42PFL5405H-05
User Manual
55 pgs2.4 Mb0

Philips 40PFL56x5K-02, 40PFL6605H-12, 37PFL5405H-05, 37PFL5405H-12, 37PFL5405H-60 User Manual

...
Register your product and get support at
www.philips.com/welcome
EN User Manual
Downloaded From TV-Manual.com Manuals
46PFL5805H/12
Contents
1 Get started 3
Important 3 Enjoy HD TV 6 Wall mount the TV 6 Product highlights 7 Access more information 8
2 Use your TV 9
Overview 9 Side controls and indicators 9 Remote control 9 Basic TV menus 11 Watch TV 13 Watch a connected device 15
3 Use more of your TV 16
Use teletext 16 Favourite channels 17 Use EPG 17 Use timers and locks 17 Use subtitles 18 Access multimedia 18 Use Scenea 19 Universal access 20
4 Set up the TV 21
Change picture and sound settings 21 Change channel settings 22 Install channels 23 Change language settings 25 Change other settings 25 Update the TV software 26 Reinstall the TV 27
5 Connect the TV 28
6 Troubleshooting 46
Contact us 46 General TV issues 46 TV channel issues 46 Picture issues 46 Sound issues 47 HDMI connection issues 47 USB connection issues 48 PC connection issues 48
7 Technical data 49
Overview 49 Power and reception 49 Display and sound 49 Display resolutions 49 Multimedia 49 Connectivity 50 Dimensions 50
8 Index 52
First connections 28 About cables 28 TV connectors overview 30 Connect devices 31 Connect more devices 37 Use Philips EasyLink 41 Use a CAM 45
Downloaded From TV-Manual.com Manuals
EN 2
English
1 Get started
Important
Congratulations
NonPublish
Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your TV at (http://www.philips.com/welcome).
Safety
NonPublish
Read and understand all instructions before you use your TV. If damage is caused by failure to follow instructions, the warranty does not apply.
Risk of electric shock or fire! Never expose the TV to rain or water. Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips Consumer Care to have the TV checked before use.
Never insert objects into the ventilation
slots or other openings on the TV.
When the TV is swivelled, ensure that
no strain is exerted on the power cord. Strain on the power cord can loosen connections and cause arcing.
Never place the TV, remote control or
batteries near naked flames or other heat sources, including direct sunlight. To prevent the spread of fire, keep candles or other flames away from the TV, remote control and batteries at all times.
Risk of short circuit or fire!
Never expose the remote control or
batteries to rain, water or excessive heat.
Downloaded From TV-Manual.com Manuals
Avoid force coming onto power plugs.
Loose power plugs can cause arcing or fire.
Risk of injury or damage to the TV!
Two people are required to lift and
carry a TV that weighs more than 25 kg/55 lbs.
When stand mounting the TV, use only
the supplied stand. Secure the stand to the TV tightly. Place the TV on a flat, level surface that can support the combined weight of the TV and the stand.
When wall mounting the TV, use only a
wall mount that can support the weight of the TV. Secure the wall mount to a wall that can support the combined weight of the TV and wall mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper wall mounting that result in accident, injury or damage.
Before you connect the TV to the
power outlet, ensure that the power voltage matches the value printed on the back of the TV. Never connect the TV to the power outlet if the voltage is different.
Risk of injury to children! Follow these precautions to prevent the TV from toppling over and causing injury to children:
Never place the TV on a surface
covered by a cloth or other material that can be pulled away.
Ensure that no part of the TV hangs
over the edge of the mounting surface.
Never place the TV on tall furniture,
such as a bookcase, without anchoring both the furniture and TV to the wall or a suitable support.
Educate children about the dangers of
climbing on furniture to reach the TV.
Risk of overheating!
Never install the TV in a confined space.
Always leave a space of at least 4 inches around the TV for ventilation. Ensure curtains or other objects never cover the ventilation slots on the TV.
EN 3
Risk of injury, fire or power cord damage!
Never place the TV or any objects on
the power cord.
To easily disconnect the TV power cord
from the power outlet, ensure that you have full access to the power cord at all times.
When you disconnect the power cord,
always pull the plug, never the cable.
Disconnect the TV from the socket and
aerial before lightning storms. During lightning storms, never touch any part of the TV, power cord or aerial cable.
Risk of hearing damage! Avoid using earphones or headphones at high volumes or for prolonged periods of time.
Low temperatures If the TV is transported in temperatures below 5°C/41°F, unpack the TV and wait until the TV temperature matches room temperature before connecting the TV to the power socket.
Screen care
NonPublish
Risk of damage to the TV screen! Never
touch, push, rub or strike the screen with any object.
Unplug the TV before cleaning. Clean the TV and frame with a soft
damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the TV.
To avoid deformations and colour
fading, wipe off water drops as soon as possible.
Avoid stationary images as much as
possible. Stationary images are images that remain on-screen for extended periods of time. Stationary images include on-screen menus, black bars, time displays etc. If you must use stationary images, reduce screen contrast and brightness to avoid screen damage.
End of use
NonPublish
Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC. Please inform yourself about the local separate collection system for electrical and electronic products.
Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.
Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed of with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environment and human health.
Downloaded From TV-Manual.com Manuals
EN 4
English
Green eco
NonPublish
This TV has been awarded the European Union Ecolabel for its environmental qualities.
A TV that is awarded the Ecolabel includes the following green eco features that contribute to energy-efficient use: Adjustable green eco settings Access green eco settings while watching TV by pressing the green button on the remote control
These green eco settings include:
Energy-saving picture settings: The
[Energy saving] smart setting applies a
combination of picture settings to reduce energy consumption.
Ambient light sensor: To save energy,
the built-in Ambient light sensor lowers the brightness of the TV screen when the surrounding light darkens.
Mute screen: Turns off the TV display.
Other functions, including sound, continue to operate normally. 'Muting' the screen saves energy if you just want to listen to audio from the TV.
See Set up the TV > Change other settings > Green eco settings (Page 25) for more information about these green eco settings.
Built-in green eco settings
Low standby power consumption: The
class-leading and highly advanced power circuitry brings down the power consumption of the TV to an extremely low level, without losing out on the constant standby functionality.
Dedicated power switch: Completely
cut off power to the TV with the dedicated power switch located on the bottom of the set.
Advanced power management: The
advanced power management of this TV ensures the most efficient use of its energy. To view how your personalised TV settings affect the TV's relative power consumption, press and select [Setup] > [Watch demos] > [Active Control].
We continually focus on lowering the environmental impact of our innovative consumer products. We aim our efforts towards making environmental improvements during manufacturing, including reduction of harmful substances, promoting energy-efficient use and providing information on end of use and product recycling.
Thanks to our environmental efforts, this TV is awarded the European Ecolabel.
Find detailed information on standby energy consumption, warranty policy, spare parts and recycling of this TV at the Philips website for your country (http://www.philips.com/).
Information on end of use To find out about the correct disposal of this
TV and batteries, see Get started > Important > End of use (Page 4).
Downloaded From TV-Manual.com Manuals
EN 5
Use a Kensington lock
NonPublish
Your TV is equipped with a Kensington security slot on the bottom of the TV. Purchase a Kensington anti-theft lock (not supplied) to secure the TV.
Enjoy HD TV
Full HD content
NonPublish
This TV can display full High-Definition (HD) video content. To enjoy HD content, you must connect your TV to an HD source.
Contact your dealer for more information on where to obtain HD video content in your country.
Your TV can display HD video content from:
a Blu-ray disc player, connected with an
HDMI cable, playing a Blu-ray disc
an upscaling DVD player, connected
with an HDMI cable, playing a DVD disc
an over-the-air HD broadcaster (DVB-T
MPEG4)
a digital HD receiver, connected with an
HDMI cable, playing HD content from a cable or satellite operator
an HD channel on your DVB-C
network
an HD game console (for example,
X-Box 360 or PlayStation 3), connected with an HDMI cable, playing an HD game
Position the TV
NonPublish
Before positioning the TV, read all
safety precautions. See Get Started > Important > Safety (Page 3).
Position the TV where light does not
shine directly on the screen.
The ideal distance from which to watch
TV is three times its diagonal screen size. For example, if the diagonal screen size of the TV is 116 cm/46 ", the ideal viewing distance is approx. 3.5m/138" from the front of the screen.
While seated, your eyes should be level
with the centre of the screen.
Wall mount the TV
NonPublish
To mount the TV, purchase an appropriate TV mount for your set. Check your TV screen size and match it against the list below for the type of wall mount to purchase:
81 cm/32 inches: 200 mm x 200 mm, M6 81 cm/32 inches: 200 mm x 300 mm, M6
(For PFL6605 only)
94 cm/37 inches: 300 mm x 200 mm, M6 102 cm/40 inches: 200 mm x 200 mm, M6
107 cm/42 inches: 300 mm x 200 mm, M6 117 cm/46 inches: 300 mm x 300 mm, M8 132 cm/52 inches: 300 mm x 300 mm, M8
Warning: Follow all instructions provided with the TV mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper TV mounting that results in accident, injury or damage.
To prevent damage to cables and connectors, be sure to leave a clearance of at least 5.5 cm/2.2" from the back of the TV.
For 32-inch to 40-inch TVs (For PFL6605 only):
Downloaded From TV-Manual.com Manuals
EN 6
English
Before you wall mount the TV, make a note of the correct length of the screw. You can determine the length of the screw by adding the thickness of your wall mount to the screw length shown in the graphic.
For 32 inch and 40 inch TVs Before you wall mount the TV, make a note of the correct length of the screw. You can determine the length of the screw by adding the thickness of your wall mount to the screw length shown in the graphic.
For 37 inch to 42 inch TVs Before you wall mount the TV, make a note of the correct length of the screw. You can determine the length of the screw by adding the thickness of your wall mount to the screw length shown in the graphic.
For 46 inch and 52 inch TVs Before you wall mount the TV, make a note of the correct length of the screw. You can determine the length of the screw by adding the thickness of your wall mount to the screw length shown in the graphic.
Downloaded From TV-Manual.com Manuals
Product highlights
Full HD LCD display
This TV is equipped with a full High-Definition (HD) LCD display, supporting the maximum HD resolution of 1920 x 1080p. This display offers a brilliant flicker-free progressive scan picture with optimum brightness and superb colors.
EN 7
The LED backlight* of the display offers exceptional picture contrast with exceptional energy saving.
*Note: Certain models are equipped with an EEFL backlight display only. For detailed product information, go to (http://www.philips.com/support).
To enjoy HD content, you must connect to an HD source first; otherwise, the picture quality will be that of a normal TV. See Get started > Enjoy HD TV > Full HD content (Page 6).
Digital TV
NonPublish
In addition to normal analogue TV broadcasts, your TV can receive digital terrestrial (DVB-T) broadcasts. Where available, your TV can also receive digital cable (DVB-C), digital satellite (DVB-S: Not supported on all models) and digital radio broadcasts.
DVB (Digital Video Broadcasting) gives you a better picture and better sound quality. Some digital broadcasters also include several audio (speech) and/or teletext languages with DVB.
EPG
Electronic Programme Guide (EPG) is an on-screen guide available for digital channels. EPG allows you to:
View a list of digital programmes being
broadcast
View upcoming programmes Group programmes by genre Set reminders when programmes start Set up preferred EPG channels
Notes:
EPG is not available in all countries. For more information on EPG, see Use
more of your TV > Use EPG (Page
17).
Multimedia
View or play your own multimedia files (such as photos, music and videos) from the USB connection on the side of the TV.
See Use more of your TV > Access
multimedia (Page 18).
Access more information
On-screen
NonPublish
You are reading the on-screen user manual. This manual contains all of the information you need to install and use this TV. Access the user manual by selecting [Help] in the home menu.
Before carrying out instructions, temporarily close the user manual by pressing the yellow button on the remote control. Press the yellow button again to open the user manual at the same page.
On the Internet
NonPublish
A printable PDF version of this user manual is available on the Internet. It contains the latest information and detailed feature explanations not covered in this on-screen user manual.
Access the PDF, as well as other product information, including FAQs and firmware upgrades, at (http://www.philips.com/support).
Downloaded From TV-Manual.com Manuals
EN 8
English
2 Use your TV
Overview
This section gives you an overview of commonly used TV controls and functions.
Side controls and indicators
NonPublish
1. Standby indicator/remote control sensor.
Remote control
Overview
NonPublish
1. 1. +/- : Increases or decreases volume. In the home menu, these buttons allow you to move horizontally.
2. (Home): Accesses the home menu. Press again to launch an activity in the home menu.
3. P/CH +/- : Switches to the next or previous channel. In the home menu, these buttons allow you to move vertically.
4. Power: Switches the TV on (' | ') or off (' o ').
Downloaded From TV-Manual.com Manuals
1. (Standby): Switches the TV to standby if it is on. Switches on the TV if it is in standby.
2. (Home): Accesses the home menu.
3. (Browse): Accesses the browse menu
to select TV channel list, the Electronic Programme Guide and teletext.
4. (Navigation buttons): Navigates menus and selects items.
5. (Previous/Next): Switches channels. Also, skips through pages of a menu, and between tracks, albums or folders.
6.OK: Confirms an entry or selection.
EN 9
7. (Experience): Accesses the experience bar menu.
8. (Options): Accesses options for the current activity or selection.
9.+/- (Volume) and (Mute): Increases or decreases volume; mutes or restores audio.
10.Colour buttons: Selects tasks or options.
11.0-9 (Numeric buttons): Selects a channel
or setting.
12. (Picture format): Selects a picture format.
Batteries
NonPublish
Open the battery cover on the back of the remote control to insert the batteries (Type AAA-LR03-1.5 V). Make sure the + and ­ends of the batteries line up correctly (+ and
- are marked inside). Remove the batteries if you are not using the remote control for a long time. Dispose of batteries according to the end of use
directives. Read Get started > Important >
End of use (Page 4).
Note: The location of the battery
compartment on some remote controls may be as follows:
13. (Subtitle): Enables or disables subtitles.
14. (Back): Returns to a previous menu
screen. Press and hold to return to watching TV.
Downloaded From TV-Manual.com Manuals
EN 10
English
Usage
NonPublish
When using the remote control, hold it close to the TV and point it at the remote control sensor. Make sure that the line-of-sight between the remote control and TV is not blocked by furniture, walls or other objects. The following illustration is an example only -­the location of the remote control sensor may differ on your TV:
Basic TV menus
Home
NonPublish
The home menu gives you easy access to connected devices, picture and sound settings, and other useful features.
1. Press .
2. Select an item in the home menu, then press OK to access the menu.
3. To exit the home menu, press or .
On-screen remote control
NonPublish
An On-Screen Remote Control (OSRC) is available, which gives you easy access to commonly-used functions. Availability of on-screen buttons differs according to your TV setup.
To access the OSRC
1. While watching TV or a connected device, press .
2. Select [Show device keys], then press OK.
3. Use the Navigation buttons and OK to select and use an on-screen button.
To start an activity, select the desired item with the Navigation buttons, then press OK:
[Help]: Accesses the electronic user
manual.
[Watch TV]: Switches back to the
antenna source if another source is selected.
[Browse USB]: If a USB storage device
is connected, accesses the content browser.
[Scenea]: Switches to the Scenea
wallpaper.
[Add your devices]: Adds new devices
to the home menu. Note that you must add a new device to the home menu in order to access it.
[Setup]: Accesses menus that allow you
to change picture, sound and other TV settings.
Browse
NonPublish
The browse menu gives you easy access to:
Electronic programme guide TV channel list Teletext
Downloaded From TV-Manual.com Manuals
EN 11
To access the browse menu, while watching TV, press .
1. Press the Navigation buttons to select an item:
[Programme guide]: Accesses the
Electronic Programme Guide.
[Channel list]: Accesses the TV channel
list.
[Text]: Accesses teletext.
2. Press OK to confirm your choice.
Experience
Press to access the experience bar menu, which provides a range of frequently-used settings.
The experience bar menu gives you easy access to:
[Picture format]: Changes the picture
format.
[Smart picture]: Frequently-used
picture settings.
[Smart sound]: Frequently-used sound
settings.
[Speakers]: Configure TV speakers for
Philips EasyLink.
[Picture shift]: Adjusts the position of
the picture.
Channel list
NonPublish
The channel list displays the TV channels and possible radio stations installed on your TV.
1. While watching TV, press .
2. Select [Channel list], then press OK.
3. Select a channel, then press OK to access the channel.
4. Press to exit the channel list without changing the channel.
Add your devices
NonPublish
After you connect a device to the TV, add this device in the home menu for easy access.
In the home menu, select [Add your devices], then press OK. Follow the instructions on-screen to add the device to the home menu.
To remove a device from the home menu, select the item, press and select [Remove
this device]. Press OK.
Setup
NonPublish
[Setup] in the home menu allows you to change most of the TV settings, including:
Picture or sound settings Installation or update of TV channels Update of TV software Other special features
1. In the home menu, select [Setup], then press OK.
2. Select an item with the Navigation buttons, then press OK:
[Personalise picture and sound]:
Guides you through picture and sound settings.
[Advanced TV settings]: Advanced
picture and sound settings.
[Search for channels] or [Search for
satellite]: Guides you through antenna
or satellite (if available) channel installation.
[Advanced channel settings] or
[Advanced satellite settings]: Advanced
channel settings.
[Update software]: Guides you through
an update of the TV software.
[Advanced software update]: Advanced
TV update settings.
[Watch demos]: Demos of special
features available with the TV.
Downloaded From TV-Manual.com Manuals
EN 12
English
Options
NonPublish
Option menus offer convenient settings related to what is on-screen.
1. Press to see what options are available.
2. To exit, press again.
Watch TV
Switch on/off or to standby
To switch to standby
Press on the remote control. The front LED indicator switches to red.
To switch off Press the power switch on the bottom of
the TV to the 'o' position. The TV switches off.
Though your TV consumes very little power when in standby, energy continues to be consumed. When not in use for an extended period of time, switch off the TV using the power switch on the bottom of the set.
Switch channels
NonPublish
Press on the remote control or
P/CH +/- on the side of the TV.
To switch on
If the front LED indicator is off, press
the power switch (1) on the bottom of the TV to the ' | ' position.
If the front LED indicator is red, press
on the remote control (2). Alternatively, switch on the TV from standby by pressing any key on the side of the TV.
Notes:
The front LED indicator does not turn
on when the TV is switched on.
The TV requires some time to start up.
During this time, the TV will not respond to the remote control or side controls. This is normal behavior.
Downloaded From TV-Manual.com Manuals
Press , then select [Channel list] to
use the channel list.
Press to return to the
previously-viewed channel.
Enter a channel number using the
Numeric buttons.
To view analogue or digital channels only
Filter the channel list to access analogue or digital channels only.
1. In the channel list, press .
2. Select [Select list] > [Analogue] or [Digital], then press OK. Depending on your selection, only digital or analogue channels become available.
EN 13
Adjust volume
NonPublish
To increase or decrease volume
Press +/- on the remote control. Press +/- on the side of the TV.
NonPublish
To mute or unmute sound
Press to mute the sound. Press again to restore the sound.
Use the [Sound] menu to adjust headphone volume. For more information, see Setup
the TV > Change picture and sound settings > More sound settings (Page 22).
Use Smart picture settings
NonPublish
Use the [Smart picture] experience bar to access frequently-used picture settings.
1. While watching TV, press .
2. Select [Smart picture], then select one of the following settings:
[Personal]: Sets the TV to your
personal preferences set in the [Picture] menus in [Setup].
[Vivid]: Rich and dynamic settings, ideal
for daylight use.
[Natural]: A natural picture setting. [Cinema]: Ideal settings for watching
movies.
[Game]: Ideal settings for gaming. [Energy saving]: The most
energy-conscious settings.
[Standard]: Adjusts picture settings to
suit most environments and types of video. Factory default settings.
[Photo]: Ideal settings for viewing
photos.
[Custom]: Allows you to customise and
store personal picture settings.
3. Press OK to confirm your choice.
4. Press to exit.
Use Smart sound settings
NonPublish
Use the [Smart sound] experience bar to access frequently-used sound settings.
1. While watching TV, press .
2. Select [Smart sound], then select one of the following settings:
[Personal]: Sets the TV to your
personal preferences set in the [Sound] menus in [Setup].
[Standard]: Adjusts sound settings to
suit most environments and types of audio.
[News]: Applies sound settings ideally
suited for spoken audio, such as the news.
[Movie]: Applies sound settings ideally
suited for movies.
[Game]: Ideal settings for gaming. [Drama]: Applies sound settings ideally
suited for drama.
[Sports]: Applies sound settings ideally
suited for sports.
3. Press OK to confirm your choice.
4. Press to exit.
Change picture format
h
Change the picture format to suit your viewing experience.
1. Press .
2. Select a picture format, then press OK to confirm your choice.
Note: Picture formats are also accessible via the experience bar menu ( ) and [Setup] menu.
The following picture formats can be selected:
[Auto fill]: Adjusts the picture to fill the
screen (subtitles remain visible). Recommended for minimal screen distortion but not for HD or PC.
Downloaded From TV-Manual.com Manuals
EN 14
English
[Auto zoom]: Enlarges the picture to fill
the screen. Recommended for minimal screen distortion but not for HD or PC.
[Super zoom]: Removes the black bars
on the sides of 4:3 broadcasts. Not recommended for HD or PC.
[Movie expand 16:9]: Scales the classic
4:3 format to 16:9. Not recommended for HD or PC.
[Wide screen]: Stretches the classic 4:3
format to 16:9.
[Unscaled]: Provides maximum detail
for PC. Only available when [PC mode] is enabled in the [Picture] menu.
Notes:
Depending on the picture source, some
picture formats are not available and will not be seen on-screen.
Watch a connected device
Add new device
NonPublish
Notes:
Before watching a connected device,
you must add it to the home menu.
HDMI ARC compliant devices
connected to the HDMI ARC connector on the TV are automatically added to the home menu.
1. Connect and switch on the device.
2. Press .
3. Select [Add your devices], then press
OK. Follow the on-screen instructions.
Watch connected device
NonPublish
1. Press .
2. Select the device from the home menu.
3. Press OK to confirm your choice.
Downloaded From TV-Manual.com Manuals
EN 15
3 Use more of
your TV
Use teletext
Select a page
NonPublish
1. Press .
2. Select [Text], then press OK.
3. Select a page by:
Entering the page number with the
Numeric buttons.
Pressing or to view the next or
previous page.
Pressing the Colour buttons to select a
colour coded item.
4. Press to exit teletext.
Access teletext options
NonPublish
1. When in teletext, press .
2. Select an option:
[Freeze page] / [Unfreeze page]:
Freezes or unfreezes the current page.
[Dual screen] / [Full screen]: Enables
or disables dual screen teletext, which splits the current channel or source to the left of the screen, with teletext on the right.
[T.O.P. overview]: Table Of Pages
(T.O.P.) teletext broadcasts allow you to jump from one subject to another without using page numbers.
N
[Enlarge] / [Normal view]: For more
comfortable reading, you can enlarge the teletext page. Press the Navigation buttons to move around the enlarged
screen.
[Reveal]: Hides or reveals hidden
information on a page, such as solutions to riddles or puzzles.
[Cycle subpages]: Cycles through
subpages automatically if subpages are available.
[Language]: Switches to a different
language group to display a language correctly when that language uses a different character set.
3. Press to exit the options menu.
Select a teletext language
Some digital TV broadcasters have several teletext languages available. You can set your primary and secondary language.
1. Press .
2. Select [Setup] > [Advanced channel
settings] or [Advanced satellite settings] > [Languages] > [Primary Text] or [Secondary Text].
3. Select your preferred teletext languages, then press OK.
Select subpages
NonPublish
A teletext page number can hold several subpages. These subpages are shown on a bar next to the main page number.
When available on a teletext page, press or to select subpages.
Search teletext
NonPublish
1. When in teletext, press OK to highlight the first word or number.
2. Press the Navigation buttons to skip to the word or number to search.
3. Press OK to begin the search.
4. Press until no word or number is highlighted to exit the search.
Use digital teletext
NonPublish
Some digital TV broadcasters offer dedicated digital text or interactive services on their digital TV channels, for example, BBC1. When in digital teletext:
Press the Navigation buttons to select
or highlight items.
Use the Colour buttons to select an
option, then press OK to confirm or activate.
Note: Digital text services are blocked when subtitles are broadcast and [Subtitles] are enabled. Read Use more of your TV > Use
subtitles (Page 18).
Use Teletext 2.5
NonPublish
Teletext 2.5 offers more colours and better graphics than normal teletext. If Teletext 2.5 is broadcast by a channel, it is switched on by default.
Downloaded From TV-Manual.com Manuals
EN 16
English
To switch Teletext 2.5 on or off
1. Press .
2. Select [Setup] > [Advanced TV settings] > [Preferences] > [Text 2.5] > [On] or
[Off], then press OK.
Favourite channels
Add or remove channels
NonPublish
1. Press .
2. Select [Channel list:], then press OK.
3. Press .
4. Select [Mark as favourite] or [Unmark as favourite], then press OK. A star appears in the channel grid, indicating that the channel is added to the favourite list. The star disappears if you remove the channel from the favourite list.
Select a favourite list
NonPublish
View only channels in a favourite list, or view all channels if a favourite list is currently selected.
1. In the channel list, press .
2. Select [Select list] > [Favourites] to display channels in a favourite list, or [All] to display all channels.
3. Press OK to confirm your choice.
Use EPG
Overview
NonPublish
The Electronic Programme Guide (EPG) is an on-screen guide available for digital channels. EPG allows you to:
View a list of digital programmes being
broadcast
View upcoming programmes Group programmes by genre Set reminders when programmes start Set up preferred EPG channels
Note: EPG is not available in all countries.
Switch on EPG
NonPublish
1. Press .
2. Select [Programme guide], then press OK.
Downloaded From TV-Manual.com Manuals
EPG options
NonPublish
Use the EPG options menu to set or clear reminders, change day and access other useful EPG options. Depending on the broadcast service, these options are available only for seven or eight days.
1. When in EPG, press .
2. Press the Navigation buttons and OK to select and adjust one of the following settings:
[Set reminder]: Sets programme
reminders.
[Clear reminder]: Clears programme
reminders.
[Change day]: Sets the EPG day. Select
[Today], [Next day] or [Previous day].
[More info]: Views programme
information.
[Search by genre]: Searches TV
programmes by genre.
[Scheduled reminders]: Lists
programmes reminders.
[Update Programme guide]: Updates
the latest programme information.
Use timers and locks
Sleeptimer
NonPublish
Sleeptimer switches the TV to standby after a pre-defined period of time. You can always switch off your TV earlier or reset the sleeptimer during the countdown.
1. Press .
2. Select [Setup] > [Advanced TV settings] > [Preferences] > [Sleeptimer].
3. Press the Navigation buttons to set the sleeptimer. The sleeptimer can be set up to 180 minutes, in steps of five minutes. The sleeptimer is switched off if it is set to zero minutes.
4. Press OK to activate the sleep timer. The TV switches to standby after the set period of time.
EN 17
Loading...
+ 38 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
