Page 1
Philips
LED TV with Pixel Plus HD
Relax and enjoy a great TV night
107cm (42")
Full HD 1080p
42PFL5606S
with brilliant LED picture
Relax and enjoy a great TV night in brilliant LED quality on the Philips 5000 Series
42PFL5606 LED TV. Powered by the Pixel Plus HD engine for clear, vivid Full HD
pictures, and complimented by authentic sound.
Your entertainment in brilliant detail
• Full HD TV with Pixel Plus HD for better details and clarity
• Brilliant LED images with low power consumption
• 100Hz Perfect Motion Rate (PMR) for superb motion sharpness
Authentic and clear sound experience
• Feel the power of 20W RMS and Incredible Surround
Complete connectivity made simple
• Seamless connectivity with 3 HDMI inputs and Easylink
• PC-input allows you to use your TV as a PC monitor
• USB for fantastic multimedia playback
Simple to set up, easy to use
• Easy to set up with setting assistance
Page 2
LED TV with Pixel Plus HD
Full HD
LED
Perfect Motion Rate
107cm (42") Full HD 1080p
Highlights
42PFL5606S/98
Pixel Plus HD
Pixel Plus HD offers the unique combination of
ul
timate sharpness, natural detail, vivid colors,
and smooth natural motion. Artifacts and noise
in any sources from multimedia to standard
definition TV and also in highly compressed
HD are detected and reduced, ensuring that
the picture is clear and razor-sharp.
LED
The most advanced LED lighting technology in
this TV combines an eye-catching minimalistic
design with stunning image quality as well as
the lowest power consumption in its category.
On top of that, LED lighting technology does
not contain any hazardous materials. Thus,
with LED backlight you can enjoy low power
consumption, high brightness, incredible
contrast, sharpness and vibrant colors.
20W RMS Incredible Surround
Feel the power of the music beat and the
atmosphere of the
movies. The powerful 20W
RMS (2x10W RMS) amplifiers create a lifelike
sound stage. Incredible Surround allows you to
experience total surround with greater depth
and width of sound complementary to the rich
viewing experience.
3 HDMI inputs with Easylink
HDMI is a single cable to carry both picture
and audio signals from your devices to your
TV, avoiding cable clutter. It carries
uncompressed signals, ensuring the highest
quality from source to screen. Together with
Philips Easylink, you need only one remote
control to perform most operations on your
TV, DVD, BluRay, set top box or home theatre
system.
USB (multimedia)
The USB connector allows access to jpeg
photos, mp3 music and video files of most
USB-sticks (USB memory-class device). Plug
the USB into the slot at the side of the TV and
access the multimedia content using the easy
on screen content browser. You can now view
and share your videos, photos and music.
PC input (HDMI and VGA)
With PC input you can use your TV as a PC
moni
tor either using a HDMI-DVI cable/
converter (for digital signals) or VGA cable (for
analog signals).
Easy to set up
This TV is easy to setup with the step by step
setting assistant. The assistant shows a few
screens with easy to choose options to select
the essential settings. The TV performance is
set to the your personal preference without
difficult terms or settings, and this very quickly.
28.9
x3
billion colours
Page 3
SIDE CONNECTORS
HDMI
VIDEO
L
R
AV IN
TV
ANTENNA
USB
2
1
1
2
3
BOTTOM REAR CONNECTORS
PC INCOMPONENT
SPDIFVIDEO OUT
VIDEO
/Y Pb Pr L R
VGA AUDI O
LED TV with Pixel Plus HD
107cm (42") Full HD 1080p
Specifications
42PFL5606S/98
Picture/Display
• Display: LED Full HD
• Diagonal screen size: 42 inch / 107 cm
• Panel resolution: 1920x1080p
• Aspect ratio: Widescreen
• Brightness: 400 cd/m²
• Response time (typical): 2 ms
• Picture enhancement: Pixel Plus HD, 100 Hz
t Motion Rate
ec
Perf
Sound
• Output power (RMS): 2x8 +10W
• Sound Enhancement: Auto Volume Leveller,
Sound, Treble and Bass Control, Virtual Surround
Sound
Smart
Connectivity
• Number of HDMI connections: 3
• EasyLink (HDMI-CEC): System audio control,
em standby, One touch play, System info
Syst
(menu language)
• Number of component in (YPbPr): 1
• Number of AV connections: 2
• Number of USBs: 2
• Other connections: Antenna IE
C75, Digita
l audio
out (coaxial), PC-in VGA + Audio L/R in,
Composite video (CVBS) out, Headphone out
Multimedia Applications
• Multimedia connections: USB
• Playback Formats: H.264/MPEG-4 AVC, JPEG Still
ures, MP3, MPEG1, MPEG2, MPEG4
pict
Supported Display Resolution
• Computer inputs: up to 1920x1080 @ 60Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to
1080p
1920x
Convenience
• Multimedia: USB autobreak-in, USB media browser
• Screen Format Adjustments: 4:3, Auto Format,
Movie expand 14:9, Mo
vie expand 16:9, Subtitle
Zoom, Super Zoom, unscaled (1080p dot by dot),
Widescreen
• Teletext: 1000 page Smart Text
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL B/G, PAL D/K, SECAM D/K, PAL I
• Video Playback: NTSC, PAL
Power
• Mains power: 220-240V; 50Hz
• Ambient temperature: 5 °C to 35 °C
• Standby power consumption: <0.5
• Power consumption: 125 W
Dimensions
•Box dimensions (W x H x D):
1210 x 722 x 168 mm
•Set dimensions (W x H x D):
x 611.1 x 39.9 mm
994.1
• Set dimensions with stand (W x H x D):
x 661.8 x 240 mm
994.1
• Product weight: 12.4 kg
• Product weight (+stand): 15.1 kg
• Weight incl. Packaging: 18 kg
• Compatible wall mount: 200 x 200mm
Accessories
• Included accessories: Power cord, Remote
Control, 2 x AAA Batteries, Table top stand, User
Manual, Quick start guide, Warranty Leaflet
•
Issue date 2014-02-13
Version: 8.5.3
12 NC: 8670 000 76637
EAN: 87 12581 60423 3
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
