Philips 50PF9967D-10, 32PF9967D-10, 42PF9967D-10 User Manual

1

EnglishDeutschFrançaisNederlands

3104 315 2457.1

Read this first !

Help?

If this instruction manual does not give an answer or if ‘Before calling service’ do not solve your TV
problem, you can call your Local Philips Customer or Service Centre. See the supplied World-wide
guarantee booklet.
Please, have the Model and Product number which you can find at the back of your television set or
on the packaging, ready, before calling the Philips helpline.

Model: 32PF9967D/10;42PF9967D/10; 50PF9967D/10
Product No:

Care of the screen

Do not touch, push or rub or strike the screen with anything hard as this may scratch, mar or damage
the screen permanently. And please do not rub with dust clothes with chemical treatment.
Do not touch the surface with bare hands or greasy cloth (some cosmetics are detrimental to the
screen). Unplug the TV before cleaning the screen.
When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials
like chamois soaks. Do not use acetone, toluene and alcohol because they cause chemical damage. Do
not use liquid cleaners or aerosol cleaners.Wipe off saliva or water drops as soon as possible.Their
long time contact with the screen causes deformations and colour fading.

Recycling

R The packaging of this product is intended to be recycled.Apply to the local authorities for correct

disposal.

Disposal of your old product

Your product is designed and manufactured with highly quality material and components, which can
be recycled and reused.When this crossed-out wheeled bin symbol is attached to a product, it
means the product is covered by the European Directive 2002/976/EC.
Please inform yourself about the local separate collection system for electrical and electronic
products. Please act according to your local rules and do not dispose of your old products with your
normal household waste.The correct disposal of your old product will help prevent potential
negative consequences for the environment and human health.

EasyLink features are based on the “one touch operation” approach.This means
that a sequence of actions are executed at the same time in both the television
and the recorder, provided both are fitted with the EasyLink function and
connected with the eurocable supplied with your recorder.

24571.1 en.qxd 31-08-2005 11:59 Pagina 1

2

Safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Connect antenna and peripheral equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Switch the TV on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Use of the remote control RC4312 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Digital mode

Switch on for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Understanding the information in the banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Rearrange services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

View or Listen to new services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Add new services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Reinstall all services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Test reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Language and location preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Access restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting up your favourite list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Using the Options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

TV guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Recording function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Analogue mode

To use the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Select the menu language and country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Store TV channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Automatic installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Manual installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Give name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Reshuffle the programme list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Select Favourite TV channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TV Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Decoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

TV menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Picture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Active Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Sound menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Ambilight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Features menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Digital Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Analogue Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Teletext menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Equipment to connect to the side connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Connect Peripheral Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Recorder (vcr-dvd+rw) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Recorder and other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

MultiChannel Surround receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Equipment to connect to a DVI connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Connect extra subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Common Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Recorder or DVD with EasyLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

To select connected equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Audio- and video equipment keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Before calling service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Centre Frequencies Table (in KHz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Contents

24571.1 en.qxd 31-08-2005 11:59 Pagina 2

3

English

& Wall mounting instructions/Table stand

According to the type of TV you’ve purchased a wall mount bracket
and/or stand may be supplied. How to mount the supplied stand and/or
wall mount bracket, see the supplied separate leaflet. Make sure that the
wall mount is being fixed securely enough so that it meets safety
standards.
The weight of the TV (excl. packaging) is about 20 kg (32PF9967D);
42 kg (42PF9967D); 58 kg (50PF9967D).

é Place or hang the TV wherever you want, but make sure that air can

circulate freely through the ventilation slots. Do not install the TV in a
confined space such as a book case or a similar unit.
To prevent any unsafe situations, no naked flame sources, such as lighted
candles, should be placed in the vicinity. Avoid heat, direct sunlight and
exposure to rain or water.
The equipment shall not be exposed to dripping or splashing.

& Before installing your TV, connect all your peripheral equipment.

See How to connect peripheral equipment, p. 29.

é Insert the aerial plug firmly into the aerial socket x at the bottom of

the TV. For best picture quality use the suppressor-aerial cable
supplied.

“ Insert the mains cord supplied into the mains at the bottom of the TV

and in the wall socket having a mains voltage of 198-264V.
To prevent damaging the power (AC) cord which could cause a fire or
electric shock, do not place the TV on the cord.

Do not insert the power plug in a wall socket before all connections are made.

UK - EIRE

Insert the two R6-type batteries (supplied) making sure that they are
the right way round.

The batteries supplied do not contain the heavy metals mercury and
cadmium. Please check on how to dispose of exhausted batteries according to
local regulations.

Press the power switch B at the right side of the TV.
An indicator on the front of the TV lights up and the screen comes on.
If the TV is in standby mode, press the

-P+ keys or the B key on the

remote control.
The first time (and only the first time !) the TV is switched on, a

congratulation message will appear on screen. Follow the instructions
on screen or go to p. 7, Switch on for the first time.

MENU P/CHV

B

Switch the TV on

Remote control

Connect antenna and peripheral equipment

Safety warnings

24571.1 en.qxd 31-08-2005 11:59 Pagina 3

4

MODEON/OFF

Ambilight

+

-

+

-

DVD/R SAT TV VCR AUX

MENU MENU

123

456

789

0

Ò

®

‡

π

º

†

®

®

®

®

OPTIONS

MHEG

CANCEL

Select

DIGITAL

b

q

h

b

æ

j

i

0

A/D

TV

DIGITAL

OK

B

v

¬

P

V

Note: For most keys pressing a key once will activate the function. Pressing a second time will de-activate it.
When a key enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list.
The list will be removed automatically after 6 seconds or press

OK to remove immediately.

DVD/R SAT TV VCR AUX

See ‘Audio- and Video equipment
keys’, p. 36.

v Select your peripherals

See p. 35.

B Standby

Press to switch the TV on or off
from or to standby mode.
When switched off, a red indicator
on the TV lights up.

b Teletext On/Off see p. 27.

For UK: Hold down for 3 seconds to
switch the teletext on.

OK Press this key

• to activate your choice, when in the
menus.

• to display the programme list.

MENU DIGITAL

To display or exit from the digital
menus (when the TV is in digital
mode).

PProgramme selection

To browse through the TV channels
and sources stored in the favourite
list or to select a page in digital
menus.

0/9 Digit keys

To select a TV channel.
For a two or three digit programme
number, enter the second or third
digit before the dash disappears.To
switch immediately to a selected one
digit TV channel, keep the digit key
pressed a bit longer.

0 Previous programme

Press to alternate between the
currently viewed and the previously
viewed TV channel.

Ambilight see also p.24.

•

ON/OFF

Press to switch Ambilight on or off.

•

MODE

Press repeatedly to select one of the
predefined ambient light settings.

Note:When the TV is switched to
standby, and you switch Ambilight On,
Ambilight will be active. Only then less
modes are available.

®Ò‡π†º

Audio and Video equipment keys,
see p. 36.

A/D

To s witch between analogue and
digital mode.

Cursor keys

Press the cursor keys up/down,
left/right to navigate through the
menus.

MENU TV

To display or exit from the analogue
menus.

VTo adjust the volume.

¬ Interrupt the sound or restore it.

i On Screen information

In analogue mode:

Press to display (when available)
information about the selected TV
channel and programme.

In digital mode:

-Press once to display the
information banner.

-Press twice to get more
information on the programme.

-Press a third time to remove it.

Menu/Remote control info

When a menu is on screen (only in
analogue mode), press

i to display

info on the selected menu item.
While the menu info is displayed,
press any key (except the menu or
digit keys) to display remote control
info.The normal function of the key is
not executed.

Use of the remote control RC4312

24571.1 en.qxd 31-08-2005 11:59 Pagina 4

5

English

MODEON/OFF

Ambilight

+

-

+

-

DVD/R SAT TV VCR AUX

MENU MENU

123

456

789

0

Ò

®

‡

π

º

†

®

®

®

®

OPTIONS

MHEG

CANCEL

Select

DIGITAL

b

q

h

b

æ

j

i

0

A/D

TV

DIGITAL

OK

B

v

¬

P

V

q Picture format

Press this key repeatedly or press the cursor up/down to select another
picture format:Auto format, Super zoom, 4:3, Movie Expand 14:9, Movie
Expand 16:9, Subtitle zoom or Wide screen.

Auto format makes the picture fill the screen as much as possible.
In case of subtitles in the bottom black bar, Auto format makes the subtitles
visible.
In case of a broadcaster logo in the corner of the top black bar, the logo
disappears from the screen.

Super zoom removes the black bars on the sides of 4:3 programs with
minimal distortion.

When in Movie Expand 14:9, Movie Expand 16:9, Super zoom or Subtitle
zoom picture format, you can make subtitles visible with the cursor up/down.

Note:With signals via the

DVI connector less picture formats are selectable.

h Active control see p. 23.

x Pixel Plus 2 demo on/off

•Press to switch the Pixel Plus 2 demo on or off. In the right part of the
screen Pixel Plus 2 is switched on.

•Press longer to display the list of digital options settings. Use the cursor
up/down to select one of the settings.
See also Picture menu, Digital options, p. 23.

b Dual screen (in analogue mode only)

& Press the b key.

Press the

b key to show Teletext on the right half of the screen.

é Press the b key to switch off Dual screen.

Active screen selection

When in dual screen picture/teletext, enter the desired page number with
the digit keys or with the

-P+ key, then press the MENU TV key, then select

the left screen (with the blue ball at the top).You can now select a
compressed or full screen view of the picture screen with the

q key.

Auto format Super zoom 4:3 Movie expand 14:9

Movie expand 16:9 Subtitle zoom Wide screen

24571.1 en.qxd 31-08-2005 11:59 Pagina 5

6

MODEON/OFF

Ambilight

+

-

+

-

DVD/R SAT TV VCR AUX

MENU MENU

123

456

789

0

Ò

®

‡

π

º

†

®

®

®

®

OPTIONS

MHEG

CANCEL

Select

DIGITAL

b

q

h

b

æ

j

i

0

A/D

TV

DIGITAL

OK

B

v

¬

P

V

Digital or Analogue TV channels ?

To r eceive TV channels, your television is equipped with 2 tuners. One is
for digital channels, the other is for analogue channels.
Use the

A/D key on the remote control to switch the TV between

analogue or digital channels.
Then use the

-P+ key or the digit keys to select TV channels.

Only for digital channels

j

Continuous subtitles on/off

Press this key to activate/deactivate the subtitle mode.
See Setup, Language and location preferences menu,p. 11.

OPTIONS

Options menu on/off, see p. 14.

MHEG CANCEL (UK only)

Some Digital TV channels transmit interactive television applications
(signalled by the

MHEG icon in the banner).

Press this key to cancel those special services (and the function bar at
the bottom of the screen).

æ TV Guide, see p. 15.

To open and close Now and Next Programme Guide.

24571.1 en.qxd 31-08-2005 11:59 Pagina 6

7

English

The first time the TV is switched on, a congratulation message will
appear on screen.The language of which changes every 5 seconds.

Note: If the menu is not displayed, see Reinstall all services, p. 10.

& Press the OK key on the remote control, the moment your preferred

language is visible on the screen

.The Setup menu is displayed.

é With the cursor keys, select Language, Country or Time zone and

check if the adjustment is according to your preferences. If necessary,
use the cursor keys to make your adjustment and press

OK to exit.

Caution : if you select a wrong country, the channel numbering will not be
according to the standard for your country.

‘ Select Service scan from the menu and press OK to start the

installation.The service scan menu is displayed.
All digital and analogue programmes are searched for and stored
automatically. When the search is complete, the menu will indicate the
number of digital services and analogue programmes found.

( Press the OK key twice to start watching TV.

The television then displays the current programme.The installation is
now complete.

Digital TV mode

Switch on for the first time

Installation

Set options and start a service scan

Language •

Country

•

Time Zone •

Service Scan •

English

Español
Français
Italiano
Suomi

24571.1 en.qxd 31-08-2005 11:59 Pagina 7

8

When you select a digital programme, an information banner is
displayed for a few seconds at the top of the screen.

Note:You can also use the i key of the remote control to display this
banner.
A second press displays more information about the programme (when
available).

The banner contains information on the channel number, channel
name, programme duration, transmission clock, programme title and
the time remaining of the current programme.

Symbols description :

i more information about this programme is available.

Press the i key to display or remove it.

j subtitling is available.

If you want to display them, press the j key or the

OPTIONS key to access the OPTIONS menu and select

subtitles.

X Other audio languages are available and can be selected in the

OPTIONS menu.

s The selected Favourite list is displayed in the one of the

colour (red, green, yellow or blue) of the activated list.

Note : A white colour s will appear if the programme is stored in
one or more of the favourite list which is currently not activated.

Understanding the information in the banner

2 11:06 - 11:09 i j X s 11:46
BBC2 Snooker Minutes left: 14

preset
number

channel name programme title

remaining time
of programme

symbols

clock

programme

start and end

time

24571.1 en.qxd 31-08-2005 11:59 Pagina 8

9

English

This menu allows you to change the order of the
stored digital channels and radio stations.

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

Note: If the digital menu does not appear, the TV
might be in analogue mode. Press the

A/D key to

switch the TV to digital mode and press the

DIGITAL MENU key again.

é Use the cursor down to select Installation

and press the cursor right twice to select the

Service lists menu.

“ Use the cursor up/down to select Rearrange

services

and press the cursor right.

‘ Use the cursor up/down to select the channel

you want to exchange.

( Press the OK key to activate.

Note: If you want to uninstall the selected channel,
press the red colour key.

§ Use the cursor up/down to select the new

channel number you want to exchange it with.

è Press the OK key to confirm.The exchange is

done.

! Repeat the operations ‘ to è until all the

channels are in the required order.

ç Press the

DIGITAL MENU key to exit the

menu.

This menu allows you to check the availability of
new TV channels or new radio stations that have
been launched by the broadcaster after the initial
installation.

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

é Use the cursor down to select Installation

and press the cursor right twice to select the

Service lists menu.

“ Use the cursor up/down to select View new

TV channels

or Listen to new Radio

stations

.

‘ If new services are available, press the cursor

right to enter into the list and use the cursor
up/down to move through the list.

( Press the DIGITAL MENU key to exit the

menu.

View or Listen to new services

Rearrange services

Setup

Installation

Manage service lists

Service lists •

Service setup •

Test reception •

Rearrange services
View new TV channels
Listen to new Radio stations

Close

Setup

Installation

Manage service lists

Service lists •

Service setup •

Test reception •

Rearrange services
View new TV channels
Listen to new Radio stations

Close

24571.1 en.qxd 31-08-2005 11:59 Pagina 9

10

This menu allows you to search for new TV
channels or radio stations that have been launched
by the broadcaster after the initial installation.

& From the digital mode, press the DIGITAL

MENU

key to display the Setup menu.

é Use the cursor down to select Installation

and press the cursor right.

“ Select Service setup with the cursor down

and press the cursor right.

‘ Use the cursor right to select Add new

services

and press the OK key to activate the
installation.
The search begins and only new channels will
be stored and added to the channel list menu.
The percentage of the installation that has been
completed and the number of channels found is
displayed.

( When the search is complete, select Store and

press the

OK key to accept the new services.

§ Press the DIGITAL MENU key to exit the

menu.

This menu allows you to reinstall all the digital TV
channels and radio stations.

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

é Use the cursor down to select Installation

and press the cursor right.

“ Use the cursor down to select Service setup

and press the cursor right.

‘ Use the cursor down to select Reinstall all

services

and press the cursor right.

( Press the OK key to start the installation.

A search is then made for all digital services
which are then stored automatically.When the
search is completed, the menu will indicate the
number of digital services found.

§ When the search is complete, press the OK

key to store the services.

è Press the DIGITAL MENU key to exit the

menu.

Reinstall all services

Add new services

Setup

Installation

Install and manage services

Service lists •

Service setup •

Test reception •

Add new services
Reinstall all services

Close

Setup

Installation

Install and manage services

Service lists •

Service setup •

Test reception •

Add new services
Reinstall all services

Close

24571.1 en.qxd 31-08-2005 11:59 Pagina 10

11

English

This menu allows you to check the strength of the
signal you are receiving through your aerial.

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

é Use the cursor down to select Installation

and press the cursor right to display the
Installation menu.

“ Use the cursor down to select Test reception

and press the cursor right.
You obtain an indication of the actual
programme frequency, the network name, the
signal quality and strength.

‘ You now have to enter the frequency of the

digital channel you want to test.

Your TV magazine can provide the list of digital
channel numbers. Use the table on page 38 to get
the frequency.

( If the signal quality and strength is poor,a

message appears at the bottom of the menu
prompting you to enter the frequency between
the lower and the higher limit.
If after keying the frequency, the reception is
still poor, you can try improving, renewing,
adjusting or updating the aerial. It is however
advisable to contact a specialised aerial installer
in order to achieve best results.

This menu allows you to select your preferred
language for audio, subtitle, teletext and menu and
make changes to the location (country and time
zone).

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

é Use the cursor down to select Preferences

and press the cursor right.

“ Use the cursor up/down to select Languages,

Location or Digital Audio Output and press

the cursor right.

‘ Use the cursor up/down to select a setting and

press the cursor right to enter into the sub­menu. Make your adjustment and press the

OK

key or the cursor left to exit.

Language default settings

•

Audio : to select the audio sound language.

•

Subtitle/Teletext : to select the

subtitle/teletext language.

•

Subtitling mode : off, on or auto (subtitle

only displayed in case of original audio
transmission).

•

Subtitles for hearing impaired : to activate

or deactivate the specific subtitle for hearing
impaired (if made available by the
broadcaster).

•

System : to select the menu language.

Location settings

•

Country : to select the country where you

are located.

•

Time zone : to select the time zone where

you are located.

Digital Audio Output settings

• Select

AC3 (if the signal is broadcasted and if

the amplifier connected supports the Dolby
Digital format).

• Select

PCM if the amplifier connected doesn’t

support Dolby Digital format. See also
Connect Peripheral Equipment, MultiChannel
Surround receiver, p. 32.

( Press the DIGITAL MENU key to exit the

menu.

Language and location preferences

Test reception

Setup

Installation

Test signal quality

Service lists •

Service setup •

Test reception •

Frequency
Network name
Signal quality
Signal strength

Close

Setup

Preferences

Select your preferred language

Languages •

Location •

Digital Audio Output •

Audio
Subtitle / Teletext
Subtitling mode
Subtitling for hearing impaired
System

Close

24571.1 en.qxd 31-08-2005 11:59 Pagina 11

12

This menu allows you to setup the access
restrictions of the digital channels.

& From the digital mode, press the DIGITAL

MENU

key to display the Setup menu.

é Use the cursor down to select Access

restriction

and press the cursor right.

“ Press the cursor right to enter into the Set

pin code protection

menu.

‘ Use the cursor left/right to set to On and

press the

OK key to exit.

You can then access the other adjustments:

Warning : the moment you use any kind of access
restriction, you need to fill in the pin code when you
schedule a program for recording.

•

Maturity rating : select your preferred rating

to lock the channel.

Maturity rating will only block certain programmes
if the broadcaster provides data with the
programme.

•

TV channels : select the TV channel you

want to lock and press the

OK key.

•

Radio station : select the radio station you

want to lock and press the

OK key.

•

Change pin code :press the cursor right to

enter in the menu. Follow the on-screen
instruction to change your access code.

The default pin code is 1234. If you have
forgotten your personal code, you can reset to the
default pin code (1234) by enter the universal
code 0711.

( Press the DIGITAL MENU key to exit the

menu.

The TV is equipped with a Common Interface
(CI) slot (see p. 34). A CI module can enable
additional services, for example Pay TV.The
Access Restrictions menu will show the CI
Access Restrictions when a CI module is
installed.The CI module is responsible for the
messages and texts on screen. In case of
failure or strange behaviour, you must call
your CI service provider.

Access restrictions

Setup

Access restrictions

Switch pin code protections “on” or “off”

Set pin code protection

Maturity rating

TV channels

Radio stations

Change pin code

Close

On Off

24571.1 en.qxd 31-08-2005 11:59 Pagina 12

13

English

This menu enables you to create a favourite list
with your preferred TV channels and radio stations.
For example, each member of your family can
create his/her own favourite list.

& From the digital mode, press the DIGITAL

MENU key to display the Setup menu.

é Press the cursor right to enter into the

Favourites list menu.

You have the choice to create 4 different
favourite lists.

“ Use the cursor up/down to select your

favourite list :

List 1, List 2, List 3 or List 4

and press the cursor right.

‘ Use the cursor up/down to select a setting and

press the cursor right to enter into the sub­menu.

•

Name : use the cursor left/right to move

around the name display area (16 characters)
and the

-P+ keys to select the

characters.When the name has been entered,
press the

OK key to exit.

•

Select TV channels : use the cursor up/down

to select your favourite TV channels and
confirm with the

OK key. Press the cursor left

to exit.

•

Select radio stations : use the cursor

up/down to select your favourite radio station
and confirm with the

OK key. Press the

cursor left to exit.

•

Add all services :press the OK key if you

want to add all the services into your
favourite list.

•

Remove all services :press the OK key if

you want to remove all the service from your
favourite list.

( Press the DIGITAL MENU key to exit the

menu.

§ Your favourite list can be selected using the

options menu (see next page).

Setting up your favourite list

Setup

Make changes to your lists of favourite services

Favourites

Preferences
Information

Access restrictions

Installation

List 1
List 2
List 3
List 4

Close

24571.1 en.qxd 31-08-2005 11:59 Pagina 13

14

This menu provides information about the software
version and the installation of new software.

& From the digital mode, press the DIGITAL

MENU key to display the setup menu.

é Use the cursor down to select Information

and press the cursor right twice.The software
version is displayed.

“ You can activate the menu to automatically

accept any software update of your digital TV.
Normally the product will detect if an update is
available while it is in standby mode. Next time
the television is turned on a banner will appear
at the bottom of the screen indicating new
software is available. Selecting

OK activates the

software download.
The software download menu will give a
description of the software together with the
date and time of the download.This may
update certain menus, functions or add new
features, but the general way in which the TV
operate will not change. Once accepted the
download will take place at the designated time
and date.

Note:The TV must be put into standby when the
download is due in order for it to take place.

‘ Press the DIGITAL MENU key to exit the

menu.

Whenever a new software is available, it is
advisable to always accept and download the
software. In case new software is available,
you will see a message when you switch on
the TV.

This menu gives you direct access to the favourite
list, the language selection and some other
selections.

& From the digital mode, press the OPTIONS

key on the remote control to display the
options menu.

é Use the cursor up/down to select a setting and

press the cursor right to enter the sub-menu.

•

Favourites : use the cursor up/down to

select your favourite list and confirm with the

OK key.

The

None option deactivates any favourite list.

To create your own favourite list, see page 13.

•

Subtitle language : use the cursor up/down

to temporarily change the language and
confirm with the

OK key.

•

Audio language : to temporarily change the

audio sound language.

To permanently change the audio and subtitle
languages, use the Preferences menu (p. 11).

•

Mode :you can choose to only have radio

stations,TV channels or services without
audio or video.

Remark : for the UK only, the TV list will contain
both radio stations and TV channels.

•

Banner duration : to select the duration for

which the banner is visible.

“ Press the OPTIONS key to exit the menu.

Using the Options menu

Information

Setup

Provides information on problem reports and....

Favourites

Preferences

Information

Access restrictions

Instalation

System software

Close

Options

Selects the active favourite list

Favourites

Subtitle language

Audio language

Mode

Banner duration

None
List 1
List 2
List 3
List 4

Exit

24571.1 en.qxd 31-08-2005 11:59 Pagina 14

15

English

The TV guide is an Electronic Service Guide that
allows you to look up digital programmes as you
would in a newspaper or TV magazine.
You can navigate through the list of digital
programmes and obtain detailed information on
the programmes.You can also program the TV to
provide a digital channel to be recorded.

& From the digital mode, press the æ key to

display the TV guide :
A list of all the digital programmes in the
currently selected favourite list is displayed.

é Use the cursor down to enter into the

Preset/service list or press the cursor right to

access

Today list.

“ Use the cursor up/down to select a

programme.

‘ The TV guide features are displayed at the

bottom of the screen. Use the coloured keys
red, green, yellow, blue or white to activate
them :

•

Record (red key) : this feature enables you to

record a digital channel even the TV is in
standby mode.You will still have to program
your video recorder.

•

Record list (green key) : this menu gives the

list of recording schedules.You can check,
modify, delete or add a new schedule by using
the cursor or coloured keys as indicated on
the screen.

•

To p (yellow key) : to go directly to the top of

the list.

•

Close (blue key) : to exit from the TV guide.

•

Options (white † key) : with this menu,

you can select your favourite list, mode or
themes.Themes are areas of interest.
You can for example decide to display only :
drama, news, movie, ...

( Press the i key if you want to display more

information about the selected programme (if
available).

§ Press the æ key to exit the menu.

TV guide

BBC ONE

1 17:15 17:24

Now/Next Today

Preset/Service Now Next

1 BBC ONE
2 BBC TWO
3 ITV Channel 3
4 Channel 4
5 ITV 2
6 BBC CHOICE

See it
Snooker
Trisha

­Soccer
News

Microscoop
Ice skating
This morning

­This afternoon
Bodger & Badger

CloseRecord Rec.list To p Options

24571.1 en.qxd 31-08-2005 11:59 Pagina 15

16

This feature enables you to record a digital channel
while the TV is in standby mode.You will still have
to program your video recorder.
If you wish to continue watching another digital
channel after setting a timer, you can do so by
changing channels in the normal way.

Important : The video recorder must be connected to

EXT2 (see Connect Peripheral Equipment, p. 30). Please

note that it is NOT possible to record one channel and
watch another channel at the same time.

& From the digital mode, press the æ key to

display the TV guide.

é Use the cursor down to enter into the

Preset/service list or press the cursor right to

access

Today list.

“ Press the red colour key to call the Record

menu.

‘ Use the cursor up/down to select a setting and

press the cursor right to enter into the sub­menu. Make your adjustment and press the

OK

key or the cursor left to exit.

•

Name : the selected programme will be

displayed here.

•

Service :you can change the number of the

programme you want to record. Press the

OK

key to confirm.

Note : it is only possible to change to a number
that is in the currently selected favourite list.

•

Enter your pin code if locked : enter your

secret code only if you have activated the
access restriction feature (see p. 12).
Press

OK to confirm.

•

Day & Month : enter the date by using the

digit keys or the

-P+ keys. Press the OK key

to exit

•

Start time : enter the start time.

•

End time : enter the end time.

•

Audio language : select your language and

confirm with the

OK key.

•

Subtitle language : make your selection and

confirm with the

OK key.

•

Subtitles for hearing impaired : select Ye s

or No and confirm with the OK key.

•

Occurrence : select Once, Daily or Weekly

and confirm with the

OK key.

( Press the red colour key to store your

recording.The TV guide reappears.
You can press the green colour key to display
the list of recordings you have set.

§ If you have finished watching television, you

must leave it in standby in order for the
recording program to be activated.

Important

:never switch off the TV with the
power button when a recording has been
programmed, but use the standby B key on
the remote control.

è If you wish to continue watching another digital

channel after setting a timer, you can do so by
changing channels in the normal way.

Important : In digital mode, if you change the

channel when the recording starts, the TV will record
the last channel. you have selected.

! When the timer is due to start a digital

channel, while you are watching another
channel, the programmed digital channel is
displayed and the recording starts.A warning
message is displayed.

ç If a digital recording is in progress,when trying

to change a channel, a confirmation is displayed
to continue recording or to cancel recording.
When you select cancel recording, the newly
selected channel is displayed.

Recording function

BBC 2

17:24

Name

Service

Enter yourpin if locked

Day & Month

Start time

End time

Audio lanugage

See it saw
1 TVE

10/08
12:15
15:44

English

CloseStore Cancel

24571.1 en.qxd 31-08-2005 11:59 Pagina 16

17

English

& Make sure you are in Analogue mode. If necessary, press

the

A/D key on the remote control.

é Press the MENU TV key on the remote control to

summon the main menu.At any moment you can exit
the menu by pressing the

MENU TV key again.

“ Use the cursor in the up/down direction to select the

TV, Setup, Demo or Install menu items.

Use the cursor left/right to select

Picture, Sound,

Ambilight or Features.

Note: Sometimes not all the menu items are visible on the
screen (indicated by a cluster of blue balls). Use the cursor
down or right to reveal all items.

‘ Use the cursor in the left/right direction to select the

menu item.

( Use the cursor up/down again to select the control you

want to select or to adjust.

Note: Items temporary not available or not relevant are displayed
in a light grey colour and cannot be selected.

The

Install menu allows you to reinstall all the analogue TV

channels and contains the following items:

If you want to change your menu language and/or the
country where you are now located, go to Language and
location preferences, p. 11.

Analogue TV mode

++

DVD/R SAT TV VCR AUX

MENU MENU

Ò

®

‡

π

º

†

®

®

®

®

Select

DIGITAL

b

A/D

TV

OK

B

v

¬

P

V

cursor to select
adjustments

OK key to

activate

return or switch
main menu on/off

Press the i key to get
information about the selected
menu item.

EasyLink

If your recorder has an EasyLink function, during installation, the
language, country and available channels are automatically
transmitted to the recorder.

TV

Setup

Demo

Install

Picture Sound Ambilight Features

Install

Automatic Manual Give name Reshuffle Favourite

install install programmes

Select the menu language and country

Installation

To use the menus

24571.1 en.qxd 31-08-2005 11:59 Pagina 17

18

You can search for and store the analogue TV channels in two different ways: using Automatic Installation
or Manual Installation (tuning-in channel by channel).
Select your choice with the cursor right.

Manual install

Install

Selection mode

System

Programme

Search

Fine tune

Store

Automatic install

Install Start

Install

& Select Automatic install in the Install menu.

Note: All channels must be unlocked in order to autoprogram. If
requested, enter your code to unlock all channels. (See TV, Features
menu, Childlock, p. 26.)

é Press the cursor down.

The autoprogramming option label

Start appears.

“ Press the cursor right.
‘ The message Searching appears and the progress of

autoprogramming is displayed.

If a cable system or a TV channel which broadcasts ACI (Automatic
Channel Installation) is detected, a programme list appears.Without
ACI broadcast, the channels are numbered according your language
and country selection.You can use Reshuffle to renumber them. See
p. 19.

It is possible that the cable company or the TV channel displays a
broadcast selection menu. Layout and items are defined by the cable
company or the TV channel. Make your choice with the cursor and press
the

OK key.

Manual installation

Automatic installation

Store TV channels

Searching for and storing TV channels is done channel by channel.
You must go

through every step of the Manual Installation menu.

& Select Manual install in the Install menu.
é Press the cursor down.

Follow the instructions on screen.

Note: Search or direct selection of a TV channel.
If you know the frequency, the C- or S-channel number, enter the 3 or
2 digits of the frequency or the channel number directly with the digit
keys 0 to 9 (e.g. 048).

Repeat to search for another TV channel after you have stored
the selected TV channel.

24571.1 en.qxd 31-08-2005 11:59 Pagina 18

19

English

It is possible to change the name stored in the
memory or to assign a name to a TV channel or
external for which a name has not yet been
entered.A name with up to 5 letters or numbers
can be given to the programme numbers 0 to 99
and to the externals.

& Select Give Name in the Install menu and

press the cursor down.

é Select the programme number.

Note: keep the cursor up/down pressed to scroll
through the programme list quickly.

“ Press the cursor right.

A keyboard appears on the screen.
Press the cursor right to enter the keyboard.
Press the cursor up/down, left/right to select
the first character and press

OK. Repeat for

every character you want to enter.
Select

Space to enter a space; Delete to erase

the highlighted character in the name entered;

Shift to display upper- or lowercase characters

on the keyboard; Special to display special
characters on the keyboard. Press

OK to

confirm.

‘ Press the cursor left repeatedly when you have

finished the name giving.

( Select another programme number and repeat

steps

“ to ‘.

pπ

® Space ® Delete

ABCDEFG 123
HIJKLMN 456
OPQRSTU 789
VWXYZ 0

® Shift ® Special

Give name

Install

VCR1

BBC1
BBC2
CNN

TVE

.....

You can change the order of the stored TV channels.

& Select Reshuffle in the Installation menu.
é Follow the instructions on screen.

& Select Favourite programmes in the Install menu.
é Select your programme number with the cursor up/down.

“ Select Ye s or No with the cursor right.
‘ Repeat é and “ for every TV channel or external you want

to make a favourite or a non-favourite TV channel or external.

Reshuffle

Install

BBC1
BBC2
TV1
CNN
ARD
NED 1

Favourite programmes

Install

Ye s
Ye s
No
Ye s
Ye s
No

BBC1
BBC2

TV1

CNN

ARD

NED 1

Select Favourite TV channels

Reshuffle the programme list

Give name

24571.1 en.qxd 31-08-2005 11:59 Pagina 19

This menu allows you to change various settings
that are presumably adjusted less frequently than
most other settings.

Menu background

Select

Ye s or No to turn the menu background

on or off.

Factory settings

This resets the picture and sound settings to
their predefined factory values, but maintains
the channel installation settings.

OSD (On Screen Display)

& Select OSD.
é Select Normal to activate the continuous

display of the programme number and
extended display of TV channel and programme
information on screen.

Minimum to activate

the display of reduced channel information.

Note:When subtitles is switched on, see Features,
p. 26, display of the programme number is not
possible.

Programme title

Select

Programme title Yes or No.

When selected

Ye s , after the selection of a TV

programme or after pressing the i key on
the remote control, a TV channel which
broadcasts teletext may transmit the name of
the TV channel or the programme title.
When selected

No, the programme title will

only appear after pressing the i key and not
after the selection of a TV channel.

Teletext 2.5

Some broadcasters offer the opportunity to
see more colours, other background colours
and nicer pictures in the teletext pages.

& Select Teletext 2.5.
é Press the cursor right to select Teletext 2.5

On

to take advantage of this feature.

“ Press the cursor right again to select Teletext

2.5 Off

if you like the more neutral teletext
layout.
The selection made is valid for all channels
which broadcast teletext 2.5.

Note: It may take a few seconds before teletext
broadcast switches over to Teletext 2.5.

Auto Surround

Sometimes the broadcaster transmits special
signals for Surround Sound encoded
programmes.
The TV automatically switches to the best
surround sound mode when

Auto Surround is

switched On.

Subwoofer

Select

Ye s if you installed an external

subwoofer. See Connect Peripheral Equipment,
Connect extra subwoofer, p. 34.

20

The Setup menu contains items that control the settings
of the TV’s functions, features, services and peripherals
you may have connected.

The

General menu allows you to change settings that

will typically be accessed only occasionally.
The

Source menu allows you to select a source.

The

Decoder menu allows you to define one or more

programme numbers as decoder programme numbers.

General Source Decoder

Menu background

Factory settings

OSD

Programme title

Teletext 2.5

Auto surround

Subwoofer

Set/Change code

Setup

Press the i key to get information about the selected menu item.

General

TV Setup

24571.1 en.qxd 31-08-2005 11:59 Pagina 20

If a decoder or a descrambler is connected, see
p. 30, you can define one or more programme
numbers as decoder programme numbers.

& Select Decoder with the cursor right.
é Select Programme.
“ Select the programme number under which

you have stored the programme coming from
your decoder.

‘ Select Status.

• Select the input used to connect your

decoder:

None or EXT1.

• Select

None if you do not want the selected

programme number being activated as a
decoder programme number.

This menu allows you to indicate the peripheral
you connected to one of the external inputs.

& Press the cursor right to enter the list of types

of peripherals attached to the selected input.

é Select the peripheral device with the cursor

up/down.

Once you have selected the source type, e.g. DVD,
this source will automatically be selected when
your remote control is in DVD mode, see p. 4, and
when you press the v key on the remote
control.

Centre input - Centre in volume

When you have connected a surround receiver to
the TV, see p. 32, the loudspeakers of the TV can
act as centre speaker, making a separate centre
speaker unnecessary.
Select

Centre input On.

When having selected

On,you can adjust the

Centre in volume with the cursor left/right to

correct volume level differences of the external
audio receiver and speakers.

21

English

Set/Change code

The Child lock feature (see TV, Features, p. 26)
allows you to lock channels to prevent others
from watching certain programmes.To watch
locked channels, a 4-digit code must be
entered.The Set/Change code menu item
allows you to create or change a Personal
Identification Number (PIN).

& Select Set/Change code.
é If no code exists yet, the menu item is set to

Set code.

If a code has previously been entered, the menu
item is set to

Change code.Follow the

instructions on screen.

Important:You have forgotten your code!

& Select Change code in the General menu and

press

OK.

é Press the cursor right and enter the overriding

code 8-8-8-8.

“ Press the cursor again and enter a new

personal 4-digit code.The previous code is
erased and the new code is stored.

Source

EXT1
EXT2
EXT3
DVI-I
Side
Centre input
Centre in volume

Setup

Decoder

Programme
Status

Setup

Decoder

Source

24571.1 en.qxd 31-08-2005 11:59 Pagina 21

22

The Demo menu allows to demonstrate the TV features
separately or in a loop.

Note:Toggling through all the Ambilight modes will display
each mode for 10 seconds each. Before switching to the next
mode the light will first fade to off and then fade up in the
next mode.

Ambilight
Teletext
Active Control

TV

Setup

Demo

Install

Press the MENU TV key on the remote control to
summon the main menu.

Notes:

- Dependent on the input signal, one or more menu items
may not be selectable.

- Some analogue menus can also be displayed when in
digital mode.

& Press the cursor right to select Picture.
é Select the menu items in the Picture menu with the

cursor up/down.

“ Adjust the settings with the cursor left/right or

enter the list of submenu items with the cursor
right. Select a submenu item with the cursor
up/down.

Note:To remove the menu background before adjusting
the picture settings, see Select TV setup, General, p. 20.

Press the i key to get
information about the selected
menu item.

Picture Sound Ambilight Features

Smart picture

Contrast

Brightness

Colour

Sharpness

Tint

Digital options

Dynamic contrast

DNR

Colour enhancement

(Hue)

Picture format

TV

Picture menu

TV menu

Demo

24571.1 en.qxd 31-08-2005 11:59 Pagina 22

23

English

Smart picture

Select

Smart picture to display a list of

predefined picture settings, each corresponding
with specific factory settings.

Personal refers to the personal preference

settings of picture in the picture menu.

Note:This Philips TV has been set at the factory to
look best in bright store environments which use
fluorescent lighting.As your home will likely not be
as well lit as a store, we recommend you that you
cycle through the various Smart picture modes to
find the one that best suits your own viewing
conditions. Most consumers will find that Natural is
the correct choice.

Digital options

Pixel Plus 2 is the most ideal setting, doubles
the horizontal resolution and increases the
number of lines by 33%.
You may consider to select Movie Plus in case a
halo effect should disturb you. Dependent on
your own preference, select Progressive scan.

Dynamic contrast

Sets the level at which the TV automatically
enhances the details in dark, middle and light
areas of the picture.

DNR

This sets the level at which noise is measured
and reduced in the picture.

Colour enhancement

This makes the colours more vivid and
improves the resolution of details in bright
colours.

Hue

This compensates for the colour variations in
NTSC encoded transmissions.

Picture format

This will adjust the size of the picture
dependent on the broadcast format and your
preferred setting.
See also Use of the remote control, Picture
format, p. 4.

The TV continuously measures and corrects all
incoming signals in order to provide the best
picture possible.The ambient light sensor adjusts
the settings according to the viewing conditions in
the room (only when having selected the Active
control value Maximum).

& Press the h key on the remote control.

Note: Switch off all menus on screen.

é The Active Control menu appears.
“ Press the cursor up/down to select the Active

Control values

Off, Minimum, Medium or

Maximum.

The picture settings are being optimised
continuously and automatically which is
displayed by bars.Those menu items can not be
selected.

‘ Press the cursor right to select Smart


.

( Press the cursor up/down to select one of the

predefined picture settings.

§ Press the cursor right to select Active

Display

.

è Press the cursor up/down to select Show bars,

Pixel Plus 2, Digital Natural Motion or Off.

When you select Pixel Plus 2 or Digital Natural
Motion, the TV screen is divided into two parts:
in the left part the selected picture quality
setting is switched off; in the right part it is
switched on.

! Press the h key again to switch off the Active

Control menu.

Active Control

24571.1 en.qxd 31-08-2005 11:59 Pagina 23

24

& Press the cursor right to select Sound.
é Select the menu items in the Sound menu with the cursor

up/down and adjust the settings with the cursor
left/right.Remember, control settings are at normal mid-range
levels when the bar scale is centred.

Smart sound

Select Smart sound to display a list of predefined sound settings,
each corresponding with specific factory settings of Treble and
Bass.

Personal refers to the personal preference settings of

sound in the sound menu.

Notes:

- Dual X is only available with dual sound transmission.

- Mono/Stereo is only selectable in case of analogue stereo
transmission.

- Nicam/Analogue is only selectable in case of Nicam transmission.

Sound

Smart sound

Equalizer

Volume
Balance

Loudness

Headphone volume

Surround mode

(Dual I-II)

(Mono/Stereo)

(Nicam/Analogue)

(3D effect)

AVL

Delta volume

TV

Ambilight is an innovative lighting concept using light with fully
adjustable colours at the back of the TV to enhance the viewing
experience.Analysis of the picture content adapts the colours
continuously, or the lights can be set to any fixed colour and many
shades of white.Ambilight creates the ideal viewing environment for
your TV resulting in improved relaxed viewing, improved perceived
picture detail, contrast and colour.
In standby mode the lights can be set/operated to any colour and
create a unique ambiance in the room.

& Select Ambilight in the TV menu.
é Press the cursor down to enter the Ambilight menu.
“ Select Ambilight and press the cursor right to select Off or On.

•

Off: will switch off the ambient lights and downlight all other

menu items.

•

On: the ambient lights will be on. Refine the light settings in

the menus below.

‘ Select Brightness to adjust the light output of the ambient

lights.

( Select Mode and press the cursor right to select Colour,

Ambiance, Relaxed, Movie or Action.

•

Colour: this will show constant light according to the settings

in the Ambilight colour menu. See below.

• The options

Ambiance, Relaxed, Movie and Action will

dynamically match brightness and colour to the screen
content.
The mode selection made will effect the speed and/or
saturation and/or intensity which determines the viewing
impression.

Ambilight

Ambilight

Brightness

Mode

(Colour)

(Palette)

(Saturation)

TV

Ambilight

Sound menu

24571.1 en.qxd 31-08-2005 11:59 Pagina 24

25

English

E.g. in Relaxed mode, the rate of brightness and colour
change is smoothly and soft which gives you a more immersive
yet relaxed viewing.

Ambiance is the rate of brightness and colour change as

predefined in the factory.

Movie will influence the perception of a movie whereas
Action mode will influence the dynamic impression.

Notes:

- The rate of change is limited, as not to cause uncomfortable

sensations.

- According to the selection made, some Ambilight menu items will be

downlighted and can not be selected.

Ambilight in Standby mode

When the TV is switched off, the ambient lights will also be
switched off.When the TV is in standby mode, ambilight can be
used to provide a unique ambience for the room.Press the
ambilight on/off key on the remote control to switch between
Ambilight Off or On.

Infrared interference on external devices

To avoid bad remote control reception, place your external
devices out of sight of the ambient lights of your TV set.

Note: Ambilight does not function well when the room temperature is
less than 15°C.

Smart Colour modes:

•

Personal: Select any Colour or hue to match to your personal

taste, e.g. your interior, the program content (sports, movie,
etc.), the mood you are in, etc.

•

Warm white:The Colour is matched to that of most normal

lightbulbs. Select this setting if you want the Ambilight to fit
best with normal living room lighting.

•

Cool white:The Colour is matched to that of normal daylight

(6500K). Select this setting if you prefer more cool lighting.

Note: the 6500 K is the SMPTE recommended setting for ambient
backlighting of displays.

•

Blue:The blue Colour is preferred by most consumers to

create a cool, modern and /or mystical atmosphere. Select this
setting according to your personal taste or mood.

24571.1 en.qxd 31-08-2005 11:59 Pagina 25

26

& Press the cursor right to select Features.
é Select the menu items with the cursor

up/down and adjust the settings with the
cursor left/right.

Programme list

Press the

OK key to switch over to the

selected TV channel or external.

Select subtitles

The subtitle page must be stored for each TV
channel:
Switch on teletext and select the proper
subtitle page from the index. Switch off
teletext.

Subtitle On will automatically display them on

the selected TV channels if subtitles are in the
transmission.A symbol will indicate that the
mode is on.
Select

On during mute when you want to

have the subtitles automatically displayed only
when the sound has been muted with the ¬
key on the remote control.

Sleeptimer

This sets a time period after which the TV
automatically switches to standby.

Child lock

& Select Child lock.
é Press the cursor right to enter the Child lock

menu.You’re summoned to enter your code.

Note:You have to re-enter your code each time you
enter the child lock menu.

Important:You have forgotten your code !
See p. 21.

“ Select one of the menu items of the child lock

menu:

•

Lock if you want to lock all channels and

externals.

•

Custom lock and press the cursor right.

Select:

-

Lock after if you want to lock all

programmes from a certain time onwards.
Press the cursor right and enter the time
with the cursor up/down and right. Press the

OK key to validate.

-

Programme lock if you want to lock a

certain TV channel or external;

• Select

Unlock to disable all locks you have set.

Off
On
On during mute

Features

Programme list

Subtitle

Sleeptimer

Child lock

TV

Child lock

Lock
Custom lock
Unlock

Lock after
Programme lock

Press the i key to get information about
the selected menu item.

& Press b to switch the teletext on.

UK only:

- MHEG is displayed when programmes are
carrying

TEXT-MHEG interactive elements,

signalled by an

MHEG icon in the banner.

- to switch teletext on, hold b down for 3
seconds.

é To use the digital teletext, follow the

instructions on screen.

“ Depending on the service, you may be asked to

use the cursor keys, the

OK key, the coloured

keys, the teletext key and sometimes the digit
keys.

‘ When you have finished watching teletext;

select a different channel with the

-P+ keys or

follow the instructions on screen to return to
picture.

Te xt info

Some digital channels also offer information on
the programme being broadcast. In that case a
message may appear at the bottom of the
screen for a few seconds. Follow the
instructions on screen and use the cursor keys
to scroll through the text pages.

Some digital channels, which you select like any other channel, offer dedicated teletext services (for
instance BBC TEXT).

Digital Teletext

Features menu

24571.1 en.qxd 31-08-2005 11:59 Pagina 26

27

English

Switch Teletext on and off

Press b to switch the teletext on.

Select a Teletext page

- Enter the desired page number with the digit
keys, the cursor keys up/down, left/right or
with the

-P+ key.

- Select the options at the bottom of the screen
with the colour keys.

Previously selected teletext page

(Only possible in case there is no list of favourite
teletext pages available. See p. 28

Press the 0 key.

Select the index teletext page

Press the white colour key † to display the
main index (usually p.100).

Only for T.O.P teletext broadcasts :

Press i.A T. O.P. overview of the teletext
subjects available is displayed.
Select with the cursor up/down, left/right the
desired subject and press the

OK key.

Not all TV channels broadcast T.O.P. teletext.

Select subpages

When a selected teletext page consists of
different subpages, a list of available subpages
appears on the screen.
Press the cursor left or right to select the next
or previous subpage.

Picture/Teletext

& Press the b key. Press the b key to show

Teletext on the right of the screen.

é Press the b key to switch off dual screen.

Enlarge a Teletext page

Press q repeatedly to display the upper
teletext part, the lower teletext part and then
to return to the normal teletext page size.
When the teletext page is enlarged, you can
scroll the text, line by line using the cursor
up/down.

Hypertext

With hypertext you can quickly jump to a
pagenumber or search for a specific word
shown on the current teletext page.

& Press the OK key to highlight the first word or

a number on the page.

é Use the cursor up/down, left/right to select any

other word or number you want to search for.

“ Press the OK key to confirm.The search starts.

A message appears at the bottom of the screen
to indicate the searching, or that the word or
page is not found.

‘ Use the cursor up to exit hypertext.

Most analogue TV channels broadcast information via teletext.This TV has a 1200 pages memory that will
store most broadcasted pages and subpages to reduce waiting time. After each programme change, the
memory is refreshed.

LIONS RECORD ANOTHER WIN 430

Index 100 News 300
BBC Info 110 Headlines 305
Children 120 Weather 400
Cookery 150 Sports 415
Education 200 Radio 500
Lottery 230 Travel 550
Finance 240 Subtitling 888
Music 280 TV Listings 600

Red Green Yellow Blue

102 «03 04 05 06 07 08 09 10 11 12»

BBC CEEFAX 102 Mon 05 Feb 16.35.22

BBC CEEFAX

Analogue Teletext

24571.1 en.qxd 31-08-2005 11:59 Pagina 27

Teletext menu

& Press the MENU TV key to activate the menu.
é Press the cursor up/down to select the menu

items.

“ Press the cursor right to activate.

Reveal

Reveals/conceals hidden information on a page,
such as solutions to riddles and puzzles.
Press the cursor right to activate.

Favourite

You may create a list of eight favourite teletext
pages in total, selected from various TV
channels.

To add a favourite page to the list:

& Select a favourite teletext page.
é Select Favourite in the teletext menu and

press the cursor right to enter the list.

“ Press the cursor right again to add the page.
‘ Press the MENU TV key to watch the current

page.

To watch a favourite page from the list:

When in Teletext, use the 0 key to browse
through the favourite pages of the TV channel
actually selected.

Note: only the pages of the current channel can be
selected.

Search

Selecting a word
On the keyboard on screen you can type in a

random word you want to search for in the
teletext pages.Whether upper- or lowercase is
used has no influence.

& Press the cursor right to enter the keyboard.
é Press the cursor left/right, up/down to select

the characters, words or functions.

“ Press the OK key to confirm each character

selected.

‘ Select Cancel to cancel the word; Space to

enter a space;

Delete to delete the last

character selected;

Shift to switch between

lowercase or capital characters;

Special to

display special characters on the keyboard and
press the

OK key.

( Press the cursor left repeatedly to return to

the Teletext menu again.

Searching a word

& Type in the word on screen or select a word

from the history list on the right and press

OK.

é Select Accept and press OK again.The

message Searching appears.

“ To cancel the searching or to search for a new

word, select

Keyboard and press OK.

‘ When a word is not found, a message appears.

When the word is found, it is highlighted in the
teletext page.To continue the search, press the

OK key.

Cycle subpages (if available)

Makes the subpages cycle automatically.
Press the cursor right to activate and to de­activate again.

Timed page

To display a specific page from a selected TV
channel at a certain time.

& Press the cursor right and select Ye s or No.
é Enter the time and pagenumber with the

cursor keys or the digit keys.

Note:Teletext does not have to remain switched on,
but you should watch the TV channel you have
selected the specific page from.

“ Press the cursor left to return to the TV menu

again.

Language

If the displayed characters on screen do not
correspond with the characters used by the
teletext broadcaster, you can change the
language group here.
Select

Group 1 or Group 2 with the cursor

right.

Press the

MENU TV key to leave the Teletext

menu.

28

102 mo 08 may 17:08:39

TELETEXT

BBC1

Red Green Yellow Blue

puck

Cancel Accept
Space Delete

ABCDEFG 1 2 3
HIJKLMN 4 5 6
OP QRSTU 7 8 9
V W X Y Z 0

Shift Special

WORD
NAME
FOOTBALL

24571.1 en.qxd 31-08-2005 11:59 Pagina 28

29

English

There is a wide range of audio and video equipment that can be connected to your TV.
The following connection diagrams show you how to connect them.

Note:

EXT1 can handle CVBS, RGB and Audio L/R;
EXT2 CVBS,Y/C, RGB and Audio L/R;
EXT3 CVBS and Audio L/R;
DVI can handle VGA, SVGA, XGA and 480p, 576p, 720p, 1080i and 1152i

Side can handle CVBS, S-VIDEO and Audio L/R.

It is preferable to connect peripherals with RGB output to

EXT1 or EXT2 as RGB provides a better picture quality.

Note: If your recorder is provided with the EasyLink function, it should be connected to

EXT2 to benefit from the

EasyLink functionality.

EXT2 EXT1 DVIAUDIO

AUDIO

OUT

CENTRE

SUBW

IN

ANTENNA

R

L

R

L

EXT3

Camera, Camcorder or Game

& Connect your camera, camcorder or Game as shown.
é Connect to VIDEO 2 and AUDIO L 3 for mono

equipment. For stereo equipment also connect

AUDIO R 3.

S-VHS quality with an S-VHS camcorder is obtained by
connecting the S-VHS cables with the

S-VIDEO input 1 and

AUDIO inputs 3.

Do not connect cable 1 and 2 at the same time.This may cause
picture distortion !

Headphone

& Insert the plug into the headphone socket L as shown.
é Press ¬ on the remote control to switch off the internal

loudspeakers of the TV.

The headphone impedance must be between 8 and 4000 Ohm.The
headphone socket has a 3.5 mm jack.

In the Sound menu select

Headphone volume to adjust the

headphone volume.

VIDEO

3

2

1

S•VIDEO

AUDIO

Connect Peripheral Equipment

Equipment to connect to the side connections

24571.1 en.qxd 31-08-2005 11:59 Pagina 29

30

Note: Do not place your recorder too close to the screen as some recorders may be susceptible for signals from the
display. Keep a minimum distance of 0,5 m from the screen.

Connect the aerial cables 1, 2 and, to obtain the optimum picture quality, eurocable 3 as shown.
If your recorder does not have a euroconnector, the only possible connection is via the aerial cable.You
will therefore need to tune in your recorder’s test signal and store the test signal under a programme
number between 90 and 99, see Manual installation, p. 18.
See the handbook of your recorder.

Decoder and Recorder

Connect a eurocable 4 to your decoder and to the special euroconnector of your recorder. See also
the recorder handbook.
See Decoder, p.21. You can also connect your decoder directly to

EXT1 with a eurocable.

RECORDER DECODER

4

1

2

3

EXT2

CABLE

Recorder (VCR-DVD+RW)

24571.1 en.qxd 31-08-2005 11:59 Pagina 30

31

English

& Connect the aerial cables 1, 2 and 3 as shown (only if your peripheral has TV aerial in-/output).

Connect your recorder to

EXTERNAL 2 with a eurocable 5.

Connect the other equipment with a eurocable 4 to one of the euroconnectors

EXTERNAL 1 or

EXTERNAL 3 to obtain a better picture quality.

If your recorder does not have a euroconnector, the only possible connection is via the aerial cable.
You will therefore need to tune in your recorder’s test signal and store the test signal under a
programme number between 90 and 99, see Manual installation, p. 18. See the handbook of your
recorder.

é Make a selection in the Setup, Source menu, p. 21.

CABLE

EXTERNAL

CABLE

1

2

RECORDER

4

3

5

Recorder and other equipment

24571.1 en.qxd 31-08-2005 11:59 Pagina 31

32

DIGITAL
AUDIO
OUT

AUDIO

OUT

CENTRE

IN

3

& Connect the audio cable to the MultiChannel Surround receiver and to AUDIO OUT L and R at the

bottom of your TV 1.

é If you want the loudspeakers of your TV to act as centre speaker, also connect an audiocable to the

multi channel Surround receiver and to the

CENTRE IN at the bottom of your TV 2.

“ Select Centre Input On in the Source menu. See p. 21.

Digital sound

& Connect your Digital MultiChannel Surround receiver also to the DIGITAL AUDIO OUT connector

3 to have digital sound being reproduced.

é Digital sound will be reproduced if the selected digital channel is broadcasted with AC3 sound

transmission.

“ Select AC3 in the digital Setup menu, Preferences, Digital Audio Output. See p. 11.
‘ Select Digital Audio input on your digital MultiChannel Surround receiver.

Warning:
If no

AC3 signal is transmitted, there will be no sound on the digital audio out output.

Note: No sound will be heard when a TV channel or external source is locked via the Features/Child lock menu
(see p. 26).

MultiChannel Surround receiver

24571.1 en.qxd 31-08-2005 11:59 Pagina 32

33

English

The DVI connector allows the following TV and monitor display modes, via the v key on the remote
control, for High Definition (HD) and computer (PC) equipment:

HD

Standard Definition TV (SDTV) 640x480i

720x576i

Enhanced Definition TV (EDTV) 640x480p

720x576p

High Definition TV (HDTV) 1920x1080i

1280x720p

PC VGA 640x480 60 Hz

SVGA 800x600 60 Hz
XGA 1024x768 60 Hz (not for 42PF9967D)

Note: If necessary, you can adjust the picture position to the centre of the screen with the cursor keys.

& Connect your equipment to the DVI connector of your TV 1.

According to the type of connector of your equipment, you may have to use an appropriate adapter.

DVD

Connect the DVI to DVI cable to the DV I connector of your TV 1.

Computer (PC):

- with a DVI connector: connect the DVI to DVI cable to the DVI connector of your TV 1.

- with a VGA connector: connect the VGA cable to a VGA to DVI adapter 4 and connect to the

DVI

connector of your TV 1.

é Connect the audio cable 2 to the DVIAUDIO R (right) and L (left) inputs of the TV when the TV

expects analogue audio for a connected peripheral equipment to come from an analogue audio input

OR

Connect the audio cable 3 to one of the DIGITAL AUDIO IN connectors of the TV when the TV
expects digital audio for a connected peripheral equipment to come from a digital audio input.
Then also make your selection of the source to which the peripheral equipment with digital audio
input has been connected in the Setup, Source menu, p. 21.

....

....

DVI

CENTRE IN

1

2

3

R
L

AUDIO

DVI

VGA

4

Equipment to connect to a DVI connector

24571.1 en.qxd 31-08-2005 11:59 Pagina 33

34

To enhance the sound reproduction of your TV you can connect an externally powered subwoofer
(between 20 and 250 Hz).

& Connect the audio cable of the external subwoofer to the SUBWOOFER socket at the rear of your

TV.

é Select Subwoofer in the Setup, General menu, p. 20.
“ Adjust the frequency of the external subwoofer to 100-120 Hz (according to your personal

preference) if present on the subwoofer.

‘ Adjust the volume level of the external subwoofer, presumed this control is present on the subwoofer.

See also the instruction manual of the external subwoofer.

A common interface is available to connect a CAM (Conditional Access Module) and a SmartCard.
Please contact your service provider to get more information about these modules.

Note:The television should always be switched off before any module is inserted in the common interface slot.

Common Interface

Connect extra subwoofer

24571.1 en.qxd 31-08-2005 11:59 Pagina 34

SUBWOOFER

COMMON INTERFACE

35

English

The recorder or DVD can be operated with the remote
control via the

Recorder or DV D menu on screen.

& Press the MENU TV key on the remote control.
é Select the Recorder or DVD menu with the cursor

up/down.

“ Press the cursor left/right, up/down to select one of

the recorder or DVD functions.

The key ® for recording can be operated in the TV
mode.
If your EasyLink recorder has the system standby
function, when you press the B key for 3 seconds, both
TV and the recorder are switched to standby.

Òp‡π † Ï

Rwd Play Stop Play Ffw Eject

Recorder

Òp ‡ π † Ï

Prev. Play Stop Play Next Eject

DVD

Press the v key on the remote control repeatedly to
select

EXT1, EXT2, EXT3, Side or DVI according to

where you connected your equipment.

Remark : Most equipment (decoder, recorder) carries out the
switching itself, when it is switched on.

DVD/R SAT TV VCR AUX

Ò

®

‡

π

º

†

®

Select

b

A/D

B

v

To select connected equipment

Recorder or DVD with EasyLink

24571.1 en.qxd 31-08-2005 11:59 Pagina 35

36

This system remote control operates the following Philips equipment:TV,
VCR, DVD, DVD/R, SAT (RC5/RC6),AMP (+TUNER), CD, CD/R.

Press the

Select key to operate any of the equipment indicated in the

display
(

AUX = CD, CDR,VCR; DVD/R = DVD, SAT = SAT (RC5).Another device

can be selected by pressing

Select repeatedly within 2 seconds.The led will

blink slowly to indicate the device.
Press one of the keys on the remote control to operate the peripheral
equipment.
To r eturn to TV mode press

Select while the led is blinking.

When no action is taken within 60 seconds, the remote goes back to TV
mode.

When you do not want the remote to go back to TV mode, and to stay in
the mode selected, proceed as follows:
Select the desired mode with the

Select key. Wait until no LED is lit. Press

the

Select key again simultaneously with the OK key for at least 2 seconds.

The remote will not go back to TV mode from now on and will remain in
the mode selected.
To go back to the default setting of the remote (TV mode) repeat what is
explained above, selecting the TV mode.

Note:When the

Select key is pressed and held for more than 2 seconds, the

RC5/RC6 system select command is transmitted.

MODEON/OFF

Ambilight

+

-

+

-

DVD/R SAT TV VCR AUX

MENU MENU

123

456

789

0

Ò

®

‡

π

º

†

®

®

®

®

OPTIONS

MHEG

CANCEL

Select

DIGITAL

b

q

h

b

æ

j

i

0

A/D

TV

DIGITAL

OK

B

v

¬

P

V

B to switch to standby
ºæ for pause (

VCR, DVD, CD)

RDS news/TA (AMP);
to shuffle play (

CD/R)

® for record
Ò for rewind (

VCR, CD);

search down (

DVD , AMP)

‡ for stop
π for play
† for fast forward (

VCR, CD);

search up (

DVD ,AMP)

b RDS display (

AMP);

to select your choice of
subtitle language (

DVD );

i display information

MENU TV to switch the menu

on or off

- P + for chapter, channel, track

selection
0 to 9 digit entry
0 tape index (

VCR),

select a DVD title/chapter,

select a frequency (

AMP)

cursor up/down

to select the next or the

previous disc (

CD)

cursor left/right

to select the previous or

following track (

CD)

search up/down (

AMP)

Additionally the DVD/R, SAT and AUX indicator
can be programmed to operate the DVD-R, DVD +
receiver, DVD-R + receiver, SAT (RC6), CD-R and
VCR instead.

& Select TV with the Select key.
é To program

•DVD-R,press the OK key + digit 2;

•

SAT (RC6),press the OK key + digit 4;

•

CD-R,press the OK key + digit 6;

•

DVD + receiver,press the OK key + digit 7;

•

DVD-R + receiver,press the OK key + digit 8;

•

VCR,press the OK key + digit 9.

“ Select the corresponding DVD/R, SAT, AUX

indicator. The remote control will operate your
DVD-R, DVD or DVD-R in combination with a
receiver (

DVD/R), SAT (RC6) (SAT), CD-R or

VCR (

AUX).

Note:To return to the modes programmed in the
factory, either remove the batteries for a few
minutes, or press the

OK key + digit 1 (DVD

mode); or + digit 3 (SAT-RC5) or + digit 5 (CD
mode).

Audio- and video equipment keys

24571.1 en.qxd 31-08-2005 11:59 Pagina 36

37

English

Symptoms Items to Check and Actions to follow

Poor Picture •Have you selected the correct TV system in the manual installation menu?

• Is your TV or house aerial located too close to loudspeakers, non-earthed audio
equipment or neon lights, etc?

• Mountains or high buildings can cause double pictures or ghost images.
Sometimes you can improve the picture quality by changing the direction of the
aerial.

• Is the picture or teletext unrecognisable? Check if you have entered the correct
frequency. See Installation, Manual installation, p. 18.

•Are brightness, sharpness and contrast out of adjustment?
Select Factory settings in the Setup, General menu, p. 20.

No Picture •Are the supplied cables connected properly ? (The aerial cable to the TV, the

other aerial to your recorder, the VGA cables to the display, the power cables.)

• Has the child lock been switched off ?

• Is your PC switched on ?

• Do you see a black screen and the indicator in front of the TV lights up blue,
this means that the display mode is not supported. Switch your VGA-source to
a correct display mode.

• In case of weak or bad signal, consult your dealer.

Digital distortion The low quality of some digital picture material may be the cause of digital image

distortion. In this case select the Soft setting using the Picture menu, Smart
Picture, without changing the picture settings manually.

No sound • No sound on any channel? Check the volume isn’t at minimum.

• Is the sound interrupted with the mute key ¬?

No solution found Switch your TV off and then on again once. Never attempt to repair a defective
for your picture or TV yourself. Check with your dealer or call a TV technician.
sound problem ?

Scanning has failed

(After checking the installation/signal from aerial) Either:

•Your aerial is not pointing properly at the digital TV transmitter;

•Your aerial installation needs to be upgraded:

•You are not in the coverage area to correctly receive digital television.

For a proper diagnosis, call our electrical retailer.

Remote control • Check if the remote control is in the correct mode.

• If your TV no longer responds to the remote control, the batteries may be dead.

•You can still use the

MENU key and the -/+ keys on the right side of your TV.

Standby Your TV consumes energy in the standby mode. Energy consumption contributes

to air and water pollution. Power consumption: 2 W.

No stable or not Check if you have selected the correct VGA mode in your PC.
synchronised VGA

Before calling service

24571.1 en.qxd 31-08-2005 11:59 Pagina 37

38

Warning concerning stationary images on the TV screen

A characteristic of Plasma Display Panels is that displaying the same image for a long time can
cause a permanent after-image to remain on the screen.This is called phosphor burn in.
Normal use of the TV should involve the showing of pictures that contain constantly moving and
changing images that fill the screen.

Examples of stationary images (this is not an all-inclusive list, you may encounter others in your
viewing):

•

TV and DVD menus: listings of DVD disk content;

•

Black bars: when black bars appear at the left and right side of the screen, it is recommended

to change to a picture format so that the picture fills the entire screen;

•

PIP and Multipip: do not view for long periods of time using the PIP function or Multipip

function;

•

TV channel logo:present a problem if they are bright and stationary. Moving or low-contrast

graphics are less likely to cause uneven aging of the screen;

•

Stock market stickers:presented at the bottom of the TV screen;

•

Shopping channel logos and pricing displays: bright and shown constantly or repeatedly in

the same location on the TV screen.
Examples of still pictures also include logos, computer images, time display, teletext and images
displayed in 4:3 mode, static images or characters, etc.

Notes:

- reduce contrast and brightness when viewing

- once burn-in occurs it will never disappear completely.

21 . . . . . . . . . . . . . . 474000

22 . . . . . . . . . . . . . . 482000

23 . . . . . . . . . . . . . . 490000

24 . . . . . . . . . . . . . . 498000

25 . . . . . . . . . . . . . . 506000

26 . . . . . . . . . . . . . . 514000

27 . . . . . . . . . . . . . . 522000

28 . . . . . . . . . . . . . .530000

29 . . . . . . . . . . . . . . 538000

30 . . . . . . . . . . . . . . 546000

31 . . . . . . . . . . . . . . 554000

32 . . . . . . . . . . . . . . 562000

33 . . . . . . . . . . . . . . 570000

34 . . . . . . . . . . . . . . 578000

35 . . . . . . . . . . . . . . 586000

36 . . . . . . . . . . . . . . 594000

37 . . . . . . . . . . . . . . 602000

38 . . . . . . . . . . . . . . 610000

39 . . . . . . . . . . . . . . 618000

40 . . . . . . . . . . . . . . 626000

41 . . . . . . . . . . . . . . 634000

42 . . . . . . . . . . . . . . 642000

43 . . . . . . . . . . . . . . 650000

44 . . . . . . . . . . . . . . 658000

45 . . . . . . . . . . . . . . 666000

46 . . . . . . . . . . . . . . 674000

47 . . . . . . . . . . . . . . 682000

48 . . . . . . . . . . . . . . 690000

49 . . . . . . . . . . . . . . 698000

50 . . . . . . . . . . . . . . 706000

51 . . . . . . . . . . . . . . 714000

52 . . . . . . . . . . . . . . 722000

53 . . . . . . . . . . . . . . 730000

54 . . . . . . . . . . . . . . 738000

55 . . . . . . . . . . . . . . 746000

56 . . . . . . . . . . . . . . 754000

57 . . . . . . . . . . . . . . 762000

58 . . . . . . . . . . . . . . 770000

59 . . . . . . . . . . . . . . 778000

60 . . . . . . . . . . . . . . 786000

61 . . . . . . . . . . . . . . 794000

62 . . . . . . . . . . . . . . 802000

63 . . . . . . . . . . . . . . 810000

64 . . . . . . . . . . . . . . 818000

65 . . . . . . . . . . . . . . 826000

66 . . . . . . . . . . . . . . 834000

67 . . . . . . . . . . . . . . 842000

68 . . . . . . . . . . . . . . 850000

69 . . . . . . . . . . . . . . 858000

Digital Frequency

Channel

Nominal Centre

Frequency KHz

Digital Frequency

Channel

Nominal Centre

Frequency KHz

Centre Frequencies Table (in KHz)

24571.1 en.qxd 31-08-2005 11:59 Pagina 38
