Philips Signage Solutions
D-Line Display
Say more
43"
UHD (3840 x 2160)
500cd/m²
43BDL4510D
Smart, fast 24/7 display.
Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb
picture quality ensures true colors and intense contrast. You can effortlessly display
content from multiple sources on a single screen.
Brilliant picture. Blazing processor speed.
• Place in landscape or portrait orientation
• 4K UHD. Rich, deep images. Stunning contrast
• ADS wide-view panel display
Operational flexibility
• SmartPower for energy saving
Effortless setup. Total control.
• Schedule what you want, when you want with SmartPlayer
• Operate, monitor and maintain with CMND & Control
Cost-effective system solution
• FailOver ensures content is always playing
• Energy-saving automatic backlight control
43BDL4510D/00
D-Line Display
43" UHD (3840 x 2160), 500cd/m²
Highlights
FailOver
From waiting room to meeting room, never
show a blank screen. FailOver lets your Philips
Professional Display switch automatically
between primary and secondary inputs
ensuring content keeps playing even if the
primary source goes down. Simply set a list of
alternate inputs to be sure your business is
always on.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
CMND & Control
Run your display network over a local (LAN)
connection. CMND & Control allows you to
perform vital functions like controlling inputs
and monitoring display status. Whether you're
in charge of one screen or 100.
SmartPlayer
Turn your USB into a true cost effective digital
signage device. Simply save your content
(video, audio, pictures) on your USB and plug
into your display.Create your playlist and
schedule your content via the on screen menu,
and enjoy your own created playlists anytime,
anywhere.
ADS wide-view panel display
Be seen from any angle with ADS wide-view
t
echnology. Advanced Super Dimension
Switch delivers faster on-display picture
processing for smoother content transitions,
remarkable image accuracy, and superior
colour reproduction with 180 degree viewing.
43BDL4510D/00
D-Line Display
43" UHD (3840 x 2160), 500cd/m²
Specifications
Picture/Display
• Diagonal screen size: 42.5 inch / 108.0 cm
• Panel resolution: 3840 x 2160
• Optimum resolution: 3840 x 2160 @ 60Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 1200:1
• Dynamic contrast ratio: 500,000:1
• Aspect ratio: 16:9
• Response time (typical): 8 ms
• Pixel pitch: 0.2451 x 0.2451 mm
• Display colors: 1.07 G Billion
• Viewing angle (H / V): 178 / 178 degree
• Picture enhancement: 3/2 - 2/2 motion pull down,
mbfi
3D Co
MA deinterlacing, Dynamic contrast enhancement,
Progressive scan
• Panel technology: ADS
lter, Motion compens. deinterlacing, 3D
Connectivity
• Video input: Display Port1.2 (x1), DVI-I (x 1),
HDMI 2.0 (x2), USB 2.0 (x2)
• Video output: DisplayPort 1.2 (x1), HDMI 2.0 (x1)
• Audio input: 3.5 mm jack
• Audio output: 3.5mm jack
• External control: RJ45, RS232C (in/out) 2.5 mm
c
k, IR (in/out) 3.5 mm jack
ja
Supported Display Resolution
mputer formats
• Co
Res
olution Refresh rate
1920 x 1080 60Hz
1024 x 768 60Hz
1280 x 1024 60Hz
1280 x 720
14
40 x 900 60 Hz
1600 x 900 60Hz
1680 x 1050 60Hz
3840 x 2160 30, 60Hz
640 x 480 60Hz
800 x 600 60Hz
deo formats
• Vi
olution Refresh rate
Res
1080i 50, 60Hz
576i 50Hz
576p 50Hz
480p 60Hz
480i 60Hz
1080p 50, 60Hz
60Hz
2160p 24, 30, 60Hz
720p 50,60 Hz
Dimensions
•Set dimensions (W x H x D):
973.0 x 561.2 x 63.5 mm
• Set dimensions in inch (W x H x D):
1 x 22.09 x 2.50 inch
38.3
• Bezel width: 13.9 mm (Even bezel)
• Product weight (lb): 23.61 lb
• Product weight: 10.71 kg
• VESA Mount: 200 (H) x 200(V) mm, M6
Convenience
• Placement: Landscape (24/7), Portrait (24/7)
•
Keyboard control: Hidden, Lockable
• Signal loop through: RS232, IR Loopthrough,
DisplayPort, HDMI
Network controllable: RS232, RJ45
•
• Energy saving functions: Smart Power
• Screen saving functions: Pixel Shift, Low Bright
Power
• Standby power consumption: 0.5 W
• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
• Consumption (Typical): 90 W
• Consumption (Max): 150 W
• Energy Label Class: G
Operating conditions
• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20 ~ 60 °C
• Altitude: 0 ~ 3000 m
• MTBF: 50,000 hour(s)
• Humidity range (operation)[RH]: 20 - 80% RH (No
nden
sation)
co
• Humidity range (storage) [RH]: 5 - 95% RH (No
sation)
conden
Sound
• Built-in speakers: 2 x 10W RMS
Accessories
• Included accessories: Quick start guide, RS232
cable, AC Power Cord, HDMI cable, Remote
Control & AAA Batteries
• Stand: BM05922(Optional)
• Included Accessories: RS232 daisy-chain cable,
Philips lo
go
(x1), Screws, USB Cover (x1), AC
Switc
h Cover
Multimedia Applications
• USB Playback Audio: AAC, HEAAC, MPEG
• USB Playback Picture: BMP, JPEG, PNG
• USB Playback Video: MPEG, H.263, H.2
VP8
64, H.265,
Miscellaneous
• On-Screen Display Languages: English, French,
German, Spanish, Polish, Turkish, Russian, Italian,
Simplified Chinese, Traditional Chinese, Arabic,
Japanese, Danish, Dutch, Finnish, Norwegian,
Portuguese, Swedish
• Regulatory approvals: CE, CCC, BSMI, CB, VCCI,
, EMF, ET
CU
• Warranty: 3 year warranty
•
L, FCC, Class A, PSB, RoHS
Issue date 2021-05-26
Version: 3.0.1
12 NC: 8670 001 68848
EAN: 87 12581 76885 0
© 2021 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
