Philips 7000 series
LED TV
123cm (49")
4K ULTRA HD
SmartTV
49PUT7692
Look beyond the ordinary.
Philips 4K LED TV packed with features. It combines the stunning borderless design, Ultra
HD details, easy connectivity and ultra slim dimensions for an entertainment experience
like never before.
Discover life-like clarity
•4K ULTRA HD
•Pixel Plus ULTRA HD
•SmartTV
• 240Hz Perfect Motion Rate (PMR) for superb motion sharpness
Experience immersive sound
• Feel the power of 20 W(2x 10W) RMS
Open up a world of entertainment
• Seamless connectivity with 3 HDMI inputs
• MHL technology for enjoying mobile content on big screen
• Fantastic video, photo and music playback via USB
Page 2
49PUT7692/V7
LED TV
123cm (49") 4K ULTRA HD, SmartTV
Highlights
4K ULTRA HD
Ultra HD TV has 4 times the resolution of a
conventional Full HD TV. With over 8 million
pixels and our unique Pixel Plus Ultra HD
engine, you'll experience improved images,
sharpness, increased depth perception,
superior contrast, smooth natural motion and
flawless details.
Pixel Plus ULTRA HD
240Hz PMR
240Hz Perfect Motion Rate (PMR) creates
extreme motion sharpness for clear and
vibrant images in fast action movies. The new
Philips PMR standard shows the combined
visible effect of the fastest panel refresh rate,
HD Natural Motion and unique processing
formula, for unprecedented motion sharpness.
Rich & clear sound experience
back of the TV you can connect multiple HD
sources, for instance an HD settop box, a Bluray player, and Game Console or Digital
Camcorder."
MHL
Mobile High Definition Link (MHL) is a mobile
audio/video interface for directly connecting
mobile phones and other portable devices to
high-definition displays/ TVs. An optional MHL
cable allows you to simply connect your MHL
capable mobile device to this large Philips MHL
LED TV, and watch your HD videos come to
life with full digital sound. Now not only you
can enjoy your mobile games, photos, movies,
or other apps on its big screen, you can
simultaneously charge your mobile device so
you never run out of power half way.
Pixel Plus ULTRA HD engine to deliver
incredible image, depth and clarity
SmartTV
Explore and enjoy the world of apps and more,
directly on your TV.
"Feel the power of the music beat and the
atmosphere of the movies. The powerful 20 W
RMS (2 x 10 W RMS) amplifiers create a lifelike
soundstage. It gives a clear and spacious sound
stage complementary to the rich viewing
experience.."
3 HDMI inputs
"HDMI makes an uncompressed digital RGB
connection from the source to the screen for
the ultimate picture quality. HDMI uses HDCP
copy protection. With 2 HDMI inputs on the
USB with Video Playback
The USB connector allows access to jpeg
photos, mp3 music and video files through USB
drives. Plug the USB into the slot at the side of
the TV and access multimedia content using
the easy on screen content browser. Now
view your videos, photos and music effortlessly
in your TV!
Page 3
49PUT7692/V7
LED TV
123cm (49") 4K ULTRA HD, SmartTV
Specifications
Picture/Display
• Diagonal screen size (inch): 49 inch
• Panel resolution: 3840x2160
• Picture enhancement: Pixel Plus Ultra HD, 3D
mbfilter, Digital Noise Reduction
Co
Sound
• Output power (RMS): 20W
• Sound System: Stereo
• Sound Enhancement: Auto Volume Leveller
Connectivity
• Number of HDMI connections_: 3
• Number of USB connections: 3
• Number of AV connections: 2
• AV output: Ext 3.5 mm jack x1
• Other connections: Componen
inpu
t, PC-In VGA, Antenna IEC75, S/PDIF out
(coaxial), PC Audio in
• EasyLink (HDMI-CEC): EasyLink
• LAN wired: Ethernet (RJ 45) 1x
• LAN wireless: IEEE 802.11 b/g/n
t Video (YPbPr)
Supported Display Resolution
• Computer formats
Resolution Refresh rate
Via HDMI/DVI
input
40 x 2160 30Hz
38
1920 x 1080 60Hz
1366 x 768 60Hz
1280 x 1024 60Hz
1280 x 720 60Hz
1024 x 768 60Hz
800 x 600 60Hz
720 x 480 60Hz
640 x 480 60Hz
deo formats
• Vi
Res
olution Refresh rate
2160p 24Hz, 30Hz
1080p 60Hz
1080p 50Hz
1080i 50, 60Hz
720p 50, 60Hz
576p 50Hz
576i
0p 60Hz
48
480i 60Hz
50Hz
Loudspeakers
• Built-in speakers: 2
Power
• Power consumption: 130 W
• Power supply: 100-240VAC, 50/60Hz
• Standby power consumption: Less than 1 watt
USB - Container
• Video: ASF, AVI, MKV, MP4, PS
USB - File Extension
• Video: *.avi, *.mkv, *.mov, *.mp4, *.mpg, *.mpeg,
*.wmv
USB - Video Decoder
• Compression Format: H.264, MPEG 1, MPEG 2,
MPEG 4
Multimedia Applications
• Music Playback Formats: MP3, WMA (v2 up to
v9.2)
• Picture Playback Formats: JPEG
• Playback Formats: AVI, JPEG Still pictures, MPEG1,
2, MPEG4
MPEG
MPEG-4 AVC, PNG still pictures
, WMA v2 up to v9.2, H.264/
Tuner/Reception/Transmission
• Video Playback: NTSC, PAL, SECAM
• Tuner bands: UHF, VHF
• TV system: PAL B/G
Dimensions
• Product weight (+stand): 12.8 kg
• Product weight: 12.4 kg
• Set dimensions (W x H x D): 1099 x 644 x 56 mm
• Set dimensions with stand (W x H x D):
99
x 693 x 238 mm
10
Accessories
• Included accessories: 2 x AAA Batteries, Remote
Control, User Manual, Warranty certificate, Power
cord, Safety/legal instructions, Table top stand,
Wall mounting bracket
• User Manual: English
Convenience
• Ease of Installation: Autostore, Fine Tuning
• Ease of Use: Graphical User Interface, On Screen
Display
On-Screen Display languages: English
•
• Screen Format Adjustments: 16:9
•
Issue date 2017-11-28
Version: 1.0.1
12 NC: 8670 001 48406
EAN: 89 03279 23471 3
© 2017 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
