Philips 32PHG4900/78, 40PFG5000/78, 48PFG5000/78, 43PFG5000/78 instructions for use
Register your product and get support at
www.philips.com/welcome
PHG4900
PHG5000
PFG5000
EN User Manual
Contents
1 Important 3
Safety 3
Care 4
Legal 5
Sustainability 6
Help and support 8
2 Use your TV 9
TV controls 9
Watch TV 10
View program guide 13
Play multimedia files 14
Interactive TV 15
3 Use more of your TV 16
Play games 16
Set locks and timers 16
4 Change your TV settings 18
Picture and sound 18
Channels 19
Language settings 21
Universal access settings 22
Other settings 22
Update software 22
Reset all 23
5 Connect your TV 24
About cables 24
Connect antenna 25
Connect devices 25
Connect more devices 31
Watch connected devices 32
Set up EasyLink devices 32
6 Troubleshooting 35
7 Specifications 38
Power and reception 38
Display and sound 38
Display resolutions 38
Multimedia 38
Connectivity 40
8 Index 41
General issues 35
Channel issues 35
Picture issues 36
Sound issues 36
Connection issues 37
Contact Philips 37
EN 2
English
1 Important
Safety
Precautions
Read and understand all instructions before
you use your TV. If damage is caused by
failure to follow the instructions, the
warranty does not apply.
Risk of electric shock or fire!
• Never expose the TV to rain or water.
Never place liquid containers, such as
vases, near the TV. If liquids are spilled
on or into the TV, disconnect the TV
from the power outlet immediately.
Contact Philips TV Consumer Care to
have the TV checked before use.
• Never place the TV, remote control or
batteries near naked flames or other
heat sources, including direct sunlight.
To prevent the spread of fire, keep
candles or other flames away from the
TV, remote control and batteries at all
times.
• Never insert objects into the ventilation
slots or other openings on the TV.
• Never expose the remote control or
batteries to rain, water or excessive
heat.
• Avoid force coming onto power plugs.
Ensure that the power plug is fully
inserted into the power socket. Loose
power plugs can cause arcing or fire.
• When the TV is swiveled, ensure that
no strain is exerted on the power cord.
Strain on the power cord can loosen
connections and cause arcing.
• To disconnect the TV from the mains
power, the power plug of the TV must
be disconnected. When disconnecting
the power, always pull the power plug,
never the cord. Ensure that you have
full access to the power plug, power
cord and outlet socket at all times.
Risk of damage to the TV!
• Two people are required to lift and
carry a TV that weighs more than 25kg
or 55lbs.
• When stand mounting the TV, use only
the supplied stand. Secure the stand to
the TV tightly. Place the TV on a flat,
level surface that can support the
combined weight of the TV and the
stand.
• When wall mounting the TV, use only a
wall mount that can support the weight
of the TV. Secure the wall mount to a
wall that can support the combined
weight of the TV and wall mount. TP
Vision Europe B.V. bears no
responsibility for improper wall
mounting that results in accident, injury
or damage.
• If you need to store the TV,
disassemble the stand from the TV.
Never lie the TV on its back with the
stand installed.
• Before you connect the TV to the
power outlet, ensure that the power
voltage matches the value printed on
the back of the TV. Never connect the
TV to the power outlet if the voltage is
different.
• Parts of this product can be made of
glass. Handle with care to avoid injury
and damage.
EN 3
Risk of injury to children!
Follow these precautions to prevent the TV
from toppling over and causing injury to
children:
• Never place the TV on a surface
covered by a cloth or other material
that can be pulled away.
• Ensure that no part of the TV hangs
over the edge of the surface.
• Never place the TV on tall furniture,
such as a bookcase, without anchoring
both the furniture and TV to the wall
or a suitable support.
• Educate children about the dangers of
climbing on furniture to reach the TV.
Risk of swallowing batteries!
• The product/remote control may
contain a coin type battery, which can
be swallowed. Keep the battery out of
reach of children at all times!
Risk of overheating!
• Never install the TV in a confined space.
Always leave a space of at least 4
inches or 10 cm around the TV for
ventilation. Ensure that curtains or
other objects never cover the
ventilation slots on the TV.
Risk of injury, fire or power cord damage!
• Never place the TV or any objects on
the power cord.
• Disconnect the TV from the power
outlet and aerial before lightning storms.
During lightning storms, never touch
any part of the TV, power cord or
aerial cable.
Risk of hearing damage!
• Avoid using earphones or headphones
at high volumes or for prolonged
periods of time.
Low temperatures
• If the TV is transported in temperatures
below 5°C or 41°F, unpack the TV and
wait until the TV temperature matches
room temperature before connecting
the TV to the power outlet.
Care
Screen
• Risk of damage to the TV screen!
Never touch, push, rub or strike the
screen with any object.
• Unplug the TV before cleaning.
• Clean the TV and frame with a soft
damp cloth and wipe gently. Never use
substances such as alcohol, chemicals or
household cleaners on the TV.
• To avoid deformations and color fading,
wipe off water drops as soon as
possible.
• Avoid stationary images as much as
possible. Stationary images are images
that remain onscreen for extended
periods of time. Stationary images
include onscreen menus, black bars,
time displays, etc. If you must use
stationary images, reduce screen
contrast and brightness to avoid screen
damage.
Placement tips
• Position the TV where light does not
shine directly on the screen.
• The ideal viewing distance of this TV is
three times its diagonal screen size. For
example, if the diagonal screen size of
the TV is 81cm / 32", the ideal viewing
distance is ~2.5m / ~92" from the front
of the screen.
• While seated, your eyes should be level
with the center of the screen.
TV placement
You can apply the best sound settings for
your TV by selecting the TV placement (wall
mount or stand mount).
1. Press
2. Select [Setup], then press OK.
3. Select [TV settings] > [General settings]
> [TV placement].
4. Select [On a TV stand] or [Wall
mounted], then press OK.
.
EN 4
English
Lock the TV
Your TV is equipped with a Kensington
security slot at the base of the TV. To secure
the TV, purchase a Kensington anti-theft lock
(sold separately).
Legal
Notice
2015 © TP Vision Europe B.V. All rights
reserved.
This product was brought to the market by
TP Vision Europe B.V. or one of its affiliated
companies, further referred to in this
document as TP Vision, which is the
manufacturer of the product. TP Vision is the
warrantor in relation to the TV with which
this booklet was packaged. Philips and the
Philips Shield Emblem are registered
trademarks of Koninklijke Philips N.V.
Specifications are subject to change without
notice. TP Vision reserves the right to
change products at any time without being
obliged to adjust earlier supplies accordingly.
The written material packaged with the TV
and the manual stored in the memory of the
TV or downloaded from the Philips web site,
are believed adequate for the intended use
of the system. If the product is used for
purposes other than those specified herein,
TP Vision cannot guarantee the proper
functioning and the safety of the product.
TP Vision cannot be held responsible for any
errors in the content of this document nor
for any problems as a result of the content in
this document. Errors reported to TP Vision
will be adapted and published on the Philips
support website as soon as possible.
Terms of warranty
• The terms of warranty can be
downloaded from the Philips support
web site. Never attempt to repair the
TV yourself because it gives risk of
injury, damage to the TV or void of
warranty!
• Use the TV and accessories only as
intended by the manufacturer.
• The caution sign printed on the back of
the TV indicates risk of electric shock.
Never remove the TV cover. Always
contact Philips TV Customer Care for
service or repairs.
• Any operation expressly prohibited in
this manual, or any adjustments and
assembly procedures not
recommended or authorized in this
manual shall void the warranty.
Pixel characteristics
This LED product has a high number of
color pixels. Although it has effective pixels
of 99.999% or more, black dots or bright
points of light (red, green or blue) may
appear constantly on the screen. This is a
structural property of the display (within
common industry standards) and is not a
malfunction.
Open source software
TP Vision Europe B.V. hereby offers to
deliver, upon request, a copy of the
complete corresponding source code for the
copyrighted open source software packages
used in this product for which such offer is
requested by the respective licences. This
offer is valid up to three years after product
purchase to anyone in receipt of this
information. To obtain the source code,
please write in English to:
“Intellectual Property Dept., TP Vision
Europe B.V., Prins Bernhardplein 200, 1097
JB Amsterdam, The Netherlands”.
EN 5
Trademarks and copyrights
Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
Manufactured under license from Dolby
Laboratories. Dolby and the double D
symbol are trademarks of Dolby
Laboratories.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of
HDMI Licensing LLC in the United States
and other countries.
Kensington and Micro Saver are registered
US trademarks of ACCO World
Corporation with issued registrations and
pending applications in other countries
throughout the world.
The DTVi brand and logo are registered
marks of Pontifical Catholic University of Rio
de Janeiro (PUC-Rio) and the Federal
University of Paraíba (UFPB).
Java and all Java based trademarks are
registered trademarks of Oracle and/or its
affiliates, in the United States and other
countries.
All other registered and unregistered
trademarks are the property of their
respective owners.
Sustainability
Energy efficiency
This TV is designed with energy-efficient
features. To access these features, press the
Green button on the remote control.
• Energy saving picture settings: You can
apply a combination of energy saving
picture settings. While you watch TV,
press the Green button and select
[Energy saving]. Then select the
[Energy saving] picture setting.
• Screen off: If you only want to listen to
audio from the TV, you can switch off
the TV display. Other functions
continue to operate normally. While
you watch TV, press the Green button
and select [Screen off].
• Low standby power: The advanced
power circuitry reduces the power
consumption of the TV to an extremely
low level, without losing out on the
constant standby functionality.
• Auto switch off: To conserve energy,
set the TV to switch off automatically
after a period of inactivity. While you
watch TV, press the Green button and
select [Auto switch off]. Then select
the period after which the TV switches
off.
• Switch off inactive devices: Switch off
connected EasyLink HDMI-CEC
(Consumer Electronic Control)
compliant devices that are inactive.
While you watch TV, press the Green
button and select [Inactive devices off].
• Power management: An advanced
power management helps save the
energy consumed by this TV. To view
how your personalized TV settings
affect the TV's relative power
consumption, press , then select
[Setup] > [Watch demos] > [Active
Control demo].
EN 6
English
Descarte do produto e de pilhas antigas
Seu produto foi projetado e fabricado com
materiais e componentes de alta qualidade,
que podem ser reciclados e reutilizados.
Baterias e Pilhas
ADVERTÊNCIA: Cuidados com a utilização
e descarte de pilhas e baterias.
Não descarte as pilhas e baterias no
•
lixo doméstico.
O descarte inadequado de pilhas e
•
baterias pode representar riscos ao
meio ambiente e à saúde humana.
Para contribuir com a qualidade
•
ambiental e com a saúde, a Envision
dispõe de pontos de coleta em suas
Assistências Técnicas.
Para evitar o vazamento de pilhas ou
•
baterias, o que pode resultar em danos à
saúde, ambientais e ao produto,
recomendamos que: (i) Remova as pilhas
do controle remoto se não for utilizá-lo
por um longo período de tempo. (ii)
Não misture pilhas (antigas com novas
ou pilhas comuns com alcalinas, etc.) (iii)
Não exponha o produto com
pilhas/baterias em seu interior a altas
temperaturas.
Pilhas e baterias descartadas recebidas
•
pelas Assistências Técnicas autorizadas
pela Envision serão encaminhadas à
destinação ambientalmente correta.
Em caso de dúvida ou consulta, favor
•
ligar para (11) 2938 0245 (Grande São
Paulo) e 0800 701 0245 (demais
regiões e estados) ou acessar o site
http://www.philips.com.br.
Linha Verde
Em caso de dúvidas relacionadas a
Sustentabilidade e Meio Ambiente, favor
ligar para a linha verde (92) 2126 8977. A
Envision e o Meio Ambiente agradecem sua
colaboração.
Energia em standby
Este modelo foi avaliado e recebeu a
classificação “A” do INMETRO, o selo Procel
da Eletrobrás para o consumo de energia em
modo de espera e a Etiqueta Nacional de
Conservação de Energia (ENCE).
EN 7
Help and support
Visit Philips website
For more information, visit the Philips
support website at
www.philips.com/support.
At the Philips support website, you can also:
• Find answers to Frequently Asked
Questions (FAQ)
• Download a printable PDF version of
this user manual
• Email us a specific question
• Chat online with Philips TV Consumer
Care (available in certain countries
only)
Use the Philips connectivity guide
An easy-to-use connectivity guide gives you
guidance on how to connect your TV to
other devices. Visit
http://www.connectivityguide.philips.com.
Search the TV forum
Your question may have already been
answered by the Philips TV community of
users. Visit
www.supportforum.philips.com.
Contact Philips
You can contact Philips TV Consumer Care
in your country for support. The number is
available in the leaflet accompanying this
product, or online at
www.philips.com/support.
Before you contact Philips, write down the
model and serial number of your TV. You
can find this information on the back of your
TV or on the TV packaging.
EN 8
English
2 Use your TV
TV controls
Sensors and indicators
1. Standby indicator LED and remote
control sensor
The standby LED indicates when your TV is
in standby. Point the remote control at the
sensor. Make sure that the line of sight
between the remote control and the TV is
not blocked.
7.
SOURCES: Watch a connected
device.
(Home): Access the Home menu.
8.
9. OK: Confirm an entry or selection.
10.
EXIT: Exit from menus or TV
functions to watch TV.
11.
through menus and select items.
(Navigation buttons): Navigate
Remote control
1. (Standby): Switch the TV on or to
standby.
2. Play buttons: Control playback of
multimedia files.
TV GUIDE: Access TV guide.
3.
4.
USB: Access USB storage device.
5. FORMAT: Change the picture
format to suit the video source.
6. SETUP: Access picture and sound
menus.
12. Color buttons: Select tasks or options.
The buttons function according to the
services offered by the service provider
13.
INFO: Display information about
current activity.
(Back): Return to the previous
14.
menu page or exit from a TV function.
OPTIONS: Access currently
15.
available options, picture and sound menus.
LIST: Access the TV channel list.
16.
EN 9
17. +/- (Volume): Adjust volume.
18.
(Mute): Mute or restore audio.
19. +/-: Switch channels.
20. 0-9 (Numeric buttons): Select TV
channels or enter text.
21. CC (Closed captions): Switch on or off
closed captions. For programs that support
closed captions.
22. . (Dot): Enter digital sub-channels.
EasyLink controls
If you connect your TV to HDMI-CEC
enabled devices, such as a Blu-ray player or
home theater, you can control them at the
same time with one remote control. Simply
switch on EasyLink after connection.
Read more about Easylink in Connect your
TV > Set up Easylink devices > Control
devices (Page 33).
Watch TV
Switch TV on or off
Switch the TV on
• Connect the TV to the mains outlet
and switch on the main power.
• If the standby LED is lit, press
the remote control.
Note: There is a short delay before the TV
responds.
Tip: If you cannot find your remote control
and want to switch on the TV from standby,
on the TV. The standby LED
press
switches off, then press
again.
Switch TV to standby
on the remote control.
Press
The standby LED on the TV switches to red.
Switch off the TV
on the TV.
Press
The standby LED switches to off.
Note: Though your TV consumes very little
energy when it is in standby or switched off,
it does use some energy. If you are not going
to use the TV for an extended period of
time, disconnect the TV from the mains plug.
Automatic switch off
You can save energy with this TV's energy
efficiency settings, which are enabled by
default. If there is no user interaction (such
as pressing a remote control button or a
control on the TV) for four hours, the TV
will automatically switch to standby.
on
EN 10
English
To disable automatic switch off
1. While you watch TV, press the Green
button on the remote control.
2. Select [Auto switch off], then press OK.
3. Use the Navigation buttons to make a
selection, then press OK.
Adjust TV volume
Increase or decrease the TV volume
• Press +/- on the remote control.
Mute or restore the TV volume
• Press
on the remote control to
mute the volume.
• Press
again to restore the volume.
Adjust headphone volume
1. Press
.
2. Select [Setup] > [TV settings] > [Sound]
> [Headphone volume], then press OK.
3. Select a level.
Switch TV channels
• Press +/- on the remote control.
• Press the Numeric buttons to enter a
channel number.
Manage favorite channels
You can view all channels or only a list of
your favorite channels.
Create a list of your favorite channels
1. Press LIST.
The channel list is displayed.
2. Select the channel to mark as favorite,
then press
OPTIONS.
3. Select [Add/remove favorites], then press
OK.
The selected channel is marked with a star.
To remove a channel from the favorites list,
select [Add/remove favorites], and then
press OK.
Display your list of favorite channels
1. Press
LIST, then press OPTIONS.
2. Select [List] > [Favorites] to display
channels in the favorite list.
3. Press OK to confirm.
Manage channel lists
After the channels are installed, you can:
• Filter channels.
• Switch between antenna and cable
channels.
• Rename channels.
• Lock a channel.
Filter channels
1. While you watch TV, press
2. Press
3. Select an option, then press OK.
• [Digital + Analog]: Display all channels
OPTIONS, then select [Filter].
in the channels list.
• [Digital TV channels]: Display only
digital channels.
• [Analog channels]: Display only analog
channels.
Note: The filtering options may vary
according to your broadcaster.
LIST.
EN 11
Switch between antenna and cable channels
You can switch between antenna and cable
channels.
1. While you watch TV, press
.
2. Select [Setup] > [Channel settings] >
[Channel installation] > [Antenna
connection].
3. Select [Antenna] to watch antenna
channels or [Cable] to watch cable channels,
then press OK.
Rename channels
When you select a channel, its name appears.
You can change this channel name.
1. While you watch TV, press
LIST.
The channel list is displayed.
2. Select the channel to rename, then press
OPTIONS.
3. Select [Rename], then press OK.
The onscreen keyboard is displayed.
4. Press the Navigation buttons to select
each character, then press OK.
5. Once complete, select [Done], then press
OK to confirm.
Lock a channel
You can prevent unauthorized access to
channels by locking them.
1. While you watch TV, press
LIST.
The channel list is displayed.
2. Select the channel to lock, then press
OPTIONS.
3. Select [Lock channel], then press OK.
4. If prompted, enter the pin code.
The channel is marked with a lock icon in
the channels list.
Tip: To watch a locked channel, enter the
pin code when prompted.
Watch connected devices
Before you can watch a device, connect the
device to the TV. See Connect your TV >
Connect devices (Page 25).
Select a device with SOURCES
1. Press
SOURCES.
2. Select a device, then press OK.
Select a device from the Home menu
1. Press
.
2. Select [Source], then press OK.
3. Select the device, then press OK.
To add or manage your connected devices,
see Connect your TV > Watch connected
devices > Change device settings (Page 32).
Use picture and sound presets
Your TV comes with predefined picture and
sound settings. You can apply these settings
or customize them.
Select your preferred picture settings
1. While you watch TV, press
2. Select [Picture and sound] > [Picture
style], then press OK.
3. Select an option, then press OK:
• [Personal]: Apply your personalized
picture settings.
• [Vivid]: Rich and dynamic settings, ideal
for daytime viewing.
• [Football]: Ideal settings for football
matches.
• [Standard]: Default settings that suit
most environments and types of video.
• [Movie]: Ideal settings for movies.
• [Photo]: Ideal settings for photos.
• [Energy saving]: Settings that conserve
the most energy.
OPTIONS.
EN 12
English
Select your preferred sound settings
1. While you watch TV, press
OPTIONS.
2. Select [Picture and sound] > [Sound
style], then press OK.
3. Select an option, then press OK:
• [Personal]: Apply your personalized
sound settings.
• [Original]: Settings that suit most
environments and types of audio.
• [Movie]: Ideal settings for movies.
• [Music]: Ideal settings for listening to
music.
• [Game]: Ideal settings for games.
• [News]: Ideal settings for spoken audio,
such as the news.
Change picture format
You can change the picture format to suit
the video source.
1. Press
2. Select a picture format, then press OK.
The available picture formats depend on the
video source:
• [Auto fill]: Adjust the picture to fill the
• [Auto zoom]: Enlarge the picture to fill
• [Super zoom]: Remove the black bars
• [Movie expand 16:9]: Scale 4:3 format
• [Wide screen]: Shows widescreen
• [Unscaled]: Provide maximum detail for
• [16:9 stretch]: Scale 4:3 format to 16:9.
• [4:3]: Display the classic 4:3 format.
FORMAT.
screen (subtitles remain visible).
Recommended for minimal screen
distortion but not for HD or PC.
the screen. Recommended for minimal
screen distortion but not for HD or PC.
on the sides of 4:3 broadcasts. Not
recommended for HD or PC.
to 16:9. Not recommended for HD or
PC.
format content unstretched. Not
recommended for HD or PC.
PC. Only available when PC mode is
selected in the Picture menu.
View program guide
What you can do
You can view channel schedules and
program synopses for digital TV channels
using program guides provided by the
broadcasters. The availability of program
guides is dependent on your broadcaster.
You cannot view a channel's program guide
information if:
• the age rating of the channel is equal or
higher than the age rating set on your
TV.
• the channel is locked.
From the broadcaster
Access broadcaster program guide
1. Press .
2. Select [TV guide], then press OK.
3. If you are viewing the program guide for
the first time, follow the onscreen
instructions to update the guide.
Customize broadcaster program guide
You can customize the displayed information
to:
• Remind you when programs start.
• Change day of display.
Note: Options may vary according to the
program information available from the
broadcaster.
1. In the program guide, press
OPTIONS.
2. Select an option, then press OK:
• [Update TV guide]: Update program
guide information.
• [Change day]: Select the day to display
program guide.
• [Search by genre]: Search programs by
genre.
EN 13
Play multimedia files
What you can do
You can play videos, photos, and music on
your TV from a USB device connected to
the TV.
Play files from USB device
If you have photos, videos or music files on a
USB storage device, you can play the files on
TV.
Caution:
• Envision is not responsible if the USB
storage device is not supported, nor is
it responsible for damage or loss of
data in the device.
• Do not overload the USB port. If you
connect a USB storage device that
consumes more than 500mA power,
make sure that it is connected to its
own external power supply.
Browse USB device
1. Connect the USB device to the USB
connector on the TV.
2. Press
then press OK.
3. Select a file from the content browser,
then press OK to start play.
4. Press the Play buttons to control play.
Tips:
• Select any of the options on the left of
Play options
Watch video
1. Select .
2. Press the Navigation buttons to select a
video file, then press OK to control play.
• Press
• To search forward or backward, press
• To stop the video, press
SOURCES, select [USB], and
the content browser to filter your files
by type.
to exit the content browser.
or . Press repeatedly to toggle
between different speeds.
.
Video options
While you play video, press OPTIONS,
then press OK to select an option:
• [Subtitles]: Switch on or off closed
captions. You can also select to display
the closed captions only when the TV is
muted.
• [Audio language]: Select an audio
language.
• [Repeat]: Select [Play once] to play all
of the video files once. Select [Repeat]
to play all of the video files repeatedly.
• [Show info]: Display the video
information.
• [Eco settings]: Adjust to save energy.
Note:
To view information about a video (for
example, played position, duration, title, or
date), select the video, then press
INFO.
To hide the information, press INFO
again.
Listen to music
1. Select
.
2. Press the Navigation buttons to select a
music track, then press OK to control play.
• Press
to exit the content browser.
• To search forward or backward, press
or . Press repeatedly to toggle
between different speeds.
• To stop the music, press .
Music options
While you play music, press OPTIONS,
then press OK to select an option:
• [Repeat]: Select [Play once] to play all
of the music files once. Select [Repeat]
to play all of the music files repeatedly.
• [Shuffle]: Enable or disable random play
of tracks.
• [Show info]: Display the music
information.
• [Eco settings]: Adjust to save energy.
Note:
To view information about a song (for
example, title, artist or duration), select the
song, then press
To hide the information, press
INFO.
INFO
again.
EN 14
Loading...
