Rechargeable
Cordless Razor
Rechargeable
Cordless Razor
3605X/
3604X/
360 1X
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric razor, basic precautions should
always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a razor that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in a shower.
3. Do not place or store razor where it can fall or be
pulled into a tub or sink.Do not place or drop into
water or other liquid.
4. Always unplug this razor from the electrical outlet
immediately after using.
5. Unplug this razor before cleaning.
WARNING
To reduce the risk of burns,fire, electric shock, or
injury to persons:
1. Close supervision is necessary when this razor is used by,
on,or near children or invalids.
2. Use this razor for its intended household use as described
in this manual.Do not use attachments not recommended
by Philips Electronics North America Corporation.
3. Never operate this razor if it has a damaged cord or plug,
if it is not working properly,if it has been dropped or
damaged,or dropped into water. Return the razor to an
Authorized Norelco Service Location for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug in razor outdoors or operate where
aerosol (spray) products are being used or where oxygen is
being administered.
7. Do not use this razor with a damaged or broken comb, as
facial injury may occur.
8. Always attach plug to razor first,then to outlet.Be cer tain
that plug is inserted firmly into razor, up to mark indicated
on plug. To disconnect, turn razor off then remove plug
from outlet.
9. Never put the razor in direct sunlight or store in
a pouch at a temperature above 140ºF.
SAVE THESE
INSTRUCTIONS
IMPORTANT
Your razor contains NICKEL-CADMIUM RECHARGEABLE
BATTERIES. See Battery Removal instruction sheet for
battery disposal information.
60 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Norelco Men’s
Razor, the razor should be used exclusiv
ely for 3 weeks. This allows your hair
and skin enough time to adapt to the Norelco Shaving System.If, after that
period of time, you are not fully satisfied with your Norelco Men’s Razor, send
the product back and we’ll refund you the full purchase price.
The razor must be shipped prepaid by insured mail, insurance prepaid,
and have the sales slip, indicating purchase price and the date of
purchase, enclosed. The razor must be postmarked no later than 60 da
ys
after the date of purchase. Norelco reserves the right to verify the purchase
price of the razor and limit refunds not to exceed suggested retail price.
Send dated sales slip,your complete name and address as indicated
below, and the razor, prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
P.O.Box 1116
Skokie, IL 60076
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Telephone No. (____)____________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
AREA CODE
Table of Contents
FEATURES 2 - 3
INDICATIONS 4
CHARGING 4
SHAVING 5
TRIMMING 6
CLEANING 6 - 9
ASSISTANCE 10
ACCESSORIES 10
BATTERY REMOVAL 10
WARRANTY Back Cover
2.
How the Norelco Lift and Cut®Patented
Shaving System Makes Close Comfortable:
Groove channels beard
closer to cutting system
Lifter raises hair Blade cuts hair which
then drops below skin level
3.
Pop-Up Trimmer
Cleaning Brush
Travel/Storage Pouch
(model 3605X only)
Rechargeable-Shaves
without a cord
Cordless-To shave
without a cord
Full 2-Year Warranty
NOTE:The Voltage Selector on
your razor makes it possible to
charge/recharge razor on either 100
to 130V AC or 220 to 240V AC.Do
not use with Direct Current (DC).
FEATURES
Double Action
Shaving System
Razor Head Assembly
Protective Razor
Head Cap
Hair Chamber captures
shaven hair
Locking ON/OFF Switch
LED Charging
Indicator Light
Built-In Charger
4.
INDICATIONS
LED Charging Indicator Light
The green LED Charging Indicator Light will light up to
indicate razor is (re)charging.
CHARGING
Battery performance is best if you recharge only when
the batteries are (almost) completely empty.
Charging or recharging at temperatures below 40ºF or
higher than 95ºF adversely affects lifetime of batteries.
Continuously recharging will reduce life of batteries.
If razor has not been used for at least 1 month,razor must
be recharged for a full 16 hours.
Do not charge razor in pouch (model 3605X only).
1 Before charging,set Voltage Selector to desired setting.
To change voltage from 115V to 230V AC , slide switch
found on bottom of razor to desired voltage.
2 Connect cord to razor. Plug into any 120V to 240V AC
outlet.Use only the cord provided.
An adaptor plug may be necessary for cord usage in some
foreign countries.
3 First time charging and recharging after non-use for
1 month or more requires a full 16 hours.
5.
SHAVING
Use your new razor exclusively for 3 weeks to fully enjoy
the closeness of a Norelco shave.*
At first you may not get as close a shave as you expect,
or your face may even become slightly irritated. This is
normal since your beard and skin will need time to adjust.
Invest 3 weeks and you'll soon experience the full joy
of your new razor.
* Stick with it! If you alternate shaving methods during
the adjustment period,it may make it more difficult to
adapt to the Norelco shaving system.
Shaving with skin dry gives the best results.
1 Turn razor ON.Shave against the direction of beard growth
using both straight and circular movements.
2 Stretch your skin with your free hand so blades can lift
and cut whiskers.Gently press razor to skin.
3 Turn razor OFF.
4 Put the protective razor head cap on the razor to
protect razor heads.
5 Replace your Norelco Double Action razor heads
(model # HQ4) once a year for optimal shaving results.
6.
TRIMMING
To groom sideburns and moustache:
1 Turn razor ON.
2 Push up Trimmer Slide Switch.
3 Hold Trimmer as shown and move in downward strokes
with gentle pressure.
4 Close Trimmer by sliding Trimmer switch down.
5 Turn razor OFF.
CLEANING
Once A Week:Razor
1 Turn razor OFF.
2 Clean the top of the razor with the supplied brush.
3 Remove Razor Head Assembly from the razor unit.
7.
4 Brush the inside of housing and Razor Head Assembly.
5 Replace the Razor Head Assembly back on razor.
Every Two Months:Razor Heads
1 Turn razor OFF and disconnect from outlet.
2 Remove Razor Head Assembly from housing unit.
3 Brush the inside of the housing.
4 Turn Razor Head Assembly over so that the
underside is exposed.
5 Press down and turn wheel of frame counterclockwise.
6 Remove the frame and brush clean.
8.
7 Slide and remove one cutter and head at a time to clean.
• Be careful not to mix up cutters and heads.They
are a matched set and if interchanged,it will greatly
affect shaving performance.
8 Separate the cutter from the head.
9 Only brush the cutter in an upward motion.
Use the short bristled side of the brush.
10 Brush the slots of the razor head.
For optimum performance,razor cutters and heads
should be cleaned in a degreasing liquid (e.g.Norelco
Razor Cleaner or alcohol) and lubricated with Norelco
Razor Lubricant,model AL80,or one drop of mineral oil
(in the center of the head).
11 Replace the cutter into head section.Slide razor head
back into frame making sure that flat rim of cutting
heads slides under 2 clamps on frame.
12 Repeat the process for the other two razor heads
(cutters and heads).
13 Replace the frame.
9.
14 Press down and turn the wheel clockwise until it locks
into place.
15 Replace the Razor Head Assembly back on razor.
After Each Use:Trimmer
1 Turn razor OFF.
2 Push Trimmer Slide Switch up to pop-up Trimmer.
3 Clean Trimmer with the brush every time you use it.
4 Lubricate the Trimmer teeth with Norelco Razor
Lubricant (model AL80), or with one drop of mineral
oil every 6 months.
5 Close Trimmer by sliding Trimmer switch down.
FULL TWO YEAR WARRANTY
Philips Electronics North America Corporation warrants each new Norelco Product,Models 3605X/3604X or
3601X (except cutters and combs) against defects in materials or workmanship for a period of two years from
the date of purchase,and agrees to repair or replace any defective product without charge.
IMPORTANT: This warranty does not cover damage resulting from accident, misuse or abuse , lack of
reasonable care,the affixing of any attachment not provided with the product or loss of parts or subjecting the
product to any but the specified voltage.* Use of unauthorized replacement parts will void this warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION WILL NOT PAY FOR
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE AND WILL
NOT REIMBURSE THE CONSUMER FOR DAMAGE RESULTING FROM WARRANTY
SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE. NO RESPONSIBILITY IS
ASSUMED FOR ANY SPECIAL,INCIDENTAL OR CONSEQUENTIAL DAMAGES.
In order to obtain warranty service,simply take or ship the pr oduct postage prepaid to the nearest Authorized
Norelco Service Location.It is suggested that for your protection you return shipments of product by insured
mail,insurance prepaid.Damage occurring during shipment is not covered by this warranty.
NOTE: No other warranty, written or oral, is authorized by Philips Electronics North America Corporation.
This warranty gives you specific legal rights,and you may also have other rights which vary from state to state.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
exclusion and limitations may not apply to you.
* Read enclosed instructions carefully.
Manufactured for:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd., Stamford,CT 06912-0015
MADE IN HOLLAND.
This symbol on the product’s nameplate means it is
listed by Underwriters’ Laboratories,Inc.
Norelco,Lift and Cut, RAZORMATE and are Registered Trademarks of
Philips Electronics North America Corporation.
is a Trademark of Philips Electronics North America Corporation.
PHILIPS and Philips Shield are Registered Trademarks of Koninklijke Philips Electronics N.V.
© 1999 Philips Electronics North America Corporation. All Rights Reserved.
®
LISTED
TM
10.
ASSISTANCE
For assistance or the Authorized Norelco Service
Location nearest you,call toll free:
1-800-243-3050
or visit our website:www.norelco.com
Authorized Norelco Service Location information is
available 24 hours a day,7 days a week.
ACCESSORIES
Replacement Heads
• Model HQ4 - For maximum razor performance, replace
your Norelco Double Action razor heads once a year.
Razor Cleaners
• ERC100 - Norelco RAZORMATE ® Electrosonic
Heads Cleaner
• RC1776 - Norelco Razor Cleaner
Razor Lubricant
• AL80 - Norelco Razor Lubricant
Norelco Razor Accessories may be purchased at a store
near you,an Authorized Norelco Service Location or by
the order form enclosed.
BATTERY REMOVAL
This Norelco razor contains rechargeable NickelCadmium batteries,which must be disposed of properly.
Batteries should only be removed when razor is to
be discarded.
Refer to enclosed instruction sheet for directions on
removing the rechargeable batteries.
Loading...
