Philips 50 T User manual

Series 50 T (M1310A) Fetal Telemetry System

SERVICE GUIDE

M1310-9000B Printed in Germany February 2002 Edition 1, A.00.01

Notice

Philips makes no warranty of any kind with regar d to this material , including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Philips shall not be liable for errors contained herein or for incidental or con sequential damages in connection with the fu rnishing, performance o r use of this material.

The information contained in this document is subject to change without notice.

Philips assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Philips.

Responsibility of the Manufacturer

Philips only considers itself responsible for any effects on safety, reliability and performance of the equipment if:

• assembly operations, extensions, re-adjustments, modifications or repairs are carried out by persons authorized by Philips, and

• the electrical installation of the relevant room complies with national standards, and

• the instrument is used in accordance with the Instructions for Use or User’s Guide.

Important

United States federal law restricts this device to sale by or on the order of a physician.

This device is not intended for home use.

Warning Failure on the part of the responsible individual hospital or institution

employing the use of this equipment to implement a satisfactory maintenance schedule may cause und ue equipment failure and possible health hazards.

Printing History

M1310-9000A April 1994 M1310-9000B February 2002

About this Manual

The manual is intended for personnel involved in the service and repair of the M1310 Telemetry System.It enables you to diagnose and repair problems with the minimum of inconvenience to the customer.

The philosophy for on-site diagnosis and repair of the M1310A Telemetry System can be summarized as follows:

• General Repair Strategy

The recommended repair method is replacement of assemblies. Every 12 months, you must carry out a series of preventive maintenance tasks and

performance assurance tests. Details can be found in Chapter 10, “Preventive Maintenance, Care and Cleaning”.

• On-site repair for standard assemblies.

• Bench repair for RF-repair.

For an overview of the system, and how to set it up, please re fer to the Instructions for Use.

Conventional current technical terms are used throughout the manual, and familiarity with these terms is assumed.

The following conventions for cautions and warnings are used in this guide:

Note—A note calls attention to an important point in the text.

Warning A warning calls attention to a condition or possible situation that could cause

injury to the user and/or patient.

Caution A caution calls attention to a condition or possible situation that could damage or destroy the product or the user’s work.

 2002 Philips Medizinsysteme GmbH

All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright holder.
