Philips 42PFL5422/93 Specifications

Download

Page 1

Philips widescreen flat TV with Pixel Plus HD

107cm (42")

LCD HD Ready

42PFL5422

Turn up your viewing experience

with Pixel Plus HD

Experience the superior picture quality of this excellent HD Ready TV with the latest LCD technology and Pixel Plus HD. It's packed into a stunning design that will complement your interior.

Breathtaking natural pictures

• HD LCD WXGA display, with a 1366 x 768p resolution

• HD Ready for the highest quality display of HD signals

• Pixel Plus HD for better details, depth and clarity

• Progressive Scan component video for optimized image quality

Crisp and Clear sound

• Virtual Surround Sound for enhanced sound

Slim, stylish design to complement your interior

• Compact and slim design that fits in every room

Designed for your convenience

• Smart Picture and Smart Sound to personalize your viewing

• PC input lets you also use your TV as a PC monitor

For advanced performance

• HDMI input for full digital HD connection in one cable

Page 2

Widescreen flat TV with Pixel Plus HD

107cm (42") LCD HD Ready

Highlights

42PFL5422/93

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD s

creen technology gives you widescreen HD resolution of 1366 x 768p pixels. It produces brilliant flicker-free progressive scan pictures with optimum brightness and superb colors. This vibrant and sharp image will provide you with an enhanced viewing experience.

HD Ready

Enjoy the exceptional picture quality of High Definiti

on pictures and be fully prepared for HD sources like HDTV settop box or Blu-ray disc. HD Ready is a protected label that offers picture quality beyond that of progressive scan. It conforms to strict standards laid out by EICTA to offer a HD screen that displays the benefits of resolution and picture quality of a High Definition signal. It has a universal connection for both analog YPbPr and uncompressed Digital connection of DVI or HDMI, supporting HDCP. It can display 720p, and 1080i signals at 50 and 60Hz.

Pixel Plus HD

Pixel Plus HD is a picture processing te

chnology that enables viewers to watch

content that is vivid, natural, and real. The result means superbly life-like pictures with incredible details and depth from any HD source.

Progressive Scan

Progressive Scan doubles the vertical resoluti

on of the image resulting in a noticeably sharper picture. Instead of sending a field comprising the odd lines to the screen first, followed by the field with the even lines, both fields are written at one time. A full image is created instantaneously, using the maximum resolution. At such a speed, your eye perceives a sharper picture with no line structure.

Virtual surround sound

Virtual surround sound creates additional audio

channels for a theater-like audio

experience.

Compact and slim design

This design style emphasizes a slim, compact l

ook that saves space and fits in anywhere.

Smart Picture and Smart Sound

Philips preset modes for Smart Picture and Smart Sound a single key on the remote control. You can select optimized picture and sound settings for the various picture and sound modes.

HDMI input

HDMI makes an uncompressed digital RGB c

onnection from the source to the screen. By eliminating conversion to an analog signal, it delivers an unblemished image. The nondegraded signal reduces flicker and leads to a clearer picture. HDMI intelligently communicates the highest output resolution with the source device. The HDMI input is fully backward compatible with DVI sources but includes digital audio. HDMI uses HDCP copy protection.

PC input

With PC input you can connect your TV to a c

omputer and use the TV as a PC monitor.

provide you with direct access via

Page 3

Widescreen flat TV with Pixel Plus HD

107cm (42") LCD HD Ready

Specifications

42PFL5422/93

Picture/Display

• Color cabinet: Silver, high gloss black

• Aspect ratio: Widescreen

• Diagonal screen size: 32 inch / 107 cm

• Display screen type: LCD WXGA Active Matrix T

•

Panel resolution: 1366 x 768p

• Picture enhancement: Pixel Plus HD, Di

Crystal Clear, 3/2 - 2/2 motion pull down, 3D Combfilter, 3D MA deinterlacing, Blue stretch, Black stretch, White stretch, Green enhancement, Progressive scan, Smart Picture, Automatic skin tone correction

• Screen enhancement: Anti-Reflection coated

tal

Supported Display Resolution

• Computer formats

Resolution Refresh rate 640 x 480 60Hz 800 x 600 56, 60Hz 1024 x 768 60Hz 1280 x 720 60Hz 1280 x 768 60Hz

deo formats

• Vi

olution Refresh rate

Res

0i 60Hz

48 480p 60Hz 576i 50Hz 576p 50Hz 720p 60Hz 1080i 60Hz

Sound

• Output power (RMS): 2 x 10 W

• Sound Enhancement: Virtual Surround Sound

• Sound System: Mono, Nicam Stereo, Stereo

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Installation: Autost

Digital Tuning, Sorting

• Ease of Use: Auto Volume Leveller (AVL), On

Display, Program List, Smart Picture, Smart

Screen

ore, Fine Tuning, PLL

Sound, Top Controls

• Remote Control: TV

• Remote control type: RC2023611/01B

• Screen Format Adjustments: 4:3, Subtitle Zoom, rwide, Widescreen, Zoom 14:9, Zoom 16:9

Supe

• Picture in Picture: Picture in graphics

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL D/K

• Video Playback: NTSC, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: Audio L/R in, CVBS in, S-Video in

•AV 4: HDMI

•Front / Side connections: Audio

Headphone Out, S-video in

• Other connections: Analog audio Left/Right out,

site video (CVBS) out, PC Audio in, PC-In

Compo VGA, S/PDIF out (coaxial)

L/R

in, CVBS in,

Power

• Ambient temperature: 0 °C to 40 °C

• Mains power: 90-264 VAC, 50/60 Hz

• Power consumption: < 275 W

• Standby power consumption: < 2 W

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, User Manual, Warranty certificate, Remote Control, Batteries for remote control

Dimensions

•Set dimensions (W x H x D):

1039 x 682 x 107 mm

• Set dimensions with stand (W x H x D):

x 745 x 291 mm

1039

• Product weight: 26 kg

• Product weight (+stand): 31 kg

•Box dimensions (W x H x D):

x 803 x 362 mm

• Weight incl. Packaging: 35 kg

• VESA wall mount compatible: 400 x 200 mm

•

Issue date 2012-01-20

Version: 1.1.3

12 NC: 8670 000 39073 EAN: 87 12581 41278 4

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com
