Philips 65PFL5602/F7, 43PFL5602/F7, 50PFL5602/F7 user manual

Download

Telev isions

5000 series

65PFL5602 55PFL5602 50PFL5602 43PFL5602

www.philips.com/welcome

EN For further assistance, call the customer support service in your

User manual

ES Manual del usuario

Manuel d’utilisation

country.

• To obtain assistance, contact Philips customer care center; In the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands

1 866 202 5960

México D.F. and área metropolitana; 58 87 97 36 Interior de la republica; 01 800 839 19 89

ES Para obtener más información, llame al centro de atención a clientes

de su país.

• Para obtener asistencia, comuníquese con centro de atención al cliente de Philips; En los Estados Unidos, en Canadá, Puerto Rico o en las Islas Vírgenes de los Estados Unidos; 1 866 202 5960 México D.F. y área metropolitana; 58 87 97 36 Interior de la republica; 01 800 839 19 89

FR Pour obtenir de l’aide supplémentaire, communiquez avec le centre

de service à la clientèle de votre pays.

• Pour obtenir de l’aide, communiquez avec le centre de service à la clientèle Philips au; Dans le États-Unis, au Canada, à Puerto Rico ou aux Îles Vierges américaines; 1 866 202 5960 México D.F. et área metropolitana; 58 87 97 36 Interior de la republica; 01 800 839 19 89

Contents

2 .English

1 Notice ....................................................................................... 5

2 Getting started ................................................................... 8

Features Included accessories Symbols used in this User manual Unpacking Installing the stands Lifting the TV set Removing cardboard Installing the remote control batteries Remote control Control panel Terminals Connecting Antenna or Cable / Satellite / IPTV set-top box Plugging in the AC power cord Selecting your connection quality Connecting your devices Initial setup

12 12 12 13 14 14 15 15

3 Use your TV ....................................................................... 22

Switching on your TV and putting it in standby mode Adjusting volume Switching channels Watching channels from an external device Access the Home menu Create a list of favorite channels Changing Picture format TV screen information Using options menu USB

22 22 22 23 23 24 24 25

4 Getting more from your TV ...................................... 30

Picture and sound setup TV settings

Picture Sound Features Installation Accessibility

31 31 31

33 34 34 36

Search for channels

Install channels

Channel settings

Channel installation Child lock

8 8 8 9

Change PIN Digital audio language Mono/Stereo

Connect to network

Wireless setting Wired setting

Network settings

Manual network settings Connection test Setting status Home network Wake-on-LAN(DIAL) Net TV Samba interactive TV settings Reset network settings

Update software

Preparing for the software upgrade Downloading the software USB upgrade Network updates

Software settings

Software Wireless Screencasting View photos, play music and watch videos using home

network Net TV Pandora operations

38 38 38 38

39 40 40 40

45 46 46 46 46

5 Useful tips ........................................................................... 53

FAQ Troubleshooting tips

6 Information ........................................................................ 56

Glossary Maintenance

7 Specifications .................................................................... 57

Displays and illustrations may differ depending on the product you purchase.

•

8 Warranty ............................................................................. 58

License .......................................................................................... end of book

3 .English

to get the most benets from your purchase.

Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out. Register Online at www.philips.com/welcome to ensure:

*Product safety notication *Additional benets

By registering your product, you'll receive notication - directly from the manufacturer - in the rare case of a product recall or safety defect.

Registering your product guarantees that you'll receive all of the privileges to which you're entitled, including special money-saving oers.

Know these safety symbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear or bottom of the cabinet.

WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.

Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert. ATTENTION: Pour éviter les choc électriques,introduire la lame la plus large de la che dans la borne

correspondante de la prise et pousser jusqu’au fond.

The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the apparatus’s enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the apparatus.

For fastest support visit us online for chat and self service solutions at www.philips.com/support

CHILD SAFETY:

PROPER TELEVISION PLACEMENT MATTERS

THE CONSUMER ELECTRONICS INDUSTRY CARES

• Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable.

• As you enjoy your television, please note that all televisions – new and old- must be supported on proper stands or installed according to the manufacturer’s recommendations. Televisions that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests, carts, etc., may fall over, resulting in injury.

TUNE IN TO SAFETY

• ALWAYS follow the manufacturer’s recommendations for the safe installation of your television.

• ALWAYS read and follow all instructions for proper use of your television.

• NEVER allow children to climb on or play on the television or the furniture on which the television is placed.

• NEVER place the television on furniture that can easily be used as steps, such as a chest of drawers.

• ALWAYS install the television where it cannot be pushed, pulled over or knocked down.

• ALWAYS route cords and cables connected to the television so that they cannot be tripped over, pulled or grabbed.

WALL OR CEILING MOUNT YOUR TELEVISION

• ALWAYS contact your retailer about professional installation if you have any doubts about your ability to safely mount your television.

• ALWAYS use a mount that has been recommended by the television manufacturer and has a safety certication by an independent laboratory (such as UL, CSA, ETL).

• ALWAYS follow all instructions supplied by the television and mount manufacturers.

• ALWAYS make sure that the wall or ceiling where you are mounting the television is appropriate. Some mounts are not designed to be mounted to walls and ceilings with steel studs or cinder block construction. If you are unsure, contact a professional installer.

• Televisions can be heavy. A minimum of two people is required for a wall or ceiling mount installation.

MOVING AN OLDER TELEVISION TO A NEW PLACE IN YOUR HOME

• Many new television buyers move their older CRT televisions into a secondary room after the purchase of a at-panel television. Special care should be made in the placement of older CRT televisions.

• ALWAYS place your older CRT television on furniture that is sturdy and appropriate for its size and weight.

• NEVER place your older CRT television on a dresser where children may be tempted to use the drawers to climb.

• ALWAYS make sure your older CRT television does not hang over the edge of your furniture.

Important safety instructions

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions. Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Only use attachments / accessories specied by the manufacturer.

Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.

10.

1 1.

12.

Unplug this apparatus during lightning storms or when unused for long periods of time.

Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

13.

14.

Note to the CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, species that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Example of antenna grounding as per NEC National Electric Code

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

ELECTRIC SERVICE EQUIPMENT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

GROUND CLAMPS

4 .English

Wall mount bracket kit

65PFL5602

FL5602

5 50PFL5602

43PFL5602 SANUS 25BB M4 x 1.378” (35mm)

You

r TV meets the VESA standard for wall mounting. Consult with your

•

local dealer for a wall mount bracket which is compatible with your TV model. The recommended wall mount bracket kit (sold separately) allows the

•

mounting of the TV on the wall. For detailed information on installing the wall mount, refer to the wall

•

mount Instruction book. Funai Corporation is not responsible for any damage to the product

•

or injury to yourself or others if you elect to install the TV wall mount bracket or mount the TV onto the bracket on your own. The wall mount bracket must be installed by experts.

•

Brand Model # Screw dimension

SANUS F80b M6 x 1.378” (35mm)

Funai Corporation is not liable for these types of accidents or injuries not

ed below.

Install the wall mount bracket on a sturdy vertical wall.

•

If installed onto a ceiling or slanted wall, the TV and wall mount bracket

•

may fall which could result in a severe injury. Do not use screws that are longer or shorter than their specified length.

•

If screws too long are used this may cause mechanical or electrical damage inside the TV set. If screws too short are used this may cause the TV set to fall. Do not fasten the screws by excessive force. This may damage the

•

product or cause the product to fall, leading to an injury. For safety reasons use 2 people to mount the TV onto a wall mounting

•

bracket. Do not mount the TV onto the wall mounting bracket while your TV is

•

plugged in or turned on. It may result in an electrical shock injury.

When installing the unit on the wall, allow this much space.

Top

Left and right side

Bottom

: 1 1.8 inches (30cm)

: 5.9 inches (15cm)

: 3.9 inches (10cm)

5 .English

1 Notice

Tra

demarks are the property of Koninklijke Philips N.V. or their respective

owners. Funai Corporation reserves the right to change products at any time

without being obliged to adjust earlier supplies accordingly. The material in this Owner’s manual is believed adequate for the intended use of the system. If the product or its individual modules or procedures are used for purposes other than those specified herein, confirmation of their validity and suitability must be obtained. Funai Corporation warrants that the material itself does not infringe any United States patents. No further warranty is expressed or implied. Funai Corporation cannot be held responsible neither for any errors in the content of this document nor for any problems as a result of the content in this document. Errors reported to Funai Corporation will be adapted and published on the Funai Corporation support website as soon as possible.

Pixel characteristics

This LCD product has a high number of color pixels. Although it has effective pixels of 99.999% or more, black dots or bright points of light (red, green or blue) may appear constantly on the screen. This is a structural property of the display (within common industry standards) and is not a malfunction.

Warranty

No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only be done by service centers and official repair shops. Failure to do so shall void any warranty, stated or implied.

Any operation expressly prohibited in this manual, any adjustments or assembly procedures not recommended or authorized in this manual shall void the warranty.

Federal communications commission notice

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment into an outlet on a circuit different from that to

•

which the receiver is connected. Consult the dealer or an experienced radio or television technician for

•

help.

Declaration of conformity

Trade name Responsible party Model

Address

Telephone number

This is not the mailing address for Open Source Software or Customer

service.

: PHILIPS : Funai Corporation, Inc. : 65PFL5602, 55PFL5602, 50PFL5602,

43PFL5602

: 12489 Lakeland Road, Santa Fe Springs, CA

90670, USA*

: 1 866 202 5960

Modifications

his apparatus may generate or use radio frequency energy. Changes or

T modifications to this apparatus may cause harmful interference.

Any modifications to the apparatus must be approved by Funai Corporation.

The user could lose the authority to operate this apparatus if an unauthorized change or modification is made.

Cables

Connections to this device must be made with shielded cables with metallic RFI / EMI connector hoods to maintain compliance with FCC Rules and regulations.

Canadian notice

CAN ICES-3 (B)/NMB-3 (B) Analog and digital television receiving apparatus, Canada BETS-7 / NTMR-7.

The following FCC/IC RSS applies to the wireless LAN

pter included in this product.

FCC caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Country code statement

For product available in the USA market, only channel 1~1 1 can be operated. Selection of other channels is not possible.

To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that do not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements and should be avoided.

mplies with Part 15 of FCC Rules and Industry Canada

evice co

This d licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

5150-5250 MHz band is restricted to indoor operations only.

h-power radars are allocated as primary users (i.e. priority users)

Hig of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Compliance with IC requirement RSS-210 A9.4.4

Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.

6 .English

Positioning the TV

Large screen TVs are heavy. 2 people are required to carry and handle

•

a large screen TV. Make sure to hold the upper and bottom

•

frames of the unit firmly as illustrated. Install the unit in a horizontal and stable

•

position. Do not install the unit in direct sunlight or in a

•

place subject to dust or strong vibration. Depending on the environment, the

•

temperature of this unit may increase slightly. This is not a malfunction.

When installing this unit in a temperate environment, avoid a place with

•

rapid temperature changes.

–Operating temperature: 41°F (5°C) to 104°F (40°C)

This unit should not be used in a tropical environment as it has not been

•

evaluated under such conditions. No objects should be placed directly on or under this unit, especially

•

lighted candles or other flaming objects. Depending on your external devices, noise or disturbance of the picture

•

and / or sound may be generated if the unit is placed too close to them. In this case, please ensure enough space between the external devices and the unit.

Do not insert the AC power cord into the power socket outlet before all

•

the connections are made. Ensure that you always have easy access to the AC power cord and

•

outlet to disconnect the TV from the AC outlet. Before you move the TV, disconnect attached cables to prevent

•

damage to connectors, especially the TV tuner. Be sure to unplug the AC power plug from the AC outlet before moving

•

or carrying the unit. When moving the TV and then setting it down, please be careful not to

•

pinch the AC power cord under the unit. Do not place this unit in an area where it may be exposed to water, oil

•

or grease such as: near a bathtub, basin, kitchen sink, washing tub, swimming pool, kitchen exhaust fan, etc., or in a damp basement.

Regulatory notices

WARNING

If your existing TV is being retained and relocated, the same considerations as above should be applied.

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a book cabinet, rack, etc., and the vents of this unit should not be covered with anything such as a tablecloth, curtain, newspaper, etc. Make sure that there is enough ventilation space (4inches / 10cm or more) around this unit.

: To prevent injury, this apparatus must be securely attached

to the furniture / wall in accordance with the instructions. Tipping, shaking or rocking the unit may cause injury / death.

: Never place a TV in an unstable location. A TV may fall,

causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

–Using cabinets or stands recommended by the

manufacturer of the TV. –Only using furniture that can safely support the TV. –Ensuring the TV is not overhanging the edge of the

supporting furniture. –Not placing the TV on tall furniture (for example,

cupboards or bookcases) without anchoring both the

furniture and the TV to a suitable support. –Not placing the TV on cloth or other materials that may

be located between the TV and supporting furniture. –Educating the children about the dangers of climbing

on furniture to reach the TV or its controls.

Press  to turn the unit on and go into standby mode. To completely turn off the unit, you must unplug the AC power plug from the AC power outlet. Disconnect the AC power plug to shut the unit off when trouble is found or not in use. The AC plug shall remain readily available.

AC power plug

Never use a gas duster on this TV. The gas trapped inside of this unit may cause ignition and explosion.

Environmental care

The packaging of this product is intended to be recycled. Contact your local authorities for information about how to recycle the packaging.

For product recycling information, please visit - www.recycle.philips.com

End of life directives

Philips pays a lot of attention to produce environmental-friendly products in green focal areas. Your new TV contains materials which can be recycled and reused. At the end of its life, specialized companies can dismantle the discarded TV to concentrate the reusable materials and to minimize the amount of materials to be disposed of. Please ensure you dispose of your old TV according to local regulations.

 Batteries usage

CAUTION

WARNING

Do not mix old and new batteries.

•

Do not mix alkaline, standard (carbon-zinc) or rechargeable (ni-cad,

•

ni-mh,Li-ion, etc.) batteries.

Disposal of used batteries

The batteries included do not contain the heavy metals mercury and cadmium, however in certain localities, disposing batteries with household waste is not permitted. Please ensure you dispose of batteries according to local regulations.

Preparing to move / ship the unit

Please pack the unit properly by following the diagram on the carton (as noted below).

To avoid damage to the screen, do not pack the stand on the same side

•

as the TV screen, refer to the illustration above.

: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

: Batteries (battery pack or battery installed) should not be

exposed to excessive heat such as sunshine, fire or the like.

All

other registered and unregistered trademarks are the property of their

respective owners.

The terms HDMI and HDMI HighDefi

nition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

Manufactured under license from

y Laboratories. Dolby, Dolby

Dolb Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

Sonic Emotion and the Sonic Emotion logo

symbol are registered trademarks

of sonic emotion ag.

Netflix is available in certain countries.

aming membership required. More

Str information at www.netflix.com.

7 .English

.freetype.org).

The American Academy of Pediatrics discourages television viewing for children younger than two years of age.

Some features may require an always-on broadband internet connection, firmware update and/or a minimum bandwidth. Internet services vary by location.

Funai Corporation Inc. does not warrant access to the portal or to any of the services, content, software and advertising. Funai Corporation Inc. may, in its sole discretion, add or remove access to any specific services, content, software and advertising at any time. Although Funai Corporation Inc. will strive to provide a good selection of services, content or software, Funai Corporation Inc. does not warrant continued access to any specific services, and content or software.

Funai Corporation Inc. does not warrant Wireless Screencasting compatibility with all source devices such as smartphones, tablets, laptops, etc. due to large variability in hardware, firmware, drivers, software and implementation of wireless casting applications on these source devices. Although Funai Corporation Inc. will strive to enhance compatibility and performance across a range of source devices, Funai Corporation Inc. does not warrant compatibility with specific source devices.

VUDU™ is a trademark of VUDU, Inc.

YouTube and the YouTube logo are trad

emarks of Google Inc.

PANDORA, the PANDORA logo, and the

Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. Used with permission.

CinemaNow and th are trademarks of BestBuy Stores L.P. and BestBuy Canada LTD.

Hotlist, Samba, Samba TV and associated logos are trademarks of Free Stream Media Corp.

e CinemaNow logo

CAUTION: READ THIS FIRST

When using a universal remote control to operate this unit.

8 .English

2 Getting started

Features

DTV / Analog TV / CATV

•

You can use your remote control to select channels which are broadcast in digital format and conventional analog format. Also, cable and satellite subscribers can access their TV channels.

Information display

•

You can display on the TV screen the title, contents (DTV only) and other information on the current program.

Autoprogram

•

This unit automatically scans and memorizes channels available in your area, eliminating difficult setup procedures.

Net TV

•

This unit lets you enjoy internet services. Use the remote control to browse the Net TV pages. You can play movies and much more, all from your TV screen.

Child lock

•

This feature allows you to block children’s access to inappropriate programs.

Closed caption decoder

•

Built-in closed caption decoder displays text for closed caption supported programs.

MTS / SAP tuner

•

Audio can be selected from the remote control.

Auto standby

•

If there is no input signal and no operation for 15 minutes, the unit will go into standby mode automatically.

Sleep timer

•

You can set the unit to go into standby mode after a specific amount of time.

Choices for on-screen language

•

Select your on-screen language: English, Spanish or French.

Stereo sound function

•

PLL frequency synthesized tuning

•

Provides free and easy channel selection and lets you tune directly to any channel using the number and decimal point “•” keys on the remote control.

Various adjustments for picture and sound

•

Customizes picture quality suitable for your room and sets your sound preference.

EasyLink via HDMI link

•

EasyLink allows your other HDMI link devices to be controlled by the HDMI cable connected to your TV.

HDMI input

•

HDMI-DVI input

•

If your video device has a DVI output jack, use an HDMI-DVI conversion cable to connect the unit.

Component video input

•

AV input

•

Audio and video input from an external device.

USB terminal

•

The picture, music and video files stored on a USB memory stick can be played back on this unit.

Digital audio output

•

Headphone audio output

•

Headphone 3.5mm stereo jack for personal listening.

Included accessories

Quick start guideUser manual Caution sheet

TV base and Screws

65”

55” / 50” / 43”

Screws packed with this unit.

65PFL5602

55PFL5602 50PFL5602

43PFL5602

* Caution sheet is not included in 43PFL5602.

Note(s)

If you lose the screws, please purchase the above-mentioned Phillips head screws at your local

•

store. If you need to replace these accessories, please refer to the part name or No. with the illustrations

•

and call our toll free customer support line found on the cover of this User manual.

Make sure the component code on your universal remote control is set to our brand. Refer to

•

the instruction book accompanying your remote control for more details. We do not guarantee 100% interoperability with all universal remote controls.

•

M4 x 0.709”(18mm)

M4 x 0.984”(25mm)

M4 x 0.551”(14mm)

Remote control

and Batteries (AAA, 1.5V x 2)

AAA

SizeQuantityModel

Symbols used in this User manual

AAA

The following is the description for the symbols used in this User manual. Description refers to:

Digital TV operation

Cable / NTSC (Analog) TV operation

If neither symbol appears, the operation is applicable to both.

•

Continued on next page.

Unpacking

It is recommended that two or more people remove the TV set from the box. Be careful not to injure your fingers and keep children away during assembly.

(65PFL5602)

Open the top flaps of the box.

Remove all accessories.

Support the top of the TV set with a hand to prevent the TV from

falling.

Unhinge the retaining tabs and unfold the left and right side of the

bottom packaging.

9 .English

Caution(s)

DO NOT take the TV set out of the box yet.

•

Remove the packing joints from the box.

Remove the outer slipbox with care.

Continued on next page.

10 .English

(55PFL5602, 50PFL5602)

Open the top flaps of the box.

Remove all accessories.

Installing the stands

(65PFL5602)

Remove both of the bottom polystyrene foam bases. Carefully tear

the plastic bag until the bottom corner of the TV is exposed.

Support the top of the TV set at all times to prevent the TV from

•

falling.

Caution(s)

Before installing the matching stand, remove the protective cardboard and carefully peel away

•

the film from the area so that it will not get stuck between the unit and the stand.

Lift up one side of the TV approx. 1 inch (2.5 cm) and insert the

matching stand upward until it fits the main unit.

Prepare a table and cover the top of it with a table cloth, blanket or

such to avoid damage to the TV set. Support both sides of the TV set and, move it onto the table.

Carefully lay the TV set, with the screen side down, on the table so

as not to deform or damage Decoration plate of the bottom of the unit.

Fasten the matching stand to the TV with 2 screws (included).

2 screws required

In the same manner as step 2, install the other stand.

Protect the plate with care

Continued on next page.

11 .English

Fasten the other stand to the TV with 2 screws (included).

2 screws required

Both stands should now be securely fastened.

(55PFL5602, 50PFL5602)

Remove the tape on the bottom of the TV set and the plastic bag.

Fasten the matching stand to the TV with 2 screws (included). While

fastening the screws, hold the stand to prevent it from falling.

Caution(s)

Before installing the matching stand, remove the protective cardboard and carefully peel away

•

the film from the area so that it will not get stuck between the unit and the stand.

2 screws required

Fasten the other stand to the TV with 2 screws (included). While

fastening the screws, hold the stand to prevent it from falling.

2 screws required

Both stands should now be securely fastened.

Continued on next page.

12 .English

(43PFL5602)

the plate with care

Lifting the TV set

Carefully lift the TV set as shown in the illustration and place it onto a stable, level surface.

Protect

Removing cardboard

Remove the cardboard attached to the screen. You are now ready to set up and enjoy your Philips TV.

×4

Note(s)

A wide open space is recommended for assembly.

•

A Phillips-head screwdriver is required to fasten the stands to the TV set.

•

When attaching the stand, ensure that all screws are tightly fastened. If the stand is not properly

•

attached, it could cause the unit to fall, resulting in injuries as well as damage to the unit. To remove the stand from this unit, unscrew the Phillips-head screws by reversing the

•

procedure. Be careful not to drop the stand when you remove it.

Installing the remote control batteries

Slide the battery cover off the back of the remote control.

Insert the two included batteries (AAA, 1.5V). Be sure the + and – ends

of the batteries line up with the markings inside the case.

Slide the cover back into position.

Note(s)

Remove the batteries if not using the remote control for an extended period of time.

•

Continued on next page.

Remote control

t s

b c

d e f

h i



 (POWER)

Turns the TV on from standby or off to standby.

VUDU



Access directly to VUDU.

EasyLink buttons



 /   .

Note(s)

Pause may not work properly on some devices even if they are EasyLink (HDMI CEC)

•

compliant.

YouTube



Access directly to YouTube.

SAP



Selects audio mode (MONO / STEREO / SAP) / audio language.

(Home)

Displays the main menu.

INFO

Displays information about the current program.

Press to decide the command of setting when the Home menu is displayed.

 (NAVIGATION buttons)

Moves the cursor, selects the on-screen menu items.

OPTIONS

Displays a list of menu items applicable to the highlighted object or screen.

SOURCE

Selects connected devices.

CH + / –

Selects a channel.

COLOR buttons

Works as direct access to user specified net apps.

0 - 9 (NUMBER buttons)

(

Used to enter a channel / program number.

• (DOT)

: Searches backward or forward through the disc.

: Starts, pauses or resumes playback.

: Stops the disc playback.

: Use with 0-9 to select digital channels.

For example, to enter 2.1, press

13 .English

PREV.CH

)

 (MUTE)

Turns the sound on and off.

VOL + / –

Adjusts the volume.

BACK

Returns to the previous menu operation.

FORMAT

Adjusts the picture size on the TV screen.

Selects closed caption settings (Off, On, CC w/mute).

NETTV

Access to Net TV menu directly.

NETFLIX

Access directly to Netflix.

: Returns to the previously viewed channel.

Continued on next page.

14 .English

Control panel

cde

Remote control sensor



Receives IR signal from remote control.

CH + / –



Selects a channel. In the menu screen, moves the cursor up (+) / down (–).



(POWER)

Turns the TV on or switches the TV into standby mode.



Opens the main on-screen menu.

SOURCE



Selects connected devices.

VOL + / –

Adjusts the volume. In the menu screen, moves the cursor left (+) / right (–).

VOL +

VOL –

: Volume up : Volume down

Terminals

i j

75 ohm cable / Antenna connection

Signal input from an antenna or cable / satellite set-top boxes.

Analog audio (L/R) input jacks

Connect analog audio signals from;

–HDMI-DVI / Analog audio (L/R) jacks signal –Component video / Analog audio (L/R) jacks signal –Composite video / Analog audio (L/R) jacks signal –PC connection / Analog audio (L/R) jacks signal with stereo mini 3.

5mm plug audio cable on PC

Digital audio output jack

Digital audio (S/PDIF) output to home theaters and other digital audio systems.

Component (Y/Pb/Pr) / Composite video (VIDEO) input jack(s) for

VIDEO

Composite video input (VIDEO) jack is a shared jack with component video input (Y) jack. Green / Yellow color orientation depends on model.

Ethernet port

For internet connection using an Ethernet cable with an RJ-45 connector.

HDMI input jack(s)

Digital audio and video input from high definition digital devices such as DVD / Blu-ray disc players, cable / satellite set-top boxes, PC’s, etc.

* For HDMI 2 only

In addition to normal HDMI and HDMI-DVI functionality, it outputs TV audio to an HDMI-ARC-compliant device, such as a home theater system.

Headphone audio output jack

Headphone 3.5mm stereo jack for personal listening.

USB terminal

(

Data input from USB memory stick only. Do not connect any device to this terminal such as digital camera, keyboard, mouse, etc.

Continued on next page.

OUT

RF cable

Antenna

Cable

Antenna

Set-top box

RF cable

OUT

RF cable

HDMI cable

Set-top box

RF cable

OUT

Component (Y/Pb/Pr)

video cables

OUT

Audio (L/R) cables

Video + Audio(L/R)

cables

15 .English

Connecting Antenna or Cable / Satellite / IPTV set-top box

Be sure your antenna or another device is connected properly before plugging in the AC power cord.

If connecting to an antenna through an RF cable

Any DTV programs that are broadcast in your area can be received for free through an antenna connection.

Cable

Antenna

RF cable

If connecting Cable / Satellite / IPTV set-top box using an RF cable

If the TV is connected to a cable or set-top box via a coaxial connection, set the TV to channel 3/4 or the channel specified by the service provider.

Antenna

RF cable

OUT

If connecting Cable / Satellite / IPTV set-top box using an HDMI cable

If the TV is connected to a cable / satellite set-top box via an HDMI cable, make sure you select the correct source by using SOURCE.

OUT

RF cable

Set-top box

Connecting a Cable / Satellite / IPTV set-top box, Bluray disc / DVD recorder via composite connectors and analog audio

Do not place your recorder too close to the screen because some recorders can be susceptible to harmful interference from the TV.

Satellite

Cable

OUTOUT

Set-top box

RF cable

Video + Audio(L/R)

Note(s)

If you have any question about the DTV’s antenna, visit www.antennaweb.org for further

•

information. Depending on your antenna system, you may need different types of combiners (mixers) or

•

separators (splitters) for HDTV signal. The minimum RF bandpass on these devices is 2,000MHz or 2GHz.

For your safety and to avoid damage to this unit, please unplug the RF coaxial cable from the

•

antenna input jack before moving the unit. If you did use an antenna to receive analog TV, it should also work for DTV reception. Outdoor

•

or attic antennas will be more effective than a set-top box or inside antenna. To turn on your reception source easily between antenna and cable, install an antenna

•

selector. If you are not receiving a signal from your cable service, contact the cable provider.

•

cables

OUT

Video +

Audio(L/R)

cables

OUT

Blu-ray disc / DVD recorder

Cable

OUT

Plugging in the AC power cord

Make sure that the AC power cord must be plugged to an AC outlet after all the necessary connections are made.

HDMI cable

RF cable

OUT

Set-top box

If connecting Cable / Satellite / IPTV set-top box using component video input

If the TV is connected to a cable / satellite set-top box via component video input, make sure you select the correct component video source

by using SOURCE.

Audio (L/R) cables

Component (Y/Pb/Pr)

video cables

OUT

RF cable

Set-top box

Caution(s)

Connect the analog audio signal cables from the external device to the analog audio L/R input

•

jacks. If you have an amplifier, connect the HDMI cable to the HDMI input via your amplifier.

•

Note(s)

Each time you plug in the AC power cord, no operations will be performed for several seconds.

•

This is not a malfunction.

Continued on next page.

Before you connect the AC power cord:

HDMI cable

HDMI-DVI

conversion cable

16 .English

No included cables are used with these connections:

Please purchase the necessary cables at your local store.

•

Be sure other devices are connected properly before plugging in the AC power cord.

Selecting your connection quality

HDMI - Highest quality

Supports high-definition digital signals and gives highest picture and sound quality. Video and audio signals are combined in one cable. You must use HDMI for full high-definition video and to enable EasyLink(HDMI CEC).

Note(s)

Philips HDMI supports HDCP (High-bandwidth Digital Contents Protection). HDCP is a form of

•

digital rights management that protects high-definition content in Blu-ray discs or DVDs. The HDMI-ARC connector on the TV features HDMI-ARC functionality. This allows output of

•

TV audio to an HDMI-ARC-compliant device.

Component (Y Pb Pr) - High quality

Connecting your devices

HDMI digital connection

HDMI connection offers the highest picture quality. HDMI (High-Definition Multimedia Interface) transports high-definition digital video and multi-channel digital audio through a single cable.

Set-top box

HDMI cable

Note(s)

If there are issues with picture/color and/or sound when connecting an external device using

•

the HDMI port, please try switching the HDMI mode. (Refer to HDMI mode  p. 35) Some HDMI cables and devices may not be compatible with the TV due to different HDMI

•

specifications. Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

•

recommended for the better compatibility. The unit accepts 480i / 480p / 720p / 1080i, 1080p, 2160p 24/30/60Hz of video signals, 32kHz/

•

44.1kHz and 48kHz of audio signals. This unit accepts LPCM, AC-3, DD+ audio signal.

•

This unit accepts only signals in compliance with EIA861.

•

Blu-ray disc / DVD player

OUT

HD game console

Supports high-definition analog signals but gives lower picture quality than HDMI. Component (Y/Pb/Pr) video cables combine red / green / blue video cables with red / white audio (L/R) cables. Match the cable colors when you connect to the TV.

Composite - Basic quality

For analog connections. Composite video / Audio analog cable usually combine a yellow video cable with red / white audio (L/R) cables. With this unit, yellow cable must be connected to Y (green) jack on the component video input jacks.

HDMI-DVI connection

This unit can be connected to a device that has a DVI terminal. Use an HDMI-DVI conversion cable for this connection and it requires audio cable for analog audio signal as well.

Cable receiver or set-top box with

the DVI output jack

HDMI-DVI

Note(s)

Some HDMI cables and devices may not be compatible with the TV due to different HDMI

•

specifications. Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

•

recommended for the better compatibility. The unit accepts 480i, 480p, 720p, 1080i, 1080p and 2160p video signals.

•

HDMI-DVI connection requires separate audio connections as well and the audio signals are

•

output as analog (L/R) audio. DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

•

HDMI-DVI

conversion cable

Audio (L/R) cables

OUT

Continued on next page.

HDMI cable

HDMI 2 IN only

Blu-ray disc / DVD recorder

Set-top box

OUT

Component (Y/Pb/Pr)

video cables

OUT

Audio (L/R) cables

DVD player

OUT

Video + Audio(L/R) cables

Internet

Network provisioning

equipment

Ethernet cable

17 .English

HDMI-ARC connection

HDMI-ARC allows you to use EasyLink to output TV audio directly to a connected audio device, without the need for an additional digital audio cable.

HDMI 2 IN only

HDMI cable

OUT

Digital home theater

amplier that supports

HDMI-ARC

Note(s)

The HDMI 2 connector is HDMI Audio Return Channel (ARC) compliant. Use it to output digital

•

audio to an HDMI home theater system. Be sure that the device is HDMI CEC and ARC compliant and that the TV is connected to the

•

device using an HDMI cable attached to HDMI-ARC connectors.

Component analog video connection

Component analog video connection offers better picture quality for video devices connected to the unit.

If you connect to the unit’s component video (Y/Pb/Pr) input jacks, connect analog audio cables to the analog audio (L/R) input jacks.

Audio (L/R) cables

OUT

Set-top box

Composite analog video connection

Composite analog video connection offers standard picture quality for video devices connected to the unit.

If you connect to the unit’s component / composite video (Y/VIDEO) input jack (green), connect audio cables to the audio (L/R) input jacks. When the audio is monaural, then only connect to the audio L input jack.

OUT

Video + Audio(L/R) cables

DVD player

Note(s)

With this unit, yellow cable must be connected to Y (green) jack on the component video input

•

jacks. Whenever you connect to the composite video input jack (Y/VIDEO), you must disconnect the

•

component video input jacks (Pb and Pr). If you leave those jacks connected, it may cause an unstable picture.

Connecting the TV to the internet using an Ethernet cable

Internet

Component (Y/Pb/Pr)

Note(s)

The unit accepts 480i, 480p, 720p, 1080i and 1080p of video signals for this connection.

•

video cables

OUT

Blu-ray disc /

Blu-ray disc / DVD recorder

DVD recorder

LAN

Network provisioning

Ethernet cable

Note(s)

Please purchase shielded Ethernet cables at your local store and use them when you connect

•

to network equipment.

After connecting an Ethernet cable, set up necessary network settings. Connect to network 

•

p. 41

Do not insert any cable other than an Ethernet cable to the Ethernet port to avoid damaging

•

the unit. If your telecommunications equipment (modem, etc.) does not have broadband router

•

functions, connect a broadband router. If your telecommunications equipment (modem, etc.) has broadband router functions but there

•

is no vacant port, then add a hub. For a broadband router, use a router which supports 10BASE-T / 100BASE-TX.

•

Do not connect your PC directly to the Ethernet port of this unit.

•

Network provisioning

equipment

Continued on next page.

Broadband router

Internet

OUT

Digital audio optical cable

OUT

HDMI cable

OUT

HDMI-DVI

conversion cable

OUT

Stereo mini 3.5 mm plug audio cable

18 .English

Connecting the TV to the internet using a wireless LAN

Internet

Network provisioning

equipment

LAN

Ethernet cable

Broadband router

Note(s)

After you make the wireless connection, set up the necessary network settings. Connect to

•

network  p. 41

Use a wireless LAN Access Point (AP) (e.g. broadband wireless router) which supports

•

IEEE 802.1 1 a/b/g/n/ac. (n is recommended for stable operation of the wireless network.) This unit does not support Ad-hoc mode.

•

Other radio devices or obstacles may cause interference to the wireless network connection.

•

WLAN

Digital audio output connection

If you connect this unit to an external digital audio device, you can enjoy multi-channel audio like 5.1ch digital broadcasting sound.

Use a digital audio optical cable to connect the unit to external digital audio devices.

PC connection

HDMI connection

This unit can be connected to your PC that has an HDMI terminal. Use an HDMI cable for this digital connection.

OUT

HDMI cable

HDMI-DVI connection

This unit can be connected to your PC that has a DVI terminal. Use an HDMI-DVI conversion cable for this video digital connection and it requires stereo mini 3.5mm plug audio cable for analog audio signal as well.

HDMI-DVI

conversion cable

Stereo mini 3.5 mm plug audio cable

OUT

Digital audio

Digital audio optical cable

optical cable

Digital home

theater amplier

Continued on next page.

19 .English

The following PC-input video signals can be displayed:

Format Resolution Refresh rate

VGA 640 x 480

SVGA 800 x 600

XGA 1,024 x 768

WXGA

1,280 x 768 1,360 x 768

60Hz

FHD 1,920 x 1,080

UHD

3,840 x 2,160

4,096 x 2,160

24/30/60Hz

Other formats or non-standard signals will not be displayed correctly.

Note(s)

Please purchase a HDMI-DVI conversion cable that has a ferrite core.

•

The following operations may reduce noise.

•

–Attach a ferrite core to the AC power cord of your PC. –Unplug the AC power cord and use the built-in battery of your portable / laptop PC.

Some HDMI cables and devices may not be compatible with the TV due to different HDMI

•

specifications. Use an HDMI cable with the HDMI logo (a certified HDMI cable). High speed HDMI cable is

•

recommended for the better compatibility. The unit accepts 480i, 480p, 720p, 1080i, 1080p and 2160p video signals only when using the

•

HDMI connection and HDMI-DVI connection. HDMI-DVI connection requires separate audio connections as well and the audio signals are

•

output as analog (L/R) audio. DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

•

USB memory stick

This unit offers easy playback of picture, music and video files. Insert the USB memory stick into the USB terminal shown below.

For a complete list of file formats and specifications supported, refer to

USB Section  p. 27

Note(s)

The unit recognizes only a USB memory stick.

•

Do not use a USB hub or an extension cable to connect an external hard disk drive to the unit.

•

(Not supported.) Always insert a USB memory stick directly to this unit.

•

A USB memory stick is not included with this unit.

•

We do not guarantee that all USB memory sticks can be supported by this unit.

•

Be sure to keep a backup copy of the original files on your USB device before you play them

•

back on this unit. We have no responsibilities for damage or loss of your USB stored data. To protect your USB memory stick files from being erased place the write protect sliding tab in

•

the protect position (if available). When you are ready to remove a USB memory stick, set the unit to go into standby mode to

•

avoid any damage to your data and the unit. A USB memory stick that requires its own driver or the device with a special system such as

•

fingerprint recognition are not supported. This unit is not allowed to use the USB memory stick which requires an external power supply

•

(500mA or more).

Continued on next page.

Before you begin:

20 .English

These operations are accessible by remote control.

Some may also be accessible by the main unit's control panel.

Initial setup

This section will guide you through the unit’s Initial setting which includes selecting a language for your on-screen menu, country, location and Autoprogram, which automatically scans and memorizes viewable channels. You can also set the network connection in this setting.

Make sure the unit is connected to an antenna or cable.

After making all the necessary connections, press  to turn on the unit.

It may take a few moments to turn on the unit for the first time.

•

Initial setup menu appears automatically after the unit is turned on.

•

Use  to select the on-screen language, Voice guide, country, TV placement and location in the middle of the TV screen, then press OK.

You must set Home in location setting. Otherwise, Picture and

•

Sound settings you adjusted will not be memorized after the unit goes into standby mode.

Use  to select Skip or Next on network setup screen.

Use  to select Wireless or Wired, then press OK.

Installation

This TV can be connected to your home network. Select your connection type.

Wireless

Wired

If you have a router with easy connect function, select Wireless and

•

use  to select Easy Connect, then press OK. When you select On in the selection screen for Software update

•

notification, A message will appear later if there is the latest software on the network server.

Skip

If you have a wireless router, select Wireless to connect to the internet.

If you connect with an Ethernet cable, select Wired to connect to the internet.

Wireless

Wired

756

Use  to select the signal type.

If the TV is connected to a cable or satellite set-top box, select the

•

2nd one and skip to step 7.

Installation

Select "Antenna" to set up a TV signal from a cable TV wall jack or a standard TV antenna.

Select "Set-top box" to set up a TV signal from a cable TV box or satellite TV receiver.

Antenna

Set-top box

1234 756

Use  to select Antenna for TV channels or Cable for CATV channels, then press OK.

Installation

Make sure that you have attached your antenna or cable signal into the jack on the back of your TV labeled "ANTENNA IN".

Now select either Antenna or Cable, using up/down key of the remote control. Once you have made your selection, press the OK button to proceed.

Antenna

Cable Skip

1234 756

–When Antenna is selected, the TV detects antenna signals. It

searches for DTV and analog TV channels available in your area.

–When Cable is selected, the TV detects signals supplied by cable.

It searches for DTV, analog TV and cable channels available in your area.

Auto programming will begin.

•

Installation

System searching. Please wait…

Auto programming may take more than 20 minutes to complete. Digital channels will take longer than Analog to nd and program. Please wait until you see the Auto Programming complete message.

Digital channels found: Analog channels found:

Total progress:

0 0

123

Stop

756

Continued on next page.

After an initial setup is completed...

Use  to select your preferred picture setting, then press OK.

Please select your preferred picture mode.

Skip

Use  to select your preferred sound setting, then press OK.

Please select your preferred sound mode.

Skip

After Picture and sound setup is completed, a message will appear

if there is the latest software on the network server.

Note(s)

If you are not receiving a signal from your cable service, contact the cable provider.

•

If you press  during Autoprogram, this setup of TV channels will be cancelled.

•

The initial Autoprogram function can be executed for either Antenna or Cable only once. When

•

you change the connection (Antenna / Cable), select Search for channels again.  p. 38

Standard

Vivid

Sports

Standard

Vivid

Sports

If you want to scan the channels automatically again.

•

Search for channels  p. 38

If you want to change to another language.

•

Language  p. 34

If you want to change the country setting.

•

Country  p. 51

If you want to change the location setting.

•

Location  p. 35

If you want to change the network setting.

•

Connect to network  p. 41

If you want to restore the picture and sound setting.

•

Picture and sound setup  p. 31

21 .English

To turn the TV on from standby or off to standby

To decrease or increase volume

To mute or unmute sound

To select channels by using CH + / –

To select channels by using the NUMBER buttons

22 .English

3 Use your TV

Switching on your TV and putting it in standby mode

Remote control

Press  on the TV or the remote control.

•

Note(s)

Energy consumption contributes to air and water pollution. When the AC power cord is plugged

•

in, your TV consumes energy with a very low standby power consumption.

Adjusting volume

Switching channels

Remote control

Press CH + / – on the TV or the remote control.

•

Digital TV operation

Remote control

Press VOL + / – on the TV or the remote control.

•

VOL + : Volume up VOL – : Volume down

Press  on the remote control to mute the sound.

•

Press  again or VOL + / – to recover the original sound.

•

For digital channels, press a number followed by a dot “•” and the

•

corresponding sub channel number.

–When selecting digital channel 1 1. 1

Be sure to press • before entering the subchannel number.

Cable / NTSC (Analog) TV operation

–When selecting cable or analog channel 1 1

Press PREV.CH to return to the previously viewed channel.

Note(s)

To select the non-memorized channels, use the NUMBER buttons.

•

Channel not available or No signal will appear on the TV screen after the subchannel broadcast

•

is over. Audio only message will appear on the TV screen, when you receive only sound signal.

•

Continued on next page.

To reset the type

Before you begin:

23 .English

Watching channels from an external device

Switching each input mode can easily switch with the remote control between TV and external devices when they are connected to the unit.

Turn on the set-top box or the connected device.



Press SOURCE and use  to select the set-top box or the connected device and wait a few seconds till the picture appears.

Watch TV

Use the remote control of the set-top box or the connected device



to select channels.

HDMI1

HDMI2

HDMI3

Video

Access the Home menu

Press .

Lock or unlock your device from the Home menu

This section describes how to lock or unlock specified device.

Press SOURCE on the remote control.

Use  to select a device to lock or unlock.

Press OPTIONS on the remote control.

Use  to select Lock or Unlock, then press OK.

If device lock is unlocked, Lock will be displayed. If device lock is

•

locked, Unlock will be displayed at the top right of the device icons.

Enter your PIN. Change PIN  p. 40

Changing device type

You can change device icons displayed in the source list.

Press SOURCE on the remote control.

Use  to select the desired device.

Press red button on the remote control.

3 4

Use  to select the desired type, then press OK.

Press OPTIONS on the remote control at step 3, then select Original

•

icon.

Guide to Home menu

Watch T V

  Watch TV

  Source   Home Network   Net TV Wireless Screencasting  Setup

Home

Network

: Switches back to the TV source if another

source is selected.

: To select connected devices. : Accesses Home network menus. : Accesses Net TV menus. : Accesses Wireless Screencasting menus. : Accesses menus that allow you to

change picture, sound and other TV settings.

Wireless

Screencasting

SetupNet TVSource

Scan connections

You can rescan TV connections and update the source list.

You must set On in Master EasyLink.  p. 36

Press SOURCE on the remote control.

Use  to move the cursor to any device.

Press OPTIONS on the remote control.

Use  to select Scan connections, then press OK.

Continued on next page.

To change the favorite list

To remove a channel from the favorite list

24 .English

Create a list of favorite channels

You can create lists of your preferred TV channels so that you can find those channels easily.

Press OK while viewing a TV program.

1 2

Use  to select the desired channel, then press yellow button.

Use  to select the desired favorite list (Favorites 1 - Favorites 4), then press OK to add or remove on the list of favorite channels.

indicates that the channel is added.

•

indicates that the channel is removed.

•



The channel will be marked with ! icon.

•

Display the list of favorite channels

Press OK while viewing a TV program.

1 2

Use  to select Favorites.

Press blue button.

1 2

Use  to select the desired favorite list (Favorites 1 - Favorites 4).

Select the desired channel, then press yellow button.

1 2

Use  to select Yes, then press OK.

Changing Picture format

Display modes can be selected when your TV receives a 16:9 or 4:3 video signal.

Three types of display modes can be selected for a PC input signal. Press FORMAT repeatedly to switch the TV aspect ratio.

For 16:9 video signal (4096 x 2160p)

Full Unscaled

For 16:9 video signal (3840 x 2160p)

Full Unscaled

Manual Zoom

For 16:9 video signal (not 2160p)

4:3Automatic

Manual Zoom

Automatic

4:3

Wide screen

Unscaled Displays a 16:9 picture at its original size.

Full

Manual Zoom

Manual Zoom setting is not available on the following models:

࣭65PFL5602/F7 ࣭65PFL5602/F7 D ࣭55PFL5602/F7 ࣭50PFL5602/F7

Your model number can be confirmed on the rating label applied on the rear cabinet.

Other than DTV and HDMI connected devices, enlarges the picture to best fit the screen. DTV and HDMI connected devices display the picture at its original size. The subtitles may remain visible.

Displays a 16:9 picture at a 4:3 size; the picture is shortened horizontally. Sidebars appear on both edges of the screen.

Displays a 16:9 picture that is stretched horizontally and vertically.

Displays a scaled 16:9 picture. Bars appear on both the upper and lower portions of the screen depending on the type of video signal.

Allows step by step vertical and horizontal stretching of the picture size to suit your viewing preferences. Manual zoom can distort the aspect ratio of the image, to switch back to a normal mode select Automatic / Normal.

Full

Wide screen

Continued on next page.

25 .English

For 4:3 video signal

4:3Super zoomAutomatic

Manual Zoom

Wide screen

Movie expand 16:9

Movie expand 14:9

Other than DTV and HDMI connected devices, enlarges the picture to best fit the screen.

Automatic

DTV and HDMI connected devices display the picture at its original size. The subtitles may remain visible.

Displays a 4:3 picture at a 16:9 size; the picture is

Super zoom

stretched horizontally and vertically and its left and right edges are enlarged. This crops out some of the top and bottom of the picture.

4:3

Displays a 4:3 picture at its original size. Sidebars appear on both edges of the screen.

Displays a 4:3 picture at a 14:9 size; the picture is stretched horizontally and vertically.

Movie expand 14:9

This crops out some of the top and bottom of the picture. Sidebars appear on both edges of the screen.

Displays a 4:3 picture at a 16:9 size; the picture is

Movie expand 16:9

stretched horizontally and vertically. This crops out some of the top and bottom of the picture.

Wide screen

Displays a picture that is stretched out of proportion to fill the screen.

Allows step by step vertical and horizontal stretching of the picture size to suit your viewing

Manual Zoom

preferences. Manual zoom can distort the aspect ratio of the image, to switch back to a normal mode select Automatic / Normal.

Manual Zoom setting is not available on the following models:

࣭65PFL5602/F7 ࣭65PFL5602/F7 D ࣭55PFL5602/F7 ࣭50PFL5602/F7

Your model number can be confirmed on the rating label applied on the rear cabinet.

For PC input signal

TV screen information

You can display the currently selected channel or other information such as the aspect ratio on the TV screen.

In the digital mode, the detailed broadcasting information for the current off-the-air channel such as program title and program guides are displayed.

Press INFO.

ba c d

1 1.1 KABC

g h i



  



Resolution: Picture format:

Sound mode: Audio language:

Favorites:

Rating:

Sleeptimer:

Channel number / Input mode

Switching channels  p. 22

Watching channels from an external device  p. 23

Broadcast station Program title (for DTV only) CC (not available if Closed caption is set to Off)

Caption settings  p. 37

Program’s image aspect ratio

Changing Picture format  p. 24

Audio language (DTV) / Audio mode (Analog TV)

Sound  p. 33

Favorites

Create a list of favorite channels  p. 24

Child lock rating

Child lock  p. 39

Remaining time on sleep timer

Sleeptimer  p. 34

A Day of Memories

1080i Full

Stereo English English audio with description.

All

None

UnscaledWide screen4:3

This unit can also be connected to your PC that has a DVI terminal.

•

Use an HDMI-DVI conversion cable for this video connection and it requires stereo mini 3.5mm plug audio cable for analog audio signal as well.

Refer to 16:9 video signal on this page if the PC has HDMI output.

•

4:3

Wide screen

Displays a proportionately stretched picture. Sidebars appear on both edges of the screen.

Displays a picture that is stretched out of proportion to fill the screen.

Unscaled Displays a picture in its original size.

If the signal source has side or top-bottom bars inserted into the picture, the Picture format function will not eliminate them.

Press INFO to hide the information.

Note(s)

While the program guide is displayed, the closed caption function is interrupted.

•

The information display will automatically disappear in 5 seconds.

•

Continued on next page.

Using options menu

Before you begin:

You can access to some TV settings directly by using OPTIONS.

Press OPTIONS to display options menu, then press OK.

Use  to select a desired setting, then press OK.

Options

a b c d

Options



Following settings can be configured.

Voice guide toggle

Closed captions

Digital audio language

Mono/Stereo

Controls



If you have our brand products such as Blu-ray disc player or DVD recorder that are compatible with EasyLink functions, connect them to this unit via an HDMI cable so you can simply operate various items from this unit’s remote control.

select a device connected to an HDMI connection.  p. 23 You must set On in Master EasyLink.  p. 36 Otherwise, LINK does not work even if you connected our brand devices to this unit.

Press OPTIONS to display options menu.

Use  to select Controls then press OK.

Use  to select the desired item, then press OK.

Device-menu

Device-contents

Device-favorite Controls the pop-up menu of your Blu-ray discs.

To set Voice guide on or off.

Voice guide toggle  p. 36

To choose the Closed captions display setting.

Closed captions  p. 37

To Select the language according to your preference. (It differs depending on the program.)

Digital audio language  p. 40

To Select an audio format.

Mono/Stereo  p. 40

Controls the menu of your connected EasyLink device.

Controls the top menu of your DVD or Blu-ray discs.

Picture and sound



Following settings can be configured.

Auto picture

Auto sound

Headphone volume

TV speakers

Picture format

Setup To display setup menu.

ECO settings



Following settings can be configured.

Switch off timer

To set predefined picture mode.

Picture  p. 31

To set predefined sound mode.

Sound  p. 33

To adjust headphone volume.

Sound  p. 33

To Select the audio output from the unit’s speakers or not.

Sound  p. 33

To switch the TV aspect ratio.

Changing Picture format  p. 24

You can turn off the unit automatically when there is no operation for specified time. In spite of this setting, the unit goes into standby mode automatically if there is no signal input and no user operation for 15 minutes.

Press  repeatedly to change the amount of time (increases the time by 30 minutes up to 240 minutes).

Each press of  will decrease the time by 30 minutes.

To cancel the timer, press  repeatedly until “0” is displayed.

26 .English

Note(s)

Some of EasyLink functions may not be available depending on your EasyLink devices or

•

discs. You must connect this unit to our brand EasyLink devices and be sure its EasyLink (HDMI CEC)

•

setting is also set to On. We do not guarantee 100% interoperability with other brands of HDMI link compliant devices.

•

Continued on next page.

27 .English

USB

Your TV is fitted with a USB connection that enables you to view photos, listen to music or watch video files stored on a USB memory stick.

Press SOURCE and use  to select USB, then press OK.

Use  to select the desired file, then press OK.


USB DISK 2016_12_24 folder_A folder_B folder_C

These recorded files must meet specifications shown below:

•

Picture (JPEG / Progressive JPEG)

JPEG Upper limit 4000x4000 pixels

Progressive JPEG Upper limit 1024x768 pixels

Music (MP3 / WAV / AAC)

MP3

WAV

AAC


Sampling frequency 16 kHz - 48 kHz

Constant bit rate 8 kbps - 320 kbps

Sampling frequency 8 kHz - 48 kHz

Constant bit rate 64 kbps - 1.5 Mbps

Sampling frequency 8 kHz - 48 kHz

Constant bit rate -

Note(s)

This unit accepts USB memory stick only. Other storage devices such as external HDD by USB

•

bus power will not work. Do not use an extension cord and/or USB hub to connect devices to this unit. Always directly

•

insert the USB flash memory stick to this unit directly. We cannot be held responsible if your USB memory stick is not supported, nor will we accept

•

any liability for damage or loss of stored data. The USB memory stick is not included with this TV.

•

A maximum of 1,023 folders or files can be recognized.

•

A file name exceeding 256 characters or contains a dot character is not supported on this TV.

•

A USB memory stick that required its own driver or the device with a special system such as

•

fingerprint recognition are not supported. Be sure to keep a backup copy of the original files on your USB device before you play them

•

back on this unit. We have no responsibilities for damage or loss of your USB stored data. To avoid damaging the USB memory stick and the unit always turn off the unit before you

•

remove the USB memory stick. This unit is not allowed to use the USB memory stick which requires external power supply (500

•

mA or more). This unit does not support MTP (Media Transfer Protocol) or the file other than FAT16 and FAT32

•

file system. If the file is not supported, an error message appears. When the unit does not recognize the USB memory stick, try reconnecting it.

•

Playing the files recorded with high bit rates, the images can be interrupted in some occasions.

•

This unit does not support external subtitles.

•

This unit cannot play back a file which goes over the limit of file restriction limit.

•

Video (MPEG / VOB / AVI / MP4)

Maximum video

Extension .avi

Video codec

Audio codec

Dolby Digital YES YES YES YES YES YES

MPEG1/2 audio

layer1/2/3

LPCM YES YES YES YES YES YES

AAC-LC YES YES YES YES YES YES

H.264, H.265/HEVC: 3840x2160@30fps,

MPEG: 1920x1080@60fps

.mpg,

.mpeg

MPEG1, MPEG2, MPEG4,

MPEG1, MPEG2, MPEG4

H.264

YES YES YES YES NO YES

.ts,

.trp,

.tp

MPEG1, MPEG2,

H.264,

H.265/

HEVC

.vob .mp4 .mkv

MPEG1,

MPEG2,

MPEG1,

MPEG4,

MPEG2

H.264,

H.265/

HEVC

MPEG1, MPEG2, MPEG4,

H.264,

H.265/

HEVC

Continued on next page.

28 .English

Viewing photos

Use  to select Photo, then press OK.

Use  to select the desired item, then press OK.

Press OK or . to start a slide show of the files.

Press OK or . to pause the slide show.

•

The . icon appears.

•

Press  or  to move between images.

•

Press BACK or . to stop the slide show.

•

Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

toggle *1

Repeat

Slide time

Transitions *2

picture *2

*1 Voice guide toggle is available in slide show and pause mode. *2 You can set Repeat, Slide time, Transitions and Auto picture when

*3 You can set Rotate and Zoom when slide show is in pause mode.

Auto

Rotate

Zoom

images are in slide show.

Off Sets Voice guide to off. On Sets Voice guide to on. Off Sets repeat playback to off.

One Sets repeat playback for a selected image file.

All

Short Switches to the next image in 5 seconds.

Medium Switches to the next image in 10 seconds.

Long Switches to the next image in 15 seconds.

None No effect when switching images.

Dissolve Overlaps the next image on the current image.

Wipe right Pushes the current image out from left.

Wipe left Pushes the current image out from right.

Wipe up Pushes the current image out from bottom.

Wipe down Pushes the current image out from top.

Box in

Box out

Selects the picture mode according to your preference. (Standard, Natural, Vivid, Sports, Movie, Game, Energy saving and Internet video)

0 Displays an image in its original direction. 90 Rotates an image 90 degrees clockwise. 180 Rotates an image 180 degrees clockwise.

270 Rotates an image 270 degrees clockwise.

1X Displays an image in its original size. 2X Magnifies a current image by 2 times. 4X Magnifies a current image by 4 times.

Sets repeat playback for all image files in the current folder.

The next image comes to the center from the outside.

The next image goes to the outside from the center.

Playing music

Use  to select Music, then press OK.

Use  to select the desired item, then press OK.

Press OK or . to play the selected files.

Press OK or . to pause, then press OK or . again to resume.

•

Press  to fast-forward search.

•

Press  to fast-backward search.

•

Press . to stop playback.

•

Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

TV Speakers

Auto sound

* Voice guide toggle is available in slide show and pause mode.

toggle

Repeat

Shuffle

Off Sets Voice guide to off. On Sets Voice guide to on. Off Sets repeat playback to off.

One

All

Off Sets shuffle playback to Off.

Off

Speakers

EasyLink

Selects the sound mode according to your preference. (Standard, Vivid, Sports, Movie, Music and News)

Sets repeat playback for a selected music file.

Sets repeat playback for all music files in the current folder.

Sets shuffle playback for all music files in the current folder.

The sound will not be output from the unit's speakers.

The sound will be output from the unit's speakers.

You can control audio output from your connected EasyLink compliant devices with VOL + / – by using this unit's remote control.

Continued on next page.

Playing movies

Use  to select Movie, then press OK.

Use  to select the desired item, then press OK.

Press OK or . to play the selected files.

Press OK or . to pause, then press OK or . again to resume.

•

Press  to fast-forward search.

•

Press  to fast-backward search.

•

Press . to stop playback.

•

Press . to resume from the point at which playback was stopped. Press OK to play from the beginning of the file.

Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

TV speakers

Auto picture

Auto sound

* Voice guide toggle is available in slide show and pause mode.

toggle

Repeat

Off Sets Voice guide to off.

On Sets Voice guide to on.

Off Sets repeat playback to off.

One

All

Off

Speakers EasyLink

Selects the picture mode according to your preference. (Standard, Natural, Vivid, Sports, Movie, Game, Energy saving and Internet video)

Selects the sound mode according to your preference. (Standard, Vivid, Sports, Movie, Music and News)

Sets repeat playback for a selected video file.

Sets repeat playback for all video files in the current folder.

The sound will not be output from the unit's speakers.

The sound will be output from the unit's speakers.

You can control audio output from your connected EasyLink compliant devices with VOL + / – by using this unit's remote control.

29 .English

Note(s)

The resume information will be kept even when the unit is Turned off.

•

If you play another file while the previously viewed file is being resumed, the resume information

•

of the previously viewed file will be deleted. The file or the folder in resume stop mode will be highlighted in gray on List or Thumbnails.

•

4 Getting more from your

This section describes the overview of the Setup menu displayed when you press  and use  to Select Setup.

The Setup menu consists of the function setting items below.

Press  to display the Home menu.

Picture and sound setup

Guides you to get the best picture and sound settings.

 p. 31

30 .English

Use  to select Setup, then press OK.

Network

Use  to select the desired menu and an item, then press OK.

Picture and

sound setup

settings

To quickly set basic picture and sound settings, press OK

Search for

channels

Channel settings

Net TVSourceWatch TV Home

Wireless

Screencasting

Connect to

network

Network

settings

Setup

Update

software

Software

settings

TV settings

Accesses menus that allow you to change picture, sound and TV usage settings.

Search for channels

Guides you through channel installation.

Channel settings

Accesses menus that allow you to change channel settings.

Connect to network

Guides you through network installation.

Network settings

Accesses menus that allow you to network settings.

 p. 31

 p. 38

 p. 41

 p. 42

Update software

Guides you through an update of the TV software.

Software settings

Accesses menus that allow you to change software settings.

 p. 46

 p. 47

Continued on next page.

Before you begin:

31 .English

Picture and sound setup

You must set Home in Location.  p. 35 Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

Press  and use  to select Setup then press OK.

Use  to select Picture and sound setup, then press OK.

Follow steps 7 to 8 in Initial setup  p. 21

TV settings


You must set Home in Location.  p. 35 Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

Press  and use  to select Setup then press OK.

Use  to select TV settings, then press OK.

Use  to select Picture, then press OK.


Sound Features Installation Accessibility

Use  to select the item you want to adjust, then press OK.

The following picture settings can be configured. Depending on the format of the picture source, some picture settings are not available.

Auto picture

Auto picture Backlight Contrast Brightness Color Tint Sharpness Pixel Plus Ultra HD Advanced settings Picture format Mode selection Horizontal position Vertical position

To set your TV to a predefined picture setting.

Personal

Standard For normal TV viewing.

Natural

Vivid

Sports

Movie

Game

Energy saving

Internet video

The customized settings you defined using the Picture menu.

Ideal picture mode for viewing high quality content without any picture enhancements.

Enhanced picture contrast and sharpness for viewing in a well-lit room.

Brilliant picture settings for high action.

Deep picture settings for a cinematic experience.

Optimized for PCs and game consoles.

Eco TV settings for low power consumption.

Optimized for low bit-rate internet video.

When you adjust the following settings, Personal picture will be set automatically.

Cursor  Cursor 

Backlight

Contrast To decrease contrast To increase contrast

Brightness To decrease brightness To increase brightness

Color

Tint To add green To add red

Sharpness To soften To sharpen

Pixel Plus Ultra HD

Advanced settings

Picture format

Mode selection

Horizontal position To move PC screen left To move PC screen right

Vertical position

HDR mode settings are only available on the following models:

࣭65PFL5602/F7 ࣭65PFL5602/F7 D ࣭55PFL5602/F7 ࣭50PFL5602/F7

Other models, such as 65PFL5602/F7 C, automatically switch to the decided picture settings upon receiving HDR signals.

Manual Zoom setting is not available on the following models:

࣭65PFL5602/F7 ࣭65PFL5602/F7 D ࣭55PFL5602/F7 ࣭50PFL5602/F7

Your model number can be confirmed on the rating label applied on the rear cabinet.

To reduce power consumption and brightness

To decrease color intensity

Enters sub-menus to adjust the following settings: (Dynamic contrast, Color enhancement, Black

stretch, 120 PMR, 4K UHD Upscaling, Macro Dimming, Noise reduction and MPEG artifact reduction)

Enters sub-menus to adjust the following settings: (Color alignment, Custom color management,

HDR mode mode)

Movie expand 14:9 Movie expand 16:9

To move PC screen down

*1, Gamma, Blue stretch and Film

Automatic

Super zoom

4:3

Wide screen

Full

Manual Zoom

Unscaled

HDTV

Cursor  Cursor 

To increase power consumption and brightness

To increase color intensity

Changing Picture format  p. 24

To turn off image enhancement features which makes the TV to act purely as a monitor

To enable image enhancement features to improve picture quality

To move PC screen up

Continued on next page.

You may adjust picture quality and enhancement settings using Pixel

Plus Ultra HD and Advanced settings sub menus.

Auto picture Backlight Contrast Brightness Color Tint Sharpness

Pixel Plus Ultra HD

Dynamic contrast

Color enhancement Black stretch 120 PMR 4K UHD Upscaling Macro Dimming Noise reduction MPEG artifact reduction

O Minimum Medium Maximum

Advanced settings Picture format Mode selection Horizontal position Vertical position

Dynamic

contrast

Color

enhancement

Black

stretch

120 PMR

4K UHD

Upscaling

Macro

Dimming

Noise

reduction

MPEG

artifact

reduction

Auto picture Backlight Contrast Brightness Color Tint Sharpness

To select the desired setting, then press OK (Off, Minimum, Medium and Maximum)

Off To set color enhancement to off

On To make colors more vivid and bright

To select the desired setting, then press OK (Off, Minimum, Medium and Maximum)

Off To set 120 PMR to Off

On To make the video appear smoother

To select the desired setting, then press OK (Off, Minimum, Medium and Maximum)

Color alignment

Custom color management HDR mode Gamma Blue stretch Film mode

Mode Red gain Green gain Blue gain Red oset Green oset Blue oset

Pixel Plus Ultra HD

Advanced settings

Picture format Mode selection Horizontal position Vertical position

32 .English

To select the desired setting, then press OK (Red, Yellow, Green, Cyan, Blue and Magenta)

Cursor  Cursor 

To rotate only

Custom color management

Tint

selected color tint in clockwise direction

To decrease color

Saturation

with only selected color

To decrease

Brightness

brightness with only selected color

Off To set HDR mode to off

HDR mode

Auto

Automatically switches to a dedicated picture quality setting when receiving HDR signal

To select the desired setting, then press OK

Gamma

(Very Dark Room, Dark Room, Normal, Bright Room and Very Bright Room)

Blue stretch

To select the desired setting, then press OK (Off, Minimum, Medium and Maximum)

Off To set film mode to off

Film mode

HDR mode settings are only available on the following models:

Auto

To optimize the picture recorded by the original film

࣭65PFL5602/F7 ࣭65PFL5602/F7 D ࣭55PFL5602/F7 ࣭50PFL5602/F7

Other models, such as 65PFL5602/F7 C, automatically switch to the decided picture settings upon receiving HDR signals.

Your model number can be confirmed on the rating label applied on the rear cabinet.

Note(s)

Mode selection is available only if

•

–The external input modes are selected HDMI 1, HDMI 2 or HDMI 3. –The connected HDMI device is outputting a video signal.

To rotate only selected color tint in counterclockwise direction

To increase color with only selected color

To increase brightness with only selected color

Color

alignment

Mode

Red gain

Green gain

Blue gain

Red offset

Green offset

Blue offset

To set the color temperature to Personal, Cool, Normal and Warm.

When you adjust the following settings,

Personal will be set automatically.

Cursor  Cursor 

To decrease red contrast

To decrease green contrast

To decrease blue contrast

To decrease red brightness

To decrease green brightness

To decrease blue brightness

To increase red contrast

To increase green contrast

To increase blue contrast

To increase red brightness

To increase green brightness

To increase blue brightness

Continued on next page.

Before you begin:

33 .English

Sound

You must set Home in Location.  p. 35 Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into standby mode.

Press  and use  to select Setup then press OK.

Use  to select TV settings, then press OK.

Use  to select Sound, then press OK.


Sound

Features Installation Accessibility

Use  to select the item you want to adjust, then press OK.

The following sound settings can be configured. Depending on the format of the broadcasting, some sound settings are not available.

Auto sound

Adjust the tonal quality for each frequency.

Equalizer

Adjust the speakers to suit your listening preference.

Balance

Auto sound Equalizer Balance Sonic Emotion Premium Auto volume leveling TV speakers Headphone volume Digital output format Delta volume

To set your TV to a predefined sound setting. When you adjust the following settings (Equalizer,

Sonic Emotion Premium and Auto volume leveling), Personal sound will be set automatically.

Personal

Standard For normal TV viewing.

Vivid Enhanced sound.

Sports Clear sound for high action.

Movie

Music Optimized for music playback.

News

To adjust each level of tonal quality Press BACK to go back to the previous menu.

To adjust the balance of the right and left speakers

The customized settings you defined using the Sound menu.

Powerful sound settings for a cinematic experience.

Set the anchor's voice at a comfortable volume.

Cursor  Cursor 

This selects sound modes for more spatial or surround sound reproduction.

Sonic

Emotion

Sonic

Emotion

Premium

This function keeps a constant Loudness differential between the TV commercials and the programs.

Auto volume

leveling

You can select the audio output from the unit’s speakers or not. If your amplifier is HDMI link function compatible and connected by an HDMI cable to this unit, some sound operations such as volume up can be changed by using this unit’s remote control. Make sure Master EasyLink is set to On.  p. 36

TV speakers

Adjust headphone volume.

Headphone

You can set the digital audio output format from SPDIF/ARC.

Digital output

If a channel or input device is too loud or too soft, navigate to that channel or input device.

Delta volume

Dialog

Enhancement

Bass

Enhancement

Absolute 3D

Sound

volume

format

Off To set Sonic Emotion to off On To set Sonic Emotion to on Off To set Dialog Enhancement to off On To set Dialog Enhancement to on Off To set Bass Enhancement to off On To set Bass Enhancement to on Off To set Absolute 3D Sound to off On To set Absolute 3D Sound to on

Off

Speakers

EasyLink

To decrease or increase volume

PCM To output PCM format

Bitstream

Provides the ability to set a custom volume level for the current channel or input source.

If the source volume is too loud, set a negative value (-1 to -12)

If the source volume is too soft, set a positive value (+1 to +12)

To remove the Auto volume leveling

To reduce volume differences between the TV commercials and the programs

No output sound from the unit’s speakers

To output sound from the unit’s speakers

To control audio output from your connected EasyLink compliant devices with VOL + / – by using this unit's remote control.

Cursor  Cursor 

To output audio in its native format as Bitstream to connected audio receiver

Cursor  Cursor 

Continued on next page.

34 .English

Features

Press  and use  to select Setup then press OK.

Use  to select TV settings, then press OK.

Use  to select Features, then press OK.

Picture Sound

Features

Installation Accessibility

Adjust the following items.

Sleeptimer

Sleep timer can set the unit to go into standby mode after an incremental period of time.

Use  to select Sleeptimer, then press OK.

Use  repeatedly to change the amount of time (increases the time by 5 minutes up to 180 minutes).

Each press of  will decrease the time by 5 minutes.

•

Press INFO once to call up the display for checking the remaining

•

time. To cancel the sleep timer, press  repeatedly until “0” is

•

displayed.

Sleeptimer

Installation

Press  and use  to select Setup then press OK.

Use  to select TV settings, then press OK.

Use  to select Installation, then press OK.

Picture Sound Features

Installation

Accessibility

Adjust the following items.

Language

You can set the language for the on-screen display.

Use  to select Language, then press OK.

Picture Sound Features

Installation

Accessibility

Language Preferences Restore default settings

Language

Preferences Restore default settings

English

Français Español

Use  to select English, Español or Français, then press OK.

Note(s)

If you need the English menu instead of the Spanish or French menu’s, press .

•

Use  to select Configuración or Configuration, then press OK. Use  to select Ajustes de TV or Réglages de la télévision, then press OK. Use  to select Instalación or Installation, then press OK. Use  to select Idioma or Langue, then press OK. Use  to select English, then press OK. Press  to exit the Home menu.

Continued on next page.

Setting your location to home

HDMI mode

TV placement

Retail Demo

One-touch play

One-touch standby

System audio control

Remote control (RC) key forwarding

HDMI-ARC (Audio Return Channel) (HDMI 2 only)

35 .English

Preferences

You can set the unit to reduce the power consumption or adjust the backlight brightness in Location setting.

EasyLink allows you to operate your connected EasyLink device.

Choosing Home gives you full flexibility to change predefined settings for picture and sound.

Use  to select Preferences, then press OK.

Use  to select Location, then press OK.

Language

Preferences

Restore default settings

Use  to select Home, then press OK.

Retail

Home

Note(s)

You must set Home in the menu. Otherwise, personalized picture and sound settings will not

•

be memorized after the unit goes into standby mode.

If there are issues with picture/color and/or sound when connecting an external device using the HDMI port, please try switching the HDMI mode following the instructions below.

Press  and use  to select Setup, then press OK.

Use  to select TV settings, then press OK.

Use  to select Installation, then press OK.

Use  to select Preferences, then press OK.

Use  to select HDMI mode, then press OK.

Use  to select HDMI1, HDMI2 or HDMI3, then press OK.

Use  to select Max 4K@60Hz + HDR, Max 4K@60Hz or Max

4K@30Hz (Compatibility) depending on the output capabilities of

the external device, then press OK.

When switching the HDMI configuration, the screen will black out

•

for a moment, then come back on.

Location

EasyLink HDMI mode TV placement Retail Demo

The unit will be set up with predefined settings for retail displays. In this setting, you can set the backlight brighter.

The unit is set to maximize the energy efficiency for home setting and it can be adjusted through a choice of picture and sound quality selections according to your preference.

Retail

Home

To apply the best settings for your TV, select wall mount or stand mount.

Use  to select Preferences, then press OK.

Use  to select TV placement, then press OK.

Use  to select Wall mounted or On a TV stand, then press OK.

When you set Location to Retail, E-sticker (Electronic Sticker) is displayed. E-sticker can be turned off using procedure below.

Use  to select Preferences, then press OK.

Use  to select Retail Demo, then press OK.

Use  to select Off, then press OK.

Use Philips EasyLink

Your TV supports Philips EasyLink, which enables one-touch play and one-touch standby between EasyLink-compliant devices. Compliant devices must be connected via an HDMI connector.

When you connect your TV to devices that support one-touch play, you can control your TV and the devices with one remote control. For

example, when you press (Play) on your DVD remote control, your TV automatically switches to the correct channel to show the DVD content.

When you connect your TV to devices that support standby, you can use your TV remote control to put your TV and all connected HDMI devices in standby mode. You can perform one-touch standby using the remote control from any of the connected HDMI devices.

When you connect your TV to HDMI CEC compliant devices, your TV can switch automatically to play audio from the connected device. To use one-touch audio, you must map the audio input from the connected device to your TV. You can use the remote control from the connected device to adjust the volume.

RC key forwarding allows you to control EasyLink-compliant devices using your TV remote control.

HDMI-ARC allows you to use Philips EasyLink to output TV audio directly to a connected audio device, without the need for an additional digital audio cable. Be sure that the device is HDMI CEC and ARC compliant, and that the TV is connected to the device using an HDMI cable attached to both HDMI-ARC connectors.

Note(s)

Philips does not guarantee 100% interoperability with all HDMI CEC devices.

•

The EasyLink-compliant device must be switched on and selected as the source.

•

Note(s)

For HDMI 1 and HDMI3, Max 4K@30Hz (Compatibility) is the default setting, and for HDMI 2,

•

Max 4K@60Hz + HDR is the default setting. The HDMI connector with HDMI mode set to Max 4K@30Hz (Compatibility) supports up to

•

UHD 30P, while The HDMI connector with HDMI mode set to Max 4K@60Hz supports up to UHD 60P. The HDMI connector with HDMI mode set to Max 4K@60Hz + HDR supports up to UHD 60P with HDR signal.

Switching the HDMI mode may cause loss of HDMI CEC functionality in certain cases.

•

Continued on next page.

EasyLink (HDMI CEC)

This function allows you to operate the linked functions between our brand devices with a EasyLink feature and this unit connecting through an HDMI cable. You must connect this unit to our brand EasyLink devices and be sure its EasyLink (HDMI CEC) setting is also set to on.

Use  to select Preferences, then press OK.

Use  to select EasyLink, then press OK.

Use  to select the item you want to adjust, then press OK.

Location

EasyLink

HDMI mode TV placement Retail Demo

Master EasyLink

Auto TV On RC key forwarding HDMI-ARC

O

Return your settings to default values

You can return settings to their default values.

Use  to select Restore default settings, then press OK.

Use  to select Reset AV settings or Reset all settings, then press OK.

Reset AV settings

Reset all settings Return all the settings to their default values.

Return picture and sound settings to their default values. The channel installation settings are not affected.

Accessibility

Press  and use  to select Setup then press OK.

Use  to select TV settings, then press OK.

Use  to select Accessibility, then press OK.

36 .English

Set the Master EasyLink to On or Off. The following additional settings will be grayed out when you set them to Off.

Off Disables all EasyLink.

Master

EasyLink

This unit will turn on when the power on signal is sent from your connected EasyLink device.

Auto TV On

You can operate some functions such as disc playback or call up the menu of the connected devices, by using this unit’s remote control.

RC key

forwarding

Note(s)

Pause may not work properly on some devices even if they are EasyLink (HDMI CEC)

•

compliant.

HDMI-ARC allows you to use Philips EasyLink to output TV audio directly to a connected audio device, without the need for an additional digital audio cable.

HDMI-ARC

(HDMI 2 only)

Off

Off Disable RC key forwarding.

Off Disable HDMI-ARC.

Selects if you have connected an external device that is compatible with the EasyLink function.

This unit stays in Standby mode even if you turn on your connected EasyLink device.

This unit turns on automatically when you turn on your connected EasyLink device.

PLAY, PAUSE. / STOP. / FWD/ / REV0 / VOL + / – / 

(MUTE) / OPTIONS /  / OK / BACK / the NUMBER buttons can

be used to control your connected EasyLink devices by this unit’s remote control.

You can output TV audio through the HDMI cable solely, provided both the TV and device are HDMI-ARC compliant.


Sound Features Installation

Accessibility

Adjust the following items.

Voice guide Caption settings Digital audio preferences

Voice guide

Lets you configure voice guide and its settings.

Use  to select Voice guide, then press OK.

Voice guide toggle

Speed

Pitch

Verbosity

Volume level

Off To set Voice guide off

On To set Voice guide on

Fast

Normal

Slow

High

Normal

Low

Verbose Set voice guide explanation

Succinct

Loud

Normal

Soft

Set voice guide speed based on your preference

Set voice guide pitch based on your preference

verbosity based on your preference

Set voice guide volume based on your preference

Continued on next page.

So, you must be Philip. Hi!

I’m pleased to meet you.

37 .English

Caption settings

Closed captions displays the audio portion of the program as superimposed text over the video.

Use  to select Caption settings, then press OK.

Voice guide

Caption settings

Digital audio preferences

Closed captions

Caption service Digital caption service Digital caption options

Off Closed caption is not displayed.

Closed captions

On Closed caption is always displayed.

CC w/mute

Closed caption is displayed when the sound is off.

Digital TV operation

In addition to the basic closed caption, DTV has its own closed caption called digital caption service. Use this menu to change the settings for digital caption service.

Select one of these before

Digital caption

service

CS-1 to CS-6

changing any other item in Caption settings menu. Choose CS-1 under

normal conditions.

You can choose the size, font, color, background and other characteristics of the caption text.

Reset to

default

You can reset the status of digital caption options.

You can change closed captioning font style, size, color and transparency. (Font style, Font size, Font color and Font

Digital caption

options

opacity)

You can change background color and transparency of the displayed caption. (Background color and Background opacity)

You can change edge color and type of the displayed caption text. (Edge color and Edge type)

Picture display

So, you must be Philip. Hi!

I’m pleased to meet you.

O On CC w/ mute

Cable / NTSC (Analog) TV operation

The primary closed captions and text services. The closed captions

CC-1 and T-1

or text is displayed in the same language as the program’s dialog (up to 4 lines of script on the TV screen).

Caption service

CC-3 and

T-3

Serve as the preferred data channels. The closed captions or text is often a secondary language.

Rarely available and broadcasters

CC-2, CC-4, T-2 and T-4

use them only in special conditions, such as when CC-1 and CC-3 or T-1 and T-3 are not available.

There are 3 display modes according to programs:

•

Paint-on Displays characters on the TV screen immediately.

Pop-on

Roll-up

Note(s)

Digital caption service that you can switch differs depending on the broadcast description.

•

Closed captioning service may not be controlled by this unit’s menu options if you are watching

•

television through an external cable or satellite set-top box. In which case you will need to use the menu options on the external set-top box to control closed captioning.

The captions do not always use correct spelling and grammar.

•

Not all TV programs and product commercials include closed caption information. Refer to your

•

area TV program listings for the TV channels and times of closed caption shows. The captioned programs are usually noted in the TV listings with service marks such as CC.

Not all captioning services are used by a TV channel during the transmission of a closed caption

•

program. Closed caption will NOT be displayed when you are using an HDMI or a component

•

connection. To show the closed caption on your TV screen, broadcast signal must contain the closed caption

•

data. Not all TV programs and commercials have the closed caption or all types of the closed

•

caption. Caption's and text may not exactly match the TV voice.

•

Changing channels may delay the closed caption for a few seconds.

•

Adjusting or muting the volume may delay the closed caption for a few seconds.

•

Abbreviations, symbols and other grammatical shortcuts may be used in order to keep pace

•

with the on-screen action. This is not a malfunction. The caption or text characters will not be displayed while the Main menu or functions display

•

is shown. If a black box appears on the TV screen, this means that the closed caption is set to the text

•

mode. To clear the box, select CC-1, CC-2, CC-3 or CC-4. If the unit receives poor quality television signals, the captions may contain errors or there might

•

be no captions at all. Some possible causes of poor quality signals are:

–Automobile ignition noise –Electric motor noise –Weak signal reception –Multiplex signal reception (ghosts or screen flutter) –Data dropout and pixelation (for DTV only)

The unit retains the closed caption setting if the power fails.

•

When the unit receives special effects playback signal (e.g. search, slow and still) from a VCR’s

•

video output channel (ch3 or ch4), the unit may not display the correct caption or text. The EUT setting that satisfies § 79.102 (e) is as follows:

•

–Font: Mono-font –Character size: Large

Once characters are stored in memory, they are displayed all at once.

Displays the characters continuously by scrolling (max. 4 lines).

Tex t font (Font style, Font size, Font color and Font opacity)

Text edge (Edge color and Edge type)

Background

(Background color and Background opacity)

Review your setting choice made above by looking in the upper left

•

corner of the displayed setting box (not all selections show the differences selected).

Continued on next page.

38 .English

Digital audio preferences

You can set the interpretive broadcasting by an audio explanation.

Use  to select Digital audio preferences, then press OK.

Voice guide Caption settings

Digital audio preferences

Audio accessibility

Audio language

Primary audio

selection criteria

Audio accessibility Audio language Primary audio selection criteria

To prioritize VI-Visually Impaired streaming or HIHearing Impaired streaming: The setting for handicapped users (Main audio, Visually Impaired or Hearing Impaired).

To set your preferred language in the audio streaming (English, Spanish or French).

To set TV priority based on either of the above settings: (Audio accessibility or Audio language).

Search for channels

Be sure the RF cable is correctly connected to this unit and you are registered with your cable TV provider when you install cable channels.

Press  and use  to select Setup, then press OK.

Use  to select Search for channels, then press OK.

Use  to select Start, then press OK.

Install channels

You can search and store all channels. If you move the unit to a different area after the initial setting, it is recommended to perform Autoprogramming.

Use  to select Antenna or Cable, then press OK.

Press OK on Start.

When the scanning and memorizing of available channels is

•

completed, the lowest memorized channel will be displayed.

Follow the on-screen instructions to complete the installation.

Channel settings

Press  and use  to select Setup, then press OK.

Use  to select Channel settings, then press OK.

Adjust the following items.

Channel installation

Child lock

Change PIN

Digital audio language

Mono/Stereo

Installation mode Uninstall channels

Channel installation

Be sure the RF cable is correctly connected to this unit and you are registered with your cable TV provider when you install cable channels.

Installation mode

Use  to select Channel installation, then press OK.

Use  to select Installation mode, then press OK.

Use  to select Antenna or Cable, then press OK.

When Antenna is selected, the TV detects antenna signals. It

•

searches for DTV and analog TV channels available in your area. When Cable is selected, the TV detects signals supplied by cable.

•

It searches for DTV, analog TV and cable channels available in your area.

Uninstall channels

The channels selected here can be skipped when selecting the channels using CH + / –.

Those channels can still be selected with the NUMBER buttons.

Use  to select Channel installation, then press OK.

Use  to select Uninstall channels, then press OK.

Use  to select the channel you want to remove, then press OK.

The removed channels are not displayed on the list of favorite

•

channels. To reactivate a removed channel, use  then press OK.

•

System searching. Please wait...

Auto programming may take more than 20 minutes to complete.

12 34

Stop

Digital channels found: Analog channels found:

Total progress:

0 0

Continued on next page.

To set the sub ratings (displayed in the right column)

39 .English

Child lock

You can prevent your children from watching certain programs or certain channels by locking the TV controls and by using ratings.

Use  to select Child lock, then press OK.

Channel installation

Child lock

Change PIN Digital audio language Mono/Stereo

Use the NUMBER buttons to enter the 4-digit numbers for your PIN

code.

When you have not set up your PIN code, enter 0, 0, 0, 0.

•

When the PIN code is correct, Child lock menu is displayed.

•

See the following description for setting each item.

Channel installation

Child lock

Change PIN Digital audio language Mono/Stereo

Note(s)

When you select the higher rating and set it to ,, the lower ratings will be blocked

•

automatically. To remove all blocks place a check in the All box and then remove that check to remove all

•

blocks. Region ratings lock will be available when the unit receives a digital broadcast using the new

•

rating system. To block any inappropriate programs, set your limits in TV ratings lock, Movie ratings lock and

•

Region ratings lock. For the United States, the unit may download the region ratings lock table, if required.

•

The Canadian rating systems on this unit are based on CEA-766-A and CRTC policy.

•

Setting TV and movie ratings

Movie ratings lock is the rating system created by MPAA. TV ratings lock has controlled access to individual programs based on their age ratings and content rating.

Use  to select TV ratings lock or Movie ratings lock, then press OK.

Use  to select the desired rating, then press OK repeatedly to switch between block and view.

indicates that the rating is locked (Blocked).

•

indicates that the sub rating is locked (Blocked).

•



indicates that the rating is not locked (Viewable).

•



TV ratings lock Movie ratings lock Canadian English rating Canadian French rating Region ratings lock

TV ratings lock

Movie ratings lock Canadian English rating Canadian French rating Region ratings lock

All None

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

TV ratings lock

Movie ratings lock

Canadian English rating

Canadian French rating

Region ratings lock

All

None

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

Movie ratings lock

TV ratings lock

Movie ratings lock

Canadian English rating

Canadian French rating

Region ratings lock

US movie

ratings

NR None No rating

– TV-Y Appropriate for all children – TV-Y7 Appropriate for all children 7 and older

G TV-G General audience

PG TV-PG Parental guidance suggested

PG-13 – Unsuitable for children under 13

– TV-14 Unsuitable for children under 14

R –

NC-17 – No one under 17 admitted

X TV-MA Mature audience only

For TV ratings lock, you can further set the sub ratings to block specific elements of programming. To set the sub ratings, follow the step below.

Use  to select the desired rating, then press OK repeatedly to switch between , and .

TV ratings lock

Movie ratings lock

Canadian English rating

Canadian French rating

Region ratings lock

US TV

ratings

All All ratings locked including no rating

All

G PG PG-13 R NC-17 X

Description

Restricted under 17 requires accompanying parent or adult guardian

All None TV-Y

TV-Y7

TV-G TV-PG TV-14 TV-MA

Fantasy Violence

Continued on next page.

40 .English

US TV ratings Sub rating

TV-Y7 Fantasy Violence TV-PG Violence

TV-14

TV-MA

Note(s)

Blocked sub rating's will appear beside the main rating category in TV ratings lock menu.

•

You cannot block a sub rating if the main rating is set to .

•

Changing the category to , or  automatically changes all its sub ratings to the (, or ).

•

Sex Language Dialog

Violence Sex Language

Canadian English or Canadian French ratings

You can select the rating for Canadian English or Canadian French broadcasting.

Use  to select Canadian English rating or Canadian French rating, then press OK.

Use  to select the desired rating, then press OK repeatedly to switch between block and view.

indicates that the rating is locked (Blocked).

•

indicates that the rating is not locked (Viewable).

•



Canadian

English

rating

C – For all children

C8+ – For all children 8 and older

– 8 ans+ Unsuitable for ages under 8

PG – Parental guidance suggested

– 13 ans+ Unsuitable for ages under 13

14+ – Unsuitable for ages under 14

– 16 ans+ Unsuitable for ages under 16

18+ 18 ans+ Adult audience only

Canadian

French rating

All Locked all ratings

E Exempt program

G General audience

Description

Change PIN

Although the default PIN code (0000) is supplied with the unit, you can set your own PIN code.

Use  to select Change PIN, then press OK.

Press the NUMBER buttons to enter the current 4-digit PIN code.

Press the NUMBER buttons to enter the new 4-digit PIN code.

Enter PIN code again to confirm.

•

Note(s)

Make sure new PIN code and confirm PIN code must be exactly the same. If they are different,

•

the space is cleared for reentering. If you have forgotten your PIN code, enter 07 1 1 to reset the PIN code.

•

Digital audio language

You can select the audio language while your TV is receiving the digital broadcasting.

Use  to select Digital audio language, then press OK.

Digital audio

language

To select the language according to your preference. (It differs depending on the program.)

Mono/Stereo

Cable / NTSC (Analog) TV operation

You can select an audio format while your TV is receiving the analog broadcasting.

Use  to select Mono/Stereo, then press OK.

Use  to select Mono, Stereo or SAP (Second Audio Program), then press OK.

Note(s)

The V-Chip can block non rated programs as per “CEA-608-E sec. L.3”. If the option to block

•

NR, None or E programs are used in Movie ratings lock, TV ratings lock, Canadian English rating or Canadian French rating accordingly “unusual results may occur and the unit may not

receive emergency bulletins or other types of programming”: / Emergency bulletins (Such as EAS messages, weather warnings and others) / Locally originated programming / News / Political / Public service announcements / Religious / Sports / Weather.

Continued on next page.

41 .English

Connect to network

Setup network connection settings in order to use Net TV or network upgrade functions.

The meanings of abbreviations are defined as below.

•

AP SSID

The key entry screen will appear when you select SSID, WEP /

•

others or proxy address.

Network settings

If your router has an easy connect feature, select Easy Connect and press OK.

If your router does not have an easy connect feature, select Manual and press OK.

Pin code

Enter the key of the selected wireless network using , then

•

press OK.

Clear All clear abc ABC 123+/; Cancel OK

: Wireless LAN access point : Wireless network name

Text

_ ? ! - d e f

g h i

p q r s

abc ABC 123+/; Clear

: Clear the entered number or word. : Clear all the entered numbers or words. : Switch to the small letter mode. : Switch to the capital letter mode. : Switch to the numeral and symbol mode. : Shows the cancellation display. : Set the entered number or word.

a b c

j k l

t u v

Easy Connect

asy Connect

. , @ ’

Manual

anua

m n o

w x y z

All clear

Cancel

Wireless setting

Select to use a wireless LAN to connect to the internet by a wireless connection.

Use  to select Wireless, then press OK.

Use  to select the desired setting, then press OK, and follow the on-screen instructions.

Select this setting if your router has an easy

Easy Connect

Scan

Manual entry

* Easy Connect cannot be used when the security protocol is set to WEP.

Change the Access Point’s security mode from WEP to others

312

(recommended).

connect button. Start scanning for wireless networks on the TV after pressing the easy connect button on your router. If connection test fails, refer to the router’s manual for more details.

Search for wireless networks automatically and select the wireless network name (SSID) from the list.

Set up the connection to the wireless LAN Access Point (AP) (e.g. wireless router) manually by entering the wireless network name (SSID).

Wired setting

Select to use an Ethernet cable to connect to the internet by a wired connection. Please purchase shielded Ethernet cables at your local store and use it when you connect to network equipment.

Use  to select Wired, then press OK.

Connection test will start automatically.  p. 44

•

Press  and use  to select Setup, then press OK.

Use  to select Connect to network, then press OK.

Network settings

This TV can be connected to your home network. Select your connection type.

Cancel

Adjust the following items.

Wireless

Wired

312

Continued on next page.

Network selection

Wireless network setting

42 .English

Network settings

Press  and use  to select Setup, then press OK.

Use  to select Network settings, then press OK.

Adjust the following items.

Manual network settings

Use  to select Manual network settings, then press OK.

Manual network settings

Connection test Setting status Home network Wake-on-LAN(DIAL) Net TV

Samba interactive TV settings Reset network settings

Use  to select Network selection, then press OK.

Use  to select the desired setting, then press OK.

Wired

Wireless

Network selection Wireless network setting IP conguration Proxy conguration

If you connect to an Ethernet cable, select Wired to connect to the internet.

If you have a router with easy connect function, select Wireless to connect to the internet.

This menu is displayed only when you set Wireless in Network selection. In order to use a wireless network, you must set up a connection to the AP (e.g. wireless router).

Use  to select Wireless network setting, then press OK.

Auto

Search for wireless networks automatically and select the SSID from the list.

Use  to select Auto, then press OK.

The list of wireless networks will be displayed. Use  to select the appropriate the SSID, then press OK.

Auto

Manually enter your SSID

•

If you select the SSID with , WEP*2 / others Key entry screen will appear. Enter the WEP*2 / others key of the selected wireless

network using , then press OK. If you select the SSID has an easy connect, the easy connect setting

•

screen will appear. Use  to select a setting, then press OK.

Easy Connect

Pin code

Manual

*1 Easy Connect cannot be used when the security protocol is set to

WEP. Change the Access Point’s security mode from WEP to others (recommended).

*2 WEP is not recommended to be used due to its major security flaws.

Change the security protocol on the wireless router to others (recommended) mode.

Confirmation message will appear. Select OK to complete the settings.

Router 1

Router 2 Router 3 Router 4

Select this setting if your router has an easy connect button. Start scanning for wireless networks on the TV after pressing the easy connect button on your router. If connection test fails, try Easy Connect again.*1 If it fails then refer to the router’s manual for more details.

Select this setting if your router has an easy connect feature but does not have an easy connect button. Enter the 8-digit PIN code shown on your TV in the Router settings menu via PC before Connect is selected.

If your wireless network with authentication setting (WEP

*2, others), WEP*2 / others Key entry screen

will appear. Enter the WEP*2 / others key of the selected wireless network using , then

press OK.

Easy Connect Pin code Manual

Note(s)

For a wireless network with authentication setting, key icon appears to the right hand of the

•

SSID. Signal icon shows the strength of the signal.

•

WEP*2 / others key appears as asterisks on the confirmation screen.

•

The wireless LAN supports following specifications.

•

–Wireless standards: IEEE 802.1 1 a/b/g/n/ac –Frequency spectrum: 2.4GHz / 5GHz –Security protocol: WEP

*2 / others

Continued on next page.

IP configuration

43 .English

Manually enter your SSID

Set up the connection to the AP (e.g. wireless router) manually by entering the SSID.

Use  to select Manually enter your SSID, then press OK.

AP (e.g. wireless router) SSID entry screen will appear.

•

Enter the SSID using , then press OK.

Use  to select the authentication setting of the selected wireless network.

For a wireless network with authentication setting, select the

•

authentication setting, according to the security type of the wireless network.

Auto

Manually enter your SSID

None Set the authentication setting to None. WEP Set the authentication setting to WEP

Others Set the authentication setting to Others.

For a wireless network without authentication setting, select None.

•

If you select WEP* or Others, WEP* / others Key entry screen will appear.

•

Enter the WEP* / others key of the selected wireless network using



Confirmation message will appear. Select Yes to complete the settings.

•

* WEP is not recommended to be used due to its major security flaws.

Change the security protocol on the wireless router to others (recommended) mode.

, then press OK.

XXXXXXXXXXXXXX

None

WEP Others

In following cases, select IP configuration to set each setting as necessary.

–When connection test failed with the setting of Connection test. –When instructed by your Internet service provider to make specific

settings in accordance with your network environment.

Use  to select IP configuration, then press OK.

Use  to select a setting, then press OK.

Network selection

Wireless network setting

IP conguration

Proxy conguration

IP setting

mode

IP address

Subnet mask

Default gateway

DNS setting

mode

Primary DNS

Secondary DNS *2, 3

MAC address

*1 Items can be selected only when IP setting mode is set to Manual. *2 Items can be selected only when DNS setting mode is set to

Manual.

Use  or the NUMBER buttons to input numbers. When you use



using the NUMBER buttons, the cursor moves to the next entry field. When you use  to input numbers, then press OK or input the triple digits by using the NUMBER buttons at the rightmost entry field, numbers will be stored and go back to the previous menu.

Manual Sets the IP setting manually.

Manual Sets the DNS setting manually.

to input numbers, then press OK or input the triple digits by

IP setting mode

IP address Subnet mask Default gateway DNS setting mode Primary DNS Secondary DNS MAC address

Auto Sets the IP setting automatically.

*1, 3

Auto Sets the DNS setting automatically.

*2, 3

A set of numbers which are assigned to devices participating in a computer network.

A mask which is used to determine what subnet an IP address belongs to.

IP address of the network device (such as

*1, 3

router) which provides internet access.

A server which handles the name and IP address over the internet.

An address which recognizes the devices connecting to the network. It is also called hardware address.

Auto

Manual

Note(s)

The range of input numbers is between 0 and 255.

•

If you enter a number larger than 255, the number will automatically be 255.

•

The manually entered number will be saved even if you change the setting to Auto.

•

If you want to enter 1 or 2 digit number in one cell, press OK to move on to the next cell.

•

If the entered IP address or the default gateway or primary DNS number is same as the default

•

setting, IP address setting will be set to Auto. (The manually entered number will be saved). When IP address setting is set to Manual, the setting of DNS setting will automatically be Manual

•

and when IP address setting is set to Auto, you can set either Auto or Manual for DNS setting.

Continued on next page.

Proxy configuration

Use  to select Proxy configuration, then press OK.

Use  to select a setting, then press OK.

Network selection Wireless network setting IP conguration

Proxy conguration

Do not use is selected for default settings.

•

If you need to change the proxy setting as instructed by your

•

internet service provider to set the designated proxy address and port, select Use.

Proxy setting

Proxy address

Proxy port

* Items can be selected only when Proxy setting is set to Use.

Note(s)

The range of input numbers for the port number is between 0 and 65535. (If you enter a number

•

larger than 65535, it will be regarded as 65535.) For proxy port, the selected ports may be blocked and not be able to use depending on your

•

network environment. If the proxy address is entered with blank only, proxy server setting will be set to Do not use.

•

Proxy address Proxy port

Do not use Does not use the proxy server.

Use Uses the proxy server.

Selects the number or word by using , then press OK.

Use  or the NUMBER buttons to input numbers.

Do not useProxy setting

Use

44 .English

Connection test

Perform the following steps to test your internet connection after you have connected an Ethernet cable or entered network settings such as IP address, DNS settings, etc. manually.

Use  to select Connection test, then press OK.

Connection test will start automatically and the test result for home

•

network and internet will appear right after the connection test finishes.

“Testing…” is displayed while the connection test is in progress.

•

Home network Internet Description

Pass Pass

Fail -

Pass Fail

If the connection test for internet passes, speed test will start

•

automatically.

Press OK to go to the list on network status confirmation screen.

Note(s)

If the connection test for both home network and internet pass, you are ready to use Net TV or

•

network upgrade functions using the internet without making any additional settings. If the connection test fails, check if the Ethernet cable is connected to this TV properly or if you

•

have entered all the required details for the wireless LAN connection properly.

Connection test is successfully completed.

Connection test for home network failed. Check the connection settings.

Connection test for internet failed. Check the connection settings.

Setting status

You can check the status of network settings.

Use  to select Setting status, then press OK.

Network setting list will be displayed.

•

MAC address of this unit will be displayed in the list.

•

Continued on next page.

45 .English

Home network

You can turn your TV into a Digital Media Renderer (DMR), which can play video, music and photo files stored on certified home media servers connected to your home network.

Use  to select Home network, then press OK.

Use  to select the item you want to adjust, then press OK.

Off Disable DMR.

Renderer

Renderer name

Change the display name of this TV to other devices on the home network.

Enable this unit to play files using DMC.

Wake-on-LAN(DIAL)

You can turn your TV on when you use remote control via IP.

Use  to select Wake-on-LAN(DIAL), then press OK.

Use  to select On or Off, then press OK.

Off To set Wake-on-LAN(DIAL) to off.

On To set Wake-on-LAN(DIAL) to on.

Net TV

Displays the deactivation settings for Net TV, Netflix ESN and Netflix software version.

YouTube deactivation

Displays the deactivation setting for YouTube.

Use  to select Net TV, then press OK.

Use  to select Net TV deactivation, then press OK.

Use  to select YouTube, then press OK.

Use  to select the desired option, then press OK.

Yes Deactivate the connection to YouTube.

No Activate the connection to YouTube.

Netflix ESN

Displays the ESN information.

Use  to select Net TV, then press OK.

Use  to select Netflix ESN, then press OK.

Displays the ESN (Electronic Serial Number) to get any services

•

from Netflix.

Netflix software version

Displays the Netflix version.

Use  to select Net TV, then press OK.

Use  to select Netflix software version, then press OK.

Netflix deactivation

Displays the deactivation setting for Netflix.

Use  to select Net TV, then press OK.

Use  to select Net TV deactivation, then press OK.

Use  to select Netflix, then press OK.

Use  to select the desired option, then press OK.

Yes Deactivate the connection to Netflix.

No Activate the connection to Netflix.

VUDU deactivation

Displays the deactivation setting for VUDU.

Use  to select Net TV, then press OK.

Use  to select Net TV deactivation, then press OK.

Use  to select VUDU, then press OK.

Use  to select the desired option, then press OK.

Yes Deactivate the connection to VUDU.

No Activate the connection to VUDU.

Samba interactive TV settings

Displays the setting for Samba TV. To learn more about Samba TV, please visit https://www.samba.tv/

Use  to select Samba interactive TV settings, then press OK.

Use  to select the desired option, then press OK.

Note(s)

Samba interactive TV settings item is displayed only when the country setting is USA.

•

Reset network settings

You can reset the status of network settings.

Use  to select Reset network settings, then press OK.

Use  to select the desired option, then press OK.

Continued on next page.

46 .English

Update software

Philips continuously tries to improve its products and we strongly recommend that you upgrade the TV software when upgrades are available.

New software can be downloaded from our website at www.philips.com/support using the model number of your TV to find information.

You can update the software through these methods:

Update with USB memory stick

•

Update from digital broadcast Update notification  p. 47

•

This section describes how to upgrade the software by using USB memory stick.

Preparing for the software upgrade

You require the following equipment:

–A PC with web browsing capability –An archive utility that supports the ZIP-format

(e.g. WinZip for Windows or StuffIt for Mac OS)

–An empty clean formatted USB memory stick

Note(s)

Only FAT / DOS-formatted portable memory is supported.

•

Use only software upgrades that can be found on the Philips web site.

•

Warning

When the software upgrade is running, don’t press any buttons.

•

Do not remove the USB memory stick during the software upgrade.

•

If an error occurs during the upgrade, retry the procedure or for further assistance, please contact

•

call center.

Downloading the software

Find information and software related to your TV and download the latest software upgrade file to your PC.

Prepare a blank USB memory stick for software update. Access www.philips.com/support and download the latest version software to a blank USB memory stick using a PC by following the directions described on the website.

Use a blank USB memory stick, download the software on your PC and

•

write the software in the root directory of the USB memory stick. For more details on how to download the software, please refer to the

•

website.

USB upgrade

You can upgrade the software by using USB memory stick.

Connect your USB memory stick with the upgrade file to the USB

terminal on the side of your TV.

Press  and use  to select Setup, then press OK.

Use  to select Update software, then press OK.

Use  to select USB, then press OK.

Use  to select the desired update file, then press OK.

Use  to select Yes, then press OK.

Read the on-screen instructions and confirm that you want to

•

continue with the installation.

Software update is in progress. Please wait. Do not remove the USB storage device or turn the TV o while upgrade is in progress.

When the software upgrade is completed, press  to set the unit into standby mode, then remove the USB memory stick.

Unplug the AC power cord for a few seconds from AC outlet and plug

it again.

Press  again to turn the unit on.

The TV starts up with the new software.

•

For further assistance, please contact call center.

•

Continued on next page.

47 .English

Network updates

You can update the software by connecting the unit to the internet.

Press  and use  to select Setup, then press OK.

Use  to select Update software, then press OK.

Use  to select Network, then press OK.

Use  to select Yes, then press OK.

This unit will then start checking for the latest FirmWare (software)

•

version.

Confirmation message will appear.

Use  to select Yes, then press OK.

The unit will start downloading the latest FirmWare (software)

•

version. The unit will start updating the FirmWare (software) version.

•

It may take a while to complete the updating.

•

When the software update is complete, press  to make sure the unit goes to standby mode.

Unplug the AC power cord for a few seconds from AC outlet and plug

it again.

Press  again to turn the unit on.

The TV starts up with the new software.

•

For further assistance, please contact call center.

Note(s)

In order to update software via the Internet, you must connect the unit to the Internet and set

•

up necessary settings.

Connect to network  p. 41 Network settings  p. 42

Please do not unplug the AC power cord or Ethernet cable while executing the Network

•

updates. All settings will remain the same even if you update the software version.

•

The version of net service will also be updated if newer version of net service is available when

•

updating the firmware. When you start up the TV or a net service after executing the software update, a message may

•

appear on the screen prompting for software update again. In this case, please select Update to start USB update or network update. For further assistance, please contact call center.

Software settings

Software

Press  and use  to select Setup, then press OK.

Use  to select Software settings, then press OK.

Use  to select Software, then press OK.

Checking your current software version number

Use  to select Software information, then press OK.

The version and a description of the current software is displayed.

•

Update notification

You can download the latest software through the air and update this unit automatically while the unit is in standby mode.

Use  to select Update notification, then press OK.

Use  to select the desired option, then press OK.

Off Disable auto-update for latest software.

License

Displays the licenses of open source software used in this unit.

Use  to select License, then press OK.

Licenses of open source software used in this unit are displayed.

•

Digital rights management

This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the appropriate license(s) from Microsoft.

Use  to select Digital rights management, then press OK.

Digital rights management is displayed.

•

A message will appear if there is the latest software on the network server.

Continued on next page.

PHILIPS_Smart_TV

If you want to manage connected device history, please press "OPTIONS".

If you want to exit, please press "BACK" key.

Your TV name

The TV is now ready to accept a connection from your source device.

48 .English

Wireless Screencasting

You can wirelessly cast or mirror the screen of your Smartphone, Tablet or

PC to the TV directly using Wireless Screencasting.

Using Wireless Screencasting

Pre

ss Q and use J K to select Wireless Screencasting, then press

OK.

Wireless Screencasting mode screen appears.

•

ivate Wireless Screencasting feature on your device.

Act

For the operation of your device, please check the instruction

•

manual of the device. Select Your TV name on your device if needed.

•

If PIN code is required on your device, please enter the 8-digit code

•

appearing in the left-hand side of the TV screen.

Once connected, the screen of your device will appear on your TV

screen.

Press T INFO to display your device name at the bottom of TV

•

screen.

Press K t or OK to pause playback. Press K t or OK again to resume

•

playback.

Using Wireless Screencasting device list

In Wireless Sc

Pre on the TV screen.

•

reencasting device list, you can find the connected devices.

ss U OPTIONS on remote when Wireless Screencasting mode is

Only the connected device names are listed.

It will be sorted from newest connection to oldest connection. A maximum of 64 connections can be recognized.

If you would like to delete a listed connection, press H I to select the device name, then press OK first. Once the confirmation message appears, please use J K to select Yes, then press OK.

View photos, play music and watch videos usi

ng home network

On your TV you can play video, music and photo files stored on home net

work certified home media servers connected to your home network.

In order to use this feature, you must connect this unit to the internet.

It is recommended that files to be played back in this unit are recorded under the following specifications:

Picture (JPEG / Progressive JPEG)

JPEG Upper limit 4000x4000 pixels

Progressive JPEG Upper limit 1024x768 pixels

Music (MP3 / WAV / AAC)

MP3

WAV

AAC

Video (MPEG / VOB / AVI / MP4)

Maximum video

Extension .avi

Video cod

Audio codec

Dolby Digital YES YES YES YES YES YES

MPEG1/2 audio

er1/2/3

lay

LPCM YES YES YES YES YES YES

AAC-LC YES YES YES YES YES YES

Note(s)

aximum of 1,023 folders or files can be recognized.

A m

•

For the home server list, maximum of 16 servers can be displayed.

•

The 10th and deeper hierarchies cannot be displayed.

•

Unplayable files in the home server will not be displayed in the file list.

•

For some files, playback is not available even if displayed in the file list.

•

In order to play back the contents in home servers, the player and the servers must be connected

•

to the same access point.

Compatibility and available playback function may differ depending on the home server.

•

Video files with unsupported audio format will be skipped.

•

The quality of the playback picture or audio differs depending on your network condition

•

Sampling frequency 16 kHz - 48 kHz

Constant bit rate 8 kbps - 320 kbps

Sampling frequency 8 kHz - 48 kHz

Constant bit rate 64 kbps - 1.5 Mbps

Sampling frequency 8 kHz - 48 kHz

Constant bit rate -

H.264, H.265/HEVC: 3840x2160@30fps,

MPEG1,

MPEG2, MPEG4,

H.264

YES YES YES YES NO YES

G: 1920x1080@60fps

MPE

.ts,

.trp,

.tp

MPEG1, MPEG2,

H.264,

H.265/

HEVC

.mpg,

.mp

MPEG1, MPEG2, MPEG4

.vob .mp4 .mkv

MPEG1, MPEG2

MPEG1, MPEG2, MPEG4,

H.264,

H.265/

HEVC

MPEG1, MPEG2, MPEG4,

H.264,

H.265/

HEVC

Note(s)

ai Corporation Inc. does not warrant Wireless Screencasting compatibility with all source

Fun devices such as smartphones, tablets, laptops, etc. due to large variability in hardware, firmware, drivers, software and implementation of wireless casting applications on these source devices. Although Funai Corporation Inc. will strive to enhance compatibility and performance across a range of source devices, Funai Corporation Inc. does not warrant compatibility with specific source devices.

Continued on next page.

49 .English

Before using home network

Follow the procedure below before using home network.

Connect this unit to the internet.

Connecting the TV to the internet using an Ethernet cable  p. 17 or Connecting the TV to the internet using a wireless LAN  p. 18

Broadband internet connection of 8Mbps or faster is required.

•

Set up the necessary network connection settings.

Connect to network  p. 41

Using home network

Start home network media servers in your home network.

For details, refer to the instruction book of the home network

•

certified device.

Press  on the remote control.

Use  to select Home Network.

This unit will start loading the home server list.

•

After loading, home server list will appear. Select a home server you

want to access, then press OK.

Guide to home network

Server 1

Server 2

Server 3

Audio Photos Video Folder

Current folder

Highway Blues

Video10 Blue hills

Audio Photos Video Folder Highway Blues Video10 Blue hills

Highway Blues Artist 00:05:28

View your pictures using home network

Press  to select a file or a folder.

Press OK or . to start a slide show of the files.

Press OK or . to pause the slide show.

•

The . icon appears. Press 0 or / to move between images.

•

Press BACK or . to stop the slide show.

•

Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

toggle *1

Repeat

Slide time

Transitions *2

picture *2

*1 Voice guide toggle is available in slide show and pause mode. *2 You can set Repeat, Slide time, Transitions and Auto picture when

*3 You can set Rotate and Zoom when slide show is in pause mode.

Auto

Rotate

Zoom

images are in slide show.

Off Sets Voice guide to off.

On Sets Voice guide to on.

Off Sets repeat playback to off.

One Sets repeat playback for a selected image file.

All

Short Switches to the next image in 5 seconds.

Medium Switches to the next image in 10 seconds.

Long Switches to the next image in 15 seconds. None No effect when switching images.

Dissolve Overlaps the next image on the current image.

Wipe right Pushes the current image out from left.

Wipe left Pushes the current image out from right.

Wipe up Pushes the current image out from bottom.

Wipe down Pushes the current image out from top.

Box in

Box out

Selects the picture mode according to your preference. (Standard, Natural, Vivid, Sports, Movie, Game, Energy saving and Internet video)

0 Displays an image in its original direction.

90 Rotates an image 90 degrees clockwise. 180 Rotates an image 180 degrees clockwise. 270 Rotates an image 270 degrees clockwise.

1X Displays an image in its original size. 2X Magnifies a current image by 2 times. 4X Magnifies a current image by 4 times.

Sets repeat playback for all image files in the current folder.

The next image comes to the center from the outside.

The next image goes to the outside from the center.

Home server list



Folder / media icon



Group (folder) / file list






Current file info



Continued on next page.

50 .English

Listen to music using home network

Press  to select a file or a folder.

Press OK or . to play the selected files.

Press OK or . to pause, press OK or . again to resume.

•

Press / to skip up the next file.

•

Press 0 to skip down the previous file.

•

Press . to stop playback.

•

Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

toggle

Repeat

Shuffle

TV Speakers

Auto sound

Voice guide toggle is available in slide show and pause mode.

Off Sets Voice guide to off.

On Sets Voice guide to on.

Off Sets repeat playback to off.

One

All

Off Sets shuffle playback to Off.

Off

Speakers EasyLink

Selects the sound mode according to your preference. (Standard, Vivid, Sports, Movie, Music and News)

Sets repeat playback for a selected music file.

Sets repeat playback for all music files in the current folder.

Sets shuffle playback for all music files in the current folder.

The sound will not be output from the unit's speakers.

The sound will be output from the unit's speakers.

You can control audio output from your connected EasyLink compliant devices with VOL + / – by using this unit's remote control.

Watch videos using home network

Press  to select a file or a folder.

Press OK or . to play the selected files.

Press OK or . to pause, press OK or . again to resume.

•

Press / to fast-forward search.

•

Press 0 to fast-backward search.

•

Press . to stop playback.

•

Press . to resume from the point at which playback was stopped.

•

Press OK to play from the beginning of the file at which playback was stopped.

Press CH + to play the next file.

•

Press CH - to play the current file at the beginning.

•

Press CH - twice within 5 seconds to play the previous file. Press OPTIONS to display the optional menu, then use  to

•

select the desired item.

Voice guide

toggle

Repeat

TV speakers

Auto picture

Auto sound

Voice guide toggle is available in slide show and pause mode.

Off Sets Voice guide to off.

On Sets Voice guide to on.

Off Sets repeat playback to off.

One

All

Off

Speakers

EasyLink

Selects the picture mode according to your preference. (Standard, Natural, Vivid, Sports, Movie, Game, Energy saving and Internet video)

Selects the sound mode according to your preference. (Standard, Vivid, Sports, Movie, Music and News)

Sets repeat playback for a selected video file.

Sets repeat playback for all video files in the current folder.

The sound will not be output from the unit's speakers.

The sound will be output from the unit's speakers.

You can control audio output from your connected EasyLink compliant devices with VOL + / – by using this unit's remote control.

Note(s)

The resume information will be kept even when the unit is Turned off.

•

If you play another file while the previously viewed file is being resumed, the resume information

•

of the previously viewed file will be deleted. The file or the folder in resume stop mode will be highlighted in gray on List or Thumbnails.

•

Continued on next page.

51 .English

Net TV

Net TV offers internet services for your TV. Use the TV remote control to browse the Net TV pages. You can play movies, listen to music and much more, all from your TV screen.

–Because Net TV is an online system, it can be modified over time to

better serve its purpose.

– Some Net TV services can be added, changed or stopped after some

time.

–You cannot download and save files or install plug-ins.

Before using Net TV

Follow the procedure below before using Net TV.

Connect this unit to the internet.

Set up the necessary network connection settings.

(Refer to Connect to network  p. 41)

Using Net TV

Press NETTV.

Net TV screen will appear, then use  to select service icon.

•

For the first time only, Terms of Use screen will appear. After

•

confirming the content, use  to select Agree, then press OK.

Guide to Net TV menu screen

Net TV start screen

My Apps functions

Remove App

Use  to select the desired App, then press OPTIONS.

Use  to select Remove App, then press OK.

The selected App will be removed from My Apps list.

•

Move App

Use  to select the desired App, then press OPTIONS.

Use  to select Move App, then press OK.

The selected App icon will be smaller.

•

Use  to the point you want to place, then press OK.

Guide to App Gallery

App Gallery

Category menu: List of category menu.



Icon list: Displays unregistered net service icons on My



Page guide: Displays the order of pages. The current page



All

Apps list.

will be highlighted.

 Now on TV

 Featured Apps  Selected Apps  Country  Terms of Use Option

Featured AppsNow on TV

Terms of UseOption

Country: USA

: Displays the image of the input under present

tuning.

: Displays fixed net service icons. : Displays movable net service icons. : Selects what country you live in. : Displays a copy of net service. : Remove or move App.

Press NETTV, then use  to select App Gallery.

Use  to select the desired App in My Apps list, then press OK.

You can also choose from Category menu. Use  to select

•

All, then use OK to select the desired category. If you select Add, the selected App icon will be placed at the end

•

of My Apps list. If you select Add and move, the selected App icon will be smaller

•

and use  to the point you want to place, then press OK.

Even if you press BACK to cancel this function, the selected App icon will be placed at the end of My Apps list.

Information on network services

For detailed information on 3rd party internet services, please visit the service providers website:

Netflix

VUDU

CinemaNow

For additional help, refer to the Frequently Asked Questions FAQs at www.philips.com/support. Select TV and enter your model number.

: http://www.netflix.com

: http://www.vudu.com

: http://www.cinemanow.com

Continued on next page.

52 .English

Pandora operations

With this unit, you can instantly listen to personalized radio stations streamed over the internet from Pandora.

To learn more about Pandora, please visit www.pandora.com

Activating Pandora

In order to listen to internet radio streamed from Pandora via the internet, you must create a Pandora account and activate this unit.

Press NETTV, then use  to select PANDORA.

Use  to select I am new to Pandora., then press OK.

Note the activation code and website address displayed on the TV

screen.

On your PC, visit the website address noted at step 4.

Follow directions on the website to create your account.

On this unit, select Go Back and press OK to complete activation.

Adding Pandora user accounts

You can add the Pandora user account.

Press NETTV, then use  to select PANDORA.

Use  to select I have a Pandora account., then press OK.

Enter your e-mail address, then press OK while OK is selected.

Enter a password, then press OK while OK is selected.

4 5

Use  to select Sign In, then press OK.

Your account is added to the user list and player screen appears

•

on the TV screen.

Note(s)

Pandora is available only in the United States.

•

You can add up to 5 accounts.

•

Creating a new station

By entering your favorite artists or tracks, Pandora selects music and creates a new station for you on the basis of the entered information.

On the station list screen, Use  to select New Station, then press OK.

Enter a name of your favorite artist or tracks, then press OK while OK

is selected.

Search result will appear on the right side of the TV screen.

•

If the selection screen with the result type appears, use  to select

•

the desired type, then press OK.

Use  to select the desired station, then press OK to start the playback.

 / .

 .

 

Note(s)

On the Tool Menu, you can delete or rename the currently selected station.

•

Resumes the playback / pause the playback. Resumes the playback.

Pauses the playback. Skips to the next track.

Guide to the player screen

On the player screen, you can set various options to the currently playing track.

American Oldies Radio

ABC

XXXXX

4:52 0:00

Artist name : Displays artist name.



Album name : Displays album name.

 





 / .

: Give thumbs up to the currently playing track.

Pandora will play tracks similar to the track.

: Give thumbs down to the currently playing

track. Pandora will skip and will not play the track.

: Resumes the playback / pause the playback.

: Skips to the next track. : Displays the Tool menu.

cbadefg

5 Useful tips

FAQ

Question Answer

My remote control does not work. What should I do?

How come the initial setup appears every time I turn on this unit?

Why can I not watch some RF signal TV programs?

How come there is no image from the connected external devices?

When I enter a channel number, why does it change automatically?

Why are captions not displayed entirely? Or why are captions delayed behind the dialog?

How can I set the clock?

My PIN code no longer works, how can I change the child lock setting?

When I start up the TV or a net service, a message appears on the screen prompting for software update again.

53 .English

Check the antenna or cable connection to the main unit.

•

Check the batteries on the remote control.

•

Check if there is an obstacle between the infrared sensor window and the remote control.

•

Test the IR signal output use IR signal check.  p. 56

•

If okay, then possible infrared sensor trouble. Aim the remote control directly at the infrared sensor window on the front of the unit.

•

Reduce the distance to the unit.

•

Re-insert or replace the AAA batteries with their polarities (+/–) as indicated on the remote control battery area.

•

When there is an infrared-equipped device such as PC near this unit, it may interrupt the remote control signal on this unit.

•

Move the infrared-equipped device away from this unit, change the angle of the device's infrared sensor or turn off the infrared communication function.

Make sure to complete the initial setup before the unit goes into standby mode.

•

Autoprogram must be completed when you set up the unit for the first time or move it to a location where previously

•

unavailable channels are broadcast. Make sure auto programming has been completed.  p. 38

•

The selected channel may not be broadcasting.

•

When Auto programming is interrupted and not completed, some channels will not be received. Make sure to complete

•

the Autoprogram.  p. 38 The selected channel cannot be viewed by the Child lock setting.  p. 39

•

The unit requires some kind of antenna input. An indoor antenna (Digital or VHF / UHF), an external antenna (Digital or

•

VHF / UHF) or an RF coaxial cable from your wall cable or set-top box needs to be plugged into the unit. Check if the correct input mode is selected by pressing SOURCE.  p. 23

•

Check the antenna, cable or other input connection to the unit.

•

When using the component video connection check that the green (Y), blue (Pb/Cb) and red (Pr/Cr) connectors are

•

connected to their corresponding colored jacks on the unit. Many digital channels have alternate channel numbers. The unit changes the numbers automatically to the ones signifying

•

the broadcasting station's channel number. These basic numbers used for the previous analog broadcasts. (e.g., input digital ch# 30 automatically changes to digital ch# 8.1)

Closed captions that are delayed a few seconds behind the actual dialog are common for live broadcasts. Most captioning

•

production companies can display a dialog to maximum of 220 words per minute. If a dialog exceeds that rate, selective editing is used to insure that the closed captions remain up-to date with the current TV screen dialog.

There is no clock function on this unit.

•

Although the default PIN code (0000) is supplied with the unit, the PIN code will be required once you set a PIN code in

•

Child lock.  p. 39 When you forget your PIN code, enter 07 1 1 in Change PIN to reset the PIN code.  p. 40

When you start up the TV or a net service after executing the software update, a message may appear on the screen prompting for software

•

update again. In this case, please select Update to start USB update or network update.  p. 46

Continued on next page.

Troubleshooting tips

Please check the following Troubleshooting tips and all connections once before calling for service.

If the unit does not perform properly when operated as instructed in this manual,

Power

No power

Make sure the AC power cord is plugged in.

•

Make sure that the AC outlet supplies the proper voltage, plug another electrical

•

appliance into the AC outlet to ensure that the AC outlet operates normally. If a power failure occurs, unplug the AC power cord for 1 minute to allow the unit

•

to reset itself.

Remote

Control buttons do not work.

Do NOT press more than one button at the same time.

•

Ensure that no buttons on the remote control are depressed and move freely.

•

Universal remote control does not work properly.

Refer to the User manual of the universal remote control for the Philips code.

•


Power is on but no screen image.

Check whether the connection for the antenna, cable or set-top box is

•

connected correctly. Check whether all the cables to the unit are connected to the correct output jack on

•

your separate device like Blu-ray disc / DVD recorder. Make sure that the selected input mode is connected to the working input jack.

•

Check if your computer is NOT in sleep mode when the input mode on this unit

•

is in PC mode. Tap any key on the computer keyboard to wake it up. Check if the correct input mode is selected by pressing SOURCE.

•

No color

View other TV channels. The problem might be limited to the broadcasting

•

station. Adjust Color in Picture settings.  p. 31

•

Picture poor

Adjust Contrast and Brightness in Picture settings.  p. 31

•

For the best picture quality, watch “High Definition” wide screen programs. If the

•

HD content is not available, watch “Standard Definition” programs instead.

You see pixelation on the screen.

When the capabilities of the unit exceed the capabilities of the digital

•

broadcasting, the signal will be increased to match the capabilities of the display on the unit. This may cause pixelation, noise or trash.

Unusual picture appears and the TV does not operate.

Press the power button first. If it does not solve, follow the procedure below.

•

Press the buttons on the remote control in the order shown below.





Unplug the AC power cord, then wait for 1 minute, and then plug it in again.



Sound

No sound is heard when using the HDMI digital connection.

Some HDMI cables and devices may not be compatible with the TV due to

•

different HDMI specifications.

No sound, distorted sound or incorrect audio sound is heard when using the HDMI-DVI connections.

Make sure that the analog audio signals from the HDMI-DVI device are

•

connected to the analog audio input L/R jacks. When using Component analog video or Composite analog video, make sure

•

that the analog audio (L/R) connectors are mounted into the audio (L/R) input jacks.

Sound intermittent or no sound.

Check if the audio cable is connected into the unit correctly.

•

You switch to a different input and the volume changes.

This unit will memorize the volume level from the last time you adjusted it.

•

If the volume of the sound from another device is higher or lower, then the

•

loudness will change. Make sure Auto volume leveling is set to On.  p. 33

•

Picture & Sound

No sound with distorted picture occurs when using the HDMI digital connection.

Some HDMI cables and devices may not be compatible with the TV due to

•

different HDMI specifications.

No picture or sound

Check if the power is on.

•

Check whether all the cables to the unit are connected to the correct output jack on

•

your separate device like Blu-ray disc / DVD recorder. View other TV channels. The problem might be limited to the broadcasting station

•

or weak signal strength. Unplug the AC power cord and wait for about 1 minute, then plug the AC power

•

cord and turn on the unit again. Check whether the connection of the antenna or cable / satellite set-top box is

•

connected correctly. Make sure that the selected input mode is connected to the working input jack.

•

Check if your computer is NOT in sleep mode when the input mode of this unit

•

is in PC mode. Tap any key on the keyboard to wake up your computer. Make sure that the sound is not muted. Press  so that the volume bar and

•

current volume level will appear on the TV screen. Make sure that the volume is NOT set to 0 or . If so, use VOL + / – to adjust to

•

the desired volume. Make sure that the headphone is NOT connected to the headphone audio

•

output jack. Make sure that the TV speakers is NOT set to Off.

•

If there are issues with picture/color and/or sound when connecting an external

•

device using the HDMI port, please try switching the HDMI mode. (Refer to HDMI

mode  p. 35) Adjusted Picture or Sound settings are not effective every time the unit is turned on.

You must set Home in Location.  p. 35 (Otherwise, the settings you adjusted

•

will not be memorized after the unit goes into standby mode.)

You see a distorted picture or hear an unusual sound. (Analog TV - NTSC signal)

You may be getting NTSC (Analog) TV signal (not HDTV signal) interference from

•

electrical appliances, automobiles, motorcycles or fluorescent lights.

Try moving the unit to another location to see if this is the cause of the problem.

•

Ghosts, lines or streaks in picture.

Electrical interference from nearby appliances may affect picture quality.

•

View other TV channels. The problem might be limited to the broadcasting station

•

or weak signal strength.

Picture poor, sound intermittent or no sound

View other TV channels. The problem might be limited to the broadcasting station

•

or weak signal strength.

Child and rating lock

Forgotten PIN code.

Enter “07 1 1” to clear your password.

•

Screen

You switch to a different input and the screen size changes.

This unit will memorize the viewing mode from the last time you used the

•

particular input modes.

The display image does not cover the entire screen.

If you are using the unit as a PC monitor, make sure that Horizontal position and

•

Vertical position in Picture are set correctly.  p. 31

If you are watching TV or using the Composite video, Component video or HDMI

•

with 480i input, press FORMAT repeatedly to switch to various screen

modes.

Different color marks on the TV screen

View other TV channels. The problem might be limited to the broadcasting

•

station, missing data or pixelation due to weak signal strength.

54 .English

Continued on next page.

55 .English

Closed captions

Closed captions are displayed as a white box. No closed captions are displayed in the closed captions-supported program.

Interference from buildings or weather conditions may cause closed captions to

•

be incomplete if watching analog TV signals. Broadcasting station may shorten the program to insert advertisements.

•

The closed caption decoder cannot read the information of the shortened program.

Black box is displayed on the TV screen.

The text mode is selected for caption. Select CC-1, CC-2, CC-3 or CC-4.

•

Software update

A message appears on the screen prompting for software update again.

When you start up the TV or a net service after executing the software update, a

•

message may appear on the screen prompting for software update again. In this case, please select Update to start USB update or network update.  p. 46

Network

Cannot connect to the network.

Check if the Ethernet cable connection is properly made. Turn on the broadband

•

router and/or modem. Check the network settings.

•

Check if the broadband router and/or modem is correctly connected.

•

Sometimes video quality is poor when using the wireless LAN.

The wireless network connection quality varies depending on the distance or

•

obstacles (e.g. wall, basement, 2nd floor) between the TV wireless LAN adapter and the wireless router (access point), from other wireless networks, and brand and type of the wireless router (access point). When using the wireless LAN of the TV, it is suggested to place the wireless router as close as possible to the television.

Wireless LAN connection fails or wireless connection is poor.

Check the installation location of the TV and wireless router (access point). Signal

•

quality may be affected for the following reasons.

–

Interference of other wireless devices, microwaves, fluorescent lights, etc., are placed nearby.

–

There are floors or walls between the wireless router and TV.

–

If the problems continue even after checking the above, try making a wired LAN connection.

Cannot use the wireless connection.

Check if the wireless LAN Access Point (AP) (e.g. wireless router) is oriented

•

properly or not placed too close between them. Once you have activated the wireless connection please wait 30 seconds for the

•

connection to be established after turning on the unit, before trying to access network features such as Net TV.

Cannot use Netflix feature.

Check if the network connection is properly made.

•

Visit http://www.netflix.com on your PC and become a Netflix member.

•

Some network services may not be available in your country.

•

Cannot add movies or TV episodes to the Instant Queue.

Visit www.netflix.com on your PC.

•

Even though the speed of the internet connection improves during playback, the picture quality of Netflix streaming movie does not improve.

The picture quality does not change during playback. It differs depending on the

•

speed of internet connection at the time of loading.

Cannot use VUDU feature.

VUDU is available only in the United States and Mexico.

•

Check if the network connection is properly made.

•

Cannot rent or buy movies / TV episodes on VUDU.

You need to activate the VUDU account. For detailed information, please visit

•

the service providers website at http://www.vudu.com Log into your account at http://my.vudu.com and check your payment

•

information.

The picture quality of streaming movie (Netflix, VUDU or CinemaNow) is poor.

Check the speed of your internet connection. You need speeds of at least 8 Mbps

•

to this player for high quality uninterrupted playback.

Streaming movie (Netflix, VUDU or CinemaNow) often stops or starts buffering during playback.

Contact your internet service provider to troubleshoot your internet connection

•

for speed and line quality. Consistent line quality and speed are very important

for internet video playback.

Cannot connect to the network while my PC is connected to the network.

Check the content of your internet service contract to see if your internet service

•

provider prevents multiple terminals connecting at the same time.

Cannot use Easy Connect to connect to the access point.

Connect the unit to the access point using scan or manual entry mode. If the

•

access point’s security mode is set to WEP*, change the setting to others

(recommended), then try Easy connect again. (For access point configuration,

please consult its user manual or manufacturer.)

* WEP is not recommended to be used due to its major security flaws. Change the security

protocol on the wireless router to others (recommended) mode.

Folder or files stored on home network media server are not displayed in the file list or cannot be played back.

Check the setting on your home media server. (Refer to the user manual of the

•

home media server.)

Check the network connection and settings.

•

Cannot use Pandora feature.

Check if the network connection is properly made.

•

Pandora is available only in the United States.

•

You must create a Pandora account and activate this unit.

•

Activating Pandora  p. 52 Wireless Screencasting

Connectivity with all Wireless Screencasting compatible devices is not

•

guaranteed.

Devices that do not comply with Wireless Screencasting standards may have

•

compatibility issues.

Note(s)

The LCD screen is manufactured to provide many years of useful life.

•

Occasionally a few non active pixels may appear as a fixed point of blue, green

or red.

This is not to be considered a defect in the LCD screen.

Some functions are not available in specific modes, but this is not a malfunction.

•

Read the description in this manual for more details on correct operations.

For additional troubleshooting, refer to the Frequently Asked Questions or FAQs on www.philips.com/support.

6 Information

56 .English

Glossary

Analog TV (NTSC)

Acronym that stands for National Television Systems Committee and the name of analog broadcasting standards. Off the air analog TV signals are no longer being sent by major broadcasting stations in the USA.

ARC (Audio Return Channel) (HDMI 2 only)

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height).

CEC (Consumer Electronics Control)

This allows you to operate the linked functions between our brand devices with CEC feature and this unit. We do not guarantee 100% interoperability with other brands of CEC compliant devices.

Component video

This is a Video signal format that conveys each of 3 principal colors of light (red, blue and green) through different signal lines. This allows the viewers to experience picture colors as original as it is. There are several signal formats, including Y / Pb / Pr and Y / Cb / Cr.

Dolby Digital

The system developed by Dolby Laboratories to compress digital sound. It offers stereo sound (2ch) or multi-channel audio.

DTV (ATSC)

Abbreviation that stands for Advanced Television Systems Committee and the name of the digital broadcasting standards.

E-sticker

E-sticker is showing set features, technical information, etc on this TV set that is displayed on the TV screen mainly used by TV retailers. Previously the information was on a printed sticker that was put on the display.

HDMI (High-Definition Multimedia Interface)

Interface that supports all uncompressed, digital audio / video formats including set-top box, Blu-ray / DVD recorder or digital television, over a single cable.

HDR

HDR stands for High Dynamic Range. By using additional data encoded with the source signal, HDR capable products offer greater contrast through an expansion of the range of the image’s color luminance. The source, cable and display must all support HDR.

HDTV (High-Definition TV)

Ultimate digital format that produces high resolution and high picture quality.

PIN code

A stored 4-digit number that allows access to parental control features.

SAP (Secondary Audio Program)

Second-audio channel delivered separately from the Main-audio channel. This audio channel is used as an alternate in bilingual broadcasting.

SDTV (Standard Definition TV)

Standard digital format that is similar to the analog TV picture quality.

Sonic Emotion Premium

Sonic Emotion Premium fills your surroundings with the right ambience, clarifies voice, and details the sound stage, making your experience more immersive and enjoyable.

Maintenance

Cleaning

Clean the front panel and other exterior surfaces of the unit with a soft

•

microfiber cloth or lens brush. Before cleaning the panel, disconnect the AC power cord.

Never use a solvent or alcohol. Do not spray insecticide liquid near the

•

unit. Such chemicals may cause damage and discoloration to the exposed surfaces.

Do not spray any liquids on the screen or other exterior surfaces of this

•

unit. If liquids enter the unit, they could cause shorts, electric shocks or fire damage.

Servicing

Should your unit become inoperative, do not try to correct the problem yourself. There are no user serviceable parts inside. Call our toll free customer support line found on the cover of this User manual to locate an authorized service center.

IR signal check

If the remote control is not working properly, you can use a digital or cell phone camera to see if it is sending out an infrared signal.

e.g.) With a digital camera: Point the digital camera towards the remote control infrared diode at the front of the remote control. Press and hold any key on the remote control and look at the camera display. If an infrared pulsating light appears on the display, the remote control is sending out an IR signal.

or dual camera cell phones may have an IR filter in one of the camera's and both will not display the IR signal.

Note: Some cameras may have an IR filter

7 Specifications

57 .English

Model #

Picture Type Diagonal screen size / Aspect ratio Viewing angles Built-in digital / analog tuner Sound Mono / Stereo Power output (RMS watts) Equalizer Ease of use

SD (4:3 source)

Picture format HD

(16:9 source) UHD

Photo slide show Music playback Video playback Channel

Channel coverage

CATV (Analog NTSC)

Tuning system

Channel access

Connectivity Component video input

(Y/Pb/Pr) Composite video input

(Shared Y green terminal with component video)

HDMI input

Analog audio L/R input PC input USB Wireless LAN Ethernet port

Digital audio output

Headphone output

Power Power requirements Temperature Operating temperature

65PFL5602 55PFL5602 50PFL5602 43PFL5602

UHD (Ultra HD) (3840 x 2160 pixels 60Hz) 65”/ 16:9 178° (V) by 178° (H) ATSC (digital) / NTSC (analog)

Mono, Stereo, Sonic Emotion Premium 10W x 2 5 Band

Automatic / Super zoom / 4:3 / Movie expand 14:9 / Movie expand 16:9 / Wide screen / Manual Zoom

Automatic / 4:3 / Wide screen / Full / Unscaled / Manual Zoom

Full / Unscaled / Manual Zoom

JPEG, Progressive JPEG MP3, WAV, AAC MPEG1, MPEG2, H.264, MPEG4, H.265/HEVC

Over-the-Air DTV (ATSC)

Over-the-Air Analog (NTSC)

2∼13, A∼W W+1∼W+94 (Analog W+1∼W+84), A-5∼A-1, 5A

Channel frequency synthesized tuning system Direct access number keyboard, Programmable scan, Channel +(up) / -(down) and

PREV. CH (Previous channel)

1 Supporting video signals : 480i/p, 720p, 1080i/p @60Hz

3 (selectable HDMI modes) Supporting HDMI video signals : 480i/p, 720p, 1080i @60Hz, 1080p, 2160p @24/30/60Hz Supporting HDMI digital audio signals : LPCM, AC3, DD+ Supporting PC-input video signal up to 4096 x 2160 1 (L audio / R audio) Via HDMI and HDMI-DVI + Analog audio L/R 1 Supporting wireless standards : IEEE 802.1 1a/b/g/n/ac (2.4GHz/5GHz) 1 1

Supporting Dolby Audio (Dolby Digital and Dolby Digital Plus) 1

1/8 inch (3.5mm)

120V∼ +/- 10%, 60Hz +/- 0.5%

41 °F (5 °C) to 104 °F (40 °C)

54.6”/ 16:9 49.5”/ 16:9 43”/ 16:9

8W x 2

: VHF: 2∼13

UHF: 14∼69 (Each channel may have e.g. 2.1∼2.9, 3.1∼3.9, etc)

: VHF: 2∼13

UHF: 14∼69

Specifications are subject to change without prior notice.

•

8 Warranty

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

Funai Service Corporation, 2425 Spiegel Drive, Groveport, OH 43125, USA

Limited warranty

one (1) year

Warranty coverage :

This warranty obligation is limited to the terms as set forth below.

Who is covered:

This product warranty is issued to the original purchaser or the person receiving the product as a gift against defects in materials and workmanship as based on the date of original purchase (“Warranty Period”) from an Authorized Dealer. The original sales receipt showing the product name and the purchase date from an authorized retailer is considered such proof.

What is covered:

This warranty covers new products if a defect in material or workmanship occurs and a valid claim is received within the Warranty Period. At its option, the company will either (1) repair the product at no charge, using new or refurbished replacement parts, or (2) exchange the product with a product that is new or which has been manufactured from new, or serviceable used parts and is at least functionally equivalent or most comparable to the original product in current inventory, or (3) refund the original purchase price of the product. Replacement products or parts provided under this warranty are covered against defects in materials and workmanship from the date of the replacement or repair for ninety (90) days or for the remaining portion of the original product's warranty, whichever provides longer coverage for you. When a product or part is exchanged, any replacement item becomes your property and the replaced item becomes company property. When a refund is given, your product becomes company property. Note: Any product sold and identied as refurbished or renewed carries a ninety (90) day limited warranty.

Replacement product can only be sent if all warranty requirements are met. Failure to follow all requirements can result in delay.

What is not covered - Exclusions and limitations:

This Limited Warranty applies only to new company manufactured products that can be identied by the trademark, trade name, or logo axed to it. This Limited Warranty does not apply to any hardware product or any software, even if packaged or sold with the product, as manufacturers, suppliers, or publishers may provide a separate warranty for their own products packaged with the bundled product.

The company is not liable for any damage to or loss of any programs, data, or other information stored on any media contained within the product, or other additional product or part not covered by this warranty. Recovery or reinstallation of programs, data or other information is not covered under this Limited Warranty.

This warranty does not apply (a) to damage caused by accident, abuse, misuse, neglect, misapplication, or non-supplied product, (b) to damage caused by service performed by anyone other than company approved Authorized Service Location, (c) to a product or a part that has been modied without written company permission, or (d) if any serial number has been removed or defaced, or (e) product, accessories or consumables sold “AS IS” without warranty of any kind by including refurbished product sold “AS IS” by some retailers.

This Limited Warranty does not cover:

• Shipping charges to return defective product.

• Labor charges for installation or setup of the product, adjustment

of customer controls on the product, and installation or repair of antenna/signal source systems outside of the product.

• Product repair and/or part replacement because of improper

installation or maintenance, connections to improper voltage supply, power line surge, lightning damage, retained images or screen markings resulting from viewing xed stationary content for extended periods, product cosmetic appearance items due to normal wear and tear, unauthorized repair or other cause not within the control of the company.

• Damage or claims for products not being available for use, or for

lost data or lost software.

• Damage from mishandled shipments or transit accidents when returning product.

• A product that requires modication or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modications.

• A product used for commercial or institutional purposes (including but not limited to rental purposes).

• Product lost in shipment and no signature verication receipt can be provided.

• Failure to operate per user manual.

To obtain assistance… Contact the Customer Care Center at:

-866-202-5960

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER, WITH THE ISSUING COMPANY NOT LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

58 .English

License

nai Corporation, Inc. hereby offers to deliver, upon request, a copy of

u the complete corresponding source code for the copyrighted open source code packages, on an “AS IS” basis, used in this product for which such offer is requested by the respective licenses. This offer is valid up to three years after the product purchase to anyone in receipt of this information. To obtain source code, please contact Funai Corporation, Inc. You should write to Funai Service Corporation OSS Request, 2425 Spiegel Drive, Groveport, OH 43125, USA. Funai Corporation, Inc. disclaims any and all warranties and representations with respect to such software and related source code including quality, reliability, usability, and accuracy, and further disclaim all express, implied, statutory or otherwise, including without limitation, any implied warranties of title, non-infringement, merchantability, or fitness for a particular purpose. Funai Corporation, Inc. shall not be liable to make any corrections to the open source software or source code or to provide any support or assistance with respect to it. Funai Corporation, Inc. disclaims any and all liability arising out of or in connection with the use of this software and/or source code.

59 .English

Funai Corporation, Inc. 12489 Lakeland Road, Santa Fe Springs, CA 90670, USA

This product has been manufactured by and is sold under the responsibility of Funai Corporation, Inc., and Funai Corporation, Inc. is the warrantor in relation to this product.

The Philips trademark and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license.

AA78DUH-65UX / AA781UH-65UL / AA7RCUH-55UL / AA7R1UH /

AA7UCUH-50UX / AA7U1UH-50UX / AA7VCUT-43UL / AA7V1UT-43UL

★★★

Philips 65PFL5602/F7, 43PFL5602/F7, 50PFL5602/F7 user manual

Specifications and Main Features

Frequently Asked Questions

User Manual
