Philips 42PFL5203/98 Leaflet

Download

Page 1

Philips LCD TV with Pixel Plus 2 HD

107cm (42")

HD Ready

42PFL5203

Be part of the action

Experience brilliant performance with a 768p display. Combined with a powerful Pixel Plus 2HD engine and fantastic invisible sound, this Flat TV ensures you're always part of the action.

See smooth and sharp action

• Pixel Plus 2 HD for great details, depth and clarity

• HD LCD display, with a 1366 x 768p resolution

• HD Natural Motion for ultra smooth motion in Full HD movies

• 28.9 billion colors for brilliant natural images

Hear pure and powerful sound

• Invisible speakers with incredible surround

• 30W RMS high audio power

Easy to connect and enjoy

• 3 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV & connected device via HDMI CEC

• PC-input allows you to use your TV as a PC monitor

• Smart mode selects a perfect mode for what you are watching

Page 2

LCD TV with Pixel Plus 2 HD

28.9

billion colours

107cm (42") HD Ready

Highlights

42PFL5203/98

Pixel Plus 2 HD

Pixel Plus 2 HD offers the unique combination o

f ultimate sharpness, natural detail, increased depth, vivid colors and smooth and natural motion from standard TV, High Definition signals and multimedia sources. Each pixel of the incoming picture is enhanced to better match the surrounding pixels, resulting in a more natural picture. Artifacts in compressed multimedia content are detected and reduced, ensuring that the picture is clean and razor sharp. Digital noise reduction ensures that the picture is perfectly smooth yet razor sharp.

LCD display, 1366 x 768p

This WXGA display with state-of-the-art LCD s

creen technology gives you widescreen HD resolution of 1366 x 768p pixels. It produces brilliant flicker-free progressive scan pictures with optimum brightness and superb colors. This vibrant and sharp image will provide you with an enhanced viewing experience.

HD Natural Motion

Philips invented HD Natural Motion to minimize movie based picture content. The award winning algorithm estimates motion in the picture and corrects juddering movements in both broadcast and recorded movie material

juddering effects that are visible with

(such as DVD and Blu-ray Disc). The resulting smooth motion reproduction and excellent sharpness take the viewing experience to a higher level.

28.9 billion colors

Vibrant and natural images from the most advan

ced color processing. The 3 color channels (RGB) are optimized for a total processing power of 28.9 billion colors. The advanced algorithms detect even the subtlest shades and skin tones, creating the best color possible.

Invisible speakers

An invisible sound system that blends perfectly w

ith the design of the cabinet. The Incredible Surround allows you to experience total surround with greater depth and width of sound. It gives a clear and spacious sound stage complementary to the rich viewing experience.

3 HDMI inputs

HDMI makes an uncompressed digital RGB conne

ction from the source to the screen for the ultimate picture quality. HDMI intelligently communicates the highest output resolution with the source device. The HDMI input is fully backward compatible with DVI sources and includes digital audio. HDMI uses HDCP copy

protection. With 2 HDMI inputs on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, for instance an HD settop box, a Blu-ray player, and game console or digital Camcorder. Your TV is fully prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry standard proto between connected devices and the TV. With EasyLink only one remote control is needed to operate main functionalities on your TV and connected devices. EasyLink uses the standard HDMI cable to transfer system commands. It works between all electronic devices equipped with HDMI CEC.

Smart mode

The optimum picture and sound depends on v

arious aspects like the video source, content type, surroundings of the room, type of display device etc. Smart Mode has predefined picture and sound settings conveniently preset by the way you use your TV. The ‘Personal’ setting, allows you to define the picture settings according to your preference, store it and gain easy access for future selection. All these conveniently built into your TV for optimal settings.

col to share functionality

Page 3

LCD TV with Pixel Plus 2 HD

107cm (42") HD Ready

Specifications

42PFL5203/98

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 24000:1

• Response time (typical): 5 ms

• Viewing angle: 178º (H) / 178º (V)

• Diagonal screen size: 42 inch / 107 cm

• Display screen type: LCD Full HD W-UXGA Act. ix

mat

• Panel resolution: 1366 x 768p

• Picture enhancement: Pixel Plus 2 HD, 3D

mbfilter, Active Control + Light sensor,

C Contrast Plus, Digital Noise Reduction, Jagged Line Suppression, Luminance Transient Improver, Progressive scan, HD Natural Motion

• Screen enhancement: Anti-Reflection coated

Supported Display Resolution

• Computer formats

Res

olution Refresh rate 640 x 480 60, 72, 75, 85Hz 720 x 400 70Hz 800 x 600 60, 72, 75, 85Hz 1024 x 768 60, 70, 75, 85Hz 1280 x 768 60Hz 1280 x 1024 60Hz 1360 x 768 60Hz

deo formats

• Vi Res

olution Refresh rate 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz 720p 50, 60Hz 1080i 50, 60Hz 1080p 24, 50, 60Hz 1080p 24, 25, 30Hz

Sound

• Equalizer: 7-bands

• Output power (RMS): 30W

• Sound Enhancement: Auto Volume Leveller,

• Sound System: Mono, Stereo, BBE

Equaliser, Incredible Surround

Graphic

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: On main display, Sleep Timer, Wake Up r

Time

• Connection Enhancement: Easy link

• Ease of Installation: Autostore, Fine Tuning,

ram Name, Sorting

Pro

• Ease of Use: 8 channel smart surf

list, Auto Volume

Leveller (AVL), Program List, Side Control

• On-Screen Display languages:

English, Simplified

Chinese, Arabic, Thai, Vietnamese

• Remote Control: TV

• Remote control type: PF02A08B

• Screen Format Adjustments: 4:3, Movie expand

, Movie expand 16:9, Subtitle Zoom, Super

14: Zoom, Widescreen

• Teletext: 1000 page Smart Text

• Signal strength indication

• Smart mode: Game, Movie, Personal, Power saver,

dard, Vivid

Sta

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL I, PAL B/G, PAL

SECAM D/K

• Video Playback: NTSC, SECAM, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• Number of Preset Channels: 99

D/K, SECAM B/G,

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, CVBS in

•HDMI 1: HDMI v1.3

•HDMI 2: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System

(menu language), System standby

inf

•Front / Side connections: HDMI v1.3, S-vi

deo in,

CVBS in, Audio L/R in, Headphone Out

• Other connections: PC-in VGA + Audio L/R in

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 100-240V, 50/60Hz

• Power consumption: 200 W

• Standby power consumption: (typical) <0.15W

46 x 716 x

262 mm

• Weight incl. Packaging: 31.5 kg

• Product weight: 20 kg

• Product weight (+stand): 25.5 kg

•Box dimensions (W x H x D): 71

x 810 x 333 mm

• VESA wall mount compatible: 400 x 400 mm

Accessories

• Included accessories: Tabletop swivel stand, Power

cord, Quick start guide, User Manual, Registration card, Warranty certificate, Remote Control, Batteries for remote control

•

Loudspeakers

• Built-in speakers: 2

SERV. C

75X

TV ANTENNA

Issue date 2014-02-10

Version: 2.0.56

12 NC: 8670 000 40468 EAN: 87 12581 42934 8

Dimensions

• Set dimensions (W x H x D): 1046 x 645 x 88 mm

• Set dimensions with stand (W x H x D):

HDMI 2

HDMI 1

AUDIO IN VGA

VIDEO

LRL

CVI AV INAV OU T

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com
