Page 1

Philips 7600 series LCD TV with Ambilight and Pixel Plus 3 HD

47"

integrated digital

47PFL7603D

Light up your experience.

Immerse yourself in a captivating Ambilight experience. Featuring a full HD 1080p display and Pixel Plus 3HD, this Flat TV combines HD Natural Motion, exciting invisible sound and Ambilight — lighting up your experience for years to come.

Elevate your viewing experience

• Ambilight enhances the viewing experience with ambient light

Pictures come alive

• Pixel Plus 3 HD for most sharp and clear pictures

• Full HD LCD display, with a 1920 x 1080p resolution

• HD Natural Motion for ultra-smooth motion in Full HD movies

• Dynamic contrast 30000:1 for incredible rich black details

Exciting and powerful sound

• Superb audio enjoyment from unique invisible speakers

• Integrated wOOx loudspeakers for deep and powerful bass

Connect, install and enjoy

• Integrated Digital Tuner for DVB-T reception

• Enjoy photo and music playback via USB

• 4 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV and connected device via HDMI CEC

Page 2

47PFL7603D/10

Highlights

LCD TV with Ambilight and Pixel Plus 3 HD

47" integrated digital

Ambilight

Ambilight makes an impressive contribution to th

e overall viewing experience by producing ambient light to complement the colours and light intensity of the on-screen image. It adds a new dimension to the viewing experience, completely immersing you into the content you are watching. It creates ambience, stimulates more relaxed viewing and improves perceived picture detail, contrast and colour. Ambilight automatically and independently adapts its colours according to the changing content on the screen.

Pixel Plus 3 HD

Pixel Plus 3 HD offers the unique combination o

f ultimate sharpness, natural detail, vivid colours and smooth natural motion on all qualities of HD, standard TV signals and multimedia content for high definition displays. Each pixel of the incoming picture is enhanced to better match the surrounding pixels, resulting in a more natural picture. Artefacts and noise in all sources from multimedia to standard TV and also in highly compressed HD are detected and reduced, ensuring that the picture is clean and razor sharp.

Full HD LCD display 1920 x 1080p

The Full HD screen has the widescreen resolutio

n of 1920 x 1080p. This is the highest

resolution of HD sources for the best possible picture quality. It is fully future-proof as it supports 1080p signals from all sources, including the most recent sources such as Bluray and advanced HD game consoles. The signal processing is extensively upgraded to support this much higher signal quality and resolution. It produces brilliant flicker-free progressive scan pictures with superb brightness and colours.

HD Natural Motion

Philips invented HD Natural Motion to minimise

juddering effects that are visible with movie-based picture content. The award winning algorithm estimates motion in the picture and corrects juddering movements in both broadcast and recorded movie material (such as DVD and Blu-ray Disc). The resulting smooth motion reproduction and excellent sharpness take the viewing experience to a higher level.

Integrated Digital DVB-T tuner

The integrated Digital DVB-T tuner lets you receive

digital terrestrial TV without an additional set top box. Enjoy quality TV clutter free.

Integrated wOOx loudspeakers

wOOx technology creates a superior bass sound by cap

turing and enhancing low frequency bass for a dramatically enhanced bass and sound experience.

4 HDMI inputs

HDMI makes an uncompressed digital RGB conne

ction from the source to the screen for the ultimate picture quality. HDMI intelligently communicates the highest output resolution with the source device. The HDMI input is fully backwards-compatible with DVI sources and includes digital audio. HDMI uses HDCP copy protection. With 3 HDMI inputs on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, such as an HD set-top box, a Blu-ray player and game console or digital camcorder. Your TV is fully prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry standard proto

col to share functionality between connected devices and the TV. With EasyLink only one remote control is needed to operate main functionalities on your TV and connected devices. EasyLink uses the standard HDMI cable to transfer system commands. It works between all electronic devices equipped with HDMI CEC.

Page 3

Issue date 2010-12-23

Version: 3.0.16

12 NC: 8670 000 36244 EAN: 87 12581 38871 3

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

AUDIO OUT

SERV. U

SPDIF OUT

AUDIO IN

HDMI 1

AUDIO IN:

LEFT / RIGHT HDMI 1 / DVI HDMI 2 / DVI HDMI 3 / DVI

EXT 2

(RGB/CVBS)

EXT 3

EXT 1

(RGB/CVBS)

HDMI 2HDMI 3

TV ANTENNA

75X

47PFL7603D/10

Specifications

LCD TV with Ambilight and Pixel Plus 3 HD

47" integrated digital

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 30000:1

• Response time (typical): 5 ms

• Viewing angle: 176º (H)/176º (V)

• Diagonal screen size: 47 inch / 119 cm

• Display screen type: LCD Full HD W-UXGA Act. mat

• Panel resolution: 1920 x 1080p

• Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2 mo

tio

n pull down, 3D Combfilter, Active Control + Light sensor, Colour Enhancement, Colour Transient Improvement, Digital Noise Reduction, Dynamic contrast enhancement, Luminance Transient Improver, 1080p 24/25/30 Hz pro

essing, 1080p 50/60 Hz processing, HD

Natural Motion

• Screen enhancement: Anti-Reflection coated sc

• Colour cabinet: Black colour deco front and white co

lour back cover

Ambilight

• Ambilight Features: Ambilight 2 Channel

• Pre-set modes: 4 Active Adaptive modes

Supported Display Resolution

• Computer formats Res

olution Refresh rate 640 x 480 60, 72, 75, 85 Hz 800 x 600 60, 72, 75, 85 Hz 1024 x 768 60, 70, 75, 85 Hz 1920 x 1080i 60 Hz Via HDMI/DVI inpu

• Video formats Res

olution Refresh rate 480i 60 Hz 480p 60 Hz 576i 50 Hz 576p 50 Hz 720p 50, 60 Hz 1080i 50, 60 Hz

1080p 24, 50, 60 Hz 1080p 24, 25, 30 Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 2 x 15 W

• Sound Enhancement: Auto Volume Leveller, Graphic

Equalizer

• Sound System: Nicam Stereo, Virtual Dolby Digital, BBE

Loudspeakers

• Built-in speakers: 2

• Loudspeaker types: wOOx loudspeakers

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer, Wake-up Clock

• Ease of Installation: Auto Programme Naming, Automa

tic Channel Install (ACI), Automatic Tuning System (ATS), Autostore, Fine Tuning, PLL Digital Tuning, Plug and Play

• Ease of Use: 4 favourite lists, Auto Volume Leveller (AVL

), Delt

a Volume per preset, Graphical User Interface, On-Screen Display, Programme List, Settings assistant Wizard, Side Control

• Electronic Programme Guide: Now + Next EPG

• Picture in Picture: Text dual screen

• Remote Control: TV

• Remote control type: RCPF03E08B

• Screen Format Adjustments: 4:3, Auto Format, Mo

vie expand 14:9, Mo

vie expand 16:9, Subtitle

Zoom, Super Zoom, Widescreen

• Teletext: 1200-page Hypertext

• Teletext enhancements: 4 favourite pages, Pro

ramme information Line

• Smart mode: Movie, Standard, Vivid

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, Slideshow files (.alb), JPEG Still pict

ures

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL I, PAL B/G, PA

L D/K, SECAM B/G,

SECAM D/K, SECAM L/L', DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Digital TV: DVB Terrestrial*

• Tuner bands: Hyperband, S-Channel, UHF, VHF

•Tuner Display: PLL

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out, RGB

• Ext 3: YPbPr, Audio L/R in

• Ext 4: HDMI v1.3

• Ext 5: HDMI v1.3

• Ext 6: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System st

andb

• Front/Side connections: HDMI v1.3, S-video in, CVBS in, Audio L

/R in, Headphone out, USB

• Other connections: Analogue

audio Left/Right out, PC Audio in, S/PDIF out (coaxial), Common Interface

Power

• Ambient temperature: 5°C to 35°C

• Mains power: 220 - 240 V, 50/60 Hz

• Power consumption: 270 W

• Standby power consumption: 0.15 W

Dimensions

•Set dimensions (W x H x D): 1163 x 712 x 117 mm

• Set dimensions with stand (W x H x D): 1163

x 786 x 310 mm

• Weight incl. Packaging: 50.7 kg

• Product weight: 29.5 kg

• Product weight (+stand): 36.5 kg

•Box dimensions (W x H x D): 12

x 883 x 391 mm

• VESA wall mount compatible: 400 x 400 mm

Accessories

• Included accessories: Power cord, Quick start guide, User Manual, Warranty certificate, Remote Control, Batteries for remote control

•
