Philips 42PFL7503 User Manual

Philips
LCD TV with Pixel Plus 3
HD

42"

Full HD 1080p

42PFL7503

Be part of the action.

Experience brilliant performance with a breathtaking full HD 1080p, 100Hz display.
Combined with a powerful Pixel Plus 3HD engine, HD Natural Motion and exciting
invisible sound, this Flat TV ensures you're always part of the action.

See every detail of the action

• Pixel Plus 3 HD for most sharp and clear pictures

• Full HD LCD display, with a 1920x1080p resolution

• HD Natural Motion for ultra smooth motion in Full HD movies

• 100Hz LCD, 3ms performance for superb motion sharpness

• 4 trillion colors processing for vivid and brilliant images

• Dynamic contrast 30000:1 for incredible rich black details

Exciting and powerful sound

• Virtual Dolby Digital for a true life audio experience

Connect, install and enjoy

• USB for fantastic photo and music playback

• 4 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV & connected device via HDMI CEC

Ready for digital

• Integrated Digital Tuner for DVB-T reception

LCD TV with Pixel Plus 3 HD

42" Full HD 1080p

Highlights

42PFL7503/10

Pixel Plus 3 HD

Pixel Plus 3 HD offers the unique combination
o

f ultimate sharpness, natural detail, vivid
colors and smooth natural motion on all
qualities of HD, standard TV signals and
multimedia content, for high definition displays.
Each pixel of the incoming picture is enhanced
to better match the surrounding pixels,
resulting in a more natural picture. Artifacts
and noise in all sources from multimedia to
standard TV and also in highly compressed HD
are detected and reduced ensuring that the
picture is clean and razor sharp.

Full HD LCD display 1920x1080p

The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.

HD Natural Motion

Philips invented HD Natural Motion to
e

liminate juddering effects that are visible with
movie based picture content. HD Natural
Motion estimates motion in the picture and
corrects juddering movements in both
broadcast and recorded movie material (such
as DVD and Blu-ray Disc). The resulting
smooth motion reproduction and excellent
sharpness take the viewing experience to a
higher level. HD Natural Motion removes
judder from SD and HD pictures, including
1080p, for a motion performance that
surpasses the cinema!

100Hz LCD (3ms)

100Hz LCD creates extreme motion
sharpness for clear and vibrant images even
with fast on-screen motion. The Double Frame
Rate Insertion works with a high 100Hz
refresh rate. It increases the sharpness of
motion reproduction to more than twice that
of conventional LCD, resulting in a
performance with a response time of 3
milliseconds (measured in Perceived Blur­Edge-Width; BEW). This unique Philips
technology brings motion sharpness of LCD
displays to an unprecedented level.

Dynamic contrast ratio 30000:1

You want the LCD flat display with the highest
c

ontrast and most vibrant images. Philips
advanced video processing combined with
unique extreme dimming and backlight
boosting technology results in vibrant images.
Dynamic Contrast will increase the contrast
with excellent blacklevel and accurate
rendition of dark shades and colors. It gives a
bright, lifelike picture with high contrast and
vibrant colors.

4 HDMI inputs

HDMI makes an uncompressed digital RGB
conne

ction from the source to the screen for
the ultimate picture quality. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources and
includes digital audio. HDMI uses HDCP copy
protection. With 3 HDMI inputs on the back
and 1 HDMI on the side of the TV you can
connect multiple HD sources, for instance an
HD settop box, a Blu-ray player, and game
console or digital Camcorder. Your TV is fully
prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry
standard proto
between connected devices and the TV. With
EasyLink only one remote control is needed to
operate main functionalities on your TV and
connected devices. EasyLink uses the standard
HDMI cable to transfer system commands. It
works between all electronic devices equipped
with HDMI CEC.

col to share functionality

LCD TV with Pixel Plus 3 HD

42" Full HD 1080p

Specifications

42PFL7503/10

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 30000:1

• Response time (typical): 3 (BEW equiv.) ms

• Viewing angle: 176º (H) / 176º (V)

• Diagonal screen size: 42 inch / 107 cm

• Display screen type: LCD Full HD W-UXGA Act.
rix

mat

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2

tion pull down, 3D Combfilter, Active Control

mo
+ Light sensor, Dynamic contrast enhancement,
Progressive Scan, 100Hz LCD, 1080p 24/25/30Hz
processing, 1080p 50/60Hz processing, HD
Natural Motion

• Screen enhancement: Anti-Reflection coated

reen

sc

• Color processing: 4 trillion colors (14bit RGB)

Supported Display Resolution

• Computer formats

Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 768 60Hz
1360 x 768 60Hz
1920 x 1080i 60Hz
1920 x 1080p 60Hz

deo formats

• Vi

Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 24, 50, 60Hz
1080p 24, 25, 30Hz

• Remote Control: TV

• Remote control type: RC2143605

• Screen Format Adjustments: 4:3, Auto Format,
vie expand 14:9, Movie expand 16:9, Subtitle

Mo
and Heading Shift, Super Zoom, Widescreen,
unscaled (1080p dot by dot)

• Teletext: 1200 page Hypertext

• Teletext enhancements: Habit Watch, Program

rmation Line

info

• Firmware upgradeable: Firmware auto upgrade

d, Firmware upgradeable via USB

wizar

• Multimedia: Digital media reader (browser), USB

reak-in

autob

• Smart mode: Game, Movie, Personal, Energy

aving, Standard, Vivid

s

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, Slideshow files (.alb), JPEG

ill pictures, MPEG1, MPEG2

St

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

• Ext 2 Scart: Audio L/R, CVBS in/out, RGB

• Ext 3: YPbPr, Audio L/R in, VGA PC-in

• Ext 4: HDMI v1.3

• Ext 5: HDMI v1.3

• Ext 6: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System

dio control, System standby

au

•Front / Side connections: HDMI

CVBS in, Audio L/R in, Headphone out, USB

• Other connections: Analog au

PDIF out (coaxial), Common Interface

v1.3, S-video in,

dio Left/Right out, S/

Sound

• Output power (RMS): 2 x 15W

• Sound Enhancement: Auto V
Signal Processing, Dynamic Bass Enhancement,
Graphic Equaliser, Smart Sound

• Sound System: Virtual Dolby Digital, BBE

olume Leveller, Digital

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Ease of Installation: Auto Program Naming,

matic Channel Install(ACI), Automatic Tuning

Auto
System (ATS), Autostore, Fine Tuning, PLL Digital
Tuning, Plug & Play

• Ease of Use: 4 favorite lists, Au
(AVL), Delta Volume per preset, Graphical User
Interface, On Screen Display, Program List,
Settings assistant Wizard, Side Control

• Electronic Program Guide: Now + Next EPG, 8
day Electronic Progr

• Picture in Picture: Text dual screen

am Guide

to Volume Leveller

Issue date 2009-08-10

Version: 1.1.7

12 NC: 8670 000 42991
EAN: 87 12581 44889 9

Power

• Ambient temperature: 5 °C to 35 °C

• Mains power: AC 220 - 240 V +/- 10%

• Power consumption: 206 W

• Standby power consumption: 0,15 W

Dimensions

• Set dimensions (W x H x D): 1046 x 644 x 88 mm

• Set dimensions with stand (W x H x D):
716 x 262 mm

46 x

10

• Weight incl. Packaging: 42 kg

• Product weight: 21 kg

• Product weight (+stand): 25.5 kg

•Box dimensions (W x H x D):

51 x 793 x 333 mm

11

• Color cabinet: High gloss b

black cabinet

• VESA wall mount compatible: 400 x 400 mm

lack deco front with

Accessories

• Included Accessories: Power cord, User Manual,

Warranty certificate, Remote Control, Batteries
for remote control

•
