Page 1

Philips 7000 series LCD TV with Pixel Plus HD

Brilliant design, powerful performance

119 cm (47")

Full HD 1080p

47PFL5609S

With superb picture and sound.

Experience brilliant performance with a Full HD 1080p display. Combined with a powerful Pixel Plus HD Engine and fantastic invisible sound, this Flat TV will never let you down.

Vivid and razor sharp pictures

• Pixel Plus HD for better details, depth and clarity

• Full HD LCD display, with a 1920x1080p resolution

• Dynamic contrast 50000:1 for incredible rich black details

• Active Control with Light Sensor optimizes picture quality

• Native cinema mode for real movie experience

Pure and lifelike sound

• 2.1 channel surround with subwoofer for deep bass

• 20W for superior sound clarity

• Dynamic Bass Enhancement for cinematic sound

• Invisible speakers with incredible surround

Easy to connect and enjoy

• USB for fantastic multimedia playback

• 3 HDMI inputs with Easylink for a full HD connection

• Smart Picture and Smart Sound to personalize your viewing

Page 2

LCD TV with Pixel Plus HD

with

119 cm (47") Full HD 1080p

Highlights

47PFL5609S/98

Pixel Plus HD

Pixel Plus HD is a picture processing te

chnology that enables viewers to watch content that is vivid, natural, and real. The result means superbly life-like pictures with incredible details and depth from any HD source.

Full HD LCD display 1920x1080p

The Full HD screen has the widescreen resolutio resolution of HD sources for the best possible picture quality. It is fully future proof as it supports 1080p signals from all sources, including the most recent like Blu-ray and advanced HD game consoles. The signal processing is extensively upgraded to support this much higher signal quality and resolution. It produces brilliant flicker-free progressive scan pictures with superb brightness and colors.

2.1 channel surround

This 2.1 channel surround with integrated subwoo

n of 1920 x 1080p. This is the highest

fer is a complete sound system that

utilises Philips incredible surround sound processing technology. It amplifies the bass frequencies from the subwoofer and at the same time optimzing mid and low frequencies. The result is a system that powerfully reproduces the full range of audio frequencies from deep bass to crystal clear high notes.

USB (multimedia)

The USB connector allows access to jpeg ph

otos, mp3 music and video files of most USB-sticks (USB memory-class device). Plug the USB into the slot at the side of the TV and access the multimedia content using the easy on screen content browser. You can now view and share your videos, photos and music.

3 HDMI inputs with EasyLink

EasyLink uses the HDMI CEC industry s

tandard protocol to share functionality between connected devices and the TV. With Easylink only one remote control is needed to operate main functionalities on your TV and connected devices. HDMI makes an uncompressed digital RGB connection from

the source to the screen for the ultimate picture quality. HDMI uses HDCP copy protection. With 2 HDMI inputs on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, for instance an HD settop box, a Blu-ray player, and Game Console or Digital Camcorder.

Smart Picture and Smart Sound

Philips preset modes for Smart Picture and Smart Sound a single key on the remote control. You can select optimized picture and sound settings for the various picture and sound modes.

Invisible speakers

An invisible sound system that blends perfectly w

ith the design of the cabinet. The Incredible Surround allows you to experience total surround with greater depth and width of sound. It gives a clear and spacious sound stage complementary to the rich viewing experience.

provide you with direct access via

Page 3

LCD TV with Pixel Plus HD

119 cm (47") Full HD 1080p

Specifications

47PFL5609S/98

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 50 000:1

• Response time (typical): 5 ms

• Viewing angle: 178º (H) / 178º (V)

• Diagonal screen size: 47 inch / 119 cm

• Display screen type: LCD Full HD W-UXGA Act. ix

mat

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus HD, 3/2 - 2/2

tio

n pull down, 3D Combfilter, Active Control

mo + Light sensor, Color Enhancement, Dynamic contrast enhancement, Jagged Line Suppression, Sharpness Adjustment, Dynamic Noise Reduction, 2D/3D noise reduction, 1080p 24/25/30Hz processing, 1080p 50/60Hz processing

• Screen enhancement: Semi-glare

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 640 x 480 60, 72, 75, 85Hz 800 x 600 60, 72, 75, 85Hz 1024 x 768 60, 70, 75, 85Hz 1280 x 768 60Hz 1280 x 1024 60Hz 1360 x 768 60Hz Via HDMI/DVI

inpu

• Video formats

olution Refresh rate

Res 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz 720p 50, 60Hz 1080i 50, 60Hz 1080p 24, 25, 30, 50, 60Hz

Sound

• Output power (RMS): 20W

• Sound Enhancement: Auto Volume Leveller,

namic Bass Enhancement, Incredible Surround,

Dy Subwoofer, Treble and Bass Control

• Sound System: Mono, Nicam Stereo, Stereo

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: On main display, Sleep Timer, Wake up k, Wake Up Timer

Cloc

• Connection Enhancement: Easy link

• Ease of Installation: Autos

Digital Tuning, Plug & Play, Program Name, Sorting

• Ease of Use: Auto Volume Leveller (AVL),

aphical User Interface, On Screen Display, Side

Gr Control, Smart Picture, Smart Sound, EasyLink

• On-Screen Display languages: Arab

French, Thai, Traditional Chinese

• Picture in Picture: Picture in graphics

• Remote Control: TV

• Remote control type: PF02A09B

• Screen Format Adjustments: 4:3, Movie expand

, Movie expand 16:9, Subtitle Zoom, Super

14: Zoom, Widescreen

• Teletext: 1000 page Smart Text

• Teletext enhancements: 4 favourite pages

• Signal strength indication

• Firmware upgradeable: Firmware upgradeable via

US Multimedia: USB media browser

•

ore, Fine Tuning, PLL

ic, En

glish,

Multimedia Applications

• Playback Formats: MP3, JPEG Still pictures, MPEG1,

MPEG4, RealMedia Video

• Playback enhancement: Picture slidesho

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL B/G, PAL D/K

• Video Playback: NTSC, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• Number of Preset Channels: 99

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: Audio L/R in, CVBS in

•Front / Side connections: HDMI

CVBS in, Audio L/R in, Headphone Out, USB

• Other connections: Monitor out, CVBS, L/R h), PC-in VGA + Audio L/R in

(cinc

•HDMI 1: HDMI v1.3

•HDMI 2: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, EasyLink,

mot

e control pass-through, System audio

v1.3, S-vi

deo in,

ntrol, System standby

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 110-240V; 50-60Hz

• Power consumption: 265 W

• Standby power consumption: (typical) <0.15W

Dimensions

• Set dimensions (W x H x D): 1150 x 712 x 88 mm

• Set dimensions with stand (W x H x D):

• Weight incl. Packaging: 32 kg

• Product weight: 21 kg

• Product weight (+stand): 25 kg

•Box dimensions (W x H x D):

• VESA wall mount compatible: 400 x 400 mm

762 x 295 mm

1150

x 871 x 310 mm

Accessories

• Included accessories: Tabletop swivel stand, Power cord, Quick start guide, User Manual, Remote Control, 2 x AAA Batteries

• User Manual: Arabic, English, French, Malay, Thai,

aditional Chinese

•

Issue date 2012-05-20

Version: 5.4.4

12 NC: 8670 000 51786 EAN: 87 12581 47817 9

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com
