5011 series

User Manual

32HFL5011T

40HFL5011T

43HFL5011T

49HFL5011T

55HFL5011T

1 TV Tour 3

1.1 Bluetooth Connection 3

2 Setting Up 4

2.1 Read Safety 4

2.2 TV Stand and Wall Mounting 4

2.3 Tips on Placement 4

2.4 Power Cable 4

2.5 Antenna Cable 4

3 Connect your Android TV 6

3.1 Network and Internet 6

4 Connect Devices 10

4.1 About Connections 10

4.2 CAM with Smart Card - CI+ 12

4.3 Receiver - Set-Top Box 13

4.4 Home Theatre System - HTS 13

4.5 Smartphones and Tablets 15

4.6 Blu-ray Disc Player 15

4.7 DVD Player 16

4.8 Headphones 16

4.9 USB Flash Drive 16

4.10 Photo Camera 16

4.11 Camcorder 16

4.12 Computer 17

5 Switching On and Off 18

5.1 On, Standby or Off 18

5.2 Word mark brightness 18

5.3 Keys on TV 18

6 Remote Control 19

6.1 Key overview 19

6.2 IR Sensor 20

6.3 Batteries 20

6.4 Cleaning 20

7 Channels 21

7.1 Watching TV channels 21

7.2 Text / Teletext 22

7.3 Interactive TV 23

8 TV Guide 25

8.1 What You Need 25

8.2 Using the TV Guide 25

9 Home Menu 26

9.1 About the Home Menu 26

9.2 Open the Home Menu 26

10 Sources 27

10.1 Switch to a device 27

10.2 Options for a TV Input 27

10.3 Device Name and Type 27

10.4 Game or Computer 27

10.5 Rescan Connections 28

11 Apps 29

11.1 About Apps 29

11.2 Start or Stop an App 29

12 Internet 30

12.1 Start Internet 30

12.2 Options on Internet 30

13 Videos, Photos and Music 31

13.1 From a USB Connection 31

13.2 Play your Videos 31

13.3 View your Photos 31

13.4 Play your Music 32

14 Smartphones and Tablets 33

14.1 Miracast 33

14.2 MHL 34

15 Settings 35

15.1 Picture 35

15.2 Sound 39

15.3 Eco Settings 42

15.4 General Settings 43

15.5 Clock, Region and Language 44

15.6 Universal Access 47

16 Channel Installation 49

16.1 Antenna/Cable Installation 49

17 Software 51

17.1 Update Software 51

17.2 Open Source Software 51

17.3 Open Source License Statement 51

17.4 Open Source License 51

18 Specifications 85

18.1 Environmental 85

18.2 Power 86

18.3 Operating System 86

18.4 Reception 86

18.5 Display Type 86

18.6 Display Type 86

18.7 Display Input Resolution 86

18.8 Dimensions and Weights 86

18.9 Connectivity 87

18.10 Sound 87

18.11 Multimedia 87

19 Help and Support 89

19.1 Register your TV 89

19.2 Troubleshooting 89

19.3 Online Help 90

19.4 Support and Repair 91

20 Safety and Care 92

20.1 Safety 92

20.2 Screen Care 93

21 Terms of Use 94

21.1 Terms of Use - TV 94

21.2 Terms of Use - Smart TV 94

22 Copyrights 95

22.1 MHL 95

22.2 Ultra HD 95

22.3 HDMI 95

22.4 Dolby Digital Plus 95

22.5 DTS Premium Sound ™ 95

22.6 DLNA Certified® 95

22.7 Microsoft 95

22.8 Wi-Fi Alliance 96

22.9 Kensington 96

22.10 Other Trademarks 96

Index 97

TV Tour

1.1

Bluetooth Connection

Your TV has Bluetooth technology inside. You can connect extra wireless speakers or a wireless

headphone. Forget connecting cables, pairing your device with the TV is enough.

Caution

Setting Up

2.1

Read Safety

Read the safety instructions first before you use the TV.

2.2

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV stand in the Quick Start Guide. The Quick Start Guide can be downloaded from www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.3

Tips on Placement

• Position the TV where light does not shine directly on the screen.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

• 32HFL5011T

VESA MIS-F 100x100, M4

• 40HFL5011T

VESA MIS-F 200x200, M4

• 43HFL5011T

VESA MIS-F 200x200, M6

• 49HFL5011T

VESA MIS-F 400x200, M6

• 55HFL5011T

VESA MIS-F 400x200, M6 Preparation

First remove the 4 plastic screw caps out of the threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESA-compliant bracket, go about 10mm deep inside the threaded bushes of the TV.

2.4

Power Cable

• Insert the power cable into the POWER connector on the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

2.5

Antenna Cable

Insert the antenna plug firmly into the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

Connect your Android TV

3.1

Network and Internet

Installation manual)

Step 3 - Select Wireless and Networks > Connect to network and press OK. Step 4 - Select Connect to network and press OK. Step 5 - Select Wireless and press OK.

Home Network

To enjoy the full capabilities of your Philips Android TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.

Connect to Network

Wireless Connection

What you need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

WPS

If your router has WPS, you can directly connect to the router without scanning for networks. Go to the router, press the WPS button and return to the TV within 2 minutes. Then press Connect to make the connection.

If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

3 - Select Network type > WPS then press OK. 4 - Go to the router, press the WPS button and return

to the TV within 2 minutes.

5 - Select Connect to make the connection. 6 - A message will be shown when the connection is

successful.

HOME and



Make the Connection

Wireless

Follow steps 1 to 5. Step 1 - Make sure that the router of your wireless

network is switched on. Step 2 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to

HOME and select Features and



WPS with PIN Code

If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Wireless and Networks > Settings and press OK. 3 - Select Network type > WPS with PIN code and press OK. 4 - Write down the 8-digit PIN code shown on screen and enter it in the router software on your PC. Consult the router manual on where to enter the PIN

HOME and



code in the router software.

5 - Select Connect to make the connection. 6 - A message will be shown when the connection is

successful.

Problems Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

4 - Select Wireless and Networks > Connect to network and press OK.

5 - Select Wired then press OK. 6 - The TV constantly searches for the network

connection. A message will be shown when the connection is successful.

Network configuration

If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on. Alternatively, if you are an advanced user and want to install your network with static IP addressing, set the TV to Static IP. To set the TV to Static IP:

Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

Select Wireless and Networks > Settings > Network configuration > Static IP. With Static IP selected in the menu, you can set the IP address and other necessary settings in Static IP configuration in the same menu.

HOME and



Wired Connection

What You Need

To connect the TV to the Internet, you need a network router with a connection to the Internet. Use a high-speed (broadband) connection to the Internet.

Make the Connection

To make a wired connection… 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on. 3 - Consumer Mode: On  Press

select Features and press OK.

HOME and



**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

Network Settings

View Network Settings

You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.

To view the current network settings… 1 - Consumer Mode: On  Press  HOME and

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Settings > View Network Settings and

press OK. 4 - Press the menu.

BACK repeatedly if necessary, to close



Network Configuration

If you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP.

4 - Select On to enable Wake on Wi-Fi (WoWLAN) .

5 - Press  BACK repeatedly if necessary, to close the menu.

To set the TV to Static IP… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Settings > Network Configuration and

press OK.

4 - Select Static IP and press OK to enable Static IP Configuration.

5 - Press  BACK to go back to previous level. 6 - Select Static IP Configuration and configure the

connection.

7 - You can set the number for IP Address, Netmask, Gateway, DNS 1, or DNS 2.

8 - Press  BACK repeatedly if necessary, to close the menu.

Switch On with LAN (WoL)

To switch on WoL… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Settings > Wake on LAN (WoL) and

press OK.

4 - Select On to enable Wake on LAN (WoL). 5 - Press  BACK repeatedly if necessary, to close

the menu.

Switch On with Wi-Fi (WoWLAN)

Switch on Wi-Fi connection

You can switch on or off Wi-Fi connection on your TV.

To switch on Wi-Fi… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Connect to Network and press OK. 4 - Select Connect and press OK. 5 - Select Wireless and press OK. 6 - Press  BACK repeatedly if necessary, to close

the menu.

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.

To switch on DMR… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Features > PTA and press OK. 4 - Select Digital Media Renderer - DMR and

press OK.

5 - Select On and press OK. 6 - Press  BACK repeatedly if necessary, to close

the menu.

You can switch this TV on from your smartphone or tablet if the TV is in Standby. The setting Wake On Wi-Fi (WoWLAN) must be switched on.

To switch on WoWLAN… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Settings > Wake on

Wi-Fi (WoWLAN) and press OK.

Switch on Wi-Fi Miracast

Switch on Wi-Fi Miracast to share the screen of your smartphone, tablet or computer on the TV.

To switch on Miracast… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks > Miracast and press OK. 3 - Select Features > Wi-Fi Miracast and press OK.

4 - Select Enable and press OK. 5 - Select Yes and press OK. 6 - Press  BACK repeatedly if necessary, to close

the menu.

Clear Wi-Fi Miracast connection

Clear the list of connected and blocked devices that are used with Miracast.

To clear Miracast connections… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Wireless and Networks and press OK. 3 - Select Features > Wi-Fi Miracast and

press OK. 4 - Select Wi-Fi Miracast Connections > Clear All and press OK. 5 - Press  BACK repeatedly if necessary, to close the menu.

Copy protection

Connect Devices

4.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

All of the HDMI connections on the TV have HDMI ARC (Audio Return Channel).

If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.

Go to www.connectivityguide.philips.com

Antenna port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

HDMI ports

HDMI Quality

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for TV signal.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

HDMI MHL

With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.

The HDMI 4 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).

This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your mobile device will not be charging when the TV is on standby.

Inform yourself about what passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

HDMI CEC - EasyLink

EasyLink

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device.

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

Only devices that support EasyLink Remote Control function will respond to the TV remote

control.

EasyLink On or Off

You can switch EasyLink on or off. The TV comes with the EasyLink settings switched on.

To switch off EasyLink completely… 1 - Consumer Mode:

On  Press

HOME and select Features and



press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Sources > Advanced > EasyLink, and press OK.

3 - Select EasyLink , and press OK. 4 - Select Off and press OK. 5 - Press

BACK, repeatedly if necessary, to close



the menu.

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their respective owners.

Operate Devices

To operate a device connected to HDMI and set up with EasyLink, select the device or its activity in the list of TV connections. Press SOURCES , select a device connected to an HDMI connection and press OK.

Once the device is selected, the TV remote control can control the device. However the keys

HOME and  OPTIONS and some other



TV keys, are not forwarded to the device. If the key you need is not on the TV remote control,

you can select the key in the Options menu. Press  OPTIONS and select Controls in the menu bar. On the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink Remote Control separately.

To switch EasyLink Remote Control on or off… 1 - Consumer Mode:

On  Press

HOME and select Features and



press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Sources > Advanced > EasyLink, and press OK .

3 - Select EasyLink Remote Control and press OK . 4 - Select On or Off and press OK. 5 - Press

BACK, repeatedly if necessary, to close



the menu.

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connection with a DVI to HDMI adapter.

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

Audio Out - Optical

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

Y Pb Pr - Component

Y Pb Pr - Component Video is a high quality connection.

The YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect. Use an Audio L/R cinch cable if your device also has sound.

Audio Out - Optical is a high quality sound connection.

This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In - Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System.

If the sound does not match the video on screen, you can adjust the audio to video synchronisation.

Scart

SCART is a good quality connection. The SCART connection can be used for CVBS and

RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals. The SCART connection also supports NTSC playback.

4.2

CAM with Smart Card - CI+

CI+

This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes,

like movies and sports, offered by digital TV operators in your region. These programmes are scrambled by the TV operator and descrambled with a prepaid CI+ module. Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV operator for more information on terms & conditions.

screens come from the TV operator. Follow the onscreen instruction to look up the PIN code setting.

4.3

Receiver - Set-Top Box

Smart Card

Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes.

Insert the smart card into the CAM module. See the instruction you received from the operator.

To insert the CAM in the TV… 1 - Look on the CAM for the correct method of

insertion. Incorrect insertion can damage the CAM and TV. 2 - While looking at the back of the TV, with the front of the CAM facing towards you, gently insert the CAM into the slot COMMON INTERFACE. 3 - Push the CAM in as far as it will go. Leave it in the slot permanently.

When you switch on the TV, it may take a few minutes before the CAM is activated. If a CAM is inserted and subscription fees are paid (subscription methods can differ), you can watch the scrambled channels supported by the CAM smart card.

Cable Box

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Settop box has no HDMI connection.

The CAM and smart card are exclusively for your TV. If you remove the CAM, you will no longer be able to watch the scrambled channels supported by the CAM.

Passwords and PIN codes

For some CAMs, you must enter a PIN code to watch its channels. When you set the PIN code for the CAM, we recommend you to use the same code you are using to unlock the TV.

To set the PIN code for the CAM…

1 - Press SOURCES . 2 - Select the channel type you are using the CAM

for. 3 - Press  OPTIONS and select Common Interface. 4 - Select the TV operator of the CAM. The following

4.4

Home Theatre System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can

only send the ARC signal to this HDMI connection.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Connect with HDMI

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.

For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out Delay on the TV.

To switch off the Audio Out delay . . . 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced > Audio out delay. 3 - Select Off and press OK. 4 - Press  BACK, repeatedly if necessary, to close

the menu.

Audio Out Offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms.

HOME and select Features and



Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Audio Out Settings

Audio Out Delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is done automatically and always correct.

Audio sync delay

The Audio Out Delay setting should be switched on. To synchronise the sound on the TV… 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced > Audio out offset. 3 - Use the slider bar to set the sound offset and

press OK. 4 - Press the menu.

Audio Out Format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio Out Format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

To set Audio Out Format…



HOME and select Features and



BACK, repeatedly if necessary, to close

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced > Audio out format. 3 - Select Multichannel or Stereo. 4 - Press

the menu.

Audio Out Levelling

Use the Audio Out Levelling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume… 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced > Audio out levelling.

3 - If the volume difference is large, select More. If the volume difference is small, select Less. 4 - Press the menu.

Audio Out Levelling affects both the Audio Out Optical and HDMI ARC sound signals.



HOME and select Features and



BACK, repeatedly if necessary, to close

HOME and select Features and



BACK, repeatedly if necessary, to close

If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an HDMI ARC connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections.

• Check if you connected the HDMI cable to an HDMI ARC connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections.

• Check if the HDMI ARC setting on the TV is switched On. 1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual) 2 - Select Sound > Advanced > HDMI ARC.

4.5

HOME and select Features and



HOME and select Features and



Smartphones and Tablets

To connect a smartphone or tablet to the TV, you can use a wireless or wired connection.

Wireless

For a wireless connection, on your smartphone or tablet download the Philips TV Remote App from your favourite app store.

Note: Philips TV Remote App can only be used by making connection to TV. Use function in Features to make the connection.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the Audio Out Format of the TV to Stereo (uncompressed).

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced > Audio out format. No sound

HOME and select Features and



Wired

For a wired connection, use the HDMI 4 MHL connection on the back of the TV.

4.6

Blu-ray Disc Player

Use a High speed HDMI cable to connect the Bluray Disc player to the TV.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

4.9

USB Flash Drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

4.7

DVD Player

Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable, if the device has no HDMI connection.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

4.8

Headphones

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press SOURCES and select USB.

To stop watching the USB flash drive content, press TV or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

4.10

Photo Camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.

If the contents list does not appear automatically, press SOURCES , and select USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

4.11

Camcorder

HDMI

For best quality, use an HDMI cable to connect the camcorder to the TV.

Audio Video LR / Scart

You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.

4.12

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Switching On and Off

2 - Select Eco Settings > Philips Wordmark and press OK. 3 - Select Maximum, Medium, Minimum or select Off to switch off the lighting of the word mark. 4 - Press  BACK, repeatedly if necessary, to close the menu.

5.1

On, Standby or Off

Make sure the TV is connected to the mains AC power. Connect the supplied power cord to the AC in connector at the back of the TV. The indicator light at the bottom of the TV lights up.

Switch on

Press  on the remote control to switch the TV on. Alternatively, press  HOME. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.

In standby mode, the TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

*Only available for certain TV models

5.3

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu. 2 - Press left or right to select  Volume, Channel or  Sources. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. 4 - The menu will disappear automatically.

To switch the TV on standby, select  and press the joystick key.



5.2

Word mark brightness

You can switch off or adjust the brightness of the Philips logo on the front of the TV.

To adjust or switch off… 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

HOME and select Features and



HOME and select Features and



Remote Control

6.1

Key overview

Top

1 -  Standby / On

To switch the TV on or back to Standby. 2 -  ALARM

To set the alarm. 3 -

To select one of the picture style. 4 -  LIST

To open the channel list.

5 - SOURCES To open or close the Sources menu.

6 To open the Sleep Timer list.

7 To select one of the sound style.

8 To switch on mychoice.

9 -  TV GUIDE To open or close the TV Guide.

PICTURE STYLE



SLEEP



SOUND STYLE



MY CHOICE



1 To open the smart information page.

2 Direct selection of options. Blue key , opens Help.

3 -  INFO To open or close programme info.

4 -  BACK To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.

5 - TV To switch back to watching TV. To leave an interactive TV application.

6 -  APPS To open the App gallery.

7 -  OPTIONS To open or close the Options menu.

8 - OK key To confirm a selection or setting.

9 - Arrow / navigation keys To navigate up, down, left or right.

10 -  HOME To open the Home menu.

SMART INFO



   

Colour keys

10 -  SETTINGS To open the Frequent Settings menu and All Settings.

Middle

Bottom

the arrow. 2 - Replace the old batteries with 2 type AAA-R03-1.5V batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and slide it back until it clicks.

Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

6.4

Cleaning

1 -

To adjust the volume level. 2 - Number keys

To select a channel directly. 3 - SUBTITLE

To switch Subtitles on, off or on during mute. 4 -  CLOCK

To display the clock. 5 -  Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext. To start the next or previous chapter on a disc.

6 To mute the sound or to restore it.

7 - TEXT To open or close Text/Teletext.

6.2

Volume





Mute

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

IR Sensor

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

6.3

Batteries

If the TV does not react on a key press on the remote control, the batteries might be empty.

To replace the batteries, open the battery compartment on the back of the remote control.

1 - Slide the battery door in the direction shown by

Channels

7.1

Watching TV channels

Guest Menu. (For professional mode information, please refer to Installation manual)

2 - Select Channels > Channel settings > Enable Channel logos and press OK.

3 - Select No and press OK. 4 - Press

the menu.

BACK, repeatedly if necessary, to close



Switch channels

To watch TV channels, press TV. The TV tunes to the TV channel you last watched.

Alternatively, press  HOME to open the Home menu and press  to select the desired channel.

To switch channels, press the channel number, type in the number with the number keys. Press OK after you entered the number to switch channels.

To switch back to the previously tuned channel, press

BACK.



To switch to a channel from a channel list

While watching a TV channel, press  LIST to open the channel grid.

The channel grid can have several pages with channels. To view the next or previous page, press To close the channel lists without switching channels, press  LIST again.

Radio channels

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel.

 

 

 

. If you know

 

Options for channels

While watching a channel, depending on the type of channel (analogue or digital) you are watching or depending on the TV settings you made, some options are available.

Open the options menu While watching a channel, press OPTIONS.

Universal access

With Universal access switched on, you can set some options for hearing impaired and visually impaired people.

Video selection

Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or angles of the same event or different programmes on one TV channel. The TV shows a message if any such TV channels are available.

Subtitles

Channel list

Channel list views

In the channel lists, you can find all installed TV and radio channels.

Next to the channel list All, which holds all installed channels where you can view the installed Radio stations separately or discover the newly added channels in New.

Channel logos

In some countries, the TV can show the channel logos. If you do not want these logos to appear, you can switch them off. To switch off Channel logos . . .

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in

HOME and select Features and



Switch Subtitles on or Subtitles off with this options. Select Automatic to show subtitles only when the sound is muted with .

Subtitle language

For digital broadcast, you can select an available subtitle language temporarily if none of your preferred languages are available.

Audio languages

For digital broadcast, you can select an available audio language temporarily if none of your preferred languages are available.

Dual I-II

If an audio signal contains two audio languages but one language — or both — has no language indication, this option is available.

Common interface

If prepaid premium content is available from a CAM, you can set the provider settings with this option.

HbbTV on this channel

You can block the HbbTV pages from a channel that offers HbbTV.

Status

Select Status to view technical information on the channel (if it is analogue or digital) or a connected device you are watching.

Enables the user to communicate his activity with his social networks (such as Twitter or email).

*For Smart TVs only.

1 - Enter the page number with the number keys. 2 - Use the arrow keys to navigate. 3 - Press a colour key to select a colour-coded

subject at the bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The subpage numbers are shown on a bar next to the main page number. To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text. To open T.O.P. Text pages within Text, press  OPTIONS and select T.O.P. overview.

Favourite pages

Picture format

If black bars appear on top and bottom or on both sides of the picture, you can adjust the picture format to a format that fills the screen.

To change the picture format . . . 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Picture Format and press OK. 3 - Select a format from the list and press OK. 4 - Press

the menu. The following format can be available according the

picture on screen . . .

• Fill screen

• Fit to screen

• Super zoom

• Movie expand 16:9

• Wide screen

• Unscaled

• 4:3

7.2

HOME and select Features and





HOME and select Features and



BACK, repeatedly if necessary, to close

Text / Teletext

Text Pages

To open Text/Teletext press TEXT, while you are watching TV channels. To close Text, press TEXT again.

The TV makes a list of the last 10 Text pages you opened. You can easily reopen them again in the Favourite Text pages column.

1 - In Text, select the star in the top left corner of the screen to show the column of favourite pages. 2 - Press  (down) or  (up) to select a page number and press OK to open the page. You can clear the list with the option Clear favourite

pages. Search Text

You can select a word and scan Text for all occurences of this word.

1 - Open a Text page and press OK. 2 - Select a word or number with the arrow keys. 3 - Press OK again to jump immediately to the next

occurence of this word or number. 4 - Press OK again to jump to the subsequent occurence. 5 - To stop searching, press  (up) until nothing is selected.

Text from a connected device

Some devices that receive TV channels can also offer Text. To open Text from a connected device . . .

1 - Press SOURCES, select the device and press OK. 2 - While watching a channel on the device, press  OPTIONS , select Show device keys and select the  key and press OK.

3 - Press 4 - To close Text, press

Digital Text (UK only)

Some digital broadcasters offer dedicated Digital Text or interactive TV on their digital TV channels. This includes normal Text using the number, colour and arrow keys to select and navigate.

BACK to hide the device keys.



BACK again.



Select a Text page

To select a page . . .

To close Digital Text, press



BACK.

Text Options

the menu.

In Text/Teletext, press following…

• Freeze page To stop the automatic rotation of subpages.

• Dual screen / Full screen To show the TV channel and Text alongside each other.

• T.O.P. overview To open T.O.P. Text.

• Enlarge To enlarge the Text page for comfortable reading.

• Reveal To unhide hidden information on a page.

• Cycle subpages To cycle subpages when these are available.

• Language To switch the group of characters that Text uses to display correctly.

• Text 2.5 To activate the Text 2.5 for more colours and better graphics.

OPTIONS to select the



7.3

Interactive TV

About iTV

With interactive TV, some digital broadcasters combine their normal TV programme with information or entertainment pages. On some pages, you can respond to a programme or vote, do online shopping or pay for a video-on-demand programme.

HbbTV, MHEG, . . .

Broadcasters use various interactive TV systems : HbbTV (Hybrid Broadcast Broadband TV) or iTV (Interactive TV - MHEG). Interactive TV is sometimes referred to as Digital Text or Red button. But each system is distinct.

Visit the broadcaster's Internet website for more information.

Text Setup

Text language

Some digital TV broadcasters have several Text languages available. To set your primary and secondary Text language . . .

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Region and Language and press OK. 3 - Select Languages > Primary

Text or Secondary Text and press OK.

4 - Select your preferred Text languages. 5 - Press

the menu.

Text 2.5

If available, Text 2.5 offers more colours and better graphics. Text 2.5 is activated as a standard factory setting. To switch off Text 2.5…

1 - Press TEXT. 2 - With Text/Teletext open on screen,

press  OPTIONS.

3 - Select Text 2.5 > Off. 4 - Press  (left) repeatedly if necessary, to close



HOME and select Features and



BACK repeatedly if necessary, to close

What You Need

Interactive TV is only available on digital TV channels. To enjoy the full benefits of Interactive TV, you need a high-speed (broadband) Internet connection to the TV.

HbbTV

If a TV channel offers HbbTV pages, you must first switch on HbbTV in the TV settings to view the pages.

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Channels > Channel settings > Enable Hbb TV and press OK.

3 - Select Yes. 4 - Press

the menu. If you want to avoid access to HbbTV pages on a

specific channel, you can block the HbbTV pages for this channel only.

1 - Tune to the channel of which you want to block the HbbTV pages. 2 - Press  OPTIONS and select HbbTV on This Channel. 3 - Select Off.



HOME and select Features and



BACK repeatedly if necessary, to close

Use iTV

Open iTV pages

Most channels that offer HbbTV or iTV invite you to press the colour key  (red) or OK key to open their interactive programme.

Navigate iTV pages

You can use the arrow and colour keys, the number keys and the  BACK key to navigate the iTV pages.

Digital Text (UK only)

To open Digital Text, press TEXT. To close, press

Close iTV pages

Most iTV pages inform you which key to use to close. To force an iTV page to close, switch to the next TV channel and press .



BACK.

Search by Genre

TV Guide

8.1

What You Need

With the TV Guide you can view a list of the current and scheduled TV programmes of your channels. Depending on where the TV guide information (data) is coming from, analogue and digital channels or only digital channels are shown. Not all channels offer TV Guide information.

The TV can collect TV Guide information for the channels that are installed on the TV. The TV cannot collect the TV Guide information for channels viewed from a digital receiver or decoder.

8.2

Using the TV Guide

Open the TV Guide

If the information is available, you can look up scheduled programmes by genre like movies, sports, etc.

To search for programmes by genre…

1 - Press  TV GUIDE. 2 - Press  OPTIONS. 3 - Select Search by Genre and press OK. 4 - Select the genre you want and press OK. A list

with the found programmes appears. 5 - You can set reminders or schedule a recording on a selected programme. 6 - Press  BACK, repeatedly if necessary, to close the menu.

To open the TV Guide, press  TV GUIDE. The TV Guide shows the channels of the selected tuner.

Press  TV GUIDE again to close. The first time you open the TV Guide, the TV scans all

TV channels for programme information. This may take several minutes. TV Guide data is stored on TV.

Tune to a Programme

From the TV Guide, you can tune to a current programme.

To switch to the programme (channel), select the programme and press OK.

View programme details

To call up the details of the selected programme…

1 - Press  INFO. 2 - Press  BACK to close.

Change Day

The TV Guide can show the scheduled programmes for the upcoming days (maximum up to 8 days).

Press the colour key  Day and select the day you need.

Home Menu

9.1

About the Home Menu

To enjoy the benefits of your Android TV, connect the TV to the Internet.

Like on your Android smartphone or tablet, the Home menu is the centre of your TV. From the Home menu you can start any application, switch to a TV channel, open a website or switch to a connected device. Depending on your TV setup and your country the Home menu can contain different items.

The Home menu is organised in rows…

 LIST

The first row shows a selection of channels. Select the channel that you want to watch.



This row allows user to customise the hotel information on TV.



The row of Apps contain all Apps that come with the TV. In this row you will also find the Apps for TV, like Watch TV, Sources, Media and others. Apps you started recently will appear in front of the row.

Features

From this row, you can open a selection of settings.

Language

User can set the language of the TV in this row.

9.2

Smart Info

Apps

Open the Home Menu

To open the Home menu and open an item…

1 - Press 2 - Select an item and press OK to open or start it. 3 - Press

without starting anything.

HOME.



BACK, to close the Home menu



10.3

Sources

10.1

Switch to a device

From the list of Sources, you can switch to any of the connected devices. You can switch to a tuner to watch TV, open the content of a connected USB Flash Drive or see the recordings you made on a connected USB Hard Drive. You can switch to your connected devices to watch their programme, a digital receiver or a Blu-ray Disc player.

To switch to a connected device…

1 - Press SOURCES to open the Sources menu. 2 - Select one of the item in the source list and

press OK. The TV will show the programme or content of the device.

3 - Press SOURCES again to close the menu. One Touch Play

With the TV in standby, you can switch on a disc player with your TV remote control. To switch on both disc player and TV from standby and start playing the disc immediately, press  (play) on the TV remote control. The device must be connected with an HDMI cable and both TV and device must have HDMI CEC switched on.

10.2

Options for a TV Input

Some TV input devices offer specific settings. To set the options for a specific TV input…

1 - Press SOURCES. 2 - Select the TV input in the list and press OK. 3 - Press  OPTIONS. You can set the options for

the selected TV input here. 4 - Press  OPTIONS again to close the Options menu.

Possible options…

Device Name and Type

When you connect a new device to the TV and the TV detects the device, you can assign an icon that fits the device type. If you connect a device with an HDMI cable and HDMI CEC, the TV detects the device type automatically and the device gets an appropriate icon.

The device type determines picture and sound styles, resolution values, specific settings or the position within the Sources menu. You don't have to worry about the ideal settings.

Rename or Change Type

You can always change the name or change the type of a connected device. Look for the  icon at the right of the device name in the Sources menu. Some TV input sources do not allow a name change.

To change the device type…

1 - Select the device in the Sources menu. 2 - Press  (right) to select the  icon and

press OK. 3 - Press keyboard. 4 - Press  (down) to find all available device types. Select the type you want and press OK.

5 - If you want to reset the type of the device to the original connector type, select Reset and press OK.

6 - Select Close and press OK to close this menu. To change the device name…

1 - Select the device in the Sources menu. 2 - Press  (right) to select the  icon and

press OK. 3 - Use the on-screen Keyboard to delete the current name and enter a new one. Press  to confirm.

4 - Press 5 - If you want to reset the name of the device to the

original connector name, select Reset and press OK.

6 - Select Close and press OK to close this menu.

BACK to hide the onscreen



BACK to hide the onscreen keyboard.



Controls

With this option you can operate the connected device with the TV remote control. The device must be connected with an HDMI cable and both TV and device must have HDMI CEC switched on.

Device Info

Open this option to view information on the connected device.

10.4

Game or Computer

The device type determines picture and sound styles, resolution values and other specifics. You don't have to worry about the ideal settings.

For some devices the type of the device is not that clear. A game console can have a built-in Blu-ray Disc player and the type is set to Player because it is used as a disc player most of the time. For this kind of devices, you can temporarily switch to the ideal

settings for gaming. Or alternatively, switch to the ideal settings for a connected computer.

You can only use the setting Game or Computer when you switch to a connected device in the Sources menu. The Game or Computer setting is stored for the selected device.

To switch to the ideal settings for gaming or computer manually…

1 - Consumer Mode: On  Press press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Game or Computer and press OK. 4 - Select Game, Computer or Off. 5 - Press  (left) to go back one step

or press Remember to set this setting back to Off when you

stop playing the game.



HOME and select Features and



BACK to close the menu.

10.5

Rescan Connections

You can rescan all TV connections to update the Sources menu with recently connected devices.

To rescan the connections…

1 - Press SOURCES to open the Sources menu. 2 - Press  (up) to select the

right of the Sources menu. 3 - Press OK to start scanning the connections. Newly connected devices will be added to the Sources menu.

icon at the top



Apps

11.1

About Apps

All the apps can be found by pressing  Apps on your remote control. These TV apps offer entertainments to enrich your hotel stay experience. Apps can also be accessed in Apps section in the Apps menu.

11.2

Start or Stop an App

You can start an app from the Home menu. To start an app… 1 - Consumer Mode:

On  Press press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select the app you want and press OK. 3 - To stop an app, press  BACK or press TV or

stop the app with its dedicated exit/stop button.

HOME and select Apps and



HOME and select Apps and



To mark the current page as a favourite.

Internet

12.1

Start Internet

You can browse the Internet on your TV. You can view any Internet website but most of them are not prepared for a TV screen.

• Some plug-ins (e.g. to view pages or videos) are not available on your TV.

• You cannot send or download files.

• Internet pages are shown one page at a time and full screen.

To start the Internet browser… 1 - Consumer Mode:

On  Press press  (right). Guest Mode: On  Guest Menu: Press press  (right). (For professional mode information, please refer to Installation manual)

2 - Select  Internet and press OK. 3 - Enter an Internet address and select ,

press OK. 4 - To close Internet, press

HOME and select Features and



HOME and select Features and



HOME or TV.



Subtitles

To select subtitles if available.

12.2

Options on Internet

Some extras are available for the Internet. To open the extras…

1 - With the website open, press  OPTIONS. 2 - Select one of the items and press OK. 3 - Press

the menu.

Enter Address

To enter a new Internet address.

Show Favourites

To view the pages you marked as favourites.

Reload Page

To load the Internet page again.

Zoom Page

Use the slider bar to set the zoom percentage.

Security Info

BACK repeatedly if necessary, to close



To view the security level of the current page.

Mark as Favourite

Video Options

Videos, Photos and Music

13.1

From a USB Connection

You can view your photos or play your music and videos from a connected USB flash drive or USB Hard Drive.

With the TV switched on, plug in a USB flash drive or a USB Hard Drive to one of the USB connections. The TV detects the device and will list your media files.

If the list of files does not appear automatically…

1 - Press SOURCES, select  USB and press OK. 2 - Select  USB Devices and press  (right) to

select the USB device you need. 3 - You can browse your files in the folder structure you have organised on the drive. 4 - To stop playing videos, photos and music, press TV.

During the video playback, press  OPTIONS to…

• Mark as Favourite – Set the selected video as favourite.

• Play All – Play all video files in this folder.

• Play One – Play this video only.

• Subtitles – If available, you can switch subtitles On, Off or On During Mute.

• Audio Language – If available, select an Audio Language.

• Shuffle – Play your files in a random order.

• Repeat – Plays all videos in this folder once or continuously.

13.3

View your Photos

View Photos

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

13.2

Play your Videos

Play Videos

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

To play a video on TV… Select  Videos , and select the file name and

press OK.

• To rewind or go fast forward, press  or . Press the keys several times to speed up - 2x, 4x, 8x, 16x, 32x.

• To jump to the next video in a folder, press OK to pause and select  on screen and press OK.

• To stop the video playback, press  (Stop).

• To go back to the folder, press

Progress Bar

To show the progress bar when a video is playing (playhead position, duration, title, date, etc.), press  INFO. Press again to hide the info.



BACK.

To view all photos on TV…

Select  Photos , and select All and press OK.

To view a photo on TV…

Select  Photos , and select the file name and press OK.

To start a slide show on TV…

If there are several photos in a folder, you can start a slide show.

To start a slide show…

1 - Select the folder with photos. 2 - Press the colour key  Slide Show .

• To jump to the next or previous photo, press  (right - next) or  (left - previous).

• To pause the slide show, press OK. To start again, press OK again.

• To stop the slide show, press OK and press

Info

To view info on a photo (size, creation date, file path, etc.), select a photo and press  INFO. Press again to hide the info.



BACK.

Slideshow with Music

You can watch a slideshow of your photos and listen to your music at the same time. You must start the usic before you start the photo slideshow.

To play music with the slide show… 1 - Select a song or a folder with songs and

press OK.

2 - Press  INFO to hide file info and progress bar. 3 - Press  BACK. 4 - Now use the navigation arrows to select the

folder with photos. 5 - Select the folder with photos and press  Slide Show. 6 - To stop the slideshow, press



BACK.

Photo Options

With a photo on screen, press  OPTIONS to…

• Mark as Favourite – Set the selected photo as favourite.

• Slide Show – Show photos one after the other.

• To jump to the next song in a folder, press OK to pause and select  on screen and press OK.

• To go back to the folder, press will keep on playing.

• To stop the music playback, press  (Stop).

Progress Bar

To show the progress bar when a song is playing (playhead position, duration, title, date, etc.), press  INFO . Press again to hide the info.

BACK, the music



Music Options

Options for playing music...

• Mark as Favourite – Set the selected song as favourite.

• Play All – Play all songs in this folder.

• Play One – Play this song only.

• Shuffle – Play your files in a random order.

• Repeat – Plays all songs in this folder once or continuously.

• Rotate – Rotate the photo to landscape or portrait format.

• Shuffle – Play your files in a random order.

• Repeat – Play the slide show once or continuously.

• Stop Music – Stop the music playing in the background.

• Slide Show Speed – Set the speed of the slide show.

• Slide Show Transition – Set the style of the photo transitions.

13.4

Play your Music

Play Music

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

To play a song on TV… Select  Music , and select the file name and

press OK If there are several songs in a folder, you can listen to

them one after the other.

• To pause a song, press OK. Press OK again to continue.

• To rewind or go fast forward, press  or . Press the keys several times to speed up - 2x, 4x, 8x, 16x, 32x.

Smartphones and Tablets

14.1

Miracast

7 - On the device, select the videos, photos or files you want to watch on TV.

* Miracast is supported by WiDi 3.5 onwards.

Stop Sharing

You can stop sharing a screen from the TV or from the mobile device.

About Wi-Fi Miracast

You can view your photos or play your music and videos from a mobile device on your TV with Wi-Fi Miracast™. The mobile device and the TV should be within range, which usually means being in the same room.

Check if your mobile device is ready for Miracast. Your TV is a Wi-Fi CERTIFIED Miracast™ device.

With Miracast™, you can watch and share the screen of your smartphone, tablet or computer on your TV screen wirelessly. You can stream videos (audio and video), share photos or anything else that's on screen of the device. No need to connect the device to your home network. Both the TV and the device must be Wi-Fi CERTIFIED Miracast™ devices and have Miracast switched on.

Miracast on this TV is subject to the HDCP protocol and cannot display copy-protected premium content sent by a device. The maximum video resolution supported is 720p for 2.4GHz Wi-Fi or 1080p for 5GHz Wi-Fi.

From the device

With the application you use to start Miracast, you can disconnect and stop watching the screen of the device on TV. The TV will switch back to the last selected programme.

From the TV

To stop watching the screen of the device on TV, you can . . .

• press TV to watch a TV broadcast

• press

• press SOURCES to open the Sources menu and select a connected device.

HOME to start another activity on TV



Block a Device

The first time you receive a request to connect from a device, you can block the device. The request from this device and all its requests in the future, will be ignored.

To block a device…

For more information on Wi-Fi CERTIFIED Miracast™ go to www.wi-fi.org

Wi-Fi®, the Wi-Fi CERTIFIED logo, the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. Wi-Fi CERTIFIED Miracast™, Miracast™ are trademarks of the Wi-Fi Alliance.

Share a Screen on TV

To share the screen of your smartphone, tablet or computer on the TV . . .

1 - Switch on the TV. 2 - Consumer Mode: On  Press

Features and then press  (right).

3 - Select Miracast and press OK. 4 - On the device, open an application such as Wi-Fi

Miracast, Wi-Fi Direct™, Intel®Wireless Display* or similar and start scanning for other Miracast devices. 5 - In the list of found devices, select the TV and connect. 6 - On the TV, agree to the request to connect to the TV. If you connect, the TV will show the screen of the device.



HOME >

Select Block… and press OK.

Unblock all devices

All previously connected and also blocked devices are stored in the Wi-Fi Miracast list of connections. If you clear this list, all blocked devices will be unblocked.

To unblock all blocked devices… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Wireless and Networks > Features and press OK.

3 - Select Wi-Fi Miracast > Wi-Fi Miracast Connections and press OK. The list is cleared.

4 - Press the menu.

Blocking a previously connected device

If you want to block a device that you previously connected, you need to clear the Wi-Fi Miracast

BACK repeatedly if necessary, to close



HOME and



connections list first. If you clear this list, you will have to confirm or block the connection for every device again.

Screen Delay

The normal delay when sharing a screen with Miracast is about 1 second. The delay might be longer if you are using older devices with less processing power.

14.2

MHL

This TV is MHL™ compliant. If your mobile device is also MHL compliant, you can

connect your mobile device with a MHL cable to the TV. With the MHL cable connected you can share what's on your mobile device on the TV screen. Your mobile device charges its battery at the same time. The MHL connection is ideal for watching movies or playing games from your mobile device on TV for a longer time.

Charging

With the MHL cable connected, your device will charge while the TV is switched on (not in standby).

MHL Cable

You need a passive MHL cable (HDMI to Micro USB) to connect your mobile device to the TV. You might need an extra adapter to connect to your mobile device. To connect the MHL cable to the TV use the HDMI 4 MHL connection.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

Settings

15.1


Picture Style

Select a Style

For easy picture adjustment, you can select a preset Picture Style.

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Picture Style and press OK. 3 - Select one of the styles in the list. 4 - Press

the menu. The available styles are…

• Personal - The picture preferences you set during the first start up.

• Vivid - Ideal for daylight viewing

• Natural - Natural picture settings

• Standard - Most energy conscious setting - Factory setting

• Movie - Ideal for watching movies

• Photo - Ideal for viewing photos

• Game - Ideal for playing games

• Computer - Ideal for viewing computer



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



in Sources menu. To restore the style to its original setting… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual) 2 - Select Picture > Picture Style, and select the Picture Style you want to restore. 3 - Press the colour key  Restore Style , and press OK. The style is restored. 4 - Press the menu.

Picture Settings

Colour

With Colour, you can adjust the colour saturation of the picture.

To adjust the colour… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Colour press OK. 3 - Adjust the value with  (up) or  (down). 4 - Press

the menu.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



HOME and



Customise a Style

Any picture setting you adjust, like Colour or Contrast, is stored in the currently selected Picture Style. It allows you to customize each style. Only the style Personal can save its settings for each connected device in the Sources menu.

Restore a Style

With a Picture Style selected, you can adjust any picture setting in All Settings > Picture…

The selected style will store the changes you made. We recommend to adjust the picture settings for the style Personal only. The Picture Style - Personal can save its settings for each individual connected device

Contrast

With Contrast, you can adjust the contrast of the picture.

To adjust the contrast… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Contrast press OK. 3 - Adjust the value with  (up) or  (down). 4 - Press

the menu.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



Sharpness

With Sharpness, you can adjust the contrast of the picture.

To adjust the contrast… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Sharpness press OK. 3 - Adjust the value with  (up) or  (down). 4 - Press

the menu.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Colour > Tint and press OK. 4 - Adjust the value with  (up) or  (down). 5 - Press

the menu.

Colour Enhancement

With Colour Enhancement, you can enhance the colour intensity and the details in bright colours.

To adjust the level…

BACK repeatedly if necessary, to close



HOME and



Advanced Picture Settings

Game or Computer

If you have a game console with a built-in Blu-ray Disc player, you might have set the type name to Bluray Disc. With Game or Computer you can switch to the ideal settings for gaming manually. Don't forget to switch the Game or Computer setting off, when you return to watch TV.

To switch the setting manually… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced press OK. 3 - Select Game or Computer, and select the device

type you want to use. To switch back to TV, select Off. 4 - Press the menu.

Colour Settings

Tint

With Tint, you can adjust the level of tint in fine detail of the picture.

To adjust the tint…

BACK repeatedly if necessary, to close



HOME and



1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Colour > Colour

Enhancement and press OK.

4 - Select Maximum, Medium, Minimum or Off. 5 - Press

the menu.

Colour Temperature

With Colour Temperature, you can set the picture to a preset colour temperature or select Custom to set a temperature setting yourself with Custom Colour Temperature. Colour Temperature and Custom Colour Temperature are settings intended for expert users.

To select a preset… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Colour > Colour

Temperature and press OK.

4 - Select Normal, Warm or Cool. Or select Custom if you want to customise a colour temperature yourself. 5 - Press the menu.

BACK repeatedly if necessary, to close



BACK repeatedly if necessary, to close



HOME and



HOME and



Custom Colour Temperature

With Custom Colour Temperature, you can set a colour temperature yourself. To set a custom colour temperature, first select Custom in the Colour Temperature menu. Custom Colour Temperature is a setting intended for expert users.

To set a custom colour temperature… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Colour > Custom Colour

Temperature and press OK.

4 - Select one of the options and press OK. 5 - Press the arrows  (up) or  (down) to adjust

the value. 6 - Press  BACK repeatedly if necessary, to close the menu.

Contrast Settings

Contrast Modes

With Contrast Mode, you can set the level at which power consumption can be reduced by dimming the intensity of the screen. Choose for the best power consumption or for the picture with the best intensity.

mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast > Dynamic

contrast and press OK.

4 - Select Off, Minimum, Medium or Maximum. 5 - Press

BACK repeatedly if necessary, to close



the menu.

Perfect Contrast

With Perfect Contrast, you can set the level at which the TV automatically enhances the details in the dark, middle and light areas of the picture.

To adjust the level… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast >

Perfect contrast and press OK.

4 - Select Off, Minimum, Medium or Maximum. 5 - Press

BACK repeatedly if necessary, to close



the menu.

To adjust the level… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast > Contrast

mode and press OK. 4 - Select Off, Standard, Best power or Best picture.

5 - Press

BACK repeatedly if necessary, to close



the menu.

Dynamic Contrast

With Dynamic Contrast, you can set the level at which the TV automatically enhances the details in the dark, middle and light areas of the picture.

To adjust the level…

Brightness

With Brightness, you can set the level of brightness of the picture signal. Brightness is a setting intended for expert users. We recommend non-expert users to adjust the brightness of the picture with the Contrast setting.

To adjust the level… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast > Brightness and press OK. 4 - Press the arrows  (up) or  (down) to adjust

the value. 5 - Press

BACK repeatedly if necessary, to close



the menu.

1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this

Video Contrast

With Video Contrast, you can decrease the range of the video contrast.

To adjust the level…

5 - Press

BACK repeatedly if necessary, to close



the menu.

Ultra Resolution

1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast > Video

contrast and press OK.

4 - Press the arrows  (up) or  (down) to adjust the value. 5 - Press

BACK repeatedly if necessary, to close



the menu.

Gamma

With Gamma, you can set a non-linear setting for picture luminance and contrast. Gamma is a setting intended for expert users.

To adjust the level… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Contrast > Gamma and press OK. 4 - Press the arrows  (up) or  (down) to adjust

the value. 5 - Press

BACK repeatedly if necessary, to close



the menu.

With Ultra Resolution, you switch on a superior sharpness in line edges and contours.

To switch on or off… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Sharpness >

Ultra resolution and press OK.

4 - Select On or Off. 5 - Press

BACK repeatedly if necessary, to close



the menu.

Noise Reduction

With Noise Reduction, you can filter out and reduce the level of image noise.

To adjust the noise reduction… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Sharpness > Noise

reduction and press OK.

4 - Select Maximum, Medium, Minimum or Off. 5 - Press

BACK repeatedly if necessary, to close



the menu.

Sharpness Settings

Super Resolution

With Super Resolution, you switch on a superior sharpness in line edges and contours.

To switch on or off… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Sharpness > Super

resolution and press OK. 4 - Select On or Off.

MPEG Artefact Reduction

With MPEG Artefact Reduction, you can smoothen the digital transitions in the picture. MPEG artefacts are mostly visible as small blocks or jagged edges in images.

To reduce the MPEG artefacts… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Sharpness > MPEG Artefact

Reduction and press OK.

4 - Select Maximum, Medium, Minimum or Off. 5 - Press

the menu.

Motion Settings

Perfect Natural Motion

BACK repeatedly if necessary, to close



mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Motion > Clear LCD and press OK. 4 - Select On or Off. 5 - Press

the menu.

BACK repeatedly if necessary, to close



With Perfect Natural Motion, you can reduce the motion judder, visible in movies on TV. Perfect Natural Motion makes any movement smooth and fluent.

To adjust the motion judder… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Motion > Perfect Natural

Motion and press OK.

4 - Select Maximum, Medium, Minimum or Off. 5 - Press

the menu.

Natural Motion

With Natural Motion, you can reduce the motion judder, visible in movies on TV. Natural Motion makes any movement smooth and fluent.

To adjust the motion judder… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Picture > Advanced and press OK. 3 - Select Motion > Digital Natural

Motion and press OK.

4 - Select Maximum, Medium, Minimum or Off. 5 - Press

the menu.

Clear LCD

With Clear LCD, you switch on a superior motion sharpness, better black level, high contrast with a flicker-free, quiet image and a larger viewing angle.

To switch on or off… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this

BACK repeatedly if necessary, to close



BACK repeatedly if necessary, to close



HOME and



HOME and



HOME and



15.2

Sound

Sound Style

Select a Style

For easy sound adjustment, you can select a preset setting with Sound Style.

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Sound Style and press OK. 3 - Select one of the styles in the list. 4 - Press

the menu. The available styles are…

• Personal - The sound preferences you set during the first start up.

• Original - Most neutral sound setting

• Movie - Ideal for watching movies

• Music - Ideal for listening to music

• Game - Ideal for gaming

• News - Ideal for speech

Restore a Style

With a Sound Style selected, you can adjust any sound setting in Setup > Sound…

The selected style will store the changes you made. We recommend to adjust the sound settings for the style Personal only. The Sound Style - Personal can save its settings for each individual connected device in Sources menu.

To restore the style to its original setting… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and select Features and



HOME and



HOME and



(For professional mode information, please refer to Installation manual) 2 - Select Sound > Sound Style, and select the Sound Style you want to restore. 3 - Press the colour key  Restore Style , and press OK. The style is restored. 4 - Press the menu.

BACK repeatedly if necessary, to close



Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Surround mode and press OK. 4 - Select Stereo or Incredible surround. 5 - Press

the menu.

BACK repeatedly if necessary, to close



Sound Settings

Bass

With Bass, you can adjust the level of low tones in the sound.

To adjust the level… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Bass press OK. 3 - Adjust the value with  (up) or  (down). 4 - Press

the menu.

Treble

With Treble, you can adjust the level of high tones in the sound.

To adjust the level… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Treble press OK. 3 - Adjust the value with  (up) or  (down). 4 - Press

the menu.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



HOME and



Auto Volume Levelling

With Auto Volume Levelling, you can set the TV to automatically level out sudden volume differences. Typically at the beginning of adverts or when you are switching channels.

To switch on or off… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Auto volume levelling and press OK. 4 - Select On or Off. 5 - Press

the menu.

Clear Sound

With Clear Sound, you improve the sound for speech. Ideal for news programmes. You can switch the speech improvement on or off.

To switch on or off… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Clear sound and press OK. 4 - Select On or Off. 5 - Press

the menu.

BACK repeatedly if necessary, to close



BACK repeatedly if necessary, to close



HOME and



HOME and



Advanced Sound Settings

Surround mode

With Surround Mode, you can set the sound effect of the TV speakers.

To set the surround mode… 1 - Consumer Mode: On  Press

select Features and press OK.

HOME and



Audio Out Format

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to

HOME and



Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Audio Out Format and press OK. 4 - Select Multichannel or Stereo. 5 - Press

the menu.

BACK repeatedly if necessary, to close



2 - Select Sound > Advanced press OK. 3 - Select Audio Out Offset and press OK. 4 - Use the slider bar to set the sound offset and

press OK. 5 - Press the menu.

BACK repeatedly if necessary, to close



Audio Out Levelling

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Audio Out Levelling and press OK. 4 - Select More, Medium or Less. 5 - Press

the menu.

Audio Out Delay

If you set an Audio sync delay on your Home Theatre System, to synchronise the sound with the picture, you must switch off Audio Out Delay on the TV.

To switch off Audio Out Delay… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Advanced press OK. 3 - Select Audio Out Delay and press OK. 4 - Select Off or On. 5 - Press

the menu.

BACK repeatedly if necessary, to close



BACK repeatedly if necessary, to close



HOME and



HOME and



Speakers

Wireless Speakers

What You Need

You can connect a wireless device with Bluetooth® to this TV – a wireless speaker, a subwoofer, a sound bar or headphones. You can also connect a wireless gamepad with Bluetooth LE.

To play the TV sound on a wireless speaker, you must pair the wireless speaker with the TV. You can pair some wireless speakers and a maximum of 4 Bluetooth LE (low energy) devices. The TV can only play the sound on one wireless audio speaker at a time. If you connect a subwoofer, the sound is played on the TV and the subwoofer. If you connect a sound bar the sound is played on the sound bar only.

Attention - Audio to Video syncronisation

Many Bluetooth speaker systems have a high, so called, 'latency'. High latency means that the audio lags behind the video, causing unsynchronised 'lip sync'. Before you purchase a wireless Bluetooth speaker system, inform yourself about the newest models and look for a device with a low latency rating. Ask your dealer for advice.

A range of selected Philips wireless speaker products can connect and play the TV sound. Consult the Philips website for suited wireless audio products for this TV - www.philips.com/tv

Select a Speaker

Audio Out Offset

If you cannot set a delay on the Home Theatre System, you can set a delay on the TV with Audio Out Offset.

To synchronise the sound on the TV… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

HOME and



To connect a wireless speaker… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Bluetooth Audio press OK. 3 - Select Connect and press OK. 4 - Press

the menu.



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



Remove a Speaker

To remove a wireless speaker… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Bluetooth Audio press OK. 3 - Select Remove and press OK. 4 - Press

the menu.

Wireless Headphone

To connect wireless Bluetooth devices such as wireless Bluetooth headphone, make sure Bluetooth is switched on.

To switch Bluetooth on… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Sound and press OK. 3 - Select Bluetooth Audio and press OK. 4 - Select Connect and press OK. 5 - Press

the menu.

Subwoofer Volume

To adjust the volume of wireless speaker… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > Bluetooth Audio press OK. 3 - Select Subwoofer-level and press OK. 4 - Adjust the value with  (up) or  (down). 5 - Press

the menu.

Problems Lost connection

• Position the wireless speaker within a range of 5 meters from the TV.

• Places with a high amount of wireless activity -



HOME and select Features and



BACK repeatedly if necessary, to close

HOME and select Features and



BACK repeatedly if necessary, to close

HOME and



HOME and



HOME and



apartments with lots of wireless routers - can hamper the wireless connection. Keep the router and wireless speaker as close to the TV as possible.

Audio and video mismatch

• Some wireless speakers systems might have audio and video sync problems. We recommend using Philips wireless audio products.

15.3

Eco Settings

Screen Off

If you only listen to music, you can switch off the TV screen to save energy.

To only switch off the TV screen… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Press press OK. (For professional mode information, please refer to Installation manual)

2 - Select Eco Settings > Screen Off. 3 - Press

the menu. To switch the screen back on, press any key on the

remote control.



HOME and select Features and



BACK repeatedly if necessary, to close

Sleep timer

With the sleep timer, you can set the TV to switch to standby automatically after a preset time.

To set the sleep timer . . . 1 - Press

press OK. *Consumer Mode: On  Setup *Guest Mode: On  Guest Menu (For professional mode information, please refer to Installation manual) 2 - Select Eco settings* > Sleep timer. *Consumer Mode : On  *Guest Mode: On  Select Eco settings > Sleep timer. (For professional mode information, please refer to Installation manual) With the slider bar you can set the time to up to 240 minutes in increments of 30 minutes. If set to Off, the sleep timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press the menu.

HOME and select Features* and



HOME > Eco settings



BACK, repeatedly if necessary, to close



HOME and



15.4

General Settings

EasyLink

Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Android Settings, and press OK. 3 - Explore the different Android settings. 4 - Press

the menu.

BACK repeatedly if necessary, to close



To switch off EasyLink completely… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sources > Advanced and press OK. 3 - Select EasyLink and

press OK, then select EasyLink one step further.

4 - Select Off. 5 - Press

the menu.

EasyLink Remote Control

To switch off EasyLink remote control… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sources > Advanced and press OK. 3 - Select EasyLink and

press OK, then select EasyLink one step further.

4 - Select Easylink Remote Control and press OK. 5 - Select Off. 6 - Press  BACK repeatedly if necessary, to close

the menu.

BACK repeatedly if necessary, to close



HOME and



HOME and



USB Keyboard Settings

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

Consumer Mode: On  Not available in this mode. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

HbbTV

If a TV channel offers HbbTV pages, you must first switch on HbbTV in the TV settings to view the pages.

3 - Select Enable Hbb TV , and press OK. 4 - Select Yes. 5 - Press

the menu.

BACK repeatedly if necessary, to close



HOME and



Android Settings

You can set or view several Android specific settings or information. You can find the list of apps installed on your TV and the storage space they need. You can configure the onscreen keyboard or allow apps to use your location. Explore the different Android settings. You can go to www.support.google.com/androidtv for more information on these settings.

To open these settings… 1 - Consumer Mode: On  Press

select Features and press OK.

HOME and



If you want to avoid access to HbbTV pages on a specific channel, you can block the HbbTV pages for this channel only.

1 - Tune to the channel of which you want to block the HbbTV pages.

2 - Press  OPTIONS and select HBB TV on This Channel and press OK. 3 - Select Off and press OK.

TV Placement

As part of the first installation, this setting is set to either On a TV stand or Hang on the Wall. If you have changed the placement of the TV since then, adjust this setting accordingly for best sound reproduction.

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Sound > TV Placement and press OK. 3 - Select On a TV stand or Hang on the Wall. 4 - Press

the menu.

BACK repeatedly if necessary, to close



HOME and



Channel Logos

15.5

Clock, Region and Language

Menu Language

To change the language of the TV menus and messages…

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Region and Language > Languages > Menu Language and press OK.

3 - Select Languages List and press OK. 4 - Select on the language you need. 5 - Press

the menu.

BACK repeatedly if necessary, to close



HOME and



In some countries, the TV can show the channel logos. If you do not want these logos to appear, you can switch them off.

To switch off the logos… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Channels > Channel Settings and press OK.

3 - Select Enable Channel Logos , and press OK. 4 - Select No . 5 - Press

the menu.

BACK repeatedly if necessary, to close



HOME and



Reinstall TV

You can redo a full TV installation. The TV is completely reinstalled.

To redo a full TV installation… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Reset > Reinstall TV and press OK. 3 - Follow the instructions on screen. The installation

may take a few minutes.

HOME and



Language preferences

Audio Language Settings

Digital TV channels can broadcast audio with several spoken languages for a programme. You can set a preferred primary and secondary audio language. If audio in one of these languages is available, the TV will switch to this audio.

If none of the preferred audio languages is available, you can select another audio language which is available.

To set the primary and secondary audio language… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Region and Language > Languages > Primary Audio or Secondary Audio and press OK.

3 - Select on the language you need. 4 - Press

the menu. To select an audio language when none of your

preferred audio language is available…

1 - Press  OPTIONS . 2 - Select Audio Language and select on the audio

language you want temporarily.

BACK repeatedly if necessary, to close



HOME and



Subtitles

Switch On

To switch on Subtitles, press SUBTITLE. You can switch subtitles On, Off or On During

Mute. Or to show subtitles automatically when the broadcasted programme is not in language – the language set for the TV – select Automatic. This setting will also show Subtitles automatically when you mute the sound.

To know if a channel is analogue or digital, switch to the channel and open Channel

Info in  OPTIONS.

Text / Teletext Languages

Text Pages

To open Text/Teletext press TEXT, while you are watching TV channels. To close Text, press TEXT again.

Select a Text page

Subtitle Language Settings

Digital channels can offer several subtitle languages for a programme. You can set a preferred primary and secondary subtitle language. If subtitles in one of these languages are available, the TV will show the subtitles you selected.

If none of the preferred subtitle languages are available, you can select another subtitle language which is available.

To set the primary and secondary subtitle language… 1 - Consumer Mode: On  Press

HOME and



select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Region and Language > Languages > Primary Subtitle or Secondary Subtitle and press OK.

3 - Select on the language you need. 4 - Press

BACK repeatedly if necessary, to close



the menu. To select a subtitle language when none of your

preferred languages are available…

1 - Press  OPTIONS . 2 - Select Subtitle Language and select on the

language you want temporarily.

To select a page . . .

1 - Enter the page number with the number keys. 2 - Use the arrow keys to navigate. 3 - Press a colour key to select a colour-coded

subject at the bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The subpage numbers are shown on a bar next to the main page number. To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text. To open T.O.P. Text pages within Text, press  OPTIONS and select T.O.P. overview.

Favourite pages

The TV makes a list of the last 10 Text pages you opened. You can easily reopen them again in the Favourite Text pages column.

pages. Search Text

You can select a word and scan Text for all occurences of this word.

Subtitles from Text

If you tune to an analogue channel, you need to make the subtitles available for each channel manually.

1 - Switch to a channel and press TEXT to open Text.

2 - Enter the page number for subtitles, usually 888. 3 - Press TEXT again, to close Text.

If you select On in the Subtitle menu when watching this analogue channel, subtitles will be shown if available.

1 - Open a Text page and press OK. 2 - Select a word or number with the arrow keys. 3 - Press OK again to jump immediately to the next

occurence of this word or number. 4 - Press OK again to jump to the subsequent occurence. 5 - To stop searching, press  (up) until nothing is selected.

Text from a connected device

Some devices that receive TV channels can also offer Text. To open Text from a connected device . . .

1 - Press SOURCES, select the device and

press OK. 2 - While watching a channel on the device, press  OPTIONS , select Show device keys and select the  key and press OK.

3 - Press  BACK to hide the device keys. 4 - To close Text, press

Digital Text (UK only)

Some digital broadcasters offer dedicated Digital Text or interactive TV on their digital TV channels. This includes normal Text using the number, colour and arrow keys to select and navigate.

To close Digital Text, press

BACK again.



BACK.



Text 2.5

If available, Text 2.5 offers more colours and better graphics. Text 2.5 is activated as a standard factory setting. To switch off Text 2.5…

1 - Press TEXT. 2 - With Text/Teletext open on screen,

press  OPTIONS.

3 - Select Text 2.5 > Off. 4 - Press

the menu.

BACK repeatedly if necessary, to close



Text Options

In Text/Teletext, press following…

• Freeze page To stop the automatic rotation of subpages.

• Dual screen / Full screen To show the TV channel and Text alongside each other.

• T.O.P. overview To open T.O.P. Text.

• Enlarge To enlarge the Text page for comfortable reading.

• Reveal To unhide hidden information on a page.

• Cycle subpages To cycle subpages when these are available.

• Language To switch the group of characters that Text uses to display correctly.

• Text 2.5 To activate the Text 2.5 for more colours and better graphics.

Text Setup Text language

Some digital TV broadcasters have several Text languages available. To set your primary and secondary Text language . . .

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Region and Language > Languages > Primary Text or Secondary Text and press OK.

3 - Select your preferred Text languages. 4 - Press

the menu.

BACK repeatedly if necessary, to close



OPTIONS to select the



HOME and



Clock

Date and Time

Automatic

To know what time it is, press Menu always shows what time it is.

In some countries, digital broadcasts do not send UTC

- Coordinated Universal Time information. The daylight saving change might be ignored and the TV might show an incorrect time.

When you record programmes - scheduled in the TV Guide, we recommend not to change the time and date manually. In some countries, for some network operators, the Clock setting is hidden to avoid an incorrect clock setting.

To correct the TV clock automatically... 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Date and Time > Source and press OK. 3 - Select Automatic NTP. 4 - Press

the menu.

Manual

To set the TV clock manually… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Date and Time > Manual Date and Time Setting and press OK.

3 - Select Date and Time to adjust. 4 - Press

BACK repeatedly if necessary, to close



BACK repeatedly if necessary, to close



HOME. The Home



HOME and



HOME and



the menu.

Hard of Hearing

Time Zone

To set the time zone… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Date and Time > Time Zone Settings and press OK. 3 - Select Time Zone Country or Time Zone Region and press OK.

4 - Select one of the time zones. 5 - Press

the menu.

15.6

BACK repeatedly if necessary, to close



HOME and



Universal Access

Switch On

With Universal Access switched on, the TV is prepared for use for the deaf, hard of hearing, blind or partially sighted people.

Switch on

If you did not switch on Universal Access during the installation, you can still switch it on in Universal Access menu. To switch on Accessibility…

3 - Select On and press OK. 4 - Press

the menu. With Universal Access switched on, the

option Universal Access is added in the Options menu.

BACK repeatedly if necessary, to close



HOME and



Some digital TV channels broadcast special audio and subtitles adapted for the hard of hearing or deaf people. With Hearing impaired switched on, the TV automatically switches to the adapted audio and subtitles, if available. Before you can switch on Hearing impaired, you have to switch on Universal Access.

To switch on Hearing impaired… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Accessibility > Hearing impaired and press OK.

3 - Select On and press OK. 4 - Press

the menu. To switch on Hearing impaired while watching TV... 1 - While watching a TV channel,

press  OPTIONS , select Universal Access and press OK. 2 - Select Hearing impaired, and select On.

To check whether a hearing impaired audio language is available, press  OPTIONS , select Audio Language and look for an audio language marked with a .

If Accessibility does not appear in the Options menu, switch on Universal Access in setup menu.

BACK repeatedly if necessary, to close



HOME and



Audio Description

Switch On

Digital TV channels can broadcast special audio commentary describing what is happening on screen. To be able to set the visually impaired audio and effects, you have to switch on Audio Description first. Also, before you can switch on Audio Description, you have to switch on Universal Access in setup menu.

With Audio Description, a narrator's commentary is added to the normal audio. To switch on the commentary (if available)…

To switch on Audio Description… 1 - Consumer Mode: On  Press

select Features and press OK.

HOME and



Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual) 2 - Select Accessibility > Audio Description and press OK.

3 - Select Audio Description one step further. 4 - Select On and press OK. 5 - Press

BACK repeatedly if necessary, to close



the menu.

3 - Select Mixed Volume and press OK. 4 - Adjust the value with  (up) or  (down). 5 - Press

BACK repeatedly if necessary, to close



the menu. If an audio language with added audio commentary is

available, you can also find this setting in  OPTIONS > Universal Access > Mixed Volume.

To switch on Audio Description while watching TV... 1 - While watching a TV channel,

press  OPTIONS , select Universal Access and press OK. 2 - Select Audio Description, and select On.

You can check if an audio commentary is available. In the Options menu, select Audio Language and look for an audio language marked with a .

Speakers/Headphones

With Speakers/Headphones, you can select where you want to hear the audio commentary. On the TV speakers only, on the headphones only or on both.

To set Speakers/Headphones… 1 - Consumer Mode: On  Press

HOME and



3 - Select Speakers/Headphones and press OK. 4 - Select Speakers, Headphones or Speakers +

Headphones and press OK.

5 - Press

BACK repeatedly if necessary, to close



the menu.

Mixed Volume

You can mix the volume of the normal audio with the audio commentary.

Audio Effect

Some audio commentary can hold extra audio effects, like stereo or fading sound.

To switch on Audio effects (if available)… 1 - Consumer Mode: On  Press

HOME and



3 - Select Audio Effect and press OK. 4 - Select On and press OK. 5 - Press

BACK repeatedly if necessary, to close



the menu.

Speech

The audio commentary can also hold subtitles for the words which are spoken.

To switch on these subtitles (if available) . . . 1 - Consumer Mode: On  Press

HOME and



3 - Select Speech and press OK. 4 - Select Descriptive or Subtitles and press OK. 5 - Press

BACK repeatedly if necessary, to close



the menu.

To mix the volume… 1 - Consumer Mode: On  Press

HOME and



Channel Installation

16.1

Antenna/Cable Installation

Update Channels

Automatic Channel Update

If you receive digital channels, you can set the TV to automatically update these channels.

Once a day, at 4 AM, the TV updates the channels and stores new channels. New channels are stored in the Channels List and are marked with a  . Channels without a signal are removed. The TV must be in standby to automatically update channels. You can switch off Auromatic Channel Update.

To switch off the automatic update…

Installation manual) 2 - Select Channels > RF Channel Installation and press OK.

3 - Enter your PIN code if necessary. 4 - Select Digital: Reception Test and press OK. 5 - Select DVB-T Search or DVB-C Search and

press OK. The digital frequency is shown for this channel. 6 - Select Search again and press OK to check the signal quality of this frequency. The test result is shown on screen. You can reposition the antenna or check the connections to possibly improve the reception. 7 - You can also change the frequency yourself. Select the frequency number one by one and use the  (up) or  (down) keys to change the value. Select Search and press OK to test the reception again. 8 - Press  BACK repeatedly if necessary, to close the menu.

1 - Consumer Mode: On  Not available in this mode. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

When new channels are found or if channels are updated or removed, a message is shown at TV start up. To avoid this message to appear after every channel update, you can switch it off.

To switch off the message… 1 - Consumer Mode: On  Not available in this

mode. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

In certain countries, the Automatic channel update is done while watching TV or on any moment when the TV is in standby.

Reception Quality

You can check the quality and signal strength of a digital channel. If you have your own antenna, you can reposition the antenna to try and improve the reception.

To check the reception quality of a digital channel… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to

HOME and



Reinstall Channels

Reinstall All Channels

You can reinstall all channels and leave all other TV settings untouched.

If a PIN code is set, you will need to enter this code before you can reinstall channels.

To reinstall channels… 1 - Consumer Mode: On  Press

3 - Enter your PIN code if necessary. 4 - Select Search for Channels and press OK. 5 - Select Start and press OK. 6 - Select Reinstall Channels, select Next and

press OK. 7 - Select the country where you are now and press OK.

8 - Select Next and press OK. 9 - Select the type of installation you want, Antenna

(DVB-T) or Cable (DVB-C) and press OK.

8 - Select Next and press OK. 11 - Select the type of channels you want, Digital

and Analogue Channels or Only Digital Channels and press OK.

8 - Select Next and press OK. 13 - Select Start and press OK to update the

digital channels. This can take a few minutes. 14 - Press close the menu.

BACK repeatedly if necessary, to



HOME and



Reinstall TV

You can redo a full TV installation. The TV is completely reinstalled.

To redo a full TV installation…

shown briefly. You can redo these steps until you have found all

available analogue TV channels.

1 - Consumer Mode: On  Press select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Reset and press OK. 3 - Select Reinstall TV and press OK. 4 - Enter your PIN code if necessary. 5 - Select Yes and press OK to confirm. 6 - The TV will reinstall completely. All settings will

be reset and installed channels will be replaced. The installation can take a few minutes. 7 - Press the menu.

BACK repeatedly if necessary, to close



HOME and



Manual Installation

Analogue TV channels can be manually installed, channel by channel.

To install analogue channels manually… 1 - Consumer Mode: On  Press

3 - Enter your PIN code if necessary. 4 - Select Analogue: Manual Installation and

press OK.

• System To set up the TV system, select System. Select your country or the part of the world where you are now and press OK.

• Search Channel To find a channel, select Search Channel and press OK. You can enter a frequency yourself to find a channel or let the TV search for a channel. Press  (right) to select Search and press OK to search for a channel automatically. The found channel is shown on screen and if the reception is poor, press Search again. If you want to store the channel, select Done and press OK.

HOME and



• Store You can store the channel on the current channel number or as a new channel number. Select Store Current Channel or Store as New Channel and press OK. The new channel number is

17.2

Software

17.1

Update Software

Update from USB

It might be necessary to update the TV software. You need a computer with an high-speed Internet connection and a USB flash drive to upload the software on the TV. Use a USB flash drive with at least 500MB free space. Make sure that write protection is switched off.

To update the TV software… 1 - Consumer Mode: On  Press

select Features and press OK. Guest Mode: On  Guest Menu: Not available in this mode. (For professional mode information, please refer to Installation manual)

2 - Select Upgrade and Clone > Firmware Upgrade from USB and press OK.

Download the software

1 - Insert the USB flash drive into your computer. 2 - On the USB flash drive, locate the

file update.htm and double click it.

3 - Click Send ID. 4 - If new software is available, download the .zip

file. 5 - After the download, unzip the file and copy the file autorun.upg onto the USB flash drive. Do not place this file in a folder.

Update the TV software

1 - Insert the USB flash drive into the TV again. The update starts automatically. 2 - A software update can take several minutes. Do not press the  key on the TV or remote control. Do not remove the USB flash drive. 3 - When the update is done, the TV will return to the channel you were watching.

If a power cut occurs during the update, never remove the USB flash drive from the TV. When the power returns, the update will continue.

To prevent an accidental update of the TV software, delete the autorun.upg file from the USB flash drive.

HOME and



Open Source Software

This television contains open source software. TP Vision Europe B.V. hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such offer is requested by the respective licences.

This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain the source code, please write in English to . . .

open.source@tpvision.com

17.3

Open Source License Statement

README for the source code of the parts of TP Vision Netherlands B.V. TV software that fall under open source licenses.

This is a document describing the distribution of the source code used on the TP Vision Netherlands B.V. TV, which fall either under the GNU General Public License (the GPL), or the GNU Lesser General Public License (the LGPL), or any other open source license. Instructions to obtain copies of this software can be found in the Directions For Use.

TP Vision Netherlands B.V. MAKES NO WARRANTIES WHATSOEVER, EITHER EXPRESS OR IMPLIED, INCLUDING ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS SOFTWARE. TP Vision Netherlands B.V. offers no support for this software. The preceding does not affect your warranties and statutory rights regarding any TP Vision Netherlands B.V. product(s) you purchased. It only applies to this source code made available to you.

17.4

Open Source License

Android (5.1.0) This TV contains the Android Lollipop Software.

Android is a Linux-based operating system designed primarily for touch screen mobile devices such as smartphones and tablet computers. This software will also be reused in TPVision Android based TV's. The original download site for this software is : https://android.googlesource.com/This piece of software is made available under the terms and

conditions of the Apache license version 2, which can be found below. Android APACHE License Version 2 (http://source.android.com/source/licenses.html)

Toolbox (N/A) The original download site for this software is :

https://android.googlesource.com/This piece of software is made available under the terms and conditions of the Apache license version 2, which can be found below. Android APACHE License Version 2 (http://source.android.com/source/licenses.html)

linux kernel (3.10.27) This TV contains the Linux Kernel. The original

download site for this software is : http://www.kernel.org/.This piece of software is made available under the terms and conditions of the GPL v2 license, which can be found below. Additionally, following exception applies : "NOTE! This copyright does *not* cover user programs that use kernel services by normal system calls - this is merely considered normal use of the kernel, and does *not* fall under the heading of "derived work". Also note that the GPL below is copyrighted by the Free Software Foundation, but the instance of code that it refers to (the linux kernel) is copyrighted by me and others who actually wrote it. Also note that the only valid version of the GPL as far as the kernel is concerned is _this_ particular version of the license (ie v2, not v2.2 or v3.x or whatever), unless explicitly otherwise stated. Linus Torvalds"

libcurl (7.21.7) libcurl is a free and easy-to-use client-side URL

transfer library, supporting DICT, FILE, FTP, FTPS, Gopher, HTTP, HTTPS, IMAP, IMAPS, LDAP, LDAPS, POP3, POP3S, RTMP, RTSP, SCP, SFTP, SMTP, SMTPS, Telnet and TFTP. libcurl supports SSL certificates, HTTP POST, HTTP PUT, FTP uploading, HTTP form based upload, proxies, cookies, user+password authentication (Basic, Digest, NTLM, Negotiate, Kerberos), file transfer resume, http proxy tunneling and more! The original download site for this software is : http://curl.haxx.se/libcurl/COPYRIGHT AND PERMISSION NOTICE

Copyright (c) 1996 - 2010, Daniel Stenberg, daniel@haxx.se.All rights reserved. Permission to use, copy, modify, and distribute this software for any purpose with or without fee is hereby granted, provided that the above copyright notice and this permission notice appear in all copies. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS ORIMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES

OF MERCHANTABILITY,FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. INNO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM,DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OROTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USEOR OTHER DEALINGS IN THE SOFTWARE. Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software without prior written authorization of the copyright holder.

libfreetype (2.4.2) FreeType is a software development library, available

in source and binary forms, used to render text on to bitmaps and provides support for other font-related operations

The original download site for this software is : https:/ /github.com/julienr/libfreetype-androidFreetype License

libjpeg (8a) This package contains C software to implement JPEG

image encoding, decoding, and transcoding. This software is based in part on the work of the Independent JPEG Group.

The authors make NO WARRANTY or representation, either express or implied, with respect to this software, its quality, accuracy, merchantability, or fitness for a particular purpose. This software is provided "AS IS", and you, its user, assume the entire risk as to its quality and accuracy. This software is copyright (C) 1991-1998, Thomas G. Lane. All Rights Reserved except as specified below. Permission is hereby granted to use, copy, modify, and distribute this software (or portions thereof) for any purpose, without fee, subject to these conditions:(1) If any part of the source code for this software is distributed, then this README file must be included, with this copyright and no-warranty notice unaltered; and any additions, deletions, or changes to the original files must be clearly indicated in accompanying documentation.(2) If only executable code is distributed, then the accompanying documentation must state that "this software is based in part on the work of the Independent JPEG Group".(3) Permission for use of this software is granted only if the user accepts full responsibility for any undesirable consequences; the authors accept NO LIABILITY for damages of any kind. These conditions apply to any software derived from or based on the IJG code, not just to the unmodified library. If you use our work, you ought to acknowledge us. Permission is NOT granted for the use of any IJG author's name or company

name in advertising or publicity relating to this software or products derived from it. This software may be referred to only as "the Independent JPEG Group's software". We specifically permit and encourage the use of this software as the basis of commercial products, provided that all warranty or liability claims are assumed by the product vendor.

libpng (1.4.1) libpng is the official Portable Network Graphics (PNG)

reference library (originally called pnglib). It is a platform-independent library that contains C functions for handling PNG images. It supports almost all of PNG's features, is extensible. The original download site for this software is : https://github.com/julienr/libpng-androidlibpng license

openssl (1.0.1j) OpenSSL is an open-source implementation of the

SSL and TLS protocols. The core library, written in the C programming language, implements the basic cryptographic functions and provides various utility functions. The original download site for this software is : http://openssl.org/OpenSSL license

Zlib compression library (1.2.7) zlib is a general purpose data compression library. All

the code is thread safe. The data format used by the zlib library is described by RFCs (Request for Comments) 1950 to 1952 in the files http://tools.ietf.org/html/rfc1950 (zlib format), rfc1951 (deflate format) and rfc1952 (gzip format) Developed by Jean-loup Gailly and Mark Adler(C) 1995-2012 Jean-loup Gailly and Mark Adler This software is provided 'as-is', without any express or implied warranty. In no event will the authors be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the following restrictions: 1. The origin of this software must not be misrepresented; you must not claim that you wrote the original software. If you use this software in a product, an acknowledgment in the product documentation would be appreciated but is not required. 2. Altered source versions must be plainly marked as such, and must not be misrepresented as being the original software. 3. This notice may not be removed or altered from any source distribution. Jean-loup Gailly Mark Adler jloup@gzip.org madler@alumni.caltech.edu

dvbsnoop (1.2)

dvbsnoop is a DVB / MPEG stream analyzer program. For generating CRC32 values required for composing PAT, PMT, EIT sections

The original download site for this software is : https:/ /github.com/a4tunado/dvbsnoop/blob/master/src/ misc/crc32.cGPL v2 http://dvbsnoop.sourceforge.net/dvbsnoop.html

ezxml (0.8.6) ezXML is a C library for parsing XML documents. The original download site for this software is :

gSoap (2.7.15) The gSOAP toolkit is an open source C and C++

software development toolkit for SOAP/XML Web services and generic (non-SOAP) C/C++ XML data bindings. Part of the software embedded in this product is gSOAP software. Portions created by gSOAP are Copyright 2001-2009 Robert A. van Engelen, Genivia inc. All Rights Reserved. THE SOFTWARE IN THIS PRODUCT WAS IN PART PROVIDED BY GENIVIA INC AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

restlet (2.1.7) Restlet is a lightweight, comprehensive, open source

REST framework for the Java platform. Rest let is suitable for both server and client Web applications. It supports major Internet transport, data format, and service description standards like HTTP and HTTPS, SMTP, XML, JSON, Atom, and WADL. The original download site for this software is : http://restlet.orgThis piece of software is made available under the terms and conditions of the Apache License version 2.

Opera Web Browser (SDK 3.5) This TV contains Opera Browser Software.

dlmalloc (2.7.2) Opera uses Doug Lea's memory allocator The original download site for this software is :

http://gee.cs.oswego.edu/dl/html/malloc.html

double-conversion Opera uses double-conversion library by Florian

Loitsch, faster double : string conversions (dtoa and strtod).The original download site for this software is : http://code.google.com/p/doubleconversionCopyright 2006-2011, the V8 project authors. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of Google Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS"AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOTLIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FORA PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHTOWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOTLIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANYTHEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USEOF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

EMX (0.9c) Opera uses EMX, which is an OS/2 port of the gcc

suite. Opera uses modified versions of the sprintf and sscanf methods from this C library.* The emx libraries are not distributed under the GPL. Linking an * application with the emx libraries does not cause the

executable * to be covered by the GNU General Public License. You are allowed * to change and copy the emx library sources if you keep the copyright * message intact. If you improve the emx libraries, please send your * enhancements to the emx author (you should copyright your * enhancements similar to the existing emx libraries).

freetype (2.4.8) Opera uses freetype FreeType 2 is a software-font

engine that is designed to be small, efficient, highly customizable and portable, while capable of producing high-quality output (glyph images).The original download site for this software is : http://ww w.freetype.org/freetype2/index.htmlFreetype License

HKSCS (2008) Opera uses HKSCS: The Government of the Hong

Kong Special Administrative Region HKSCS mappingsThe original download site for this software is : http://www.ogcio.gov.hkBefore downloading the Software or Document provided on this Web page, you should read the following terms (Terms of Use). By downloading the Software and Document, you are deemed to agree to these terms.1. The Government of the Hong Kong Special Administrative Region (HKSARG) has the right to amend or vary the terms under this Terms of Use from time to time at its sole discretion.2. By using the Software and Document, you irrevocably agree that the HKSARG may from time to time vary this Terms of Use without further notice to you and you also irrevocably agree to be bound by the most updated version of the Terms of Use.3. You have the sole responsibility of obtaining the most updated version of the Terms of Use which is available in the "Digital 21" Web site (http://www.og cio.gov.hk/en/business/tech_promotion/ccli/terms/t erms.htm).4. By accepting this Terms of Use, HKSARG shall grant you a non-exclusive license to use the Software and Document for any purpose, subject to clause 5 below.5. You are not allowed to make copies of the Software and Document except it is incidental to and necessary for the normal use of the Software. You are not allowed to adapt or modify the Software and Document or to distribute, sell, rent, or make available to the public the Software and Document, including copies or an adaptation of them.6. The Software and Document are protected by copyright. The licensors of the Government of Hong Kong Special Administrative Region are the owners of all copyright works in the Software and Document. All rights reserved.7. You understand and agree that use of the Software and Document are at your sole risk, that any material and/or data downloaded or otherwise obtained in relation to the Software and Document is at your discretion and risk and that you will be solely responsible for any damage caused to

your computer system or loss of data or any other loss that results from the download and use of the Software and Document in any manner whatsoever.8. In relation to the Software and Document, HKSARG hereby disclaims all warranties and conditions, including all implied warranties and conditions of merchantability, fitness for a particular purpose and non-infringement.9. HKSARG will not be liable for any direct, indirect, incidental, special or consequential loss of any kind resulting from the use of or the inability to use the Software and Document even if HKSARG has been advised of the possibility of such loss.10. You agree not to sue HKSARG and agree to indemnify, defend and hold harmless HKSARG, its officers and employees from any and all third party claims, liability, damages and/or costs (including, but not limited to, legal fees) arising from your use of the Software and Document, your violation of the Terms of Use or infringement of any intellectual property or other right of any person or entity.11. The Terms of Use will be governed by and construed in accordance with the laws of Hong Kong.12. Any waiver of any provision of the Terms of Use will be effective only if in writing and signed by HKSARG or its representative.13. If for any reason a court of competent jurisdiction finds any provision or portion of the Terms of Use to be unenforceable, the remainder of the Terms of Use will continue in full force and effect.14. The Terms of Use constitute the entire agreement between the parties with respect to the subject matter hereof and supersedes and replaces all prior or contemporaneous understandings or agreements, written or oral, regarding such subject matter.15.In addition to the licence granted in Clause 4, HKSARG hereby grants you a non-exclusive limited licence to reproduce and distribute the Software and Document with the following conditions:(i) not for financial gain unless it is incidental;(ii) reproduction and distribution of the Software and Document in complete and unmodified form; and(iii) when you distribute the Software and Document, you agree to attach the Terms of Use and a statement that the latest version of the Terms of Use is available from the "Office of the Government Chief Information Officer" Web site (http://www.ogcio .gov.hk/en/business/tech_promotion/ccli/terms/term s.htm).

IANA (Dec 30 2013) Opera uses Internet Assigned Numbers Authority:

Character encoding tag names and numbers. The original download site for this software is : https://www.iana.org

ICU (3) Opera uses ICU : International Components for

Unicode: Mapping table for GB18030The original

download site for this software is : http://site.icu-proj ect.org/http://source.icuproject.org/repos/icu/icu/trunk/license.html

MozTW (1.0) Opera uses MoxTW : MozTW project: Big5-2003

mapping tables. The original download site for this software is : https://moztw.orgThis piece of software is made available under the terms and conditions of CCPL

NPAPI (0.27) Opera uses NPAPI : Netscape 4 Plugin API: npapi.h,

npfunctions.h, npruntime.h and nptypes.h. Distributed as part of the Netscape 4 Plugin SDK.The original download site for this software is : wiki.mozilla.orgThis piece of software is made available under the terms and conditions of mozilla licencse as described below.

Unicode (4.0) Opera uses Unicode : Data from the Unicode

character database. The original download site for this software is : www.unicode.orghttp://www.unicod e.org/copyright.html

Webp (0.2.0) Opera uses Webp : libwebp is a library for decoding

images in the WebP format. Products may use it to decode WebP images. The turbo servers will eventually re-decode images to WebP. The original download site for this software is : https://developers.google.com/speed/webp/?csw=1 https://chromium.googlesource.com/webm/libwebp/ Additional IP Rights Grant (Patents)"This implementation" means the copyrightable works distributed by Google as part of the WebM Project.Google hereby grants to you a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in this section)patent license to make, have made, use, offer to sell, sell, import, transfer, and otherwise run, modify and propagate the contents of this implementation of VP8, where such license applies only to those patent claims, both currently owned by Google and acquired in the future, licensable by Google that are necessarily infringed by this implementation of VP8. This grant does not include claims that would be infringed only as a consequence of further modification of this implementation. If you or your agent or exclusive licensee institute or order or agree to the institution of patent litigation against any entity (including a cross-claim or counterclaim in a lawsuit) alleging that this implementation of VP8 or any code

incorporated within this implementation of VP8 constitutes direct or contributory patent infringement, or inducement of patent infringement, then any patent rights granted to you under this License for this implementation of VP8shall terminate as of the date such litigation is filed.

This piece of software is made available under the terms and conditions of the GPL v2 license, which can be found below.

live555 (0.82)

FaceBook SDK (3.0.1) This TV contains Facebook SDK. The Facebook SDK

for Android is the easiest way to integrate your Android app with Facebook's platform. The SDK provides support for Login with Facebook authentication, reading and writing to Facebook APIs and support for UI elements such as pickers and dialogs. The original download site for this software is : https://developer.facebook.com/docs/androidThis piece of software is made available under the terms and conditions of the Apache License version 2.

iptables (1.4.7) iptables is a user space application program that

allows a system administrator to configure the tables provided by the Linux kernel firewall (implemented as different Netfilter modules) and the chains and rules it stores. Different kernel modules and programs are currently used for different protocols; iptables applies to IPv4The original download site for this software is : https://android.googlesource.comThis piece of software is made available under the terms and conditions of the GPL v2.

libyuv (814) libyuv is an open source project that includes YUV

conversion and scaling functionality. The original download site for this software is : http://code.google.com/p/libyuvThis piece of software is made available under the terms and conditions BSD.

ffmpeg (2.1.3) This TV uses FFmpeg. FFmpeg is a complete, cross-

platform solution to record, convert and stream audio and video. The original download site for this software is : http://ffmpeg.orgThis piece of software is made available under the terms and conditions of the GPL v2 license, which can be found below.

u-boot (2011-12) U-boot is a boot loader for embedded boards based

on ARM, MIPS and other processors, which can be installed in a boot ROM and used to initialize and test the hardware or to download and run application code

Live555 provides RTP/RTCP/RTSP client. The original download site for this software is : http://www.live555.comThis piece of software is made available under the terms and conditions of the LGPL v2.1 license, which can be found below.

Bluetooth Stack (Bluedroid) This TV uses Bluetooth stack. The original download

site for this software is :This piece of software is made available under the terms and conditions of Android Apache License Version 2.

EXIF (NA) Exif JPEG header manipulation tool. The original

download site for this software is : http://www.sentex.net/~mwandel/jhead/Portions of this source code are in the public domain

and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of The Android Open Source Project nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS"AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOTLIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESSFOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THECOPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING,BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSSOF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSEDAND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUTOF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OFSUCH DAMAGE.

EXPAT (2.1.0) EXPAT is a XML Parser. The original download site for

Copyright (c) 2001, 2002, 2003, 2004, 2005, 2006 Expat maintainers. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OFMERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANYCLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT,TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THESOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

neven face recognition library (NA) This TV uses neven face recognition library which is

used for face recognitionThis piece of software is made available under the terms and conditions of Android Apache License version 2.

Unicode (4.8.1.1)

that the above copyright notice(s) and this permission notice appear in all copies of the Software and that both the above copyright notice(s) and this permission notice appear in supporting documentation. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE. Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software without prior written authorization of the copyright holder. All trademarks and registered trademarks mentioned herein are the property of their respective owners.

IPRoute2 (NA) IPRoute2 is used for TCP/IP, Networking and Traffic

control. The original download site for this software is : http://www.linuxfoundation.org/collaborate/workgr oups/networking/iproute2This piece of software is made available under the terms and conditions of GPL V2.

mtpd (NA) mtpd is used for VPN Network. The original download

site for this software is : http://libmtp.sourceforge.net/This piece of software is made available under the terms and conditions of Apache License version 2.0.

This TV uses Unicode which specifies the representation of text

The original download site for this software is : http://icu-project.orgICU License - ICU 1.8.1 and later

of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, provided

MDNS Responder (NA) MDNS Responder. The Mdns Responder project is a

component of Bonjour, Apple's ease-of-use IP networking initiative. The original download site for this software is : http://www.opensource.apple.com/t arballs/mDNSResponder/This piece of software is made available under the terms and conditions of Apache License version 2.0.

NFC (NA) NFC Semiconductor's NFC Library. Near Field

Communication (NFC) is a set of short-range wireless technologies, typically requiring a distance of 4cm or

less to initiate a connection. NFC allows you to share small payloads of data between an NFC tag and an Android-powered device, or between two Androidpowered devices. This piece of software is made available under the terms and conditions of Apache License version 2.0.

Skia (NA) Skia is a complete 2D graphic library for drawing Text,

Geometries, and Images. The original download site for this software is : http://code.google.com/p/skia/Copyright (c) 2011 Google Inc. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of Google Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS"AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOTLIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FORA PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHTOWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOTLIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANYTHEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USEOF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Sonic Audio Synthesis library (NA) The original download site for this software is :

http://www.sonivoxmi.com/This piece of software is made available under the terms and conditions of Apache License version 2.0.

Sqlite (3071100) The original download site for this software is :

www.sqlite.org.This piece of software is made available under the terms and conditions of Apache

License version 2.0.

Nuance Speech Recognition engine (NA) The original download site for this software is :

http://www.nuance.com/This piece of software is made available under the terms and conditions of Apache License version 2.0.

C++Standard Template Library library (5) This TV uses Implementation of the C++ Standard

Template Library. The original download site for this software is : http://stlport.sourceforge.netBoris Fomitchev grants Licensee a non-exclusive, nontransferable, royalty-free license to use STLport and its documentation without fee. By downloading, using, or copying STLport or any portion thereof, Licensee agrees to abide by the intellectual property laws and all other applicable laws of the United States of America, and to all of the terms and conditions of this Agreement. Licensee shall maintain the following copyright and permission notices on STLport sources and its documentation unchanged :Copyright 1999,2000 Boris Fomitchev

This material is provided "as is", with absolutely no warranty expressed or implied. Any use is at your own risk. Permission to use or copy this software for any purpose is hereby granted without fee, provided the above notices are retained on all copies. Permission to modify the code and to distribute modified code is granted, provided the above notices are retained, and a notice that the code was modified is included with the above copyright notice. The Licensee may distribute binaries compiled with STLport (whether original or modified) without any royalties or restrictions. The Licensee may distribute original or modified STLport sources, provided that: The conditions indicated in the above permission notice are met; The following copyright notices are retained when present, and conditions provided in accompanying permission notices are met :Copyright 1994 Hewlett-Packard Company Copyright 1996,97 Silicon Graphics Computer Systems, Inc. Copyright 1997 Moscow Center for SPARC Technology. Permission to use, copy, modify, distribute and sell this software and its documentation for any purpose is hereby granted without fee, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation. HewlettPackard Company makes no representations about the suitability of this software for any purpose. It is provided "as is" without express or implied warranty. Permission to use, copy, modify, distribute and sell this software and its documentation for any purpose is hereby granted without fee, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice

appear in supporting documentation. Silicon Graphics makes no representations about the suitability of this software for any purpose. It is provided "as is" without express or implied warranty. Permission to use, copy, modify, distribute and sell this software and its documentation for any purpose is hereby granted without fee, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation. Moscow Center for SPARC Technology makes no representations about the suitability of this software for any purpose. It is provided "as is" without express or implied warranty

svox (NA) The original download site for this software is :

http://www.nuance.com/This piece of software is made available under the terms and conditions of Apache License version 2.0.

tinyalsa (NA) This TV uses tinyalsa: a small library to interface with

ALSA in the Linux kernel The original download site for this software is : http://github.com/tinyalsaCopyright 2011, The Android Open Source Project Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of The Android Open Source Project nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY The Android Open Source Project ``AS IS'' ANDANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THEIMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSEARE DISCLAIMED. IN NO EVENT SHALL The Android Open Source Project BE LIABLEFOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIALDAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS ORSERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVERCAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICTLIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAYOUT OF THE USE OF THIS SOFTWARE, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCHDAMAGE.

Vorbis Decompression Library (NA) This TV uses Tremolo ARM-optimized Ogg Vorbis

decompression library. Vorbis is a general purpose audio and music encoding format contemporary to MPEG-4's AAC and TwinVQ, the next generation beyond MPEG audio layer 3The original download site for this software is : http://wss.co.uk/pinknoise/tremoCopyright (c) 2002-2008 Xiph.org Foundation Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:- Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.Redistributions in binary form must reproduce the above copy right notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.Neither the name of the Xiph.org Foundation nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOTLIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FORA PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE FOUNDATIONOR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOTLIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANYTHEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USEOF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

wpa_supplicant_Daemon (v0.8) Library used by legacy HAL to talk to wpa_supplicant

daemonThe original download site for this software is : http://hostap.epitest.fi/wpa_supplicant/This piece of software is made available under the terms and conditions of GPL version 2.

gson (2.3) Gson is a Java library that can be used to convert

Java Objects into their JSON representation. It can also be used to convert a JSON string to an equivalent Java object. Gson can work with arbitrary

Java objects including pre-existing objects that you do not have source-code of. The original download site for this software is : https://code.google.com/p/google-gson/This piece of software is made available under the terms and conditions of the Apache License 2.0

This software includes an implementation of the AES Cipher, licensed by Brian Gladman

The original download site for this software is : http://www.gladman.me.uk/This piece of software is licensed by Brian Gladman

libUpNp (1.2.1) The original download site for this software is :

http://upnp.sourceforge.net/This piece of software is made available under the terms and conditions of the BSD.

dnsmasq Dnsmasq is a lightweight, easy to configure DNS

forwarder and DHCP server The original download site for this software is : https:/

/android.googlesource.com/platform/external/dnma sqThis piece of software is made available under the terms and conditions of the GPL v2 license, which can be found below.

TomCrypt (1.1) iwedia stack is using tomcrypt for sw decryption The original download site for this software is : http://

manpages.ubuntu.com/manpages/saucy/man3/libto mcrypt.3.htmlThis piece of software is made available under the terms and conditions of the DO WHAT THE FUCK YOU WANT TO PUBLIC LICENSE

AsyncHttpclient (1.4.6) The original download site for this software is :

http://loopj.com/android-async-http/This piece of software is made available under the terms and conditions of the APACHE LICENSE 2.0

Jackson Parser (2.x) Ipepg client uses Jackson Parser for string

manipualation. The original download site for this software is : https://github.com/FasterXML/jacksoncoreThis piece of software is made available under the terms and conditions of the APACHE LICENSE 2.0

TP Vision Netherlands B.V. is grateful to the groups and individuals above for their contributions.

_________________________________

Inc. 51 Franklin Street, Fifth Floor, Boston, MA

02110-1301, USA

Everyone is permitted to copy and distribute verbatim copies

of this license document, but changing it is not allowed.

Preamble The licenses for most software are designed to take

away your freedom to share and change it. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program whose authors commit to using it. (Some other Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs; and that you know you can do these things.

To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights.

We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software.

Also, for each author's protection and ours, we want

to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and passed on, we want its recipients to know that what they have is not the original, so that any problems introduced by others will not reflect on the original authors' reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all.

The precise terms and conditions for copying, distribution and modification follow.

sections as part of a whole which is a work based on the Program, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program). Whether that is true depends on what the Program does.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change.

b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License.

c) If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same

a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,

b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,

c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the

balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

free for all its users. This license, the Lesser General Public License,

applies to some specially designated software packages--typically libraries--of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully about whether this license or the ordinary General Public License is the better strategy to use in any particular case, based on the explanations below.

When we speak of free software, we are referring to freedom of use, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive source code or can get it if you want it; that you can change the software and use pieces of it in new free programs; and that you are informed that you can do these things.

Each version is given a distinguishing version number. If the Program specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation.

NO WARRANTY

________________________________

Inc. 51 Franklin Street, Fifth Floor, Boston, MA

02110-1301 USA Everyone is permitted to copy and distribute verbatim

copies of this license document, but changing it is not

allowed.

[This is the first released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2, hence the version number

2.1.] Preamble The licenses for most software are designed to take

away your freedom to share and change it. By contrast, the GNU General Public Licenses are intended to guarantee your freedom to share and change free software--to make sure the software is

To protect your rights, we need to make restrictions that forbid distributors to deny you these rights or to ask you to surrender these rights. These restrictions translate to certain responsibilities for you if you distribute copies of the library or if you modify it.

For example, if you distribute copies of the library, whether gratis or for a fee, you must give the recipients all the rights that we gave you. You must make sure that they, too, receive or can get the source code. If you link other code with the library, you must provide complete object files to the recipients, so that they can relink them with the library after making changes to the library and recompiling it. And you must show them these terms so they know their rights.

We protect your rights with a two-step method: (1) we copyright the library, and (2) we offer you this license, which gives you legal permission to copy, distribute and/or modify the library.

To protect each distributor, we want to make it very clear that there is no warranty for the free library. Also, if the library is modified by someone else and passed on, the recipients should know that what they have is not the original version, so that the original author's reputation will not be affected by problems that might be introduced by others.

Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license.

Most GNU software, including some libraries, is covered by the ordinary GNU General Public License. This license, the GNU Lesser General Public License, applies to certain designated libraries, and is quite

different from the ordinary General Public License. We use this license for certain libraries in order to permit linking those libraries into non-free programs.

When a program is linked with a library, whether statically or using a shared library, the combination of the two is legally speaking a combined work, a derivative of the original library. The ordinary General Public License therefore permits such linking only if the entire combination fits its criteria of freedom. The Lesser General Public License permits more lax criteria for linking other code with the library.

We call this license the "Lesser" General Public License because it does Less to protect the user's freedom than the ordinary General Public License. It also provides other free software developers Less of an advantage over competing non-free programs. These disadvantages are the reason we use the ordinary General Public License for many libraries. However, the Lesser license provides advantages in certain special circumstances.

For example, on rare occasions, there may be a special need to encourage the widest possible use of a certain library, so that it becomes a de-facto standard. To achieve this, non-free programs must be allowed to use the library. A more frequent case is that a free library does the same job as widely used non-free libraries. In this case, there is little to gain by limiting the free library to free software only, so we use the Lesser General Public License.

In other cases, permission to use a particular library in non-free programs enables a greater number of people to use a large body of free software. For example, permission to use the GNU C Library in nonfree programs enables many more people to use the whole GNU operating system, as well as its variant, the GNU/Linux operating system.

Although the Lesser General Public License is Less protective of the users' freedom, it does ensure that the user of a program that is linked with the Library has the freedom and the wherewithal to run that program using a modified version of the Library.

The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference between a "work based on the library" and a "work that uses the library". The former contains code derived from the library, whereas the latter must be combined with the library in order to run.

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

A "library" means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of those functions and data) to form executables.

The "Library", below, refers to any such software library or work which has been distributed under

these terms. A "work based on the Library" means either the Library or any derivative work under copyright law: that is to say, a work containing the Library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term "modification".)

"Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library.

Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing it). Whether that is true depends on what the Library does and what the program that uses the Library does.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

?a) The modified work must itself be a software library.

?b) You must cause the files modified to carry prominent notices stating that you changed the files and the date of any change.

?c) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this License.

?d) If a facility in the modified Library refers to a function or a table of data to be supplied by an application program that uses the facility, other than as an argument passed when the facility is invoked, then you must make a good faith effort to ensure that, in the event an application does not supply such function or table, the facility still operates, and performs whatever part of its purpose remains meaningful.

(For example, a function in a library to compute square roots has a purpose that is entirely welldefined independent of the application. Therefore, Subsection 2d requires that any application-supplied function or table used by this function must be optional: if the application does not supply it, the square root function must still compute square roots.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Library, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same

sections as part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

In addition, mere aggregation of another work not based on the Library with the Library (or with a work based on the Library) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies to all subsequent copies and derivative works made from that copy.

This option is useful when you wish to copy part of the code of the Library into a program that is not a library.

If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code.

However, linking a "work that uses the Library" with the Library creates an executable that is a derivative of the Library (because it contains portions of the Library), rather than a "work that uses the library". The executable is therefore covered by this License. Section 6 states terms for distribution of such executables.

When a "work that uses the Library" uses material from a header file that is part of the Library, the object code for the work may be a derivative work of the Library even though the source code is not. Whether this is true is especially significant if the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true is not precisely defined by law.

If such an object file uses only numerical parameters, data structure layouts and accessors, and small macros and small inline functions (ten lines or less in length), then the use of the object file is unrestricted, regardless of whether it is legally a derivative work. (Executables containing this object code plus portions of the Library will still fall under Section 6.)

Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section 6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with the Library itself.

You must give prominent notice with each copy of the work that the Library is used in it and that the Library and its use are covered by this License. You must supply a copy of this License. If the work during execution displays copyright notices, you must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this License. Also, you must do one of these things:

?a) Accompany the work with the complete corresponding machine-readable source code for the Library including whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the work is an executable linked with the Library, with the complete machine-readable "work that uses the Library", as object code and/or source code, so that the user can modify the Library and then relink to produce a modified executable containing the modified Library. (It is understood that the user who changes the contents of definitions files in the Library will not necessarily be able to recompile the application to use the modified definitions.)

?b) Use a suitable shared library mechanism for linking with the Library. A suitable mechanism is one that (1) uses at run time a copy of the library already present on the user's computer system, rather than copying library functions into the executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified version is interface-compatible with the version that the work was made with.

?c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials specified in Subsection 6a, above, for a charge no more than the cost of performing this distribution.

?d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specified materials from the same place.

?e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy.

For an executable, the required form of the "work that uses the Library" must include any data and utility programs needed for reproducing the executable from it. However, as a special exception, the materials to be distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction means you cannot use both

them and the Library together in an executable that you distribute.

?a) Accompany the combined library with a copy of the same work based on the Library, uncombined with any other library facilities. This must be distributed under the terms of the Sections above.

?b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining where to find the accompanying uncombined form of the same work.

LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply, and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

Each version is given a distinguishing version number. If the Library specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation. If the Library does not specify a license version number, you may choose any version ever published by the Free Software Foundation.

NO WARRANTY

_______________________________

______________________________

MIT LICENSE Permission is hereby granted, free of charge, to any

person obtaining a copy of this software and associated

documentation files (the "Software"), to deal in the Software without

restriction, including without limitation the rights to use, copy, modify,

merge, publish, distribute, sublicense, and/or sell copies of the

Software, and to permit persons to whom the Software is furnished to

do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included

in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND,

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF

BSD LICENSE Redistribution and use in source and binary forms,

with or without modification, are permitted provided that the following conditions are met:

THIS SOFTWARE IS PROVIDED BY THE REGENTS AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.

IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY

CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT,

TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE

SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

_____________________________

Apache License

Version 2.0, January 2004

http://www.apache.org/licenses/

TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION

1. Definitions.

"License" shall mean the terms and conditions for use, reproduction,

and distribution as defined by Sections 1 through 9 of this document.

"Licensor" shall mean the copyright owner or entity authorized by

the copyright owner that is granting the License.

"Object" form shall mean any form resulting from mechanical

transformation or translation of a Source form, including but

not limited to compiled object code, generated documentation,

and conversions to other media types.

"Work" shall mean the work of authorship, whether in Source or

Object form, made available under the License, as indicated by a

(an example is provided in the Appendix below).

"Derivative Works" shall mean any work, whether in Source or Object

form, that is based on (or derived from) the Work and for which the

editorial revisions, annotations, elaborations, or other modifications

"Legal Entity" shall mean the union of the acting entity and all

other entities that control, are controlled by, or are under common

control with that entity. For the purposes of this definition,

"control" means (i) the power, direct or indirect, to cause the

direction or management of such entity, whether by contract or

otherwise, or (ii) ownership of fifty percent (50%) or more of the

outstanding shares, or (iii) beneficial ownership of such entity.

"You" (or "Your") shall mean an individual or Legal Entity

exercising permissions granted by this License.

"Source" form shall mean the preferred form for making modifications,

including but not limited to software source code, documentation

source, and configuration files.

represent, as a whole, an original work of authorship. For the purposes

of this License, Derivative Works shall not include works that remain

separable from, or merely link (or bind by name) to the interfaces of,

the Work and Derivative Works thereof.

"Contribution" shall mean any work of authorship, including

the original version of the Work and any modifications or additions

to that Work or Derivative Works thereof, that is intentionally

submitted to Licensor for inclusion in the Work by the copyright owner

or by an individual or Legal Entity authorized to submit on behalf of

the copyright owner. For the purposes of this definition, "submitted"

means any form of electronic, verbal, or written communication sent

to the Licensor or its representatives, including but not limited to

communication on electronic mailing lists, source code control systems,

institute patent litigation against any entity (including a

and issue tracking systems that are managed by, or on behalf of, the

Licensor for the purpose of discussing and improving the Work, but

excluding communication that is conspicuously marked or otherwise

designated in writing by the copyright owner as "Not a Contribution."

"Contributor" shall mean Licensor and any individual or Legal Entity

on behalf of whom a Contribution has been received by Licensor and

subsequently incorporated within the Work.

2. Grant of Copyright License. Subject to the terms and conditions of

this License, each Contributor hereby grants to You a perpetual,

worldwide, non-exclusive, no-charge, royaltyfree, irrevocable

publicly display, publicly perform, sublicense, and distribute the

Work and such Derivative Works in Source or Object form.

3. Grant of Patent License. Subject to the terms and conditions of

this License, each Contributor hereby grants to You a perpetual,

worldwide, non-exclusive, no-charge, royaltyfree, irrevocable

(except as stated in this section) patent license to make, have made,

use, offer to sell, sell, import, and otherwise transfer the Work,

cross-claim or counterclaim in a lawsuit) alleging that the Work

or a Contribution incorporated within the Work constitutes direct

or contributory patent infringement, then any patent licenses

granted to You under this License for that Work shall terminate

as of the date such litigation is filed.

4. Redistribution. You may reproduce and distribute copies of the

Work or Derivative Works thereof in any medium, with or without

modifications, and in Source or Object form, provided that You

meet the following conditions:

(a) You must give any other recipients of the Work or

Derivative Works a copy of this License; and

(b) You must cause any modified files to carry prominent notices

stating that You changed the files; and

that You distribute, all copyright, patent, trademark, and

attribution notices from the Source form of the Work,

excluding those notices that do not pertain to any part of

the Derivative Works; and

where such license applies only to those patent claims licensable

by such Contributor that are necessarily infringed by their

Contribution(s) alone or by combination of their Contribution(s)

with the Work to which such Contribution(s) was submitted. If You

(d) If the Work includes a "NOTICE" text file as part of its

distribution, then any Derivative Works that You distribute must

include a readable copy of the attribution notices contained

within such NOTICE file, excluding those notices that do not

pertain to any part of the Derivative Works, in at least one

of the following places: within a NOTICE text file distributed

as part of the Derivative Works; within the Source form or

documentation, if provided along with the Derivative Works; or,

within a display generated by the Derivative Works, if and

wherever such third-party notices normally appear. The contents

of the NOTICE file are for informational purposes only and

do not modify the License. You may add Your own attribution

notices within Derivative Works that You distribute, alongside

or as an addendum to the NOTICE text from the Work, provided

that such additional attribution notices cannot be construed

as modifying the License.

You may add Your own copyright statement to Your modifications and

may provide additional or different license terms and conditions

for use, reproduction, or distribution of Your modifications, or

for any such Derivative Works as a whole, provided Your use,

reproduction, and distribution of the Work otherwise complies with

the conditions stated in this License.

with Licensor regarding such Contributions.

6. Trademarks. This License does not grant permission to use the trade

names, trademarks, service marks, or product names of the Licensor,

except as required for reasonable and customary use in describing the

origin of the Work and reproducing the content of the NOTICE file.

7. Disclaimer of Warranty. Unless required by applicable law or

agreed to in writing, Licensor provides the Work (and each

Contributor provides its Contributions) on an "AS IS" BASIS,

WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or

implied, including, without limitation, any warranties or conditions

of TITLE, NON-INFRINGEMENT, MERCHANTABILITY, or FITNESS FOR A

PARTICULAR PURPOSE. You are solely responsible for determining the

appropriateness of using or redistributing the Work and assume any

risks associated with Your exercise of permissions under this License.

8. Limitation of Liability. In no event and under no legal theory,

whether in tort (including negligence), contract, or otherwise,

unless required by applicable law (such as deliberate and grossly

5. Submission of Contributions. Unless You explicitly state otherwise,

any Contribution intentionally submitted for inclusion in the Work

by You to the Licensor shall be under the terms and conditions of

this License, without any additional terms or conditions.

Notwithstanding the above, nothing herein shall supersede or modify

the terms of any separate license agreement you may have executed

negligent acts) or agreed to in writing, shall any Contributor be

liable to You for damages, including any direct, indirect, special,

incidental, or consequential damages of any character arising as a

result of this License or out of the use or inability to use the

Work (including but not limited to damages for loss of goodwill,

work stoppage, computer failure or malfunction, or any and all

other commercial damages or losses), even if such Contributor

has been advised of the possibility of such damages.

Licensed under the Apache License, Version 2.0 (the "License");

you may not use this file except in compliance with the License.

9. Accepting Warranty or Additional Liability. While redistributing

the Work or Derivative Works thereof, You may choose to offer,

and charge a fee for, acceptance of support, warranty, indemnity,

or other liability obligations and/or rights consistent with this

License. However, in accepting such obligations, You may act only

on Your own behalf and on Your sole responsibility, not on behalf

of any other Contributor, and only if You agree to indemnify,

defend, and hold each Contributor harmless for any liability

incurred by, or claims asserted against, such Contributor by reason

of your accepting any such warranty or additional liability.

END OF TERMS AND CONDITIONS

APPENDIX: How to apply the Apache License to your work.

You may obtain a copy of the License at

http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software

distributed under the License is distributed on an "AS IS" BASIS,

WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.

See the License for the specific language governing permissions and

limitations under the License.

_____________________________

This copy of the libpng notices is provided for your convenience. In case of

any discrepancy between this copy and the notices in the file png.h that is

included in the libpng distribution, the latter shall prevail.

To apply the Apache License to your work, attach the following

boilerplate notice, with the fields enclosed by brackets "[]"

replaced with your own identifying information. (Don't include

the brackets!) The text should be enclosed in the appropriate

comment syntax for the file format. We also recommend that a

file or class name and description of purpose be included on the

same "printed page" as the copyright notice for easier

identification within third-party archives.

If you modify libpng you may insert additional notices immediately following

this sentence.

This code is released under the libpng license.

libpng versions 1.2.6, August 15, 2004, through 1.4.1, February 25, 2010, are

distributed according to the same disclaimer and license as libpng-1.2.5

with the following individual added to the list of

Contributing Authors

Cosmin Truta

libpng versions 1.0.7, July 1, 2000, through 1.2.5 October 3, 2002, are

distributed according to the same disclaimer and license as libpng-1.0.6

with the following individuals added to the list of Contributing Authors

Simon-Pierre Cadieux Eric S. Raymond Gilles Vollant

and with the following additions to the disclaimer:

There is no warranty against interference with your enjoyment of the

Distributed according to the same disclaimer and license as libpng-0.88,

with the following individuals added to the list of Contributing Authors:

John Bowler Kevin Bracey Sam Bushell Magnus Holmgren Greg Roelofs Tom Tanner

libpng versions 0.5, May 1995, through 0.88, January 1996, are

For the purposes of this copyright and license, "Contributing Authors"

is defined as the following set of individuals:

library or against infringement. There is no warranty that our

efforts or the library will fulfill any of your particular purposes

or needs. This library is provided with all faults, and the entire

risk of satisfactory quality, performance, accuracy, and effort is with

the user.

libpng versions 0.97, January 1998, through 1.0.6, March 20, 2000, are

distributed according to the same disclaimer and license as libpng-0.96,

with the following individuals added to the list of Contributing Authors:

Tom Lane Glenn Randers-Pehrson Willem van Schaik

libpng versions 0.89, June 1996, through 0.96, May 1997, are

Andreas Dilger Dave Martindale Guy Eric Schalnat Paul Schmidt Tim Wegner

The PNG Reference Library is supplied "AS IS". The Contributing Authors

and Group 42, Inc. disclaim all warranties, expressed or implied,

including, without limitation, the warranties of merchantability and of

fitness for any purpose. The Contributing Authors and Group 42, Inc.

assume no liability for direct, indirect, incidental, special, exemplary,

or consequential damages, which may result from the use of the PNG

Reference Library, even if advised of the possibility of such damage.

Permission is hereby granted to use, copy, modify, and distribute this

source code, or portions hereof, for any purpose, without fee, subject

to the following restrictions:

The FreeType Project LICENSE

be misrepresented as being the original source.

source or altered source distribution.

The Contributing Authors and Group 42, Inc. specifically permit, without

fee, and encourage the use of this source code as a component to

supporting the PNG file format in commercial products. If you use this

source code in a product, acknowledgment is not required but would be

A "png_get_copyright" function is available, for convenient use in "about"

boxes and the like:

----------------------------

2006-Jan-27

David Turner, Robert Wilhelm, and Werner Lemberg

Introduction ============

The FreeType Project is distributed in several archive packages;

some of them may contain, in addition to the FreeType font engine,

printf("%s",png_get_copyright(NULL));

Also, the PNG logo (in PNG format, of course) is supplied in the

files "pngbar.png.jpg" and "pngbar.jpg (88x31) and "pngnow.png.jpg" (98x31).

Libpng is OSI Certified Open Source Software. OSI Certified Open Source is a

certification mark of the Open Source Initiative.

Glenn Randers-Pehrson glennrp at users.sourceforge.net February 25, 2010

_____________________________ This software is based in part on the work of the

FreeType Team.

----------------------

various tools and contributions which rely on, or relate to, the

FreeType Project.

This license applies to all files found in such packages, and

which do not fall under their own explicit license. The license

affects thus the FreeType font engine, the test programs,

documentation and makefiles, at the very least.

This license was inspired by the BSD, Artistic, and IJG

(Independent JPEG Group) licenses, which all encourage inclusion

and use of free software in commercial and freeware products

alike. As a consequence, its main points are that:

o We don't promise that this software works. However, we will be

interested in any kind of bug reports. (`as is' distribution)

o You can use this software for whatever you want, in parts or

full form, without having to pay us. (`royaltyfree' usage)

o You may not pretend that you wrote this software. If you use

it, or only parts of it, in a program, you must acknowledge

Throughout this license, the terms `package', `FreeType Project',

and `FreeType archive' refer to the set of files originally

distributed by the authors (David Turner, Robert Wilhelm, and

Werner Lemberg) as the `FreeType Project', be they named as alpha,

beta or final release.

somewhere in your documentation that you have used the

FreeType code. (`credits')

We specifically permit and encourage the inclusion of this

software, with or without modifications, in commercial products.

We disclaim all warranties covering The FreeType Project and

assume no liability related to The FreeType Project.

Finally, many people asked us for a preferred form for a

credit/disclaimer to use in compliance with this license. We thus

encourage you to use the following text:

`You' refers to the licensee, or person using the project, where

`using' is a generic term including compiling the project's source

code as well as linking it to form a `program' or `executable'.

This program is referred to as `a program using the FreeType

engine'.

This license applies to all files distributed in the original

FreeType Project, including all source code, binaries and

documentation, unless otherwise stated in the file in its

original, unmodified form as distributed in the original archive.

If you are unsure whether or not a particular file is covered by

""" Portions of this software are copyright ?<year>

Please replace <year> with the value from the FreeType version you

actually use.

Legal Terms ===========

--------------

this license, you must contact us to verify this.

specified below.

--------------

THE FREETYPE PROJECT IS PROVIDED `AS IS' WITHOUT WARRANTY OF ANY

KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. IN NO EVENT WILL ANY OF THE

AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY DAMAGES CAUSED BY THE

USE OR THE INABILITY TO

our work, you must acknowledge us. However, no fee need be paid

to us.

USE, OF THE FREETYPE PROJECT.

-----------------

This license grants a worldwide, royalty-free, perpetual and

irrevocable right and license to use, execute, perform, compile,

display, copy, create derivative works of, distribute and

sublicense the FreeType Project (in both source and object code

forms) and derivative works thereof for any purpose; and to

authorize others to exercise some or all of the rights granted

herein, subject to the following conditions:

o Redistribution of source code must retain this license file

(`FTL.TXT') unaltered; any additions, deletions or changes to

the original files must be clearly indicated in accompanying

documentation. The copyright notices of the unaltered,

original files must be preserved in all copies of source

files.

--------------

Neither the FreeType authors and contributors nor you shall use

the name of the other for commercial, advertising, or promotional

purposes without specific prior written permission.

We suggest, but do not require, that you use one or more of the

following phrases to refer to this software in your documentation

or advertising materials: `FreeType Project', `FreeType Engine',

`FreeType library', or `FreeType Distribution'.

As you have not signed this license, you are not required to

accept it. However, as the FreeType Project is copyrighted

material, only this license, or another one contracted with the

authors, grants you the right to use, distribute, and modify it.

Therefore, by using, distributing, or modifying the FreeType

Project, you indicate that you understand and accept all the terms

o Redistribution in binary form must provide a disclaimer that

states that the software is based in part of the work of the

FreeType Team, in the distribution documentation. We also

encourage you to put an URL to the FreeType web page in your

documentation, though this isn't mandatory.

These conditions apply to any software derived from or based on

the FreeType Project, not just the unmodified files. If you use

of this license.

-----------

There are two mailing lists related to FreeType:

o freetype@nongnu.org

Discusses general use and applications of FreeType, as well as

future and wanted additions to the library and distribution.

If you are looking for support, start in this list if you

haven't found anything to help you in the documentation.

o freetype-devel@nongnu.org

* are met: * * 1. Redistributions of source code must retain the

above copyright

Discusses bugs, as well as engine internals, design issues,

specific licenses, porting, etc.

Our home page can be found at

http://www.freetype.org

--- end of FTL.TXT ---

_____________________________

LICENSE ISSUES ==============

The OpenSSL toolkit stays under a dual license, i.e. both the conditions of

the OpenSSL License and the original SSLeay license apply to the toolkit.

See below for the actual license texts. Actually both licenses are BSD-style

Open Source licenses. In case of any license issues related to OpenSSL

please contact openssl-core@openssl.org.

OpenSSL License

---------------

rights reserved. * * Redistribution and use in source and binary forms,

with or without * modification, are permitted provided that the

following conditions

* notice, this list of conditions and the following disclaimer.

* * 2. Redistributions in binary form must reproduce

the above copyright * notice, this list of conditions and the following

disclaimer in * the documentation and/or other materials

provided with the * distribution. * * 3. All advertising materials mentioning features or

use of this * software must display the following

acknowledgment: * "This product includes software developed by

the OpenSSL Project * for use in the OpenSSL Toolkit.

(http://www.openssl.org/)" * * 4. The names "OpenSSL Toolkit" and "OpenSSL

Project" must not be used to * endorse or promote products derived from this

software without * prior written permission. For written

permission, please contact * openssl-core@openssl.org. * * 5. Products derived from this software may not be

called "OpenSSL" * nor may "OpenSSL" appear in their names

without prior written * permission of the OpenSSL Project. * * 6. Redistributions of any form whatsoever must

retain the following * acknowledgment: * "This product includes software developed by

the OpenSSL Project * for use in the OpenSSL Toolkit

(http://www.openssl.org/)" * * THIS SOFTWARE IS PROVIDED BY THE OpenSSL

PROJECT ``AS IS'' AND ANY

commercial use as long as

* EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE

* IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

* PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR

* ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,

* SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT

* NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;

* LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)

* HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,

* STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)

* ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED

* OF THE POSSIBILITY OF SUCH DAMAGE. * =========================== *

* the following conditions are aheared to. The following conditions

* apply to all code found in this distribution, be it the RC4, RSA,

* lhash, DES, etc., code; not just the SSL code. The SSL documentation

* included with this distribution is covered by the same copyright terms

* except that the holder is Tim Hudson (tjh@cryptsoft.com).

* * Copyright remains Eric Young's, and as such any

should be given attribution * as the author of the parts of the library used. * This can be in the form of a textual message at

program startup or * in documentation (online or textual) provided with

the package. * * Redistribution and use in source and binary forms,

with or without

* This product includes cryptographic software written by Eric Young

* (eay@cryptsoft.com). This product includes software written by Tim

* Hudson (tjh@cryptsoft.com). * */

Original SSLeay License

-----------------------

with Netscapes SSL. * * This library is free for commercial and non-

* modification, are permitted provided that the following conditions

* are met: * 1. Redistributions of source code must retain the

disclaimer. * 2. Redistributions in binary form must reproduce

the above copyright * notice, this list of conditions and the following

disclaimer in the * documentation and/or other materials

provided with the distribution. * 3. All advertising materials mentioning features or

use of this software * must display the following acknowledgement: * "This product includes cryptographic software

written by * Eric Young (eay@cryptsoft.com)" * The word 'cryptographic' can be left out if the

rouines from the library * being used are not cryptographic related :-).

* 4. If you include any Windows specific code (or a derivative thereof) from

* the apps directory (application code) you must include an acknowledgement:

* "This product includes software written by Tim Hudson (tjh@cryptsoft.com)"

* * THIS SOFTWARE IS PROVIDED BY ERIC YOUNG

``AS IS'' AND * ANY EXPRESS OR IMPLIED WARRANTIES,

INCLUDING, BUT NOT LIMITED TO, THE * IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE * ARE DISCLAIMED. IN NO EVENT SHALL THE

AUTHOR OR CONTRIBUTORS BE LIABLE

1.0.1. "Commercial Use" means distribution or otherwise making the

Covered Code available to a third party.

1.1. "Contributor" means each entity that creates or contributes to

the creation of Modifications.

1.2. "Contributor Version" means the combination of the Original

Code, prior Modifications used by a Contributor, and the Modifications

made by that particular Contributor.

* FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL

* DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS

* OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)

* HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT

* LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY

* OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF

* SUCH DAMAGE. * * The licence and distribution terms for any

publically available version or * derivative of this code cannot be changed. i.e. this

code cannot simply be * copied and put under another distribution licence * [including the GNU Public Licence.] */

_____________________________

1.3. "Covered Code" means the Original Code or Modifications or the

combination of the Original Code and Modifications, in each case

including portions thereof.

1.4. "Electronic Distribution Mechanism" means a mechanism generally

accepted in the software development community for the electronic

transfer of data.

1.5. "Executable" means Covered Code in any form other than Source

Code.

1.6. "Initial Developer" means the individual or entity identified

as the Initial Developer in the Source Code notice required by Exhibit

1.7. "Larger Work" means a work which combines Covered Code or

MOZILLA PUBLIC LICENSE

Version 1.1

---------------

portions thereof with code not governed by the terms of this License.

1.8. "License" means this document.

1.8.1. "Licensable" means having the right to grant, to the maximum

extent possible, whether at the time of the initial grant or

subsequently acquired, any and all of the rights conveyed herein.

Contributor's choice. The Source Code can be in a compressed or

archival form, provided the appropriate decompression or de-archiving

software is widely available

1.9. "Modifications" means any addition to or deletion from the

substance or structure of either the Original Code or any previous

Modifications. When Covered Code is released as a series of files, a

Modification is: A. Any addition to or deletion from the

contents of a file containing Original Code or previous

Modifications.

B. Any new file that contains any part of the Original Code or

previous Modifications.

1.10. "Original Code" means Source Code of computer software code

which is described in the Source Code notice required by Exhibit A as

Original Code, and which, at the time of its release under this

for no charge.

1.12. "You" (or "Your") means an individual or a legal entity

exercising rights under, and complying with all of the terms of, this

License or a future version of this License issued under Section 6.1.

For legal entities, "You" includes any entity which controls, is

controlled by, or is under common control with You. For purposes of

this definition, "control" means (a) the power, direct or indirect,

to cause the direction or management of such entity, whether by

contract or otherwise, or (b) ownership of more than fifty percent

(50%) of the outstanding shares or beneficial ownership of such

entity.

License is not already Covered Code governed by this License.

1.10.1. "Patent Claims" means any patent claim(s), now owned or

hereafter acquired, including without limitation, method, process,

and apparatus claims, in any patent Licensable by grantor.

1.11. "Source Code" means the preferred form of the Covered Code for

making modifications to it, including all modules it contains, plus

any associated interface definition files, scripts used to control

compilation and installation of an Executable, or source code

differential comparisons against either the Original Code or another

well known, available Covered Code of the

2.1. The Initial Developer Grant. The Initial Developer hereby grants You a world-

wide, royalty-free, non-exclusive license, subject to third party

intellectual property claims: (a) under intellectual property rights

(other than patent or trademark) Licensable by Initial

Developer to use, reproduce, modify, display, perform, sublicense and

distribute the Original Code (or portions thereof) with or

without Modifications, and/or as part of a Larger Work; and

(b) under Patents Claims infringed by the making, using or

selling of Original Code, to make, have

made, use, practice, sell, and offer for sale, and/or otherwise

dispose of the Original Code (or portions thereof).

2.1(a) and (b) are effective on the date Initial Developer

first distributes Original Code under the terms of this

License.

(d) Notwithstanding Section 2.1(b) above, no patent license is

granted: 1) for code that You delete from the Original Code; 2)

separate from the Original Code; or 3) for infringements caused

by: i) the modification of the Original Code or ii) the

combination of the Original Code with other software or devices.

2.2. Contributor Grant. Subject to third party intellectual property

claims, each Contributor hereby grants You a world-wide, royalty-free,

non-exclusive license

(a) under intellectual property rights (other than patent or

trademark) Licensable by Contributor, to use, reproduce, modify,

display, perform, sublicense and distribute the Modifications

created by such Contributor (or portions thereof) either on an

of such combination), to make, use, sell, offer for sale, have

made, and/or otherwise dispose of: 1) Modifications made by that

Contributor (or portions thereof); and 2) the combination of

Modifications made by that Contributor with its Contributor

Version (or portions of such combination).

effective on the date Contributor first makes Commercial Use of

the Covered Code.

(d) Notwithstanding Section 2.2(b) above, no patent license is

granted: 1) for any code that Contributor has deleted from the

Contributor Version; 2) separate from the Contributor Version;

3) for infringements caused by: i) third party modifications of

Contributor Version or ii) the combination of Modifications made

by that Contributor with other software (except as part of the

Contributor Version) or other devices; or

4) under Patent Claims infringed by Covered Code in the

absence of Modifications made by that Contributor.

3.1. Application of License.

unmodified basis, with other Modifications, as Covered Code

and/or as part of a Larger Work; and

(b) under Patent Claims infringed by the making, using, or

selling of Modifications made by that Contributor either alone

and/or in combination with its Contributor Version (or portions

The Modifications which You create or to which You contribute are

governed by the terms of this License, including without limitation

Section 2.2. The Source Code version of Covered Code may be

distributed only under the terms of this License or a future version

of this License released under Section 6.1, and You must include a

copy of this License with every copy of the

Source Code You distribute. You may not offer or impose any

terms on any Source Code

Executable version or related documentation in which You describe the

origin or ownership of the Covered Code.

version that alters or restricts the applicable version of this

License or the recipients' rights hereunder. However, You may include

an additional document offering the additional rights described in

Section 3.5.

3.2. Availability of Source Code. Any Modification which You create or to which

You contribute must be made available in Source Code form under the

terms of this License either on the same media as an Executable

version or via an accepted Electronic Distribution Mechanism to anyone to

whom you made an Executable version available; and if made

available via Electronic

3.4. Intellectual Property Matters (a) Third Party Claims. If Contributor has knowledge that a

license under a third party's intellectual property rights is required to

exercise the rights granted by such Contributor under

Sections 2.1 or 2.2, Contributor must include a text file with

the Source Code distribution titled "LEGAL" which

describes the claim and the party making the claim in sufficient detail

that a recipient will know whom to contact. If Contributor

obtains such knowledge after the Modification is made available as

described in Section 3.2,

Distribution Mechanism, must remain available for at least twelve (12)

months after the date it initially became available, or at least six

(6) months after a subsequent version of that particular Modification

has been made available to such recipients. You are responsible for

ensuring that the Source Code version remains available even if the

Electronic Distribution Mechanism is maintained by a third party.

3.3. Description of Modifications. You must cause all Covered Code to which You

contribute to contain a file documenting the changes You made to

create that Covered Code and the date of any change. You must include a

prominent statement that

Contributor shall promptly modify the LEGAL file in all copies

Contributor makes available thereafter and shall take other steps

(such as notifying appropriate mailing lists or newsgroups)

reasonably calculated to inform those who received the Covered

Code that new knowledge has been obtained.

(b) Contributor APIs. If Contributor's Modifications include an

application programming interface and Contributor has knowledge

of patent licenses which are reasonably necessary to implement

that API, Contributor must also include this information in the

LEGAL file.

the Modification is derived, directly or indirectly, from Original

Code provided by the Initial Developer and including the name of the

Initial Developer in (a) the Source Code, and (b) in any notice in an

disclosed pursuant to Section 3.4(a) above, Contributor

believes that Contributor's

Modifications are Contributor's original creation(s) and/or

and if You include a notice stating that the Source Code version of

Contributor has sufficient rights to grant the rights conveyed by

this License.

3.5. Required Notices. You must duplicate the notice in Exhibit A in

each file of the Source Code. If it is not possible to put such notice in

a particular Source Code file due to its structure, then You must

include such notice in a location (such as a relevant directory) where a

user would be likely to look for such a notice. If You created one or

more Modification(s) You may add your name as a Contributor to the

notice described in Exhibit A. You must also duplicate this License

in any documentation for the Source Code where You describe

recipients' rights or ownership rights relating to Covered Code. You may

choose to offer, and to charge a fee for, warranty, support, indemnity or

liability obligations to one or more recipients of

Covered Code. However, You may do so only on Your own behalf, and not on

behalf of the Initial Developer or any Contributor. You must make it

absolutely clear than any such warranty, support, indemnity or

liability obligation is offered by You alone, and You hereby agree to

indemnify the Initial Developer and every Contributor for any

liability incurred by the

the Covered Code is available under the terms of this License,

including a description of how and where You have fulfilled the

obligations of Section 3.2. The notice must be conspicuously included

in any notice in an Executable version, related documentation or

collateral in which You describe recipients' rights relating to the

Covered Code. You may distribute the Executable version of Covered

Code or ownership rights under a license of Your choice, which may

contain terms different from this License, provided that You are in

compliance with the terms of this License and that the license for the

Executable version does not attempt to limit or alter the recipient's

rights in the Source Code version from the rights set forth in this

License. If You distribute the Executable version under a different

license You must make it absolutely clear that any terms which differ

from this License are offered by You alone, not by the Initial

Developer or any Contributor. You hereby agree to indemnify the

Initial Developer and every Contributor for any liability incurred by

the Initial Developer or such Contributor as a result of any such

terms You offer.

3.7. Larger Works.

Initial Developer or such Contributor as a result of warranty,

support, indemnity or liability terms You offer.

3.6. Distribution of Executable Versions. You may distribute Covered Code in Executable

form only if the requirements of Section 3.1-3.5 have been met

for that Covered Code,

You may create a Larger Work by combining Covered Code with other code

not governed by the terms of this License and distribute the Larger

Work as a single product. In such a case, You must make sure the

requirements of this License are fulfilled for the Covered Code.

If it is impossible for You to comply with any of the terms of this

License with respect to some or all of the Covered Code due to

statute, judicial order, or regulation then You must: (a) comply with

the terms of this License to the maximum extent possible; and (b)

describe the limitations and the code they affect. Such description

must be included in the LEGAL file described in Section 3.4 and must

be included with all distributions of the Source Code. Except to the

extent prohibited by statute or regulation, such description must be

sufficiently detailed for a recipient of ordinary skill to be able to

understand it.

6.3. Derivative Works. If You create or use a modified version of this

License (which you may only do in order to apply it to code which is not

already Covered Code governed by this License), You must (a) rename

Your license so that the phrases "Mozilla", "MOZILLAPL", "MOZPL",

"Netscape", "MPL", "NPL" or any confusingly similar phrase

do not appear in your license (except to note that your license differs

from this License) and (b) otherwise make it clear that Your

version of the license contains terms which differ from the Mozilla

Public License and Netscape Public License. (Filling in the name of

the Initial

This License applies to code to which the Initial Developer has

attached the notice in Exhibit A and to related Covered Code.

6.1. New Versions. Netscape Communications Corporation

("Netscape") may publish revised and/or new versions of the License from time to

time. Each version will be given a distinguishing version number.

6.2. Effect of New Versions. Once Covered Code has been published under

a particular version of the

Developer, Original Code or Contributor in the notice described in

Exhibit A shall not of themselves be deemed to be modifications of

this License.)

COVERED CODE IS PROVIDED UNDER THIS LICENSE ON AN "AS IS" BASIS,

WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING,

WITHOUT LIMITATION, WARRANTIES THAT THE COVERED CODE IS FREE OF

DEFECTS, MERCHANTABLE, FIT FOR A PARTICULAR PURPOSE OR NON-INFRINGING.

THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE COVERED CODE

IS WITH YOU. SHOULD ANY COVERED CODE PROVE DEFECTIVE IN ANY RESPECT,

License, You may always continue to use it under the terms of that

version. You may also choose to use such Covered Code under the terms

of any subsequent version of the License published by Netscape. No one

other than Netscape has the right to modify the terms applicable to

Covered Code created under this License.

YOU (NOT THE INITIAL DEVELOPER OR ANY OTHER CONTRIBUTOR) ASSUME THE

COST OF ANY NECESSARY SERVICING, REPAIR OR CORRECTION. THIS DISCLAIMER

OF WARRANTY CONSTITUTES AN ESSENTIAL PART OF THIS LICENSE. NO USE OF

ANY COVERED CODE IS AUTHORIZED HEREUNDER EXCEPT UNDER THIS DISCLAIMER.

8.1. This License and the rights granted hereunder will terminate

Sections 2.1 and/or 2.2 automatically terminate at the expiration of

the 60 day notice period specified above.

automatically if You fail to comply with terms herein and fail to cure

such breach within 30 days of becoming aware of the breach. All

sublicenses to the Covered Code which are properly granted shall

survive any termination of this License. Provisions which, by their

nature, must remain in effect beyond the termination of this License

shall survive.

8.2. If You initiate litigation by asserting a patent infringement

claim (excluding declatory judgment actions) against Initial Developer

or a Contributor (the Initial Developer or Contributor against whom

You file such action is referred to as "Participant") alleging that:

(b) any software, hardware, or device, other than such Participant's

Contributor Version, directly or indirectly infringes any patent, then

any rights granted to You by such Participant under Sections 2.1(b)

and 2.2(b) are revoked effective as of the date You first made, used,

sold, distributed, or had made, Modifications made by that

Participant.

8.3. If You assert a patent infringement claim against Participant

alleging that such Participant's Contributor Version directly or

indirectly infringes any patent where such claim is resolved (such as

by license or settlement) prior to the initiation of patent

(a) such Participant's Contributor Version directly or indirectly

infringes any patent, then any and all rights granted by such

Participant to You under Sections 2.1 and/or 2.2 of this License

shall, upon 60 days notice from Participant terminate prospectively,

unless if within 60 days after receipt of notice You either: (i)

agree in writing to pay Participant a mutually agreeable reasonable

royalty for Your past and future use of Modifications made by such

Participant, or (ii) withdraw Your litigation claim with respect to

the Contributor Version against such Participant. If within 60 days

of notice, a reasonable royalty and payment arrangement are not

infringement litigation, then the reasonable value of the licenses

granted by such Participant under Sections 2.1 or 2.2 shall be taken

into account in determining the amount or value of any payment or

license.

8.4. In the event of termination under Sections

8.1 or 8.2 above, all end user license agreements (excluding

distributors and resellers) which have been validly granted by You or any

distributor hereunder prior to termination shall survive termination.

UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER TORT

mutually agreed upon in writing by the parties or the litigation claim

is not withdrawn, the rights granted by Participant to You under

(INCLUDING NEGLIGENCE), CONTRACT, OR OTHERWISE, SHALL YOU, THE INITIAL

DEVELOPER, ANY OTHER CONTRIBUTOR, OR ANY DISTRIBUTOR OF COVERED CODE,

OR ANY SUPPLIER OF ANY OF SUCH PARTIES, BE LIABLE TO ANY PERSON FOR

ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY

CHARACTER INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF GOODWILL,

WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION, OR ANY AND ALL OTHER

COMMERCIAL DAMAGES OR LOSSES, EVEN IF SUCH PARTY SHALL HAVE BEEN

INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. THIS LIMITATION OF

LIABILITY SHALL NOT APPLY TO LIABILITY FOR DEATH OR PERSONAL INJURY

RESULTING FROM SUCH PARTY'S NEGLIGENCE TO THE EXTENT APPLICABLE LAW

PROHIBITS SUCH LIMITATION. SOME JURISDICTIONS DO NOT ALLOW THE

EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO

THIS EXCLUSION AND LIMITATION MAY NOT APPLY TO YOU.

applicable law, if any, provides otherwise), excluding its conflict-

of-law provisions. With respect to disputes in which at least one

party is a citizen of, or an entity chartered or registered to do

business in the United States of America, any litigation relating to this

License shall be subject to the jurisdiction of the Federal Courts

of the Northern District of California, with venue lying in Santa

Clara County, California, with the losing party responsible for

costs, including without limitation, court costs and reasonable

attorneys' fees and expenses. The application of the United Nations

Convention on Contracts for the International Sale of Goods is

expressly excluded. Any law or regulation which provides that the

language of a contract

The Covered Code is a "commercial item," as that term is defined in

48 C.F.R. 2.101 (Oct. 1995), consisting of "commercial computer

software" and "commercial computer software documentation," as such

terms are used in 48 C.F.R. 12.212 (Sept. 1995). Consistent with 48

C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through

227.7202-4 (June 1995), all U.S. Government End Users acquire Covered

Code with only those rights set forth herein.

This License represents the complete agreement concerning subject

matter hereof. If any provision of this License is held to be

unenforceable, such provision shall be reformed only to the extent

necessary to make it enforceable. This License shall be governed by

California law provisions (except to the extent

shall be construed against the drafter shall not apply to this

License.

As between Initial Developer and the Contributors, each party is

responsible for claims and damages arising, directly or indirectly,

out of its utilization of rights under this License and You agree to

work with Initial Developer and Contributors to distribute such

responsibility on an equitable basis. Nothing herein is intended or

shall be deemed to constitute any admission of liability.

Initial Developer may designate portions of the Covered Code as

"Multiple-Licensed". "Multiple-Licensed" means that the Initial

Developer permits you to utilize portions of the Covered Code under

Your choice of the NPL or the alternative licenses, if any, specified

by the Initial Developer in the file described in Exhibit A.

EXHIBIT A -Mozilla Public License.

If you do not delete the provisions above, a recipient may use your

version of this file under either the MPL or the [___] License."

[NOTE: The text of this Exhibit A may differ slightly from the text of

``The contents of this file are subject to the Mozilla Public License

Version 1.1 (the "License"); you may not use this file except in

compliance with the License. You may obtain a copy of the License at

http://www.mozilla.org/MPL/

Software distributed under the License is distributed on an "AS IS"

basis, WITHOUT WARRANTY OF ANY KIND, either express or implied. See the

License for the specific language governing rights and limitations

under the License.

The Original Code is _________.

the notices in the Source Code files of the Original Code. You should

use the text of this Exhibit A rather than the text found in the

Original Code Source Code for Your Modifications.]

The Initial Developer of the Original Code is ______.

Contributor(s): __________.

Alternatively, the contents of this file may be used under the terms

of the _____ license (the "[___] License"), in which case the

provisions of [______] License are applicable instead of those

above. If you wish to allow use of your version of this file only

under the terms of the [____] License and not to allow others to use

your version of this file under the MPL, indicate your decision by

deleting the provisions above and replace them with the notice and

other provisions required by the [___] License.

Specifications

18.1

Environmental

European Energy Label

The European Energy Label informs you on the energy efficiency class of this product. The greener the energy efficiency class of this product is, the lower the energy it consumes. On the label, you can find the energy efficiency class, the average power consumption of this product in use and the average energy consumption for 1 year. You can also find the power consumption values for this product on the Philips website for your country at www.philips.com/TV

Product Fiche

• Visible Screen Size : 139 cm / 55 inch

• On Mode Power Consumption (W) : 67 W

• Annual Energy Consumption (kWh) * : 98 kWh

• Standby Power Consumption (W) **: <0.50 W Display Resolution (Pixels) : 1920 x 1080p Network Standby : <3W

* Energy consumption kWh per year, based on the power consumption of the television operating 4 hours per day for 365 days. The actual energy consumption depends on how the television is used.

** When the TV is turned off with the remote control and no function is active.

End of Use

Disposal of your old product and batteries

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

32HFL5011

• Energy Efficiency Class : A+

• Visible Screen Size : 80 cm / 32 inch

• On Mode Power Consumption (W) : 29 W

• Annual Energy Consumption (kWh) * : 42 kWh

• Standby Power Consumption (W) **: <0.50 W

• Display Resolution (Pixels) : 1920 x 1080p

• Network Standby : <3W

40HFL5011

• Energy Efficiency Class : A+

• Visible Screen Size : 102 cm / 40 inch

• On Mode Power Consumption (W) : 38 W

• Annual Energy Consumption (kWh) * : 55 kWh

• Standby Power Consumption (W) ** : <0.50 W

• Display Resolution (Pixels) : 1920 x 1080p

• Network Standby : <3W

43HFL5011

• Energy Efficiency Class : A+

• Visible Screen Size : 108 cm / 43 inch

• On Mode Power Consumption (W) : 43 W

• Annual Energy Consumption (kWh) * : 62 kWh

• Standby Power Consumption (W) **: <0.50 W

• Display Resolution (Pixels) : 1920 x 1080p

• Network Standby : <3W

49HFL5011

• Energy Efficiency Class : A+

• Visible Screen Size : 123 cm / 49 inch

• On Mode Power Consumption (W) : 50 W

• Annual Energy Consumption (kWh) * : 79 kWh

• Standby Power Consumption (W) ** : <0.50 W Display Resolution (Pixels) : 1920 x 1080p Network Standby : <3W

55HFL5011

• Energy Efficiency Class : A+

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2012/19/EU.

Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the enviroment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Please inform yourself about the local separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old

product helps to prevent potential negative consequences for the environment and human health.

18.5

Display Type

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste.

Please find out for yourself about the local rules on separate collection of batteries because correct disposal will help to prevent negative consequences for the environment and human health.

18.2

Power

Product specifications are subject to change without notice. For more specification details of this product, see www.philips.com/support

Power

• Mains power : AC 220V +/-10%

• Ambient temperature : 5°C to 35°C

• Power saving features : Eco mode, Picture mute (for radio), Auto switch-off timer, Eco settings menu.

The power rating stated on the product typeplate is the power consumption for this product during normal household use (IEC 62087 Ed.2). The maximum power rating, stated between brackets, is used for electrical safety (IEC 60065 Ed. 7.2).

18.3

Operating System

Diagonal screen size

• 32HFL5011 : 80 cm / 32 inch

• 40HFL5011 : 102 cm / 40 inch

Display resolution

• 1920 x 1080p

18.6

Display Type

Diagonal screen size

• 43HFL5011 : 108 cm / 43 inch

• 49HFL5011 : 123 cm / 49 inch

• 55HFL5011 : 139 cm / 55 inch

Display resolution

• 1920 x 1080p

18.7

Display Input Resolution

Video formats

Resolution — Refresh rate

• 480i - 60 Hz

• 480p - 60 Hz

• 576i - 50 Hz

• 576p - 50 Hz

• 720p - 50 Hz, 60 Hz

• 1080i - 50 Hz, 60 Hz

• 1080p - 24 Hz, 25 Hz, 30 Hz

Computer formats

Resolutions (amongst others) Android OS : Android Lollipop 5.1

18.4

Reception

• Aerial input : 75 ohm coaxial (IEC75)

• Tuner bands : Hyperband, S-Channel, UHF, VHF

• DVB : DVB-T (terrestrial, antenna) COFDM 2K/8K, DVB-T2, DVB-C (cable) QAM

• Analogue video playback : SECAM, PAL

• Digital video playback : MPEG2 SD/HD (ISO/IEC 13818-2), MPEG4 SD/HD (ISO/IEC 14496-10)

• Digital audio playback (ISO/IEC 13818-3)

• 640 x 480p - 60 Hz

• 800 x 600p - 60 Hz

• 1024 x 768p - 60 Hz

• 1280 x 768p - 60 Hz

• 1360 x 765p - 60 Hz

• 1360 x 768p - 60 Hz

• 1280 x 1024p - 60 Hz

• 1920 x 1080p - 60 Hz

18.8

Dimensions and Weights

32HFL5011

• without TV stand:

Width 726.5 mm - Height 425.4 mm - Depth 76.8 mm

- Weight ± 5.15 kg

• with TV stand:

Width 726.5 mm - Height 488.6 mm - Depth 179.2

mm - Weight ± 6.43 kg

40HFL5011

• without TV stand: Width 918 mm - Height 531.5 mm - Depth 79.2 mm Weight ± 8 kg

• with TV stand: Width 918 mm - Height 598.5 mm - Depth 211.9 mm Weight ± 9.98 kg

43HFL5011

• without TV stand: Width 968.2 mm - Height 562.4 mm - Depth 76.8 mm

- Weight ± 9.1 kg

• with TV stand: Width 968.2 mm - Height 624.7 mm - Depth 249.4 mm - Weight ± 10.5 kg

49HFL5011

• without TV stand: Width 1099.2 mm - Height 631.9 mm - Depth 78.6 mm

- Weight ± 12.4 kg

• with TV stand: Width 1099.2 mm - Height 693.8 mm - Depth 249.4 mm - Weight ± 13.9 kg

55HFL5011

• without TV stand: Width 1239.2 mm - Height 711.6 mm - Depth 79.8 mm

- Weight ± 14.3 kg

• with TV stand: Width 1239.2 mm - Height 778.2 mm - Depth 265.9 mm - Weight ± 16.7 kg

18.9

Connectivity

TV Side

• HDMI 3 in - ARC

• HDMI 4 in - ARC/MHL

• USB 2 - USB 3.0

• USB 3 - USB 2.0

• 1x Common Interface slot: CI+/CAM

• Headphones - Stereo mini-jack 3.5mm

TV Rear

• Audio In (DVI to HDMI) - Stereo mini-jack 3.5mm

• SCART: Audio L/R, CVBS in, RGB

• YPbPr : Y Pb Pr, Audio L/R

TV Bottom

• HDMI 1 in - ARC

• HDMI 2 in - ARC

• USB 1 - USB 2.0

• Audio out - Optical Toslink

• Network LAN - RJ45

• Antenna (75)

18.10

Sound

• HD Stereo

• Output power (RMS) : 16W

• Dolby® Digital Plus

• DTS Premium Sound ™

18.11

Multimedia

Connections

• USB 2.0

• Ethernet LAN RJ-45

• Wi-Fi 802.11a/b/g/n/ac (built-in)

• BT2.1 with EDR & BT4.0 with BLE

Supported USB file systems

• FAT 16, FAT 32, NTFS

Playback formats

• Containers : 3GP, AVCHD, AVI, MPEG-PS, MPEG-TS,

MPEG-4, Matroska (MKV), Quicktime (MOV, M4V,

M4A), Windows Media (ASF/WMV/WMA)

• Video Codecs : MPEG-1, MPEG-2, MPEG-4 Part 2,

MPEG-4 Part 10 AVC (H264), H.265 (HEVC), VC-1,

WMV9, VP9

• Audio Codecs : AAC, HE-AAC (v1/v2), AMR-NB,

Dolby Digital, Dolby Digital Plus, DTS Premium

Sound™, MPEG-1/2/2.5 Layer I/II/III (includes MP3),

WMA (v2 to v9.2), WMA Pro (v9/v10)

• Subtitles :

– Formats : SAMI, SubRip (SRT), SubViewer (SUB),

MicroDVD (TXT), mplayer2 (TXT), TMPlayer (TXT)

– Character encodings : UTF-8, Central Europe and

Eastern Europe (Windows-1250), Cyrillic

(Windows-1251), Greek (Windows-1253), Turkish

(Windows-1254), Western Europe (Windows-1252)

• Image Codecs : JPEG, JPS, MPO

• Limitations :

– Maximum supported total bit rate for a media file is

30Mbps.

– Maximum supported video bit rate for a media file

is 20Mbps.

– MPEG-4 AVC (H.264) is supported up to High

Profile @ L5.1.

– H.265 (HEVC) is supported upto Main / Main 10

Profile up to Level 5.1

– VC-1 is supported up to Advanced Profile @ L3.

Wi-Fi Certified

This TV supports Miracast certified devices.

Supported media server software (DMS)

• You can use any DLNA V1.5 certified media server

software (DMS class).

• You can use the Philips TV Remote app (iOS and

Android) on mobile devices.

Performance may vary, depending on the capabilities

of the mobile device and the software used.

ESD regulations

This apparatus meets performance criteria B for ESD. In case the apparatus does not recover in file sharing mode due to electrostatic discharge, user interference is required.

Help and Support

and reconnected to the power supply, the startup

screen is displayed at the next startup. To switch on

the TV from standby, press  on the remote control

or on the TV.

19.1

Register your TV and enjoy a range of benefits including full support (including downloads), privileged access to information about new products, exclusive offers and discounts, the chance to win prizes and even participate in special surveys about new releases.

Go to www.philips.com/welcome

19.2

Troubleshooting

Switch On and Remote Control

The TV does not switch on

• Disconnect the power cable from the power outlet. Wait for one minute then reconnect it.

• Make sure that the power cable is securely connected.

Creaking sound at startup or switch off

When you are switching the TV on, off or to standby, you hear a creaking sound from the TV chassis. The creaking sound is due to the normal expansion and contraction of the TV as it cools and warms up. This does not affect performance.

TV does not respond to the remote control

The TV requires some time to start up. During this time, the TV does not respond to the remote control or TV controls. This is normal behaviour. If the TV continues to be unresponsive to the remote control, you can check if the remote control is working by means of a mobile phone camera. Put the phone in camera mode and point the remote control to the camera lens. If you press any key on the remote control and you notice the infra red LED flicker through the camera, the remote control is working. The TV needs to be checked. If you do not notice the flickering, the remote control might be broken or its batteries are low. This method of checking the remote control is not possible with remote controls which are wirelessly paired with the TV.

The TV goes back to standby after showing the Philips startup screen

When the TV is in standby, a Philips startup screen is displayed, then the TV returns to standby mode. This is normal behaviour. When the TV is disconnected

The standby light keeps on blinking

Disconnect the power cable from the power outlet.

Wait 5 minutes before you reconnect the power

cable. If the blinking reoccurs, contact Philips TV

Consumer Care.

Channels

No digital channels found during the installation

See the technical specifications to make sure that

your TV supports DVB-T or DVB-C in your country.

Make sure that all cables are properly connected and

that the correct network is selected.

Previously installed channels are not in the channel

list

Make sure that the correct channel list is selected.


No picture / distorted picture

• Make sure that the antenna is properly connected to

the TV.

• Make sure that the correct device is selected as the

display source.

• Make sure that the external device or source is

properly connected.

Sound but no picture

• Make sure that the picture settings are set correctly.

Poor antenna reception

• Make sure that the antenna is properly connected to

the TV.

• Loud speakers, unearthed audio devices, neon

lights, high buildings and other large objects can

influence reception quality. If possible, try to improve

the reception quality by changing the antenna

direction or moving devices away from the TV.

• If reception on only one channel is poor, fine-tune

this channel with Manual Installation.

Poor picture from a device

• Make sure that the device is connected properly.

• Make sure that the picture settings are set correctly.

Picture settings change after a while

Make sure that Location is set to Home . You can

change and save settings in this mode.

A commercial banner appears

Make sure that Location is set to Home.

Picture does not fit the screen

Change to a different picture format.

Picture format keeps changing with different channels

Select a non 'Auto' picture format.

Picture position is incorrect

Picture signals from some devices may not fit the screen correctly. Check the signal output of the connected device.

Computer picture is not stable

Make sure that your PC uses the supported resolution and refresh rate.

Sound

No sound or poor sound quality

If no audio signal is detected, the TV automatically switches the audio output off — this does not indicate malfunction.

compatible. EasyLink features only work with devices

that are HDMI-CEC compatible.

No volume icon shown

• When an HDMI-CEC audio device is connected and

you use the TV Remote Control to adjust the volume

level from the device, this behaviour is normal.

Photos, videos and music from a USB device do not

show

• Make sure that the USB storage device is set to Mass

Storage Class compliant, as described in the storage

device's documentation.

• Make sure that the USB storage device is compatible

with the TV.

• Make sure that the audio and picture file formats are

supported by the TV.

Choppy playback of USB files

• The transfer performance of the USB storage device

may limit the data transfer rate to the TV which

causes poor playback.

Wi-Fi, Internet and Bluetooth

• Make sure that the sound settings are correctly set.

• Make sure that all cables are properly connected.

• Make sure that the volume is not muted or set to zero.

• Make sure that the TV audio output is connected to the audio input on the Home Theatre System. Sound should be heard from the HTS speakers.

• Some devices may require you to manually enable HDMI audio output. If HDMI audio is already enabled, but you still do not hear audio, try changing the digital audio format of the device to PCM (Pulse Code Modulation). Refer to the documentation accompanying your device for instructions.

HDMI and USB

HDMI

• Note that HDCP (High-bandwidth Digital Content Protection) support can delay the time taken for a TV to display content from an HDMI device.

• If the TV does not recognise the HDMI device and no picture is displayed, switch the source from one device to another and back again.

• If the picture and sound of a device connected with HDMI is distorted, check if a different HDMI Ultra HD setting can solve this problem.

• If there are intermittent sound disruptions, make sure that output settings from the HDMI device are correct.

• If you use an HDMI-to-DVI adapter or HDMI-to-DVI cable, make sure that an additional audio cable is connected to AUDIO IN (mini-jack only), if available.

HDMI EasyLink does not work

• Make sure that your HDMI devices are HDMI-CEC

Wi-Fi network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb

the wireless network.

• Make sure that the firewalls in your network allow

access to the TV's wireless connection.

• If the wireless network does not work properly in

your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the

router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for

information on indoor range, transfer rate and other

factors of signal quality.

• Use a high-speed (broadband) Internet connection

for your router.

DHCP

• If the connection fails, you can check the DHCP

(Dynamic Host Configuration Protocol) setting of the

router. DHCP should be switched on.

Bluetooth lost connection

• Position the wireless speaker within a range of 5

meters from the TV.

• Places with a high amount of wireless activity -

apartments with lots of wireless routers - can hamper

the wireless connection. Keep the router and wireless

speaker as close to the TV as possible.

Bluetooth Audio and Video syncronisation

• Before you purchase a wireless Bluetooth speaker,

inform yourself about its quality of Audio to Video

syncronisation, commonly called 'lip sync'. Not all

Bluetooth devices perform correctly. Ask your dealer

for advice.

19.3

Online Help

To solve any Philips TV related problem, you can consult our online support. You can select your language and enter your product model number.

Go to www.philips.com/support . On the support site you can find your country's

telephone number to contact us as well as answers to frequently asked questions (FAQs). In some countries, you can chat with one of our collaborators and ask your question directly or send a question by email. You can download new TV software or the manual to read on your computer.

19.4

Support and Repair

For support and repair, call the Consumer Care hotline in your country. Our service engineers will take care of a repair, if necessary.

Find the telephone number in the printed documentation that came with the TV. Or consult our website www.philips.com/support and select your country if needed.

Support app



You can also look up the Support app in the Apps row of the Home menu. Open this app to find the telephone number to contact us.

TV model number and serial number

You might be asked to provide the TV product model number and serial number. Find these numbers on the packaging label or on the type label on the back or bottom of the TV.

Warning



Do not attemp to repair the TV yourself. This may cause severe injury, irrepairable damage to your TV or void your warranty.

Risk of Injury or Damage to the TV

Safety and Care

20.1

Safety

Important

Read and understand all safety instructions before you use the TV. If damage is caused by failure to follow instructions, the warranty does not apply.

Secure the TV from Falling Over

You can find the mounting instructions in the Quick Start Guide that came with the TV. In case you lost this guide, you can download the guide from www.philips.com

Use the product type number of the TV to look for the Quick Start Guide to download.

Risk of Electric Shock or Fire

• Never expose the TV to rain or water. Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips TV Consumer Care to have the TV checked before use.

• Never expose the TV, remote control or batteries to excessive heat. Never place them near burning candles, naked flames or other heat sources, including direct sunlight.

• Never insert objects into the ventilation slots or other openings on the TV.

• Never place heavy objects on the power cord.

• Avoid force coming onto power plugs. Loose power plugs can cause arcing or fire. Ensure that no strain is exerted on the power cord when you swivel the TV screen.

• To disconnect the TV from the mains power, the power plug of the TV must be disconnected. When disconnecting the power, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

• Two people are required to lift and carry a TV that

weighs more than 25 kg or 55 lbs.

• If you mount the TV on a stand, only use the

supplied stand. Secure the stand to the TV tightly.

Place the TV on a flat, level surface that can support

the weight of the TV and the stand.

• When wall mounted, ensure that the wall mount can

safely bear the weight of the TV set. TP Vision bears

no responsibility for improper wall mounting that

results in accident, injury or damage.

• Parts of this product are made of glass. Handle with

care to avoid injury or damage.

Risk of damage to the TV !

Before you connect the TV to the power outlet,

ensure that the power voltage matches the value

printed on the back of the TV. Never connect the TV

to the power outlet if the voltage is different.

Risk of Injury to Children

Follow these precautions to prevent the TV from

toppling over and causing injury to children:

• Never place the TV on a surface covered by a cloth

or other material that can be pulled away.

• Ensure that no part of the TV hangs over the edge of

the mounting surface.

• Never place the TV on tall furniture, such as a

bookcase, without anchoring both the furniture and

TV to the wall or a suitable support.

• Teach children about the dangers of climbing on

furniture to reach the TV.

Risk of swallowing batteries !

The remote control may contain coin-type batteries

which can easily be swallowed by small children.

Keep these batteries out of reach of children at all

times.

Risk of Overheating

Never install the TV in a confined space. Always leave

a space of at least 10 cm or 4 inches around the TV

for ventilation. Ensure curtains or other objects never

cover the ventilation slots on the TV.

Lightning Storms

Disconnect the TV from the power outlet and antenna before lightning storms. During lightning storms, never touch any part of the TV, power cord or antenna cable.

Risk of Hearing Damage

Avoid using earphones or headphones at high volumes or for prolonged periods of time.

Low Temperatures

If the TV is transported in temperatures below 5°C or 41°F, unpack the TV and wait until the TV temperature reaches room temperature before connecting the TV to the power outlet.

Humidity

In rare occasions, depending on temperature and humidity, minor condensation can occur on the inside of the TV glass front (on some models). To prevent this, do not expose the TV to direct sunlight, heat or extreme humidity. If condensation occurs, it will disappear spontaneously while the TV is playing for a few hours. The condensation moisture will not harm the TV or cause malfunction.

20.2

Screen Care

• Never touch, push, rub or strike the screen with any object.

• Unplug the TV before cleaning.

• Clean the TV and frame with a soft damp cloth and wipe gently. Avoid touching the Ambilight LEDs on the backside of the TV. Never use substances such as alcohol, chemicals or household cleaners on the TV.

• To avoid deformations and colour fading, wipe off water drops as quickly as possible.

• Avoid stationary images as much as possible. Stationary images are images that remain onscreen for extended periods of time. Stationary images include onscreen menus, black bars, time displays, etc. If you must use stationary images, reduce screen contrast and brightness to avoid screen damage.

more, black dots or bright points of light (red, green or

blue) may appear constantly on the screen. This is a

structural property of the display (within common

industry standards) and is not a malfunction.

21.1

Europe B.V. or one of its affiliates, hereinafter referred to as TP Vision, which is the manufacturer of the product. TP Vision is the warrantor in relation to the TV with which this booklet was packaged. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V or their respective owners. TP Vision reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly.

The written material packaged with the TV and the manual stored in the memory of the TV or downloaded from the Philips website www.philips.com/support are believed to be adequate for the intended use of the system.

The material in this manual is believed adequate for the intended use of the system. If the product, or its individual modules or procedures, are used for purposes other than those specified herein, confirmation of their validity and suitability must be obtained. TP Vision warrants that the material itself does not infringe any United States patents. No further warranty is expressed or implied. TP Vision cannot be held responsible neither for any errors in the content of this document nor for any problems as a result of the content in this document. Errors reported to Philips will be adapted and published on the Philips support website as soon as possible.

CE compliance

Hereby, TP Vision Europe B.V. declares that

this television is in compliance with the

essential requirements and other relevant provisions

of Directives 1999/5/EC (RTTE), 2004/108/EC

(EMC), 2006/95/ EC (Low Voltage), 2009/125/EC

(Energy Labelling) and 2011/65/EC (RoHS).

From June 2016 onwards the following Directives

are valid 2014/53/EU (RED), 2009/125/EC (Eco

Design), 2010/30/ EU (Energy Labelling) and

2011/65/EC (RoHS).

Compliance with EMF

TP Vision manufactures and sells many products

targeted at consumers which, like any electronic

apparatus, in general have the ability to emit and

receive electromagnetic signals. One of TP Vision’s

leading business principles is to take all necessary

health and safety measures for our products, to

comply with all applicable legal requirements and to

stay well within the Electro Magnetic Field (EMF)

standards applicable at the time of producing the

products.

TP Vision is committed to developing, producing and

marketing products that cause no adverse health

effects. TP Vision confirms that, as long as its products

are handled properly for their intended use, they are

safe to use according to scientific evidence available

today. TP Vision plays an active role in the

development of international EMF and safety

standards, enabling TP Vision to anticipate further

developments in standardisation for early integration

in its products.

Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur

Terms of warranty - Risk of injury, damage to TV or void of warranty! Never attempt to repair the TV yourself. Use the TV and accessories only as intended by the manufacturer. The caution sign printed on the back of the TV indicates risk of electric shock. Never remove the TV cover. Always contact Philips TV Customer Care for service or repairs. Find the telephone number in the printed documentation that came with the TV. Or consult our website www.philips.com/support and select your country if needed. Any operation expressly prohibited in this manual, or any adjustments and assembly procedures not recommended or authorised in this manual, shall void the warranty.

Pixel characteristics This LCD/LED product has a high number of colour pixels. Although it has effective pixels of 99.999% or

21.2

You can see the terms of use, privacy policy, and also

set privacy settings of your Smart TV.

To open the terms of use of Smart TV page…

1 - Press

2 - Select  Apps to open Apps.

3 - Select Support.

HOME to open the Home menu.



22.4

Copyrights

22.1

MHL

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

22.2

Ultra HD

The DIGITALEUROPE UHD Display Logo is a trademark of DIGITALEUROPE.

Dolby Digital Plus

Dolby®

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

22.5

DTS Premium Sound ™

22.3

HDMI

HDMI®

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

DTS Premium Sound ™

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the Symbol

together are registered trademarks, and DTS 2.0

Rights Reserved.

22.6

DLNA Certified®

(If applicable)

DLNA®, the DLNA Logo and DLNA CERTIFIED® are

trademarks, service marks, or certifi cation marks of

the Digital Living Network Alliance.

22.7

Microsoft

Windows Media

Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

Microsoft PlayReady

Content owners use Microsoft PlayReady™ content access technology to protect their intellectual property, including copyrighted content. This device uses PlayReady technology to access PlayReady-protected content and/or WMDRMprotected content. If the device fails to properly enforce restrictions on content usage, content owners may require Microsoft to revoke the device's ability to consume PlayReady-protected content. Revocation should not affect unprotected content or content protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

22.8

Wi-Fi Alliance

Wi-Fi®, the Wi-Fi CERTIFIED logo, the Wi-Fi logo are

registered trademarks of the Wi-Fi Alliance.

22.9

Kensington

(If applicable)

Kensington and Micro Saver are registered US trademarks of ACCO World Corporation with issued registrations and pending applications in other countries throughout the world.

22.10

Other Trademarks

All other registered and unregistered trademarks are the property of their respective owners.

Index

Antenna connection 5 Antenna, Manual Installation 50 Apps 29 Audio commentary 47 Audio Description 47 Audio Out - Optical, tips 12 Audio Out Delay 14 Audio Out Format 14 Audio Out Levelling 15 Audio Out Offset 14 Audio Out Settings 14 Audio to Video Sync 14 Auto Volume Levelling 40 Automatic Channel Update 49

Backlight Contrast 35 Bass 40 Blu-ray Disc player, connect 15 Brightness, Philips Logo 18

Cable, Manual Installation 50 CAM, Conditional Access Module 12 Camcorder, connect 16 Channel 21 Channel logos 44 Channel Update Message 49 Channel, Antenna Installation 49 Channel, Automatic Channel Update 49 Channel, Cable Installation 49 Channel, Reinstall 49 Channel, TV guide 25 CI+ 12 Clear LCD 39 Clear Miracast connection 9 Clear Sound 40 Colour 35 Colour, Colour enhancement 36 Colour, colour temperature 36 Colour, custom colour temperature 37 Colour, Tint 36 Common Interface Slot 12 Computer, connect 17 Connectivity Guide 10 Consumer Care 91 Contact Philips 91 Contrast 35 Contrast, Contrast Mode 37 Contrast, Dynamic Contrast 37 Contrast, Gamma 38 Contrast, Perfect Contrast 37 Contrast, Video Contrast 38

Digital Text 22 Disposal of TV or batteries 85 DMR, Digital Media Renderer 8 DVD player 16

EasyLink 10 EasyLink, On or Off 11 EasyLink, Remote control 11 Eco Settings 42 End of use 85 European Ecolabel 85

Game or Computer 27 Game or Computer, setting 36 Gamma 38

Hard of hearing 47 HbbTV 23 HDMI MHL 10 HDMI, ARC 10 HDMI, DVI connection 11 Headphones, connect 16 Hearing impaired 47 Home Menu 26 Home Theatre System, Multichannel 14 Home Theatre System, problems 15 Home Theatre System, volume levelling 15

Incredible Surround 40 Interactive TV 24 Interactive TV, about 23 Internet memory, clear 7

iTV 23

Keys on TV 18

Media 31 Media files, from a USB drive 31 Motion, Clear LCD 39 Motion, Natural Motion 39 Motion, Perfect Natural Motion 39 MPEG Artefact Reduction 38

Natural Motion 39 Network Installation 6 Network, Clear Wi-Fi Miracast connection 9 Network, connect 6 Network, settings 7 Network, Static IP 8 Network, Switch on Wi-Fi 8 Network, View Settings 7 Network, Wired 7 Network, Wireless 6 Network, WoWLAN 8 Network, WPS 6 Network, WPS with PIN code 6 Noise Reduction 38

On a TV stand, TV Placement 44 On and Off 18

On the wall, TV Placement 44 Online support 91 Open Source software 51

Partially sighted 47 Perfect Natural Motion 39 Philips Logo, Brightness 18 Photo camera, connect 16 Photos, Videos and Music 31 Picture Style 35 Picture, Backlight Contrast 35 Picture, Colour 35 Picture, Sharpness 36 Placement, TV placement 4 Placement, Viewing distance 4 Power connection 4 Power consumption check 42 Problems 89 Problems, Channels 89 Problems, Connection, HDMI 90 Problems, Connection, Internet 90 Problems, Connection, USB 90 Problems, Connection, Wi-Fi 90 Problems, Picture 89 Problems, Remote control 89 Problems, Sound 90 Product Fiche 85

TV Installation 50 TV network name 7

Universal Access 47 Universal Access, Hard of hearing 47 Universal Access, Speakers/Headphones 48 USB Flash Drive, connect 16

Visually impaired 47

Wi-Fi 6 Wired Network 7 Wireless Audio 41 Wireless Network 6 Wireless Speakers, about 41 Wireless Speakers, select 41 WoWLAN 8

YPbPr connection, tips 12

Reception Quality 49 Register your product 89 Reinstall TV 50 Remote control and batteries 20 Repair 91

Safety Instructions 92 SCART connection, tips 12 Screen care 93 Sharpness 36 Sharpness, MPEG Artefact Reduction 38 Sharpness, Noise reduction 38 Sharpness, Super Resolution 38 Sharpness, Ultra Resolution 38 Smart Card, CAM 12 Software, Update 51 Sound Style 39 Sound, Auto Volume Levelling 40 Sound, Bass 40 Sound, Clear Sound 40 Sound, surround mode 40 Sound, Treble 40 Speakers, Wireless 41 Standby 18 Support, online 91 Surround Mode 40 Synchronise Audio and Video 14

Teletext 22 Terms of Use 94 Test Reception 49 Text 22 Text language, Primary 23 Text language, Secondary 23 Treble 40 TV Guide 25

Contact information

Albania/Shqipërisë

+355 44806061

Armenia

0-800-01-004

Austria/Österreich

0150 2842133

Belarus/Беларусь

8 10 800 2000 00 04

Belgium/België/Belgique

02 7007360

Bulgaria/България

0 0800 1154426

+359 2 4916273

Croatia/Hrvatska

0800 222 782

Czech Republic/Česká

republika

800 142100

Denmark/Danmark

352 587 61

Estonia/Eesti Vabariik

800 0044 307

Finland/Suomi

09 229 019 08

France

01 57324070

Greece/Ελλάδα

0 0800 4414 4670

Greece Cyprus

800 92 256

Hungary/Magyarország

068 001 85 44

(06 1) 700 8151

Republic of Ireland/Poblacht nah Éireann

1 601 1161

Northern Ireland/Tuaisceart Éireann

1 601 1161

Italy/Italia

02 4528 7030

Kazakhstan/Қазақстан

8 10 800 1000 00 04

Kosovo/Kosovës

+355 44806061

Latvia/Latvija

800 03 448

Lithuania/Lietuva

880 030 049

Luxembourg/Luxemburg

26 84 3000

Netherlands/Nederlands

010 4289533

Norway/Norge

22 70 82 50

Portugal

0800 780 902

Romania/România

03 727 66905 031 6300042

Russia/Россия

8 (800) 220 0004

Serbia/Srbija

11 321 68 40

Slovakia/Slovensko

0800 0045 51

Slovenia

0800 80 255

Spain/España

915 909 335

Sweden/Sverige

08 6320 016

Switzerland/Schweiz/Suisse

223 102 116

Turkey/Türkiye

0 850 222 44 66

Ukraine/Україна

0 800 500 480

United Kingdom

020 7949 0069

Germany

0696 640 4383

Poland/Polska

022 349 1505

This information is correct at the time of print. For updated information, see www.philips.com/support.

Philips 49HFL5011T/12, 32HFL5011T/12, 40HFL5011T/12, 55HFL5011T/12, 43HFL5011T/12 user manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Index
