Register your product and get support at
www.philips.com/welcome
6900 series
User Manual
50PUG6900
58PUG6900
Contents
1 My new TV 4
1.1 Ultra HD TV 4
1.2 Smart TV 4
1.3 App gallery 4
1.4 Rental videos 4
1.5 Social networks 4
1.6 Skype 5
1.7 Pause TV and recordings 5
1.8 Gaming 5
1.9 EasyLink 5
2 Setting up 6
2.1 Read safety 6
2.2 TV stand and wall mounting 6
2.3 Tips on placement 6
2.4 Power cable 6
2.5 Antenna cable 6
3 Network 8
3.1 Wireless network 8
3.2 Wired network 9
3.3 Network settings 9
4 Connections 11
4.1 Tips on connections 11
4.2 EasyLink HDMI CEC 12
4.3 Set-top box - STB 13
4.4 Home Theater System - HTS 13
4.5 Blu-ray Disc player 15
4.6 DVD player 15
4.7 Game console 15
4.8 USB Hard Drive 16
4.9 USB keyboard or mouse 16
4.10 USB flash drive 17
4.11 Photo camera 17
4.12 Camcorder 18
4.13 Computer 18
4.14 Headphones 19
5 Turn on 20
5.1 On or Standby 20
5.2 Keys on TV 20
6 Remote control 21
6.1 Key overview 21
6.2 Keyboard 21
6.3 IR sensor 22
6.4 Pairing with TV 23
6.5 Batteries 23
6.6 Cleaning 23
7 TV channels 24
7.1 Watching TV channels 24
7.2 Channel installation 27
8 Home menu 29
9 TV guide 30
9.1 What you need 30
9.2 Using the TV guide 30
9.3 Recordings 30
10 Sources 31
10.1 Sources list 31
10.2 From standby 31
10.3 EasyLink 31
11 Timers and clock 32
11.1 Sleeptimer 32
11.2 Clock 32
11.3 Switch off timer 32
12 3D 33
12.1 What you need 33
12.2 The 3D glasses 33
12.3 Care of the 3D glasses 34
12.4 Watch 3D 34
12.5 Optimal 3D viewing 34
12.6 Health warning 34
13 Games 36
13.1 Play a game 36
13.2 Two-player games 36
14 Your photos, videos and music 37
14.1 From a USB connection or network computer
37
14.2 Wi-Fi Miracast 38
15 Pause TV 40
16 Recording 41
16.1 What you need 41
16.2 Record a program 41
16.3 Watch a recording 41
17 Skype 43
17.1 About Skype 43
17.2 External camera 43
17.3 Start with Skype 43
17.4 Skype menu 44
17.5 My profile 45
17.6 Contacts 45
17.7 Calling on Skype 46
17.8 Skype credit 47
17.9 Skype settings 48
17.10 Sign out 49
17.11 Quit Skype 49
17.12 Terms of use & Privacy Policy 49
18 Smart TV 50
18.1 About Smart TV 50
18.2 What you need 50
18.3 Setup Smart TV 50
18.4 Smart TV Apps 50
18.5 Multi view 52
18.6 Reset Smart TV 52
19 Multi room 53
19.1 About Multi room 53
19.2 What you need 53
19.3 Using Multi room 53
20 Share this… 54
21 Settings 55
21.1 Setup menu 55
21.2 Picture 55
21.3 Sound 58
21.4 Universal access - Key beep 60
22 Specifications 61
22.1 Environmental 61
22.2 Reception 62
2
22.3 Display 62
22.4 Power 62
22.5 Dimensions and weights 62
22.6 Connectivity 62
22.7 Multimedia 63
23 Software 64
23.1 Software update 64
23.2 Software version 64
23.3 Open source software 64
23.4 Open-source license 64
24 Troubleshooting and support 71
24.1 Troubleshooting 71
24.2 Register 72
24.3 Help 72
24.4 Online help 73
24.5 Consumer Care / Repair 73
25 Safety and care 74
25.1 Safety 74
25.2 Screen care 75
26 Terms of use, copyrights and licenses
76
26.1 Terms of use 76
26.2 Copyrights and licenses 76
Index 79
3
1
1.3
My new TV
1.1
Ultra HD TV
This TV has an Ultra HD display. Its resolution is
four times higher than normal HD displays. Ultra HD
means 8 million pixels for the most refined and
lifelike picture on a TV.
On top, the new Ultra Pixel HD Engine continuously
converts any incoming TV signal into Ultra HD
resolution. So you can enjoy this stunning picture
quality the moment you turn on the TV. Ultra HD
offers TV viewing that is crisp and sharp, even on a
big screen.
App gallery
Open the App gallery in Smart TV to browse the
Apps, the collection of tailored websites for TV.
Find the App for YouTube videos, a national
newspaper, an online photo album, Twitter, etc.
There are Apps for renting videos from an online
video store and Apps for watching programs you
missed.
If the App gallery does not have what you are
looking for, try the World Wide Web and surf the
Internet on TV.
In Help, press Keywords and look up App
gallery for more information.
1.4
Rental videos
To watch a rental video, you don't need to leave your
home.
Simply rent the latest movie from your regional online
video store.
1.2
Smart TV
Connect this Philips Smart LED TV to the Internet and
discover a new world of television. You can make a
wired connection to your router or you can link up
wirelessly with Wi-Fi.
With the TV connected to your home network, a
smartphone can show a photo on TV, you can play
videos stored on your computer or control the TV with
your tablet.
With your TV connected to the Internet, you can
watch a rental video from an online video store, read
the online TV guide or record your favorite TV show
on a USB Hard Drive.
The Smart TV Apps add to the fun with all sorts of
entertainment and convenient services.
In Help, press Keywords and look up Smart TV
for more information.
Start Smart TV and add the video store App to the
Smart TV start page.
Open the video store App, create your personal
account, select the movie and press play.
No fuss with downloading, you can watch the
movie immediately.*
In Help, press Keywords and look up Rental
videos for more information.
* Depending on the video streaming service of the
selected video store.
1.5
Social networks
No need to get up to check your friend's messages on
your computer.
Open Smart TV, select your social network page and
send a message back from your couch.
4
Smart TV supports the popular social networks
Twitter.
In Help, press Keywords and look up App
gallery for more information.
1.6
Skype
With Skype™ you can make video calls on your TV for
free.
You can call and see your friends from anywhere in
the world.
To make a video call, you need a camera with a builtin microphone and a good connection to the Internet.
Some Philips TVs have a camera and microphone
built in.
1.8
Gaming
If you select your game console in the Home menu,
the TV switches to the settings ideal for gaming
automatically.
If you play a multi-player game with split screens, you
can set the TV to show each screen as a full screen
simultaneously.
Each player can focus on his own game to play.
The TV uses 3D technology to show both screens. To
play a two-player game with two different full screen
pictures, you need a pair of 3D glasses for each
player.
In Help, press Keywords and look up Game
console or Two player games for more information.
In Help, press Keywords and look
up Skype for more information.
1.7
Pause TV and recordings
If you connect a USB Hard Drive, you can pause and
record a broadcast from a digital TV channel.
Pause your TV and answer that urgent phone call or
simply take a break during a sports game, while the
TV stores the broadcast on the USB Hard Drive. You
can start watching again later.
With a USB Hard Drive connected, you can also
record digital broadcasts. You can record while you
are watching a program or schedule a recording of an
upcoming program.
1.9
EasyLink
With EasyLink you can operate a connected device,
like a Blu-ray Disc player, with the remote control of
the TV.
EasyLink uses HDMI CEC to communicate with the
connected devices.
In Help, press Keywords and look
up EasyLink for more information.
In Help, press Keywords and look up Pause TV
or Recording for more information.
5
2
accident or injury.
Setting up
2.1
Read safety
Read the safety instructions first before you use the
TV.
In Help, go to Safety and care > Safety.
2.2
TV stand and wall mounting
TV stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it from
www.philips.com.
Use the product type number of the TV to look for the
Quick Start Guide to download.
2.3
Tips on placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal
screen size. When seated, your eyes should be level
with the center of the screen.
2.4
Power cable
Wall mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
• For 58-inch TV: VESA MIS-F 400x400, M6
• For 50-inch TV: VESA MIS-F 400x200, M6
• For 40-inch TV: VESA MIS-F 200x100, M4
To attach the bracket securely, use screws of the
length indicated in the drawing.
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
In Help, press Keywords and look up Turning on
for more information about turning the TV on or off.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TV's weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
6
2.5
Antenna cable
Insert the antenna plug firmly into the ANTENNA
socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
7
3
Network
3.1
Wireless network
What you need
To connect the TV wirelessly to the Internet, you need
a wireless router. Use a high-speed (broadband)
connection to the Internet.
Protected Setup), you can select WPS. Select your
choice and press OK.
• Scan
Select Scan to scan for your wireless network (your
wireless router). The TV might find several wireless
networks in your proximity.
• WPS
If your router has WPS, you can directly connect to
the router without scanning. Go to the router, press
the WPS button and return to the TV within 2 minutes.
Then press Connect to make the connection.
If you have devices in your wireless network that use
the WEP security encryption system, you cannot use
WPS.
If you must use the WPS PIN code to connect, select
Scan instead of WPS.
Step 7 - From the list of networks found, select your
wireless network and press OK.
If your network is not in the list because the network
name is hidden (you turned off the SSID broadcast of
the router), select Manual entry to enter the network
name yourself.
Network devices
The TV can connect to other devices in your wireless
network, like your computer or smartphone. You can
use a computer with Microsoft Windows or Apple OS
X.
File sharing
On this TV, you can open photos, music and videos
stored on your computer. Use a recent version of
media server software like Philips MediaManager*,
Windows Media Player 11, Twonky™ or similar.
Install the media server software on your computer
and set it up to share your media files with the TV.
Read the manual of the media server software for
more information. This software must be running on
your computer to view or play your files on TV.
* You can download the Philips MediaManager
software from the Philips support
site www.philips.com/support
Step 8 - Depending on the type of router, you can
now enter your encryption key (WEP, WPA or WPA2).
If you have entered the encryption key for this
network before, you can select Next to make the
connection immediately.
If your router supports WPS or WPS PIN, you select
WPS, WPS PIN or Standard. Select your choice and
press OK.
• Standard
Select Standard to enter the encryption key
(password, passphrase or security key) manually. You
can use the keyboard on the RC to enter the
encryption key. Once you have entered the key, press
Connect.
• WPS PIN
To make a secured WPS connection with a PIN code,
select WPS PIN and press OK. Write down the 8-digit
PIN code shown and enter it in the router software on
your PC. Return to the TV and press Connect. Consult
the router manual on where to enter the PIN code in
the router software.
Step 9 - A message will be shown when the
connection is successful.
Make the connection
Follow steps 1 to 9.
Step 1 - Make sure that the router of your wireless
network is turned on.
Step 2 - Press and select Setup and press OK.
Step 3 - Select Connect to network and press OK.
Step 4 - Select Connect and press OK.
Step 5 - Select Wireless and press OK.
Step 6 - Select Scan to scan for your wireless
network. If you have a router with WPS (Wi-Fi
Network configuration
If the connection fails, you can check the DHCP
setting of the router. DHCP should be set to On.
Alternatively, if you are an advanced user and want to
install your network with Static IP addressing, set the
TV to Static IP.
To set the TV to Static IP, press and select Setup
and press OK. Select Network settings > Network
settings > Network configuration > Static IP. With
Static IP selected in the menu, you can set the IP
address and other necessary settings in Static IP
8
configuration in the same menu.
Network problems
Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi
802.11b/g/n devices in your proximity might disturb
the wireless network.
• Make sure that the firewalls in your network allow
access to the TV's wireless connection.
• If the wireless network does not work properly in
your home, try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the
router connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.
• Use a high-speed (broadband) Internet connection
for your router.
3.2
Wired network
Connect the router
To connect and setup the router follow steps 1 to 5.
1 - Connect the router to the TV with a network cable
(Ethernet cable**).
2 - Make sure that the router is turned on.
3 - Press and select Setup and press OK.
4 - Select Connect to network and press OK.
5 - Select Wired and press OK.
The TV constantly searches for the network
connection. A message will be shown when the
connection is successful.
Network configuration
If the connection fails, you can check the DHCP
setting of the router. DHCP should be set to On.
Alternatively, if you are an advanced user and want to
install your network with Static IP addressing, set the
TV to Static IP.
To set the TV to Static IP, press and
select Setup and press OK.
Select Network settings > Network
settings > Network configuration > Static IP. With
Static IP selected in the menu, you can set the IP
address and other necessary settings in Static IP
configuration in the same menu.
**To fulfill EMC regulations, use a shielded FTP Cat.
5E Ethernet cable.
What you need
You need a network router to connect the TV to the
Internet. Use a router with a high-speed (broadband)
connection to the Internet.
File sharing
On this TV, you can open photos, music and videos
stored on your computer. Use a recent version of
media server software like Windows Media Player 11,
Twonky™ or similar.
Install the media server software on your computer
and set it up to share your media files with the TV.
Read the manual of the media server software for
more information. This software must be running on
your computer to view or play your files on TV.
3.3
Network settings
To open the Network settings . . .
1 - Press and select Setup and press OK.
2 - Select Network settings and press OK.
• View network settings
All current network settings are shown here. The IP
and MAC address, signal strength, speed, encryption
method, etc.
• Network settings
- Network type
Sets the network to Wired or Wireless.
- Network configuration
Sets the network configuration to DHCP or Static IP.
• Wi-Fi media playback
To receive multimedia files from smartphones or
tablets, set the DMR to On.
• Static IP configuration
If Static IP is selected, you can set all necessary static
9
IP settings here.
• Wi-Fi Miracast
For more information on Wi-Fi Miracast,
press Keywords and look up Wi-Fi Miracast™.
• Reset Wi-Fi Miracast group
Clear the list of connected and blocked devices that
are used with Miracast.
• Wi-Fi smart screen
For more information on Wi-Fi smart screen,
press Keywords and look up Wi-Fi smart
screen.
• TV network name
If you have more than one TV in your network, you
can rename the TVs here.
• Netflix settings
Adjust Netflix settings.
• Clear Internet memory
With Clear Internet Memory, you clear all Internet files
stored on your TV. You clear your
Philips Smart TV registration and parental control
settings, video store app logins, Smart TV app
favorites, and Internet bookmarks and history.
Interactive MHEG applications save cookies to your
TV. These files are also cleared.
10
4
EasyLink HDMI CEC
Connections
4.1
Tips on connections
Connectivity guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
If you need help to connect several devices to the TV,
you can visit the Philips TV connectivity guide. The
guide offers information on how to connect and
which cables to use.
Go to www.connectivityguide.philips.com
Antenna
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
If your devices are connected with HDMI and have
EasyLink, you can operate them with the TV remote
control. EasyLink HDMI CEC must be turned On on
the TV and the connected device.
For more information on using EasyLink, press
Keywords and look up EasyLink CEC.
DVI to HDMI
Use a DVI to HDMI adapter if your device only has a
DVI connection. Use one of the HDMI connections
and add an Audio L/R cable (mini-jack 3.5mm) to
Audio In for sound, on the back of the TV.
Copy protection
DVI and HDMI cables support HDCP (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
HDMI ARC
All of the HDMI connections on the TV have HDMI
ARC (Audio Return Channel).
If the device, typically a Home Theater System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.
You can use any HDMI connection on this TV to
connect the HTS but ARC is only available for 1
device/connection at a time.
HDMI
HDMI CEC
HDMI connections provide the best picture and
sound quality. HDMI cables combine video and audio
signals. Use an HDMI cable for high-definition (HD)
and TV signals. For best signal quality, use a highspeed HDMI cable, and do not use HDMI cables
longer than 5 m.
In case you prefer to turn off ARC on the HDMI
connections, press and select Setup and press OK.
Select TV settings > Sound > Advanced > HDMI ARC.
HDMI Ultra HD
You can watch videos filmed or made in 'native' Ultra
HD resolution - 3840x2160 pixels - on this TV.
Connect a Blu-ray Disc player, game console or
computer that plays Ultra HD videos to the HDMI 3
connection. Use a High speed HDMI cable to connect.
The HDMI UHD connections have ARC (Audio Return
Channel).
Only the HDMI 3 connection has HDCP 2.2 .
11
Video-Audio LR
EasyLink
CVBS - Component Video is a high quality
connection. Next to the CVBS signals add the Audio
Left and Right signals for sound.
Audio Out - Optical
Audio Out - Optical is a high quality sound
connection. This optical connection can carry 5.1
audio channels. If your device, typically a Home
Theater System (HTS), has no HDMI ARC connection,
you can use this connection with the Audio In Optical connection on the HTS. The Audio Out Optical connection sends the sound from the TV to
the HTS.
With EasyLink you can operate a connected device
with the TV remote control. EasyLink uses HDMI CEC
(Consumer Electronics Control) to communicate with
the connected devices. Devices must support HDMI
CEC and must be connected with an HDMI
connection.
EasyLink setup
The TV comes with EasyLink turned on. Make sure
that all HDMI CEC settings are properly set up on the
connected EasyLink devices. EasyLink might not work
with devices from other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink.
Example HDMI CEC branding names are property of
their respective owners.
You can set the type of the audio out signal to fit the
audio capabilities of your Home Theater System.
For more information, press Keywords and look
up Audio Out settings.
If the sound does not match the video on screen, you
can adjust the audio to video synchronization.
For more information, press Keywords and look
up Audio to video sync.
4.2
EasyLink HDMI CEC
Operate devices
To operate a device connected to HDMI and set up
with EasyLink, select the device - or its activity - in
the list of TV connections. Press SOURCES , select
a device connected to an HDMI connection and press
OK.
Once the device is selected, the TV remote control
can control the device. However and OPTIONS
keys and some other TV keys are not forwarded to
the device.
If the key you need is not on the TV remote control,
you can select the key in the Options menu.
Press OPTIONS and select Controls in the menu
bar. On the screen, select the device key you need
and press OK.
Some very specific device keys might not be available
in the Controls menu.
Note: Only devices that support EasyLink remote
12
control function will respond to the TV remote
control.
EasyLink settings
The TV comes with all EasyLink settings turned on.
You can turn off any EasyLink setting independently.
EasyLink
To turn off EasyLink completely . . .
1 - Press and select Setup and press OK.
2 - Select TV settings > General settings > EasyLink.
3 - Select Off and press OK.
4 - Press , repeatedly if necessary, to close the
menu.
EasyLink Remote Control
If you want devices to communicate but you don't
want to operate them with the TV remote control, you
can turn off EasyLink remote control separately.
In the EasyLink settings menu, select EasyLink
Remote Control and select Off.
Next to the antenna connections, add an HDMI cable
to connect the Set-top box to the TV.
Switch off timer
Switch off this automatic timer if you only use the
remote control of the set-top box. This prevents the
TV from turning off automatically after 4 hours
without a key press on the TV remote control.
To turn off the Switch off timer, press and
select Setup and press OK.
Select TV settings > General settings > Switch off
timer and set the slider bar to Off.
Pixel Plus link
Some devices, a DVD or Blu-ray Disc player, might
have their own picture quality processing. To avoid
bad picture quality caused by interference with the
TV processing, the picture processing of these devices
should be disabled. The TV comes with Pixel Plus link
turned on and disables the picture quality processing
of recent Philips devices connected to the TV.
To turn off Pixel Plus link, in the EasyLink settings
menu, select Pixel Plus link and select Off.
Auto turn off devices
You can set the TV to turn off the connecting HDMICEC compliant devices if
they are not the active source. The TV switches the
connected device to standby after 10 minutes of
inactivity.
4.3
Set-top box - STB
Use 2 antenna cables to connect the antenna to the
Set-top box (a digital receiver) and the TV.
4.4
Home Theater System - HTS
Connect HTS
Use an HDMI cable to connect a Home Theater
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
Alternatively, you can use a SCART cable, if the
device has no HDMI connection.
HDMI ARC
If your Home Theater System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal, but once you have
connected the Home Theater System, the TV can
only send the ARC signal to this HDMI connection.
If the Home Theater System has no HDMI ARC
connection, add an optical audio cable to send the
13
sound of the TV picture to the Home Theater System.
Out delay setting should be turned on.
To synchronize the sound on the TV . . .
1 - Press and select Setup and press OK.
2 - Select TV
settings > Sound > Advanced > Audio Out offset.
3 - Use the slider bar to set the sound offset and
press OK.
4 - Press , repeatedly if necessary, to close the
menu.
Audio to video synchronization (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theater Systems with
a disc player to match the sound with the video.
For more information, press Keywords and look
up Audio to video sync.
Audio Out settings
Audio Out delay
With a Home Theater System (HTS) connected to the
TV, the picture on the TV and the sound from the HTS
should be synchronized.
Automatic audio to video sync
With recent Philips Home Theater Systems, the audio
to video sync is done automatically.
Audio sync delay
For some Home Theater Systems you may need to
adjust the audio sync delay to synchronize the audio
to the video. On the HTS, increase the delay value
until there is a match between picture and sound. A
delay value of 180ms may be required. Read the user
manual of the HTS. With a delay value set up on the
HTS, you need to turn off Audio Out delay on the TV.
To turn off the Audio Out delay . . .
1 - Press and select Setup and press OK.
2 - Select TV settings > Sound > Advanced > Audio
Out delay.
3 - Select Off and press OK.
4 - Press , repeatedly if necessary, to close the
menu.
Audio Out offset
Audio Out format
If you have a Home Theater System (HTS)
with multichannel sound processing capabilities like
Dolby Digital, DTS® or similar, set the Audio out
format to Multichannel. With Multichannel, the TV can
send the compressed multichannel sound signal from
a TV channel or connected player to the Home
Theater System. If you have a Home Theater System
without multichannel sound processing, select Stereo.
To set the Audio Out format . . .
1 - Press and select Setup and press OK.
2 - Select TV
settings > Sound > Advanced > Audio Out
format.
3 - Select Multichannel or Stereo.
4 - Press , repeatedly if necessary, to close the
menu.
Audio Out leveling
Use the Audio Out leveling setting to level the volume
(loudness) of the TV and the Home Theater System
when you switch over from one to another. Volume
differences can be caused by differences in sound
processing.
To level the difference in volume . . .
1 - Press and select Setup and press OK.
2 - Select TV
settings > Sound > Advanced > Audio Out
leveling.
3 - If the volume difference is large, select More. If
the volume difference is small, select Less.
4 - Press , repeatedly if necessary, to close the
menu.
Audio Out leveling affects both the Audio Out Optical and HDMI ARC sound signals.
If you cannot set a delay on the Home Theater
System, you can set the TV to sync the sound. You
can set an offset that compensates for the time
necessary for the Home Theater System to process
the sound of the TV picture. You can set the value in
steps of 5ms. Maximum setting is -60ms. The Audio
14
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theater System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theater System has no DTS sound processing.
You can fix this by setting the Audio Out format of the
TV to Stereo.
Press and select Setup > TV
settings > Sound > Advanced > Audio out format.
No sound
If you cannot hear the sound from the TV on your
Home Theater System, check the following . . .
• Check if you connected the HDMI cable to an HDMI
ARC connection on the Home Theater System. All
HDMI connections on the TV are HDMI ARC
connections.
• Check if the HDMI ARC setting on the TV is turned
On.
Go to Home > Setup > TV settings > Sound >
Advanced > HDMI ARC.
4.6
DVD player
Use an HDMI cable to connect the DVD player to the
TV.
If the DVD player is connected with HDMI and has
EasyLink CEC, you can operate the player with the TV
remote control.
For more information on EasyLink,
press Keywords and look up EasyLink HDMI
CEC.
4.7
4.5
Blu-ray Disc player
Use a High speed HDMI cable to connect the Blu-ray
Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC,
you can operate the player with the TV remote
control.
For more information on EasyLink, press
Keywords and look up EasyLink HDMI CEC.
Game console
HDMI
For best quality, connect the game console with a
high-speed HDMI cable to the TV.
Video-Audio LR
Connect the game console with a composite cable
(CVBS) and an audio L/R cable to the TV.
15
4.8
USB Hard Drive
What you need
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive. If you
want to record a broadcast with TV guide data from
the Internet, you need to have the Internet
connection installed on your TV before you install the
USB Hard Drive. Formatting removes all files from the
USB Hard Drive.
1 - Connect the USB Hard Drive to one of the USB
connections on the TV. Do not connect another USB
device to the other USB ports when formatting.
If you connect a USB Hard Drive, you can pause or
record a TV broadcast. The TV broadcast must be a
digital broadcast (DVB broadcast or similar).
To pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 32GB of
disk space.
To record
To pause and record a broadcast, you need a
minimum of 250GB of disk space.
TV guide
Before you decide to buy a USB Hard Drive to record,
you should check if it is possible to record digital TV
channels in your country.
Press TV GUIDE on the remote control. If there is
a Record button on the TV guide page, you can
record.
For more information on how to install a USB Hard
Drive, press Keywords and look up USB Hard
Drive, installation.
2 - Turn on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
For more information, press Keywords and look
up Pause TV or Recording.
4.9
USB keyboard or mouse
USB keyboard
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
You can connect a keyboard and a mouse to the TV.
Use one of the USB connections to connect.
16
Install the keyboard
To install the USB keyboard, turn on the TV and
connect the USB keyboard to one of the USB
connections on the TV. When the TV detects the
keyboard for the first time, you can select your
keyboard layout and test your selection. If you select
a Cyrillic or Greek keyboard layout first, you can
select a secondary Latin keyboard layout.
To change the keyboard layout setting when a layout
was selected…
1 - Press and select Setup and press OK.
2 - Select TV settings > General settings > USB
keyboard settings and press OK.
Keys for channel renaming
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary
layout is set, press the Ctrl + Shift keys
simultaneously.
Keys for Smart TV Apps and Internet pages
• Shift+Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• + = zoom in one step
• - = zoom out one step
• * = fit the web page to the screen width
You can use the scroll wheel to scroll pages up and
down.
For more information on how to connect a keyboard,
press Keywords and look up USB keyboard.
Mouse speed
You can adjust the speed of the mouse moving on
screen.
To adjust the speed . . .
1 - Press and select Setup and press OK.
2 - Select TV settings and press OK.
3 - Select General settings > Mouse settings and
press OK.
4 - Press the arrows (up) or (down) to increase
or decrease the speed.
5 - Press OK to store and close the setting.
6 - Press , repeatedly if necessary, to close the
menu.
4.10
USB flash drive
You can view photos or play your music and videos
from a connected USB flash drive.
Insert a USB flash drive in one of the USB
connections on the TV while the TV is turned on.
USB mouse
Connect USB mouse
You can connect a USB mouse (USB-HID type) to
navigate pages on the Internet.
On an Internet page, you can select and click on links
more easily.
Connect the mouse
Turn the TV on and connect the USB mouse to one of
the USB connections on the TV. You can also connect
the USB mouse to a connected USB keyboard.
The TV detects the flash drive and opens a list
showing its content.
If the contents list does not appear automatically,
press SOURCE , select USB and press OK.
To stop watching the USB flash drive content, press
or select another activity.
To disconnect the USB flash drive, you can pull out
the flash drive anytime.
For more information on watching or playing content
from a USB flash drive, press Keywords and look
up Your photos, videos and music.
Mouse clicks
• Left click = OK
• Right click = Back
17
4.11
Photo camera
To view photos stored on your digital photo camera,
you can connect the camera directly to the TV.
Use one of the USB connections on the TV to
connect. Turn on the camera after you have made the
connection.
4.13
Computer
Connect
If the contents list does not appear automatically,
press SOURCE , select USB and press OK.
Your camera might need to be set to transfer its
content with PTP (Picture Transfer Protocol). Read
the user manual of the digital photo camera.
For more information on viewing photos, press
Keywords and look up Your photos, videos and
music.
4.12
Camcorder
HDMI
For best quality, use an HDMI cable to connect the
camcorder to the TV.
You can connect your computer to the TV and use
the TV as a PC monitor.
With HDMI
Use an HDMI cable to connect the computer to the
TV.
With DVI to HDMI
Alternatively, you can use a DVI to HDMI adapter to
connect the PC to HDMI and an audio L/R cable (minijack 3.5mm) to AUDIO IN L/R on the back of the TV.
Video-Audio LR
Use a Video Audio L/R cable to connect the
camcorder to the TV.
18
Settings
Ideal monitor setting
If your computer is added as a Computer type of
device in the Source menu (the list of connections),
the TV is set to the ideal Computer setting
automatically.
If you use your computer to watch movies or use it to
play games, you might want to set the TV back to the
ideal TV watching or gaming setting.
To set the TV to the ideal setting manually . . .
1 - Press and select Setup and press OK.
2 - Select TV settings > Picture > Advanced >
Activity style and press OK.
3 - Select Game (for gaming) or
select Computer (for watching a movie) and
press OK.
4 - Press , repeatedly if necessary, to close the
menu.
Remember to set the Game or computer setting back
to Computer when you stop playing the game.
4.14
Headphones
You can connect a set of headphones to the
connection on the TV. The connection is a mini-jack
3.5mm. You can adjust the volume of the headphones
separately.
To adjust the volume . . .
1 - Press and select Setup and press OK.
2 - Select TV settings > Sound > Headphones
volume and press OK.
3 - Press (up) or (down) to adjust the volume.
4 - Press , repeatedly if necessary, to close the
menu.
19
5
Turn on
5.1
On or Standby
Make sure you have plugged in the main power on
the back of the TV before you turn on the TV.
If the red indicator light is off, press the Joystick on
the right side on the back of the TV to put the TV in
standby - the red indicator will light up.
With the TV in standby, press on the remote
control to turn the TV on.
Switch to standby
To switch the TV to standby, press on the remote
control.
Turn Off
To turn the TV Off, press the Joystick on the right of
the TV on the back. The red indicator light is off. The
TV is still connected to the main power but consumes
a minimum of energy.
To turn off the TV completely, disconnect the power
plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
5.2
Keys on TV
While the on-screen display is on, press the Joystick
to display the menu.
• Use the arrow/navigation keys to navigate up, down,
left or right.
• Press the Joystick to confirm a selection or setting.
20
6
Remote control
To open the Smart TV start page.
2 - Color keys
Follow the on-screen instructions.
6.1
Key overview
Top
1 - Standby / On
To turn the TV On or back to Standby.
2 - Playback and record keys
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to fast forward
• Record , to record now
3 -
To select an Ambilight setting.
Ambilight
3 - INFO
To open or close program info.
4 - BACK
To switch back to the previous channel you selected.
To close a menu without changing a setting.
To go back to the previous Smart TV page.
5 - HOME
To open or close the home menu.
6 - EXIT
To switch back to watching TV.
7 - OPTIONS
To open or close the Options menu.
8 - OK key
To confirm a selection or setting.
9 - Arrow / navigation keys
To navigate up, down, left or right.
10 - MULTIVIEW
To open an extra small screen.
Bottom
4 - TV GUIDE
To open or close the TV guide.
5 - Settings
To open the Settings menu.
6 - Picture format
To open or close the Picture format menu.
7 - SOURCES
To open or close the Sources menu - the list of
connected devices.
8 - SEARCH
To open the Popular searches page.
Middle
1 -
To adjust the volume level.
2 - Number keys and text keypad
To select a TV channel directly or to enter text.
3 - CC
To turn subtitles on, off, or on during mute.
4 - LIST
To open or close the channel list.
5 - Channel
To switch to the next or previous channel in the
channel list.
To open the next or previous page in Text or start the
next or previous chapter on a disk.
Volume
1 - SMART TV
6 -
To mute the sound or to restore it.
7 - (Dot)
To enter digital sub-channels.
21
Mute
6.2
Keyboard
Overview
Overview of a keyboard.
1 - Character
Character position.
2 - Shift
To type uppercase characters.
3 - Ω Special characters
To open the onscreen keyboard to select accented
characters or symbols.
4 - Fn key
To type a number or punctuation character.
5 - Spacebar
Enter a space.
6 - Navigation and OK
Navigate through the menus, and confirm a selection.
7 -
Delete the character in front of the text cursor.
8 - Share this
To share online what you are now watching.
Writing text
With the keyboard on the back of the remote control,
you can write text in any text field on screen. Turn the
keyboard facing upwards to activate the keyboard
keys. Hold the remote control with two hands and
type with both thumbs.
Uppercase and lowercase
• To type an uppercase character, press the
(Shift) key just before you type the character.
• To type several uppercase characters consecutively,
press and hold the key while typing.
• To type uppercase constantly, press the key for
2 seconds to switch the keyboard in uppercase mode.
• To switch out of uppercase mode, press the key
again. If no keys are pressed for 20 seconds,
uppercase mode turns off automatically. Also, if you
press another modifier key, like Fn or Ω, you switch
out of uppercase mode.
Numbers and punctuation characters
• To type a number or punctuation character, press
the Fn key just before you type the number or
punctuation character you need. You can turn the Fn
mode on or off as you would for the uppercase
mode.
Internet
• You can use the Fn key to enter www. or .com.
Accented letters and symbols
Accented characters and symbols are not directly
available on the remote control keyboard.
To type such a character, you can open the onscreen
keyboard.
To open the onscreen keyboard, press Ω. In the
onscreen keyboard, you can navigate to the character
you need. Switch the keyboard layout with the color
keys. Press OK to enter a character. The onscreen
keyboard disappears when you press a character on
the remote control keyboard.
Alternatively, you can enter special characters with
the remote control SMS/text keypad on the front of
the remote control.
6.3
Enter text
• To enter text into a text field, select the text field and
start typing. Press OK to confirm the text.
IR sensor
The remote control of the TV uses RF (radio
frequency) to send its commands to the TV. With RF,
you do not need to point the remote control at the
TV.
However, the TV can also receive commands from a
remote control that uses IR (infrared) to send
commands. If you use such a remote control, always
make sure you point the remote control at the
infrared sensor on the front of the TV.
22
6.4
again.
6.5
Batteries
If the TV does not react on a key press on the remote
control, the batteries might be empty.
To replace the batteries, open the battery
compartment on the keyboard side of the remote
control.
Pairing with TV
This remote control uses radio frequency (RF) to send
its commands to the TV. Unlike remote controls using
infrared signals, with this remote control you can send
commands without pointing at the TV.
The TV will notify you when the battery power of the
remote control is low.
Pairing the remote control
For the remote control to communicate with the TV,
both TV and remote control should be paired with
each other. Once paired, you cannot use the remote
control to control another TV.
When you started the initial TV installation, the TV
asked you to press the OK key, and by doing so, the
pairing was done. When you turn off the TV, the
pairing is stored. You can pair up to 5 remote controls
with this TV.
Pairing again
You can pair another remote control with this TV.
The method to pair a remote control is different for a
remote control already paired with another TV
compared with a remote control that is not paired yet.
• The remote control is paired with another TV
To pair, hold the remote control close to the Philips
logo (about 4 in) and press the Red and Blue
key at the same time. A message will appear if pairing
is successful.
• The remote control is not paired yet
To pair, hold the remote control close to the Philips
logo (about 4 in) and press OK. A message will
appear if pairing is successful.
For retail
1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2 type AAA-
LR03-1.5V alkaline batteries. Make sure the + and the
- ends of the batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.
Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.
For more information, press Keywords and look
up End of use.
6.6
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
To pair a new — not yet paired — TV with a remote
control which is already paired with another TV, hold
the remote control close to the Philips logo (about 4
in) and press the Red and Blue key at the
same time. A message will appear if pairing is
successful.
Note:
If the remote control is still fail to pair the TV,
press > Setup > TV settings > General
settings > Reinstall TV, then repeat pairing step
23
7
Channel list
TV channels
7.1
Watching TV channels
Switch channels
To watch TV channels, press . The TV tunes to the
TV channel you last watched.
Alternatively, press to open the Home menu and
select Watch TV and press OK.
To switch channels, press
know the channel number, type in the number with
the number keys. Press OK after you entered the
number to switch channels.
or
. If you
Favorite channels
You can create a favorite channel list that only holds
the channels you want to watch. With the Favorite
channel list selected, you will only see your favorite
channels when you switch through channels.
Create your favorite channel list
1 - While watching a TV channel, press
open the channel list.
2 - Select the channel and press Mark as
favorites. The selected channel is marked with a .
3 - To finish, press . The channels are added to
the Favorites list
To remove a channel from the Favorites list, select the
channel and press Remove.
Channel list views
In the channel lists, you can find all installed TV and
radio channels.
Channel list options
According to the channel list on screen,
press OPTIONS to select one of the options.
LIST to
To switch back to the previously tuned channel,
press .
To switch to a channel from a channel list
While watching a TV channel, press LIST to open
the channel lists.
In a channel list, navigate to a TV channel or radio
station. With its icon highlighted, press OK to change
the TV channel or listen to the radio station.
The channel list can have several pages with
channels. To view the next or previous page,
press
To close the channel lists without switching channels,
press LIST again.
or
.
Channel logos
In some countries, the TV can show the channel
logos. If you do not want these logos to appear, you
can turn them off.
To turn off Channel logos . . .
1 - Press and select Setup and press OK.
2 - Select TV settings > General
settings > Channel logos and press OK.
3 - Select Off and press OK.
4 - Press , repeatedly if necessary, to close the
menu.
Radio channels
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel. A
cable channel installation usually places radio
stations from channel number 1001 onwards.
Rename channels
You can rename channels in the channel list.
1 - Select the channel you want to rename in one of
the channel lists.
24
2 - Press Rename.
3 - You can enter text with the remote control
keyboard or open the on-screen keyboard.
With the remote control keyboard
• To delete a character, position the cursor behind the
character and press .
• To enter a character, press the character on the
keyboard.
• When you are ready, press OK to select Done. Press
OK again to finish renaming.
For more information on using the keyboard, press
Keywords and look up Remote control, keyboard.
With the on-screen keyboard
• To open the on-screen keyboard, place the cursor in
the name text field and press OK.
• To delete the character in front of the cursor, press
Backspace .
• To enter a character, select the character with the
arrow keys and press OK.
• To select uppercase characters, press .
• To select numbers or special characters, press .
• When you are ready, press to close the onscreen keyboard.
• To finish renaming, select Done and press OK.
Lock a channel
To prevent children from watching a channel or a
program, you can lock channels or lock age rated
programs.
Lock a channel
You can lock a channel to prevent children from
watching it. To watch a locked channel you need to
enter the Child lock code.
You cannot lock programs from connected devices.
To lock a channel . . .
1 - While watching a TV channel, press LIST to
open the Channel list.
2 - In any list, select the channel you want to lock.
3 - Press OPTIONS and select Lock channel. In a
channel list, a locked channel is marked with a lock .
suitable for their age, you can use an age rating.
Some digital broadcasters have age rated their
programs. When the age rating of a program is equal
to or higher than the age you have set as age rating
for your child, the program will be locked.
To watch a locked program you must enter the child
lock code. The parental age rating is set for all
channels.
To set an age rating . . .
1 - Press and select Setup and press OK.
2 - Select Channel settings > Child lock > Age ratings
lock and press OK.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set code and press OK. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
4 - Set the age and press OK.
5 - Press , repeatedly if necessary, to close the
menu.
The TV will ask for the code to unlock the program.
For some broadcasters / operators, the TV only locks
programs with a higher rating.
Content rating
You can block programs with objectionable content.
1 - Press and select Setup and press OK.
2 - Select Channel settings > Child lock > Content
ratings lock.
3 - If no child lock code is set, you must enter one
now. Enter a 4-digit code.
4 - Set the content and press OK. The selected
content is blocked.
5 - Press , repeatedly if necessary, to close the
menu.
Set or change the lock code
To set the lock code or to change the current code . . .
1 - Press and select Setup and press OK.
2 - Select Channel settings > Child lock > Set code or
Change code and press OK.
3 - If a code is set already, enter the current Child
lock code and then enter the new code twice.
The new code is set.
Forgotten your code?
To override and enter a new child lock code in case
you forget it, enter 8888.
To unlock a channel, select the locked channel in the
channel list. Press OPTIONS and select Unlock
channel. You will need to enter the Child lock code.
Age ratings lock
To prevent children from watching a program not
25
Loading...
