Philips 42HF7945D-27B, 32HF5545D-27B, 26HF7945D-27B, 26HF7955H-27B, 26HF7945D User Manual

Philips Commercial Solutions

User Manual

Thank you for choosing Philips.

P

O

T

S

Read your Quick Use Guide and/or
Owner’s Manual first for quick tips
that make using your Philips product
more enjoyable.
If you have read your instructions
and still need assistance,
you may access our online help at
www.philips.com/hospitality

or call
1-866-497-4225
while with your product
(and Model / Serial number)

Need help fast?

26HF5545D
32HF5545D
32HF7945D
26HF7945D
42HF7945D
26HF7955H
32HF7955H

For Customer Use

Enter below the Serial No. which is located on
the rear of the cabinet. Retain this information
for future reference.

Model No. ______________________________
Serial No.

___________________________

Contents

Important Safety Instructions ............ 2

Safety Information and Useful Tips ... 5

Before Calling Service ......................... 6

Basic TV Connections .......................... 8

Antenna Connection ...................................... 8

Mains Connection ........................................... 8

Switching on the TV ....................................... 8

Use and Care of Optional Remote

Controls ................................................ 9

Overview of TV Connectors and

Controls .............................................. 10

Optional Remote Controls ............... 11

RC2888/01 ..................................................... 11

Guest Remote Control Keys ............. 12

Overview of TV Setup Main Menu /

Sub-Menus ........................................... 13

Accessing the Setup Menu ................ 14

Accessing TV Setup Menu using the

Remote Control (RC2573GR) .................. 14

Definitions, Acronyms and

Abbreviations ..................................... 31

USA Limited Warranty .................... 34

Who is covered? ........................................... 34

What is covered? .......................................... 34

What is the period of coverage? ............... 34

What we will do to correct problems? ... 35

What is excluded? ........................................ 35

How to get warranty service in U.S.A.,
Puerto Rico or U.S. Virgin Islands? or

Where can I get more information?......... 36

Cleaning and Care .............................. 37

Environmental Care .......................... 37

Index .................................................... 38

Dolby Digital ....................................... 39

Kensington Security Slot ................... 39

Installation ......................................... 15

A. Selecting the language ............................ 15

B. Selecting your Communication Source

.......................................................................... 15

C. Changing the settings of a channel ...... 15

D. Tuning channels automatically ............. 19

E. Selecting Cable or Antenna mode ...... 19

F. Selecting Virtual or Physical Channel . 19

G. Enabling your current ring .................... 20

H. Setting up the options for Digital

Channels ......................................................... 20

I. Selecting and Configuring thesettings

and options ................................................... 22

Important Safety Instructions
Read before operating equipment

For the quickest and most trouble free

1.
installation, please consult the quick start
guide that came packed in the Television
(or down load it from www.philips.com/
hospitality if you have lost it).

Keep these instructions.

2.

Heed all warnings.

3.

Follow all instructions.

4.

5.

Do not use this TV near water.

6.

Clean only with a dry, soft, non-abrasive
cloth.

7.

Do not block any of the ventilation
openings. Install in accordance with the
manufacturers instructions.

8.

Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.

9.

Do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and third grounding
prong. The wide blade or third prong
are provided for your safety. When
the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.

10.

Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.

Only use attachments/accessories

11.
specified by the manufacturer.

12.
tripod, bracket, or table
specified by the manufacturer,
or sold with the TV. When a cart is
used, use caution when moving the
cart/TV combination to avoid injury from
tip-over.

Unplug this TV during lightning storms

13.
or when unused for long periods of time.

Refer all servicing to qualified service

14.
personnel. Servicing is required when the
TV has been damaged in any way, such as
power-supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into apparatus, the TV has been
exposed to rain or moisture, does not
operate normally, or has been dropped.

This product may contain lead and

15.
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org

Damage Requiring Service - The TV

16.
should be serviced by qualified service
personnel when:

• The power supply cord or the plug
has been damaged; or

• Objects have fallen, or liquid has been
spilled into the TV; or

• The TV has been exposed to rain; or

• The TV does not appear to operate
normally or exhibits a marked change
in performance; or

• The TV has been dropped, or the
enclosure damaged.

Use only with a cart, stand,

2

Important Safety Instructions
Read before operating equipment

Stand, Wall or Ceiling Mounting

17.

- Philips warrantees that this product
is safety tested and UL Certified when
mounted with the enclosed stand
or stands sold by Philips. No such
warrantees are made regarding third
party mounts or stands.

Power Lines - An outdoor antenna

18.
should be located away from power
lines.

Outdoor Antenna Grounding - If

19.
an outside antenna is connected to the
receiver, be sure the antenna system
is grounded so as to provide some
protection against voltage surges and
built up static charges. Section 810 of
the National Electric Code, ANSI/NFPA
No. 70-1984, provides information with
respect to proper grounding of the mast
and supporting structure, grounding of
the lead-in wire to an antenna discharge
unit, size of grounding connectors,
location of antenna-discharge unit,
connection to grounding electrodes,
and requirements for the grounding
electrode. See Figure below.

Object and Liquid Entry - Care

20.
should be taken so that objects do not
fall and liquids are not spilled into the
enclosure through openings.

Battery Usage CAUTION - To

21.
prevent battery leakage that may result
in bodily injury, property damage, or
damage to the unit:

• Install all batteries correctly, with +
and - aligned as marked on the unit

• Do not mix batteries (old and new or
carbon and alkaline, etc.)

• Remove batteries when the unit is
not used for a long time.

3

Important Safety Instructions
Read before operating equipment

Example of America Grounding as per NEC - National Electric Code

Example of America Grounding as per NEC - National Electric Code

ANTENNA LEAD-IN WIRE

GROUND CLAMP

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMPS

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE

POWER SERVICE GROUNDING ELECTRODE
EQUIPMENT (NEC ART 250, PART H)

EQUIPMENT (NEC ART 250, PART H)

ANTENNA LEAD-IN WIRE

ANTENNA DISCHARGE UNIT

ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

(NEC SECTION 810-21)

Know these safety symbols

C A U T I O N

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This “bolt of lightning” indicates material not
insulated within your unit which may cause
an electrical shock.

For the safety of everyone in your property,
please do not remove product covering.

The “exclamation point” calls attention
to features for which you should read
the enclosed literature closely to prevent
operating and maintenance problems.

4

WARNING: To reduce the risk of fire or

electric shock, this appliance should not be
exposed to rain or moisture and objects
filled with liquids, such as vases, should not
be placed on this apparatus.

CAUTION: To prevent electric shock,
match wide blade of plug to wide slot, and
fully insert.

ATTENTION: Pour éviter les chocs
électriques, introduire la lame la plus large
de la fiche dans la bome correspondante de
la prise et pousser jusqu’au fond.

Safety Information and Useful Tips

Ensure the power cord is fully inserted

Two people are required to lift and carry

1.
a TV that weighs more than 55 pounds.
Improper handling of the TV can cause
serious injury.

If you place the TV set on a solid surface.

2.
Ensure the surface is level and that it can
withstand the weight of the TV.

Installing the TV on the wall requires

3.
special skill that should only be
performed by a qualified personnel.
You should not attempt to do the work
yourself. Philips bears no responsibility
for improper mounting or mounting
that results in accident or injury. Make
sure that the wall mount is being fixed
securely enough so that it meets safety
standards.

This TV is compatible with the VESA

4.
wall mounting standard. Please contact
your local electronics supplier for a
VESA compliant bracket to wall mount
this TV. Before you mount your TV on a
wall, ensure the wall is suitable to carry
the weight of the TV.

Do not insert the power plug in the wall

5.
socket before all connections are made.

Do not touch any part of the TV, power

6.
lead, or aerial lead during lightning
storms.

Do not leave the TV in stand-by mode

7.
for an extended period of time. Instead,
disconnect the TV from the mains.

The TV set is always connected to the

8.
mains. Disconnection of the TV set can
be done by:

• unplugging the mains cord located at
the back of TV set, or

• unplugging the mains plug from the
mains socket outlet.
Pull the power lead by the plug - do not
pull on the power lead.

9.
into the TV mains socket and the wall
socket.

If the TV is mounted on a swivel base

10.
or swivel arm, ensure no strain is placed
on the power cord when the TV is
swivelled. Strain on the power cord can
loosen connections and cause arcing or
fire.

Verify that the mains supply voltage in

11.
your location corresponds to the voltage
printed on the sticker at the rear of the
TV.

5

Before Calling Service

If you are experiencing problems, check this list of symptoms and suggested steps to take
before requesting service. You may be able to solve the problem yourself.

Note: Please become familiar with the commercial features as described in TV installation / Setup
because the effects of several of these features, if not thoroughly understood might appear as faulty
operation.

Symptoms Suggested steps to take

Installation


• Check commercial TV setup (TV installation /

TV does not respond
to commands
(volume, channel,
power), or cannot be
turned on (if it is off).
Or cannot be turned
off (if TV is on).

TV turns off by

• TV automatically turns off after approximately
itself.

No Picture• Check that the antenna / cable is connected

•
setup) menu, including power on, volume minimum
/ maximum features. See page 14 and 23.

•
5 minutes when no RF signal is present (unless
POWER ON = FORCED). See page 23.

Check Energy Saving Programmability setting (see

•
ESP) in TV installation / setup. See page 25.

•
properly at the rear of the TV.

Check Tuning Mode setting (Air / Cable).

•

Possible TV station problem. Try another channel.

•

There is picture but

• Try increasing the volume.
no sound

•

Check that the sound is not muted. If it is, press

•
the MUTE button on the remote control to
restore sound.

6

Before Calling Service

Symptoms Suggested steps to take

Display

Uneven color display.• Ensure that the TV is not placed near any speakers

Double image /

• Check antenna, cable or set-top box.•
"ghost" image

•
or magnetic objects.

Snowy / noisy picture• Check antenna, cable and / or setup box

Poor or no picture• Possible electrical interference from appliances or

Sound

Power No power• Ensure that the TV's AC power cord is plugged into

Remote
Control

No Sound• Check if the volume of TV is not at the minimum.

TV does not respond

• Try changing the batteries.
to remote control

•
connections. Ensure that they are properly
connected.

•
other sources.

Check picture adjustments (brightness, contrast,

•
color, tint).

•
Try pressing the Volume + button of the remote
control to increase sound.

Check that the mute mode is not on. If mute mode

•
is on, press the Mute button on the remote control
to deactivate mute mode.

•
the main socket and to your TV. If there is still no
power, disconnect the plug. Wait for 60 seconds
and re-attach plug. Turn on the TV again.

•

Aim remote control directly at remote control

•
sensor lens on TV and try pressing any button on
the remote control.

7

Basic TV Connections

Antenna Connection

Connect the antenna or RF cable signal to
the 75 ohm RF 'F' connector socket located
on the TV.

Mains Connection

Ensure that the mains voltage and frequency
are correct. Please refer to the product
labelling and documentation.

Note:

The power button on the TV does

not disconnect the television from the AC
mains. It toggles the TV between on and
stand-by mode. To completely turn off the
AC mains power, you must unplug the AC
mains plugs from the wall socket.

Switching on the TV

Press the power button on the TV or on
one of the optional remote controls to
switch the TV set on.

Note: If the TV is in commercial mode, it
might not respond to the front panel or the
remote control. Please refer to the section
on TV Installation and TV Setup Menu
in this documentation for more information.

8

Use and Care of Optional Remote Controls

To load batteries into the remote control:

Remove the battery compartment lid

•
from the back of the remote
control.

•

Insert two AA-sized batteries into the
battery compartment, making sure the
positive + and negative - polarity line up
correctly as indicated inside the case.

•

Re-attach the battery compartment lid.

Note: Always remove batteries from the
remote control if it is not used for a long
period of time. This is to prevent damage to
the remote control due to battery leakage.

9

Overview of TV Connectors and Controls

CHANNEL

2DATA

1DATA

8

VGA In

CHANNEL

Warning :

Risk of electric shock. Rear jack panel

•
must be removed by qualified personnel
only.

Do not connect any telephone cables

•
or equipment to Data 1 (RJ12) & Data 2
(RJ45) connectors.

1.

. POWER

To switch the TV on and off. To
disconnect from the mains, remove the
mains cord from the mains socket at the
back of the TV or remove the mains plug
from the wall socket.

- CHANNEL +

2.
To select a channel.

MENU

3.
To display or close menus.

- VOLUME +

4.
To increase or decrease volume.

Data 1 (RJ 12)

5.
For Pay Per View Terminal connection.

Data 2 (RJ 45)

6.
For Smartcard XpressBox connection.

10

8 Ω Speaker

7.
To connect to bathroom speaker (for
7955D model only) and pendant control
(for 7955H model only). A stereo jack
must be used.

VGA In

8.
For PC/Lap-top VGA input.

TV Aerial

9.
To connect to the aerial plug.

Audio Out

10.
To connect to an amplifier with coaxial
digital output.

Audio / Video Inputs

11.
To connect to video camera or
camcorder. Only one video connection
can be used at a time.

HDMI

12.
To connect to peripheral equipment,
including high-definition equipment.

Component Video Inputs/Audio

13.

Inputs

To connect to DVD or decoder which
have the same connectors.

Smart Card Slot

14.
(Applicable to certain models only).
For use with compatible 32 pin smart
card.

Optional Remote Controls

The following remote controls are applicable
to Philips Business Display Solutions TV
products. These can be used for setup and
configuration purposes.

RC2888/01

Guest Mode Remote Control (optional)

RC2573GR is an optional remote control
for Institutional TV / Business Display
Solutions features and Smart Card settings.
It can be purchased separately.

SMART

TEXT

2

56

809

_

POWER

SLEEP

3

GUIDE

CH

A/CH

+

Slide this button
up to enter into

Guest mode.

or

Slide this button
down to enter
into Setup

GUEST

DCM

SETUP

RECALL

CC

1

4

7

RESET

M

mode.

++

VOL CH

__

A

EFG

CLOCK A / V

DBC

11

Guest Remote Control Keys

1

2

3
4
5

6

7

8

9

Source Select

1.
To toggle between available video
sources.

Closed Caption

2.
To activate the Closed Caption function.

Smart Sound

3.
To select the predefined sound settings.

Sleep

4.
To activate the sleep timer. Press
the button repeatedly to increase
countdown time.

10
11

12

13

14

15

16

17

Menu

5.
To call up or exit the menus.

Navigation cursors

6.
To navigate through the menus/
submenus.

Volume + / –

7.
To adjust the TV volume.

0 to 9 Digit keys

8.
To select a TV channel. For a two digit
number, enter the second digit before
the dash disappears.

Alternate Channel

9.
To toggle between the alternate
channels

Channel Guide

10.
To activate the channel guide function.

Standby

11.
Power the TV off or on.

DVD keys (if applicable)

12.

To pause DVD play.

To start DVD playback.

To pause DVD playback.

To fast forward DVD playback

To fast forward DVD playback.

Smart Sound

13.
To select predefined sound settings.

OK

14.
To confirm a selection.

Channel + / –

15.
To select channels.

Mute

16.
To turn off or on sound.

Format

17.
To select TV screen formats.

12

Overview of TV Setup Main Menu / Sub-Menus

SETUP

LANGUAGE

COMMUNICATION

COMMUNICATION

STORE

DCM TYPE

CHANNEL INSTALL

CHANNEL

INPUT

CHANNEL LOGO

DIGITAL

RINGS

LABEL

MUTE

ENGLISH, ESPANOL, FRANCAIS

SP - SPI, SP - I2C, HM -LINK,

SERIAL XPRESS, MULTI RC,

SMART RC, OFF

-

>

GENERIC, NO SOURCE SWITCH

TV 2

TUNER, AV, SVIDEO, CVI, VGA,

HDMI, *CARD CVBS, *CARD-YC,

*CARD CVI

>

NO, YES

(1) (2) (3) (4)

( ) >

NONE, AUDIO, VIDEO

AUTO INSTALL TV

CABLE TUNING

USE CHANNEL TABLE

CURRENT RING

DIGITAL SETUP

CONFIGURATION

START

NO, YES

NO, YES

RING1, RING2, RING3, RING4

CHANNEL SETUP, AUDIO,
DIGITAL CC, EMERGENCY ALERT

SWITCH ON / OSD, PICTURE /
SOUND, SECURITY, CONTROL,
VIDEO ADJUSTMENT, FEATURES,
CC / V-CHIP

* CARD CVBS, CARD-YC, CARD CVI are available on certain models only.

13

Accessing the Setup Menu

The following remote control commands
are applicable to Philips Business Display
Solutions TV products. These can be used
for setup and configuration purposes.

ACCESSING TV SETUP MENU

USING THE REMOTE CONTROL

(RC2573GR)

Slide the button to the Setup location.

1.

SMART

TEXT

2

56

809

POWER

3

GUIDE

CH

SLEEP

GUEST

DCM

SETUP

RECALL

CC

1

4

7

RESET

To scroll through the menu :

1.

Press the

or button on the
remote control. A highlight indicates
that the respective menu item’s setting is
selected for modification.

Press the

2.

to modify the setting of

the selected menu item.

To exit menu, press the

3.
the remote control.

button on

2.

Press the
control to activate the TV Setup Menu.

LANGUAGE ENGLISH

COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

button on the remote

SETUP

14

Installation

A. Selecting the language

You can select ENGLISH, ESPANOL or
FRANCAIS as your preferred language.

Press the > button repeatedly to select

•
your preferred language.

COMMUNICATION SP - SPI

STORE >
DCM TYPE >

COMMUNICATION

LANGUAGE ENGLISH

COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

SETUP

B. Selecting your Communication

Source

There are seven options in the
COMMUNICATION menu which can be
selected by using the < > buttons on the
remote control.

They are SP - SPI, SP - I2C, HM - LINK,

SERIAL XPRESS, MULTI RC, SMART
RC and OFF. The factory default is SP-SPI

and this is correct for most systems.

LANGUAGE ENGLISH

COMMUNICATION >

CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

SETUP

Select SP - SPI, SP - I2C, HM - LINK

•
or SERIAL XPRESS options to
allow you to identify a connection link
between the TV Display and the setup
box.

For SP - SPI and SP - I2C, select

•
GENERIC under DCM TYPE if the
set-top box requires source switch.

As for MULTI RC, select this option

•
to use the specified color code to
correspond to the remote control.

Select SMART RC option to access the

•
SMOOVIE functionality on this TV set.

Proceed to select STORE and store all

•
your selections.

C. Changing the settings of a

channel

This feature allows you to change settings
for a particular channel.

LANGUAGE ENGLISH
COMMUNICATION >

CHANNEL INSTALL >

AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

SETUP

15

Installation

Press the > button to enter into

1.
the CHANNEL INSTALL menu.

LANGUAGE ENGLISH
COMMUNICATION >

CHANNEL INSTALL >

AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

SETUP

• Press the > button to enter into
the CHANNEL INSTALL menu.

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2

INPUT TUNER
CHANNEL LOGO >
DIGITAL NO
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

Selecting an input source

3.

• Select TUNER, AV, SVIDEO, CVI,

VGA, HDMI, CARD-CVBS,
CARD-YC or CARD CVI.
Note : Card-YC, Card CVI, and

Card CVBS are available on certain
models only.

• If TUNER is selected, you can
assign a logo to the channel (refer to
CHANNEL LOGO section below).
You can also access DIGITAL
options (refer to DIGITAL section
on page 18 ).

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2

INPUT TUNER

CHANNEL LOGO >
DIGITAL YES
DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

Assigning a channel logo / text to

4.

the channel

• Press the > button to enter into the
CHANNEL LOGO mode display

Selecting a channel

2.

• Select the channel by using the Digit
0 - 9 buttons.

• For Cable mode, channel selection is
from 01 - 250.

• For Antenna mode, selection of
channel is from 02 - 250.

• In order to input a three digit channel,
the TV must be configured to allow
three digit channel entry. Please see
page 26 under “3 DIGIT ENTRY”
for instructions on how to do this.

16

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER

CHANNEL LOGO >

DIGITAL YES
DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

• Use P + / – to access the available
logo pages and the < > < > buttons
to navigate and select the logo.

Installation

• Press the Digit 0 button on your
remote control to confirm selection.

• You can also choose to input text for
the selected channel. Press Digit 5 on
your remote control to use keyboard

• Use the < > < > buttons to
navigate and select the character and
press Digit 0 to input text. Repeat
step until you have completed your
input of text.

5.

Selecting Digital Channel Options

• If the current channel you are mapping
is a digital or high definition channel,
use the < > buttons to select YES.
Selecting NO will remove the

DIGITAL CH SCROLL, DIGITAL
MAJOR CH and DIGITAL MINOR
CH. Since the channel is not digital,

these options will not appear in the
menu.

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING YES

USE CHANNEL TABLE NO

CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >

DIGITAL YES

DIGITAL CH SCROLL >
RF CHANNEL NUMBER 8
MPEG PROGRAMME NUMBER 2
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >

DIGITAL YES

DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

• If NO is selected in the USE
CHANNEL TABLE (see page 19),

the options for DIGITAL MAJOR
CH and DIGITAL MINOR CH.

are replaced with the options of
RF CHANNEL NUMBER and
MPEG PROGRAM NUMBER.

Scrolling the Digital Channels

6.

• If NO is selected, press the < >
buttons to go the previous or next
digital channel.

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >
DIGITAL YES

DIGITAL CH SCROLL >

DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

17

Installation

Searching the Digital Major

7.

Channels / RF Channel Number

• For DIGITAL MAJOR CH / RF
CHANNEL NUMBER, key in the

channel number (1 to 999) using the
Digit 0 - 9 buttons.

Searching the Digital Minor

8.

Channel / MPEG Program Number

• For DIGITAL MINOR CH / MPEG
PROGRAM NUMBER , use the

Digit 0 - 9 buttons to key in the
channel number (0 to 999).

• Press the < button from Channel 0
to select NO.

• If NO is selected, go back to
DIGITAL MAJOR CH. / RF
CHANNEL NUMBER to enter
one part channel number.

• Use the Digit 0 - 9 buttons to key in
the channel number (1 to 16383).

Selecting your preferred ring

9.
There are four groups of rings. Each ring
comprises a group of channels.

• Press the < > buttons to select
preferred ring. A red dash will appear
beside the selected ring.

• Press the < > buttons to confirm
selection. A “X” will appear
beside the ring.

• Press the
ring mode.

button to save and exit

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >
DIGITAL YES
DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0

RINGS (1X ) ( 2 ) (3 ) (4 )

LABEL ( ) >
MUTE NONE

Naming a channel

10.
You can assign a name to a channel.

• Press the < > buttons to move to
the first character slot. A red dash will
appear.

• Press the < > buttons to key in the
first character.

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >
DIGITAL YES
DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1X ) ( 2 ) (3 ) (4 )

LABEL ( S P O _ )

MUTE NONE

• Press the < > buttons to move to
the next character slot and continue
to key in the next character
(maximum of 8 characters).

• Press the
label mode.

Selecting the Mute Source

11.

button to save and exit

You can choose to mute the Audio or
the Video.

• Press the < > buttons to select
NONE, AUDIO or VIDEO.

18

Installation

CHANNEL INSTALL

CHANNEL INSTALL

CHANNEL TV 2
INPUT TUNER
CHANNEL LOGO >
DIGITAL YES
DIGITAL CH SCROLL >
DIGITAL MAJOR CH 1
DIGITAL MINOR CH 0
RINGS (1X ) ( 2 ) (3 ) (4 )
LABEL ( S P O _ ) >

MUTE AUDIO

D. Tuning channels automatically

Press the > button to enter START

1.
mode.

E. Selecting Cable or Antenna

mode

1.

Select YES to use Cable mode and NO
to use Antenna mode.

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >

CABLE TUNING YES

USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >

AUTO INSTALL TV >

CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

START >

Press the > button again to start

2.

SETUP

AUTO INSTALL TV

automatic installing of channels.
Note : To interrupt automatic installing
of channels, press any button on the
remote control.

F. Selecting Virtual or Physical

Channel

The USE CHANNEL TABLE option
relates to the use of Virtual channels versus
Physical channels.

1.

Select NO to use Physical channel
number as most PPV systems mandate
that the TV use Physical channels.

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING YES

USE CHANNEL TABLE NO

CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

2.

Select YES for a stand alone system
where the channels are tuned and
ordered by their Virtual channel
numbers.

19

Installation

Most HD stations are assigned Physical
channel numbers that differ from their
traditional analog channel numbers.
So the channel you know as Channel 2,
is actually broadcasting its HD signal on
a physical channel unrelated to Channel
2, say 19.1 for example. Selecting YES
will cause the HD broadcast of Channel
2 to appear as Channel 2.1, the virtual
channel instead of the physical location
of the broadcast, 19.1.

G. Enabling your current ring

Four groups of RING are available.

To enable CURRENT RING, select

1.
from RING1 to RING4.

If “SMART RC” is selected under

2.
COMMUNICATION source (see page
15, “Selecting your Communication
Source”), then RING 4 will not be
available.

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE YES

CURRENT RING RING1

DIGITAL SETUP >
CONFIGURATION >

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE YES
CURRENT RING RING1

DIGITAL SETUP >

CONFIGURATION >

RF SETUP

CHANNEL INSTALL

CHANNEL SETUP >

AUDIO >
DIGITAL CC SETUP >
EMERGENCY ALERT >

1.

Setting up the VCHIP / DIGITAL
RATING and FACTORY CH RESET

• Press the > button to enter the
CHANNEL SETUP mode.

CHANNEL _ SETUP

CHANNEL INSTALL

VCHIP / DIGITAL RATING >

FACTORY CH RESET CLEAR ? > >

H. Setting up the options for

Digital Channels

Press the > button to enter the

•
DIGITAL SETUP mode.

20

VCHIP / DIGITAL RATING

allows you to configure and enable
content restrictions on the TV
based upon the VCHIP STANDARD
(see www.fcc.gov/vchip/ for more
information on ratings).

Installation

FACTORY CHANNEL RESET
allows you to clear the digital channel
map. Note : You need to do an
automatic installation after FACTORY
CHANNEL RESET is confirmed.

• Press the < > buttons to select
the item you want to configure.

• Press the < > buttons to select
option.

2.

Selecting the Digital Audio
language

Allows you to select your preferred
digital audio language (English, Spanish or
French).

RF SETUP

CHANNEL INSTALL

CHANNEL SETUP >

AUDIO >

DIGITAL CC SETUP >
EMERGENCY ALERT >

• Press the > button to enter the
AUDIO mode.

• Press the > button to enter the
Preferred Language mode and select
your preferred language.

AUDIO LANGUAGE

CHANNEL INSTALL

ENGLISH SELECTED

SPANISH
FRENCH

Selecting the Digital Closed

3.

Caption options

DIGITAL CLOSED CAPTION
SETUP allows you to select the default

Closed Captioning option and also
configure the digital text / background
properties of digital CC.

RF SETUP

CHANNEL INSTALL

CHANNEL SETUP >
AUDIO >

DIGITAL CC SETUP >

EMERGENCY ALERT >

AUDIO SETUP

CHANNEL INSTALL

PREFERRED LANGUAGE English >

DIGITAL CC

CAPTION OPTION ON

CAPTION TEXT >
CAPTION BACKGROUND

>

21

Installation

• Press the > button to enter the
DIGITAL CC SETUP menu and
select your default Closed Captioning
option and also configure the digital
text / background properties of digital
CC.

Activating the Emergency Alert

4.

Use this option to enable or disable
MEDIUM to LOW alert.

• Press the > button to enter the
EMERGENCY ALERT menu and
select MEDIUM or LOW.

RF SETUP

CHANNEL INSTALL

CHANNEL SETUP >
AUDIO >
DIGITAL CC SETUP >

EMERGENCY ALERT >

• Press the < > buttons to select
MEDIUM or LOW.

• Press the < > buttons to select ON
or OFF.

• Select ON option to enable
EMERGENCY ALERT.
Note : HIGH Emergency Alert
cannot be disabled

I. Selecting and Configuring the

settings and options

In the CONFIGURATION menu, it allows
you to select and configure the settings and
options for :

1.

Switch On / OSD

2.

Picture / Sound

3.

Security

4.

Control

5.

Video Adjustment

6.

Features

7.

CC / V - CHIP

•

Press the > button to enter the

CONFIGURATION menu.

SETUP

CHANNEL INSTALL

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING YES
USE CHANNEL TABLE YES
CURRENT RING RING1
DIGITAL SETUP >

CONFIGURATION >

EMERGENCY ALERT

CHANNEL INSTALL

MEDIUM ON

LOW OFF

22

Press the < > buttons to select the

•
item you want to configure.

Installation

Specifying the configurations when

1.

switching on TV

In the SWITCH ON / OSD menu, it
allows you to select and configure the
settings and options for :
– Welcome Message
– Switch on Channel
– Switch on Volume
– Switch on Picture Format
– Power On
– Volume Indicator
– Channel Display

SWITCH ON / OSD

CHANNEL INSTALL

WELCOME MESSAGE >

SWITCH ON CHANNEL TV 2
SWITCH ON VOLUME 30
SWITCH ON PIC FMT WIDESCREEN
POWER ON LAST STATUS
VOLUME INDICATOR YES
CHANNEL DISPLAY ALL

You can choose to:

– key in a welcome message.
– set a channel which you desire the TV
to always tune to at startup.
– specify the volume setting at startup.
– select your preferred picture format
at startup (4:3, Zoom 14:9, Stretch
4:3, Zoom 16:9, Subtitle Zoom, Wide
screen, Super zoom or Full screen).

– select the status (Last Status, On,
Standby or Forced On) of the TV
when powered on. If FORCED ON
option is selected, the POWER
buttons on the Guest Remote Control
and the TV will be disabled.

– display the volume indicator.

– display the channel number or label
(if any) or both.

2.

Specifying the configurations for TV
PICTURE / SOUND

You can select and configure the settings
and options for Brightness, Color,

Contrast, Sharpness, Tint, Active
Control, Treble, Bass, Balance and
AVL

• Press the > button to enter the
PICTURE / SOUND menu.

CONFIGURATION

CHANNEL INSTALL

SWITCH ON / OSD >

PICTURE / SOUND >

SECURITY >
CONTROL >
VIDEO ADJUSTMENTS >
FEATURES >
CC / V-CHIP >

PICTURE / SOUND

CHANNEL INSTALL

BRIGHTNESS 45

COLOR 38
CONTRAST 70
SHARPNESS 50
TINT 36
ACTIVE CONTROL YES
TREBLE 52
BASS 55
BALANCE 0
AVL ON

• Press the < > buttons to select
the item you want to configure.

• Press the < > buttons to make
adjustments or select option.

23

Installation

Specifying the Security options

3. Note :The default security setting is
In the SECURITY menu, you can
select the option to enable access to the
SETUP menu without a RC2573GR
setup remote control.

CONFIGURATION

CHANNEL INSTALL

SWITCH ON / OSD >
PICTURE / SOUND >

SECURITY >

CONTROL >
VIDEO ADJUSTMENTS >
FEATURES >
CC / V-CHIP >

• Press the > button to enter the
SECURITY menu.

SECURITY

CHANNEL INSTALL

SECURITY STANDARD

KEYBOARD LOCK ALL
REMOTE CONTROL LOCK YES

STANDARD. When security setting
is in STANDARD mode, it may be
vulnerable to unauthorized operations.

• In the KEYBOARD LOCK option,
select YES to lock the TV keyboard
buttons except for the POWER
button. Select ALL to lock all the
TV keyboard buttons

SECURITY

CHANNEL INSTALL

SECURITY STANDARD

KEYBOARD LOCK ALL

REMOTE CONTROL LOCK YES

• In the REMOTE CONTROL
LOCK option, select YES to lock
all the guest remote control buttons.
This feature is particularly suited for
TVs that are used in public areas to
prevent guests with a remote from
changing the station settings in the TV.

• Press the < > buttons to select the
item you want to configure.

• If STANDARD option is selected in
the SECURITY menu, the TV
SETUP menu can be accessed by
entering a special security code
with a guest remote control.
“Contact the Philips Commercial
Solutions Customer Care Center at
[phone] should you require
further assistance.

• If HIGH is selected, the TV setup
menu can be accessed only with an a
RC2573GR setup remote control in
setup mode.

24

SECURITY

CHANNEL INSTALL

SECURITY STANDARD
KEYBOARD LOCK ALL

REMOTE CONTROL LOCK YES

Installation

4.

Configuring the Control options

The CONTROL menu allows you to
select and configure the settings and
options for :
– ESP (Energy Saving Programmability)
– Digit Timeout
– 3 Digit Entry
– Source Menu Item
– Channel Guide
– Minimum Volume
– Maximum Volume

• Press the > button to enter the
CONTROL menu.

CONFIGURATION

CHANNEL INSTALL

SWITCH ON / OSD >
PICTURE / SOUND >
SECURITY >

CONTROL >

VIDEO ADJUSTMENTS >
FEATURES >
CC / V-CHIP >

• Press the < > buttons to select the
item you want to configure.

CONTROL

CHANNEL INSTALL

ESP OFF

DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY NO
SOURCE MENU ITEM NO
CHANNEL GUIDE NO
MIN VOLUME 10
MAX VOLUME 35

• The ESP (Energy Saving
Programmability) option allows you
to select a specified period of time

(from 1 HR / 2 HR ......... / 99 HR) to

power down your TV automatically. If
it does not receive any commands
during this period from the remote
control or the TV keyboard, this
energy saving feature will take effect.

Note : If a remote or keyboard
command is received before the ESP
time period expires, the Timer will
reset and begin counting down again.

CONTROL

CHANNEL INSTALL

ESP 2

DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY NO
SOURCE MENU ITEM NO
CHANNEL GUIDE NO
MIN VOLUME 10
MAX VOLUME 35

• The DIGIT TIMEOUT option
allows you to specify a time period
(from 1 second to 9.9 seconds) for
the channel to switch to another
channel when you key in the channel
number. It is advisable not to specify
too short a time period especially
when you want to key in 2 digit
channel number. For example, if you
specify a 1 second time period, you
may not have enough time to key the
second digit as the channel will switch
after you key in the first digit.
Note : The recommended and default
setting is 3.0 seconds.

25

Installation

CONTROL

CHANNEL INSTALL

ESP 2

DIGIT TIMEOUT 3 . 0

3 DIGIT ENTRY NO
SOURCE MENU ITEM NO
CHANNEL GUIDE NO
MIN VOLUME 10
MAX VOLUME 35

• In the 3 DIGIT ENTRY option,
select YES to enable channel selection
of 1 to 250 for cable mode and 2 to
250 for antenna mode.
Select NO enable channel selection of
1 to 99 for cable mode and 2 to 99 for
antenna mode.

CONTROL

CHANNEL INSTALL

ESP 2
DIGIT TIMEOUT 3 . 0

3 DIGIT ENTRY YES

SOURCE MENU ITEM NO
CHANNEL GUIDE NO
MIN VOLUME 10
MAX VOLUME 35

CONTROL

CHANNEL INSTALL

ESP 2
DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY NO

SOURCE MENU ITEM YES

CHANNEL GUIDE NO
MIN VOLUME 10
MAX VOLUME 35

• The CHANNEL GUIDE is an
on-screen guide of channels that
can be used for displaying the channels
programmed into the TV. The guide
will only function for channels you
have labeled (see page 18 “Naming
a Channel”). This feature is useful for
showing your guests where channels
or inputs are mapped and is usually
not used in a PPV system as the PPV
system has its own map and guide.

• In the CHANNEL GUIDE option,
select YES to enable the Channel
Guide.

• The SOURCE MENU ITEM option
allows you to remove Source from the
options menu the guest can see. The
guest will not have access to any
inputs not mapped to a channel in this
case.

• If YES is selected, the Source
line item will appear in the options
menu. If you select NO, the
Source line item will not appear.

26

ESP 2
DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY YES
SOURCE MENU ITEM YES

CHANNEL GUIDE YES

MIN VOLUME 10
MAX VOLUME 35

CONTROL

• The MIN and MAX VOLUME
options allows you to specify the
limit setting for Minimum and
Maximum Volume.

Installation

ESP 2
DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY NO
SOURCE MENU ITEM YES
CHANNEL GUIDE NO

MIN VOLUME 10

MAX VOLUME 35

Adjusting the Picture horizontally

5.

and vertically

The VIDEO ADJUSTMENTS
options allows you to adjust the picture
horizontally and vertically. This is useful
for configuring channels that have tickers
or scrolling banners at the bottom such
as news and sports channels.

SWITCH ON / OSD >
PICTURE / SOUND >
SECURITY >
CONTROL >

VIDEO ADJUSTMENT >

FEATURES >
CC / V-CHIP >

CONTROL

CONFIGURATION

CHANNEL INSTALL

• Press the < > buttons to select the
item you want to configure.

• Press the < > buttons to make
adjustments.

Configuring the Features options

6.

and settings

• Press the > button to enter the
FEATURES menu.
In the FEATURES menu, you may
select and configure the settings and
options for:
– Smartpower
– Smart Sound Key
– Default HDMI Audio
– Low Power Standby
– Loud Speaker Mute

CONFIGURATION

CHANNEL INSTALL

SWITCH ON / OSD >
PICTURE / SOUND >
SECURITY >
CONTROL >
VIDEO ADJUSTMENTS >

FEATURES >

CC / V-CHIP >

• Press the > button to enter the
VIDEO ADJUSTMENT menu.

VIDEO ADJUSTMENT

CHANNEL INSTALL

HORIZONTAL < >

VERTICAL < >

• Press the < > buttons to select the
item you want to configure.

• Press the < > buttons to select
options.

FEATURES

CHANNEL INSTALL

SMARTPOWER OFF

SMART SOUND KEY SMART SOUND
DEFAULT HDMI AUDIO AV AUDIO
LOW POWER STANDBY YES
LOUD SPEAKER MUTE NO

27

Installation

• The SMARTPOWER option allows
you to put the TV in an energy saving
mode which can save up to 30% in
energy consumption costs.

• Select from LOW, MEDIUM or
HIGH to activate energy saving mode.

SMARTPOWER LOW

SMART SOUND KEY SMART SOUND
DEFAULT HDMI AUDIO AV AUDIO
LOW POWER STANDBY YES
LOUD SPEAKER MUTE NO

FEATURES

• In the SMART SOUND KEY
option, select AUDIO SELECT to
allow you to configure the Smart
Sound button on the Guest remote
control to toggle the different audio
sources and smart sound settings.

FEATURES

CHANNEL INSTALL

SMARTPOWER LOW

SMART SOUND KEY AUDIO SELECT

DEFAULT HDMI AUDIO AV AUDIO
LOW POWER STANDBY YES
LOUD SPEAKER MUTE NO

FEATURES

CHANNEL INSTALL

SMARTPOWER LOW

SMART SOUND KEY SMART SOUND

DEFAULT HDMI AUDIO AV AUDIO
LOW POWER STANDBY YES
LOUD SPEAKER MUTE NO

• The DEFAULT HDMI AUDIO
option allows you to select the HDMI
Audio from different Sources.
This feature is particularly useful for
connecting DVI sources to this
television. DVI Video can convert
easily to HDMI with a simple adaptor,
but the audio signal is not present
and must then be connected to one
of the other inputs on the TV. This
feature allows you to match the DVI
video to the Audio signal you have
connected.

FEATURES

CHANNEL INSTALL

SMARTPOWER LOW
SMART SOUND KEY SMART SOUND

DEFAULT HDMI AUDIO AV AUDIO

LOW POWER STANDBY YES
LOUD SPEAKER MUTE NO

• Select SMART SOUND to
listen to different SMART SOUND
modes.

28

• By default, the LOW POWER
STANDBY option is set to YES.

If an interactive SmartCard is used
with the TV, set the LOW POWER

STANDBY option to NO.

Installation

SMARTPOWER LOW
SMART SOUND KEY SMART SOUND
DEFAULT HDMI AUDIO AV AUDIO

LOW POWER STANDBY YES

LOUD SPEAKER MUTE NO

FEATURES

SWITCH ON / OSD >
PICTURE / SOUND >
SECURITY >
CONTROL >
VIDEO ADJUSTMENTS >
FEATURES >

CC / V-CHIP >

CONFIGURATION

CHANNEL INSTALL

• In the LOUD SPEAKER MUTE
option, select YES to mute the TV
speakers permanently.

FEATURES

CHANNEL INSTALL

SMARTPOWER LOW
SMART SOUND kEY SMART SOUND
DEFAULT HDMI AUDIO AV AUDIO
LOW POWER STANDBY YES

LOUD SPEAKER MUTE YES

Configuring the CC / V-CHIP

7.

options and settings

The CC / V-CHIP menu allows you
to select and configure the settings and
options for :
– Save CC
– CC
– Saved V-CHIP
– V-CHIP Menu Item
– V-CHIP SETUP

• The SAVE CC option allows the TV
to remain in whatever CC mode the
last guest selected, rather than
returning to the default setting you
specify in the next step.

CC / V - CHIP

CHANNEL INSTALL

SAVE CC YES

CC OFF
SAVED V - CHIP NO
V - CHIP MENU ITEM NO
V - CHIP SETUP >

• This is the default CC mode. As long
as SAVE CC is set to OFF the TV
will always power up with CC in the
mode specified here. Options are ON,
OFF and ON MUTE.

CC / V - CHIP

CHANNEL INSTALL

SAVE CC YES

CC ON

DIGITAL CC MODE CS1
ANALOG CC MODE CC1
SAVED V - CHIP NO
V - CHIP MENU ITEM NO
V - CHIP SETUP >

29

Installation

• The DIGITAL CC MODE option
allows you to set your digital CC
options from CS1 to CS6. In

• Go to the SAVE V-CHIP option and
select YES to allow the guest to save
all the V-CHIP settings.

the ANALOG CC MODE option,
it allows you to set your analog CC
options from CC 1 to CC 4 and
TXT 1 to TXT 4.

Note : If Digital CC option that was
selected is not available in the current
digital channel, the TV will switch to
Analog CC mode.

CC / V - CHIP

CHANNEL INSTALL

SAVE CC YES
CC ON

DIGITAL CC MODE CS1

ANALOG CC MODE CC1
SAVED V - CHIP NO
V - CHIP MENU ITEM NO
V - CHIP SETUP >

SAVE CC YES
CC ON
DIGITAL CC MODE CS1
ANALOG CC MODE CC1
SAVED V - CHIP YES
V - CHIP MENU ITEM YES

V - CHIP SETUP >

• In the V-CHIP MENU ITEM option,
select YES to allow the guest to
change all the V-CHIP settings.

CC / V - CHIP

CC / V - CHIP

CHANNEL INSTALL

SAVE CC YES
CC ON
DIGITAL CC MODE CS1
ANALOG CC MODE CC1
SAVED V - CHIP YES

V - CHIP MENU ITEM YES

V - CHIP SETUP >

• In the V-CHIP SETUP option,
proceed to change the V-CHIP
settings.

30

Definitions, Acronyms and Abbreviations

APAC Automatic Pixel Aging Correction. A technique whereby the image

displayed on the television screen is periodically shifted slightly, for the
purpose of minimizing plasma panel phosphor “burn-in”.

A/V Audio / video.

BDS Business Display Solutions. See PBS.

Bit Rate Sometimes written “bitrate”, the frequency at which bits are passing a given

CVI Component video input. Sometimes used interchangeably with “YPbPr”.

CVBS Composite Video Broadcast Standard. Video signal containing combined

DB-9 Standardized 9-pin connector, typically used for RS-232 asynchronous serial

DB-15 Standardized 15-pin connector, typically used for VGA/ computer display

DCM Data Communications Module. ITV terminology for devices that

DFU Directions For Use. Philips Consumer Electronics term for product

DHCP Dynamic Host Configuration Protocol. A protocol used on TCP/IP

DNS The network service used in TCP/IP networks that translates host names to

DVI Digital Visual Interface, a digital interface standard created by the Digital

HTML Hypertext Markup Language. The set of markup symbols or codes inserted

IR Infrared, long-wavelength light energy invisible to the human eye. In this

IR-FACE ITV interface module that adds ITV features and connectivity to non-ITV

MP3 A compressed digital audio format. MPEG (Motion Pictures Experts Group)

(physical or metaphorical) “point”, quantified in terms of bits per second
(bit/s).

color, luminance, and synchronization signals. Also often referred to as
“AUX” video.

communications.

signals.

communicate with Philips Institutional Television products by means of the
Philips ITV SmartPort.

instruction documentation.

networks. Allows client configuration (TCP/IP address, default gateway,
DNS configuration, etc.) to be sent to clients.

IP addresses.

Display Working Group (DDWG) to convert analog signals into digital
signals to accommodate both analog and digital monitors.

in a file intended for display on a World Wide Web browser page.

context as applied to wireless remote controls.

televisions.

Layer 3 Audio compression.

31

Definitions, Acronyms and Abbreviations

MPEG Moving Picture Experts Group. General term for a range of audio and

ITV Institutional Television. See PBS. Commercial / non-consumer division of

NA Not available, not applicable.

NC Not connected, no connection.

Off See “Stand-by”.

On A state of operation in which the unit (television) is connected to an AC

OSD On-Screen Display. The display of alphanumeric text that appears over the

PBS Philips Business Solutions. A commercial / non-consumer division of

Plug Connector on a cable that connects to a plug.

PPV Pay Per View.

video compression, and the name of the standards organization for digital
video and digital audio compression. Operates under the auspices of the
International Organisation for Standardization (ISO).

Philips Consumer Electronics Co.

power source, in active use, and capable of responding to queries or
commands from a control device (IR remote control) and/or DCM.

video image. Typically generated by a character generator usually integrated
into the television chassis control processor.

Philips Consumer Electronics. Co., of which Philips BDS, Business Display
Solutions, formerly known as ITV, is a part.

RC Remote control.

RC-5, RC-6 Philips IR remote control communication protocol.

RJ-11 Registered jack 11. Modular telephone-style connector form factor with 4

RJ-12 Registered jack 12. Modular telephone-style connector form factor with 6

Router Technically, also known as a Layer 2 Switch. A switching hub that operates

RTSP Real-Time Streaming Protocol. Allows control of multimedia streams

electrical conductors.

electrical conductors.

at the Data Link Layer (Layer 2), and builds a table of the MAC addresses of
all the connected stations.

delivered, for example, via RTP (RFC 3389, Real-time Transport Protocol
Payload). Control includes absolute positioning within the media stream,
recording and possibly device control.

32

Definitions, Acronyms and Abbreviations

RTP Real-time Transport Protocol. Defines a standardized packet format for

Setup Mode See System 7. Remote control mode used to configure Philips Institutional

SmartPort™ Philips proprietary three-wire synchronous serial communications and

SmartPlug™ See SmartPort.

Socket Connector on a cable that connects to socket.

SBB Set-back box. Used interchangeably with “set-top box”. General term for a

STB Set-top box. See SBB.

Stand by Generally referred to as “off”. A state of operation, characterized by

System 0 First data word of a Philips RC-5 / RC-6 remote control code for standard

System 7 First data word of a Philips RC-5 / RC-6 remote control code reserved for

TCP Transmission Control Protocol / Internet Protocol. De facto standard

UDP User Datagram Protocol. A minimal message-oriented transport layer

YPbPr Component video signals consisting of luminance, and blue and red

delivering audio and video over the Internet.

Televisions for specialized and/or restricted features such as front panel
lockout, volume range, channel list, etc..

control interface.

device that adds functionality to, and / or interfaces a television with, a host
content- and/or control- environment.

relatively low power consumption, in which the unit (television) is
connected to an AC power source, but not in active use, and capable of
responding to queries or commands from a control device and/or DCM.

television commands. Synonymous with Business Display Solutions / ITV
”guest” mode.

specialized commands. Used for Business Display Solutions / ITV ”setup”
mode.

protocol for Internet communications.

protocol that is currently documented in IETF RFC 768. Used by Philips
NetLink to issue device discovery packets.

components.

33

USA Limited Warranty

Thank you for purchasing this PHILIPS branded Commercial Television.

All Philips branded commercial televisions are designed and
manufactured to high standards and deliver high-quality performance.
Within the first year of purchase, this two-year Limited Warranty may
entitle you to receive an “Advance Exchange*” model on-site within
72 hours of qualification. Within the second year of purchase, this
two-year Limited Warranty may entitle you to receive an “Advance
Exchange*” model on-site delivered via Ground Transportation.

Philips’ Commercial Television

For more information on this and more great Philips products visit our web site at:

http://www.philips.com/hospitality

Philips F1rst Choice Limited Warranty

One Year 72 hour Advance Exchange* / Two Years Advance Exchange*

WHO IS COVERED?

The original purchaser for end use. You must have a sales receipt or other document showing
that you purchased the Product. Please retain and store your Proof of Purchase securely.

WHAT IS COVERED?

Defects in materials and workmanship if a valid claim is received by Philips within the Warranty
Period. When the warranty on the purchased product expires, the warranty on all exchanged
products (including their parts and service labor) also expires.

WHAT IS THE PERIOD OF COVERAGE?

Two (2) years. For two (2) years from the date of purchase, as evidenced by your proof of
purchase, Philips will provide an “Advance Exchange” subject to the terms and conditions
herein.

34

USA Limited Warranty

WHAT WE WILL DO TO CORRECT PROBLEMS?

*For the first year, the defective Product will be exchanged with a new Product (or one
that has been renewed to original specifications) and delivered within seventy-two hours
of qualification. During the second year, the defective product will be exchanged with one
that has been renewed to original specifications and delivered via Ground Transportation.
In the event of a failure of multiple units at the same location, Philips reserves the right at its
sole discretion to send personnel to the location to determine the cause of the failure and
determine the most efficient means of resolving the failure.

WHAT IS EXCLUDED?

•

unless otherwise provided for herein, shipping charges to return defective products to
Philips.

•

unless shipped by Philips, damage to or loss of product during shipment.

•

labor charges for installation or setup of the product, adjustment of customer controls on
the product, and installation or repair of antenna systems outside of the product.

•

product repair and/or part replacement because of accident, misuse, unauthorized repair
or other cause not within the control of Philips.

•

reception problems caused by signal conditions or PPV, cable, or antenna systems outside
the unit. o modifications or adaptations to enable a product to operate in any country
other than the country for which it was designed, manufactured, approved

•

and/or authorized, or repair of products damaged by such modifications or adaptations.

•

modifications or adaptations to enable a product to operate with any PPV system
other than the PPV systems for which it was designed, manufactured, approved, and/or
authorized, or repair of products damaged by such modifications.

•

CONSEQUENTIAL, INCIDENTAL, INDIRECT OR SPECIAL DAMAGES RESULTING
FROM THE PRODUCT, INCLUDING BUT NOT LIMITED TO DAMAGES FOR LOST
DATA, LOST SOFTWARE, OR LOSS OF USE OF THE PRODUCT. (Some states do not
allow the exclusion of such damages, so the above exclusion may not apply to you. This
provision also excludes such damages for prerecorded material, whether copyrighted or
not copyrighted, among all other potential claims.)

•

products on which the model, production or serial number has been altered, deleted,
removed or made illegible.

•

product sold AS IS or Renewed.

35

USA Limited Warranty

HOW TO GET WARRANTY SERVICE IN U.S.A., PUERTO RICO OR

U.S. VIRGIN ISLANDS? OR WHERE CAN I GET MORE INFORMATION?

Before requesting service, please check your owner’s manual as adjustments of the controls
discussed there may save you a service call. Also, please prepare the following details so we
can solve your problem quickly.

•

Philips type number

•

Philips serial number

•

Purchase date (copy of receipt of purchase may be required)

•

Pay Per View Provider (if any)

•

High Definition signals offered at property (if any)

•

Your proof of purchase indicating: date of purchase, dealer name, model and product serial
number.

•

The full address to which the swap model should be delivered.

Then, contact Philips’ ITV Customer Care Center at: [phone]

(IN U.S.A., PUERTO RICO AND U.S. VIRGIN ISLANDS, ALL IMPLIED
WARRANTIES, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE DURATION OF THIS EXPRESS WARRANTY. But, because some states do

not allow limitations on how long an implied warranty may last, this limitation may not apply to
you.)

This Limited Warranty gives you specific legal rights. You may have other rights which vary
from state to state.

WARRANTY SERVICE IN CANADA: While this warranty statement is not valid
for Canadian purchases, you may be eligible for warranty service. Please contact
Philips Canada at: [phone]

Just a phone call away

Philips’ customer help desks are located worldwide. Within the U.S. you can contact Philips
Customer Care Monday-Friday from 8:00 AM-9:00 PM Eastern Time (ET) and on Saturdays
from 10:00 AM-5:00 PM ET by using the USA contact phone number listed above. To
avoid possible shock hazard, please be sure that the television is unplugged from the electrical
outlet before cleaning.

36

Cleaning and Care

Environmental Care

•

Do not touch the screen with anything
hard as this scratch, mar or damage the
screen permanently.

•

Do not rub with dust clothes with
chemical treatment.

•

Do not touch the surface with bare
hands or greasy cloth (some cosmetics
are detrimental to the screen).

•

Unplug the TV before cleaning the
screen.

•

When the surface becomes dusty, wipe
gently with absorbent cotton or other
soft materials like chamois soaks. Do
not use acetone, toluene and alcohol
cleaners because they cause chemical
damage.

•

Do not use liquid or aerosol cleaners.

•

Wipe off saliva or water droplets as
soon as possible. Long time contact with
the screen causes deformations and
color fading.

•

This Philips Institutional Television
product and its packaging contain
materials that can be recycled and
re-used. Specialized companies can
recycle your product to increase the
amount of reusable materials and
minimize the amounts which need to be
properly disposed.

•

This product might also use batteries
which should not be thrown away when
depleted, but should be handed in and
disposed of as small chemical waste.

•

Please find out about the local
regulations regarding the disposal of
the television, batteries, and packaging
materials whenever you replace existing
equipment.

•

This product consumes energy in the
stand-by mode. Energy consumption
contributes to air and water pollution. It
is advisable to switch off your television
overnight instead of leaving it in stand-by
mode.

37

Index

A

Accessing the setup Menu 14
Antenna mode 19
Audio select 28
Automatic channel tuning 19

B

Basic TV connections 8
Before calling service 6

C

Cable mode 19
CC (Closed Caption) 29
Changing channel settings 15
Channel guide 26
Channel install 16
Channel logo 16
Cleaning and care 37
Communication source 15
Confi guration 22
Control options 25
Current ring 20

D

Default HDMI audio 28
Defi nitions, acronyms and abbreviations 31
Digital audio language 21
Digital channel scroll 17
Digital closed caption setup 21
Digital minor channel 17
Digital setup 20
Digit timeout 25

E

Emergency alert 22
Energy saving programmability 25
Environmental Care 37

F

Factory channel reset 21
Features 27

G

Guest remote control keys 12

I

Important safety instructions 2

K

Keyboard lock 24

L

Language selection 15
Loud speaker mute 29
Low power standby 28

M

Maximum volume 26
Minimum volume 26
MPEG Program number 17

N

Naming a channel 18

O

Optional remote controls 11
Overview of TV connectors and controls 10
Overview of TV setup main menu/sub­menus 13

P

Physical channel 19
Picture and sound 23
Picture format 23

R

RF Channel Number 17

S

Safety information and useful tips 28
Security 24

38

Selecting input source 16
Smartpower 28
Smart RC 15
Smart sound key 28
Source menu item 26
Switch on/ OSD 23

T

Three digit entry 26

U

U.S.A. limited warranty 34
Use and care of optional remote controls 9

V

V-CHIP menu item 30
V-CHIP setup 30
Video adjustment 27
Virtual channel 19
Selecting input source 16
Smartpower 28
Smart RC 15
Smart sound key 28
Source menu item 26
Switch on/ OSD 23

T

Three digit entry 26

Dolby Digital

Manufactured under license from Dolby
Laboratories. ‘Dolby’ and the double­D symbol are trademarks of Dolby
Laboratories.

Kensington Security Slot

(if present)

Your TV is equipped with a Kensington
Security Slot, to prevent it from getting
stolen. An anti-theft Kensington lock has to
be purchased separately. The Kensington
lock is a plastic-coated steel cable with a
lock. One end has to be fixed to the opening
of the TV and locked with a special key. The
other end is attached to a fixed point.

® Kensington and MicroSaver are registered US
trademarks of ACCO World Corporation with
issued registrations and pending applications in
other countries throughout the world. All other
registered and unregistered trademarks are the
property of their respective owners.

U

U.S.A. limited warranty 34
Use and care of optional remote controls 9

V

V-CHIP menu item 30
V-CHIP setup 30
Video adjustment 27
Virtual channel 19

39

© 2007 Koninklijke Philips N.V.

All rights reserved

Document order number: 3139 125 39171

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

To power outlet

AC in

To wall socket

SETUP

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >

AUTO INSTALL TV >

CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

Change the settings of the
channels as desired (delete
unwanted channels, assign
digital channels, assign input
sources). Refer to “Changing
the settings of a channel”
section in this guide.

Change the TV settings as desired.
Refer to “Conguring Volume /

Picture and Other Common
settings” section in this guide.

For detailed explanation, refer to
the user manual.

Record the TV conguration
settings into a Wireless
SmartLoader. Refer to the
“Cloning the TV

conguration to a
SmartLoader and the
SmartLoader conguration
to the TV” section in this guide.

Slide the button
to the Setup
position.

Power on the TV.

Connect RF signal and plug
TV into power outlet.

Press the M button on the
remote to display Setup
menu and press the Cursor
Down button repeatedly
until AUTO INSTALL TV
is highlighted.

Press the Cursor Right
button to start automatic
channel installation.

A

B

C

D

E

F

How to use this guide What you can find in the box

2

Stand alone installation

3

Quick Start Guide

4

Changing the settings of a channel

Configuring the Volume / Picture and Other
Common settings

Note: This section is only
applicable after channels
have been installed in the
TV (see Section 3 on
channel installation).

Press the M button on the remote
to display the Setup menu.
Press the Cursor Down button
repeatedly until CHANNEL
INSTALL is highlighted.

Cloning the TV configuration to a SmartLoader
and the SmartLoader configuration to the TV

6

Installing a Pay-Per-View SmartCard

Installing a Pay-Per-View Box

7

M6 (18mm) x 4

M5 (25mm) x 2

x 2

Fo

r
C

ust

o

m

e

r

Use

E
nte

r

b

e
l

o

w

t

h
e

S

eria

l
N

o.

w
h

ic

h

is

lo

c
ated

o

n

th

e

re

a
r o

f

t

h
e

c

a

b
in

e

t
.
Ret

a
in

th

is

i
nf

o
r
m

a
t
io

n

f
o

r

fu

t

u
re

r

e

f
e

r
e

n

c
e.

M
o

d

el

No

.

_

_
_

___

___

__

_

__

____

_

_
___

_
_

_

__

_

_

S
e

ri
a

l

No.

______

_

__

_
______

__

____

___

_

_

Philips

Business Displa

y

Solutions

26

HF55

4

5D

3

2H

F55

4

5

D

3

2

HF

7945D

2

6HF

79

4

5D

42H

F7

94

5D

26

HF7955H

3

2H

F7

95

5

H

U

s

e

r

M

a

nua

l

Thank

you

f
o

r

c
ho

o
si

n
g

P
hil

i
ps.

N

e

ed

h

el

p

f
as

t

?

R
e

ad

y

o

u
r

Q

u
ick

U

s
e

G

u

i
d

e

an

d

/o

r

O

wn

e

r’

s
M

anu

a

l
fi

rs

t
fo

r

qu

i
c

k

tip

s

t

h
a

t
mak

e u

s

ing

y
o

u

r

P

h
il

i
ps

p

r
o

d

u

ct

m

o
r

e
e

n
j
o

y

abl

e

.
I
f

yo

u

h

a

ve

re

a
d

y

o

u
r

i
n

s

truc

tio

ns

an

d s

t
i
l

l
n

eed

as

s

is

t

a

nc

e,
y
o

u

m

a

y
ac

c

es

s
o

ur

on

li
n

e

he

lp

at

ww

w

.p

hil

i

p

s
.
c

om

/

h

os

p

i

t

ali

t
y

or

ca

ll

1-

8

66

­49

7-42

25
w
h

i
le

w

i

t

h

y
ou

r

p

rod

u

ct

(

a
n

d

M

o

d

el

/

S
er

i
a

l

n

u

m

b

er

)

S

T

O

P!

Quick Start Guide

x 4

For

C

us

t
om

e

r

U

se

Ente

r
be

low

t
h

e

Se

ria

l N

o

.
wh

ic
h

is

loca

ted

on

th

e

r

ear

o

f

t
h

e

c

abin

e

t.

R

e

t
a
in

t
h
is

i

nf

orm

at

io
n

f

o

r
futu

r
e

r

e
f

er

e
nc

e.

M

od

el

No

.

_
_

_

__

__

___

__

__

__

___

_
_

__

___

__

_

_

Se

r
i
al

N

o.

_

_____

_

___

__________

__

_____

Philips Business Display Solutions

26

HF55

45

D

3

2H

F5

545

D

32HF7

94

5

D

26

HF

7

9

45

D

4

2

H

F7

945D

26H

F795

5

H

3

2H

F79

5

5

H

U

ser

M

anu

a

l

T

h

a

n
k

yo

u

f

o

r

c
h

oo

s
i

n
g

P

h
i

l
i
p
s

.

Ne

ed

h

e

l
p

fast?

Rea

d

y

o

ur

Q

uick

Us

e

Gui

d

e

an

d

/
o

r

O

wne

r’

s

Man

u

al

fir

s

t
f

or

quic

k

tip

s

t

h

a
t
ma

k

e

u

sing

yo

u

r

P

hil

ips

p

r
o

du

c

t

m

o

r
e

en

joy

ab

l

e
.

If

yo

u

h

ave re

ad

y
o

u
r

ins

truc

t
i
o

ns

an

d

stil

l

n

ee

d

ass

ist

a

nc

e,
y
o

u

m

ay

a

c

c
es

s

our

o

n

l
i
n

e

he

lp

at

w

ww

.
p

hi

l
i

p

s.

c

o

m/

h

os

p

i
ta

li
ty

or

c

a

l

l

1

­86

6

­4

97

­4

2

25

w

h
i

l
ew

it

h

you

r

p

rod

u

c
t

(an

d

M

od

el

/

S

eria

l

nu

m

b

er)

S

T

O

P

!

Quick Start Guide

42” model

A

Press the MENU button on
SmartLoader to display menu
on TV.

B

C D

To load the TV conguration into
a SmartLoader, select “TV to

SmartLoader” and press the
Cursor Right button to start.

To load the SmartLoader conguration into
the TV, select “SmartLoader to TV” and
press the Cursor Right button to start.
Note: In both cases, the process takes
approximately 30 seconds to complete.

A

Press the Cursor Right button to
enter into the CHANNEL

INSTALL menu and use the Digits
0 - 9 buttons to select a channel.

B

© 2007 Koninklijke Philips N.V.

All rights reserved

Document order number: 3139 125 39181

Press the Cursor Down button to
select INPUT and use the Cursor
Left or Right button to select input
source.

C

Press the Cursor Down button
repeatedly until DIGITAL is
highlighted. Press the Cursor Right
button to select YES. Set the RF
CHANNEL NUMBER to the
physical channel where the digital
program is located and the MPEG
PROGRAM NUMBER to the
program desired within that physical
channel.

Note : You can also highlight the
DIGITAL CH SCROLL item and

press the Cursor Left or Right
button to select the digital channel
numbers.

D

Press the Cursor Down button to
select RINGS and press the
Cursor Right button repeatedly to
select RING 1 to 4. Press the
Cursor Up or Down button to
save or remove the channel from
each ring.
‘X’ means the channel is saved.

E

Press the M button on the remote to
display the Setup menu and press the
Cursor Down button repeatedly
until CONFIGURATION is
selected.

A

Press the Cursor Right button to
enter into the CONFIGURATION
menu and press the Cursor Right
button again to enter the SWITCH
ON / OSD menu.
Press the Cursor Down button to
select SWITCH ON CHANNEL.
Press the Cursor Right button to
select the channel that you want it to
appear when the TV is powered on. Do
likewise for SWITCH ON VOLUME,

SWITCH ON PIC FMT and
WELCOME MESSAGE.

B

In the CONFIGURATION menu,
select PICTURE / SOUND. Press
the Cursor Left or Right button to
enter the PICTURE / SOUND
menu and change to your desired
picture and sound settings.

C

D

E

In the CONFIGURATION menu, select
CONTROL. Press the Cursor Left or
Right button to enter the CONTROL

menu and select MAX VOLUME to set
your desired maximum volume setting.

In the CONFIGURATION menu,
select VIDEO ADJUSTMENT
and press the Cursor Right
button to enter the VIDEO

ADJUSTMENT menu. Select
HORIZONTAL or VERTICAL

and use the Cursor Left or Right
button to adjust picture horizontally
or vertically.

A

Insert the Pay-Per-View SmartCard into
the SmartCard slot on the rear of the TV
(available for certain models only) and
connect the other cables as directed by
the Pay-Per-View provider.

B

C

B

26” / 32” models

To power outlet

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

SETUP

LANGUAGE ENGLISH
COMMUNICATION >

CHANNEL INSTALL >

AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

CHANNEL

INPUT TUNER
CHANNEL LOGO >
DIGITAL NO
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

CHANNEL INSTALL

TV 8

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

CHANNEL TV 8
INPUT TUNER
CHANNEL LOGO >

DIGITAL YES

DIGITAL CH SCROLL >
RF CHANNEL NUMBER 8
MPEG PROGRAM NUMBER 2
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

CHANNEL INSTALL

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

CHANNEL

INPUT TUNER

CHANNEL LOGO >
DIGITAL NO
RINGS (1 ) (2 ) (3 ) (4 )
LABEL ( ) >
MUTE NONE

CHANNEL INSTALL

TV 8

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

CHANNEL
INPUT TUNER
CHANNEL LOGO >
DIGITAL NO

RINGS (1X ) (2 ) (3 ) (4 )

LABEL ( ) >
MUTE NONE

CHANNEL INSTALL

TV 8

SETUP

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >

CONFIGURATION >

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

SWITCH ON / OSD

WELCOME MESSAGE >

SWITCH ON CHANNEL TV 2

SWITCH ON VOLUME 30
SWITCH ON PIC FMT WIDESCREEN
POWER ON LAST STATUS
VOLUME INDICATOR YES
CHANNEL DISPLAY ALL

Slide button up on the left of the
SmartLoader to the position.
Aim SmartLoader at green LED
(4 to 6 inches away from TV).

MENU

8

9

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CONTROL

ESP 2
DIGIT TIMEOUT 3 . 0
3 DIGIT ENTRY NO
SOURCE MENU ITEM YES
CHANNEL GUIDE NO
MIN VOLUME 10

MAX VOLUME 35

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

CHANNEL INSTALL

VIDEO ADJUSTMENT

HORIZONTAL <>

VERTICAL <>

SMARTLOADER

SMARTLOADER TO TV

>

TV TO SMARTLOADER

MENU

MENU

SMARTLOADER

SMARTLOADER TO TV

>

TV TO SMARTLOADER

SMARTLOADER

SMARTLOADER TO TV

>

TV TO SMARTLOADER

NOTE : Step A in this section
may not be needed as the
Communication mode by
default is set to SP - SPI.
Perform this step only if
you want to conrm the
Communication mode is
set correctly.

In the SETUP menu, select
COMMUNICATION. Press
the Cursor Right button to enter
COMMUNICATION menu.

Press Cursor Right button to
select SP - SPI.
Press Cursor Right button and
select STORE and press the
Cursor Right button to store
selection.

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

COMMUNICATION SP - SPI

STORE >
DCM TYPE >

COMMUNICATION

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

01 26HF7945D / 27
02 SV1A0707100003
03 IC7U1 - 0 .11 / M3 .22
04 LC72HUL1 - 0 .13
05 OPT (30) 22 20 1C 23
06 OPT - MODEL 26HF7945D / 27
07
08 COMMUNICATION SP - SPI ONLINE
09 TV 2 NOT TUNED

A

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

COMMUNICATION SP - SPI

STORE >
DCM TYPE >

COMMUNICATION

Insert the RJ12 cable of the
Pay-Per-View box to the DATA
1 (RJ12) connector on the rear
of the TV and connect the other

cables as directed by the
Pay-Per-View provider.

C

Press the RECALL button on the
remote and check SP - SPI is on-line.
If SP - SPI shows “OFFLINE”, check the
RJ12 cable and connection between
terminal and TV.

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

01 26HF7945D / 27
02 SV1A0707100003
03 IC7U1 - 0 .11 / M3 .22
04 LC72HUL1 - 0 .13
05 OPT (30) 22 20 1C 23
06 OPT - MODEL 26HF7945D / 27
07
08 COMMUNICATION SP - SPI ONLINE
09 TV 2 NOT TUNED

Sample of
Pay-Per-View
SmartCard

Connect to the
Data 1 (RJ 12)
connector at the
rear of the TV.

Sample of
Pay-Per-View
box

OR

MENU

CHANNEL INSTALL

PICTURE / SOUND

BRIGHTNESS 45

COLOR 38
CONTRAST 70
SHARPNESS 50
TINT 36
ACTIVE CONTROL YES
TREBLE 52
BASS 55
BALANCE 0
AVL ON

Press the RECALL button on the remote
and check SP - SPI is on-line. If SP - SPI
shows “OFFLINE”, check the RJ12 cable
and connection between terminal and TV.

Smoovie TV Installation

5

For information about Smoovie
TV™, see www.smoovie.tv or

call 1-888-256-5284.

Follow the
instructions for setting up TV
for use as a stand alone (see
section 3). At this point, all of
your channels, including those
you wish to use for the
Smoovie TV

™ are programmed

and accesible.

A

B

To install the restricted Smoovie
TV™ channels, press the M button

on the remote (in Setup position) to
display Setup menu. Press the Cursor

Down button repeatedly until
CURRENT RING is highlighted. Press

the Cursor Right button repeatedly
until RING 4 is selected for each
channel that you want to enjoy

Smoovie functionality.

C

SETUP

LANGUAGE ENGLISH
COMMUNICATION >
CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO

CURRENT RING RING4

DIGITAL SETUP >
CONFIGURATION >

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

M

A/CH

1

4

7

809

2

56

3

+

++

_

COMMUNICATION SMART RC

STORE >
DCM TYPE >

COMMUNICATION

SETUP

LANGUAGE ENGLISH

COMMUNICATION >

CHANNEL INSTALL >
AUTO INSTALL TV >
CABLE TUNING NO
USE CHANNEL TABLE NO
CURRENT RING RING1
DIGITAL SETUP >
CONFIGURATION >

NOTE : Perform this step only if
you are installing digital channels.

Diagnosing Basic Problems

10

If the TV does not seem to communicate with the external interactive
terminal, do the following steps.

A

Press the RECALL button on the
remote (in Setup position). Item 08
of the menu should read

COMMUNICATION SP - SPI.

B

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

01 26HF7945D / 27
02 SV1A0707100003
03 IC7U1 - 0 .11 / M3 .22
04 LC72HUL1 - 0 .13
05 OPT (30) 22 20 1C 23
06 OPT - MODEL 26HF7945D / 27
07
08 COMMUNICATION SP - SPI ONLINE
09 TV 2 NOT TUNED

If it is not SP -SPI, press the M button
on the remote to display the Setup
menu. Press the Cursor Down button
to select COMMUNICATION and
press the Cursor Right button
repeatedly to select SP - SPI.
Press the Cursor Right button and
select STORE and press the Cursor

Right button to store selection.

C

If the TV still does not communicate
with the external interactive
terminal, press the RECALL button
on the remote. Check item 08 of
the menu.
If it reads “ COMMUNICATION
SP -SPI OFFLINE”, check the
RJ12 cable and connection between
terminal and TV.

POWER

SLEEP

GUIDE

CH

CC

RESET

SMART

GUEST

DCM

SETUP

TEXT

RECALL

1

4

7

809

2

56

3

01 26HF7945D / 27
02 SV1A0707100003
03 IC7U1 - 0 .11 / M3 .22
04 LC72HUL1 - 0 .13
05 OPT (30) 22 20 1C 23
06 OPT - MODEL 26HF7945D / 27
07
08 COMMUNICATION SP - SPI OFFLINE
09 TV 2 NOT TUNED

If an “F”, appears in the upper right hand
corner of the screen it indicates the TV is
in factory mode. To restore normal
operation, press and hold the CHANNEL
DOWN and the VOLUME DOWN
keyboard buttons on the side of the TV for
a few seconds. The “F” should disappear.

NOTE : Step A in this section
may not be needed as the
Communication mode by
default is set to SP - SPI.
Perform this step only if
you want to conrm the
Communication mode is
set correctly.

In the SETUP menu, select
COMMUNICATION. Press
the Cursor Right button to enter
COMMUNICATION menu.

Press Cursor Right button to
select SP - SPI.
Press Cursor Right button and
select STORE and press the
Cursor Right button to store
selection.

The purpose of this Quick Start Guide is to assist you
in getting this Philips Commercial television installed
as quickly as possible. It contains the necessary
information needed for most typical connections and
installations. For detailed documentation of additional
features, please consult the user manual or online help
at www.philips.com/hospitality.

Go through this Quick Start Guide and read the
instructions on :

- how to do a Stand alone installation

- how to change the settings of a channel

- how to do a Smoovie TV installation

- how to configure the Volume / Picture and
other common settings

- how to clone the TV configuration to a
SmartLoader and from the SmartLoader
to the TV

- installing a Pay-Per-View SmartCard

- installing a Pay-Per-View Box

- how to diagnose basic problems

™

™

In the Setup menu, press the Cursor
Up or Down repeatedly until
COMMUNICATION is highlighted.

Press the Cursor Right button to
enter COMMUNICATION menu.
Press the Cursor Right button
repeatedly until SMART RC is
selected. Select STORE and press the
Cursor Right button to store
selection. Your TV is now installed for
Smoovie TV functionality and the
channels you have selected for
restricted access are no longer
accessable without a Smoovie TV
remote.

™

™
