User Manual

1 My new TV 4

1.1 Ultra HD TV 4

1.2 Smart TV 4

1.3 App gallery 4

1.4 Rental videos 4

1.5 Social networks 4

1.6 Ambilight+hue 5

1.7 Skype 5

1.8 Smartphones and tablets 5

1.9 Pause TV and recordings 5

1.10 Gaming 5

1.11 EasyLink 6

2 Setting up 7

2.1 Read safety 7

2.2 TV stand and wall mounting 7

2.3 Tips on placement 7

2.4 Power cable 7

2.5 Antenna cable 8

2.6 Satellite dish 8

3 Network 9

3.1 Wireless network 9

3.2 Wired network 10

3.3 Network settings 10

4 Connections 12

4.1 Tips on connections 12

4.2 EasyLink HDMI CEC 13

4.3 Common interface - CAM 14

4.4 Set-top box - STB 15

4.5 Satellite receiver 15

4.6 Home Theatre System - HTS 16

4.7 Blu-ray Disc player 17

4.8 DVD player 17

4.9 Game console 17

4.10 USB Hard Drive 18

4.11 USB keyboard or mouse 19

4.12 USB flash drive 20

4.13 Photo camera 20

4.14 Camcorder 20

4.15 Computer 21

4.16 Headphones 21

4.17 Wireless speakers (For 7500 series TV) 22

5 Switch on 23

5.1 On or Standby 23

5.2 Keys on TV 23

5.3 Word mark brightness 23

6 Remote control 24

6.1 Key overview for 7100, 7500 series 24

6.2 Key overview for 6300, 6500, 6600, 6700 series 25

6.3 Keyboard 26

6.4 Pointer (For 7500 series TV) 27

6.5 IR sensor for RF remote control 28

6.6 IR sensor for non-RF remote control 28

6.7 Pairing with TV 28

6.8 Batteries 29

6.9 Cleaning 29

7 TV channels 30

7.1 Watching TV channels 30

7.2 Channel installation 35

8 Satellite channels 39

8.1 Satellite channels 39

8.2 Watching satellite channels 39

8.3 Satellite channel list 39

8.4 Favourite satellite channels 39

8.5 Lock satellite channels 40

8.6 Satellite installation 41

8.7 Problems with satellites 45

9 Home menu 46 10 TV guide 47

10.1 What you need 47

10.2 Using the TV guide 47

10.3 Recordings 47

11 Sources 48

11.1 Sources list 48

11.2 From standby 48

11.3 EasyLink 48

12 Timers and clock 49

12.1 Sleeptimer 49

12.2 Clock 49

12.3 Switch off timer 49

13 3D 50

13.1 3D 50

13.2 What you need 50

13.3 The 3D glasses 50

13.4 Care of the 3D glasses 51

13.5 Watch 3D 51

13.6 Optimal 3D viewing 51

13.7 Health warning 52

14 Games 53

14.1 Play a game 53

14.2 Two-player games 53

15 Your photos, videos and music 55

15.1 From a USB connection or network computer 55

15.2 Wi-Fi Miracast 56

16 Pause TV 58 17 Recording 59

17.1 What you need 59

17.2 Record a programme 59

17.3 Watch a recording 59

18 Skype 61

18.1 About Skype 61

18.2 What you need 61

18.3 Start with Skype 61

18.4 Skype menu 62

18.5 My profile 62

18.6 People 63

18.7 Calling on Skype 64

18.8 Skype credit 65

18.9 Skype settings 65

18.10 Sign out 67

18.11 Quit Skype 67

18.12 Terms of use & Privacy Policy 67

19 Smart TV 68

19.1 About Smart TV 68

19.2 What you need 68

19.3 Setup Smart TV 68

19.4 Smart TV Apps 68

19.5 Reset Smart TV 70

20 Multi room 71

20.1 About Multi room 71

20.2 What you need 71

20.3 Using Multi room 71

21 Share this… 73 22 MyRemote App 74

22.1 About MyRemote App 74

22.2 What you need 74

22.3 App download 75

22.4 App menu 75

22.5 App functions 75

27.2 Screen care 106

28 Terms of use, copyrights and licenses 107

28.1 Terms of use 107

28.2 Copyrights and licenses 107

Index 110

23 Settings 78

23.1 Setup menu 78

23.2 Picture 79

23.3 Sound 83

23.4 Ambilight 86

23.5 Universal access 88

24 Specifications 91

24.1 Environmental 91

24.2 Reception for non-satellite TVs 92

24.3 Reception for satellite TVs 92

24.4 Display 92

24.5 Power 93

24.6 Dimensions and weights (7500 series) 93

24.7 Dimensions and weights (7100 series) 93

24.8 Dimensions and weights (6600/6700 series) 94

24.9 Dimensions and weights (6500 series) 94

24.10 Connectivity for three side connector 94

24.11 Connectivity for two side connector 95

24.12 Multimedia 95

25 Software 96

25.1 Software update 96

25.2 Software version 96

25.3 Open source software 96

25.4 Open source license 96

26 Troubleshooting and support 102

26.1 Troubleshooting 102

26.2 Register 103

26.3 Help 103

26.4 Online help 103

26.5 Consumer Care / Repair 104

27 Safety and care 105

27.1 Safety 105

There are Apps to rent a video from an online video store and Apps for watching programmes you missed.

My new TV

1.1

Ultra HD TV

This TV has an much as normal HD displays. Ultra HD means 8 million pixels for the most refined and lifelike picture on TV.

On top, the new converts any incoming TV signal into Ultra HD resolution. So you can enjoy this stunning picture quality the moment you switch on the TV. Or you can watch native Ultra HD videos through the HDMI 4 connection. Ultra HD offers TV viewing that is crisp and sharp even on a big screen.

Ultra HD

Ultra Pixel HD Engine

display. Its resolution is four times as

continuously

If the App gallery does not hold what you are looking for, try the World Wide Web and surf the Internet on TV.

, press 

Help

information.

1.4

Keywords

and look up

App gallery

for more

Rental videos

To watch a Simply rent the latest movie from your regional online video store.

rental video

, you don't need to leave your home.

• Only for TVs that have an Ultra HD display.

1.2

Smart TV

Connect this a new world of television. You can make a wired connection to your router or you can link up wirelessly with Wi-Fi.

With the TV connected to your home network, a smartphone can show a photo on TV, you can play videos stored on your computer or control the TV with your tablet.

With your TV connected to the Internet, you can watch a rental video from an online video store, read the online TV guide or record your favourite TV show on a USB Hard Drive.

The Smart TV Apps add to the fun with all sorts of entertainment and convenient services.

Help

information.

Philips Smart LED TV

, press 

Keywords

to the Internet and discover

and look up

Smart TV

for more

Start Smart TV and add the video store App to the Smart TV start page.

Open the video store App, create your personal account, select the movie and press play. No fuss with downloading, you can watch the movie immediately*.

, press 

Help

more information. * Depending on the video streaming service of the selected

video store.

1.5

Keywords

and look up

Rental videos

for

Social networks

No need to get up to check your friend's messages on your computer. Open Smart TV, select your message back from your couch.

social network

page and send a

1.3

App gallery

Open the collection of tailored websites for TV.

Find the App for YouTube videos, a national newspaper, an online photo album, Facebook, Twitter, etc.

App gallery

in Smart TV to browse the Apps, the

Smart TV supports the popular social networks Facebook and

Twitter. In

information.

1.6

Help

, press 

Keywords

Ambilight+hue

and look up

App gallery

for more

1.8

Smartphones and tablets

To use your smartphone or tablet as a TV remote control or as your media controller, download the from your smartphone or tablet app store.

Philips MyRemote

app

With

Ambilight+hue

follow the Ambilight colours of the TV. The Philips hue lamps will expand the Ambilight effect across the

room. If you don’t have any Philips hue lamps yet, buy the

Philips hue Starter Kit

and install the bulbs and bridge. You can buy extra Philips hue bulbs separately.

• Only for TVs with Ambilight.

1.7

, you can set up your

(includes a hue bridge and 3 hue bulbs)

Philips hue

lamps to

Skype

Operate your TV from your smartphone or tablet, switch channels or change the volume. With the MyRemote app, you can use your phone or tablet to send photos, music or videos from your computer to your TV. And with MyRemote app on a tablet, you can call up the TV guide, read about the programmes and switch the TV to a channel with a simple tap of your finger. The MyRemote app is available for iOS and Android.

, press 

Help

more information.

1.9

Keywords

and look up

MyRemote app

for

Pause TV and recordings

If you connect a broadcast from a digital TV channel.

USB Hard Drive

, you can pause and record a

With

Skype™

You can call and see your friends from anywhere in the world. To make a video call, you need a camera with a built-in microphone and a good connection to the Internet. Some Philips TVs have a camera and microphone built in.

Help

information.

you can make video calls on your TV for free.

, press 

Keywords

and look up

Skype

for more

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can start watching again later. With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.

, press 

Help

Recording

Keywords

for more information.

and look up

Pause TV

1.10

Gaming

If you select your game console in the Home menu, the TV switches to the settings ideal for gaming automatically.

If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen simultaneously. Each player can focus on his own game to play.

The TV uses 3D technology to show both screens. To play a two-player game with two different full screen pictures, you need a pair of 3D glasses for each player.

Two player games

1.11

Help

, press 

Keywords

for more information.

and look up

Game console or

EasyLink

With

EasyLink

Disc player, with the remote control of the TV. EasyLink uses HDMI CEC to communicate with the connected

devices.

you can operate a connected device, like a Bluray

, press 

Help

information.

Keywords

and look up

EasyLink

for more

Setting up

2.1

Read safety

Read the safety instructions first before you use the TV. In Help, go to

2.2

Safety and care

TV stand and wall mounting

TV stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Safety

• For 6800 series 50-inch TV VESA MIS-F 400x200, M6

• For 6800 series 40-inch TV VESA MIS-F 200x100, M6

• For 6700 series 40-inch/48-inch TV VESA MIS-F 400x200, M6

• For 6600 series 55-inch/65-inch TV VESA MIS-F 400x400, M6

• For 6600 series 40-inch/48-inch TV VESA MIS-F 400x200, M6

• For 6500 series 55-inch TV VESA MIS-F 400x400, M6

• For 6500 series 32-inch/42-inch/47-inch TV VESA MIS-F 400x200, M6

• For 6400 series 55-inch TV VESA MIS-F 400x400, M6

• For 6400 series 40-inch/48-inch TV VESA MIS-F 400x200, M6

Caution

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TV's weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

Wall mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

To fix the bracket securely, use screws with a length indicated in the drawing.

• For 7500 series 42-inch/47-inch/55-inch/65-inch TV VESA MIS-F 400x400, M6

• For 7179/7189/7199 series 42-inch/47-inch/55-inch/65-inch TV VESA MIS-F 400x400, M6

• For 7100 series 42-inch/47-inch TV VESA MIS-F 300x300, M6

• For 7100 series 55-inch TV VESA MIS-F 400x400, M6

• For 6800 series 58-inch TV VESA MIS-F 400x400, M6

2.3

Tips on placement

• Position the TV where light does not shine directly on the screen.

• Dim lighting conditions in the room for best Ambilight effect.*

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

* Ambilight function is only for TVs with Ambilight.

2.4

Power cable

• Insert the power cable into the back of the TV.

• Make sure the power cable is securely inserted in the connector.

POWER

connector on the

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

, press 

Help

information on switching the TV on or off.

2.5

Keywords

and look up Switching on for more

Antenna cable

Insert the antenna plug firmly into the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

2.6

ANTENNA

socket at the

Satellite dish

Attach the satellite F-type connector to the satellite connection

at the back of the TV.

SAT

• Only for TVs with a built-in satellite tuner.

Network

3.1

Wireless network

What you need

To connect the TV wirelessly to the Internet, you need a wireless router. Use a high-speed (broadband) connection to the Internet.

Network devices

The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.

File sharing

On this TV, you can open photos, music and videos stored on your computer. Use a recent version of media server software like Philips MediaManager*, Windows Media Player 11, Twonky™ or similar.

Install the media server software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. This software must be running on your computer to view or play your files on TV. * You can download the Philips MediaManager software from the Philips support site www.philips.com/support

Make the connection

Follow steps 1 to 5.

- Make sure that the router of your wireless network is

Step 1

switched on.

- Press and select

Step 2

- Select

Step 3

- Select

Step 4

- Select

Step 5

- Select

Step 6

have a router with WPS (Wi-Fi Protected Setup), you can select

. Select your choice and press OK.

WPS

Connect to network

Connect

Wireless Scan

and press OK.

to scan for your wireless network. If you

and press OK.

Setup

and press OK.

•

Scan

Select router). The TV might find several wireless networks in your proximity.

•

WPS

If your router has WPS, you can directly connect to the router without scanning. Go to the router, press the WPS button and return to the TV within 2 minutes. Then press the connection. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS. If you must use the instead of WPS.

Step 7

network and press OK. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select

Step 8

your encryption key (WEP, WPA or WPA2). If you entered the encryption key for this network before, you can select make the connection immediately. If your router supports WPS or WPS PIN, you select

WPS PIN

•

Standard

Select passphrase or security key) manually.You can use the keyboard on the RC to enter the encryption key. Once you have entered the key, press

•

WPS PIN

To make a secured WPS connection with a PIN code, select

WPS PIN

shown and enter it in the router software on your PC. Return to the TV and press to enter the PIN code in the router software.

Step 9

successful.

Network configuration

If the connection fails, you can check the DHCP setting of the router. DHCP should be set to On. Alternatively, if you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP. To set the TV to Static IP, press and select

OK configuration

you can set the IP address and other necessary settings in

IP configuration

to scan for your wireless network (your wireless

Scan

Connect

WPS PIN code

- In the list of networks found, select your wireless

Manual entry

- Depending on the type of router, you can now enter

Standard

and press OK. Write down the 8-digit PIN code

- A message will be shown when the connection is

to enter the network name yourself.

Standard

Connect

. Select your choice and press OK.

to enter the encryption key (password,

Connect

. Consult the router manual on where

to connect, select

Scan

WPS

and press

Setup

. Select

Network settings

Static IP

in the same menu.

Network settings

. With Static IP selected in the menu,

Network

to make

Static

Network problems

Connect the router

Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi 802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

3.2

Wired network

What you need

To connect and setup the router follow steps 1 to 5. 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on. 3 - Press and select 4 - Select 5 - Select

The TV constantly searches for the network connection. A message will be shown when the connection is successful.

Network configuration

If the connection fails, you can check the DHCP setting of the router. DHCP should be set to On. Alternatively, if you are an advanced user and want to install your network with static IP addressing, set the TV to Static IP. To set the TV to Static IP, press and select press OK. Select

configuration

you can set the IP address and other necessary settings in

IP configuration

**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

Connect to network

and press OK.

Wired

Network settings

Static IP

in the same menu.

and press OK.

Setup

and press OK.

and

Setup

Network settings

. With Static IP selected in the menu,

Network

Static

You need a network Use a router with a high-speed (broadband) connection to the Internet.

File sharing

On this TV, you can open photos, music and videos stored on your computer. Use a recent version of media server software like Philips MediaManager*, Windows Media Player 11, Twonky™ or similar. Install the media server software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. This software must be running on your computer to view or play your files on TV. * You can download the Philips MediaManager software from the Philips support site www.philips.com/support

Help

software, supported

software.

, press



Keywords

to connect the TV to the Internet.

router

and look up

for an overview of supported media server

Media server

3.3

Network settings

To open the Network settings . . .

1 - Press and select 2 - Select

•

View network settings

All current network settings are shown here. The IP and MAC address, signal strength, speed, encryption method, etc.

•

Network settings

- Network type

Sets the network to Wired or Wireless.

- Network configuration

Sets the network configuration to DHCP or Static IP.

•

Wi-Fi media playback

To receive multimedia files from smartphones or tablets, set the DMR to On.

•

Static IP configuration

If Static IP is selected in Network Settings menu, you can set all necessary static IP settings here.

•

Wi-Fi Miracast

Network settings

and press OK.

Setup

and press OK.

For more information on Wi-Fi Miracast, press



Keywords

•

Reset Wi-Fi direct group

and look up

Wi-Fi Miracast™

Clear the list of connected and blocked devices that are used with Miracast.

•

Wi-Fi smart screen

For more information on Wi-Fi smart screen, press



Keywords

screen

•

MyRemote recording

and look up

MyRemote App, Wi-Fi smart

Manage TV recordings remotely with a smartphone or tablet..

•

TV network name

If you have more than one TV in your network, you can rename the TVs here.

•

Netflix Settings

Adjust Netflix settings.

•

Clear Internet memory

With Clear Internet memory, you can clear all Internet files stored on your TV. You clear your Philips Smart TV registration and parental rating settings, your video store app logins, all Smart TV app favourites, Internet bookmarks and history. Interactive MHEG applications can also save so-called 'cookies', on your TV. These files will also be cleared.

Connections

4.1

Tips on connections

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device. For more information on using EasyLink, press and look up

EasyLink CEC



Keywords

Connectivity guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to

www.connectivityguide.philips.com

Antenna

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

DVI to HDMI

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to AUDIO IN for sound, on the back of the TV.

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

All of the HDMI connections on the TV have HDMI ARC (Audio Return Channel). If the device, typically a Home Theatre Sysytem (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals. You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.

HDMI

HDMI CEC

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) or Ultra HD (UHD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

EasyLink HDMI CEC

In case you prefer to switch off ARC on the HDMI connections, press and select Select

TV settings

HDMI Ultra HD

You can watch videos filmed or made in 'native' Ultra HD resolution - 3840x2160 pixels - on this TV.

Connect a blu-ray Disc player, game console or computer that plays Ultra HD videos to an speed HDMI cable to connect. The HDMI UHD connection can have ARC (Audio Return Channel) and does not support 3D.

• Only for TVs have an Ultra HD display.

Setup

Sound

and press OK.

Advanced

connection. Use a High

HDMI

HDMI ARC

Y Pb Pr - Audio L R

Y Pb Pr - Component Video is a high quality connection. The YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

• Only for TVs with component connectors.

CVBS - Audio L R

Audio Out - Optical

Audio Out - Optical is a high quality sound connection. This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

CVBS - Composite Video is a high quality connection. The CVBS connection can be used for High Definition (HD) TV signals. Next to the CVBS signal adds the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

• Only for TVs with component/composite connectors.

Scart

SCART is a good quality connection. The SCART connection can be used for CVBS and RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals.

Use the SCART adapter cable to connect your device.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. For more information, press

Out settings

If the sound does not match the video on screen, you can adjust the audio to video synchronisation. For more information, press

to video sync

4.2



Keywords



Keywords

and look up

Audio

EasyLink HDMI CEC

EasyLink

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

1 - Press and select 2 - Select

OK.

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink remote control separately. In the EasyLink settings menu, select and select

TV settings

and press OK.

Off

and press OK.

Setup

General settings

EasyLink, and press

EasyLink remote control

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their respective owners.

Operate devices

To operate a device connected to HDMI and set up with EasyLink, select the device - or its activity - in the list of TV connections. Press an HDMI connection and press OK.



SOURCES

, select a device connected to

Pixel Plus Link

Some devices, a DVD or Blu-ray Disc player, might have their own picture quality processing. To avoid bad picture quality caused by interference with the TV processing, the picture processing of these devices should be disabled. The TV comes with Pixel Plus Link switched on and disables the picture quality processing of recent Philips devices connected to the TV. To switch off Pixel Plus Link, in the EasyLink settings menu, select

Pixel Plus Link

Auto subtitle shift

If you play a DVD or Blu-ray Disc on a Philips disc player that supports subtitles, the TV can move the subtitles upwards. Subtitles will be visible whatever Picture format you select. The TV comes with Auto subtitle shift switched on. To switch off Auto subtitle shift, in the EasyLink settings menu, select

Auto subtitle shift

Auto switch off devices

You can set the TV to switch off the connecting HDMI-CEC compliant devices if they are not the active source. The TV switches the connected device to standby after 10 minutes of inactivity.

and select

Off

Once the device is selected, the TV remote control can control the device. However and  other TV keys are not forwarded to the device. If the key you need is not on the TV remote control, you can select the key in the Options menu. Press  the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

Note: Only devices that support function will respond to the TV remote control.

OPTIONS

and select

OPTIONS

Controls

EasyLink remote control

keys and some

in the menu bar. On

EasyLink settings

The TV comes with all EasyLink settings switched on. You can switch off any EasyLink setting independently.

EasyLink

To switch off EasyLink completely . . .

4.3

Common interface - CAM

CI+

This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes, like movies

and sports, offered by digital TV broadcasters in your region. These programmes are scrambled by the TV broadcaster and descrambled with a prepaid CI+ module. Digital TV broadcasters provide this CI+ module (Conditional Access Module - CAM) when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV broadcaster for more information on terms & conditions.

For more information on connecting a CAM module, press



Keywords

CAM

and look up

Common Interface CAM

connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Set-top box has no HDMI connection.

Insert a CAM module

Switch off the TV before inserting a CAM. Look on the CAM for the correct method of insertion. Incorrect insertion can damage the CAM and TV.

Use the Common Interface slot on the TV to insert the CAM card. With the front of the card facing towards you, gently insert the CAM as far as it will go. Leave the card in the slot permanently.

It may take a few minutes before the CAM is activated. Removing the CAM will deactivate the broadcast service on TV. If a CAM is inserted and subscription fees are paid, (connection methods can differ), you can watch the TV broadcast. The inserted CAM is exclusively for your TV.

CAM settings

Switch off timer Switch off this automatic timer, if you only use the remote

control of the Set-top box. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

To switch off the Switch off timer, press and select press OK. Select

TV settings

set the slider bar to

4.5

General settings

Off

Switch off timer

Setup

and

Satellite receiver

• Only for TVs with a built-in satellite tuner. Connect the dish antenna cable to the Satellite receiver.

and

To set passwords or PIN codes for the CAM TV broadcast, press and select Select

Channel settings

Select the CAM TV broadcaster and press OK.

4.4

and press OK.

Setup

Common Interface

Set-top box - STB

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to

Next to the antenna connection, add an HDMI cable to connect the device to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.

Switch off timer

Audio to video synchronisation (sync)

Switch off this automatic timer, if you only use the remote control of the Set-top box. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

To switch off the Switch off timer, press and select press OK. Select

TV settings

set the slider bar to

4.6

General settings

Off

Switch off timer

Setup

and

Home Theatre System - HTS

Connect HTS

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player. Alternatively, you can use a SCART cable if the device has no HDMI connection.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, press

to video sync



Keywords

and look up

Audio

Audio Out settings

Audio Out delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is done automatically synchronised and always correct.

Audio sync delay

For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio out delay on the TV.

To switch off the Audio Out delay . . .

1 - Press and select 2 - Select 3 - Select 4 - Press , repeatedly if necessary, to close the menu.

TV settings

and press OK.

Off

Setup

and press OK.

Sound

Advanced

Audio out delay

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.

Audio Out offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms. The Audio Out delay setting should be switched on.

To synchronise the sound on the TV . . .

1 - Press and select 2 - Select 3 - Use the slider bar to set the sound offset and press OK. 4 - Press , repeatedly if necessary, to close the menu.

Audio Out format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio out format to

TV settings

Setup

Sound

and press OK.

Advanced

Audio out offset

Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

To set the Audio out format . . .

4.7

Blu-ray Disc player

Use a

High speed HDMI

player to the TV.

cable to connect the Blu-ray Disc

1 - Press and select 2 - Select

format

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

Audio Out levelling

Use the Audio Out levelling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume . . .

1 - Press and select 2 - Select

levelling

3 - If the volume difference is large, select difference is small, select 4 - Press , repeatedly if necessary, to close the menu.

Audio Out levelling affects both the Audio Out - Optical and HDMI ARC sound signals.

TV settings

Multichannel

TV settings

Setup

Sound

Stereo

Sound

Less

and press OK.

Advanced

and press OK.

Advanced

Audio out

. If the volume

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

For more information on EasyLink, press up

EasyLink HDMI CEC

4.8



Keywords

and look

DVD player

Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable, if the device has no HDMI connection.

Problems with HTS sound

Setup

Stereo

TV settings

setting on the TV is switched On.

TV settings

Sound

HDMI ARC

Audio

Advanced

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the

out format

Press and select

Audio out format

No sound

If you cannot hear the sound from the TV on your Home Theatre System, check the following . . .

• Check if you connected the HDMI cable to an connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections.

• Check if the Press and select

HDMI ARC

of the TV to

HDMI ARC

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

For more information on EasyLink, press look up

4.9

EasyLink HDMI CEC



Keywords

and

Game console

HDMI

CVBS - Audio L R

For best quality, connect the game console with an High speed HDMI cable to the TV

Y Pb Pr - Audio L R

Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.

Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

4.10

USB Hard Drive

What you need

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

CVBS - Audio L R / Scart

Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.

If your game console only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter to connect to the SCART connection.

Note: the CVBS to SCART Adapter is not provided in the TV set.

To pause

To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 32GB disk space.

To record

To pause and record a broadcast, you need a minimum of 250GB disk space.

TV guide

Before you decide to buy a USB Hard Drive to record, you can check if it is possible to record digital TV channels in your country. Press button on the TV guide page, you can record.

For more information on how to install a USB Hard Drive, press





TV GUIDE

Keywords

on the remote control. If there is a Record

and look up

USB Hard Drive, installation

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel, press

(Pause). Trying to pause will start the formatting. Follow the instructions on screen. When the USB Hard Drive is formatted, leave it connected

permanently.

Recording



Keywords

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

For more information, press

USB

and look up



Pause

Install the keyboard

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard lay-out first, you can select a secondary Latin keyboard lay-out.

To change the keyboard lay-out setting when a lay-out was selected…

1 - Press and select 2 - Select

settings Keys for channel renaming

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard lay-outs, if a secondary lay-out is set, press the

Keys for Smart TV Apps and Internet pages

• Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width.

TV settings

and press OK.

Setup

Ctrl + Shift

connections on the TV. When

USB

and press OK.

General settings

keys simultaneously.

USB keyboard

USB mouse

Connect USB mouse

You can connect a USB mouse (USB-HID type) to navigate pages on the Internet.

4.11

USB keyboard or mouse

USB keyboard

Connect a USB keyboard (USB-HID type) to enter text on your TV.

You can connect a keyboard and a mouse to the TV. Use one of the

connections to connect.

USB

On an Internet page, you can select and click on links more easily.

Back



Connect the mouse

Switch the TV on and connect the USB mouse to one of the

connections on the TV. You can also connect the USB

USB

mouse to a connected USB keyboard.

Mouse clicks

• Left click =

• Right click =

You can use the scroll wheel to scroll pages up and down. For more information on how to connect a keyboard,

press



Keywords

Mouse speed

You can adjust the speed of the mouse moving on screen.

and look up

USB keyboard

To adjust the speed . . .

1 - Press and select 2 - Select 3 - Select

press OK. 4 - Press the arrows  (up) or  (down) to increase or lower the speed.

5 - Press OK to store and close the setting. 6 - Press , repeatedly if necessary, to close the menu.

4.12

TV settings General settings

and press OK.

Setup

and press OK.

Pointer / Mouse settings

and

USB flash drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the TV while the TV is switched on.

connections on the

USB

If the contents list does not appear automatically, press

SOURCE

Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

For more information on viewing photos, press

Keywords

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher. You cannot play a native Ultra HD video on any of the USB connections.

4.14

, select

and look up

and press OK.

USB

Your photos, videos and music





Camcorder

HDMI

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press

SOURCE

To stop watching the USB flash drive content, press select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

For more information on watching or playing content from a USB flash drive, press

videos and music

4.13

, select

and press OK.

USB



Keywords

and look up





EXIT

Your photos,

Photo camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the on the camera after you made the connection.

connections on the TV to connect. Switch

USB

For best quality, use an HDMI cable to connect the camcorder to the TV.

CVBS - Audio L R / Scart

You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter to connect to the SCART connection.

Note: the CVBS to Scart Adaptor is not provided in the TV set.

CVBS - Audio L R

Use a Video Audio L/R cable to connect the camcorder to the TV.

the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Settings

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

4.15

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

Ideal monitor setting

If your computer is added as a Computer type of device in the Source menu (the list of connections), the TV is set to the ideal Computer setting automatically.

If you use your computer to watch movies or use it to play games, you might want to set the TV back to the ideal TV watching or gaming setting.

To set the TV to the ideal setting manually . . .

1 - Press and select 2 - Select

style

3 - Select a movie) and press OK. 4 - Press , repeatedly if necessary, to close the menu.

Remember to set the Game or computer setting back to

4.16

TV settings

and press OK.

Game

Computer

when you stop playing the game.

and press

Setup

(for gaming) or select


Advanced

OK.

Computer

Activity

(for watching

Headphones

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter to connect

You can connect a set of headphones to the  connection on the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

To adjust the volume . . .

1 - Press and select 2 - Select

press OK.

3 - Press  (up) or  (down) to adjust the volume. 4 - Press , repeatedly if necessay, to close the menu.

TV settings > Sound

Setup

and press

OK.

Headphones volume

and

4.17

Wireless speakers (For 7500 series TV)

You can connect a wireless speaker - a subwoofer or a sound bar - to this TV. A range of selected Philips wireless speaker products can connect and play the TV sound. Consult

www.philips.com/tv

To play the TV sound on a wireless speaker, you must pair the wireless speaker with the TV. You can pair up to 10 wireless speakers but you can only use 1 speaker system - a subwoofer or a sound bar - at a time.

To pair a wireless speaker with the TV… 1 - Switch on the wireless speaker and place it within range of

the TV. Read the user manual of the device for specific information on pairing and wireless range. 2 - The wireless speak blue LED indicator button will brink rapidly to indicate that it is ready to be paired by the TV.

3 - On the TV, press , select 4 - Select 5 - Select 6 - Follow the instuctions on screen. You will pair the device

with the TV and the TV will store the connection. 7 - At any time to re-pair the TV with the wireless speaker, press and hold for 3 second the blue LED indicator button on the wireless speaker, and repeat step 3 to 6.

TV settings Wireless speaker

Sound

and press OK.

Setup

Sound output

Add new speaker

and press OK.

For more information on switching the TV sound to the wireless speaker, press

select



Keywords

and look up

Wireless speakers,

Switch on

5.1

On or Standby

Make sure you plugged in the mains power on the back of the TV before you switch on the TV. If the red indicator light is off, press the Joystick on the right side or on the back of the TV to put the TV in standby - the red indicator will light up.

• Press the Joystick to confirm a selection or setting.

5.3

Word mark brightness

You can switch off or adjust the word mark lighting. To adjust or switch off…

With the TV in standby, press  onon the remote control to switch the TV on.

Switch to standby

To switch the TV to standby, press  on the remote control.

Switch Off

To switch the TV Off, press the Joystick on the right or on the back. The red indicator light is off. The TV is still connected to the mains power but consumes a minimum of energy. To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

1 - Press and select 2 - Select

brightness

3 - Select off the lighting of the word mark. 4 - Press , repeatedly if necessary, to close the menu.

• Only available for certain TV models

TV settings

and press OK.

Maximum, Medium, Minimum

and press OK.

Setup

General settings

Word mark

or select

to switch

Off

5.2

Keys on TV

While the on-screen display is on, press the Joystick to display the menu.

• Use the arrow/nevigation keys to nevigate up, down, left or right.

Remote control

6.1

Key overview for 7100, 7500 series

Top

- 

Standby

To switch the TV On or back to Standby.

Playback and record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to record now



To select an Ambilight setting.



TV GUIDE

To open or close the TV guide.



Settings

To open the Settings menu.

Ambilight

keys



SMART TV

To open the Smart TV start page.

Colour keys

Follow on screen instructions. Blue key , opens Help.



INFO

To open or close programme info.



BACK

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous Smart TV page.

HOME

To open or close the home menu.



EXIT

To switch back to watching TV.



OPTIONS

To open or close the Options menu.

- OK key

To confirm a selection or setting.

Arrow / navigation

To navigate up, down, left or right.



To open an extra small screen.

MULTIVIEW

keys



Picture format

To open or close the Picture format menu.



SOURCES

To open or close the Sources menu - the list of connected devices.



To open the Popular searches page.

Middle

Bottom



Volume

To adjust the volume level.

Number keys

To select a TV channel directly or to enter text.

SUBTITLE

and

text keypad

To switch subtitles on, off or Automatic.



LIST

To open or close the channel list.



Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text or start the next or previous chapter on a disc.



Mute

To mute the sound or to restore it.

TEXT

To open or close Text / Teletext.

6.2

Key overview for 6300, 6500, 6600, 6700 series

Top

Middle



SMART TV

To open the Smart TV start page.

Colour keys

Follow on screen instructions. Blue key , opens Help.



INFO

To open or close programme info.



BACK

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous Smart TV page.

- 

Standby

To switch the TV On or back to Standby.

Playback and record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to record now



To select an Ambilight setting.



TV GUIDE

To open or close the TV guide.



Settings

To open the Settings menu.



Picture format

To open or close the Picture format menu.

Ambilight

keys

HOME

To open or close the home menu.



EXIT

To switch back to watching TV.



OPTIONS

To open or close the Options menu.

- OK key

To confirm a selection or setting.

Arrow / navigation

To navigate up, down, left or right.



To open an extra small screen.

MULTIVIEW

keys

Bottom



SOURCES

To open or close the Sources menu - the list of connected devices.



To open the Popular searches page.



Volume

To adjust the volume level.

Number keys

and

text keypad

To select a TV channel directly or to enter text.

SUBTITLE

To switch subtitles on, off or Automatic.



LIST

To open or close the channel list.



Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text or start the next or previous chapter on a disc.



Mute

To mute the sound or to restore it.

TEXT

To open or close Text / Teletext.

6.3

Keyboard

Overview

Qwerty and Cyrillic

Overview of a Qwerty / Cyrillic keyboard.*

Cyrillic characters

Characters available when the keyboard is switched to Cyrillic.

- 

Cyrillic keyboard switch

To switch the keyboard to the Cyrillic characters or back to Qwerty.



Shift

To type uppercase characters.

Ω Special characters

To open the onscreen keyboard to select accented characters or symbols.

- Fn key

To type a number or punctuation character



Spacebar

- 

Share this

To share online what you are watching at the moment.

Navigation

and

Qwerty and Azerty

Overview of a Qwerty / Azerty keyboard.*

Qwerty / Azerty character

Character position if the keyboard layout is set to Azerty.



Shift

To type uppercase characters.

Ω Special characters

To open the onscreen keyboard to select accented characters or symbols.

- Fn key

To type a number or punctuation character.



Spacebar

Navigation

and

* Your remote control has a Qwerty / Azerty or a Qwerty / Cyrillic keyboard, depending on your region.

Writing text

With the keyboard on the back of the remote control, you can write text in any text field on screen. Turn the keyboard facing upwards to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs.

Enter text

• To enter text in a text field on screen, select the text field and start typing. Press OK to confirm the text.

Backspace



7 To delete the character in front of the text cursor.

- 

Share this

To share online what you are watching at the moment.

Uppercase and lowercase

• To type an uppercase character, press the  (Shift) key just before you type the character.

• To type several uppercase characters consecutively, press and hold the  key while typing.

• To type uppercase constantly, press the  key for 2 seconds

to switch the keyboard in uppercase mode.

• To switch out of uppercase mode, press the  key again. If no keys are pressed for 20 seconds, the uppercase mode switches off automatically. Also, if you press another modifier key, like Fn or Ω, you switch out of uppercase mode.

Numbers and punctuation characters

• To type a number or punctuation character, press the Fn key just before you type the number or punctuation character you need. You can switch the Fn mode on or off as you do for the uppercase mode.

Internet

• You can use the Fn key to enter

www.

.com

Accented letters and symbols

Qwerty and Azerty keyboard

The standard layout of the remote control keyboard is Qwerty.

Azerty keyboard

Depending on your region, the remote control keyboard can be set to Azerty. The Azerty characters are shown at the top right of the relevant keys. To set the keyboard layout to Azerty, . . .

- Press and select

- Select

2 keyboard

- Select

6.4

TV settings

Azerty

and press OK.

Setup

General settings

Qwerty

Remote control

Pointer (For 7500 series TV)

Accented characters and symbols are not directly available on the remote control keyboard. To type such a character, you can open the onscreen keyboard.

To open the onscreen keyboard, press Ω. In the onscreen keyboard, you can navigate to the character you need. Switch the keyboard layout with the colour keys. Press OK to enter a character. The onscreen keyboard disappears when you press a character on the remote control keyboard.

Alternatively, you can enter special characters with the remote control SMS/text keypad on the front of the remote control.

Qwerty, Azerty and Cyrillic keyboard

The standard layout of the remote control keyboard is Qwerty.

Azerty keyboard

Depending on your region, the remote control keyboard can be set to Azerty. The Azerty characters are shown at the top right of the relevant keys. To set the keyboard layout to Azerty, . . .

- Press and select

menu.

- Select

2 keyboard

- Select

Cyrillic keyboard

Depending on your region, the remote control keyboard can be switched to Cyrillic characters. The Cyrillic characters are shown at the top right of the keyboard keys. To write Cyrillic characters . . .

- Press  on the remote control.

- Press  again to switch back to Qwerty.

TV settings

Azerty

and press OK to open the Setup

Setup

General settings

Qwerty

Remote control

About pointer

Instead of navigating the screen with the arrow keys, you can use the pointer. You can move the pointer — a blue arrow — over the TV screen by moving the remote control. Just like you move the cursor on a computer screen with a mouse.

You can use the pointer to navigate

Internet pages

the use of the pointer. When the pointer is not available, you can use the arrow keys to navigate the screen. You can adjust the speed of the pointer or if you never want to use the pointer, you can switch it off.

* Gradually more Smart TV Apps will come available for use with the pointer.

on TV. Some Smart TV Apps might not support

Smart TV Apps*

and

Using the pointer

When you open the Smart TV start page, the pointer is shown in the middle of the screen.

Put your thumb on the OK key — do not press it — and move the remote control from the wrist, no need to move your arm. You can let go of the OK key and leave the pointer where it is. You can move the remote control and pick up the pointer again when you put your thumb on the OK key.

When you press an arrow key to navigate, the pointer disappears. To recall the pointer, put your thumb on the OK key and briefly jiggle the remote control.

When you hover the pointer over a link . . .

1 - The pointer lights up. 2 - Press OK to open the link.

When you hover the pointer over a text field . . . Press OK to enter text.

However, the TV can also receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

6.6

IR sensor for non-RF remote

Pointer speed

You can adjust the speed of the pointer, the speed at which the pointer moves on screen.

To adjust the speed . . .

1 - Press and select 2 - Select 3 - Select

press OK. 4 - Press the arrows  (up) or  (down) to increase or lower the speed.

5 - Press the arrow  (right) to test the speed you set. 6 - Press the arrow  (left) to return to the setting. You can

adjust the setting again.

7 - Press OK to store and close the setting. 8 - Press , repeatedly if necessary, to close the menu.

TV settings General settings

and press OK.

Setup

and press OK.

Pointer and mouse speed

and

Switch off

If you want to navigate the Smart TV and Internet pages with the arrow keys only, you can switch off the pointer.

To switch off the pointer . . .

1 - Press and select 2 - Select 3 - Select

select 4 - Press , repeatedly if necessary, to close the menu.

TV settings General settings

Off

and press OK.

Setup

and press OK.

Remote control pointer

and

control

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

6.7

Pairing with TV

* Only for 7100, 7500 series TV This remote control uses radio frequency (RF) to send its

commands to the TV. Contrary to remote controls using infrared signals, with this remote control you can send commands without pointing at the TV.

The TV will notify you when the battery power of the remote control is low.

Pairing the remote control

6.5

IR sensor for RF remote control

The remote control of the TV uses RF (radio frequency) to send its commands to the TV. With RF, you do not need to point the remote control at the TV.

For the remote control to communicate with the TV, both TV and remote control should be paired with each other. Once paired, you cannot use the remote control to control another TV. When you started the initial TV installation, the TV invited you to press the OK key, and by doing so, the pairing was done. When you switch off the TV, the pairing is stored. You can pair up to 5 remote controls with this TV.

Pairing again

You can pair another remote control with this TV. The method to pair a remote control is different for a remote control already paired with another TV compared with a remote control that is not paired yet.

•

The remote control is paired with another TV

To pair, hold the remote control close to the Philips logo (about 10cm) and press the  Red and  Blue key at the same time. A message will appear if pairing is successful.

•

The remote control is not paired yet

To pair, hold the remote control close to the Philips logo (about 10cm) and press OK. A message will appear if pairing is successful.

For retail

To pair a new — not yet paired — TV with a remote control which is already paired with another TV, hold the remote control close to the Philips logo (about 10cm) and press the

Red and  Blue key at the same time. A message will



appear if pairing is successful. Note:

If the remote control is still fail to pair the TV, press > Setup > TV settings > General settings > Reinstall TV, then repeat pairing step again.

With click door

The TV will notify you when the battery power of the remote control is low.

To replace the batteries, open the battery compartment on the keyboard side of the remote control.

1 - Use a small coin or other small, blunt object and press the square shaped release button to open the battery lid. 2 - Slide the blue lock open in the direction shown by the arrow and lift the lock. 3 - Replace the old batteries with 2 type batteries. Make sure the + and the - ends of the batteries line up correctly.

4 - Push the blue lock down and slide it back until it clicks. 5 - Reposition the battery door and push it down until it clicks.

Put the remote control down for about 15 seconds to calibrate the pointer.

AA-LR6-1.5V

alkaline

6.8

Batteries

With sliding door

If the TV does not react on a key press on the remote control, the batteries might be empty.

To replace the batteries, open the battery compartment on the keyboard side of the remote control.

1 - Slide the battery door in the direction shown by the arrow. 2 - Replace the old batteries with 2 type

alkaline batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and slide it back until it clicks.

AAA-LR03-1.5V

Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

For more information, press

use

6.9



Keywords

and look up

End of

Cleaning

Your remote control is treated with a scratch-resistant coating. To clean the remote control, use a soft damp cloth. Never use

substances such as alcohol, chemicals or household cleaners on the remote control.

Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

For more information, press

use



Keywords

and look up

End of

Channel list

TV channels

7.1

Watching TV channels

Switch channels

To watch TV channels, press . The TV tunes to the TV channel you last watched.

Alternatively, press to open the Home menu and select

Watch TV

To switch channels, press  + or  -. If you know the channel number, type in the number with the number keys. Press after you entered the number to switch channels.

To switch back to the previously tuned channel, press .

To switch to a channel from a channel list

While watching a TV channel, press channel lists.

and press OK.



to open the

LIST

Favourite channels

You can create a favourite channel list that only holds the channels you want to watch. With the Favourite channel list selected, you will only see your favourite channels when you switch through channels.

Create your favourite channel list

1 - While watching a TV channel, press channel list.

2 - Select All to view all channels. 3 - Select the channel, and press  to mark as favourite. 4 - The selected channel is marked with a . 5 - To finish, press . The channels are added to the Favourites

list. To remove a channel from the favourites list, select the channel

with , then press  again to unmark as favourite.

Reorder

You can reorder — reposition — channels in the Favourite channel list.

1 - In the channel list to reposition.

2 - Press . 3 - Select the channel to reorder and press OK. 4 - Press the

channel to another location and press OK. 5 - Once complete, press  channel list.

You can highlight another channel and do the same.

Favourites

Navigation buttons



, highlight the channel you want

to move the highlighted

to exit from the Favourite

EXIT

to open the

LIST

The channel list can have several pages with channels. To view the next or previous page, press To close the channel lists without switching channels, press

LIST

again.



Radio channels

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel.



Channel list views

In the channel lists, you can find all installed TV and radio channels.

Next to the channel list you can set up a list of installed channels in

Channel logos

In some countries, the TV can show the channel logos. If you do not want these logos to appear, you can switch them off. To switch off Channel logos . . .

1 - Press and select 2 - Select

press OK.

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

stations separately or discover the newly added

Radio

New

TV settings

and press OK.

Off

, which holds all installed channels,

All

Favourites

Setup

General settings

, view the

and press OK.

Channel logos

and

Rename channels

You can rename channels in the channel list. 1 - Select the channel you want to rename in one of the channel

lists.

2 - Select the channel to rename. 3 - Press .

You can enter text with the remote control keyboard or open the on-screen keyboard.

With the on-screen keyboard

• To open the on-screen keyboard, place the cursor in the name text field and press OK.

• To delete the character in front of the cursor, press

Backspace

• To enter a character, select the character with the arrow keys and press OK.

• To select uppercase characters, press .

• To select numbers or special characters, press .

• When you are ready, press  to close the on-screen keyboard.

• To finish renaming, select

With the remote control keyboard*

• To delete a character, position the cursor behind the character and press .

• To enter a character, press the character on the keyboard.

• When you are ready, press OK to select Press OK again to finish renaming.

For more information on using the keyboard, press * Only for the remote control with keyboard

Lock a channel

To prevent children from watching a channel or a programme, you can lock channels or lock age rated programmes.

Lock a channel

You can lock a channel to prevent children from watching it. To watch a locked channel you need to enter the Child lock code. You cannot lock programmes from connected devices.



Keywords

and look up

and press OK.

Done

Remote control, keyboard



Some digital broadcasters have age rated their programmes. When the age rating of a programme is equal to or higher than the age you have set as age rating for your child, the programme will be locked. To watch a locked programme you must enter the child lock code. The parental age rating is set for all channels.

To set an age rating . . .

1 - Press and select 2 - Select

press 3 - Enter a 4-digit Child lock code and confirm. Now you can set an age rating.

4 - Set the age and press OK. 5 - Press , repeatedly if necessary, to close the menu.

To switch off the parental age rating, select The TV will ask for the code to unlock the programme. For

some broadcasters / operators, the TV only locks programmes with a higher rating.

Set or change the lock code

To set the lock code or to change the current code . . .

1 - Press and select 2 - Select

press OK. 3 - If a code is set already, enter the current Child lock code and then enter the new code twice.

The new code is set. Forgotten your code? If you have forgotten your code to unlock, call Consumer Care

in your country. Find the telephone number on the documentation that came with the TV or go to

www.philips.com/support

Channel settings

OK.

Channel settings

and press OK.

Setup

Child lock

and press OK.

Setup

Child lock

Parental rating

as age setting.

None

Change code

and

Options for channels

While watching a channel, depending on the type of channel (analogue or digital) you are watching or depending on the TV settings you made, some options are available.

To lock a channel . . . 1 - While watching a TV channel, press





OPTIONS

and select Unlock channel. You will need

and select

Channel list

2 - In any list, select the channel you want to lock. 3 - Press

list, a locked channel is marked with a lock . To unlock a channel, select the locked channel in the channel list.

Press to enter the Child lock code.

Parental rating

To prevent children from watching a programme not suitable for their age, you can use an age rating.



Lock channel

to open the

LIST

. In a channel

Open the options menu

While watching a channel, press

Universal access



OPTIONS

With Universal access switched on, you can set some options for hearing impaired and visually impaired people. For more information, press

Universal access

Video selection

Digital TV channels can offer multi video signals (multi-feed broadcast), different camera viewpoints or angles of the same event or different programmes on one TV channel. The TV shows a message if any such TV channels are available.



Keywords

and look up

Picture format

If black bars appear on top and bottom or on both sides of the picture, you can adjust the picture format to a format that fills the screen.

To change the picture format . . . 1 - While watching a TV channel, press  to open the

menu.

format

2 - Select a format from the list and press OK.


Subtitles

Switch

Automatic



Subtitle language

For digital broadcast, you can select an available subtitle language temporarily if none of your preferred languages are available. For more information, press

Subtitles

Audio languages

For digital broadcast, you can select an available audio language temporarily if none of your preferred languages are available. For more information, press

languages

Dual I-II

If an audio signal contains two audio languages but one language — or both — has no language indication, this option is available.

Common interface

If prepaid premium content is available from a CAM, you can set the provider settings with this option.

Subtitles on

Subtitles off

to show subtitles only when the sound is muted with

with this options. Select



Keywords

and look up



Keywords

and look up

Audio

The following format can be available according the picture on screen . . .

•

Basic

- Fill screen

- Fit to screen

•

Advanced

- Last setting

- Shift

- Zoom

- Stretch

- Native

- Undo

Text / Teletext

Text pages

To open Text (Teletext) while you are watching TV channels, press To close Text, press TEXT again.

TEXT

HbbTV on this channel

You can block the HbbTV pages from a channel that offers HbbTV. For more information, press

MHP applications

Enable or disable the MHP applications. For more information, press

Status

Select analogue or digital) or a connected device you are watching.

Enables the user to communicate his activity with his social networks (such as Twitter, facebook or email).

to view technical information on the channel (if it is

Status



Keywords

and look up

HbbTV



Keywords

and look up

MHP

Select a Text page

To select a page . . .

1 - Enter the page number with the number keys. 2 - Use the arrow keys to navigate. 3 - Press a colour key to select a colour-coded subject at the

bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The subpage numbers are shown on a bar next to the main page number. To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text. To open T.O.P. Text pages within Text, press



OPTIONS

and select

T.O.P. overview

4 - Press , repeatedly if necessary, to close the menu.

Audio languages

Text options

In Text, press

•

Freeze page

To stop the automatic rotation of subpages.

•

Dual screen / Full screen

To show the TV channel and Text alongside each other.

•

T.O.P. overview

To open T.O.P. Text.

•

Enlarge

To enlarge the Text page for comfortable reading.

•

Reveal

To unhide hidden information on a page.

•

Cycle subpages

To cycle subpages when these are available

•

Language

To switch the group of characters that Text uses to display correctly.

•

Text 2.5

To activate the Text 2.5 for more colours and better graphics.

Text setup

Text language

Some digital TV broadcasters have several Text languages available. To set your primary and secondary Text language . . .



OPTIONS

to select the following . . .

If the TV channel broadcasts multiple or dual audio languages, you can select your preferred audio language.

1 - While you watch TV, press 2 - For digital channels, select

channels, select selection. 3 - Select from the available languages, then press OK.

Note:

If you have selected select between:

•

: Primary audio language or

Main

•

: Secondary audio language

SAP

Alternate audio



OPTIONS

Audio language

. Press OK to confirm your

for analogue channels,

. For analogue

Subtitles and languages

Subtitles

Switch subtitles on

To open the Subtitle menu, press You can set subtitles to On, To show subtitles when the broadcasted programme is not in your language — the language you set for the TV, select

Automatic

the sound with . For analogue channels, subtitles must be made available in

. Also, this setting will show subtitles when you mute

Text

Off

SUBTITLE

Automatic

1 - Press and select 2 - Select 3 - Select 4 - Select your preferred Text languages. 5 - Press , repeatedly if necessary, to close the menu.

Text 2.5

If available, Text 2.5 offers more colours and better graphics. Text 2.5 is activated as a standard factory setting. To switch off Text 2.5 . . .

1 - Press 2 - While watching the teletext, press  3 - Select 4 - Press , repeatedly if necessary, to close the menu.

Menu language

To change the language or the TV menus and messages . . .

1 - Press and select 2 - Select

press OK. 3 - Select the language you want and press OK.

Channel settings Primary Teletext

TEXT

Text 2.5

TV settings

and press OK.

Setup

Language

Secondary Teletext

Off

and press OK.

Setup

General settings

OPTIONS

Menu language

and

Subtitles for digital channels

There is no need to set subtitles in Text for digital channels. Digital channels can offer several subtitle languages for a programme. You can set a preferred primary and secondary subtitle language. If subtitles in one of these languages are available, the TV will show them. If none of the preferred subtitle languages are available, you can select another subtitle language which is available.

To set the primary and secondary subtitle language . . .

1 - Press and select 2 - Select

subtitles language OK

Channel settings

and press OK.

Setup

and select

Secondary subtitles language

Languages

Primary

and press

3 - Select a language and press OK. 4 - Press , repeatedly if necessary, to close the menu.

To select a subtitle language when none of your preferred languages are available . . .

1 - Press 2 - Select

temporarily and press OK.

Subtitles for analogue channels

For analogue channels, you need to make the subtitles available for each channel manually.

1 - Switch to a channel and press 2 - Enter the page number for subtitles, usually 3 - Press

If you select On in the Subtitle menu when watching this analogue channel, subtitles will be shown if available. To know if a channel is analogue or digital, switch to the channel and open



OPTIONS

Subtitle language

again, to close Text.

TEXT

in the

Status

and select a language you want

to open Text.

TEXT

888

Options

menu.

Menu language

To change the language or the TV menus and messages . . .

1 - Press and select 2 - Select

press OK.

3 - Select the language you want and press OK. 4 - Press , repeatedly if necessary, to close the menu.

TV settings

and press OK.

Setup

General settings

Menu language

and

Interactive TV

About iTV

With interactive TV, some digital broadcasters combine their normal TV programme with information or entertainment pages. On some pages, you can respond to a programme or vote, do online shopping or pay for a video-on-demand programme.

Audio languages

Digital TV channels can broadcast audio with several spoken languages for a programme. You can set a preferred primary and secondary audio language. If audio in one of these languages is available, the TV will switch to this audio. If none of the preferred audio languages is available, you can select another audio language which is available.

To set the primary and secondary audio language . . .

1 - Press and select 2 - Select

audio language

3 - Select a language and press OK. 4 - Press , repeatedly if necessary, to close the menu.

To select an audio language when none of your preferred audio language is available . . .

1 - Press 2 - Select

temporarily and press OK.

Channel settings

Secondary audio language



OPTIONS

Audio language

and press OK.

Setup

and select

and select an audio language you want

Languages

Primary

and press OK.

HbbTV, MHEG, . . .

Broadcasters use various interactive TV systems : HbbTV (Hybrid Broadcast Broadband TV) or iTV (Interactive TV MHEG). Interactive TV is sometimes referred to as Digital Text or Red button. But each system is distinct.

Visit the broadcaster's Internet website for more information.

What you need

Interactive TV is only available on digital TV channels. To enjoy the full benefits of Interactive TV, you need a high-speed (broadband) Internet connection to the TV.

HbbTV

If a TV channel offers HbbTV pages, you must first switch on HbbTV in the TV settings to view the pages.

1 - Press and select 2 - Select

press OK.

3 - Select On and press OK. 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Setup

and select

and press OK.

General settings

HbbTV

and

Audio languages for the hearing and visually impaired

Some digital TV channels broadcast special audio and subtitles adapted for people who are hearing or visually impaired.

For more information, press 

Universal access.

Keywords

and look up

If you want to avoid access to HbbTV pages on a specific channel, you can block the HbbTV pages for this channel only.

1 - Tune to the channel of which you want to block the HbbTV pages. 2 - Press press OK. 3 - Select

Use iTV

Open iTV pages

Most channels that offer HbbTV or iTV invite you to press the



OPTIONS

and press OK.

Off

and select

HBB TV on this channel

and

key or OK key to open their interactive programme.



Off

Navigate iTV pages

You can use the arrow and colour keys, the number keys and the  key to navigate the iTV pages. You can use the  (Play),  (Pause) and  (Stop) keys to watch videos within iTV pages.

Digital Text (UK only)

To open Digital Text, press

Close iTV pages

Most iTV pages inform you which key to use to close. To force an iTV page to close, switch to the next TV channel and switch back.

About interactive TV

With interactive TV, some digital broadcasters combine their normal TV programme with information or entertainment pages.

Note:

• You cannot download files to your TV with this feature.

• Not all TV programmes, commercials and features include closed captioning information.

• You cannot respond to the digital content. Visit the broadcaster's Internet website for more information.

7.2

. To close, press .

TEXT

Channel installation

Update channels

Automatic update

If you receive digital channels, you can set the TV to automatically update the list with new channels. Alternatively, you can start a channel update yourself.

Automatic channel update

Once a day, at 6 AM, the TV updates the channels and stores new channels. New channels are stored in the All channels list but also in the New channels list. Empty channels are removed. If new channels are found or if channels are updated or removed, a message is shown at TV start up. The TV must be in standby to automatically update channels.

To switch off the message at start up . . .

1 - Press and select 2 - Select 3 - Select

Channel settings Channel installation

and press OK.

Setup

and press OK.

Channel update message

To switch off the Automatic channel update . . .

1 - Press and select 2 - Select 3 - Select

Off Start an update

To start an update yourself . . .

1 - Press and select 2 - Select 3 - Select

screen. The update may take a few minutes. In certain countries, the Automatic channel update is done while

watching TV or any moment when the TV is in standby.

Channel settings Channel installation

and press OK.

Search for channels Update channels

and press OK.

Setup

and press OK.

Automatic channel update

and press OK.

Setup

and press OK.

and follow the instructions on

Reinstall channels

You can search for and reinstall channels and leave all other TV settings untouched. Alternatively, you can do a full new TV installation.

If a child lock code is set, you will need to enter this code before you can reinstall channels.

Reinstall channels

To reinstall the channels only . . .

1 - Press and select 2 - Select

3 - Select the country where you install the TV. 4 - Select

search may take a few minutes. Follow the instructions on screen.

Full installation

To redo a full TV installation . . .

1 - Press and select 2 - Select

press OK. The installation may take a few minutes. Follow the instructions on screen.

Factory settings

Factory settings sets the TV back to the original TV settings for picture and sound. To switch back to the original Factory settings . . .

1 - Press and select 2 - Select

settings

3 - Press OK to confirm. 4 - Press , repeatedly if necessary, to close the menu.

Search for channels

Antenna (DVB-T)

TV settings

and press OK.

Setup

Re-install channels

Cable (DVB-C)

and press

. The channel

and press OK.

Setup

General settings

Reinstall TV

and

and press OK.

Setup

General settings

Factory

Channel list copy

Introduction

Channel list copy is intended for dealers and expert users. In some countries, Channel list copy is only available for copying satellite channels.

With

Channel list copy

one TV onto another Philips TV of the same range. With Channel list copy, you avoid the time-consuming channel search by uploading a predefined channel list on a TV. Use a USB flash drive of minimum 1 GB.

Conditions

• Both TVs are from the same year range.

• Both TVs have the same hardware type. Check the hardware type on the TV type plate on the back of the TV. Typically noted as Q . . . LA

• Both TVs have compatible software versions.

Current version

You can check the current version of the TV software with

Current software info

, you can copy the channels installed on

> Setup > Software settings

Child lock code of this TV. 5 - The TV notifies you if the channel list is copied to the TV successfully. Unplug the USB memory device.

To an already installed TV

1 - Verify the country setting of the TV. (To verify this setting, press and select

channels

later If the country is correct continue with step 2. If the country is not correct, you need to start a reinstallation. To start the reinstallation, press and select Select Select the correct country and skip the Search for channels. Finish the installation. When done, continue with step 2. 2 - Plug in the USB memory device that holds the channel list of the other TV. 3 - To start the channel list upload, press and select 4 - Select

Copy to TV

Child lock code of this TV. 5 - The TV notifies you if the channel list is copied to the TV

successfully. Unplug the USB memory device.

Cancel

TV settings

Setup

TV settings

Setup

Re-install channels

to leave the Search for channels.)

and press OK.

and press OK. You might be asked to enter the

and press OK. Select

and press OK. Press  and

General settings

Setup

Reinstall TV

Channel list copy

Search for

and press OK.

> OK.

Copy channel list

To copy a channel list . . . 1 - Switch on the TV which has its channels installed. Plug in a

USB memory device.

2 - Press and select 3 - Select

Copy to USB

TV, you might be asked to enter the Child lock code you entered during the installation. 4 - When copying is done, unplug the USB memory device.

Now you can upload the copied channel list onto another Philips TV.

Upload channel list

Upload a copied channel list

Depending on whether your TV is already installed or not, you must use a different way to upload a channel list.

To a TV that is not yet installed

1 - Plug in the power plug to start the installation and select language and country. You can skip Search for channels. Finish the installation. 2 - Plug in the USB memory device that holds the channel list of the other TV. 3 - To start the channel list upload, press and select 4 - Select

Copy to TV

TV settings

and press OK. To copy the channel list from this

and press OK.

Setup

TV settings

and press OK. You might be asked to enter the

and press OK.

Setup

General settings

Channel list copy

DVB-T or DVB-C

DVB-T or DVB-C reception

If both DVB-T and DVB-C reception is available in your country and if this TV is ready to receive DVB-T and DVB-C for your country, you have selected one or the other during the channel installation.

If you want to change the DVB setting to start a new channel installation . . .

1 - Press and select 2 - Select 3 - Select

Antenna (DVB-T)

4 - Select the DVB setting you want. 5 - Press , repeatedly if necessary, to close the menu.

DVB-C channel installation

For ease of use, all DVB-C settings are set to automatic. If your DVB-C provider gave you specific DVB-C values, the network ID or network frequency, enter these values when the TV asks for them during installation. It might be necessary to adjust the scanning (full or quick scan) or enter a specific symbol rate in the installing. To set a

Manual

Channel number conflicts

In some countries, different TV channels (broadcasters) might have the same channel number. While installing, the TV shows the list with channel number conflicts. You need to select which

Channel settings Channel installation

Symbol rate

and press OK.

Setup

and press OK.

Antenna connection

Cable (DVB-C)

, first set the Symbol rate to

and press OK.

Settings

menu while

TV channel you want to install on a channel number with multiple TV channels.

DVB-T + DVB-C

If you can use a DVB-T antenna input but also a DVB-C input, you can set up your TV for both DVB-T and DVB-C. Install one system followed by the other with the necessary settings. Once each system is installed, you need to switch the antenna input signal on the

Antenna

connection on the back of the TV and set the TV in the appropriate system to view the installed channels on TV. To select the DVB-T or DVB-C setting, see above.

DVB settings

Access DVB settings

Network frequency

With the

Network frequency mode

set to

Manual

, you can enter the network frequency value received from your cable provider here. To enter the value, use the number keys.

Frequency scan

Select the method of searching for channels. You can select the faster

Quick scan

method and use the predefined settings used

by most cable providers in your country. If this results in having no channels installed or if some channels

are missing, you can select the extended

Full scan

method. This

method will take more time to search for and install channels.

1 - Press and select 2 - Select 3 - Select

Search for channels

Re-install Channels

and press OK.

Setup

and press OK.

4 - Select the country where you install this TV. 5 - Select 6 - Select

C settings

Cable (DVB-C) Start to search channels

, or select

Settings for DVB-

7 - Press  , repeatedly if necessary, to close the menu.

Symbol rate mode

If your cable provider did not give you a specific value to install the TV channels, leave the setting on

Automatic

If you received a specific symbol rate value, select

symbol rate

Symbol rate mode

Manual

However, the value you received could be in the predefined list of symbol rates already. Select

Predefined symbol rates

check if your value is available automatically.

Symbol rate

Digital channels

If you know your cable provider is not offering digital channels, you can skip searching for digital channels. Select

Off

Analogue channels

If you know your cable provider is not offering analogue channels, you can skip searching for analogue channels. Select

Off

Free / Scrambled

If you have a subscription and a CAM - Conditional Access Module for pay TV services, select

Free + scrambled

. If you did

not subscribe to pay TV channels or services, you can select

Free channels

For more information, press

Conditional Access Module

only.



Keywords

and look up

CAM -

With the

Symbol rate mode

set to

, you can enter the

Manual

symbol rate value you received from your cable provider. To enter the value, use the number keys.

Network frequency mode

If you intend to use the fast

to search for channels, select

scan

Quick scan

method in

Automatic

Frequency

. The TV will use 1 of the predefined network frequencies (or HC - homing channel) as used by most cable providers in your country.

If you received a specific network frequency value to search for channels, select

Manual

Reception quality

If you receive digital channels, you can check the quality and signal strength of a channel.

If you have your own antenna, you can reposition the antenna to try and improve the reception. To check the reception quality of a digital channel . . .

- Tune to the channel.

- Press and select

- Select

3 reception test

Channel settings

and press OK.

Setup

Channel installation

The digital frequency is shown for this channel. If the reception is poor, you can reposition your antenna. To check the signal quality of this frequency again, select

and press OK.

To enter a specific digital frequency yourself, use the remote

Digital :

control digit keys. Alternatively, select the frequency, position the arrows on a number with  and  and change the number with

and . To check the frequency, select



and press OK.

If you use DVB-C to receive channels, the option

mode is

available. For Symbol rate mode, select

Symbol rate

Automatic

, unless your cable provider gave you a specific symbol rate value. To enter the symbol rate value, use the number keys.

Manual installation

Analogue TV channels can be manually installed, channel by channel.

To install analogue channels manually . . .

1 - Press and select 2 - Select

Manual installation

•

System

Channel settings

and press OK.

To set up the TV system, select

and press OK.

Setup

Channel installation

System

and press OK.

Analogue :

Select your country or the part of the world where you are now.

•

Search channel

To find a channel, select Search channel and press OK. Select

and press OK. You can also enter a frequency yourself. If

the reception is poor, press the channel, select

•

Fine tune

and press OK.

Done

To fine tune a channel, select

again. If you want to store

Fine tune

and press OK. You can fine tune the channel with  or . If you want to store the channel found, select

•

Store current channel / Store as new channel

Done

and press

You can store the channel on the current channel number or as a new channel number. Select

Store current channel

Store as new channel

You can redo these steps until you have found all available analogue TV channels.

Satellite channels

The lists Radio or New are only shown when radio stations are available or new channels were found with a channel update.

8.1

Satellite channels

• Only for TVs with a built-in satellite tuner.

8.2

Watching satellite channels

To watch satellite channels . . . Press and select satellite channel you last watched.

Change channel

To change channels, press the next channel in the selected channel list. If you know the channel number, you can use the number keys on the remote control. To change back to the previously tuned channel, press



You can also tune to a channel directly from the Satellite channel list.

8.3

Satellite

and press OK. The TV tunes to the



. The TV will tune to

 

Satellite channel list

About the channel list

When the satellite installation is completed, all satellite channels are put in the channel list. You can view the list of all channels or filter the list down to show the favourite channels only or the radio stations only. Or, after a channel update, you can find the newly added channels in the list of new channels.

Tune from the channel list

To tune to a channel from the channel list . . . 1 - In the channel list, select  or  in the menu bar to select

the TV or Satellite channel list.

2 - Select a list. 3 - Select a channel in any of the lists and press OK. The TV will

tune to the selected channel.

Channel list options

To view the channel list options on the current channel . . . 1 - With the All channels list on screen, select a channel and

press



OPTIONS

2 - Select the option you want and press OK. Available options for satellite channels . . .

•

Satellite

Filter the channel list to only show the channels of a specific satellite or show the channels of all satellites.

•

Free/Scrambled

Filter the channel list to only show the free-to-air channels, only the scrambled channels or both. Scrambled channels are marked with a key .

•

Lock channel

You can lock a channel. First select a channel in the list, press



OPTIONS

enter the 4-digit child lock code. A locked channel is marked with a lock .

•

Unlock channel

To unlock a locked channel. Select a locked channel in the list, press



OPTIONS

have to enter the 4-digit child lock code.

and select

and and select

Lock channel

. You will have to

Unlock channel

. You will

From any list, you can directly tune to a channel. The list you select in the channel list, determines the channels you tune to with the  + and

You can only reorder channels in the list of favourite channels.

 

keys.

Select a list filter

The list you select in the channel list, determines the channels you tune to with the  + and

To select a channel list . . .

1 - Press and select 2 - Press

the current channel selected. 3 - Navigate up to select



LIST

Satellite

to open the channel list. The list appears with

or a list filter.

All

keys.

 

and press OK.

Channel list copy

Channel list copy, you can copy the channels installed on one TV onto another Philips TV of the same range. Channel list copy will copy both terrestrial and satellite channels.

For more information, press

list copy

is intended for dealers and expert users. With



Keywords

and look up

Channel

8.4

Favourite satellite channels

Reorder favourite channels

You can only reorder channels in the Favourites list.

Favourite channels

You can mark channels as favourite channels. Your favourite satellite channels are collected in the satellite channel list.

Watching favourite channels

Set up a favourite channel list to easily switch between the channels you want to watch. To only switch between your favourite channels with and close the channel list again.

There are two favourite lists, one for TV channels and one for satellite channels.



and

, select the Favourites list in the channel list



Favourites

list of the

Set up your favourites list

To compose a list of your favourite channels . . . 1 - While watching a channel, press

channel list.

2 - In the menu bar, select  for satellite channels. 3 - Select the 4 - The TV will ask you to start adding channels immediately.

Press OK. To avoid a lot of reordering later, select the channels in the order you want them in the list. 5 - To add a channel to the Favourites list, select the channel and press OK. You can then select another channel to add as a favourite. 6 - To finish, press .

Favourites

list.



to open the

LIST

1 - In the channel list to reposition.

2 - Press . 3 - Select the channel to reorder and press OK. 4 - Press the

channel to another location and press OK. 5 - Once complete, press  channel list.

8.5

Navigation buttons

Favourites

, highlight the channel you want

to move the highlighted

to exit from the Favourite

EXIT

Lock satellite channels

Lock a channel

You can lock a channel to prevent children from watching it. To watch a locked channel you need to enter the Child lock code. You cannot lock programmes from connected devices.

To lock a channel . . . 1 - While watching a TV channel, press

open the channel list.

2 - In any list, select the channel you want to lock. 3 - Press

list, a locked channel is marked with a lock . To unlock a channel, select the locked channel in the channel list

and press



OPTIONS



OPTIONS,

and select

select



Lock channel

Unlock channel

Use an age rating

LIST

. In a channel

Add or remove favourite channels

To add or remove favourites list . . . 1 - While watching a TV channel, press

channel list.

list. To remove a channel from the favourites list, press  to

unmark as favourite.



to open the

LIST

To prevent children from watching a programme not suitable for their age, you can use an age rating.

To set an age rating . . .

1 - Press and select 2 - Select

press 3 - Enter a 4-digit Child lock code and confirm. Now you can set an age rating.

4 - Set the age and press OK. 5 - Press , repeatedly if necessary, to close the menu.

To switch off the parental age rating, select The TV will ask for the code to unlock the programme. For

some broadcasters / operators, the TV only locks programmes

Satellite settings

and press OK.

Setup

Child lock

Parental rating

as age setting.

None

and

with a higher rating.

Child lock code

You can set or change the Child lock code. To set the lock code or to change the current code . . .

1 - Press and select 2 - Select

press OK. 3 - If a code is set already, enter the current Child lock code and then enter the new code twice.

The new code is set.

Forgotten your Child lock code?

If you forgot your code, you can override the current code and enter a new code.

1 - Press and select 2 - Select

press OK.

3 - Enter the overriding code 4 - Now enter a new Child lock code and enter it again to

confirm.

8.6

Satellite settings

and press OK.

Setup

Child lock

and press OK.

Setup

Child lock

8888

Change code

and

Change code

and

Satellite installation

Installing satellites

About installing satellites

Installing

You can install your satellites during the initial TV setup. The satellite installation follows the TV channel installation. If you only watch satellite channels, you can skip the TV channel installation. You can always start a new satellite installation from the Setup menu.

To install satellite channels . . .

1 - Press and select 2 - Select 3 - Select 4 - The TV shows the current installation setting. If the current

setting corresponds with the satellite installation you want, you can start searching for satellites. Select to step 5. If the current setting is not the setting you want, select

Settings

- In the Settings menu, select the exact number of satellites

you want to install. Or, if you use a Unicable setup, select

Unicable for 1 satellite

the number of satellites you want to install for Unicable. Select the setting you want and press OK.

- If the exact number of satellites is set or you completed the

Unicable settings, select 5 - The TV will search for satellites available on the alignment of your antenna dish. This may take a few minutes. If a satellite is found, its name and reception strength are shown on screen. 6 - If a channel package is available for any of the satellites found, you can select the package you want. 7 - To install the channels of the satellites found, select and press OK. The TV shows the number of channels and radio stations found. 8 - To store the satellite settings, all satellite channels and satellite radio stations, select

Search for satellite Install satellites

and press OK. Go to step 4b.

and press OK.

Setup

and press OK.

Unicable for 2 satellites

and press OK.

Finish

and press OK. Go

according

Install

This TV has a built-in satellite DVB-S/DVB-S2 receiver. Connect the cable from your satellite dish directly to the TV. Use a coaxial cable fit for connecting a satellite antenna dish. Make sure your satellite dish is perfectly aligned before you start the installation.

Up to 4 satellites

You can install up to 4 satellites (4 LNBs) on this TV. Select the exact number of satellites you wish to install at the start of the installation. This will speed up the installation.

Unicable

You can use a Unicable system to connect the antenna dish to the TV. Select if you are installing satellites for a Unicable system, for 1 or for 2 satellites at the start of the installation.

MDU - Multi-Dwelling-Unit

The satellite receiver of this TV supports MDU on the Astra satellites and for Digiturk on the Eutelsat satellite. MDU on Türksat is not supported.

Channel packages

About channel packages

Satellites can offer channel packages that bundle free channels (free-to-air) and offer a sorting that suits a country. Some satellites offer subscription packages - a collection of channels you pay for.

If you choose a subscription package, the TV might ask you to select a Quick or Full installation. Select

Satellite operator channels only

the package only or select package and all other available channels too. We recommend a Quick installation for subscription packages. If you have additional satellites that are not part of your subscription package, we recommend a Full installation. All installed channels are put in the channels list All.

All satellite channels

to install the channels of

to install the

Update channel packages

User band number

With

Update channel package

channels that were in the satellite channel list before but are now missing. The missing channels were repositioned on the transponder by the satellite operator. The TV must be updated with the latest version of the channel package.

To download the latest version of the channel package . . .

- Go to the Philips support website

and enter the type number of your TV.

- Click on

2 PredefinedSortingList

- Download the file on your computer and copy the file on

the root directory of a USB flash drive, not in a folder (if necessary, unzip the file first).

- Plug the USB flash drive into the TV and press and

select

- Select

5 channel package

- The TV will copy the file and ask you to start a channel

update immediately. Select few minutes. If you want to postpone the channel update, you can do it later with

channels

- After the channel update is done, the missing channels

should be back at their former position in the satellite channel list.

Software and drivers

and press OK.

Setup

Satellite settings

and press OK.

Setup

, you can bring back satellite

www.philips.com/support

and look for the file :

Channel installation

and press OK. This may take a

Yes

Search for satellite

Update

In a Unicable system, each connected satellite receiver must be numbered (e.g. 0, 1, 2 or 3 etc.).

You can find the available user bands and their number on the Unicable switchbox. User band is sometimes shortened as UB. There are Unicable switchboxes that offer 4 or 8 user bands. If you select Unicable in the settings, the TV will ask you to assign the unique user band number for its built-in satellite receiver. A satellite receiver cannot have the same user band number as another satellite receiver in the Unicable system.

User band frequency

Next to the unique user band number, the built-in satellite receiver needs the frequency of the selected user band number. These frequencies are mostly shown next to the user band number on a Unicable switchbox.

Add a satellite

You can add an additional satellite to your current satellite installation. The installed satellites and their channels remain untouched. However, some satellite operators do not allow adding a satellite.

Unicable setup

The Unicable system

You can use a Unicable system to connect the antenna dish to the TV. A Unicable system uses one cable to connect the satellite dish to all satellite receivers in its system. Unicable is typically used in apartment buildings. If you use a Unicable system, the TV will ask you to assign a user band number and corresponding frequency during the installation. You can install 1 or 2 satellites with Unicable on this TV.

If you notice some missing channels after a Unicable installation, another installation might have been done at the same moment on the Unicable system. Do the installation again to install the missing channels.

The additional satellite should be seen as an extra, it is not your main satellite subscription or not the main satellite of which you use its channel package. Typically, you would add a 4th satellite when you have 3 satellites already installed. If you have 4 satellites installed, you might consider removing one first to be able to add a new satellite.

Settings

If you currently have only 1 or 2 satellites installed, the current installation settings might not allow adding an extra satellite. If you need to change the installation settings, you must redo the complete satellite installation. You cannot use change of settings is needed.

To add a satellite . . .

1 2 3

shown.

satellites.

press OK. The TV installs the channels of the found satellites.

press OK.

Add satellite

- Press and select

- Select

- If the TV has found one or more satellites, select

- To store the channels and radio stations, select

Search for satellite Add satellite

and press OK. The TV will search for new

Add

and press OK.

Setup

and press OK.

and press OK. The current satellites are

Install

Finish

if a

and

Remove a satellite

Update satellite channels

You can remove one or more satellites from your current satellite installation. You remove the satellite and its channels. However, some satellite operators do not allow removing a satellite.

To remove satellites . . .

- Press and select

- Select

are shown.

- Use the arrows keys to select the satellite you want to

remove.

- Press OK to mark a satellite to remove. Press OK again to

unmark.

- Select

removed.

- Select

Search for satellite Remove satellite

Remove

Exit

, press OK and confirm. The satellites are

and press OK to close Remove satellite.

and press OK.

Setup

and press OK.

and press OK. The current satellites

Reorder and rename channels

You can reorder and rename satellite channels.

Reorder

You can only reorder channels in the Favourites list. For more information on Reordering satellite channels, press and look up

Rename channels

You can rename channels in the channel list.

lists -

control keyboard or open the on-screen keyboard.

With the remote control keyboard

To delete a character, position the cursor behind the character and press . To enter a character, press the character on the keyboard. When you are ready, press OK to select to finish renaming. For more information on entering text, press look up



Keywords

Satellite, reorder channels

- Select the channel you want to rename in one of the channel

All, Favourites, Radio

- Press



Rename

. You can enter text with the remote

New

. Press OK again

Done

and

Remote control, keyboard



Keywords

Once a day, at 6 AM, the TV automatically updates the satellite channels. A channel update looks for new channels and adds them to the channel list. No longer available channels are removed and if a provider reorders its channel package, the channel list of the TV will be updated. The TV must be on standby to automatically update the satellite channels. Alternatively, you can do a channel update yourself at any moment.

New channels, found with the channel update, are marked with the letter N and collected in the channel list New. New channels are also added in the All channel list. New channels stay in the channel list New as long as you do not tune to them or mark them as a favourite.

Switch off the automatic channel update

You can completely switch off the TV at night to avoid a channel update. Alternatively, you can switch off the automatic update in the setup menu.

1 - Press and select 2 - Select

channel update Switch off the update for a specific satellite

1 - Press and select 2 - Select

update option

3 - With the arrow keys, select the satellite you do not wish to update. Press OK to unmark the satellite. 4 - Select The TV will not update the channels from the satellite you unmarked.

Start an update yourself

1 - Press and select 2 - Select 3 - Select 4 - If you want to check which satellites are set for updating,

select 5 - With the arrow keys, mark or unmark the satellites for updating. Select 6 - Select minutes. 7 - Select

Satellite settings

and select

Satellite settings

and press OK to close the menu.

Done

Search for satellite Update channels

Settings

and press OK.

Done

Update

Finish

and press OK. The update may take a few

and press OK.

Setup

Channel installation

Off

and press OK.

Setup

Channel installation

and press OK.

Setup

and press OK.

Automatic

With the on-screen keyboard To open the on-screen keyboard, place the cursor in the name

text field and press OK. To delete the character in front of the cursor, press

Backspace

To enter a character, select the character with the arrow keys and press OK. To select uppercase letters, press . To select numbers or special characters, press . When you are ready, press  to close the on-screen keyboard. To finish renaming, select

and press OK.

Done



Languages and audio

Preferred languages and subtitles

Satellite channels can hold different audio languages, subtitle languages or Text languages. You can set the TV to automatically switch to the language, subtitle language or Text language you prefer, if this language is available on the channel or Text pages.

To set the your preferred language . . .

1 - Press and select 2 - Select 3 - Select 4 - Press , repeatedly if necessary, to close the menu.

Hearing impaired audio

Satellite settings Languages

and press OK. Select the setting you want.

and press OK.

Setup

and press OK.

- Press and select

- Select

2 Speakers / Headphones

- Select

and press OK.

- Press , repeatedly if necessary, to close the menu.

Satellite settings

Speakers, Headphones

and press OK.

Setup

Languages

and press OK.

Audio description

Speakers + headphones

Some digital TV channels broadcast special audio and subtitles adapted for hearing impaired people. With Hearing impaired switched on, the TV automatically switches to the adapted audio and subtitles, if available. Before you can switch on Hearing impaired, you have to switch on

Universal access

Switch on

To switch on Hearing impaired, press

Universal access

and press OK.

To check whether a hearing impaired audio language is available, press



OPTIONS

audio language marked with a . If Universal access does not appear in the Options menu, switch

Universal access

For more information, press

Universal access

Audio description

and press OK.Select

, select

in Setup.



OPTIONS

Hearing impaired

Audio language



Keywords

, select

and look for an

and look up

Mixed volume

You can mix the volume of the normal audio with the audio commentary.

To mix the volume . . .

- Press

bar.

- Select

- Use the arrows up and down to set the slider bar.

- Press OK to confirm.

Audio effect

Some audio commentary can hold extra audio effects, like stereo or fading sound.

To switch on Audio effects (if available) . . .

- Press and select

- Select

2 Audio effects

- Select On or

- Press , repeatedly if necessary, to close the menu.



OPTIONS

Universal access

Satellite settings

and press OK.

and select the

Setup

and press OK.

Off

Options

Mixed volume

and press OK.

Languages

tab in the menu

and press OK.

Audio description

Switch on

Digital TV channels can broadcast special audio commentary describing what is happening on screen. To be able to set the Audio description audio and effects, you have to switch on Audio description first. Also, before you can switch on Audio description, you have to switch on

Audio description

With Audio description, a narrator's commentary is added to the normal audio. To switch on the commentary (if available) . . .

- With

and select the

- Select

- Select On and press OK.

You can check if an audio commentary is available. In the audio language marked with a .

Speakers / Headphones

You can select where you want to hear the audio commentary. On the TV speakers only, on the headphones only or on both.

To set Speakers / Headphones . . .

Universal access

Audio description

Options

switched on, press

Options

menu, select

tab in the menu bar.

Universal access

and press OK.

Audio language



OPTIONS

and look for an

Speech

The audio commentary can also hold subtitles for the words which are spoken.

To switch on these subtitles (if available) . . .

- Press and select

- Select

2 Speech

- Select

- Press , repeatedly if necessary, to close the menu.

Satellite settings

and press OK.

Descriptive

and press OK.

Setup

Languages

(audio) or

Subtitles

Audio description

and press OK.

Manual installation

Manual installation is intended for expert users. You can use Manual installation to quickly add new channels from a satellite transponder. You need to know the frequency and polarization of the transponder. The TV will install all channels of that transponder. If the transponder was installed before, all its channels - the former and the new ones - are moved to the end of the channel list All. You cannot use Manual installation if you need to change the number of satellites. If this is needed, you have to do a complete installation with Install satellites.

To install a transponder . . .

- Press and select

- Select

2 installation

- If you have more than 1 satellite installed, select the

satellite/LNB for which you want to add channels.

- Set the

4 mode

manually. Enter the transponder.

- If a transponder is found, select

the new transponder on the selected LNB.

- Select

8.7

Satellite settings

and press OK.

Polarization

Manual

to leave the manual installation.

Exit

, you can enter the symbol rate in

Frequency

and press OK.

Setup

Channel installation

you need. If you set the

and start searching for the

and press OK to store

Store

Manual

Symbol rate

Problems with satellites

The TV cannot find the satellites I want or the TV installs the same satellite twice

• Make sure that the correct number of satellites is set in Settings at the start of the installation. You can set the TV to search for One, Two or 3/4 satellites.

A dual head LNB cannot find a second satellite

• If the TV finds one satellite but cannot find a second one, turn the dish a few degrees. Align the dish to get the strongest signal on the first satellite. Check the signal strength indicator of the first satellite on screen. With the first satellite set at the strongest signal, select Search again to find the second satellite.• Make sure the settings are set to Two satellites.

Changing the installation settings did not solve my problem

• All settings, satellites and channels are only stored at the end of the installation when you finish.

All satellite channels are gone

• If you use a Unicable system, make sure you assigned a unique user band number to the satellite receiver in the Unicable settings. It might be that another satellite receiver is using the same user band number.

Some satellite channels seem to have disappeared from the channel list

• If some channels seem to be gone or displaced, the broadcaster might have changed the transponder location of these channels. To restore the channel positions in the channel list, you can try an update of the channel package.

I cannot remove a satellite

• Subscription packages do not allow removing a satellite. To remove the satellite, you have to do a complete installation again and select another package.

Sometimes the reception is poor

• Check if the satellite dish is solidly mounted. Strong winds can move the dish.

• Snow and rain can degrade the reception.

Home menu

From the Home menu, you can start any activity you can do with the TV.

Open the Home menu to start watching TV or start watching a disc on your Home Theatre System. Also in the Home menu, you can open Smart TV to surf the Internet, start Skype or open Help if you need information on using the TV.

Open the Home menu

1 - To open the Home menu, press . 2 - Select an activity using the arrow keys and press OK to start

the activity. 3 - To close the Home menu without changing the current activity, press .

•

Help

Select look up a topic in an alphabetical list.

•

Setup

Select

•

Satellite

Select for TVs with a built-in satellite tuner).

•

Select TV and press OK to watch TV channels.

•

Smart TV

Select page. (only for Smart TVs)

•

Source

Select underneath the icon. Press OK to switch to the selected device.

•

TV guide

Select scheduled TV programmes of your channels.

•

Recordings

Select recordings.

•

Skype

Select

•

Demo

Select

and press OK to open the on screen Help. You can

Help

to install channels or adjust all TV settings.

Setup

Satellite

Smart TV

Source

TV guide

Recordings

Skype

Demo

and press OK to watch satellite channels (only

and select a connected device in the list

and press OK to open a list of the current and

to make video calls for free. (only for Smart TVs)

to watch demonstration videos.

and press OK to open the Smart TV start

and press OK to open the list of your

Change day

TV guide

10.1

What you need

With the TV guide you can view a list of the current and scheduled TV programmes of your channels. Depending on where the TV guide information (data) is coming from, analogue and digital channels or only digital channels are shown. Not all channels offer TV guide information.

The TV can collect TV guide information for the channels that are installed on the TV (e.g the channels you watch with Watch TV). The TV cannot collect the TV guide information for channels viewed from a digital receiver.

10.2

Using the TV guide

Open the TV guide

To open the TV guide, press 

TV GUIDE

The TV guide can show scheduled programmes for the upcoming days (maximum up to 8 days).

If the TV guide information comes from the broadcaster, you can press Press

 

Alternatively, you can press

day

Select

Previous day, Today

the day of the schedule.

to view the schedule of one of the next days.



to go back to the previous day.



OPTIONS

Next day

and select

and press OK, to select

Change

Set a reminder

You can set reminders that alert you of the start of a programme with a message on screen.

• To set a reminder, select the programme in the schedule and press  for clock.

• To cancel the reminder, press the  for

• To view a list of all reminders you have set, press 

Set reminder

OPTIONS, and select All reminders

. The programme is marked with a

Clear reminder

Press 

The first time you open the TV guide, the TV scans all TV channels for programme information. This may take several minutes. TV guide data is stored in the TV.

TV GUIDE

again to close.

Tune to a programme

Switch to a programme

From the TV guide, you can switch to a current programme. To select a programme, use the arrow keys to highlight the programme name. Navigate to the right to view programmes scheduled later that day. To switch to the programme (channel), select the programme and press OK.

Search by genre

If the information is available, you can look up scheduled programmes by genre like movies, sports, etc.

To search for programmes by genre, press  select

Search by genre

Select a genre and press OK. A list with the found programmes appears.

10.3

OPTIONS

and

Recordings

From the TV guide, you can instantly record or schedule a recording of a TV programme. To store the recordings, connect a USB Hard Drive to the TV.

For more information on Recording, press look up

Recording



Keywords

and

View programme details

To call up the details of the selected programme, press 

INFO

Sources

To rescan all TV connections and update the Sources menu, press



OPTIONS.

select

Scan connections

and press OK.

11.1

Sources list

In the list of connections - the Source menu - you can find the devices connected to the TV. From this Source menu, you can switch to a device.

Sources menu

To open the Sources menu, press To switch to a connected device, select the device with the arrows  (left) or  (right) and press OK. For some devices (HDMI-CEC devices), you can select an activity directly in the list underneath the device icon. Select the device and select an activity and press OK. To close the Source menu without switching to a device, press 

Automatic detection

SOURCES

again.



SOURCES

11.2

From standby

With the TV in standby, you can switch on a connected device with your TV remote control.

Play

To switch on both disc player and TV from standby and start playing the disc or programme immediately, press  (play) on the TV remote control. The device should be connected with an HDMI cable and both TV and device must have HDMI CEC switched on.

Home Theatre System

You can switch on your Home Theatre System to listen to an audio disc or a radio channel and leave the TV in standby. To only switch on the HTS, with the TV in standby, press



SOURCES

on the TV remote control.

When you connect a new device to the TV, the device is detected automatically and put in the Sources menu. The device is shown as an icon (the device type) and has a name. If the device type does not correspond with the device, e.g. the TV says it is a player but it is not, you can change the type. To change the type of the device, press select a type that fits the device and press OK. If the name does not fit the device or you want to give the device a name of your own, press control keypad to enter a new name.

An appropriate device type helps you in using the device. The device type determines picture and sound styles, resolution values, specific settings or the position within the Sources menu.

When you connect a new device to the TV, the icon of the device jumps to the front of the Sources menu.

If the TV does not detect the device automatically, select the connection you used to connected the device and adjust the Device type and name.

Original name and icon

To restore the device icon to its original name and type icon, press



OPTIONS.

press OK.

Select

Original name and icon



Rename



Change type

. Use the remote

and

11.3

EasyLink

With

EasyLink

remote control. EasyLink uses HDMI CEC to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

For more information, press up

EasyLink

you can operate a connected device with the TV



Keywords

and look

Scan connections

Timers and clock

12.1

Sleeptimer

With the sleep timer, you can set the TV to switch to standby automatically after a preset time.

To set the sleep timer . . .

off. To deactivate the

1 - Press and select 2 - Select

and set the slider bar to 3 - Press , repeatedly if necessary, to close the menu.

For more information on environmentally friendly TV settings, press

TV settings



Keywords

Switch off timer

Setup

General settings Off

and look up

. . .

and press OK.

Eco settings

Switch off timer

1 - Press and select 2 - Select

With the slider bar you can set the time to up to 240 minutes in increments of 30 minutes. If set to switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press , repeatedly if necessary, to close the menu.

12.2

TV settings

and press OK.

Setup

General settings

Sleep timer

, the sleep timer is

Off

Clock

To know what time it is, press the TV guide.

In some countries, digital broadcasts do not send UTC Coordinated Universal Time information. The daylight saving change might be ignored and the TV might show an incorrect time.

To correct the TV clock . . .

1 - Press and select 2 - Select

clock mode,

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

TV settings

and select

Daylight saving

Setup



TV GUIDE

and press OK.

General settings

Country dependent

and select the appropriate setting.

to find the time in

Clock

Auto

To set the TV clock manually . . .

1 - Press and select 2 - Select

clock mode,

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

12.3

TV settings

and select

and

Day

Time

and press OK.

Setup

General settings

Manual

to adjust.

Clock

Auto

Switch off timer

If you do not press a key on the remote control during a 4 hour period, or if the TV receives no input signal nor remote control commands for 10 minutes, the TV switches off automatically to save energy.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-top box - STB) and you do not use the remote control of the TV, you should deactivate the automatic switch

For Active 3D sets

13.1

• Only for TVs with 3D function.

13.2

What you need

For Active 3D sets

This is an Active 3D TV. On this TV, you can watch 3D programmes and movies in full High Definition resolution with Active 3D.

To watch 3D you need to :

• Tune to a TV channel that broadcasts programmes in 3D.

• Rent a movie in 3D from an online video store with Smart TV.

• Watch a movie in 3D from a 3D Blu-ray Disc, a USB device or computer.

Overview

1 - On or off switch 2 - Player 1 or player 2 selection 3 - Receiver lens 4 - Battery compartment

When you unpack the 3D glasses, also remove the small plastic foil from the battery compartment that prevents the battery from running empty.

Switch on and off

Switch on

When a 3D programme is shown on screen, press  on the 3D glasses and put them on. The glasses need some seconds to adjust to the 3D signal from the 3D transmitter on the TV. At first use, this may take up to 15 seconds.

Battery level

You can check the battery level when you switch on the 3D glasses.

Also, to watch 3D on this TV, you will need one of these types of Philips Active 3D glasses. . .

• PTA507

• PTA508

• PTA509

• PTA517

• PTA518

• PTA519

For Passive 3D sets

This is a Passive 3D TV. To watch 3D you need to :

• Tune to a TV channel that broadcasts programmes in 3D.

• Rent a movie in 3D from an online video store with Smart TV.

• Watch a movie in 3D from a 3D Blu-ray Disc, a USB device or computer.

You can view photos in Ultra HD resolution in 3D, from a USB connection.

• If the LED light blinks green, you can use the glasses for 4 hours or more.

• If the LED light blinks orange, you can use the glasses for at least 2 hours but less than 4.

• If the LED light blinks red, the battery is almost empty and less than 2 hours of 3D watching remain.

Switch off

To switch off the 3D glasses, press . The LED light blinks red 4 times. When the 3D glasses do not receive 3D signals for 2 minutes, the glasses switch off automatically.

3D transmitter

Make sure the receiver lens in the centre of the glasses can receive the 3D signals. Also, clear objects away from the 3D transmitter on the TV.

1 - 3D transmitter on the TV 2 - 3D receiver on the 3D glasses

13.3

The 3D glasses

Two-player gaming

You can use these glasses to play two-player games. Two players can watch the same TV but see two different screens to play a game. To switch the glasses to watch the Player 1 or Player 2 screen,

switch on the glasses and then press the

• If the LED light is orange and lits continuously for 2 seconds, the glasses are set for player 1.

• If the LED light is orange and blinks, the glasses are set for player 2.

For more information, press

player gaming

Replacing the batteries

To replace the battery of the 3D glasses PTA508, unscrew the small battery lid and replace the battery: type CR2032 (3V). Make sure the + side of the battery is visible. Replace the lid and fix it with the screw.

To replace the battery of the 3D glasses PTA509, PTA51, press the small knob on the battery lid and slide the lid up to open. Replace the battery: type CR2032 (3V). Make sure the + side of the battery is visible. Replace the lid and slide it down until it clicks.



Warning

Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type.



Keywords

Player 1/2

and look up

key.

Two-

For Passive 3D sets

When a 3D programme is shown on screen, simply put on the 3D glasses to watch the programme in 3D.

Recommended viewing height

13.5

Watch 3D

To experience the best 3D effect while you watch 3D programmes:

• Sit at a distance that is at least three times the width (w) of the TV screen.

• Do not sit more than 6m away.

3D switching

The first time a 3D signal is detected, you can set your preference on how to start 3D in the future.

• To switch to 3D automatically, select

• To show a notification first, select

• To never switch to 3D, select You can still change this preference in >

> 3D >

Start 3D

When the TV switches to 3D or when a notification is shown that 3D is available, put on your 3D glasses.

If the TV cannot detect the 3D signal (the 3D signal tag is missing), the 3D programme is shown as a double image on screen. To switch to 3D, adjust the 3D settings and select Side by side or Top / bottom according to the double image positions.

Stop 3D

To stop watching 3D, press , select 3D settings and select Off. 3D is switched to 2D when you switch to another channel or connected device.

Switch to 3D

Setup

TV settings

Automatic

Notification only

Never

For best picture quality, when watching passive 3D, your eyes should be level with the centre of the screen.

13.4

Care of the 3D glasses

• Do not use cleaning chemicals containing alcohol, solvent, surfactant, or wax, benzene, thinner, mosquito repellent or lubricant. Using these chemicals can cause discoloration or cracks.

• Do not expose the 3D glasses to direct sunlight, heat, fire or water. This may result in a product malfunction or fire.

• Do not drop, bend or apply force to the lenses of the 3D glasses.

• Use a clean soft cloth (microfiber or cotton flannel) to clean the lenses to avoid scratching them. Never spray cleaner directly onto the 3D glasses. This may damage the electronics (for Active 3D glasses).

2D to 3D conversion

You can convert any 2D programme to watch it in 3D.

1 - Press . 2 - Select

conversion

To adjust the 3D depth...

1 - Press . 2 - Select 3 - Select an option, then press OK.

To switch off 2D to 3D conversion...

1 - Press . 2 - Select

Note: If you switch to another activity, the conversion stops. You can change the depth of 3D for a weaker or stronger 3D

effect in the 2D to 3D conversion. To change the 3D effect, press  and select depth),

Picture and sound

Normal

3D settings

3D effect

3D settings

3D effect

(optimal 3D quality) or

. Select

Off

2D to 3D

> 2D, then press

(no 3D),

Less

(more 3D depth).

(less 3D

13.6

Optimal 3D viewing

For an optimal 3D viewing experience, we recommend that you:

• sit at least 3 times the height of the TV screen away from the TV, but no further than 6 meters away.

• avoid fluorescent lighting (such as TL lighting or certain energy saving light bulbs which operate on a low frequency) and direct sunlight as they may interfere with the 3D experience.

13.7

Health warning

• Watching 3D is not recommended for children under the age of six.

• If you or your family have a history of epilepsy or photosensitive seizures, consult a medical professional before exposing yourself to flashing light sources, rapid image sequences or 3D viewing.

• If you experience any discomfort, stop watching 3D and do not immediately engage in any potentially hazardous activity (for example driving a car) until your symptoms have disappeared. If symptoms persist, do not resume watching 3D without consulting a medical professional first.

• To avoid discomfort such as dizziness, headache or disorientation, we recommend not watching 3D for extended periods of time.

• Do not use the 3D glasses for any purpose other than watching 3D TV.

• If you normally wear corrective glasses or use contact lenses, wear the 3D glasses together with these glasses or lenses.

• Keep the glasses away from small children to avoid the swallowing of small parts or batteries.

• Parents should monitor their children during 3D viewing and ensure they do not experience any discomfort as mentioned above. Watching 3D is not recommended for children under six years of age as their visual system is not fully developed yet.

• Avoid the use of the 3D glasses in case of eye infection or other diseases transmitted by contact (e.g. conjunctivitis, head lice, etc.). Only start using the 3D glasses again when the infection has disappeared completely.

Games

14.1

Play a game

What you need

To play a two-player game with this TV, you need 2 active 3D glasses - Philips PTA507, PTA508, PTA509, PTA517, PTA518 or PTA519. Also, the game console must be connected with HDMI.

With a game console connected to the TV, you can play games on TV.

For more information on connecting a game console, press



Keywords

Start a game

1 - Switch on the game console. 2 - Press , select the game console and press OK. 3 - Start the game.

Ideal game setting

For some games, where speed and precision is needed, set the TV to the ideal If your game console is added as a Sources menu (list of connections), the TV is set to the ideal Game setting automatically. If the type of your game console is set as disc player most of the time, leave the device type set to

To set the TV to the ideal setting manually . . .

1 - Press and select 2 - Select

and press OK.

style

3 - Select 4 - Press , repeatedly if necessary, to close the

menu. Remember to set the Game or computer setting back to Off when you stop playing the game.

and look up

Game

TV settings

and press OK.

Game

Game console, connect

setting before you start playing.

type of device in the

Game

Player

and press OK.

Setup


Advanced

and used as a

Activity

Player

Play a two-player game

To start a two-player game . . .

1 - Press 2 - On the game console, start the game and select the multi or

two-player mode. Select the mode for split screen viewing. 3 - On the TV, press select 4 - Select the format in which the split screen game is shown on screen, shows the 2 screens as full screens. To watch the 2 different screens, put on the 3D glasses. To switch the glasses to watch the Player 1 screen or Player 2 screen, press the

In and out of split screen view

In two-player split screen view, you can switch back and forth

from split screen to combined view, to be able to read the game menu or game scores. To switch views back and forth, press OK on the remote control of the TV.

Stop a Two-player game

To stop the two-player split screen view, press and select another activity.



SOURCES

Two-player gaming

Side by side

, select the game console and press OK.



OPTIONS

Top / bottom

Player 1/2

and press OK.

selection key on the glasses.

, select

Picture and sound

and press OK. The TV

14.2

Two-player games

For Active 3D sets

About two-player gaming

For Passive 3D sets

About two-player gaming

If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen. Each player sees only his part of the game, full screen. The TV uses 3D technology to show both screens. To view the two different full screen pictures, you need a pair of 3D glasses for each player.



SOURCES

PTA436

, select the game console and press OK.

(sold separately).

What you need

To play a two-player game with this TV, you need a two-player kit with 2 passive 3D glasses - Philips Also, the game console must be connected with HDMI.

Play a two-player game

To start a two-player game . . .

1 - Press 2 - On the game console, start the game and select the multi or

two-player mode. Select the mode for split screen viewing. 3 - On the TV, press select

Two-player gaming

4 - Select the format in which the split screen game is shown on screen,

Side by side

shows the 2 screens as full screens. To watch the 2 different screens, put on the 3D glasses. To switch the glasses to watch the Player 1 screen or Player 2 screen, press the

In and out of split screen view

In two-player split screen view, you can switch back and forth from split screen to combined view, to be able to read the game menu or game scores. To switch views back and forth, press OK on the remote control of the TV.



OPTIONS

Top / bottom

Player 1/2

and press OK.

selection key on the glasses.

, select

Picture and sound

and press OK. The TV

Stop a Two-player game

To stop the two-player split screen view, press and select another activity.

Your photos, videos and music

15.1

Photos



Folders



Music



Videos

view and browse your folders to look

. Alternatively, you

The menu bar

Navigate to the menu bar and select the type of file you want to watch or play. Select



can open the for a file.

Sorting

From a USB connection or network computer

What you need

You can view your photos or play your music and videos from a connected USB flash drive or USB Hard Drive. If you have a computer in your home network, you can view and play your files from your computer on the TV.

From a USB device

With the TV switched on, plug in a USB flash drive or USB Hard Drive to one of the USB connections. The TV detects the device and lists your files. If the list does not appear automatically, press select

Browse USB

and press OK.



SOURCES

To browse your photos by date, month, year or alphabetically by name, press To browse your music by album, artist, genre or alphabetically by name, press Videos are sorted alphabetically.



Sort

View photos

To view photos, select photo thumbnail and press OK. If there are several photos in the same folder, select a photo and press



folder. To jump to the next or previous photo, press To stop the slide show or close the photo, press (Stop).

You can play music with a slide show. Start the slide show after you started the music.

- Select a song or a folder with songs and press OK.

- Press

- Select a photo or a folder with photos and press

show

show to start a slide show of all photos in this

Slide



LIST



Photos

and select

in the menu bar, select a





Photos



LIST





Slide



Warning

If you try to pause or record a programme with a USB Hard Drive connected, the TV will ask you to format the USB Hard Drive. This formatting will delete all current files on the USB Hard Drive.

From a computer

If the TV and the computer are in the same network, the TV can browse and play files stored on your computer. On your computer, you need to install media server software like Twonky™ to share your files with the TV. The TV shows your files and folders as they are organised on your computer. To browse the files on your computer, press select

Browse network

and press OK.



SOURCES

Menu bar and sorting

With a USB device connected, the TV sorts the files by type. Navigate to the menu bar and select the type of file you are looking for. If you browse files from a computer, you can only browse the files and folders as they are organized on the computer.

Info

To view info on a photo (size, creation date, file path, etc.), select a photo and press Press again to hide the info.

Options

Press

• Shows your photos in a random order.

• Plays the slide show continuously.

• Sets the speed of the slide show.

• Sets the style of the photo transitions.

To close another activity.



OPTIONS

Shuffle

Repeat

Slide show speed

Slide show transition

Browse USB



Browse network

INFO

, press and select

Play music

To play music, select and press OK. If there are more songs in the same folder, press play all songs in this folder. To jump to the next or previous song, press To pause the music, press OK. Press OK again to continue. To make a 10-second jump in a song or 10-second jump back, press  or . To rewind or fast forward, press  or . Press the keys several times to speed up - 2x, 4x, 8x, 16x, 32x. To stop the music playback, press  (Stop).



in the menu bar, select a song

Music





Play all



Options

Press

• If available, you can switch subtitles On,

• Plays your videos in a random order.

• Plays a video once or continuously.

To close another activity.



Subtitles

Shuffle

Repeat

OPTIONS

Browse USB

Browse network

Off

On during mute

, press and select

If you press

Info

To view song info (title, artist, duration, etc.), select the song and press Press again to hide the info.

Options

Press

•

Shuffle

Plays your music randomly.

•

Repeat

Plays the song once or continuously.

•

Screen off

If you only listen to music, you can switch off the TV screen to save energy. To switch off the screen, press

settings

switch the screen back on, press any key on the remote control. To close

another activity.





INFO



OPTIONS

in the menu bar, select

Browse USB

or , the music keeps on playing.

LIST



OPTIONS

Screen off

Browse network

, select



Eco

and press OK. To

, press and select

15.2

Wi-Fi Miracast

About Wi-Fi Miracast

Your TV is a Miracast™, you can watch and share the screen of your smartphone, tablet or computer on your TV screen wirelessly. You can stream videos (audio and video), share photos or anything else that's on screen of the device. No need to connect the device to your home network. Both the TV and the device must be Wi-Fi Certified Miracast™ devices and have Miracast switched on.

Wi-Fi Certified Miracast™

device. With

Play videos

To play a video, select video and press OK. If there are more videos in the same folder, press

to play all videos in this folder.

all

To jump to the next or previous video, press To pause the video, press OK. Press OK again to continue. To make a 10-second jump forward or backward in a video, press  or . To rewind or go fast forward, press  or . Press the keys several times to speed up - 2x, 4x, 8x, 16x, 32x. To stop the video playback, press  (Stop).

Info

To view info on a video (playhead position, duration, title, date, etc.), select the video and press Press again to hide the info.



Videos

in the menu bar, select a



Play



INFO





For more information on Wi-Fi Certified Miracast™ go to

www.wi-fi.org

Wi-Fi®

registered trademarks of the Wi-Fi Alliance.

Miracast™, Miracast

, the Wi-Fi CERTIFIED logo, the Wi-Fi logo are

Wi-Fi CERTIFIED

™ are trademarks of the Wi-Fi Alliance.

Switch on Miracast

The TV comes with Miracast switched On and is ready to show the screen of a device with Miracast.

Switch off Miracast

If you do not want the TV to receive requests for screen sharing from other devices, you can switch off Miracast on the TV.

- Press and select

- Select

press OK.

- Press , repeatedly if necessary, to close the menu.

Network settings

and press OK.

Setup

Wi-Fi Miracast

Off

and

Share a screen on TV

To share the screen of your smartphone, tablet or computer on the TV . . .

1 - Switch on the TV. 2 - On the device, open an application such as Wi-Fi Miracast,

Wi-Fi Direct™, Intel®Wireless Display* or similar and start scanning for other Miracast devices.

3 - In the list of found devices, select the TV and connect. 4 - On the TV, agree to the request to connect to the TV. You

might be asked to enter a PIN code from the device on the TV enter the numbers with the digit keys on the remote control. Alternatively, you might be asked by the TV to enter a PIN code on the device. If you connect, the TV will show the screen of the device. 5 - On the device, select the videos, photos or files you want to watch on TV.

* Miracast is supported by WiDi 3.5 onwards.

Stop sharing

If you want to block a device that you previously connected, you need to clear the Wi-Fi Miracast connections list first. If you clear this list, you will have to confirm or block the connection for every device again.

Screen delay

The normal delay when sharing a screen with Miracast is about 1 second. The delay might be longer if you are using older devices/computers with less processing power.

Specifics

• Miracast on this TV is subject to the HDCP protocol and cannot display copy-protected premium content sent by a device.

• The maximum video resolution supported is 720p.

From the device

With the application you use to start Miracast, you can disconnect and stop watching the screen of the device on TV. The TV will switch back to the last selected programme.

From the TV

To stop watching the screen of the device on TV, you can . . .

• press  to watch a TV broadcast

• press to start another activity on TV

• press connected device.



SOURCES

to open the Sources menu and select a

Block a device

The first time you receive a request to connect from a device, you can block the device. This request, and all requests in the future, from this device, will be ignored. To block a device, select press OK.

Unblock all devices

Block . . .

in the request window and

All previously connected and blocked devices are stored in the Wi-Fi Miracast list of connections. If you clear this list, all blocked devices will be unblocked.

To unblock all blocked devices . . .

1 - Press and select 2 - Select 3 - Press OK to clear the list. 4 - Press , repeatedly if necessary, to close the menu.

Blocking a previously connected device

Network settings

and press OK.

Setup

Reset Wi-Fi direct group

Pause TV

You can pause a TV broadcast and resume watching it later. Only digital TV channels can be paused. You must connect a USB Hard Drive to buffer the broadcast. You can pause a broadcast for a maximum time span of 90 minutes. For more information, press

Hard Drive



Keywords

and look up

USB

Pause or resume a broadcast

To pause a broadcast, press  (Pause). A progress bar appears briefly on screen. To call up the progress bar, press  (Pause) again. To resume watching, press  (Play). The icon on screen indicates you are watching a paused broadcast.

Back to the actual TV broadcast

To switch back to the actual TV broadcast, press  (Stop). The moment you switch to a digital channel, the USB Hard

Drive starts buffering the broadcast. When you switch to another digital channel, the broadcast of the new channel is buffered and the broadcast of the former channel is cleared. When you switch to a connected device (a Blu-ray Disc player or digital receiver) the USB Hard Drive stops buffering and the broadcast is cleared. Also when you switch the TV to standby the broadcast is cleared.

Whilst recording a programme on the USB Hard Drive, you cannot pause a broadcast.

Instant replay

Whilst watching a broadcast from a digital TV channel, you can easily instant replay the broadcast. To replay the last 10 seconds of a broadcast, press  (Pause) and press  (Left). You can press  repeatedly until you reach the start of the broadcast buffer or the maximum time span.

Progress bar

With the progress bar on screen, press  (Rewind) or press

(Forward) to select from where you want to start viewing



the paused broadcast. Press these keys repeatedly to change speed.

Specifics

• The Audio Description audio (commentary) for the visually impaired is not available for playback in Pause TV or Recording.

• You can buffer the digital (DVB) subtitles of a channel. You cannot buffer subtitles that come from Text services. To check if digital (DVB) subtitles are available, tune to the TV channel and press select only buffer a subtitle language preceded by a



OPTIONS

Subtitle language

, select



Options

to open the list of Subtitles. You can

in the menu bar and

icon.

DVB

Recording

the TV guide comes from the Internet, you can select the date at the top of the page and press OK.

17.1

What you need

To record a TV programme you need . . .

• a connected USB Hard Drive formatted on this TV

• digital TV channels installed on this TV (the channels you watch with Watch TV)

• to receive channel information for the built-in TV guide (from the broadcaster or from the Internet)

For more information, press

Hard Drive, installation

17.2



Keywords

and look up

USB

Record a programme

Record now

To record the programme you are watching, press  (Record) on the remote control.

2 - With the programme highlighted, press press



OPTIONS

buffer at the end of the programme. You can add some extra buffer if needed.

3 - Select for recording. A warning will appear / will be shown automatically when overlapping recordings are scheduled. If you plan to record a programme in your absence, remember to leave the TV switched to standby and the USB Hard Drive switched on.

Schedule

and select

and press OK. The programme is scheduled

Record



Record

. The TV adds some time

List of recordings

To view the list of recordings and scheduled recordings, press , select



Recordings

In this list, you can select a recording to watch, remove recorded programmes, adjust the end time of an ongoing recording or check the free disk space. Also in this list, if the TV guide comes from the Internet, you can schedule a recording for which you set the beginning and end time yourself, as a timed recording not linked to a programme. To set a timed recording, select

Schedule recording

the channel, date and time span. To confirm the recording, select

Schedule

and press OK.

at the top of the page and press OK. Set

and press OK.

If you receive TV guide information from the Internet, you can adjust the end time of the recording in the pop-up window before you confirm the recording. If you receive TV guide information from the broadcaster, the recording starts immediately. You can adjust the end time of the recording in the list of recordings. To stop recording, press  (Stop).

Schedule a recording

You can schedule a recording of an upcoming programme for today or a few days from today (maximum of 8 days away).

1 - To schedule a recording, press On the TV guide page, select the channel and programme you wish to record. You can enter the channel number to jump to the channel in the list. Press  (Right) or  (Left) to scroll through the programmes of a channel. To change the date of the list, press

Select day

. In the list, select the day you want and press OK. If



TV Guide



OPTIONS

and select

Remove a scheduled recording

To remove a scheduled recording, select the upcoming recording in the list and press OK. Alternatively, you can select the scheduled recording and press

Cancel recording



OPTIONS

and select

Specifics

• While recording a programme, you can watch a previously recorded programme.

• While recording, you cannot switch TV channels.

• While recording, you cannot pause the TV broadcast.

• To Record, broadcasters need a reliable clock setting. If you reset the TV clock manually, recordings may fail.

• The Audio Description audio (commentary) for the visually impaired cannot be recorded.

• You can record the digital (DVB) subtitles of channel. You cannot record subtitles that come from Text services. To check if digital (DVB) subtitles are available, tune to the TV channel and press and select only record a subtitle language preceded by a



OPTIONS

Subtitle language

, select



OPTIONS

to open the list of Subtitles. You can

in the menu bar

icon.

DVB

17.3

Watch a recording

To watch a recording . . .

1 - Press , select 2 - - In the list, select the recording and press  (Play) to start

the playback. You can use the  (Forward),  (Rewind), (Pause) or  (Stop) keys on the remote control.

Expired recording

Broadcasters can limit the number of days a recording can be viewed. A recording in the list can show the number of days before it expires.

Failed recording

When a scheduled recording was prevented by the broadcaster or when the broadcast was interrupted, a recording is marked as

Failed

Delete a recording

To delete a made recording, select the recording in the list, press



OPTIONS

For more information, press

a programme



and select

Recordings

and press OK.

Delete recording



Keywords

and look up



Record

Skype

18.1

About Skype

With

Skype™

You can call and see your friends from anywhere in the world. Talk to your friends while watching them on the big screen of your TV.

18.2

What you need

To make a video call on Skype, you need the separately sold

Philips PTA317

good connection to the Internet. Before you can start Skype, the TV must have a good quality

connection to the Internet. You can connect your TV either wireless or wired. For more information, press

Network, wireless

you can make video calls on your TV for free.

TV camera with a built-in microphone and a



Keywords

and look up

If the TV camera is not connected, Skype will not start.

To sign in to Skype…

1 - Press to open the Home menu. 2 - Select

in page. 3 - Select the Name. To open the on screen keyboard, select the text field and press OK. If you have signed in before, press select your Skype Name. The TV remembers the 5 last Skype Names that signed in.

4 - Select the 5 - When done, select

You are signed in if the Skype menu opens on screen.

Need help?

If you have forgotten your Skype Name or password, or are having problems signing in, please visit www.skype.com/support

and press OK to start Skype and open the Sign

Skype

Skype Name

Password

Skype Name

text field and enter your Skype

text field and enter your password.

and press OK.

and

password



. If you

LIST

and

Skype account

To use Skype, you need to create a Skype account for yourself or for your family. You can create a new account for Skype on your TV or on your computer.

Skype Credit or Skype Subscriptions

With Skype, for a little cost, you can also call phones or mobile phones. Using your computer you can buy Skype Credit or take a Skype subscription at www.skype.com

No emergency calls

Skype is not a replacement for your telephone and cannot be used for emergency calling.

18.3

Start with Skype

Install the camera

Connect the TV camera cable to one of the USB connections on the TV. Bend the small clamp as shown in the illustration below and position the camera on the top of the TV.

Point the camera to the position you usually sit at. When you are making a Skype call, you can pan, tilt or zoom in or out the camera image.

You can position the camera anywhere you want but it is recommended to put it away from the speakers of the TV.

New Skype account

If you don't have a create a new Skype account on your computer. Once you have successfully created the new account, you can use your Skype Name and password to sign in on TV. To create a Skype account on your computer, go to www.skype.com

If you have a remote control with an integrated keyboard or have a USB keyboard connected to the TV, you can create a new Skype account on your TV.

To create a new account on your TV… 1 - On the Skype

press OK.

2 - On the next menu, select 3 - The TV opens the web page of www.skype.com directly.

You can create your new account on this web page. 4 - When Skype confirms that your new account is successfully created, leave the web browser and go back to the of Skype on TV. 5 - Enter your

Skype Name

A Skype Name must begin with a letter, upper or lowercase. It must have 6 to 32 characters and can contain numbers. A Skype Name cannot contain a space.

Password

Your password must have 6 to 20 characters and must at least contain one letter or one number. It cannot contain special characters like a trademark, bullet or euro sign. A Skype

Skype Name

page, select

Skype name

and

Password

Open browser

and

Password

yet, you can

Create a new account

and press OK.

to sign in.

and

page

password cannot contain a space.

If you don't have a Skype Name and Password yet, you can create a new account on the sign in page on TV.

1 - On the sign-in page, select New account and press OK. 2 - Create your new account.

• Full name Enter your full name.

• Skype name Enter a name as your Skype name. Your Skype Name will be shown in the list of contacts of other Skype users. A Skype Name must begin with a letter, upper or lowercase. It must have 6 to 32 characters and can contain numbers. A Skype Name cannot contain a space.

• Password Enter your password. Your password must have 6 to 20 characters and must at least contain one letter or one number. It cannot contain special characters like a trademark, bullet or euro sign. A Skype password cannot contain a space.

• Email Enter your email address. 3 - Read and accept the Skype Terms of Use. 4 - If your new account was accepted, you are signed in.

You can edit or complete your Skype profile on your computer. Start Skype on your computer, sign in with your Skype Name and Password and open your Skype profile. You can change your profile picture, add a mood message or set the privacy settings.

No emergency calls

No emergency calls with Skype

Skype is not a replacement for your telephone and cannot be used for emergency calling.

18.4

Skype menu

When you have signed in successfully, Skype opens the

The Skype menu items are…

•

My profile - your Skype name

To view or modify your Skype profile. Select your and press OK.

•

People

In contacts.

• In number by dialing the number on a dial pad. You must have

Skype Credit

You can't select not connected.

, you can start making a Skype call and manage your

People

Call phones

, you can call a landline or a mobile phone

or a

Skype subscribtion

Call phones

if a camera and microphone are

to call a phone number.

Skype

Skype Name

Microsoft account

If you have a Microsoft account, you can use this account to sign in to Skype on TV.

To sign in with a Microsoft account… 1 - On the Skype

account

2 - Select account sign in web page.

3 - Enter your Microsoft account email and password. 4 - Select the

and press OK.

and press OK. The TV will open the Microsoft

Submit

page, select

button and press OK.

•

History

Contact requests

•

Settings

voicemail settings or view your blocked contacts and much more.

•

Sign out

To sign out of Skype on TV.

, you can view your missed and former calls or view

, you can change your password, set your privacy and

18.5

My profile

•

Public

View or change your profile information that can be viewed by your contacts.

•

Phone

You can enter or change your home, office or mobile phone number here.

•

Private

View or change your email address, check the amount of credit you have or view the subscription information, or write a message that reflects your mood.

, you can edit your personal profile for Skype.

easily find your contact. If you do not know their Skype Name or email, you can also try to look for them by name.

To add a Skype contact…

1 - On the 2 - Select 3 - Enter a

You can also try to enter a name. To open the on screen keyboard, press OK. When you're done, press OK. 4 - Skype will search for the contact you are looking for and will show the search results. 5 - Select the contact you want and press OK to send a contact request. 6 - Write the request and press OK. Skype will send the request message to your new contact. If the contact accepts the request, the Skype Name of the new contact will appear in the your list and you can call your contact on Skype.

Add a phone number

Contacts

Add Skype Contact

Skype Name

page, press

or email address of your new contact.



OPTIONS

and press OK.

•

Profile picture

If you did not upload a profile picture with your computer yet, you can select one of the available avatars as Profile picture here.

•

Online status

You can change your online status. Select the status you want your contacts to see when you are online.

18.6

People

Your contacts

In Your contacts are shown with their

online and available for a Skype call when a green dot is shown next their name.

You can use the text box in the top left corner of the contact page to search for a contact within your contact list. Or, simply scroll down the list to find the contact you want.

, you can find the list of your

People

Skype contacts

Skype Name

. Contacts are

In as a contact. You can call a phone with a Skype voice call. You need Skype Credits to make a phone call.

To add a phone number…

1 - On the 2 - Select 3 - Enter the name of your contact. To open the on screen

keyboard, press OK. When you're done, press OK. 4 - Enter the phone number of your contact. Always start with a country code (e.g. +31 for The Netherlands). Do not use the double zero. When you're done , press OK. The name of your phone number contact will appear in your list.

, the list of your contacts, you can add a phone number

People

Contacts

Add a Phone Number

page, press



OPTIONS

and press OK.

Accept a contact request

When you receive a next to

To accept a contact request…

1 - In the 2 - Select

and press OK. Skype will ask you to accept this contact. If you accept, the contact will appear in your contact list.

History

Skype menu

Contact requests

Contact request

in the

Skype menu

, select

History

and press OK. Select the request

, a small icon will show

and press OK.

Add a contact

Add a Skype contact

In contact.

Add a Skype contact

If you know the Skype Name or email of a friend, Skype can

, the list of your contacts, you can add a new Skype

People

Block a contact

You can unable to contact you on Skype. A blocked contact will not be notified, you will appear as being offline in the contact list of the blocked contact. You can always unblock contacts you have blocked.

To block a contact…

a Skype contact. A blocked contact will be

Block

1 - On the 2 - Press

contact is blocked. To unblock a contact…

1 - Select a contact that is blocked. 2 - Press

contact is unblocked.

Contacts



OPTIONS



OPTIONS

page, select the contact you want to block.

and select

and press OK. The

Block

Unblock

and press OK. The

To mute your microphone, select switch it back on, select 

While you are making a video call, you can change the viewpoint of the camera. For more information on changing the viewpoint, press

Keywords

and look up

Mic On

Skype, camera zoom, pan and tilt



Mic Off

and press OK.

and press OK. To



To view a list of blocked contacts…

1 - In the 2 - Select

contacts you have blocked.

Skype menu

Blocked contacts

, select

Settings

and press OK. The list will show all

and press OK.

Remove or rename

You can To remove a contact… 1 - On the

remove. 2 - Press contact is removed from the list.

To rename a contact… 1 - On the

rename.

2 - Press 3 - Enter the new name for this contact in the text field. To

open the on screen keyboard, press OK. When you're done, press OK.

18.7

Remove



Contacts

OPTIONS

Contacts

OPTIONS

Rename

page, select the contact you want to

contacts.

and select

Remove

Rename

and press OK. The

and press OK.

Calling on Skype

Make a Voice call

Make a switched off.

To make a Voice call…

1 - On the 2 - Select

answers the call, you can talk to your contact. 3 - To end the call, select

A contact can add you to a voice call with more than one participant. You cannot add an extra participant yourself.

Voice call

Call

to call without video, with the camera

Contacts

page, select the contact you want to call.

and press OK. If your contact is on Skype and



End call

and press OK.

Calling phones

With Skype you can also call landline phones and mobile phones. To call phones you need to buy Skype Credit or a Skype subscription.

To call a phone…

1 - On the 2 - Select

available or have a Skype subscription to make a call with a phone number. If your contact answers the phone, you can talk to your contact. 3 - To end the call, select

With Skype, you can also call a phone number directly. You can enter the phone number with the dial pad.

Contacts

Call

page, select a phone number contact.

and press OK. You must have



End call

and press OK.

Skype Credits

Video or voice call

Make a Video call

Make a screen.

To make a Video call…

1 - On the 2 - Select

has a Skype camera connected and answers the call, you can see this person on TV. 3 - To end the call, select

When your Skype camera is switched on, a blue indicator LED lights up. You can check what your contact can see in the small screen on the bottom right of the TV screen.

To switch the Skype camera off, select

Video call

. To switch it back on, select

to call and see your friends on your TV

Contacts

page, select the contact you want to call.

and press OK. If your contact is on Skype,



End call

and press OK.



Video On

Video Off

and press OK.

and press

To open the dial pad…

1 - In the 2 - If the dial pad is not on screen, select

press OK. 3 - Dial the phone number. You can navigate to the numbers and press OK or use the number keys on the remote control.

No emergency calls

Skype is not a replacement for your telephone and cannot be used for emergency calling.

Skype menu

, select

Call phones

and press OK.



Show Dial Pad

and

Receiving a call

When you are signed in to Skype and watching TV, a ringtone and a message on screen will alert you of an incoming call. The message will show who is calling and you can answer or decline the call.

To answer the call, select To answer the call with the camera switched off, select

with audio

and press OK.

Answer with video

and press OK.

Answer

2 - Select 3 - To stop recording, select

Play a Voicemail

A contact can send a voicemail message to you. If a voicemail was sent to you, a small icon will show on the Skype menu. You can play a voicemail from the History page.

To play a voicemail…

and speak your message.

Yes

End call

and press OK.

To decline the call, select

Decline call

and press OK.

History

In the

History

calls you made, including the calls you missed. You can also see new contact requests and listen to voicemails.

To view a list, select

Outgoing calls

To view new contact requests, select press OK.

To view and listen to your voicemails, select press OK.

For how long your Skype events are kept in this history list depends on the amount of contacts you have and how intensively you use Skype.

page of the Skype menu, you will find a list of all

All calls, Missed calls, Incoming calls

and press OK.

Contact requests

Voicemails

and

Voicemail

1 - In the 2 - Select 3 - Select the voicemail you want to play and press OK. You can

listen to a voicemail as many times you want. To manage your voicemails, press

18.8

Skype menu

Voicemails

, select

and press OK.



OPTIONS

History

and press OK.

Skype credit

On Skype, you can buy Skype Credit or take a Skype subscription. With Skype Credit or a Skype subscription available, you can call landline phones and mobile phones with your TV.

Buy Skype Credit

To buy Skype Credit or take a Skype subscription, sign in to Skype on your computer. The Skype Credit you buy will be available when you sign in to Skype on your TV.

The amount of credit or the subscription information is shown on each page where you can make a phone call.

About Voicemail

If someone calls you on Skype and you do not take the call, he or she can leave a spoken message on your you call a contact and they can't take the call, you can send a Skype voicemail to your contact.

To send a voicemail or to receive a voicemail, you - or your contact - must set up Skype voicemail first. You can set up Voicemail on your computer. Go to www.skype.com

When you made voicemail available for you on a computer, set your voicemail preferences in the

Voicemails

Record a Voicemail

When you call a contact and they can't take the call, you can leave a voicemail.

To record a voicemail… 1 - Call a contact. If your call was not answered, Skype will

propose to send a

Voicemail

Skype menu

Skype voicemail

Settings

. If

Skype Credit low

You will be notified if your credit is too low to make a phone call.

18.9

Skype settings

Signing in

You can set Skype to automatically sign in when you select Skype from the Home menu. You do not need to enter your Skype Name or password.

To sign in when Skype starts…

1 - Sign in to Skype with your account. 2 - In the 3 - Select 4 - Press  (right) to select the check box and press OK to

mark

Skype menu

Signing in

Sign me in when Skype starts

, select

Settings

and press OK.

Change password

Blocked contacts

You can change your current Skype password and enter a new password for your Skype account.

To change your password…

1 - Sign in to Skype with your account. 2 - In the 3 - Select 4 - Press  (right) to select

current password. Press OK first if you want to use the on screen keyboard. 5 - Press  (down) to select password. 6 - Press  (down) again to select enter the new password. 7 - Press  (down) again to select password for confirmation.

Skype menu

Change password

, select

Settings

Current password

New password

and press OK.

and enter your

and enter you new

Repeat new password

to send the new

Apply

and re-

Video

You can set Skype to restrict the use of video in Skype calls. With

Automatically receive video from

automatically receive and show video from

my contact list only

With

Show that I have video to

your video to To set the Video settings…

1 - Sign in to Skype with your account. 2 - In the 3 - Select 4 - Press  (right) to select the radio buttons and press OK to

mark or unmark.

Skype menu

Video

or from

People in my contact list only

, select

No one

, you can set Skype to send out

Settings

, you can set Skype to

Anyone, People in

or to

No one

and press OK.

You can view a list of all your Blocked contacts. To view the list…

1 - Sign in to Skype with your account. 2 - In the 3 - Select

blocked contacts, press

Skype menu

Blocked contacts

, select

Settings

and press OK. To manage your



OPTIONS

and press OK.

Voicemail

You can set some preferences for sending voicemails. If you allow a contact to send you a voicemail when you can't

take the call, check the box of

voicemail

receive voicemails. If you allow a contact to send you a voicemail when you can't

answer the call within 15 seconds and you are in another call, check the box of

If you allow a voicemail, when you declined a call, check the box of

To set your preferences for voicemail…

1 - Sign in to Skype with your account. 2 - In the 3 - Select 4 - Press  (down) or  (up) to select a check box. Press

to check or uncheck.

. Leave the box unchecked, if you do not want to

I am already in a call

I decline an incoming call

Skype menu

Voicemail

, select

and press OK.

Send unanswered calls to

Settings

and press OK.

Call forwarding

Never miss a Skype call with

Call Forwarding

Privacy

You can set Skype to restrict incoming Skype calls. You can allow calls from

contact list only

To set the Privacy settings…

1 - Sign in to Skype with your account. 2 - In the 3 - Select 4 - Press  (right) to select the radio buttons and press OK to

mark or unmark.

Skype menu

Privacy

Anyone

, select

or from

Settings

From people in my

and press OK.

If you are not online or can't take the call, you can forward a Skype call to any phone or mobile phone. You can also forward a Skype call to another Skype account. You can set up to three phone numbers or Skype Names in order of preference to forward calls to. You need Skype Credit or a Skype subscription to forward calls to phones. Forwarding Skype calls to other Skype accounts is free of charge. For more information on call forwarding, go to www.skype.com/support

To set up call forwarding…

1 - Sign in to Skype with your account. 2 - In the 3 - Press OK to check the check box for

am not on Skype

4 - In the entry fields below, enter the phone numbers or Skype Names from your contact list in order of preference to forward your calls to. Always add the country code for phone numbers. 5 - Change, if necessary, the amount of seconds before Skype

Skype menu

, select

Settings

and press OK.

Forward calls when I

forwards your call. 6 - Select

to store your

Save

Call Forwarding

setup.

Camera zoom, pan and tilt

You can set the viewpoint of your camera. You can zoom in or out, pan or tilt the camera frame. While you are in a Video call, you can set the camera viewpoint.

To set the camera viewpoint…

18.12

Read the Terms of Use of Skype at www.skype.com/go/tou Also read the Privacy Policy at www.skype.com/go/privacy

1 - Start a 2 - Press  (right) to select the icon above the small screen and

press OK. A bar with colour key functions appears. 3 - To shift (pan) the camera frame, press  (left) or (right). To tilt the camera frame, press  (up) or  (down). To zoom in, press 4 - Press back to your Skype call.

18.10

Video call



Done

and wait until the call is ongoing.



Zoom in

to store the camera viewpoint and to go

. To zoom out, press 



Zoom out

Sign out

When you sign out of Skype, you are signing out your Skype account. Your Online status will change to contacts will not be able to call you.

To sign out… 1 - Press

Skype menu

2 - Select



Sign out

from anywhere within Skype to return to the

Back

in the Skype menu and press OK.

Offline

. Your

The TV will ask you to quit Skype or to use Skype with another Skype account.

18.11

Quit Skype

When you sign out of Skype, the Skype application on TV is still active. Another Skype account can sign in or you can create a new account. To stop the Skype application on TV, you must quit Skype.

Smart TV

19.1

About Smart TV

1 - Switch on Smart TV parental control by selecting then press OK.

2 - Enter an unlock PIN code of your choice. 3 - Confirm your PIN code.

Adult 18+ rated apps are now locked. To open a locked app, select the app and press OK. The TV will ask you to enter your 4-digit code.

Enable

and

Connect this a new world of television. You can make a wired connection to your router or you can link up wirelessly with Wi-Fi.

With the TV connected to your home network, a smartphone can show a photo on TV, you can play videos stored on your computer or control the TV with your tablet.

With your TV connected to the Internet, you can watch a rental video from an online video store, read the online TV guide or record your favourite TV show on a USB Hard Drive. The Smart TV Apps add to the fun with all sorts of entertainment and convenient services.

19.2

Philips Smart LED TV

to the Internet and discover

What you need

To enjoy with a high-speed (broadband) connection to the Internet. You can use a home network connected to the Internet. You do not need a computer.

For more information, press up

Tip

To enter text or to navigate an Internet page more easily, you can consider to connect a USB keyboard and a USB mouse to the TV. For more information, press

keyboard

Smart TV Apps

Network

USB mouse

you must connect the TV to a router



Keywords

and look

and look up

USB

19.4

Smart TV Apps

Open Smart TV

The Smart TV start page is your link to the Internet. You can rent movies online, read newspapers, watch videos and listen to music, also shop online, open your social network page (Facebook, Twitter, . . .) or watch TV programmes when it suits you with Online TV. To do this, you open Apps - Internet sites which are tailored for TV. With your TV connected to the Internet, you can open Smart TV.

Open Smart TV

To open the Smart TV start page, press Alternatively, you can press , select

The TV connects to the Internet and opens the Smart TV start page. This may take a few seconds.

Close Smart TV

To close the Smart TV start page, press and select another activity.

TP Vision Europe B.V. bears no responsibility regarding the content and the quality of the content provided by the content service providers.

Smart TV start page



Smart TV

and press OK.

19.3

Setup Smart TV

The first time you open Smart TV, you need to configure your connection. Read and agree to the terms and conditions to continue. If you do not want to set up Smart TV, press .

To register with Club Philips . . .

1 - Select 2 - Enter your email address, select 3 - Confirm the email address.

Parental control

To lock Adult 18+ rated apps . . .

and press OK.

Continue

and press OK.

1 - Now on your TV 2 - Your Apps 3 - App gallery 4 - Internet 5 - Recommended Apps 6 - Search 7 - Colour keys for control

Your Apps

You start Apps from the Smart TV start page. If the start page does not hold any Apps yet, you can add Apps from the App gallery.

App gallery

In the App gallery you find all available Apps.

Internet

The Internet App opens the World Wide Web on your TV. On your TV, you can view any Internet website but most of them are not tailored for a TV screen.

- Some plug-ins (e.g. to view pages or videos) are not available on your TV.

- Internet pages are shown one page at a time and full screen.

Recommended Apps

In this window, Philips presents a range of recommended Apps for your country, Apps for Online TV or a selection of rental movies from Video stores. You can select and open them from the Recommended Apps window.

With Search, you can search the App gallery for relevant Apps. Enter a keyword in the text field, select  and press OK to start searching. You can enter names, titles, genres and description keywords to search. Alternatively, you can leave the text field empty and search for the most popular searches/keywords for a range of categories. In the list of found keywords, select a keyword and press OK to search for items with that keyword.

Open an App

To open an App, you must add it to your list of Apps in the Smart TV start page first.You can add Apps to your list from the App gallery. The list of your Apps on the Smart TV start page can be several pages long. Use the arrow keys to go to the next or previous page. Alternatively, press page).

Open an App

To open an App . . .

- Press and select

- On the start page, select an App icon and press OK.

In an App, press  to go back 1 step or page.

Close an App

Smart TV

(Next page) or



(Previous

On an App page, press If a lock  is shown next to the loading animation on the bottom of the screen while loading a page, the transfer is secured.

Feedback on an App

Select the App and press like' button and send a suggestion or remark to us. You can also report an App malfunction.

Manage your Apps

In the list of Apps on the Smart TV start page you can . . .

•

Remove an App

To remove an App from the list, select the App icon and press



Remove

•

Move an App

To reposition an App in the list, select the App icon, press



Press OK to confirm the position.

•

Lock an App

To lock an App, select the App icon and press When you lock an App, you must enter the 4 digit PIN code you set for Parental control when you configured Smart TV. In the list, a locked App is marked with a lock . To unlock an App, select the App icon and press You must enter the 4 digit PIN code to unlock.

and use the arrow keys to reposition the App.

Move



OPTIONS



Feedback

. The App is still available in the App gallery.

and select

to select a 'like' or 'don't

Security info



Lock



Unlock

App gallery

Open the collection of tailored websites for TV.

Find the App for YouTube videos, a national newspaper, an online photo album, Facebook, Twitter, etc. There are Apps to rent a video from an online video store and Apps for watching programmes you missed. If the App gallery does not hold what you are looking for, try the World Wide Web and surf the Internet on TV.

App gallery

in Smart TV to browse the Apps, the

To close an App and return to the Smart TV start page, press



Smart TV

Reload an App page

If an App page did not load properly, press select

Zoom

To zoom in on an App page . . .

- Press

- Use the slider bar to set the zoom level.

- Return to normal view by resetting the slider bar.

View security info

You can check the security level of an App page.

to reload the page.

Reload



OPTIONS

and select



Zoom page

OPTIONS

and

Rental video Apps

With the video store Apps in Smart TV, you can rent your favourite movie from an online rental video store. You can pay securely with your credit card.

Rent a movie

1 - Open a Video store App in your list of Apps or select a recommended video on the Smart TV start page.

2 - Select a movie. 3 - Make the online payment. 4 - Start watching. You can use the  (Play) and  (Pause) keys.

Most Video stores ask you to create a login account.

Streaming video

With this TV, you can watch rental movies sent as a streaming video format. You can almost instantly watch the movie. You might need a USB Hard Drive to store some video buffer. If you have a USB Hard Drive connected, you can also download rental movies from video stores that offer movie downloading only. You can pause or restart a downloaded rental movie. Consult the video store regarding the rental duration of rental movies.

Internet traffic

Streaming or downloading many videos may exceed your monthly Internet traffic limit.

Online TV

With the Online TV App on the Smart TV start page*, you can watch TV programmes you missed or watch programmes whenever it suits you best.

Open Online TV

To open the Online TV App . . .

1 - Press 2 - On the start page, select the

3 - Select a programme on the page and press OK to start watching. You can use the  (Play) and  (Pause) keys.

List per broadcaster

To view the Online TV programmes ordered by broadcaster, press Select a broadcaster and press OK.





All broadcasters

Smart TV



Online TV

icon and press

* If available in your region.

19.5

Reset Smart TV

To reset your connection with Smart TV, clear the Internet memory on the TV. You will clear your Philips Smart TV registration and parental rating setting, your video store app logins, all Smart TV app favourites, Internet bookmarks and history.

To clear the Internet memory . . .

- Press and select

- Select

press OK.

Network settings

and press OK.

Setup

Clear Internet memory

and

20.3

Multi room

20.1

About Multi room

With Multi room you can wirelessly send -stream- digital TV channels from another Philips TV to this TV. You can stream any digital TV channel from the other TV, also channels from a subscription smart card. If you can watch the digital channel on the other TV, you can watch it on this one. If you don't have an antenna connection in the room where this TV is, you can use Multi room to watch the digital channels the other TV has to offer.

If the type number of both TVs, end with an eight e.g. (the screen size) standby with this TV. Also, recordings made with the other TV and stored on its connected HDD can be watched on this TV.

Streaming a TV channel with Multi room will reduce the resolution from HD to SD.You cannot stream radio channels (audio only).

20.2

PFLxxx8

What you need

To stream and watch TV channels from another Philips TV, the other TV needs to serve as a TV channel source. Both TVs must be connected to your wireless home network. For more information, press

Network

If the other Philips TV — the source — has a model number that ends with a seven, e.g. (the screen size) the latest software, you're all set. On the other TV, read the Help chapter on update its TV software.

Switch on with Wi-Fi

If the type number of both TVs, end with an eight e.g. (the screen size) standby with this TV. Make sure you switch on the setting

Switch on with Wi-Fi

To switch on Switch on with Wi-Fi . . .

- Press , select

- Select

2 On

If all conditions on both TVs are met, you can use Multi room.

PFLxxx8

Network settings

and press OK.

, you can switch on the other TV if it's in



Keywords

and look up

PFLxxx7

Software update

and it has

, you can switch on the other TV from

on the other TV.

and press OK.

Setup

Switch on with Wi-Fi

and select

Using Multi room

First time use

When you start Multi room for the first time, switch on both TVs.

Once this TV made a connection with the other TV, the other one will appear automatically in the even when it's in standby.

Browse network

Stream a TV channel

With Multi room, you can watch the current TV channel or open the channel list of the other TV. If you select a channel from the list, the other TV will also switch to the channel you selected. If the other TV has a build-in satellite tuner with installed channels or a connected Hard Disc Drive (HDD) with recordings*, you can also watch these on this TV. You cannot switch channels while the other TV is recording, in Pause TV mode or using Skype.

To watch a TV channel from the other TV . . .

- Make sure the other TV is in standby* or switched on.

- On this TV, press

and press OK.

- If the TV is not yet connected to your home network, the

network installation will start automatically. If the TV is already connected, go to step 4.

- In the

TV and press OK. If you have several TVs in your home, you might want to change the name of the other TV. You can do that on the TV itself.

- Select what you want to watch from the other TV . . .

• to watch the current channel of the other TV, select

channel

• to open the channel list of the other TV, select press  (Right).

• to open the satellite channel list of the other TV, select

satellite

• to open the list of recordings* on the other TV, select

recordings

• you can switch channels with switch channels when the other TV is recording, in Pause TV mode or using Skype.

* To switch on the other TV from standby or to watch its recordings from a connected HDD, both TVs must have a type number that ends with an eight, e.g. (screen size)

Browse network

and press OK.

and press  (Right).



SOURCES

menu, select the name of the other



, select

and

Browse network



Current

Watch TV

Watch

. You cannot

PFLxxx8

and

Watch

TV name

To change the TV name . . . Press >

Setup

Network settings

TV network name

Share this…

With the share the channel and programme name you’re watching or share the Internet address of the site you’re on. You can share the title and info of a programme selected in the TV Guide or share the App name and its icon from Smart TV. You can share all these things on Facebook or Twitter or any social network available on your Smart TV App pages.

Your TV must be connected to the Internet. To share what you’re watching or have selected at this

moment…

1 - Press  to open the 2 - Select the social network you want to share on and press

3 - The TV will open the social network website. Depending on what social network you have selected, you can post, send or enter a message.

Share this

 key on the Remote Control, you can

Share this

menu.

MyRemote App

number (E.g. xxPFLxxx4). If the last number is a '4' your TV is a 2009 model. If the last number is a '5' your TV is a 2010 model. A '6' for 2011, a '7' for 2012 and an '8' for 2013.

22.1

About MyRemote App

What this App can do

The MyRemote App and this TV, offer . . .

•

SimplyShare

smartphone or tablet

•

Control

control

•

TV guide

channel you want

•

Wi-Fi smart screen

smartphone or tablet The MyRemote App v4.x is available for iPhone, iPad and

Android™. The MyRemote App functions may vary according to version and operating system of the mobile device.

It's free You can download the MyRemote App for free.

If you want to add the functions Wi-Fi smart screen, a small cost may apply.

Languages

The following languages are available in the MyRemote App : English, German, French, Italian, Spanish, Portuguese, Dutch and Russian. If the language set on your mobile device is not one of these languages, the MyRemote App language is switched to English.

- share photos, music and videos from your

- use your smartphone or tablet as a TV remote

- consult the TV schedule and switch the TV to the

- watch a TV channel on your

22.2

What you need

Home network

Your TV, smartphone, tablet and computer, must be linked up with your home network to enjoy the MyRemote App.

To connect the TV to your home network . . . 1 - Connect your network router to the Internet, if it was not

connected yet (a broadband Internet connection). 2 - Connect the TV to your network router. You can do this wireless or wired.

For more information, press

Network, wireless



Keywords

Network, wired

Media server software

If you want to view your photos or play your music and videos from your computer on the TV, you have to install media server software on your computer. Setup this media server software to share your files on your home network. For more information, press

servers, supported

compatible with the TV.



Keywords

for the list of media server software that is

and look up

Media

The MyRemote App is continually being developed. Future versions will have new functions and will be gradually available. Regularly check the MyRemote App updates on the App stores.

Apple, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.Android is a trademark of Google Inc. Google Play is a trademark of Google Inc.

On other Philips TVs

MyRemote App with other TVs

You can use the MyRemote App on Philips TV models built from 2009 onwards. If your TV is a 2009 model, you need to update the TV software and activate need to activate JointSpace on the TV. TV models from 2011 and onwards are ready to use the MyRemote App.

To know in what year your TV was built, check the TV type

JointSpace

. If you have a 2010 model, you only

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.

To check if DMR is switched on . . .

1 - Press and select 2 - Select 3 - Select 4 - Select On and press OK. 5 - Press , repeatedly if necessary, to close the menu.

Network settings Digital Media Renderer - DMR

Setup

and press OK.

TV network name

If you have more than one TV in your home network, you can rename the TV in Network settings.

button

Select device

You can check the compatibility of MyRemote with your other Philips products at the online support page of your product at www.philips.com/support. Also ensure your Philips product has been updated with the latest software.

at the top right corner of the App menu.

To rename your TV . . .

1 - Press and select 2 - Select 3 - Select

name. You can use the keyboard on the remote control to change the TV network name.

4 - Select 5 - Press , repeatedly if necessary, to close the menu.

22.3

Network settings TV network name

and press OK when ready.

Done

and press OK.

Setup

and press OK.

and press OK to show the current

App download

To download the MyRemote App on your smartphone or tablet, you can use the QR codes on this page. Select the operating system (or device type) you need and use your QR code reader to go to the download page directly.

Apple iPhone

To download the app on your iPhone, go to the Apple App Store and look for the

Apple iPad

To download the app on your iPad, go to the Apple App Store and look for the

Google play

To download the app on your Android device, go to Google play and look for the

Philips MyRemote App

Philips MyRemote HD App

Philips MyRemote App

22.5

App functions

SimplyShare

With

SimplyShare

or videos from a device in your home network to another device in your network.*

To open SimplyShare in the MyRemote app, tap the

SimplyShare

Select a device to send media from

1 - Tap the white bar at the top to open the list of available devices in your network. 2 - Tap a device in the list.

Select a device to play the media

1 - Tap the white bar at the bottom to open the list of available devices in your network. 2 - Tap a device in the list.

Select a media file

Some devices that send files offer them by type of media. If so, you can select the type of media you are looking for -

Videos

1 - Tap the type of media you are looking for. 2 - In the list, tap the song, video or photo to play it on the

device you selected.

Compatible media formats

, you can send media files like photos, music

button in the MyRemote App menu.

Music

Photos

22.4

App menu

From the MyRemote App menu, you can start the different MyRemote App functions. Simply tap a function to open it. To go back to the App menu, tap the App menu button at the top of the page.

Tool tips

To know what the particular buttons of the App do, tap the



To close the Tool tips, tap anywhere on the touchscreen.

Select device

In the MyRemote App menu, you can select the device - e.g. this TV - with which you want to use all the App functions. Tap the

icon. The tool tips appear on top of the available buttons.

A wide range of media formats can be played on your TV. For more information, press

formats

* You can check the compatibility of MyRemote with your specific Philips product at the online support page of your product at www.philips.com/support. Also ensure your Philips product has been upgraded with the latest software.



Keywords

and look up

TV guide

What you need

To view the TV guide of the TV on your smartphone or tablet . . .

• there must be a TV guide with channel and programme information on the TV

• the TV guide information has to come from the Internet

Playback

• the TV guide of the TV must be linked up with the smartphone or tablet

If you have a USB Hard Drive installed on your TV, you can schedule recordings on the TV from your smartphone or tablet.

For more information on the TV guide, press look up

MyRemote recording

To schedule a recording in the TV guide from your smartphone or tablet . . .

• connect and format a USB Hard Drive on your TV

• make sure the setting MyRemote recording is switched on

• before you use the MyRemote recording function, you must switch the TV to standby and back on again

For more information on connecting a USB Hard Drive, press



Setting up

To open the TV guide on your smartphone or tablet, the TV guide must be linked to your mobile device.

Also, first check if the TV guide on your TV is updated from the Internet.

1 - Press and select 2 - Select 3 - Select 4 - Press , repeatedly if necessary, to close the menu.

Link up with the TV

TV guide

Keywords

and look up

Setup TV settings From the Internet

General settings

USB Hard Drive

and press OK.

TV guide



Keywords

and

To open the TV guide, tap the TV guide button on the MyRemote App menu. The first time you tap the TV guide button, you will be asked to link up the tablet and TV, if you did not link up yet.

Schedule a recording

With the MyRemote App you can schedule a recording in the TV guide of the TV.

For more information on Recording, press look up

Recording



Keywords

and

Control

With the turn your smartphone or tablet into a full remote control for your TV.

Tap the player or Home Theatre System) to control. Tap the device icon to show its remote control.

Tap the Control button to select the TV (or Philips Blu-ray Disc player or Home Theatre System) to control.Tap the device icon to show its remote control.

Control

function on the MyRemote App menu, you

button to select the TV (or Philips Blu-ray Disc

To link up your smartphone or tablet with the TV guide of the TV . . .

1 - Press guide on TV. 2 - Press the  (yellow) key to open the list of detected mobile devices. 3 - Select to link up. 4 - On the mobile device, start the MyRemote App and tap the

Setup

5 - Tap the 6 - Enter the code to link up.

The MyRemote recording setting

Make sure this setting is switched on to schedule a recording.

1 - Press and select 2 - Select 3 - Select On and press OK. 4 - Press , repeatedly if necessary, to close the menu.

Using the TV guide

With the TV guide function, you can call up the TV guide of your TV on your smartphone or tablet. You can consult the TV schedule and read programme info. You can tap the programme title to switch the TV to the selected channel directly.



TV GUIDE

Link a mobile device

button on the home menu.

TV guide

Network settings

on the remote control to open the TV

and press OK to view the code

item.

and press OK.

Setup

MyRemote recording

Wi-Fi smart screen

What you need

With the TV channel from your TV on your smartphone or tablet. If you use an Android operating system, you can only view free-to-air TV channels.

What you need

To watch TV on your smartphone or tablet . . .

• you must have digital TV channels installed on your TV (the channels you watch with Watch TV)

• the TV must be switched on

• your home network must be a secured network. Secure your network with

• you must have the setting Press >

Buy Wi-Fi smart screen

How to buy

Tap

Wi-Fi smart screen

WEP, WPA, WPA2

Setup

Network settings

Wi-Fi smart screen

function, you can watch a digital

or set it up using

Wi-Fi smart screen

in the

App menu

switched on.

Wi-Fi smart screen

to open the function.

WPS

If you did not purchase this function yet, you will be asked to buy it online. After the purchase, automatically and you can start watching TV.

Parental rating

Some digital broadcasters have rated their programmes. When the rating is equal or higher than the rating you have set for your child's age, the programme will be locked. You will need a

to unlock and watch the programme.

code

To switch on menu. Switch on age. The parental rating in the MyRemote App is set for watching TV on your smartphone or tablet, not the TV. If you have forgotten your PIN code, you need to reinstall the MyRemote App from the App store. On the purchase page for Wi-Fi smart screen, you can restore your purchase without cost.

Watch a TV channel

To watch a TV channel with the Wi-Fi smart screen function, tap

Wi-Fi smart screen

will show the TV channel currently on TV. If the TV is switched to a connected device, you need to switch the TV back to

Watch TV

available).

Switch TV channels

To switch TV channels, swipe the touchscreen of your smartphone or tablet. Swipe to the right to watch the previous channel or swipe to the left to watch the next channel. The sequence of channels follows the TV channel list. You can also use the channels.

Parental rating

or to

Watch Satellite

in the

Channel bar

Wi-Fi smart screen

, tap the

, set your PIN code and set an

App menu

(if a built-in satellite tuner is

to look for and switch to TV

button on the App

Setup

. Wi-Fi smart screen

opens

screen again.

Tool bar

In the Wi-Fi smart screen tool bar, you can select the picture format, select the TV or Satellite channel list (if available on TV), open the tool tips or switch the TV on standby. To call up the once. The Tool bar appears at the top of the screen, together with the Channel bar. To close the Tool bar and Channel bar, tap the middle of the screen again.

App menu button

To go back to the MyRemote App menu, tap the button.

Scale

To scale the picture to just fit or completely fill the screen, tap the

Scale

TV or Satellite

If you have a built-in satellite tuner in your TV, you can select the channel list of which channel list is currently selected. To change the current channel list, tap the button and tap TV or

Satellite

built-in satellite tuner, there is no selection button.

Tool bar

button to toggle between fill or fit.

Watch TV

to select the channel list you want. If you do not have a

, tap the middle of your touchscreen

Watch satellite

. The button shows

App menu

Pause TV and Recording

If you pause the TV broadcast on TV or start recording a broadcast with the TV (on a connected USB Hard Drive), the Wi-Fi smart screen function will stop.

Sound

The sound that comes with the TV channel is mono sound.

Subtitles

Subtitles on Wi-Fi smart screen are not supported.

Channel bar

To switch to a channel further up or down the TV channel list, you can call up the To call up the once. The Channel bar appears at the bottom of the screen, together with the Channel bar and look for a TV channel. To switch to a TV channel, tap the channel icon once. To close the Channel bar and Tool bar, tap the middle of the

Channel bar

Tool bar

, tap the middle of your touchscreen

at the top. You can swipe the

Channel settings

Settings

23.1

Setup menu

Quick picture settings

With

Quick picture settings

preferences in a few easy steps. The settings you made are stored under the your picture preference if some settings were changed. You can set a preferred picture setting for every TV activity or connected device individually.

To return to your preferred picture setting, while watching a TV channel, press menu bar, select

To set a Quick picture setting . . . 1 - Press , select an activity or a connected device (or its

connection) and press OK.

2 - Press again, select 3 - Select

steps and finish. The activity or connection has your personal preferences.

Picture style



OPTIONS

Picture style

Quick picture settings

you can set your basic picture

Personal

, select Picture and sound in the

and select

and press OK.

Setup

and press OK. Go through the

. You can return to

Personal

In the

Channel settings

preferences or switch on the Universal access for people who are hearing and visually impaired. You can set an age rating to prevent children from watching a rated programme and set or change your Child lock code. You can switch on the Automatic channel update, do a digital reception test or install analogue channels manually.

Languages

Press

Universal access

Press and hearing impaired users settings.

Channel installation

Press

Channel update message

installing analogue channels or connection.

Child lock

Press



Keywords



Keywords



Keywords



Keywords

menu, you can set your language

and look up

Audio language

and look up

Universal access

and look up

Automatic channel update

. Also look up

DVB

Manual installation

to switch the antenna

Child lock

Subtitles

for visually

for

For more information, press  Keywords and look up

style


TV settings

In the

TV settings

Ambilight

a collection of settings like

off timer, Universal access

For more information, press you need

settings. The item

menu you can set all

General settings

Menu language, Sleep timer, Switch

and more.



Keywords

Picture, 3D, Sound

in the menu holds

and look up the topic

and

Search for channels

With

Search for channels

list and possible newly found channels are added to the channel list. You can also do a reinstallation of all channels. A channel update or a channel reinstall may take some time.

Press



Keywords

reinstall

, you can update your current channel

and look up

Channel, update

Channels,

Search for satellite

Press



Keywords

and look up

Satellite settings

Languages

Press

Channel installation

Press

update automatic update options

Child lock

Press



Keywords

and look up



Keywords

Satellite, channel update message

and look up



Keywords

and look up

Connect to network

Press



Keywords

Network, wired

and look up

Satellite, installation

Audio language

Satellite, automatic channel

Satellite, channel lock

Network, wireless

Subtitles

Satellite,

Network settings

Press



Keywords

and look up

Network, settings

3 - Select adjust it.

4 - Press , repeatedly if necessary, to close the menu. To return to the original Picture style values . . .

TV settings

, navigate to the individual setting and

Update software

Press

update



Keywords

Software, USB update

and look up

Software, Internet

Software settings

Press



Keywords

and look up

Software, current version

Watch demo

With

Watch demos

demonstration videos of some of the picture quality features of your TV.

Active control

The TV monitors the incoming picture quality, the level of motion in the picture, brighter or darker scenes and the light conditions in your room. With these values, the TV adjusts the picture for best performance.

in the

menu, you can watch some

Setup

1 - Press and select 2 - Select

style you want to reset. 3 - Press

For more information on adjusting individual picture settings, press

Vivid

If the Picture style is switched back to switch on the TV, the TV location is set to meant for in-store promotion. To set the TV for Home use . . .

1 - Press and select 2 - Select

3 - Select 4 - Press , repeatedly if necessary, to close the menu.



TV settings



Reset

Keywords

TV settings

and press OK.

Home

. The style is reset.

and look up

and press OK.

Setup


and press OK.

General settings

Picture style

every time you

Vivid

Shop

Location

and select the

. A setting

and press

Picture settings

Colour

23.2


Picture style

For easy picture adjustment, you can select a preset setting with

Picture style

1 - While watching a TV channel, press the

Options

2 - Select

style

3 - Select a style and press OK. The available Picture styles are . . .

•

Personal

•

Vivid

•

Natural

•

Movie

•

Energy saving

•

Standard

•


Adjust a Picture style

You can adjust a Picture style . . .

1 - Select the style and press OK. 2 - Press and select



OPTIONS

menu.

Picture and sound

- Your preferences made in Quick picture settings

- Ideal for daylight viewing

- Natural picture settings

- Ideal for watching movies

- Energy-efficient settings

- Factory standard settings

- Ideal for viewing photos

in the menu bar and select

and press OK.

Setup

to open


With picture.

To adjust the colour . . .

1 - Press and select 2 - Select 3 - Press  (right) and adjust the value with  (up)

or  (down). 4 - Press , repeatedly if necessary, to close the menu.

Contrast

With are watching 3D pictures, this setting is switched to

To adjust the contrast . . .

1 - Press and select 2 - Select 3 - Press  (right) and adjust the value with  (up) or

(down). 4 - Press , repeatedly if necessary, to close the menu.

Sharpness

With detail of the picture.

, you can adjust the colour saturation of the

Colour

and press OK.

Setup

TV settings

Contrast

TV settings

Sharpness

, you can adjust the contrast of the picture. If you

Setup

, you can adjust the level of sharpness in fine


and press OK.


Colour

Contrast

3D contrast



To adjust the sharpness . . .

1 - Press and select 2 - Select 3 - Press  (right) and adjust the value with  (up)

or  (down). 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Setup


and press OK.

Sharpness

5 - Press OK to confirm a setting. You can also select one of the presets in this menu. 6 - Press , repeatedly if necessary, to close the menu.

ISF Colour control

Advanced picture settings

Colour settings

Colour enhancement

With

Colour enhancement

intensity and the details in bright colours. To adjust the level . . .

1 - Press and select 2 - Select

Colour enhancement

3 - Press  (right) and select 4 - Press , repeatedly if necessary, to close the menu.

Colour temperature

With colour temperature or select setting yourself with temperature and Custom colour temperature are settings intended for expert users.

To select a preset . . .

1 - Press and select 2 - Select

Colour temperature

3 - Press  (right) and select

Custom

4 - Press , repeatedly if necessary, to close the menu.

Custom colour temperature

TV settings

Maximum, Medium, Minimum

Colour temperature

TV settings

if you want to set a colour temperature yourself.

, you can enhance the colour

and press OK.

Setup

Custom colour temperature

Setup


, you can set the picture to a preset


Advanced

Custom

and press OK.

Normal, Warm

to set a temperature

Advanced

Off

Colour

. Colour

Colour

Cool

. Select

With

Colour control

reproduction of the TV. Colour control is an ISF expert setting. Get the most out of your TV display with ISF® Calibration. You

can ask an ISF calibration expert to come to your home and set the TV to the most optimal picture setting. Additionally the expert can set an ISF Calibration for Ambilight. Ask your dealer for an ISF Calibration of your TV.

The ISF Calibration expert stores and locks the ISF settings as 2 picture styles. Once the ISF Calibration is done, press

OPTIONS

to watch TV during bright light conditions or select dark light conditions. An ISF Calibration can be done on every activity in the Home menu, like Watch TV or a connected Blu-ray Disc player.

Calibration benefits are . . .

• better picture clarity and sharpness

• better detail in bright and dark parts

• deeper and darker blacks• better colour purity and quality

• reduced energy consumption

Expert picture settings

When ISF Day or ISF Night is selected while an ISF Calibration is not yet performed on the TV, some expert picture settings are available.

1 - Press and select 2 - Select

OK Reset picture style settings

To reset a picture style to its original values, select the picture style you want to reset in the OPTIONS menu. Then . . .

1 - Press and select 2 - Select 3 - Select

, select

TV settings

TV settings Reset

, an ISF expert can calibrate the colour

Picture style

and press OK. Select

and press OK.

Setup


ISF expert settings

and press OK.

Setup

, press OK and confirm.




ISF Day

ISF Night

and press

for

With

Custom colour temperature

temperature yourself. To set a Custom colour temperature, first select

Custom

Custom colour temperature menu available. Custom colour temperature is a setting intended for expert users.

To set a custom colour temperature . . .

1 - Press and select 2 - Select

Custom colour temperature

3 - Press  (right). 4 - Select a setting with the arrow keys. (WP is white point and

BL is black level.)

in the

TV settings

Colour temperature

Setup


, you can set a colour

and press OK.

Advanced

setting to make the

Colour

ISF RGB only mode

With

RGB only mode

RGB colours only.

Contrast settings

Contrast modes

With

Contrast modes

consumption can be reduced by dimming the intensity of the screen. Choose for the best power consumption or for the

, an ISF expert can switch the screen to

, you can set the level at which power

picture with the best intensity. To adjust the level . . .

1 - Press and select 2 - Select

Contrast modes

TV settings

3 - Press  (right) and select

Standard

Off

Setup


and press OK.

Advanced

Contrast

Best picture, Best power

4 - Press , repeatedly if necessary, to close the menu.

Dynamic contrast

With

Dynamic contrast

, you can set the level at which the TV automatically enhances the details in the dark, middle and light areas of the picture.

Video contrast

With

Video contrast

, you can decrease the range of the video contrast. If you are watching 3D pictures, this setting is switched to

3D video contrast

. Video contrast and 3D video contrast are

settings intended for expert users. To adjust the level . . .

1 - Press and select 2 - Select

Video contrast

TV settings

3 - Press  (right) and adjust the value with  (up) or

Setup


and press OK.

Advanced

Contrast



(down). 4 - Press , repeatedly if necessary, to close the menu.

To adjust the level . . .

1 - Press and select 2 - Select

Dynamic contrast

TV settings

Setup


and press OK.

Advanced

Contrast

3 - Press  (right) and select

Maximum, Medium, Minimum

Off

4 - Press , repeatedly if necessary, to close the menu.

Perfect contrast

With

Perfect contrast

, you can set the level at which the TV automatically enhances the details in the dark, middle and light areas of the picture.

To adjust the level . . .

1 - Press and select 2 - Select

Perfect contrast

TV settings

Setup


and press OK.

Advanced

Contrast

3 - Press  (right) and select

Maximum, Medium, Minimum

Off

4 - Press , repeatedly if necessary, to close the menu.

Brightness

With

Brightness

, you can set the level of brightness of the picture signal. Brightness is a setting intended for expert users. We recommend non-expert users to adjust the brightness of the picture with the

Contrast

setting.

To adjust the level . . .

1 - Press and select 2 - Select

Brightness

TV settings

Setup


and press OK.

Advanced

Contrast

3 - Press  (right) and adjust the value with  (up) or  (down). 4 - Press , repeatedly if necessary, to close the menu.

Light sensor

The

Light sensor

adjusts the picture and Ambilight settings automatically to the lighting conditions of the room. You can switch Light sensor on or off.

To switch on or off . . .

1 - Press and select 2 - Select

Light sensor

TV settings

3 - Press  (right) and select On or

Setup


and press OK.

Advanced

Off

Contrast

4 - Press , repeatedly if necessary, to close the menu.

• Only for TVs with light sensor function.

Gamma

With

Gamma

, you can set a non-linear setting for picture luminance and contrast. Gamma is a setting intended for expert users.

To adjust the level . . .

1 - Press and select 2 - Select

Gamma

TV settings

Setup


and press OK.

Advanced

Contrast

3 - Press  (right) and adjust the value with  (up) or  (down). 4 - Press , repeatedly if necessary, to close the menu.

Sharpness settings

Super resolution

With

Super resolution

, you switch on a superior sharpness in

line edges and contours. To switch on or off . . .

1 - Press and select 2 - Select

Super resolution

TV settings

3 - Press  (right) and select On or

Setup


and press OK.

Advanced

Off

Sharpness

4 - Press , repeatedly if necessary, to close the menu.

Ultra resolution

With

Ultra resolution

line edges and contours. To switch on or off . . .

1 - Press and select 2 - Select

Ultra resolution

3 - Press  (right) and select On or 4 - Press , repeatedly if necessary, to close the menu.

Noise reduction

TV settings

, you switch on a superior sharpness in

and press OK.

Setup


Advanced

Off

Sharpness

select

Maximum, Medium, Minimum

4 - Press , repeatedly if necessary, to close the menu.

HD Natural Motion

With

HD Natural Motion

visible in movies on TV. Perfect Natural Motion makes any movement smooth and fluent.

To adjust the motion judder . . .

1 - Press and select 2 - Select

Natural Motion

3 - Press  (right) and select 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Maximum, Medium, Minimum

, you can reduce the motion judder,

and press OK.

Setup


Advanced

Off

Motion

With

Noise reduction

image noise. To adjust the noise reduction . . .

1 - Press and select 2 - Select

Noise reduction

3 - Press  (right) and select

Off

4 - Press , repeatedly if necessary, to close the menu.

MPEG artefact reduction

With transitions in the picture. MPEG artefacts are mostly visible as small blocks or jagged edges in images.

To reduce the MPEG artefacts . . .

1 - Press and select 2 - Select

MPEG artefact reduction

3 - Press  (right) and select 4 - Press , repeatedly if necessary, to close the menu.

TV settings

MPEG artefact reduction

TV settings

Maximum, Medium, Minimum

, you can filter out and reduce the level of

and press OK.

Setup


Advanced

Maximum, Medium, Minimum

, you can smoothen the digital

and press OK.

Advanced

Off

Sharpness

Clear LCD

With

Clear LCD

better black level, high contrast with a flicker-free, quiet image and a larger viewing angle.

To switch on or off . . .

1 - Press and select 2 - Select

LCD

3 - Press  (right) and select On or 4 - Press , repeatedly if necessary, to close the menu.

, you switch on a superior motion sharpness,

and press OK.

Setup

TV settings


Advanced

Off

Motion

Clear

Game or computer

You can switch the TV to the ideal picture setting for gaming or for using the TV as a computer monitor. There is a different setting for in the Source menu - Game console or Computer - the TV switches automatically to the ideal setting when you switch to the device. If you switch the setting manually, do not forget to switch it off when you switch to watching TV or another connected device.

Game

Computer

. If a device has a correct type set

Motion settings

Perfect Natural Motion

With

Perfect Natural Motion

judder, visible in movies on TV. Perfect Natural Motion makes any movement smooth and fluent.

To adjust the motion judder . . .

1 - Press and select 2 - Select

Perfect Natural Motion

3 - Press  (right) and

TV settings

, you can reduce the motion

and press OK.

Setup


Advanced

Motion

To switch the setting manually . . .

1 - Press and select 2 - Select 3 - Select

the picture settings for watching TV. 4 - Press , repeatedly if necessary, to close the menu.

TV settings Game, Computer

and press OK.

Setup


Advanced

or TV. The setting TV returns to

Activity style

Location

Sound settings

If the TV is located in a shop, you can set the TV to display an in store promotion banner. The automatically. The automatic

To set the TV to Shop location . . .

1 - Press and select 2 - Select

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

23.3

TV settings

Shop

and press OK.

Picture style

Switch off timer

and press OK.

Setup

General settings

is set to

is switched off.

Location

Vivid

and press

Sound

Sound style

For easy sound adjustment, you can select a preset setting with

Sound style

1 - While watching a TV channel, press the

Options

2 - Select Picture and sound in the menu bar and select

style

3 - Select a Sound style and press OK.



OPTIONS

menu.

to open

Sound

Bass

With To adjust the level . . .

1 - Press and select 2 - Select 3 - Press  (right) and adjust the value with  (up)

or  (down). 4 - Press , repeatedly if necessary, to close the menu.

Treble

With To adjust the level . . .

1 - Press and select 2 - Select 3 - Press  (right) and adjust the value with  (up)

or  (down). 4 - Press , repeatedly if necessary, to close the menu.

Surround mode

, you can adjust the level of low tones in the sound.

Bass

and press OK.

Setup

TV settings

, you can adjust the level of high tones in the sound.

Treble

TV settings

Setup

Sound

and press OK.

Sound

Bass

Treble

The different Sound styles are . . .

•

Personal

and sound

•

Original

•

News

•

Movie

•

Game

•

Music

Adjust a Sound style

You can adjust a Sound style . . .

1 - Select the style and press OK. 2 - Press and select 3 - Select

adjust it. Press  to close the menu to store your setting.

To return to the original Sound style values . . .

- Press and select

- Select

style you want to reset.

- Press

Press sound settings.

- Your personal choices made in Personalise picture

- Factory standard

- Ideal for speech

- Ideal for watching movies

- Ideal for gaming

- Ideal for listening to music

and press OK.

Setup

TV settings



Reset



Keywords

, navigate to the individual setting and

and press OK.

Setup

. The style is reset.

and look up

Sound

Sound style

Sound

and select the

for adjusting individual

With

Surround mode

speakers. If you select TV will switch to you start watching 3D. If you do not want the TV to switch automatically, select

To set the surround mode . . .

1 - Press and select 2 - Select 3 - Press  (right) and select

Incredible surround 3D

4 - Press , repeatedly if necessary, to close the menu.

Auto surround 3D

With switch to Incredible surround 3D when the TV is switched to 3D.

To switch on or off . . .

1 - Press and select 2 - Select 3 - Press  (right) and select On or 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Auto surround 3D

TV settings

, you can set the sound effect of the TV

Incredible surround

Incredible surround 3D

Off

Auto surround 3D

and press OK.

Setup

Sound

, you can block the TV to automatically

Sound

Surround mode

Stereo, Incredible surround

and press OK.

Auto surround 3D

for 2D viewing, the

automatically when

Off

Headphones volume

With

Headphones volume

, you can set the volume of a

connected headphones separately. To adjust the volume . . .

To switch speakers directly . . . 1 - While watching TV, press

and sound

2 - Select

Speakers

and select TV or



OPTIONS

and select

Amplifier

(audio device).

3 - Press , repeatedly if necessary, to close the menu.


1 - Press



OPTIONS

and select

Picture and sound

in the menu bar. 2 - Press  (down) and select

Headphones volume

and press

3 - Press  (up) or  (down) to adjust the volume. 4 - Press , repeatedly if necessary, to close the menu.

Advanced sound settings

Auto volume levelling

With

Auto volume leveling

, you can set the TV to automatically level out sudden volume differences. Typically at the beginning of adverts or when you are switching channels.

To switch on or off . . .

1 - Press and select 2 - Select

leveling

TV settings

3 - Press  (right) and select On or

Setup

Sound

and press OK.

Advanced

Off

Auto volume

4 - Press , repeatedly if necessary, to close the menu.

TV speakers

You can send the TV sound to a connected audio device - a Home Theatre System or audio system. With

TV speakers

, you select where you want to hear the TV sound and how you want to control it.

• If you select

, you permanently switch off the TV speakers.

Off

• If you select On, the TV speakers are always on. With an audio device connected with HDMI CEC, you can use

one of the EasyLink settings.

• If you select

EasyLink

, the TV sends the TV sound to the audio device. The TV will switch off the TV speakers when the device is playing the sound.

• If you select

EasyLink autostart

, the TV will switch on the audio device, send the TV sound to the device and switch off the TV speakers. With

EasyLink

EasyLink autostart

selected, you can still switch to TV speakers or device speakers in the Picture and sound menu.

To set the TV speakers . . .

1 - Press and select 2 - Select

TV settings

3 - Press  (right) and select

EasyLink autostart

Setup

Sound

and press OK.

Advanced

TV speakers

Off, TV speakers, EasyLink

4 - Press , repeatedly if necessary, to close the menu.

Clear sound

With

Clear sound

, you improve the sound for speech. Ideal for news programmes. You can switch the speech improvement on or off.

To switch on or off . . .

1 - Press and select 2 - Select

TV settings

3 - Press  (right) and select On or

Setup

Sound

and press OK.

Advanced

Off

Clear sound

4 - Press , repeatedly if necessary, to close the menu.

HDMI ARC

If you do not need an Audio Return Channel (ARC) on any of the HDMI connections, you can switch the ARC signal off.

For more information, press

ARC



Keywords

and look up

HDMI

Audio Out format

With

Audio Out format

you can set the audio out signal of the TV to fit the sound processing capabilities of your Home Theatre System.

For more information, press

Out format



Keywords

and look up

Audio

Audio Out levelling

With

Audio Out leveling

you can level the sound volume of the Home Theatre System with the volume of the TV when you switch over from one to another.

For more information, press

Out leveling



Keywords

and look up

Audio

Audio Out delay

If you set an Audio sync delay on your Home Theatre System, to synchronise the sound with the picture, you must switch off

on the TV.



Keywords

and look up

Audio

Audio Out delay

For more information, press

Out delay

Audio Out offset

Remove a wireless speaker

If you cannot set a delay on the Home Theatre System, you can set a delay on the TV with

For more information, press

Out offset

Audio Out offset



Keywords

and look up

Audio

Speakers

Wireless speakers

What you need

You can connect a wireless speaker - a subwoofer or a sound bar - to this TV. If you connect a subwoofer, the sound is played on the TV and the subwoofer. If you connect a sound bar the sound is played on the sound bar only.

To get wireless audio on your TV, go to www.philips.com/tv and apply for the adapter a range of selected Philips wireless speaker products can connect and play the TV sound.

Consult the Philips website for suited wireless audio products for this TV.

Select a wireless speaker

When a wireless speaker is paired with the TV, you can select the speaker to play the TV sound in the Settings menu. If you connected several wireless speaker systems, you can switch between the different wireless speakers in the

PTA209 Wireless Audio Adapter

. With this

Speakers

menu.

You can unpair and remove a wireless speaker from the list of paired speakers.

To unpair and remove a wireless speaker…

1 - Press and select 2 - Select 3 - Press  (right) and select 4 - Select the name of the wireless speaker and press  (right). 5 - Select

is removed from the list. 6 - Press , repeatedly if necessary, to close the menu.

Subwoofer settings

If you connect a wireless subwoofer, you can do some additional sound settings.

Volume offset

Compared to the volume of the TV, you can slightly increase or decrease the volume of the subwoofer.

1 - Press and select 2 - Select 3 - Press  (right) and select 4 - Select the name of the wireless speaker and press  (right). 5 - Select

(down) keys to adjust. 6 - Press , repeatedly if necessary, to close the menu.

TV settings

Remove speaker

TV settings

Volume offset

and press OK.

Setup

Sound

and press OK. Use the  (up) and

Sound output

Wireless speaker

and press OK. The wireless speaker

and press OK.

Sound output

Wireless speaker



To select a wireless speaker to play the TV sound…

1 - Press and select 2 - Select 3 - Press  (right) and select 4 - Select the name of the wireless speaker and press OK. The

TV speakers will switch off. If you select a wireless subwoofer the TV speakers stay switched on. 5 - Press , repeatedly if necessary, to close the menu.

To switch to wireless speakers in the

1 - While watching TV, press . 2 - Select

and press OK. 3 - Press , repeatedly if necessary, to close the menu.

For more information on pairing a wireless speaker, press

Keywords

TV settings

Speakers

and look up

and select the name of the wireless speaker

and press OK.

Setup

Sound

Wireless speakers, connect

Sound output

Wireless speaker

Speakers

menu…



Problems

Lost connection

• Position the wireless speaker within a range of 5 meters from the TV.

• Places with a high amount of wireless activity - apartments with lots of wireless routers - can hamper the wireless connection. Keep the router and wireless speaker as close to the TV as possible.

Audio and video mismatch

• There is a audio and video mismatch on the wireless speaker when you switch the your game console or computer has the correct device type set in

Sources

• If you switch off picture settings like or

HD Natural Motion

Home Theatre System

You can send the TV sound to a connected audio device - a Home Theatre System or audio system.

You can select where you want to hear the TV sound and how

Activity style

, the switch is made automatically.

, an audio and video mismatch will occur.

Game

Perfect Natural Motion

Computer

. If

you want to control it.

• If you select

, you permanently switch off the TV speakers.

Off TV speakers

, the TV speakers are always on.

create an Ambilight static colour yourself. First, select the Ambilight style you prefer.

To select an Ambilight style . . .

With an audio device connected with HDMI CEC, you can use one of the EasyLink settings.

• If you select audio device. The TV will switch off the TV speakers when the device is playing the sound.

• If you select audio device, send the TV sound to the device and switch off the TV speakers. With EasyLink or EasyLink autostart selected, you can still switch to TV speakers if necessary.

To set the TV speakers . . .

1 - Press and select 2 - Select 3 - Press  (right) and select

EasyLink autostart

4 - Press , repeatedly if necessary, to close the menu. To switch to speakers directly . . .

1 - While watching TV, press 2 - Select 3 - Press , repeatedly if necessary, to close the menu.

EasyLink

EasyLink autostart

TV settings

Speakers

, the TV sends the TV sound to the

, the TV will switch on the

and press OK.

Setup

and select TV or

Sound

Sound output

Off, TV speakers, EasyLink



Amplifier

(audio system).

TV placement

1 - Press and select 2 - Select 3 - Select one of the preset style or 4 - Press , repeatedly if necessary, to close the menu.

To select a static colour . . .

1 - Press and select 2 - Select

style

3 - Select the colour from the colour palette. Press OK to confirm. 4 - Press , repeatedly if necessary, to close the menu.

Static

TV settings

and press OK.

Setup

Ambilight

Setup

Ambilight

and press OK.

Ambilight style

Off

and press OK.

Ambilight

Ambilight settings

Ambilight brightness

With Ambilight the Ambilight.

To adjust the level . . .

1 - Press and select 2 - Select 3 - Press 4 - Press , repeatedly if necessary, to close the menu.

Brightness

TV settings

and adjust the value with  (up) or  (down).

, you can set the level of brightness of

and press OK.

Setup

Ambilight

Brightness

As part of the first installation, this setting is set to either

TV stand

of the TV since then, adjust this setting accordingly for best sound reproduction.

- Press and select

- Select

press OK.

- Select

- Press , repeatedly if necessary, to close the menu.

23.4

Wall mounted

TV settings

On a TV stand

.If you have changed the placement

and press OK.

Setup

General settings

Wall mounted

TV placement

and press OK.

On a

and

Ambilight

• Only for TVs with Ambilight.

Ambilight style

Ambilight can have a preset mode or a static mode. With preset mode, the TV follows the colours of the image on screen. With

, Ambilight has a constant static colour. You can

Static

Ambilight saturation

With Ambilight the Ambilight.

To adjust the level . . .

1 - Press and select 2 - Select 3 - Press 4 - Press , repeatedly if necessary, to close the menu.

Ambilight+hue

What you need

With

Ambilight+hue

follow the will expand the Ambilight effect across the room. If you don’t have any Philips hue lamps yet, buy the (includes a hue bridge and 3 hue bulbs) and install the bulbs and bridge. You can buy extra Philips hue bulbs separately.

To set up Ambilight+hue on your TV you need…

• a Philips hue bridge

• a few Philips hue bulbs

Saturation

TV settings

and adjust the value with  (up) or  (down).

Ambilight

, you can set the level of saturation of

and press OK.

Setup

Ambilight

, you can set up your

colours of the TV. The Philips hue lamps

Saturation

Philips hue Starter Kit

Philips hue

lamps to

• this TV connected to your home network You can do the complete Ambilight+hue setup on TV and don’t

need the Ambilight+hue App. If you do download the free

Ambilight+hue App

on your smartphone or tablet later, you can use this App to adjust some Ambilight+hue settings.

Configure

Configuration steps

To configure

Philips hue

bulbs as

Ambilight+hue

bulbs, follow the steps on the following pages…

1 - Network 2 - Hue bridge 3 - Hue bulbs 4 - Configure bulb

Network

In this first step, you will prepare the TV to find the

bridge

Philips hue

The TV and the Philips hue bridge must use the same network. Connect the Philips hue bridge to the router — the router of the network the TV is using. Switch on the hue bulbs.

To start the configuration…

1 - Press  (Ambilight) and switch Ambilight On. 2 - Press and select 3 - Select

4 - Select

5 - Select

TV settings

Ambilight+hue

Configure Ambilight+hue

and press OK.

Setup

Ambilight

Ambilight+hue

and press

one step further, select On and press

and press OK. If the TV is connected to your home network, it will start looking for the Philips hue bridge immediately. If the TV is not yet connected to your network, the TV will start the network setup first. You must connect the TV to your home network.

With the TV connected to your network, go to page

bridge

Hue

For more info on connecting the TV to your home network, press



Keywords

and look up

Network, wireless

Hue bridge

In the following step, you will link up the TV with the

bridge

Philips hue

The TV can only be linked up to one hue bridge. To link the hue bridge… 1 - With the TV connected to the network, it will show the

available hue bridges. If the TV did not find your hue bridge yet, you can select

Scan again

If the TV found the only hue bridge you have, select

and press OK.

and press OK. If you have more than one hue bridge available, press  (up) or

(down) to select the hue bridge you want to use and then



select 2 - After you pressed OK, go to the

and press OK.

Philips hue bridge

and press the link button in the middle of the device. This will link the hue bridge with the TV. Do this within 30 seconds. The TV will confirm if a hue bridge is linked to the TV. 3 - On this confirmation, select OK and press OK.

With the Philips hue bridge linked to the TV, go to page

bulbs

Hue

Hue bulbs

In the following step, you will select the

Philips hue bulbs

that have to follow the Ambilight. You can select a maximum of 9 Philips hue bulbs for Ambilight+hue.

To select the bulbs for Ambilight+hue… 1 - In the

Configure Ambilight+hue

menu, select

Hue bulbs

and press OK. 2 - Mark the bulbs that have to follow the Ambilight. To mark a bulb, select the bulb name and press OK. 3 - When you’re done, select the OK button and press OK.

With the bulbs marked for Ambilight+hue, go to page

Configure bulb

In the following step, you will configure each

Philips hue bulb

. To configure each hue bulb… 1 - Select the bulb name in the

Configure Ambilight+hue

menu and press OK. The bulb you selected is blinking. 2 - First indicate where you placed the bulb relative to the TV. A correct setting of the

will send the correct Ambilight

Angle

colour to the bulb. Press  (up) or  (down) to adjust.

3 - Press  (right) to set the distance. 4 - Secondly, indicate the

Distance

between the bulb and the TV. The further away from the TV, the weaker the Ambilight colour. Press  (up) or  (down) to adjust.

5 - Press  (right) to set the brightness. 6 - Finally, set the

Brightness

of the bulb. Press  (up) or



(down) to adjust.

7 - To stop configuring this bulb, select OK and press OK. 8 - In the

Configure Ambilight+hue

menu, you can select every bulb and do the same. 9 - When all Ambilight+hue bulbs are configured, select

Finish

and press OK. Ambilight+hue is ready for use.

You can always change the Ambilight+hue configuration later. To change the configuration, press and select

settings

Immersion

Ambilight

Ambilight+hue

Setup

1 - Press and select 2 - Select

off

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Fade out to off

and press OK.

Setup

Ambilight

Immediate switch off

Advanced

TV switch

With

Immersion

for the Ambilight+hue bulbs. To adjust the Ambilight+hue Immersion…

1 - Press and select 2 - Select

Immersion

3 - Press  (up) or  (down) to adjust. 4 - Press , repeatedly if necessary, to close the menu.

Info

View configuration

Ambilight+hue configuration. Which network you use, how many bulbs are connected, etc.

To view the current Ambilight+hue setup…

1 - Press and select 2 - Select

configuration

3 - Select the item you want to view and press OK. 4 - Press , repeatedly if necessary, to close the menu.

Advanced Ambilight settings

Wall colour

, you can adjust the level of the Ambilight effect

and press OK.

Setup

TV settings

and press OK.

TV settings

and press OK.

, you can consult the current

Ambilight

Setup

Ambilight

Ambilight+hue

and press OK.

Ambilight+hue

View

Lounge light mood

When the TV is on standby, you can switch Ambilight on and create a Lounge light effect in your room.

To switch Ambilight on while the TV is on standby, press (Ambilight).

To change the Lounge light colour range, press (Ambilight) again. To switch off Lounge light, press and hold  (Ambilight) for a few seconds.

You can also set up the colour range in the TV settings menu.

1 - Switch on the TV (out of the Lounge light mode). 2 - Press and select 3 - Select

mood

4 - Select the colour range you prefer. 5 - Press , repeatedly if necessary, to close the menu.

Lounge light+hue

If you installed Ambilight+hue, you can let the hue bulbs follow Lounge light from Ambilight. The Philips hue lamps will expand the Loung light effect across the room. The hue bulbs are switched on and automatically set to follow Lounge light when you configure Ambilight+hue.

To switch the hue bulbs on or off…

TV settings

and press OK.

Setup

Ambilight

and press OK.

Advanced



Lounge light

With

Wall colour

wall on the Ambilight colours. Select the colour of the wall behind the TV and the TV will modify the Ambilight colours to appear as they are intended.

To select the colour of the wall . . .

1 - Press and select 2 - Select 3 - Select the colour sample that matches the colour of the wall

behind the TV and press OK. 4 - Press , repeatedly if necessary, to close the menu.

TV switch off

With immediately or slowly fade out when you switch off the TV. The slow fade out gives you some time to switch on the lights in your living room.

To select the TV switch off . . .

TV settings

TV switch off

, you can neutralise the influence of a coloured

and press OK.

Setup

Ambilight

, you can set Ambilight to switch off

Advanced

Wall colour

1 - Press and select 2 - Select

light+hue

3 - Select On or 4 - Press , repeatedly if necessary, to close the menu.

TV settings

Off

Setup

Ambilight

and press OK.

Advanced

Lounge

ISF for Ambilight

With Ambilight colour next to the ISF picture calibration.

To select the ISF for Ambilight . . .

1 2 3 4

The expert can now set the static colour in the ISF setting in Advanced Ambilight settings.

, you can ask an ISF expert to calibrate a static

ISF

- Press and select

- Select

- Press , repeatedly if necessary, to close the menu.

TV settings

ISF

and press OK.

Setup

Ambilight style

ISF

23.5

Universal access

Switch on

Speakers / Headphones

3 - Select and press OK. 4 - Press , repeatedly if necessary, to close the menu.

Speakers, Headphones

and press OK.

Speakers + headphones

With

Universal access

hearing and visually impaired people.

Switch on

If you did not switch on you can still switch it on in To switch on Universal access . . .

1 - Press and select 2 - Select

and press OK.

3 - Select On and press OK. 4 - Press , repeatedly if necessary, to close the menu.

With Universal access switched on in Setup, the Universal access option is added in the Options menu.

TV settings

switched on, the TV is set for use for

Universal access

Setup

and press OK.

Setup

General settings

during the installation,

Universal access

Hearing impaired

Switch on

Digital TV channels can broadcast special audio commentary describing what is happening on screen. To be able to set the visually impaired audio and effects, you have to switch on Also, before you can switch on Audio description, you have to switch on

Universal access

Audio description

first.

Visually impaired

Mixed volume

You can mix the volume of the normal audio with the audio commentary.

To mix the volume . . . 1 - Press

menu bar.

2 - Select 3 - Use the arrows up and down to set the slider bar. 4 - Press OK to confirm.

Audio effect

Some audio commentary can hold extra audio effects, like stereo or fading sound.

To switch on

1 - Press and select 2 - Select

Audio effects

3 - Select On or 4 - Press , repeatedly if necessary, to close the menu.



OPTIONS

Mixed volume

Audio effects

Channel settings

and press OK.

and select

and press OK.

Setup

and press OK.

Off

Universal access

(if available) . . .

and press OK.

Languages

in the

Audio description

With Audio description, a narrator's commentary is added to the normal audio. To switch on the commentary (if available) . . .

1 - With

OPTIONS

2 - Select 3 - Select On and press OK.

You can check if an audio commentary is available. In the Options menu, select audio language marked with a .

Speakers / Headphones

With to hear the audio commentary. On the TV speakers only, on the headphones only or on both.

To set Speakers / Headphones . . .

1 - Press and select 2 - Select

Universal access

Audio description

Speakers / Headphones

Channel settings

and select the

Setup

switched on, press

Options

tab in the menu bar.

and press OK.

Audio language

, you can select where you want

and press OK.

Languages



and look for an

Audio description

Speech

The audio commentary can also hold subtitles for the words which are spoken.

To switch on these subtitles (if available) . . .

1 - Press and select 2 - Select

Speech

3 - Select 4 - Press , repeatedly if necessary, to close the menu.

Channel settings

and press OK.

Descriptive

and press OK.

Setup

Languages

(audio) or

Subtitles

Audio description

and press OK.

Key beep

the remote control. The volume of the beep is fixed. To switch on Key beep . . .

- Press

- Select

If Universal access does not appear in the Options menu, switch on

gives an audio feedback each time you press a key on



OPTIONS

Key beep

Universal access

, select

Universal access

and select On.

Setup

and press OK.

For more information, press up

Universal access



Keywords

and look

Specifications

24.1

power consumption of this product in use and the average energy consumption for 1 year. You can also find the power consumption values for this product on the Philips website for your country at

www.philips.com/TV

Environmental

Saving energy

The

Eco settings

While you are watching TV channels, press  to open

settings

Active settings are marked with a . You can mark or unmark each setting with the OK key. Press  again to close

Energy saving

This Picture style sets the picture, together with Ambilight, in the most ideal energy conscious setting. For more information, press

style

Screen off

If you only listen to music, you can switch off the TV screen to save energy. Select press any key on the remote control.

Light sensor

To save energy, the built-in ambient light sensor lowers the brightness of the TV screen when the surrounding light darkens. The built-in light sensor automatically adjusts the picture, together with Ambilight, to the lighting conditions of the room.

Screen off

bundle the settings that help the environment.



Keywords

and look up

Eco settings

and press OK. To switch the screen back on,

Eco


Eco-label

Philips continuously focuses on lowering the environmental impact of its innovative consumer products. We aim our efforts towards environmental improvements during manufacturing, reduction of harmful substances, energy-efficient use, end-of-life instructions and product recycling.

Thanks to our environmental effort, this TV has been awarded the

European Ecolabel

You can find detailed information on standby energy consumption, warranty policy, spare parts and recycling of this TV on the Philips website for your country at

– the flower – (www.ecolabel.eu).

www.philips.com

End of use

Disposal of your old product and batteries

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

Switch off timer

If you do not press a key on the remote control during a 4 hour period, or if the TV receives no signal for 10 minutes, the TV switches off automatically to save energy. If you use the TV as a monitor or use a digital receiver to watch TV (a Set-top box - STB) and you do not use the remote control of the TV, deactivate the automatic switch off.

In addition to the Eco settings, your TV also has environmentally friendly technology with regard to power consumption.

Inactive devices off

Switch off connected EasyLink HDMI-CEC (Consumer Electronic Control) compliant devices that are inactive.

European energy label

The

European Energy Label

efficiency class of this product. The greener the energy efficiency class of this product is, the lower the energy it consumes. On the label, you can find the energy efficiency class, the average

informs you on the energy

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC.

Please inform yourself about the local separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste.

Please find out for yourself about the local rules on separate collection of batteries because correct disposal will help to prevent negative consequences for the environment and human health.

24.4

Display

Type

24.2

Reception for non-satellite TVs

• Aerial input : 75 ohm coaxial (IEC75)

• Tuner bands : Hyperband; S-Channel; UHF; VHF

• DVB :

- For model name with PxH: DVB-T (terrestrial, antenna) COFDM 2K/8K; DVB-C (cable) QAM

- For model name with PxT: DVB-T2; DVB-C (cable) QAM

• Analogue video playback : NTSC; SECAM; PAL

• Digital video playback : MPEG2 SD/HD (ISO/IEC 13818-2); MPEG4 SD/HD (ISO/IEC 14496-10)

• Digital audio playback (ISO/IEC 13818-3)

Note: See selected countries on the TV type plate

24.3

Reception for satellite TVs

• Aerial input : 75 ohm coaxial (IEC75)

• Tuner bands : Hyperband, S-Channel, UHF, VHF

• DVB :

- For model name with PxK: DVB-T (terrestrial, antenna) COFDM 2K/8K; DVB-C (cable) QAM; DVB-S/S2 QPSK, symbol rate 2 to 45M symbols, SCPC and MCPC

- For model name with PxS: DVB-T2; DVB-C (cable) QAM; DVB-S/S2 QPSK, symbol rate 2 to 45M symbols, SCPC and MCPC

• Analogue video playback : NTSC, SECAM, PAL

• Digital video playback : MPEG2 SD/HD (ISO/IEC 13818-2), MPEG4 SD/HD (ISO/IEC 14496-10)

• Digital audio playback (ISO/IEC 13818-3)

• Satellite aerial input : 75 ohm F-type

• Input frequency range : 950 to 2150MHz

• Input level range : 25 to 65 dBm

• Supported satellites : Astra 19.2°E, Astra 23.5°E, Astra 28.2°E, Hotbird 13.0°E, TürkSat 42.0°E, Eutelsat 7°W, Thor 1°W

• Astra HD+ support

• LNB : DiSEqC 1.0, 1 to 4 LNBs supported, Polarity selection 14/18V, Band selection 22kHz, Tone burst mode, LNB current 300mA max

Note: See selected countries on the TV type plate.

• Diagonal screen size :

- 81 cm / 32 inch

- 102 cm / 40 inch

- 107 cm / 42 inch

- 119 cm / 47 inch

- 122 cm / 48 inch

- 127 cm / 50 inch

- 140 cm / 55 inch

- 164 cm / 65 inch

• Display resolution : 1920x1080p

Input resolution for HD/FHD TVs

Video formats

Resolution — Refresh rate

• 480i - 60 Hz

• 480p - 60 Hz

• 576i - 50 Hz

• 576p - 50 Hz

• 720p - 50 Hz, 60 Hz

• 1080i - 50 Hz, 60 Hz

• 1080p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz

Computer formats

Resolutions (amongst others)

• 640 x 480p - 60 Hz

• 800 x 600p - 60 Hz

• 1024 x 768p - 60 Hz

• 1280 x 768p - 60 Hz

• 1360 x 765p - 60 Hz

• 1360 x 768p - 60 Hz

• 1280 x 1024p - 60 Hz

• 1920 x 1080p - 60 Hz

Input resolution for UHD TVs

Video formats

Resolution — Refresh rate

• 480i - 60 Hz

• 480p - 60 Hz

• 576i - 50 Hz

• 576p - 50 Hz

• 720p - 50 Hz, 60 Hz

• 1080i - 50 Hz, 60 Hz

• 1080p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz

• 2160p - 24 Hz, 25 Hz, 30 Hz

Computer formats

Resolutions (amongst others)

• 640 x 480p - 60 Hz

• 800 x 600p - 60 Hz

• 1024 x 768p - 60 Hz

• 1280 x 768p - 60 Hz

• 1360 x 765p - 60 Hz

• 1360 x 768p - 60 Hz

• 1280 x 1024p - 60 Hz

• 1920 x 1080p - 60 Hz

• 3840 X 2160p - 24 Hz, 25 Hz, 30 Hz

Width 1230.6 mm - Height 712 mm - Depth 35.8 mm - Weight ±19.5 kg

• with TV stand: Width 1230.6 mm - Height 772 mm - Depth 280 mm - Weight ±21 kg

65PFx75x9

• without TV stand: Width 1445.9 mm - Height 829.4 mm - Depth 54.5 mm Weight ±25 kg

• with TV stand: Width 1445.9 mm - Height 882.7 mm - Depth 315 mm Weight ±26 kg

24.7

24.5

Power

Product specifications are subject to change without notice. For more specification details of this product, see www.philips.com/support

Power

• Mains power : AC 220-240V +/-10%

• Ambient temperature : 5°C to 35°C

• Standby power consumption : < 0.3W

• Power saving features : Energy saving, Screen off, Light sensor*, Switch off timer, Inactive devices off.

The power rating stated on the product typeplate is the power consumption for this product during normal household use (IEC 62087 Ed.2). The maximum power rating, stated between brackets, is used for electrical safety (IEC 60065 Ed. 7.2).

24.6

Dimensions and weights (7500 series)

42PFx7509

• without TV stand: Width 950 mm - Height 554 mm - Depth 35.8 mm - Weight ±11.5 kg

• with TV stand: Width 950 mm - Height 647 mm - Depth 240 mm - Weight ±12.8 kg

47PFx7509

• without TV stand: Width 1061 mm - Height 616 mm - Depth 35.8 mm - Weight ±13.7 kg

• with TV stand: Width 1061 mm - Height 676 mm - Depth 240 mm - Weight ±15 kg

55PFx7509

• without TV stand:

Dimensions and weights (7100 series)

42PFx7109

• without TV stand: Width 949 mm - Height 551 mm - Depth 53 mm - Weight ±10.8 kg

• with TV stand: Width 949 mm - Height 612 mm - Depth 213 mm - Weight ±12 kg

42PFx7179/7189

• without TV stand: Width 950 mm - Height 554 mm - Depth 35.8 mm - Weight ±11.5 kg

• with TV stand: Width 950 mm - Height 647 mm - Depth 240 mm - Weight ±12.8 kg

42PFx7199

• without TV stand: Width 950 mm - Height 554 mm - Depth 35.8 mm - Weight ±11.5 kg

• with TV stand: Width 950 mm - Height 690 mm - Depth 240 mm - Weight ±14 kg

47PFx7109

• without TV stand: Width 1060 mm - Height 620 mm - Depth 53 mm - Weight ±12.9 kg

• with TV stand: Width 1060 mm - Height 677 mm - Depth 222 mm - Weight ±14.2 kg

47PFx7179/7189

• without TV stand: Width 1061 mm - Height 616 mm - Depth 35.8 mm - Weight ±13.7 kg

• with TV stand: Width 1061 mm - Height 676 mm - Depth 240 mm - Weight ±15 kg

47PFx7199

• without TV stand:

Width 1061 mm - Height 616 mm - Depth 35.8 mm - Weight ±13.7 kg

• with TV stand: Width 1061 mm - Height 676 mm - Depth 240 mm - Weight ±16.4 kg

55PFx7109

• without TV stand: Width 1230.6 mm - Height 716.1 mm - Depth 53.5 mm Weight ±17.4 kg

• with TV stand: Width 1230.6 mm - Height 770 mm - Depth 280 mm - Weight ±18.9 kg

55PFx7179/7189

• without TV stand: Width 1230.6 mm - Height 712 mm - Depth 35.8 mm - Weight ±19.5 kg

• with TV stand: Width 1230.6 mm - Height 772 mm - Depth 280 mm - Weight ±21 kg

55PFx7199

• without TV stand: Width 1230.6 mm - Height 712 mm - Depth 35.8 mm - Weight ±19.5 kg

• with TV stand: Width 1230.6 mm - Height 772 mm - Depth 246 mm - Weight ±22.4 kg

24.8

Dimensions and weights (6600/6700 series)

40PFx6719

• without TV stand: Width 911.3 mm - Height 528 mm - Depth 61.8 mm - Weight ±8.1 kg

• with TV stand: Width 911.3 mm - Height 587.3 mm - Depth 213.1 mm Weight ±9.3 kg

48PFx6719

• without TV stand: Width 1082 mm - Height 625 mm - Depth 57 mm - Weight ±10.8 kg

• with TV stand: Width 1082 mm - Height 683 mm - Depth 223 mm - Weight ±12.2 kg

40PFx6609

• without TV stand: Width 911.3 mm - Height 528 mm - Depth 61.8 mm - Weight ±8.1 kg

• with TV stand: Width 911.3 mm - Height 587.3 mm - Depth 213.1 mm Weight ±9.3 kg

48PFx6609

• without TV stand:

Width 1082 mm - Height 625 mm - Depth 57 mm - Weight ±10.8 kg

• with TV stand: Width 1082 mm - Height 683 mm - Depth 223 mm - Weight ±12.2 kg

55PFx6609

• without TV stand: Width 1230.6 mm - Height 714.8 mm - Depth 53.5 mm Weight ±17.4 kg

• with TV stand: Width 1230.6 mm - Height 774.8 mm - Depth 280 mm Weight ±18.9 kg

65PFx6659

• without TV stand: Width 1445.9 mm - Height 829.4 mm - Depth 54.5 mm Weight ±25 kg

• with TV stand: Width 1445.9 mm - Height 882.7 mm - Depth 315 mm Weight ±26 kg

24.9

Dimensions and weights (6500 series)

32PFx6500

• without TV stand: Width 725.7 mm - Height 429.2 mm - Depth 55.4 mm - Weight ±5.2 kg

• with TV stand: Width 725.7 mm - Height 484.6 mm - Depth 179.4 mm Weight ±6.4 kg

42PFx6500

• without TV stand: Width 957 mm - Height 554.5 mm - Depth 61.8 mm - Weight ±8.6 kg

• with TV stand: Width 957 mm - Height 615.5 mm - Depth 213.1 mm - Weight ±9.8 kg

47PFx6500

• without TV stand: Width 1068 mm - Height 623 mm - Depth 61.8 mm - Weight ±8 kg

• with TV stand: Width 1068 mm - Height 676.8 mm - Depth 222 mm - Weight ±9 kg

55PFx6500

• without TV stand: Width 1230.6 mm - Height 714.8 mm - Depth 53.5 mm Weight ±17.4 kg

• with TV stand: Width 1230.6 mm - Height 774.8 mm - Depth 280 mm Weight ±18.9 kg

24.10

Connectivity for three side connector

TV Rear

• Audio In (DVI to HDMI): Stereo mini-jack 3.5mm

• CVBS: Audio L/R, CVBS in, RGB

• SCART: Audio L/R, CVBS in, RGB

• YPbPr : Y Pb Pr, Audio L/R : Stereo mini-jack 3.5mm

• Digital Audio out: Optical, Toslink

• Network LAN : RJ45

TV Downside

• HDMI in with ARC

• USB 2.0

TV Side

• HDMI in with ARC

• USB 2.0

• Common interface slot: CI+/CAM

• Headphones: Stereo mini-jack 3.5mm

24.11

Connectivity for two side connector

TV Rear

• Audio In (DVI to HDMI): Stereo mini-jack 3.5mm

• CVBS: Audio L/R, CVBS in, RGB

• SCART: Audio L/R, CVBS in, RGB

• YPbPr : Y Pb Pr, Audio L/R : Stereo mini-jack 3.5mm

• Digital Audio out: Optical, Toslink

• Network LAN : RJ45

• HDMI in with ARC

• USB

TV Side

• HDMI in with ARC

• USB 2.0

• Common interface slot: CI+/CAM

• Headphones: Stereo mini-jack 3.5mm

• Containers : 3GP, AVCHD, AVI, MPEG-PS, MPEG-TS, MPEG-4, Matroska (MKV), Quicktime (MOV, M4V, M4A), Windows Media (ASF/WMV/WMA)

• Video Codecs : MPEG-1, MPEG-2, MPEG-4 Part 2, MPEG-4 Part 10 AVC (H264), VC-1, WMV9

• Audio Codecs : AAC, HE-AAC (v1/v2), AMR-NB, Dolby Digital, Dolby Digital Plus, DTS 2.0 + Digital Out™, MPEG-1/2/2.5 Layer I/II/III (includes MP3), WMA (v2 to v9.2), WMA Pro (v9/v10)

• Subtitles : – Formats : SAMI, SubRip (SRT), SubViewer (SUB), MicroDVD (TXT), mplayer2 (TXT), TMPlayer (TXT) – Character encodings : UTF-8, Central Europe and Eastern Europe (Windows-1250), Cyrillic (Windows-1251), Greek (Windows-1253), Turkish (Windows-1254), Western Europe (Windows-1252)

• Image Codecs : JPEG

• Limitations : – Maximum supported total bit rate for a media file is 30Mbps. – Maximum supported video bit rate for a media file is 20Mbps. – MPEG-4 AVC (H.264) is supported up to High Profile @ L4.1. – VC-1 is supported up to Advanced Profile @ L3.

Wi-Fi Certified Miracast™*

This TV supports WiDi 4.x devices.

Supported media server software (DMS)*

• PC - Microsoft Windows XP, Vista or Windows 7 – You can use any DLNA certified® media server software. – Microsoft - Windows Media Player

• Mac OS X – You can use any DLNA certified® media server software.

• Mobile devices – Philips MyRemote - iOS, Android – Interoperability and performance may vary, depending on the capabilities of the mobile device and the software used.

ESD regulations

This apparatus meets performance criteria A for ESD. In case the apparatus does not recover in file sharing mode due to electrostatic discharge, user interference is required.

* Only for Smart TVs.

24.12

Multimedia

Connections

• USB 2.0

• Ethernet LAN RJ-45*

• Wi-Fi 802.11b/g/n (built-in)*

Supported USB file systems

• FAT 16, FAT 32, NTFS

Playback formats

Update from Internet

Software

25.1

Software update

Update from USB

It might be necessary to update the TV software. You need a computer with an high-speed Internet connection and a USB memory device to upload the software on the TV. Use a USB memory device with 256MB free space. Make sure that write protection is switched off.

1 -

Start the update on TV

Press , select Select

Update software

2 -

Identify the TV

Insert the USB memory into one of the USB connections of the TV. Select USB memory device.

3 -

Download the TV software

Insert the USB memory into your computer. On the USB memory device, locate the file double click it. Click on If new software is available, download the .zip file. After the download, unzip the file and copy the file

autorun.upg

Do not place this file in a folder.

4 -

Update the TV software

Insert the USB memory into the TV again. The update starts automatically. The TV switches itself off for 10 seconds and then back on again. Please wait.

Do not . . .

• use the remote control

• remove the USB memory device from the TV If a power cut occurs during the update, never remove the USB

memory device from the TV. When the power returns, the update will continue. At the end of the update, the message

successful

and press  on the remote control.

Do not . . .

• press  twice

• press the power switch on the TV The TV switches itself off (for 10 seconds) and then back on again. Please wait.

and press OK. An identification file is written on the

Start

Send ID

appears on screen. Remove the USB memory device

and press OK.

Setup

and press OK.

USB

update.htm

onto the USB memory device.

Operation

and

If the TV is connected to the Internet, you may receive a message from TP Vision to update the TV software. You need a high-speed (broadband) Internet connection.

If you receive this message, we recommend you carry out the update. Select Update. Follow the instructions on screen.

You can also look for new updates yourself. To look for an update . . .

1 - Press and select 2 - Select

press OK. Follow the instructions on screen. When the update is complete, the TV switches off and back on

again automatically. Wait for the TV to switch itself back on. Do not press the Power switch  on the TV.

25.2

Update software

and press OK.

Setup

TV with Internet

, then

Software version

To view the current TV software version . . .

1 - Press and select 2 - Select 3 - Select 4 - Press , repeatedly if necessary, to close the menu.

25.3

Software settings Current software info

and press OK.

Setup

and press OK.

and see

Release Version.

Open source software

This television contains open source software. TP Vision Europe B.V. hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such offer is requested by the respective licences.

This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain the source code, please write in English to . . .

Intellectual Property Dept. TP Vision Europe B.V. Prins Bernhardplein 200 1097 JB Amsterdam The Netherlands

The TV software has been updated. You can use the TV again. To prevent an accidental update of the TV software, delete the autorun.upg file from the USB memory device.

25.4

Open source license

This piece of software is made available under the terms and conditions of the libjpg license, which can be found below. Source: http://www.ijg.org/

Acknowledgements and License Texts for any open source software used in this Philips TV.

This is a document describing the distribution of the source code used on the Philips TV, which fall either under the GNU General Public License (the GPL), or the GNU Lesser General Public License (the LGPL), or any other open source license. Instructions to obtain source code for this software can be found in the user manual.

PHILIPS MAKES NO WARRANTIES WHATSOEVER, EITHER EXPRESS OR IMPLIED, INCLUDING ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS SOFTWARE. Philips offers no support for this software. The preceding does not affect your warranties and statutory rights regarding any Philips product(s) you purchased. It only applies to this source code made available to you.

Freetype (2.4.3) FreeType is a software font engine that is designed to be small, efficient, highly customizable, and portable while capable of producing high-quality output (glyph images). This piece of software is made available under the terms and conditions of the FreeType Project license, which can be found below. Source: http://freetype.sourceforge.net

zlib (1.2.3) The 'zlib' compression library provides in-memory compression and decompression functions, including integrity checks of the uncompressed data. This piece of software is made available under the terms and conditions of the zlib license, which can be found below. Source: http://www.zlib.net/

libmng (1.0.10) libmng -THE reference library for reading, displaying, writing and examining Multiple-Image Network Graphics.MNG is the animation extension to the popular PNG image-format. This piece of software is made available under the terms and conditions of the libmng license, which can be found below. Source: http://sourceforge.net/projects/libmng/files/

u-Boot loader (1.3.4) Used by boot loader and only linked with boot loader, GPL license. This piece of software is made available under the terms and conditions of the u-Boot loader license, which can be found below. Source: http://sourceforge.net/projects/u-boot/files/u-boot/UBoot-1.1.4/u-boot-1.1.4.tar.bz2/download

Libcurl (7.21.7) HTTP client;libcurl is a free and easy-to-use client-side URL transfer library, supporting FTP, FTPS, HTTP, HTTPS, SCP, SFTP, TFTP, TELNET, DICT, LDAP, LDAPS, FILE, IMAP, SMTP, POP3 and RTSP. libcurl supports SSL certificates, HTTP POST, HTTP PUT, FTP uploading, HTTP form based upload, proxies, cookies, user+password authentication (Basic, Digest, NTLM, Negotiate, Kerberos4), file transfer resume, http proxy tunneling and more! This piece of software is made available under the terms and conditions of the Libcurl license, which can be found below. Source: http://curl.haxx.se/

c-ares (1.7.4) c-ares is a C library that performs DNS requests and name resolves asynchronously. This piece of software is made available under the terms and conditions of the c-ares license, which can be found below. Source: http://c-ares.haxx.se/c-ares-1.7.1.tar.gz

Fraunhofer AAC Ecnoder (3.3.3) AAC Ecnoder. Source: Android JB source code

unicode (3.2) This library is used to perform UNICODE string manipulation. This piece of software is made available under the terms and conditions of the ICU license, which can be found below. Source: http://www.icu-project.org/

libpng (1.2.43) PNG decoder. This piece of software is made available under the terms and conditions of the libpng license, which can be found below. Source: http://www.libpng.org/pub/png/libpng.html

libjpg (6b) This library is used to perform JPEG decoding tasks.

openssl (1.0.0d) OpenSSL is an open source implementation of the SSL and TLS protocols. The core library (written in the C programming language) implements the basic cryptographic functions and provides various utility functions. Wrappers allowing the use of the OpenSSL library in a variety of computer languages are available. This piece of software is made available under the terms and conditions of the 1.7.4 license, which can be found below. Source: http://www.openssl.org/source/openssl-1.0.0.tar.gz

Expat (2.01) xml paser; Expat is an XML parser library written in C. It is a stream-oriented parser in which an application registers handlers for things the parser might find in the XML document (like start tags). An introductory article on using. This piece of software is made available under the terms and conditions of the Expat license, which can be found below.

Source: http://expat.sourceforge.net/

DirectFB include SAWMAN (1.4.0) It is a software library for GNU/Linux/UNIX based operating system with a small memory footprint that provides graphics acceleration, input device handling and abstraction layer, and integrated windowing system with support for translucent windows and multiple display layers on top of the Linux framebuffer without requiring any kernel modifications. This piece of software is made available under the terms and conditions of the DirectFB license, which can be found below. Source: http://sourceforge.net/projects/jointspace/files/remote_a pplications_SDK/remote_spplications_SDK_v1.3.1/DirectFB141_ source_1.3.1.7z/download

SAWMAN SquashFS is a compressed read-only file system for Linux. SquashFS compresses files, inodes and directories, and supports block sizes up to 1 MB for greater compression. SquashFS is also the name of free/open software, licensed under the GPL, for accessing SquashFS filesystems. Source: http://squashfs.sourceforge.net/

Linux Kernel (3.0) The Linux kernel is an operating system kernel used by the Linux family of Unix-like operating systems. This piece of software is made available under the terms and conditions of the Linux Kernel license, which can be found below. Source: http://www.kernel.org

SQLite (3.7.2) SQLite is a in-process library that implements a self-contained, serverless, zero-configuration, transactional SQL database engine. This piece of software is made available under the terms and conditions of the SQLite license, which can be found below. Source: http://www.sqlite.org/download.html

SquashFS (3.4) SquashFS is a compressed read-only file system for Linux. SquashFS compresses files, inodes and directories, and supports block sizes up to 1 MB for greater compression. SquashFS is also the name of free/open software, licensed under the GPL, for accessing SquashFS filesystems. This piece of software is made available under the terms and conditions of the SquashFS license, which can be found below. Source: http://squashfs.sourceforge.net/

glibc (2.6.1) Any Unix-like operating system needs a C library: the library which defines the ``system calls'' and other basic facilities such as open, malloc, printf, exit...The GNU C library is used as the C library in the GNU system and most systems with the Linux kernel This piece of software is made available under the terms and conditions of the glibc license, which can be found below. Source: http://www.gnu.org/software/libc/

mtd-utils (1) The aim of the system is to make it simple to provide a driver for new hardware, by providing a generic interface between the hardware drivers and the upper layers of the system. Hardware drivers need to know nothing about the storage formats used, such as FTL, FFS2, etc., but will only need to provide simple routines for read, write and erase. Presentation of the device's contents to the user in an appropriate form will be handled by the upper layers of the system. This piece of software is made available under the terms and conditions of the mtd-utils license, which can be found below. Source: http://www.linux-mtd.infradead.org/index.html

libusb (1.0.6) This is the home of libusb, a library that gives user level applications uniform access to USB devices across many different operating systems. libusb is an open source project licensed under the GNU Lesser General Public License version 2.1.Many participants in the libusb community have helped and continue to help with ideas, implementation, support and improvements for libusb. This piece of software is made available under the terms and conditions of the libusb license, which can be found below. Source: http://libusb.wiki.sourceforge.net http://www.libusb.org/

libusb-compat (0.1.3) Library to enable user space application programs to communicate with USB devices. This piece of software is made available under the terms and conditions of the libusb-compat license, which can be found below. Source: http://libusb.wiki.sourceforge.net/LibusbCompat0.1

NTFS-3G Read/Write Driver (2010.5.22) NTFS-3G is an open source cross-platform implementation of the Microsoft Windows NTFS file system with read-write support. NTFS-3G often uses the FUSE file system interface, so it can run unmodified on many different operating systems. It is runnable on Linux, FreeBSD, NetBSD, OpenSolaris, BeOS, QNX, WinCE, Nucleus, VxWorks, Haiku,MorphOS, and Mac OS X It is licensed under either the GNU General Public License or a proprietary license. It is a partial fork of ntfsprogs and is under active maintenance and development. This piece of software is made available under the terms and conditions of the NTFS-3G Read/Write Driver license, which can be found below. Source: http://www.tuxera.com

WPA Supplicant (0.5.10 & 0.6.7) These packages are used to provide WiFi access.The supplier for these tools is Atheros.These pieces of software are made available under the terms and conditions of the GPL v2 license, which can be found below. This piece of software is made available under the terms and conditions of the WPA Supplicant license, which can be found below.

Source: http://hostap.epitest.fi/wpa_supplicant/

ntfsprogs (2.0.0) Some useful tool for ntfs file sytem. This piece of software is made available under the terms and conditions of the ntfsprogs license, which can be found below. Source: http://sourceforge.net/projects/linux-ntfs

fuse (2.8.4) Fuse is a simple interface for userspace programs to export a virtual filesystem to the linux kernel. This piece of software is made available under the terms and conditions of the fuse license, which can be found below. Source: http://fuse.sourceforge.net/

libiconv (1.11.1) This library provides an iconv() implementation, for use on systems which don't have one, or whose implementation cannot convert from/to Unicode. . This piece of software is made available under the terms and conditions of the libiconv license, which can be found below. Source: http://ftp.gnu.org/pub/gnu/libiconv

DM_VERITY. This piece of software is made available under the terms and conditions of the lvm2 license, which can be found below. Source: ftp://sources.redhat.com/pub/lvm2/releases/

encfs (1.3.2) A library provides an encrypted filesystem in user-space. Source: http://www.arg0.net/encfs

boost (1.15.0) A library provides free peer-reviewed portable C++ source libraries is used for encfs. Source: http://www.boost.org

rlog (1.4) A library that provides a flexible message logging facility for C programs and libraries is used for encfs. Source: http://www.arg0.net/rlog

iptables (1.4.15) For Cross connection. Source: http://www.netfilter.org/projects/iptables/

electric-fence (2.1.13) Used for memory corruption detection. This piece of software is made available under the terms and conditions of the electric-fence license, which can be found below. Source: http://perens.com/FreeSoftware/ElectricFence/electricfence_2.1.13-0.1.tar.gz

liveMedia When Wifi Display or streaming RtspPlayer are enabled. This piece of software is made available under the terms and conditions of the electric-fence license, which can be found below. Source: www.live555.com

QT (4.7.0) Netflix skpe besttv pandora picasa? will use QT. This piece of software is made available under the terms and conditions of the QT license, which can be found below. Source: http://qt.nokia.com/

e2fsprogs (1.41.14) e2fsprogs provides the filesystem utilities for use with the ext2 filesystem, it also supports the ext3 and ext4 filesystems. This piece of software is made available under the terms and conditions of the e2fsprogs license, which can be found below. Source: http://e2fsprogs.sourceforge.net/

bash (3.2.48) Bash is the shell, or command language interpreter, that will appear in the GNU operating system. Bash is an sh-compatible shell that incorporates useful features from the Korn shell (ksh) and C shell (csh). It is intended to conform to the IEEE POSIX P1003.2/ISO

9945.2 Shell and Tools standard. It offers functional improvements over sh for both programming and interactive use. In addition, most sh scripts can be run by Bash without modification. Source: http://www.gnu.org/software/bash/

coreutils (6.9) The GNU Core Utilities are the basic file, shell and text manipulation utilities of the GNU operating system. These are the core utilities which are expected to exist on every operating system. Source: http://www.gnu.org/software/coreutils/

findutils (4.2.31) The GNU Find Utilities are the basic directory searching utilities of the GNU operating system. These programs are typically used in conjunction with other programs to provide modular and powerful directory search and file locating capabilities to other commands. Source: http://www.gnu.org/software/findutils/

alsa (1.0.24.1) Advanced Linux Sound Architecture (ALSA). This piece of software is made available under the terms and conditions of the alsa license, which can be found below. Source: http://www.alsa-project.org

lvm2 (2.02.89)

gawk (3.1.5) If you are like many computer users, you would frequently like to make changes in various text files wherever certain patterns appear, or extract data from parts of certain lines while discarding the rest. To write a program to do this in a language such as C or Pascal is a time-consuming inconvenience that may take many lines of

code. The job is easy with awk, especially the GNU implementation: gawk. Source: http://www.gnu.org/software/gawk/

grep (2.5.1a) The grep command searches one or more input files for lines containing a match to a specified pattern. By default, grep prints the matching lines. Source: http://www.gnu.org/software/grep/

gzip (1.3.12) GNU Gzip is a popular data compression program originally written by Jean-loup Gailly for the GNU project. Mark Adler wrote the decompression part. Source: http://www.gnu.org/software/gzip/

inetutils (1.4.2) Inetutils is a collection of common network programs. Source: http://www.gnu.org/software/inetutils/

iputils (s20101006) The iputils package is set of small useful utilities for Linux networking. It was originally maintained by Alexey Kuznetsov. Source: http://www.skbuff.net/iputils/

module-init-tools (3.12) Provides developer documentation for the utilities used by Linux systems to load and manage kernel modules (commonly referred to as "drivers"). Source: https://modules.wiki.kernel.org/index.php/Main_Page

ncurses (5.7) The Ncurses (new curses) library is a free software emulation of curses in System V Release 4.0, and more. It uses Terminfo format, supports pads and color and multiple highlights and forms characters and function-key mapping, and has all the other SYSV-curses enhancements over BSD Curses. Source: http://www.gnu.org/software/ncurses/

Source: http://psmisc.sourceforge.net/

sed (4.1.5) sed (stream editor) isn't an interactive text editor. Instead, it is used to filter text, i.e., it takes text input, performs some operation (or set of operations) on it, and outputs the modified text. sed is typically used for extracting part of a file using pattern matching or substituting multiple occurrences of a string within a file. Source: http://www.gnu.org/software/sed/

tar (1.17) GNU Tar provides the ability to create tar archives, as well as various other kinds of manipulation. For example, you can use Tar on previously created archives to extract files, to store additional files, or to update or list files which were already stored. Source: http://www.gnu.org/software/tar/

util-linux-ng (2.18) Various system utilities. Source: http://userweb.kernel.org/~kzak/util-linux-ng/

udhcpc (0.9.8cvs20050303-3) Udhcpc is a very small?DHCP?client geared towards?embedded systems. Source: http://udhcp.sourcearchive.com/downloads/0.9.8cvs20050303-3/

Libxml2 (2.7.8) The "libxml2" library is used in AstroTV as a support for the execution of NCL application. This library was developed for the GNOME software suite and is available under a "MIT" license. Source: http://www.xmlsoft.org

uriparser (0.7.7) For MPEG-DASH Source: http://uriparser.sourceforge.net/

net-tools (1.6) The Net-tools?package is a collection of programs for controlling the network subsystem of the Linux kernel. Source: http://www.linuxfromscratch.org/blfs/view/6.3/basicnet/n et-tools.html

procps (ps, top) (3.2.8) procps is the package that has a bunch of small useful utilities that give information about processes using the /proc filesystem. The package includes the programs ps, top, vmstat, w, kill, free, slabtop, and skill. Source: http://procps.sourceforge.net/index.html

psmisc (22.13) This PSmisc package is a set of some small useful utilities that use the proc filesystem. We're not about changing the world, but providing the system administrator with some help in common tasks.

xerces-c++ (3.1.1) For MPEG-DASH Source: http://xerces.apache.org/

webp (0.2.1) For Netflix Source: https://code.google.com/p/webp/

wget (1.10.2) GNU Wget is a free software package for retrieving files using HTTP, HTTPS and FTP, the most widely-used Internet protocols. It is a non-interactive commandline tool, so it may easily be called from scripts,?cron?jobs, terminals without X-Windows support, etc. Source: http://ftp.gnu.org/gnu/wget/wget-1.10.2.tar.gz

wireless_tools (0.29)

100

Philips 42PFK7189/12 instructions for use

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents
