Draft
Philips Signage Solutions
Draft
D-Line Display
49"
Powered by Android
450cd/m²
49BDL4050D
Chasing innovation
powered by Android
Amaze your guests with a smarter, faster, signage display. With integrated WiFi and
capable of running Android apps, it's the next evolution in signage solutions.
Innovative solutions for any signage application
• Android: A faster, richer, signage experience.
• CMND: Take control of your displays
•Integrated WiFi
Maximizing the impact of your message
• Save and play content with internal memory
• Connect and control your content via the cloud
• Enhance your connectivity with an integrated mPCIe slot.
Care about you, your business and your audience
• SmartPower for energy saving
• Keep your content up and running with FailOver
• Show clinical images consistently with D-image
• Ensure your content is running with automatic screenshots
49BDL4050D/00
D-Line Display
Draft
49" Powered by Android, 450cd/m²
Highlights
Powered by Android
WIth Android OS integrated into the display,
you can w
the planet and save your own app directly into
the display. With the built-in scheduler, you
can daypart your apps and content based on
your customer and time of day and with the
auto orientation feature, showing content in
portrait or landscape is as simple as turning the
display.
CMND
A robust display management platform,
CMND put
With the display management module, install
and maintain all connected displays remotely
and from one central location. With the
content management module, manage and
update your content (in both portrait and
landscape), in real time, with the simple yet
robust drag and drop interface.
SmartBrowser
ork with the most developed OS on
s the power back into your hands.
window. Simply connect the display to the
internet using WiFi or with an RJ45 cable, and
enjoy your own created playlists
FailOver
Keeping your content up and running is critical
for demanding commercial applications. While
it is unlikely you will face a content disaster,
FailOver provides 24/7 protection with a
revolutionary technology that plays back-up
content on screen in the event of a media
player failure. FailOver automatically kicks in
when the primary input fails. Simply select a
primary input connection and a FailOver
connection and your ready for instant
protection.
Internal Memory
playing a cached version of the content,
ensuring that your media stays up even if the
network goes down.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
PCI Slot
With an integrated PCI slot, you can connect
an
extra WiFI/bluetooth or 4G LTE module,
allowing for even greater communication with
the display. Machine to machine
communication is also enhanced, with
numerous configurations available for
customers to use, such as the ability to expand
product features or signal-handling capability.
Connect and control your content via the
cloud with the integrated HTML5 browser.
Using the Chromium based browser, design
your content online and connect a single
display, or your complete network. Show
content in both landscape and portrait mode,
with fullHD resolution. Streaming content can
also be shown in a PIP (picture-in-picture)
Save and play content with internal memory.
Upload your media into the display and
playback content immediately. Working in
conjunction with the internal browser, it also
serves as a memory cache when streaming
online content. If the network ever fails, the
internal memory keeps content running by
Proof of Play
Content is king, and with the automatic
s
creenshot feauture, you can make sure that
your content is up and running at all times.
Screenshots are taken throughout the day,
which are then stored in the FTP server. From
there, the screenshots can be viewed no
matter when, or where you are.
49BDL4050D/00
D-Line Display
Draft
49" Powered by Android, 450cd/m²
Specifications
Picture/Display
• Diagonal screen size: 48.5 inch / 123.2 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60Hz
• Brightness: 450 cd/m²
• Contrast ratio (typical): 1100:1
• Dynamic contrast ratio: 500,000:1
• Aspect ratio: 16:9
• Response time (typical): 12 ms
• Pixel pitch: 0.55926 x 0.55926 mm
• Display colors: 16.7 million
• Viewing angle (H / V): 178 / 178 degree
• Picture enhancement: 3/2 - 2/2 motion pull down,
mbfi
3D Co
MA deinterlacing, Dynamic contrast enhancement,
Progressive scan
lter, Motion compens. deinterlacing, 3D
Connectivity
• Video input: DisplayPort (1.2), HDMI (x2), DVI-D,
USB
• Video output: DisplayPort, DVI-I
• Audio input: 3.5 mm jack, Audio Left/Right (RCA)
• Audio output: Audio Left/Right (RCA), External
eaker
connector
sp
• Other connections: mPCIe,
USB power outlet (5 V. 2 amp)
• External control: RJ45, RS232C (in/out) 2.5 mm
k, IR (in/out) 3.5 mm jack
jac
micro SD, micro USB,
Supported Display Resolution
• Computer formats
Res
olution Refresh rate
1920 x 1080 60Hz
1440 x 900 60Hz
1366 x 768 60Hz
1360 x 768 60Hz
1280 x 800 60Hz
1280 x 768 60Hz
1024 x 768 60Hz
800 x 600 56, 60, 72, 75Hz
640 x 480 60, 67, 72, 75Hz
deo formats
• Vi
Res
olution Refresh rate
1080p 50, 60Hz
1080i 50, 60Hz
720p
57
6i 50Hz
576p 50Hz
50, 60Hz
480p 60Hz
480i 60Hz
Dimensions
• Set dimensions in inch (W x H x D):
43.2 x 24.9 x 1.8 inch
• Bezel width: 9.5 mm (T/L/R), 15.6 mm (B)
• Product weight (lb): TBD
•Product weight: TBD kg
• VESA Mount: 400 x 400 mm, M6
Convenience
• Memory: 16GB eMMC
• Placement: Landscape, Portrait
• Tiled Matrix: Up to 10 x 10
• Keyboard control: Hidden, Lockable
• Signal Loop Through: DVI, VGA, RS232, IR
oop
through, DisplayPort
L
• Network controllable: RJ45, RS232, One Wire
• Energy saving functions: Smart Power
• Screen saving functions: Pixel Shift, Low Bright
• Other convenience: Carrying handles
CEC), HDMI (One Wire)
(HDMI-
Power
•Consumption (On mode): TBD
• Standby power consumption: <0.4 W
• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
Operating conditions
• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20 ~ 60 °C
• Relative humidity: 20 ~ 80 %
• Altitude: 0 ~ 3000 m
• MTBF: 50,000 hour(s)
Sound
• Built-in speakers: 2 x 10W RMS
Accessories
• Included accessories: Remote Control, Batteries
for remote control, Quick start guide, RS232 cable,
AC Power Cord
• Stand: BM05922(Optional)
• Optional accessories: ColourCalibrationKit
460
(CCK
1)
Multimedia Applications
• USB Playback Audio: AAC, AIF, AIFF, M4A, MP3,
WMA, ASF, LPCM, M3U, MP4
WAV,
• USB Playback Picture: BMP, GIF, JPEG, JPG, PDF
• USB Playback Video: M2TS, M4V, MK3D, MKV,
MP4, MPEG, MPG, MTS, TS, TTS, VOB,
WMV
Miscellaneous
• On-Screen Display Languages: English, French,
German, Spanish, Polish, Turkish, Russian, Italian,
Simplified Chinese, Traditional Chinese, Arabic,
Japanese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
C, C
-Tick, RoHS, GOST, BSMI, CB, J-Moss,
CC
PSE, VCCI
• Warranty: 3 year warranty
•
Issue date 2016-02-07
Owner: Tom Ringhs
Version: 0.0.0
12 NC: 8670 001 37394
Test leaflet, for internal use only!
© 2016 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
