42PFL7008 42PFL7108 47PFL7008 47PFL7108 55PFL7008 55PFL7108

www.philips.com/welcome

User manual

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

1.10

2.1

2.2

2.3

2.4

2.5

2.6

2.7

2.8

2.9

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

4.1

4.2

4.3

4.4

4.5

5.1

5.2

5.3

5.4

5.5

6.1

6.2

6.3

6.4

6.5

6.6

6.7

7.1

Contents

Tour 3

Smart TV 3 App gallery 3 Rental videos 3 Online TV 3 Social networks 3 Skype 4 Smartphones and tablets 4 Pause TV and recordings 4 Gaming 4 EasyLink 5

Setting up 6

TV stand and wall mounting 6 Tips on placement 6 Power cable 6 Antenna 6 Satellite dish 7 Network 7 Connect devices 9 Setup menu 17 Safety and care 18

TV 21

Switch on 21 Remote control 21 TV channels 25 TV guide 33 Switch to devices 34 Subtitles and languages 35 Timers and clock 36 Picture settings 36 Sound settings 39 Ambilight settings 41 Universal access 43

Satellite channels 45

Watching satellite channels 45 Satellite channel list 45 Favourite satellite channels 45 Lock satellite channels 46 Satellite installation 47

3D 52

What you need 52 Your passive 3D glasses 52 Watch 3D 52 Optimal 3D viewing 52 Health warning 53

Smart TV 54

Home menu 54 Smart TV Apps 54 Videos, photos or music 56 Multi room 59 Pause TV 60 Recording 61 MyRemote App 62

Skype 67

What is Skype? 67

7.2

7.3

7.4

7.5

7.6

7.7

7.8

8.1

8.2

9.1

9.2

9.3

9.4

9.5

9.6

9.7

9.8

10.1

10.2

10.3

10.4

11.1

11.2

11.3

11.4

12.1

12.2

12.3

12.4

12.5

12.6

12.7

12.8

12.9

12.10

Start Skype 67 Contacts 68 Calling on Skype 69 Skype Credit 70 Skype settings 70 Sign out 71 Terms of Use 71

Games 72

Play a game 72 Two-player games 72

TV Specifications 73

Environmental 73 Power 74 Reception 74 Display 74 Sound 74 Multimedia 74 Connectivity 75 Dimensions and weights 75

TV Software 76

Software version 76 Software update 76 Open source software 76 Open source license 76

Support 77

Copyrights and licences 78

HDMI 78 Dolby 78 DTS 2.0 + Digital Out™ 78 Skype 78 DLNA Certified® 78 DivX Certified® 78 Microsoft 78 Wi-Fi Alliance 78 MHEG software 79 Other trademarks 79

Index 80

2 Contents

Tour

1.1

Smart TV

Connect this Philips Smart LED TV to the Internet and discover a new world of television. You can make a wired connection to your router or you can link up wireles s ly with Wi-Fi.

With the TV connected to your home network, a smartphone can show a photo on TV, you can play videos stored on your computer or control the TV with your tablet.

With your TV connected to the Internet, you can watch a rental video from an online video store, read the online TV guide or record your favourite TV show on a USB Hard Drive. The Smart TV Apps add to the fun with all sorts of entertainment and convenient services.

In Help, press * List and look up Smart TV for more information.

1.2

App gallery

Open the App gallery in Smart TV to browse the Apps, the collection of tailored websites for TV.

Find the App for YouTube videos , a national newspaper, an online photo album, Facebook, Twitter, etc. There are Apps to rent a video from an online video s tore and Apps for watching programmes you missed. If the App gallery does not hold what you are looking for, try the World Wide Web and surf the Internet on TV.

In Help, press * List and look up App gallery for more information.

1.3

Rental videos

To watch a rental video, you don't need to leave your home. Simply rent the latest movie from your regional online video store.

Start Smart TV and add the video store App to the Smart TV start page. Open the video store App, create your personal account, select the movie and press play. No fuss with downloading, you can watch the movie immediately*.

In Help, press * List and look up Rental videos for more information.

* Depending on the video streaming service of the selected video store.

1.4

Online TV

With the Online TV Apps of Smart TV (streaming TV), you can watch a TV programme you just missed or watch a programme when it suits you best. Look for the broadcaster logo in the App gallery.

In Help, press * List and look up Online TV for more information.

Tour / Social networks 3

1.5

Social networks

No need to get up to check your friend's messages on your computer. Open Smart TV, select your social network page and send a message back from your couch.

Smart TV supports the popular social networks Facebook and Twitter.

In Help, press * List and look up App gallery for more information.

1.6

Skype

With Skype™ you can make video calls on your TV for free.

You can call and see your friends from anywhere in the world. To make a video call, you need a camera with a built-in microphone and a good connection to the Internet. Some Philips TVs have a camera and microphone built in.

In Help, press * List and look up Skype for more information.

1.7

Smartphones and tablets

To use your smartphone or tablet as a TV remote control or as your media controller, download the Philips MyRemote app from your smartphone or tablet app store.

Operate your TV from your smartphone or tablet, switch channels or change the volume. With the MyRemote app, you can use your phone or tablet to send photos, music or videos from your computer to your TV. And with MyR emote app on a tablet, you can call up the TV guide, read about the programmes and switch the TV to a channel with a simple tap of your finger. T he MyR em ote app is available for iOS and Android.

In Help, press * List and look up MyRemote app for more information.

1.8

Pause TV and recordings

If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can start watching again later. With a USB Hard Drive connected, you can als o record digital broadcasts. You can record while you are watching a program or schedule a recording of an upcoming programme.

In Help, press * List and look up Pause TV or Recording for more information.

1.9

Gaming

If you select your game console in the Home menu, the TV switches to the settings ideal for gaming automatically.

If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen simultaneously. Each player can focus on his own game to play.

4 Tour / Gaming

The TV uses 3D technology to show both screens. To play a two-player game with two different full screen pictures, you need a pair of 3D glasses for each player.

In Help, press * List and look up Game console or Two- player games for more information.

1.10

EasyLink

With EasyLink you can operate a connected device, like a Bluray Dis c player, with the remote control of the TV. EasyLink uses HDMI CEC to communicate with the connected devices.

In Help, press * List and look up EasyLink for more information.

Tour / EasyLink 5

Setting up

2.1

TV stand and wall mounting

TV Stand

You can find the mounting instructions of the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com. Use the product type number of the TV to look for the Quick Start Guide to download.

Wall mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

VESA MIS-F 400x400,M6

To fix the bracket securely, use a screw length as shown in the drawing.

Caution

Wall mounting the TV requires special s kills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TV's weight. Also read the safety precautions before positioning the TV. TP Vision Netherlands B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.2

Tips on placement

• Position the TV where light does not shine directly on the

screen.

• Dim lighting conditions in the room for best Ambilight effect.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV from is three times its

diagonal screen size. When seated, your eyes should be level with the centre of the screen.

2.3

Power cable

Insert the power cable into the POWER socket of the TV. Make sure the power cable is securely inserted into the TV. Make sure that the power plug in the wall socket is accessible at all times. When dis connecting the power cable, always pull the plug, never the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

In Help, press * List and look up Standby for more information on switching the TV on and off.

2.4

Antenna

Locate the antenna connection at the back of the TV. Insert the antenna cable securely into the Antenna a socket.

You can connect your own antenna or connect to an antenna signal from an antenna distribution system (common in certain regions). Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

6 Setting up / Antenna

2.5

Satellite dish

Locate the F-type satellite connection at the back of the TV. Attach the cable from your satellite dish - or Unicable splitter to this connection.

2.6

Network

Wireless connection

What you need

To connect the TV wirelessly to the Internet, you need a wireless router. Use a high-speed (broadband) connection to the Internet.

File sharing

The TV can find and open files on other devices in your wireless network, like your computer or NAS device. You can use a computer with a Microsoft Windows XP, Vista or Windows 7, Mac OSX or Linux-based operating system.

Media server software

With media s erver software on your computer, you can open your photos, music and videos stored on your computer on your TV s creen. Use a recent version of media server software like Windows Media Player 11, Twonky™ or similar*. Install the software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. To open your files on the TV, the media server software must be running on your computer.

* In Help, press * List and look up Media server software,

supported for an overview of supported media server software.

Make the connection

Follow s teps 1 to 5.

Step 1 - Make sure that the router of your wireless network is

switched on.

Step 2 - Press h and select S Setup and press OK. Step 3 - Select Connect to network and press OK. Step 4 - Select Wire less and press OK. Step 5 - Select Scan to scan for your wireless network. If you

have a router with WPS (Wi-Fi Protected Setup), you can select WPS. Select your choice and press OK.

- Scan Select Scan to scan for your wireless network (your wireless router). The TV might find s everal wireless networks in your proximity.

- WPS If your router has WPS, you can directly connect to the router without scanning. Go to the router, press the WPS button and return to the TV within 2 minutes. Then press Connect to make the connection. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS. If you must use the WPS pin code to connect, select Scan instead of WPS.

Step 6 - In the list of networks found, select your wireless network and press OK. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select Manual entry to enter the network name yourself.

Step 7 - Depending on the type of router, you can now enter your encryption key (WEP, WPA or WPA2). If you entered the encryption key for this network before, you can select Next to make the connection immediately. If your router supports WPS or WPS pin, you can select WPS , WPS pin or Standard. Select your choice and press OK.

- Standard Select Standard to enter the encryption key (password, passphrase or security key) manually. You can use the keyboard on the RC to enter the encryption key. Once you have entered the key, press Connect.

- WPS pin

Setting up / Network 7

To make a secured WPS connection with a PIN code, select WPS pin and press OK. Write down the 8-digit PIN code shown and enter it in the router software on your PC. Return to the TV and press Connect. Consult the router manual on where to enter the PIN code in the router software.

Step 8 - A message will be shown when the connection is successful.

Network configuration

If the connection fails, you can check the DHCP setting of the router. DHCP should be set to On. Alternatively, if you are an advanced user and want to install your network with static IP addressing, set the TV to Static IP. To set the TV to Static IP, press h and select S Setup and press OK. Select Network settings > Network configuration > Static IP. With Static IP selected in the menu, you can set the IP address and other necessary settings in Static IP

configuration in the same menu.

Network problems

Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi 802.11b/g/n

devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router

connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on

indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

Wired connection

What you need

You need a network router to connect the TV to the Internet. Use a router with a high-speed (broadband) connection to the Internet.

Installation Follow s teps 1 to 5. 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on.

3 - Press h and select S Setup and press OK. 4 - Select Connect to network and press OK. 5 - Select Wired and press OK.

The TV constantly searches for the network connection. A message will be shown when the connection is successful.

Network configuration

File sharing

The TV can find and open files on other devices in your network, like your computer. You can use a computer with a Microsoft Windows XP, Vista or Windows 7, Mac OSX or Linux operating system.

Media server software

With media server software on your computer, you can open your photos, music and videos stored on your computer on your TV s creen. Use a recent version of media server software like Windows Media Player 11, Twonky™ or similar*. Install the software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. To open your files on TV, the media server software must be running on your computer.

* In Help, press * List and look up Media server software, supported for an overview of supported media server software.

**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

Network settings

To open the Network settings, press h and select S Setup and press OK. Select Network settings and press OK.

View network settings

All current network settings are shown here. The IP and MAC address, signal strength, speed, encryption method, etc.

Network type

Sets the network to Wired or Wireless.

Network configuration

Sets the network configuration to DHCP & Auto IP or Static IP.

Static IP configuration

If Static IP is set, you can set all necessary static IP settings here.

Digital Media Renderer - DMR

8 Setting up / Network

To receive multimedia files from smartphones or tablets, set the DMR to On.

Wi-Fi M iracast

For m ore information on Wi-Fi Miracas t, press * List and look up Wi-Fi Miracast™.

Wi-Fi Miracast connections

For m ore information on Wi-Fi Miracas t, press * List and look up Wi-Fi Miracast™.

Wi-Fi s m art screen

For m ore information on Wi-Fi smart screen, press * List and look up MyRemote App, WiFi smart screen.

TV network name

If you have more than one TV in your network, you can rename the TVs here.

Clear Internet memory

With Clear Internet memory you clear all Internet files stored on your T V. You clear your Philips Smart TV regis tration and parental rating setting, your video store app logins, all Smart TV app favourites , Internet bookmarks and history. Interactive MHEG applications can also save so-called 'cookies', on your TV. These files will also be cleared.

2.7

Connect devices

Tips on connections

Connectivity guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a

good transfer of picture and sound.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to www.connectivityguide.philips.com

Antenna

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

HDMI

HDMI CEC

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched on on the TV and the connected device. In Help, press * List and look up EasyLink HDMI CEC for more information on using EasyLink.

DVI to HDMI

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5 mm) to Audio In VGA/DVI for sound, on the back of the TV.

Copy protection

DVI and HDMI cables s upport HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

All of the HDMI connections on the TV have HDMI ARC (Audio Return Channel).

Setting up / Connect devices 9

If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals. You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.

In case you prefer to switch off ARC on the HDMI connections, press h and select S Setup and press OK. Select TV settings > Sound > Advanced > HDMI ARC.

Y Pb Pr

Component Video YPbPr is a high quality connection. The

YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

Use the supplied YPbPr adapter cable to connect your device. Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect. Use an Audio L/R cinch to mini-jack (3.5mm) adapter cable (not s upplied) if your device als o has sound.

SCART

SCART is a good quality connection. The SCART connection

can be used for CVBS and RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals.

Use the supplied SCART adapter cable to connect your device.

Audio Out - Optical

Audio Out - Optical is a high quality sound connection. This

optical connection can carry 5.1 audio channels. If your audio device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can connect this sound cable to an Audio In - Optical connection on the HTS. This Audio cable will send the sound of the TV to the HTS.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. In Help, press * List and look up Audio Out settings for more information.

If the sound does not match the video on screen, you can adjust the audio to video synchronization. In Help, press * List and look up Audio to video sync for more information.

EasyLink HDMI CEC

EasyLink

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC* to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

* Consumer Electronics Control

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their res pective owners .

10 Setting up / Connect devices

Operate devices

To operate a device connected to HDMI and set up with EasyLink, select the device -or its activity- in the list of TV connections. Press c SOURCE, select a device connected to an HDMI connection and press OK.

Once the device is s elected, the TV remote control can control the device. However the h (Home) and o

OPTIONS keys and some other typical TV keys, like Ambilight, are not forwarded to the device.

If the key you need is not on the TV remote control, you can select the key in the Options menu. Press o OPTIONS and select % Controls in the menu bar. Select the device key you need on screen and press OK . Some very specific device keys might not be available in the Controls menu.

EasyLink settings

The TV comes with all EasyLink settings switched on. You can switch off any EasyLink setting independently.

EasyLink

To switch off EasyLink completely, press h and select S Setup and press OK. Select TV settings > General settings > EasyLink > EasyLink. Select Off and press OK.

EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink remote control separately. In the EasyLink settings menu, select EasyLink Remote

Control and select Off.

Pixel Plus link

Some devices, a DVD or Blu-ray Disc player, might have their own picture quality processing. To avoid bad picture quality caused by interference with the TV processing, the picture processing of these devices should be disabled. The TV comes with Pixel Plus link switched on and disables the picture quality processing of recent Philips devices connected to the TV. To switch off Pixel Plus link, in the EasyLink settings menu, select Pixel Plus link and select Off.

Auto subtitle shift

If you play a DVD or Blu-ray Disc on a Philips disc player that supports subtitles, the TV can move the subtitles upwards. Subtitles will be visible whatever Picture format you select. The TV comes with Auto subtitle shift switched on. To switch off Auto subtitle shift, in the EasyLink settings menu, select Auto subtitle shift and select Off .

Common Interface CAM

CI+

This TV is ready for the CI+ Conditional Access.

With CI+ you can watch prem ium HD programmes, like movies and sports, offered by digital TV broadcasters in your region. These programmes are scram bled by the TV broadcaster and descrambled with a prepaid CI+ module. Digital TV broadcasters provide this CI+ module (Conditional Access Module - CAM) when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV broadcaster for more information on terms & conditions.

In Help, press * List and look up Common Interface CAM for more information on connecting a CAM.

CAM

Insert a CAM module

Switch off the TV before inserting a CAM. Look on the CAM for the correct method of insertion. Incorrect insertion can damage the CAM and the TV.

Use the Common Interface slot on the TV to insert the CAM card*. Gently insert the CAM as far as it will go and leave it in the slot permanently. It may take a few minutes before the CAM is activated. Removing the CAM will deactivate the broadcast service on TV.

* The Common Interface slot accepts a PC card (PCMCIA) in which you insert a smart card. Both cards should be supplied by the TV broadcaster.

If a CAM is inserted and subscription fees have been paid, (connection methods can differ), you can watch the TV broadcast. The inserted CAM is exclusively for your TV.

CAM settings

To set passwords or PIN codes for the CAM TV broadcast, press h and select S Setup and press OK. Select Channel settings > Common Interface. Select the CAM TV broadcaster and press OK.

Setting up / Connect devices 11

Set-top box STB

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Set-top box has no HDMI connection.

Switch off timer

Switch off this automatic timer, if you only use the remote control of the Set-top box. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

To switch off the Switch off timer, press h and select S Setup and press OK. Select TV settings > General settings > Switch off timer and set the slider bar to 0.

Satellite receiver

Connect the dish antenna cable to the Satellite receiver.

Next to the antenna connection, add an HDMI cable to connect the device to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.

Switch off timer

Deactivate the Switch off timer, if you only us e the remote control of the Satellite receiver. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

To deactivate, press h and select S Setup and press OK. Select TV settings > General settings > Switch off timer and set the slider bar to 0.

Home Theatre System (HTS)

Connect

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

Alternatively, you can use a SCART cable if the device has no HDMI connection.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable to send the sound of the TV picture to the Home Theatre System.

12 Setting up / Connect devices

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most DVD Home Theatre Systems to match the sound and video. A mismatch can be visible in scenes with people talking - when they finish sentences before their lips stop moving or just the opposite. In Help, press * List and look up Audio to video sync for more information.

Audio Out settings

Audio Out delay

With a Home Theatre S ystem (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised. A mismatch can be visible in scenes with people talking - when they finish sentences before their lips stop moving or just the opposite.

Automatic audio to video sync

With recent Philips Home Theatre Sys tems , the audio to video sync is automatically synchronised and always correct.

Audio sync delay

For s ome Home Theatre S ystems you might need to adjus t the audio sync delay to synchronise the audio to video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to s witch off Audio Out delay on the TV.

To switch off the Audio Out delay . . .

1 - Press h and select S Setup and press OK. 2 - Select TV settings > Sound > Advanced > Audio Out delay. 3 - Select Off and press OK. 4 - Press b, repeatedly if necessary, to close the menu.

Audio Out offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms. The Audio Out delay setting should be switched on.

To synchronise the sound on the TV . . .

1 - Press h and select S Setup and press OK.

2 - Select TV settings > Sound > Advanced > Audio Out offset. 3 - Use the slider bar to set the sound offset and press OK. 4 - Press b, repeatedly if necessary, to close the menu.

Audio Out format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio out format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

To set the Audio Out format . . .

1 - Press h and select S Setup and press OK. 2 - Select TV settings > Sound > Advanced > Audio Out format. 3 - Select Multichannel or Stereo. 4 - Press b, repeatedly if necessary, to close the menu.

Audio Out leveling

Use the Audio Out leveling setting to level the volume (loudnes s) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume . . .

1 - Press h and select S Setup and press OK. 2 - Select TV settings > Sound > Advanced > Audio Out leveling. 3 - If the volume difference is large, select More. If the volume difference is small, select Less. 4 - Press b, repeatedly if necessary, to close the menu.

Audio Out leveling affects both the Audio Out - Optical and HDMI-ARC sound signals.

Troubleshooting

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is there when the audio or video file has DTS sound but the Home Theatre Sys tem has no DTS sound processing. You can fix this by setting the

Audio Out format of the TV to Stereo. Go to Home > Setup > TV settings > Sound > Advanced > Audio Out format

No sound

If you cannot hear the sound from the TV on your Home Theatre System, check the following . . .

• Check if you connected the HDMI cable to a HDMI ARC connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections .

• Check if the HDMI ARC setting on the TV is switched On. Go to Ho me > Setup > TV settings > Sound > Advanced >

HDMI ARC

Setting up / Connect devices 13

Blu-ray Disc Player

Use a High speed HDMI cable to connect the Blu-ray Disc player to the TV.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV re m ote control. In Help, press * List and look up EasyLink HDMI CEC for more information.

DVD Player

Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.

If the DVD player is connected with HDMI and has EasyLink HDMI CEC, you can operate the player with the TV remote control. In Help, press * List and look up EasyLink HDMI CEC for more information.

Game console

HDMI

You can connect a game console to the TV. You can use an HDMI, YPbPr or SCART connection.

For best quality, us e an High speed HDMI cable to connect the game console to the TV.

If the game console is connected with HDMI and has EasyLink HDMI CEC, you can operate the game console with the TV remote control.

Audio Video LR / Scart

You can connect a game console to the TV. If your game console only has Video (CVBS) and Audio L/R output, us e a Video Audio L/R to SCART adapter to connect to the SCART connection.

USB Hard Drive

What you need

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To pause

To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 32GB Hard Drive space.

To record

To pause or record a broadcast, you need a Hard Drive with a minimum of 250GB Hard Drive space.

14 Setting up / Connect devices

TV guide

Before you decide to buy a USB Hard Drive to record, you can check if you can record digital TV channels in your country. Press Guide on the remote control. If there is a Record button on the T V guide page, you can re cord program mes from digital TV channels.

In Help, press * List and look up USB Hard Drive,

Installation to install a USB Hard Drive on this TV.

Installation

Before you can pause or record a broadcas t, you mus t connect and format a USB Hard Drive. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel, press p

(Pause). Trying to pause will start the formatting. Formatting removes all files from the connected USB Hard Drive. Follow the instructions on screen. When the USB Hard Drive is formatted, leave it connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format anothe r USB Hard Drive, the content on the form e r will be lost. A USB Hard Drive installed on your TV will need reformatting for us e with a computer.

In Help, press * List and look up Pause TV or Recording to pause or record TV channels.

USB keyboard or mouse

USB keyboard

Connect a USB keyboard (USB-HID type) to enter text on your TV.

You can connect a keyboard and a mouse to the TV. Use one of the USB connections of the TV to connect.

Install the keyboard

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the firs t time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard lay-out first, you can select a secondary Latin keyboard lay-out. To change the keyboard lay-out setting later on, press h and select S Setup and press OK. Select TV settings > General settings > USB mouse and

keyboard > Keyboard settings and press OK.

Keys for channel renaming

- Enter Â = OK

- Backs pace z = delete character before cursor

- Arrow keys = navigate within a text field

- To switch between keyboard lay-outs, if a secondary lay-out is set, press the Alt + Shift keys simultaneously.

Keys for Smart TV Apps and Internet pages

- Tab and Shift Tab = Next and Previous

- Home = scroll to the top of the page

- End = scroll to the bottom of the page

- Page Up = jump one page up

- Page D own = jump one page down

- + = zoom in one step

- - = zoom out one step

- * = fit to width

In Help, press * List and look up USB mouse, to connect a USB mouse.

USB mouse

Connect

You can connect a USB mouse (USB-HID type) to navigate pages on the Internet. On an Internet page, you can select and click on links more easily.

Connect the mouse

Setting up / Connect devices 15

Switch the TV on and connect the USB mouse to one of the USB connections on the TV. You can also connect the USB mouse to a connected USB keyboard.

Mouse clicks

- Left click = OK

- Right click = Back b You can use the scroll wheel to scroll pages up and down.

In Help, press * List and look up USB keyboard, to connect a USB keyboard.

Speed

You can adjust the speed of the mouse, the speed of the mouse moving on screen.

To adjust the speed . . .

1 - Press h, select S Setup and press OK. 2 - Select TV settings and press OK. 3 - Select General settings > Pointer and mouse speed and press OK. 4 - Press the arrows u (Up) or v (Down) to increase or lower

the speed.

5 - Press the arrow x (Right) to test the speed you set. 6 - Press the arrow w (Left) to return to the setting. You can

adjust the s etting again.

7 - Press OK to store and close the setting. 8 - Press b, repeatedly if necessary, to close the menu.

USB flash drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press c SOURCE, select USB and press OK.

To stop watching the USB flash drive content, press t TV or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

In Help, press * List and look up Videos, photos and music, to watch or listen to content from a USB flash drive.

Photo camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.

If the contents list does not appear automatically, press c SOURCE, select USB and press OK. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

In Help, press * List and look up Videos, photos and music for more information on viewing photos .

Camcorder

You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter to connect to the SCART connection.

For best quality, us e an HDMI cable to connect the camcorder to the TV.

Or use a SCART adapter to connect the camcorder to the TV.

16 Setting up / Connect devices

Computer

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter to connect the PC to HDMI and an audio L/R cable to AUDIO IN L/R on the back of the TV.

Ideal monitor setting

If your computer is added as a Computer type of device in the Source menu (list of connections), the TV is set to the ideal Computer setting automatically.

If you use your computer to watch movies or use it to play games, you might want to set the TV back to the ideal TV watching or gaming setting.

To set the TV to the ideal setting manually . . .

1 - Press h, select S Setup and press OK. 2 - Select TV settings > Picture > Game or computer and press OK. 3 - Select Game (for gaming) or select Off (for watching a movie) and press OK. 4 - Press b, repeatedly if necessary, to close the menu.

Remember to set the Game or computer setting back to

Computer when you stop playing the game.

Picture format - Unscaled

Additionally, you can also set the Picture format to Unscaled an expert pixel for pixel dis play mode (black bars may appear). 1 - Press o OPTIONS and select o Options in the menu bar. 2 - Select Picture format > Unscaled and press OK.

In Help, press * List and look up Display resolutions, for an overview of the s upported PC resolutions.

Headphones

You can connect a set of headphones to the H connection on the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones s eparately.

To adjust the volume . . . 1 - Press o OPTIONS and select j Picture and sound in the menu bar.

2 - Press v (down) and select Headphones volume and press OK. 3 - Press u (up) or v (down) to adjust the volume. 4 - Press b, repeatedly if necessary, to close the menu.

2.8

Setup menu

Quick picture settings

With Quick picture settings you can set your basic picture preferences in a few easy steps. The settings you made are stored under the Picture style - Personal. You can return to your picture preference if some s ettings were changed. You can set a preferred picture setting for every TV activity or connected device individually.

To return to your preferred picture setting, while watching a TV channel, press o OPTIONS, select j Picture and

sound in the menu bar, select Picture style and select Personal.

Setting up / Setup menu 17

To set a Quick picture setting . . . 1 - Press h, select an activity or a connected device (or its connection) and press OK.

2 - Press h again, select S Setup and press OK. 3 - Select Quick picture settings and press OK. Go through

the steps and finish. The activity or connection has your personal preferences.

In Help, press * List and look up Picture style, for more information.

TV settings

In the TV settings menu you can set all Picture, 3D, Sound and Ambilight settings. The item General settings in the menu holds a collection of settings like Menu language, Sleep timer, Switch off timer, Universal access and more. In Help, press * List and look up the topic or setting you need.

Search for channels

In Help, press * List and look up Channel, update or Channels, reinstall, for more information.

Channel settings

Languages In Help, press * List and look up Audio language or Subtitles for more information.

Universal access

In Help, press * List and look up Universal access for more information on setting up the TV for visually and hearing impaired users.

Channel installation

In Help, press * List and look up Automatic channel update or Channel update message. Also look up Manual installation for installing analogue channe ls or DVB to switch the antenna connection.

Child lock

In Help, press * List and look up Child lock for more information.

Search for satellite

In Help, press * List and look up Satellite, installation for more information.

Satellite settings

Languages

In Help, press * List and look up Audio language or Subtitles for more information.

Channel installation In Help, press * List and look up Satellite, automatic channel update or Satellite, channel update message or Satellite, automatic update options for more information.

Child lock

In Help, press * List and look up Satellite, channel lock for more information.

Connect to network

In Help, press * List and look up Network, wireless or Network, wired, for more information.

Network settings

In Help, press * List and look up Network, settings, for more information.

Update software

In Help, press * List and look up Software, Internet update or Software, USB update, for more information.

Software settings

In Help, press * List and look up Software, current version, for more information.

Watch demos

With Watch demos in the Setup menu, you can watch some demonstration videos of some of the picture quality features of your TV.

Active control

The TV monitors the incoming picture quality, the level of motion in the picture, brighter or darker scenes and the light conditions in your room. With thes e values, the TV adjusts the picture for best performance.

18 Setting up / Safety and care

Safety

Read me

Read and understand all safety instructions before you use the TV. If damage is caused by failure to follow instructions, the warranty does not apply.

Risk of electric shock or fire!

• Never expose the TV to rain or water. Never place liquid

containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Consumer Care to have the TV checked before use.

• Never expose the TV, remote control or batteries to excessive heat. Never place them near burning candles, naked flam e s or other he at source s , including direct sunlight.

• Never insert objects into the ventilation slots or other openings on the TV.

• Never place heavy objects on the power cord.

• Avoid force coming onto power plugs. Loose power plugs

can cause arcing or fire. Ensure that no strain is exerted on the power cord when you swivel the TV screen.

• To disconnect the TV from the mains power, the power plug of the TV m us t be disconnected. When disconnecting the power, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

Risk of injury or damage to the TV!

• Two people are required to lift and carry a TV that weighs

more than 25 kg or 55 lbs.

• If you mount the TV on a stand, only use the supplied stand. Secure the stand to the TV tightly. Place the TV on a flat, level surface that can support the weight of the TV and the stand.

• When wall mounted, ensure that the wall mount can safely bear the weight of the TV set. TP Vision Netherlands B.V. bears no responsibility for improper wall mounting that results in accident, injury or damage.

• Parts of this product are made of glass. Handle with care to avoid injury or damage.

Risk of damage to the TV!

Before you connect the TV to the power outlet, ens ure that the power voltage matches the value printed on the back of the TV. Never connect the TV to the power outlet if the voltage is different.

Risk of injury to children!

Follow thes e precautions to prevent the TV from toppling over and causing injury to children:

• Never place the TV on a surface covered by a cloth or other material that can be pulled away.

• Ensure that no part of the TV hangs over the edge of the mounting surface.

• Never place the TV on tall furniture, such as a bookcase, without anchoring both the furniture and TV to the wall or a suitable support.

• Teach children about the dangers of climbing on furniture to reach the TV.

Risk of swallowing batteries!

The remote control may contain coin-type batteries which can easily be swallowed by small children. Keep these batteries out of reach of children at all times.

Risk of overheating!

Never install the TV in a confined space. Always leave a space of at least 10 cm or 4 inches around the TV for ventilation. Ensure curtains or other objects never cover the ventilation slots on the TV.

Lightning storms

Dis connect the TV from the power outlet and antenna before lightning storms. During lightning storms, never touch any part of the TV, power cord or antenna cable.

Risk of hearing damage!

Avoid using earphones or headphones at high volumes or for prolonged periods of time.

Low temperatures

If the TV is transported in temperatures below 5°C or 41°F, unpack the TV and wait until the TV temperature reaches room temperature before connecting the TV to the power outlet.

Lightning storms

Dis connect the TV from the power outlet and antenna before lightning storms. During lightning storms, never touch any part of the TV, power cord or antenna cable.

Risk of hearing damage!

Avoid using earphones or headphones at high volumes or for prolonged periods of time.

Low temperatures

If the TV is transported in temperatures below 5°C or 41°F, unpack the TV and wait until the TV temperature reaches room temperature before connecting the TV to the power outlet.

Screen care

• Never touch, push, rub or strike the screen with any object.

• Unplug the TV before cleaning.

• Clean the TV and frame with a soft damp cloth and wipe

gently. Avoid touching the Ambilight LEDs on the backside of the TV. Never use substances such as alcohol, chemicals or household cleaners on the TV.

Setting up / Safety and care 19

• To avoid deformations and colour fading, wipe off water drops as quickly as possible.

• Avoid stationary images as much as possible. Stationary images are images that remain onscreen for extended periods of time. Stationary images include ons creen menus , black bars , time displays, etc. If you must use stationary images, reduce screen contrast and brightness to avoid screen damage.

Temperature and humidity

In rare occasions, depending on temperature and humidity, minor condensation can occur on the inside of the TV glass front (on some models). To prevent this, do not expos e the TV to direct sunlight, heat or extreme humidity. If condensation occurs, it will disappear spontaneously while the TV is playing for a few hours. The condensation moisture will not harm the TV or cause malfunction.

20 Setting up / Safety and care

3.1

Switch on

Switch on and off

Make sure you plugged in the mains power on the back of the TV before you switch on the TV. If the red indicator light is off, press the small key A on the right s ide of the back of the TV to put the TV in standby - the red indicator will light up.

With the TV in standby, press A on the remote control to switch the TV on. Alternatively, you can use the CH+, CH- and h key to switch the TV on.

Quick start

To switch on the TV faster than usual, you can set the TV in Quick start mode. In Help, press * List and look up Quick start for more information.

Switch to standby

To switch the TV to standby, press A on the remote control.

Switch off

To switch the TV off, press the small key A on the right of the TV on the back. There is no red indicator light. The TV is still connected to the mains power but consumes a minimum of e nergy. To switch off the TV comple tely, dis conne ct the power plug. When dis connecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

Quick start

With Quick s tart, the TV can s tart up faster than usual. When you switch the TV on from standby the TV picture already appears after a few seconds, if Quick start is activated.

The TV can remember your daily habit of watching TV. Some time before you usually switch on the TV, Quick start will activate automatically, allowing you to switch on quickly. Alternatively, you can select up to 3 fixed time frames a day during which the TV is ready to switch on quickly.

When you switch the TV back to standby, Quick start remains active until the set time frame ends.

Activate

To set the Quick start activation, press h and select S Setup and press OK to open the Setup menu. Select TV settings > General settings > Quick start > Activation. You can select Automatic or Manual.

- Automatic Select Automatic to activate Quick start automatically. The TV remembers your watching habit and activates Quick start during these time frames. With Automatic, the TV can set up to 4 time frames of 1 hour.

- Manual Select Manual to activate Quick start during 3 fixed time frames a day. As an example, you can set a time frame in the morning, one at noon and one in the evening. For each time frame, you can set the time span yours elf. If Quick start is set to Manual, you can also select a Standby delay. With Standby delay, you can set the TV to keep Quick start active for some time after you switched the TV to standby. You can set the delay to up to 1 hour in steps of 15 minutes.

Specifics

The TV clock has to work properly to activate Quick start. Quick start activation cannot be longer than a 4 hour time frame. Quick start increases the energy consumption during standby.

3.2

Remote control

TV / Remote control 21

Top

1 - A Standby

To switch the TV on or back to standby. 2 - Playback and record keys

• Play x, to playback

• Pause p, to pause playback

• Stop q, to stop playback

• Rewind !, to rewind

• Fast Forward ‹,to wind fast forward

• Record r, to record now

3 - GUIDE

To open or close the TV guide.

4 - c SOURCE

To open or close the list of connections.

5 - 3D

To open or close the 3D menu.

6 - AMBILIGHT

To switch Ambilight on or off and to switch Ambilight on in standby.

7 - f FORMAT

To open or close the Format menu.

8 - TV

To switch back to watching channels.

Middle

1 - h Home

To open or close the home menu.

2 - L LIST

To open or close the channel list or your list of photos, music or videos.

3 - / EXIT

To quit an interactive TV application, like Hbb TV.

4 - b Back

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous Smart TV Internet page.

5 - SMART TV

To open the Smart TV start page.

6 - i INFO

To open or close Info. 7 - OK key To confirm a selection.

8 - Arrow keys

To navigate up, down, left or right.

8 - o OPTIONS

To open or close the Options menu.

Bottom

1 - CH-, Channel - / Previous page

To switch to the previous channel in the channel list, the previous page in Text or the previous chapter on a disc. 2 - CH+, Channel + / Next page To switch to the next channel in the channel list, the next page in Text or the next chapter on a disc. 3 - Volume - and + To adjust the volume level.

4 - **** Colour keys

Direct s election of options. Blue key * information on what is selected and direct link to Help. 5 - Number keys and text keypad To select a TV channel directly or to enter text.

6 - SUBTITLE

To switch subtitles on, off or on during mute.

7 - TEXT

To open or close Text. 8 - m, Mute To mute the sound or to restore it.

Keyboard

Overview

Qwerty and Azerty

Overview of a Qwerty / Azerty keyboard.*

1 - Fn key - To type a number or punctuation character. 2 - ( Shift - To type uppercase letters. 3 - y Spacebar 4 - Arrows for navigation.

22 TV / Remote control

5 - Enter - To confirm the text you entered. 6 - Backspace - Deletes the character in front of the text

cursor. 7 - Ω Special character - To open the onscreen keyboard to select accented letters or symbols. 8 - Azerty letter - Letters available if the keyboard layout is set to Azerty in the Setup menu.

* Your remote control has a Qwerty / Azerty or a Qwerty / Cyrillic keyboard, depending on your region.

Qwerty and Cyrillic

Overview of a Qwerty / Cyrillic keyboard.*

1 - Fn key - To type a number or punctuation character. 2 - ( Shift - To type uppercase letters. 3 - y Spacebar 4 - Arrows for navigation. 5 - Enter - To confirm the text you entered. 6 - Backspace - Deletes the character in front of the text

cursor. 7 - Ω Special character - To open the onscreen keyboard to select accented letters or symbols. 8 - î Cyrillic keyboard switch - To switch to the Cyrillic keyboard or back to Qwerty. 9 - Cyrillic letter - Letters available if the keyboard is switched to Cyrillic.

* Your remote control has a Qwerty / Azerty or a Qwerty / Cyrillic keyboard, depending on your region.

Writing text

With the keyboard on the back of the remote control, you can write text in any text field on screen. Turn the keyboard facing upwards to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs.

Enter text

To enter text in a text field on screen, select the text field and start typing. Press Enter to confirm the text.

Uppercase and lowercase

To type an uppercase letter, press the ( (Shift) key just before you type the letter. To type several uppercase letters consecutively, press and hold the ( key while typing. To type uppercase constantly, press the ( key for 2 seconds to switch the keyboard in uppercase mode. To switch out of uppercase mode, press the ( key again. If no keys are pressed for 20 seconds, the uppercase mode switches off automatically. Also, if you press another modifier key, like Fn or Ω, you switch out of uppercase mode.

Numbers and punctuation characters

To type a number or punctuation character, press the Fn key just before you type the number or punctuation character you need. You can switch the Fn mode on or off as you do for the uppercase mode.

Internet You can use the Fn key to enter www. or .com.

Accented letters and symbols

Accented letters and symbols are not available on the remote control keyboard. To type such a character, you can open the ons creen keyboard.

To open the onscreen keyboard, press Ω. In the onscreen keyboard, you can navigate to the character you need. Switch the keyboard layout with the colour keys. Press OK to enter a character. The onscreen keyboard disappears when you press a character on the remote control keyboard.

Alternatively, you can enter special characters with the remote control SMS/text keypad on the front of the remote control.

Qwerty, Azerty and Cyrillic keyboard

The standard layout of the remote control keyboard is Qwerty.

Azerty keyboard

Depending on your region, the remote control keyboard can be set to Azerty. The Azerty characters are shown at the top right of the relevant ke ys. To set the keyboard layout to Azerty, . . . 1 - Press h and select S Setup and press OK to open the Setup menu.

2 - Select TV settings > General settings > Remote control keyboard. 3 - Select QWERTY or AZERTY.

Cyrillic keyboard

Depending on your region, the remote control keyboard can be switched to Cyrillic characters. The Cyrillic characters are shown at the top right of the keyboard keys. To write Cyrillic characters, press î on the remote control. Press î again to switch back to Qwerty.

TV / Remote control 23

Pointer

About pointer

Instead of navigating the screen with the arrow keys, you can use the pointer. You can move the pointer - a blue arrow over the TV scre en by moving the remote control. Just like you move the cursor on a computer screen with a mouse.

You can use the pointer to navigate Smart TV Apps* and Internet pages on TV. Some Smart TV Apps might not support the use of the pointer. When the pointer is not available, you can use the arrow keys to navigate the screen. You can adjust the speed of the pointer or if you never want to use the pointer, you can switch it off.

*Gradually more Smart TV Apps will become available for use with the pointer.

Using the pointer

When you open the Sm art TV start page, the pointer is shown in the middle of the TV screen.

Put your thumb on the OK key - do not press it - and move the remote control from the wrist, no need to move your arm. You can let go of the OK key and leave the pointer where it is. You can move the remote control and pick up the pointer again when you put your thumb back on the OK key.

When you press an arrow key to navigate, the pointer disappears. To recall the pointer, put your thumb on the OK key and briefly jiggle the remote control.

When you hover the pointer over a link . . .

1 - The pointer lights up. 2 - Press OK to open the link.

When you hover the pointer over a text field . . . Press OK to enter text.

Speed

You can adjust the speed of the pointer, the speed at which the pointer moves on screen.

To adjust the speed . . .

1 - Press h, select S Setup and press OK.

2 - Select TV settings and press OK. 3 - Select General settings > Pointer and mouse speed and press OK. 4 - Press the arrows u (Up) or v (Down) to increase or lower

the speed.

5 - Press the arrow x (Right) to test the speed you set. 6 - Press the arrow w (Left) to return to the setting. You can

adjust the s etting again.

7 - Press OK to store and close the setting.

Switch off

If you want to navigate the Smart TV and Internet pages with the arrow keys only, you can switch off the pointer.

To switch off the pointer . . .

1 - Press h, select S Setup and press OK. 2 - Select TV settings and press OK. 3 - Select General settings > Remote control pointer and select Off. 4 - Press b, repeatedly if necessary, to close the menu.

IR Sensor

The remote control of the TV uses RF (radio frequency) to send its commands to the TV. With RF, you do not need to point the remote control at the TV.

However, the TV can also receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

Pairing

This remote control uses radio frequency (RF) to send its commands to the TV. Contrary to remote controls using infrared signals, with this remote control you can send commands without pointing at the TV.

With no need to point the remote control, using the keyboard on the back or sending com m ands from another room changing the volume or switching channels - is easy. Additionally, the TV can notify you when the battery power of the remote control is low.

Pairing the remote control

For the re m ote control to communicate with the T V, both TV and remote control should be paired with each other. Once paired, you cannot use the remote control to control another TV. When you started the initial TV installation, the TV invited you to press the OK key, and by doing so, the pairing was done. When you switch off the TV, the pairing is stored. You can pair up to 5 remote controls with this TV.

24 TV / Remote control

Pairing again

You can pair another remote control with this TV. The method to pair a remote control is different for a remote control already paired with another TV compared with a remote control that is not paired yet.

• The remote control is paired with another TV

To pair, hold the Remote control close to the Philips logo (about 10cm) and press the * Red and * Blue key at the same time. A message will appear if pairing is successful.

• The remote control is not paired yet

To pair, hold the Remote control close to the Philips logo (about 10cm) and press OK. A message will appear if pairing is successful.

For retail

To pair a new - not yet paired - TV with a remote control which is already paired with another TV, hold the Remote control close to the Philips logo (about 10cm) and press the

* Red and * Blue key at the same time. A message will

appear if pairing is s uccessful.

Batteries

The TV will notify you when the battery power of the remote control is low.

To replace the batteries, open the battery compartment on the keyboard side of the remote control.

1 - Use a toothpick or other small, blunt object and press the small, square shaped release button to open the lid. 2 - Press the small lever next to the blue clip to release the clip. 3 - Replace the old batteries with 2 type AAA-LR03-1.5V alkaline batteries. Make sure the + and the - ends of the batteries line up correctly.

4 - Press the blue clip down until it clicks. 5 - Reposition the battery cover and press it until it clicks.

Put the remote control down for about 15 seconds to calibrate the pointer.

Remove the batteries if you are not using the remote control for a long time. Dis pose of batterie s according to the end of use directives. In Help, press * List and look up End of use for more information.

Cleaning

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

3.3

TV channels

Watching TV channels

Switch channels

To watch TV channels, press t TV. The TV tunes to the TV channel you last watched.

Alternatively, press h to open the Home menu and select

Watch TV and press OK.

Switch channels

To switch channels, press CH+ or CH-. If you know the channel number, type in the number with the number keys. Press OK after you entered the number to switch channel. To switch back to the previously tuned channel, press b.

To switch to a channel from a channel list

While watching a T V channel, press L LIST to open the channel lists. Select a list in the row of tabs.

In a channel list, navigate to a TV channel or radio station. With the highlight on its icon, press OK to switch to the TV channel or lis ten to the radio station. The channel list can have several pages with channels. To view the next or previous page, press CH- or CH+. To close the channel lists without switching channel, press L LIST again.

TV / TV channels 25

+ 58 hidden pages
