture.

MPEG artifact reduction

Smoothen transitions and haziness in the digital picture.

Picture enhancement

Fine-tune each pixel to match surrounding pixels and produce a brilliant,

high-denition image.

• {Advanced sharpness}: Enable superior sharpness, especially on lines and contours in the picture.

• {Dynamic contrast}: Dynamically enhance the details in the dark, medium and light areas of the picture.

• {Colour enhancement}: Dynamically enhance the vividness and details of colours.

Picture style

Backlight

Colour

Sharpness

Noise reduction

MPEG artifact reducti...

Picture enhancement

Advanced

Scan mode

Format and edges

HDMI input range

Picture reset

1. Press [ ] button to display the OSD menu.

2. Press [ ] [ ] [ ] or [ ] button to choose menu item or adjust its value.

3. Press [ ] button to conrm menu selection and enter its submenu.

4. Press [ ] button to exit the OSD menu.

5.1. Settings

Press [ ] HOME button.

Advanced

Access advanced settings such as gamma, tint, video contrast and so on.

• {Gamma}: Adjust the non-linear setting for picture luminance and contrast.

• {Tint}: Change the colour balance.

• {Custom tint}: Customise colour balance setting. Only available if {Tint}  {Custom} is chosen.

• {Video contrast}: Adjust video contrast.

• {Brightness}: Adjust screen brightness.

• {Hue}: Adjust screen hue.

Scan mode

Change the display area of the image.

Format and edges

• {Picture format}: Change the picture format.

• {Zoom}: Expands the horizontal and vertical sizes of the image simultaneously.

• {H Zoom}: Expands the horizontal size of the image only.

Page 34

BDL5588XC/55BDL3005X

Sound style

Bass

Treble

Balance

Volume

Minimum volume

Maximum volume

Surround mode

Audio out (line out)

Advanced

Sync. Volume

Sound reset


Sound

Tiling

Network

General settings

Advanced

Help

• {V Zoom}: Expands the vertical size of the image only.

Note: Zoom, H Zoom and V Zoom are functional only when the

Picture format setting is set to Custom Zoom. See page 19 for the descriptions about

Picture format

HDMI input range

HDMI video format color ranges

• {Auto}: Automatically HDMI video format color ranges.

• {Limit}: Chose HDMI video format Limit range.

• {Full}: Chose HDMI video format Full range.

Picture reset

Reset all your picture settings to the factory defaults.

5.1.2. Sound

Sound style

Access predened sound settings.

Bass

Adjust to increase or decrease lower-pitched sounds.

Treble

Adjust to increase or decrease higher-pitched sounds.

Balance

Adjust to emphasize left or right audio output balance.

Volume

Adjust to increase or decrease the volume.

Minimum volume

Set the Minimum volume.

Maximum volume

Set the Maximum volume.

Surround mode

Set surround effects for audio performance.

Audio out (line out)

Adjust audio output volume.

Advanced

Access advanced settings to enhance your audio experience.

• {Auto volume leveling}: Enable the reduction of sudden volume changes.

• {Speaker settings}: Turn on or off the internal speakers.

• {Clear sound}: Enhance sound quality.

• {Audio out format}: Choose the type of audio output through the digital audio output connector. (HDMI only)

• {Audio out delay}: Automatically sync the image on this display

to the audio from a connected home theatre.

• {Audio out offset}: Adjust the setting for audio output delay. Available if {Audio out delay} is switched on.

Sync. Volume

Choose to {On} or {Off} the Sync. Volume function. Set {On} to synchronize the volume of internal speaker and line-out. Set {Off} to adjust the volume of internal speaker and line-out, respectively.

Sound reset

Reset to default setting.

Card OPS audio

Choose to set OPS audio output format. The options are: {Auto}, {Analog}, {Digital} NOTE: When the user select Card OPS source, this item will be

appear in OSD menu.

5.1.3. Tiling


Sound

Tiling

Network

General settings

Advanced

Help

With this function you can create a single large-screen matrix (video wall) that consists of up to 100 sets of this display (up to 10-sets on the vertical and 10-sets on the horizontal sides).

Enable

Choose to {On} or {Off} the Tiling function. If {On}, the display will apply the settings in {H monitors}, { V monitors}, {Position}, and {Frame comp.}.

H monitors

Adjust displays on the horizontal side.

V monitors

Adjust displays on the vertical side.

Position

Adjust the position of this display in the screen matrix.

Enable

H monitors

V monitors

Position

Frame comp.

Frame comp. H

Frame comp. V

Switch on delay

RS232-Routing

Auto ID

Tiling tool

Page 35

BDL5588XC/55BDL3005X

3 4

Example: 2 x 2 screen matrix (4 displays)

H monitors = 2 displays V monitors = 2 displays

H monitors

Position

1 2

V monitors

Example: 5 x 5 screen matrix (25 displays)

H monitors = 5 displays V monitors = 5 displays

H monitors

1 2

6 7

3 4

8 9

11 12 13 14 15

V monitors

16 17 18 19 20

21 22 23 24 25

Frame comp.

Choose to turn the frame compensation function on or off. If selected {On}, the display will adjust the image to compensate for the width of the display bezels in order to accurately display the image.

{On}

Position

{Off}

Frame comp.H

Adjust the horizontal frame compensation.

Frame comp.V

Adjust the vertical frame compensation.

Switch on delay

Adjust the power-on delaying time (in seconds) allows a sequential powering-on for each display by their ID number when multiple displays are connected.

RS232-Routing

Select control port.

• {RS232}: Select RS232 Control.

• {LAN(RJ-45)}: Select LAN control.

• {IR} Select the operation mode of the remote control when multiple

displays are connected via an RS232C connection.

• {IR Control}

• {Normal} All displays can be operated normally by the remote control unit.

• {Primary} Designate this display as the primary display for remote control

operation. Only this display can be operated by the remote control.

• {Secondary} Designate this display as the secondary display. This display can not be

operated by the remote control, and will only receive the control signal from the primary display via the RS232C connection.

• {Control Monitor-ID} Select the ID number for the IR control the display via the RS232C

connection.

• {Card OPS RS232}: Select RS232 Control. (Only available when OPS is started.)

Auto ID

The setup function enables setting up {Monitor ID} of connected machine according to {H monitors} settings. Example: H monitors sets as 4

Page 36

BDL5588XC/55BDL3005X

1 2

(2). Enter activate key in OSD

5 6

7 8

9 10 11 12

13 14 15 16

Note: To use this function, serial connect all machines with RS-232 cable and set their Network control port to RS-232 too. Note: To use this function for DP 1.2 connectivity, the maximum resolution only support to 1920x1080/60Hz @ 4sets. For 4Kx2K/30Hz resolution only support to 2 sets connectivity.

Tilling tool

To activate the tiling tool function by enter the activate key that buy from the dealer.


Sound

Tiling

Network

General settings

Advanced

Help

Enable

H monitors

V monitors

Position

Frame comp.

Frame comp. H

Frame comp. V

Switch on delay

RS232-Routing

Auto ID

Tiling tool

Status

Activate

Cancel

Done Clear

(3). Press [ ] button and it will pop out the on-screen keyboard.

You can move the cursor to enter the activate key. After nishing

choose

Done

Note: Press yellow key of remote control, the input change to number digital.

. , @ ‘

g h i

p q r s

abc ABC 123 www Backspace

a b c

j k l

t u v

? ! -

d e f

m n o

w x y z

Done

Hide

(4). Tiling tool activate message

(1). Enter activate menu


Sound

Tiling

Network

General settings

Advanced

Help

Status

Activate

Cancel

Tiling tool activation successful

xxxxxxx

Done

Clear

Page 37

BDL5588XC/55BDL3005X


Sound

Tiling

Network

General settings

Advanced

Help

Menu language

Monitor Group

Monitor ID

Eco mode

Auto search

Clock

Scheduling

Sleep timer

OneWire

Local KB lock

RC lock

(5). Check tiling tool status on in OSD


Sound

Tiling

Network

General settings

Advanced

Help

Status

5.1.4. Network


Sound

Tiling

Network

General settings

Advanced

Help

Network settings

• {Network conguration}: Choose how this display should assign addresses to the network resources. The user can choose {DHCP & Auto IP} (suggested) or {Static IP}.

• {Network type}: Choose Wired (default) to set the network type.

Digital Media Renderer - DMR

Receive multimedia les from the connected device by your network.

Network name

In the multiple-display connection, you can rename each display for easy

identication.

Use the on-screen keyboard or the remote control keypad to enter the name.

Clear Internet memory

Clear all the cookies, bookmarks, history list and text used for auto ll.

Network settings

Digital Media Rendere...

Network name

Clear Internet memory

5.1.5. General settings

Menu language

Choose language used for OSD menus.

Monitor group

Adjust the group range between 1 to 255. The default setting is 255.

Monitor ID

Adjust the ID number for controlling the display via the RS232C connection. Each display must have a unique ID number when multiple sets of this display are connected. Monitor ID number range is between 1 to 255. The default setting is 1.

Eco mode

Set this display to reduce the power consumption automatically. NOTES: Factory default setting is “low power standby”, but user could

not reset it to default after setting Eco mode to”Normal” by “Factory reset” in MENU. However, user can still change the ECO mode back to “low power standby” manually.

Auto search

Choose to let this display detect and display available signal sources automatically.

Clock

Set the current date and time for the display’s internal clock. NOTES:

The Daylight saving time denition and behavior:

The current implementation of daylight saving is a reminder tool for the customer which doesn’t know how to adjust the clock for daylight saving on and off. It does not adjust the real time clock automatically. Problem is that there are no stable rules per region, or country when to adjust the clock. To solve this the user must be able to set the daylight saving start en stop date. When daylight saving correction is on (user selectable) then the real time clock should be adjusted at the moment in time set in the daylight saving on and off date. At daylight start date the clock should be put forward 1 hour at 2 o’clock. At daylight stop date the clock should be put back 1 hour at 2 o’clock.

The existing daylight on/off menu item should be replaced with the following menu structure:

Menu item {Daylight saving} opens submenu containing the following items:

• Menu item {Daylight saving start date} Selection item {1st, 2nd, 3rd, 4th, last} Sunday of selection item {1-12 month}

• Menu item {Daylight saving stop date} Selection item {1st, 2nd, 3rd, 4th, last} Sunday of selection item {1-12 month}

• Menu item {Correction time} Selection item {0.5, 1.0, 1.5, 2.0} hour

• Menu item {Daylight saving} Selection item {on, off}

Page 38

BDL5588XC/55BDL3005X

when “daylight saving” is “on” the real time clock would have been adjusted automatically for winter and summer time when passing the critical moment in time (eg April 5, 2015, 02.00 o’clock: time will be set 1 hour later or October 25, 2015, 02.00 o’clock: time will be set 1 hour earlier).

Scheduling

This function allows you to program up to 7 different scheduled time

intervals for this display to activate. You can set:

• Which input source the display will use for each scheduled activation period.

• The time for the display to turn on and turn off.

• The days in a week for the display to activate.

NOTES:

• We recommend you to set up current date and time in the {Clock} menu before using this function.

• After changing the {Clock} option in the {General settings} menu, you need to set this {Scheduling} again.


Sound

Tiling

Network

General settings

Advanced

Help

1. There are 7 schedule can be set. Go to

Schedule 1

Schedule 2

Schedule 3

Schedule 4

Schedule 5

Schedule 6

Schedule 7

Menu language

Monitor Group

Monitor ID

Eco mode

Auto search

Clock

Scheduling

Sleep timer

OneWire

Local KB lock

RC lock

Status

Source

On time

Off time

Repeat modes

Playlist setting

Status

and choose On.

Off

Schedule 1

Schedule 2

Schedule 3

Schedule 4

Schedule 5

Schedule 6

Schedule 7

3. Set

Schedule 1

Schedule 2

Schedule 3

Schedule 4

Schedule 5

Schedule 6

Schedule 7

4. Set

Schedule 1

Schedule 2

Schedule 3

Schedule 4

Schedule 5

Schedule 6

Schedule 7

Status

Source

On time

Off time

Repeat modes

Playlist setting

Slideshow durations

On time

Status

Source

On time

Off time

Repeat modes

Playlist setting

00 : 00

Cancel Done

Off time

Status

Source

On time

Off time

Repeat modes

Playlist setting

14 : 00

Cancel

USB playlist

HDMI 1

HDMI 2

DisplayPort

Card OPS

DVI-D

YPbPr

VGA

Internet

SmartCMS

Done

2. Go to

Source

and choose input source. If {Source}  {USB} is chosen. You need to set playliist. If {Source}  {BROWSER} is chosen. You need to set URL address.

NOTE: If {Source}  {Autoplay} is chosen. You need to create a

folder named “

philips”

in the root directory of the USB and

put the les (pictures or videos) you want to display in the

folder.

5. Go to

Schedule 1

Schedule 2

Schedule 3

Schedule 4

Schedule 5

Schedule 6

Schedule 7

Repeat modes

and choose.

Status

Source

On time

Off time

Repeat modes

Playlist setting

No repeat

Every Sunday

Every Monday

Every Tuesday

Every Wednesday

Every Thursday

Every Friday

Every Saturday

Page 39

BDL5588XC/55BDL3005X

6. If {Source}  {USB} is chosen. Go to


Options Exit

Playlist setting


Video

0001/0002

- Press [ ] [ ] buttons to choose les.

- Press [ ] [ ] buttons to switch Playlist and File Manager.

- Press [ ] button to set or clear the playlist.

7. To save the playlist, press [ ] and choose


Movie.avi


Sort


Media Type


Recursive Parser

Save list

Options Exit

\media\photo

[..]


Save list

0004/0004

NOTES:

• Each Playlist supports up to 30 les.

• Playlist will not be cleared after {Factory settings}. You have to

manually remove the les or delete usb_schedulinglist.txt in the

USB.

Sleep timer

Switch off this display after a specied time.

OneWire

Connect and control your HDMI-CEC compliant devices through HDMI port to this display with the same remote control.

Local KB lock

Choose to enable or disable the keyboard (control buttons) function of the display.

• {Unlock}: Enable the keyboard function.

• {Lock all}: Lock all keyboard function.

• {Lock but volume}: Disable all the keyboard function except the [ ] and [ ] button.

• {Lock but power}: Disable all the keyboard function except the [ ] button.

• {Lock all expect volume and power}: Disable all the keyboard function except the [ ], [ ] and [ ] button:

RC lock

Choose to enable or disable the button function of the remote control.

• {Unlock}: Enable the keyboard function.

• {Lock all}: Lock all keyboard function.

• {Lock but volume}: Disable all the keyboard function except the [ ] and [ ] button.

• {Lock but power}: Disable all the keyboard function except the [ ] POWER button.

• {Lock all expect volume and power}: Disable all the keyboard function except the [ ] [ ] and [ ] POWER button:

NOTE: To disable the lock function from

RC lock

item, press buttons [ ] and 1 9 9 8 on the

Local KB lock

remote control.

Pixel shift

For video input sources, you may choose {On} to move the screen image automatically to protect the display from “burn-in” or “after-image” symptoms 30 seconds after not operating the display.

Smart power

Choose a backlight level to optimise dynamic power consumption and picture contrast.

The options are: {Off}, {Standard}, {Medium}, {High}.

Wake on lan

Choose {On} and you can turn on the display by network.

Switch on state

Choose the display status used for the next time you connect the power cord.

• {On} - The display will turn on when the power cord is connected to a wall outlet.

• {Standby} - The display will remain Standby when the power cord is connected to a wall outlet.

• {Last status} - The display will return to the previous power status (on/off/standby) when removing and replacing the power cord.

Light sensor

Choose {On} and the display will automatically adjust backlight. Only available when you plug in CRD41.

Human sensor

Set the display to turn on backlight if it does sensor human and turn off

backlight after an amount of the specied.

The options are :{Off, 10 ~ 60} minutes. Only available when you plug in CRD41.

Power LED Light

Choose {Off} to turn off the indicator.

Logo

Choose {Off} and the display will not display the logo when you switch on.

Advanced power management

Choose {On}. Then, when no signal, the display will automatically turn off.

Source notication

When you press [ ] POWER button to turn on the display from standby mode or change the input signal, the information OSD is displayed on the upper left corner of the screen.

Choose {Off} to turn off this function.

Page 40

BDL5588XC/55BDL3005X


Sound

Tiling

Network

General settings

Advanced

Help

Jitter clean

EQ boost

USB copying


Sound

Tiling

Network

General settings

Advanced

Help

DisplayPort Ver.

Set the DisplayPort version to 1.1a or 1.2, this setting is only valid on DisplayPort input and output,

1.1a: Switch DisplayPort Ver. to 1.1a(default), the DisplayPort output is the clone of the DisplayPort input.

1.2: Switch DisplayPort Ver. to 1.2 to support MST(Multi-Stream Transport)

NOTE:

• If the display is black screen or abnormal under DisplayPort source, please switch to 1.1a and turn AC off and on.

• For DP daisy chain application, please select the same DP version in all PD.

Cooling Fan

Select {On} to turn on the cooling fan all the time. Select {Auto} to turn on/off the cooling fan according to the display’s temperature.

NOTES:

• The default {Auto} option will start running the cooling fan if the temperature of 45°C (113°F) is reached and stop running the cooling fan if the temperature of 43°C (109°F).

• A temperature-warning message will be shown on the screen if the temperature reaches 58°C (136°F). All key functions except [ ] key will then be disabled.

• Once the temperature reaches 60°C (140°F), the display power will be shut down automatically.

Factory settings

Reset all your customized settings to the factory defaults.

5.1.7. Help

5.1.6. Advanced

Jitter clean

Turn on/off Jitter cleaning function for HDMI and DVI signal quality

enhancement. The default setting is on.

EQ boost

Adjust digital signal EQ boost.

USB copying

Copy user logo “Welcomelogo.png” to internal memory .

Page 41

6. USB device compatibility

USB Video Subtitle Formats (for language subtitles, etc.)

BDL5588XC/55BDL3005X

File

Extensions

.mpg

mpeg

.vob

Container Video codec Maximum resolution

MPEG-1 1920x1080 25p,30p,50i,60i 30

MPEG-2 1920x1080 25p,30p,50i,60i 30

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 25p,30p,50p,60p,60i 30

Max.Frame Rate

(fps)

Max.Bit Rate

(Mbps)

Audio codec

MPEG-1(L1&L2),

MPEG-1,2,2.5 L3,

AAC/HE-AAC(v1&v2),

MPEG-2 1920x1080 25p,30p,50i,60i 30

.ts TS

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 25p,30p,50p,60p,60i 30

1920x1080i@eld rate=50, 60Hz

MVC

1920x1080p@frame rate=24, 25,30Hz

1280x720p@frame rate=50, 60Hz

- 30

MPEG-1(L1&L2), MPEG-1,2,2.5 L3,

AAC/HE-AAC (v1&v2)

MPEG-2 1920x1080 25p,30p,50i,60i 30

.ts

.m2ts

.mts

.mt2

.ts

.m2ts

.mts

.ts

.m2ts

.mts

MaTS

TTS

AVCHD

AVCHD MVC

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 25p,30p,50p,60p,60i 30

1920x1080i @ eld rate=50, 60Hz

MVC

1920x1080p @ frame rate=24, 25,30Hz

1280x720p @ frame rate=50, 60Hz

- 30

MPEG-2 1920x1080 25p,30p,50i,60i 30

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 25p,30p,50p,60p,60i 30

1920x1080i@eld rate=50, 60Hz

1920x1080p@frame rate=24, 25,30Hz

1280x720p @ frame rate=50, 60Hz

- 30

MPEG-1(L1&L2), MPEG-1,2,2.5 L3,

AAC/HE-AAC (v1&v2)

MPEG-1(L1&L2), MPEG-1,2,2.5 L3,

AAC/HE-AAC (v1&v2)

MPEG-1(L1&L2), MPEG-1,2,2.5 L3,

AAC/HE-AAC (v1&v2)

.m4v M4V H.264 1920x1080 25p,30p,50p,60p,60i 30 AAC

.ism/

Manifest

.mpd

frag MP4

H.264 1920x1080 25p,30p,50p,60p,60i 30

1920x1080i@eld rate=50, 60Hz

MVC

1920x1080p@frame rate=24, 25,30Hz

1280x720p @ frame rate=50, 60Hz

- 30

AAC/HE-AAC(v1&v2),

WMA, WMA-PRO

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 30

.mp4 MP4

MVC

1920x1080i@eld rate=50, 60Hz

1920x1080p@frame rate=24, 25,30Hz

1280x720p @ frame rate=50, 60Hz

- 30

AAC/HE-AAC(v1&v2),

WMA, WMA-PRO

WMV9/VC1 1920x1080 30p,60i 30

.mkv

.mk3d

MKV

MPEG-4 ASP 1920x1080 25p,30p,50i,60i 30

H.264 1920x1080 30

MPEG-1(L1&L2), MPEG-1,2,2.5 L3,

AAC/HE-AAC (v1&v2),

WMA, WMA-PRO

DVD-PCM

Page 42

BDL5588XC/55BDL3005X

USB Multimedia Formats

File Extensions Container Video codec

.mp3 MP3 - - 48 384 MPEG-1,2,2.5 L3 .wma

.asf

.wma WMA Pro - - 96 768 WMA,WMA Pro

.wav(PC) LPCM - - 192 768 LPCM

.aif(mac)

.aiff(mac)

.aac

.mp4

.m4a

.pls .m3u .m4a M4A - - 48 1024 AAC,HE-AAC(v1&v2)

NOTES:

• Sound or video may not work if the contents have a standard bit rate/frame rate above the compatible Frame/sec listed in the table above.

• Video content with a Bit rate or Frame rate larger than the rate specied in the table above can cause choppy video during playback.

WMA

(V2 up to V9.2)

LPCM - - 192 768 LPCM

AAC - - 48 1024 AAC,HE-AAC(v1&v2)

Playlists - - - - -

- - 48 192 WMA

Maximum resolution

Frequency

(kHz)

Max.Bit Rate

(Mbps)

Audio codec

Page 43

BDL5588XC/55BDL3005X

7. Input Mode

VGA Resolution:

Standard

Resolution

VGA 640 480

WVGA 720 400 70 Hz 33.75 MHz 16:9 Wide Video Gr aphic Arr ay

SVGA 800 600

XGA 1024 768

WXGA 1280 768 60 Hz 79.5 MHz 5:3 Wide XGA WXGA 1280 800 60 Hz 79.5 MHz 16:10 Wide XGA

SXGA 1280 960 60 Hz 108 MHz 4:3 Super XGA

SXGA 1280 1024 60 Hz 108 MHz 5:4 Super XGA WXGA 1360 768 60 Hz 85.5 MHz 16:9 Wide XGA WXGA 1366 768 60 Hz 85.5 MHz 16:9 Wide XGA

UXGA 1600 1200 60 Hz 162 MHz 4:3 Ultra XGA

HD1080 1920 1080 60 Hz 148.5 MHz 16:9 HD1080

SDTV Resolution:

Standard

Resolution

480i

480p 59.94 Hz 27 MHz

576i

576p 50 Hz 27 MHz

HDTV Resolution:

Standard

Resolution

720p 1280 720

1080i 1920 1080

1080p 1920 1080

• The PC text quality is optimum in HD 1080 mode (1920 x 1080, 60Hz).

• Your PC display screen might appear different depending on the manufacturer (and your particular version of Windows).

• Check your PC instruction book for information about connecting your PC to a display.

• If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5KHz (horizontal). In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power is turned off (or if the PC is disconnected). If so, press the [INPUT] button to enter the video mode. Also, make sure that the PC is connected.

• When horizontal synchronous signals seem irregular in RGB mode, check PC power saving mode or cable connections.

• The display settings table complies to the IBM/VESA standards, and based on the analog input.

• The DVI support mode is regarded as same to the PC support mode.

• The best timing for the vertical frequency to each mode is 60Hz.

Active Resolution

H Pixels V Lines

Active Resolution

H Pixels V Lines

720 480

720 576

Active Resolution

H Pixels V Lines

Refresh Rate Pixel Rate Aspect Ratio Stand for Mode

60 Hz 25.175 MHz

72 Hz 31.5 MHz 75 Hz 31.5 MHz

60 Hz 40 MHz 75 Hz 49.5 MHz 60 Hz 65 MHz

75 Hz 78.75 MHz

Refresh Rate Pixel Rate Aspect Ratio Stand for Mode

29.97 Hz 13.5 MHz

25 Hz 13.5 MHz

Refresh Rate Pixel Rate Aspect Ratio Stand for Mode

50 Hz 60 Hz 25 Hz 30 Hz 50 Hz 60 Hz

74.25 MHz 16:9 Normally DVB Mode

74.25 MHz 16:9 Normally ATSC Mode

148.5 MHz 16:9 Normally ATSC Mode

4:3 Video Graphic Array

4:3 Super VGA

4:3 Extended Graphic Array

4:3 Modied NTSC Standard

4:3 Modied PAL Standard

Page 44

BDL5588XC/55BDL3005X

8. Pixel Defect Policy

We strive to deliver the highest quality products and use some of the industry’s most advanced manufacturing processes whilst practicing stringent quality control. However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects will be repaired during the warranty period in line with your local guarantee conditions.

This notice explains the different types of pixel defects and denes the acceptable defect level for the LCD screen. In order to qualify for repair under warranty, the number of pixel defects must exceed a certain level as shown in the reference table. If the LCD screen is within specication a warranty

exchange / claim back will be refused. Additionally, because some types or combinations of pixel defects are more noticeable than others, Philips sets even higher quality standards for those.

8.1. Pixels and Sub-Pixels

A pixel, or picture element, is composed of three sub-pixels in the primary colors of red, green and

subpixel

pixel

8.2. Types of Pixel Defects + Dot Definition

Pixel and sub-pixel defects appear on the screen in different ways. There are three categories of pixel defects and several types of sub-pixel defects within each category.

Dot denition = What is a defective “Dot”? :

One or more defective, adjacent sub-pixel are dened as one “dot”. The no. of defective sub-pixels are not relevant to dene a defective dot. This means

that a defective dot can consist of one, two or three defective sub-pixels which can be dark or lit.

blue. Many pixels together form an image. When all sub-pixels of a pixel are lit, the three colored sub-pixels together appear as a single white pixel. When all are dark, the three colored sub-pixels together appear as a single black pixel. Other combinations of lit and dark sub-pixels appear as single pixels of other colors.

RR G B

One dot = One Pixel; consists of three sub-pixels of Red, Green, and Blue.

8.3. Bright Dot Defects

Bright dot defects appear as pixels or sub-pixels that are always lit or “on”. These are the examples of bright dot defects:

One lit red, green or blue sub pixel Two adjacent lit sub pixels:

Red + Blue = Purple Red + Green = Yellow Green + Blue = Cyan (Light Blue)

Three adjacent lit sub pixels (one white pixel)

Page 45

BDL5588XC/55BDL3005X

8.4. Dark Dot Defects

Black dot defects appear as pixels or sub-pixels that are always dark or “off”. These are the examples of black dot defects:

One dark dot Two adjacent dark dots = 1 pair of dark dots Two dark dots, specications denes the

minimum distance between dark dots

8.5. Proximity of Pixel Defects

Because pixel and sub-pixels defects of the same type that are nearby one another may be more noticeable, Philips also species tolerances for the proximity of pixel defects. In the table below you can nd specications about:

• Allowed amount of adjacent dark dots = (adjacent dark dots =1 pair of dark dots)

• Minimum distance between dark dots

• Total no. of all defective dots

8.6. Pixel Defect Tolerances

In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or subpixel defects exceeding the tolerances listed in the following table.

BRIGHT DOT EFFECT ACCEPTABLE LEVEL 1 lit sub pixel 2 BLACK DOT EFFECT ACCEPTABLE LEVEL 1 dark sub pixel 10 TOTAL DOT DEFECTS OF ALL TYPES 12

NOTE: * 1 or 2 adjacent sub pixel defects = 1 dot defect

8.7. MURA

Dark spots or patches may occasionally appear on some liquid crystal display (LCD) panels. This is known within the industry as Mura, which is a Japanese

term for “unevenness.” It is used to describe an irregular pattern or area in which uneven screen uniformity appears under certain conditions. Mura is a result of the deterioration of the liquid crystal alignment layer and is most commonly caused by long-term operation under high ambient temperatures. It is an industry- wide phenomenon and Mura is not repairable. It is also not covered by our warranty terms.

Mura has been around since the introduction of LCD technology and with screens getting bigger and in operation 24/7, many displays are running in low

light conditions. This all adds to the possibility of Mura affecting displays.

HOW TO SPOT MURA

There are many symptoms of Mura and also multiple causes. Several of these are listed below:

• Impurities or foreign particles in the crystal matrix

• Uneven distribution of LCD matrix during manufacturing

• Non-uniform luminance distribution of the backlight

• Panel assembly induced stress

• Flaws within the LCD cells

• Thermal induced stress - high temperature operation over long periods of time

HOW TO AVOID MURA

Although we can not guarantee the complete eradication of Mura every time, in general the appearance of Mura can be minimized by these methods:

• Lower the backlight brightness

• Use a screen saver

• Reduce the ambient temperature around the unit

Page 46

BDL5588XC/55BDL3005X

9. Cleaning and Troubleshooting

9.1. Cleaning

Caution When Using the Display

• Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high

temperature of exhaust air being released through the ventilation holes. Burns or personal injuries may occur if any body parts are brought too close. Placing any object near the top of the display could also result in heat related damage to the object as well as the display itself.

• Be sure to disconnect all cables before moving the display. Moving the display with its cables attached may damage the cables and thus cause re

or electric shock.

• Disconnect the power plug from the wall outlet as a safety precaution before carrying out any type of cleaning or maintenance procedure.

Front Panel Cleaning Instructions

• The front of the display has been specially treated. Wipe the surface gently using only a cleaning cloth or a soft, lint-free cloth.

• If the surface becomes dirty, soak a soft, lint-free cloth in a mild detergent solution. Wring the cloth to remove excess liquid. Wipe the surface of

the display to remove dirt. Then use a dry cloth of the same type to dry.

• Do not scratch or hit the surface of the panel with ngers or hard objects of any kind.

• Do not use volatile substances such as insert sprays, solvents and thinners.

Cabinet Cleaning Instructions

• If the cabinet becomes dirty, wipe the cabinet with a soft, dry cloth.

• If the cabinet is extremely dirty, soak a lint-free cloth in a mild detergent solution. Wring the cloth to remove as much moisture as possible. Wipe

the cabinet. Use another dry cloth to wipe over until the surface is dry.

• Do not allow any water or detergent to come into contact with the surface of the display. If water or moisture gets inside the unit, operating

problems, electrical and shock hazards may result.

• Do not scratch or hit the cabinet with ngers or hard objects of any kind.

• Do not use volatile substances such as insert sprays, solvents and thinners on the cabinet.

• Do not place anything made from rubber or PVC near the cabinet for any extended periods of time.

Page 47

9.2. Troubleshooting

Symptom Possible Cause Remedy

BDL5588XC/55BDL3005X

No picture is displayed 1. The power cord is disconnected.

2. The main power switch on the back of the display is not switched on.

3. The selected input has no connection.

4. The display is in standby mode.

Interference displayed on the display or

audible noise is heard

Color is abnormal The signal cable is not connected properly. Make sure that the signal cable is attached rmly to the

Picture is distorted with abnormal patterns 1. The signal cable is not connected

Display image doesn’t ll up the full size of

the screen

Caused by surrounding electrical appliances

or uorescent lights.

properly.

2. The input signal is beyond the capabilities of the display.

1. The zoom mode is not set correctly.

2. Scan Mode may be set incorrectly to underscan.

3. If the image exceeds the screen size, Scan Mode may need to be set to Underscan.

1. Plug in the power cord.

2. Make sure the power switch is switched on.

3. Connect a signal connection to the display.

Move the display to another location to see is the interference is reduced.

back of the display.

1. Make sure that the signal cable is attached rmly.

2. Check the video signal source to see if it is beyond

the range of the display. Please verify its specications with this display’s specication section.

Use the Zoom mode or Custom zoom function in the

Screen menu to ne tune display geometry and time

frequency parameter.

Can hear sound, but no picture Improperly connected source signal cable. Make sure that both video inputs and sound inputs are

correctly connected.

Can see picture but no sound is heard 1. Improperly connected source signal

cable.

2. Volume is turned all the way down.

3. {Mute} is turned on.

4. No external speaker connected.

Some picture elements do not light up Some pixels of the display may not turn on. This display is manufactured using an extremely high level

After-Images can still be seen on the display after the display is powered off. (Examples

of still pictures include logos, video games,

computer images, and images displayed in 4:3

normal mode)

How to setup the settings in the menu to control all the monitors at the same time and

individually via RC?

A still picture is displayed for an over extended period of time

Daisy chained by RS232 and no IR cable 1. The rst display sets as “Primary” on OSD (Advanced

1. Make sure that both video inputs and sound inputs are correctly connected.

2. Press [ ] or [ ] button to hear sound.

3. Switch MUTE off by using the [ ] button.

4. Connect external speakers and adjust the volume to a suitable level.

of precision technology: however, sometimes some pixels of the display may not display. This is not a malfunction.

Do not allow a still image to be displayed for an extended period of time as this can cause a permanent after-image to remain on the display.

option/IR control item), others set as “Secondary”.

2. The setup OSD will show on Top-Left of display.(Toggle

MENU will show again if it disappear)

3. Default setting: ID NO: 0, GP NO: 0, this setting can

control all displays by IR. The “+”, “-” can change “ID NO” to control signal

display by “Monitor ID”. The “UP”, “DOWN” can change “GP NO” to control

multi-display by “Group ID”.

*The rst display always be controlled by IR.

Page 48

BDL5588XC/55BDL3005X

How is the RC working? Daisy chain : no RS232 connected and IR

cable

No need setting, just to connect with IR cables and control by IR.

*This way has out-of-synchronizm phenomenon. Suggest to use above setting with RS-232 cable.

Page 49

BDL5588XC/55BDL3005X

10. Technical Specifications

Display:

Item Specications

Screen Size (Active Area) 54,6” (138.7 cm) LCD Aspect Ratio 16:9 Number of pixels 1920 (H) x 1080 (V) Pixel pitch 0.630 (H) x 0.630 (V) [mm] Displayable colors 1.06B colors Brightness (typical) 500 cd/m2 Contrast ratio (typical) 1400:1 Viewing angle 178 degrees

In/Out Terminals:

Item Specications

Speaker Output Internal Speakers

External Speakers

Audio Output 3.5mm phone jack x 1 0.5V [rms] (Normal) / 2 Channel (L+R) Audio Input RCA Jack x 2

3.5mm phone jack x 1 RS232C 2.5mm Phone jack x 2 RS232C in/RS232C out RJ-45 RJ-45 Jack x 1 (8 pin) 10/100 LAN Port HDMI Input HDMI Jack x 2

(Type A) (18 pin)

DVI-D Input DVI-D jack Digital RGB: TMDS (Video) VGA Input D-Sub Jack x 1 (15 pin) Analog RGB: 0.7V [p-p] (75Ω), H/CS/V: TTL (2.2kΩ), SOG: 1V [p-p] (75Ω)

DVI-I (DVI-D & VGA) Output

Component Input BNC Jack x 3 Y: 1V [p-p] (75Ω), Pb: 0.7V [p-p] (75Ω), Pr : 0.7V [p-p] (75Ω)

Video Input BNC x 1 (Share with

Displayport in/out Displayport Jack x 2

DVI-I Jack x 1 (29 pin) Digital RGB: TMDS (Video)

Component_Y)

(20 pin)

10W (L) + 10W (R) [RMS]/8Ω

82 dB/W/M/160 Hz ~ 13 KHz

0.5V [rms] (Normal) / 2 Channel (L+R)

Digital RGB: TMDS (Video + Audio) MAX: Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)

Audio - 48 KHz/ 2 Channel (L+R)

Supports LPCM only

MAX: 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)

Analog RGB: 0.7V [p-p] (75Ω), H/CS/V: TTL (2.2kΩ), SOG: 1V [p-p] (75Ω) MAX: 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)

MAX: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p Composite 1V [p-p] (75Ω)

Digital RGB: TMDS (Video + Audio) MAX: Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)

Audio - 48 KHz/ 2 Channel (L+R)

Supports LPCM only

Page 50

BDL5588XC/55BDL3005X

General:

Item Specications

Power Supply AC 100 - 240V, 50 - 60Hz, 3.5A Power Consumption (Max) 320 W Power Consumption (typ.) 185 W Power Consumption (Standby & Off) <0.5 W Dimensions (With Stand) [W x H x D] 1213.4 x 726.2 x 400.0 Dimensions (Without Stand) [W x H x D] 1213.4 x 684.2 x 99.25 (@Wall mount) / 107.65 (@Handle) Weight (With Stand) 28.8 Kg Weight (Without Stand) 26.5 Kg

Gross Weight (Without Stand) 42 Kg

Product Fiche :

Item Specications

Energy Efciency Class B Visible Screen Size 138.7 cm / 54.6 inch On Mode Power Consumption (W) 155 W Annual Energy Consumption (kWh) 226 kWh Standby Power Consumption (W) 0.50 W Off Mode Power Consumption (W) 0.50 W Display Resolution (Pixels) 1920 x 1080

Network Standby (W) 0.8W

Environmental Condition:

Item Specications

Temperature Operational 0 ~ 40°C

Storage -20 ~ 60°C

Humidity Operational 20 ~ 80% RH (No condensation)

Storage 5 ~ 95% RH (No condensation)

Altitude Operational 0 ~ 3,000 m

Storage / Shipment 0 ~ 9,000 m

Page 51

Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.

Specications are subject to change without notice.

Philips 55BDL3005X User Guide

Specifications and Main Features
