Philips 32PHD5505/71 user manual

Register your product and get support at:

www.philips.com/TVsupport

32PHT5505

43PFT5505

EN User Manual

Table of contents

1 Caution 2

2 Important 3

Safety 3

3 Overview of your TV 5

Remote control 5
Using the remote control 6

4 Using the TV 7

Switching the TV on or off 7
Switch channels 7
Adjust the TV volume 8

5 Other uses of the TV 9

Accessing the TV menu 9
Changing the picture and sound settings 9
Function settings 10
Using the timer 11

Playing multimedia les from USB devices 12

Updating the TV software 13
Restoring factory settings 13

7 Connecting the TV 17

Down ports 17
Side ports 17
Connecting to a computer 18
Using Philips EasyLink 19

8 Product information 20

Display resolutions 20
Multimedia 20
Audio output power 20
Intrinsic resolution 20
Tuner/reception/transmission 20
Remote control 20
Power supply 20
Suppor ted TV mounts 21

9 Troubleshooting 22

10 Warranty 25

English

6 Setting up channels 14

Setting up channels automatically 14
Swapping channels 14
Renaming channels 14
EPG 14
Recording option 15
Time-shift option 15

1EN

®

1 Caution

2019© TP Vision Europe B.V. All rights reserved.
Specications are subject to change without

notice. All trademarks are the proper ty of
Koninklijke Philips N.V. or their respective

owners. TP Vision Europe B.V. reserves the right

to change products at any time without being
obliged to adjust previously supplied products.
The material in this manual is adequate for
the intended use of the system. If the product,
or its individual modules or procedures, are

used for purposes other than those specied
herein, their validity and suitability must rst
be conrmed. TP Vision Europe B.V. warrants

that the material itself does not infringe upon
any patents from the United States. No further
warranty is expressed or implied.

TP Vision Europe B.V. accepts no responsibility

for any errors in the content of this document,
nor for any issues that arise due to the content
of this document. Errors reported to Philips

will be rectied and published on the Philips

support website as quickly as possible.

Terms of warranty

• Risk of injury, damage to the TV or voided
warranty! Never attempt to repair the TV
yourself.

• Please only use the TV and accessories as
set out by the manufacturer.

• The caution sign printed on the back of
the TV indicates the risk of electric shock.
Never remove the TV cover. Please contact
Philips Customer Support if repairs are
needed.

• Operations expressly prohibited in this
manual, or any adjustments and assembly
steps that are not recommended or
authorised in this manual, are not within
the scope of the warranty.

Pixel characteristics

This LCD/LED product has a high number
of colour pixels. Although its proportion of
effective pixels is 99.999% or more, black dots
or bright points of light (red, green or blue)
may appear persistently on the screen. This
is a structural proper ty of the display (within

common industry standards), and is not a fault.

Mains fuse (/56)

This TV is tted with an approved moulded

plug. Should the mains fuse need replacing, it
must be replaced with a fuse of the same value
as indicated on the plug (e.g. 10A).

1 Remove the fuse cover and fuse.
2 The replacement fuse must comply with

BS 1362 and carry the ASTA approval

mark. If the fuse is lost, please contact your

dealer to conrm the correct type.

3 Ret the fuse cover.

Copyright

®

Kensington and Micro Saver are registered US
trademarks of ACCO World Corporation with
issued registrations and pending applications
in other countries and regions throughout the

world.

HDMI, the HDMI logo and High-Denition

Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC
in the United States and other countries and
regions.
All other registered and unregistered
trademarks are the proper ty of their respective

owners.

This product is manufactured under license
from Dolby Laboratories. Dolby, Dolby Audio
and the double-D symbol are registered
trademarks of Dolby Laboratories.

2 EN

2 Important

Please read and make sure you understand all
instructions before using the TV. Damage caused by
a failure to follow the instructions is not covered by

the warranty.

Safety

Risk of electric shock or re!

• Never expose the TV to rain or water. Never
place liquid containers (such as vases) next
to the TV. If liquids are spilt on or inside the
TV, disconnect the TV from the power supply
immediately. Contact the Philips Customer
Service Centre to have the TV checked before
you use it again.

• Never place the TV, remote control or
batteries near naked ames or other heat

sources (including direct sunlight).

To avoid re spreading, always keep candles or
other naked ames away from the TV, remote

control and batteries.

• Never insert any objects into the ventilation
slots or other openings on the TV.

• Make sure that no strain is placed on the
power cable when swivelling the TV. Strain on
the power cable can loosen connections and
cause arcing.

• The power plug of the TV must be
disconnected to disconnect the TV from the
mains supply. When you disconnect the power,
always pull out the power plug, and never the
cable. Ensure that the power plug, power cable
and outlet socket are accessible at all times.

• The power plug is a disconnection device and
should be kept so that it is easy to operate.

Risk of short circuit or re!

• Never expose the remote control or batteries
to rain, water or excessive heat.

• Avoid pulling the power plug. Loose power
plugs can lead to arcing or re.

Risk of personal injury or damage to the TV!

• TVs weighing more than 25 kg must be
carried by at least two people.

• Use the stand supplied when mounting the TV
on a stand. Secure the TV to the stand tightly.

Place the TV on a at, level surface that can

bear the weight of the TV and the stand.

• When mounting the TV on a wall, use a wall
mount that can bear the weight of the TV.
Secure the wall mount bracket to a wall that
can bear the total weight of the TV and the

wall mount. TP Vision Europe B.V. accepts no

responsibility for improper wall mounting
leading to accident, injury or damage.

• Remove the stand from the TV when storing
the TV. Never place the TV face down with the
stand attached.

• Before connecting the TV to the power outlet,

make sure that the power voltage matches
the value printed on the back of the TV. Never
connect the TV to the power outlet if the
voltages do not match.

• This product contains glass parts. Handle with
care to avoid injury or damage.

Risk of injury to children!

Follow these precautions to prevent the TV from
toppling over and injuring children:

• Never place the TV on a surface covered by
a cloth or other material that can be pulled
away.

• Make sure that no part of the TV hangs over
the edge of the supporting surface.

• When you place the TV on high furniture
(such as a bookcase), both the furniture and
the TV must be secured either to the wall or a
suitable support.

• Educate children on the dangers of climbing
on furniture to reach the TV.

Risk of swallowing batteries!

• The product/remote control may contain
coin-type batteries, which can easily be
swallowed. Keep these batteries out of reach
of small children at all times!

Risk of overheating!

• Never install the TV in a conned space.

Leave a space of at least 4 inches (10 cm)
around the TV for ventilation. Ensure that the
ventilation slots on the TV are not covered by
curtains or other objects.

English

3EN

Risk of injury, re or power cord damage!

• Never place the TV or any objects on the
power cable.

• Disconnect the TV from the power outlet
and antenna before lightning storms. During
lightning storms, never touch any part of the
TV, power cable or antenna.

Risk of damage to hearing!

• Avoid the use of earphones or headphones
at high volume for prolonged periods.

Low temperatures

• If the TV is transported in temperatures
below 5°C (41°F), unpack the TV and wait
for it to reach room temperature before
connecting the TV to the power outlet.

• Displaying static images from video games
and computers for extended periods may
cause an afterimage and ghosting due to
screen burn. Reduce the screen brightness
and contrast accordingly when using the TV
in this way.

Any afterimages, ghosting or marks displayed
on the TV screen due to the causes mentioned
above are not covered by the warranty.

Recycling

Screen care

• Avoid static images as much as possible.
Static images are images that remain
onscreen for extended periods. Examples
include onscreen menus, black bars and
time displays. If you must use static images,
reduce the screen contrast and brightness
to avoid screen damage.

• Unplug the TV before cleaning.

• Use a soft damp cloth to wipe the TV and

frame. Never use substances such as alcohol,
chemical products or household cleaners to
clean the TV.

• Risk of damage to the screen! Never touch,
push, rub or strike the screen with an object.

• Wipe off any water as quickly as possible to
avoid deformation and discolouration.

Note

Static images may cause permanent damage to
the TV screen.

• Do not display static images on LCD TV
screens for longer than 2 hours, as this
can cause ghosting onscreen. To prevent
ghosting, reduce the brightness and contrast
of the screen when displaying static images.

• Watching programmes in 4:3 format for
extended periods may leave different marks
on the left and right of the screen and the
border of the image. Therefore, avoid using
this mode for prolonged periods.

This product has been manufactured using high­performance materials and components that can
be recycled and reused.

When the crossed-out wheeled bin symbol is
attached to a product, the product is covered
by European Directive 2002/96/EC. Familiarise
yourself with your local separate collection
system for electrical and electronic products.
Follow local regulations and do not dispose of
your old products with normal household waste.
Proper disposal of old products helps to prevent
potential harm to the environment and human
health.

This product contains batteries covered by
European Directive 2006/66/EC. These batteries
cannot be disposed of together with normal
household waste.
Educate yourself on local regulations covering
the separate collection of batteries, as proper
battery disposal helps to prevent harm to the
environment and human health.

4 EN

3 Overview of

4

1

5

3

2

Remote control

your TV

Congratulations on your purchase and welcome

to Philips! To fully benet from the support

offered by Philips, please register your TV at
www.philips.com/TVsupport.

Control panel

a Volume+: Without the key menu, the

volume-up function is available.

b Volume-: Without the key menu, the

volume-down function is available.

c Channel-: When there is no keyboard

menu, switch to the prior channel function;
when the keyboard menu appears, move
up and down the appropriate options.

d Channel+: When there is no keyboard

menu, switch to the next channel function;
when the keyboard menu appears, move
up and down the appropriate options.

e Signal source/OK: In standby, the signal

source/OK key is used as a power key.
Press this key to boot.
After booting, the signal source/OK key is
used to open the keyboard menu functions.

Note: In USB mode, the signal source/OK

key has no function.

22

21

20

19

SOURCES EXIT

18

17

16

15

14

SETUP

FORMAT

OPTIONSINFO

LISTBACK

a (Standby/On)

Switch the TV on or to standby.

b Playback buttons

Control video, music or text.

c FORMAT

Change picture format.

d (Home)

Access or exit from the main menu and
return to the previous menu.

English

1

2

3
4

5

6

7

8

9

10

11

12

13

5EN

e EXIT

Switches to TV.

f OPTIONS

In TV mode, access Options to select audio.

g (Navigation buttons)

Navigate through menus and select items.

h OK

Conrm an entry or selection.

i LIST

Access or exit from the TV channel list.

j CH +/- (Channel +/-)

Changes channels; scrolls up/down through

the options in USB mode.

k (Mute)

Mute or restore audio.

l 0-9 (Numeric buttons 0-9)

Select channel.

m TEXT

Enable or disable teletext.

n SUBTITLE

Select the subtitles.

o +/- (Volume)

Adjust volume.

p BACK

Return to the previous menu or exit from a
certain function , and switch to the previous
channel or signal source.

q INFO

Display information about current activity.

r Color buttons

Select tasks or options.

s SOURCES

Select connected devices

t SETUP

Accesses TV setup menu.

u TV GUIDE

Accesses or exits the TV guide.

v Red dot

Recording function.

Using the remote control

When you use the remote control, hold it close
to the TV and point it at the remote control
sensor. Make sure that the line-of-sight between
the remote control and TV is not blocked by
furniture, walls or other objects.

5m

30

6 EN

4 Using the TV

Switch channels

This section helps you to perform basic TV
operations.

Switching the TV on or off

Standby indicator

To switch on

• Plug in the power plug.

» If the standby indicator is red, press

(Standby-On) on the remote control.

To switch to standby

• Press (Standby-On) on the remote
control.

» The standby indicator switches to red.

Tip

• Though your TV consumes ver y little power when

in standby mode, energy continues to be consumed.
When not in use for an extended period of time,
disconnect the TV power cable from the power outlet.

4

2

• Press CH+/- on the remote control or the
lower right section of the TV.

• Enter a channel number using the numeric
buttons on the remote control.

• Press on the remote control to switch
and return to the previous channel.

1

5

3

View installed channel

All available channels can be viewed in the
channel list.

LIST

1 Press LIST.

» The channel list appears.

2 Press to select channels and to

browse the channel list.

3 Press OK to watch the selected channel.
4 Press to switch and return to the last

watched channel.

English

7EN

Watch connected devices

Note

• Switch on the device before selecting it as an external

signal source.

Use the Souces button

SOURCES

1 Press SOURCES.

» The source list appears.

2 Press to select a device.
3 Press OK to conrm.

» The TV switches to the selected

device.

Adjust the TV volume

4

2

To increase or decrease volume

• Press VOL +/- on the lower right section
of the TV or the Volume control +/- on
the remote control.

To mute or unmute sound

• Press (Mute).

• Press again to restore the sound.

1

5

3

8 EN

5 Other uses of

the TV

Accessing the TV menu

The menu helps you set up channels, change
the picture and sound settings, and access other
functions.

1 Press (Home) .

» The menu screen is displayed.

Philips TV

Channels

Sources

Ulies

Sengs

Select to view the list of sengs

offered in this TV

2 Select [Setting].
3 Press to select from the following

options:

• [Picture] / [Sound] / [TV] (only shown in
TV mode) / [Settings] / [Parental] (only
shown in TV mode) /[EasyLink].

4 Press OK to confirm.
5 Press

Changing the picture and
sound settings

You can change the picture and sound settings
to suit your preferences. You can use the preset
settings or manually adjust the settings.

(Home)

previous menu.

to exit or return to the

Adjusting the picture settings

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Picture].

» The [Picture] menu is displayed.

2 Press to select/adjust the settings:

• [Smart Picture]:

• [Standard]: standard picture settings.

This option is recommended for home
entertainment use.

• [Vivid]: increases the contrast and
sharpness of the picture.

• [Movie]: applies to lm settings and works

best in a home cinema environment.

• [Natural]: increases the softness of the
picture.

• [Personal]: you can customise your settings

• [Brightness]: adjusts the intensity and detail of

• [Video Contrast]: adjusts the intensity and

• [Color]: adjusts the colour saturation (the

• [Tint]: adjusts the level of green (this option

• [Sharpness]: adjusts the sharpness of the image

• [Color Temperature]:

• [Advance Control]:

with this option.

dark areas (the adjustments made can only be
saved in personal settings).

detail of bright areas, while dark areas remain
unchanged (the adjustments made can only be
saved in personal settings).

adjustments made can only be saved in
personal settings).

only appears when using the NTSC system).

(the adjustments made can only be saved in
personal settings).

• [Cool]: gives a bluish-white hue.

• [Normal]: gives a white hue. Users can

customise the white hue when in PC
mode.

• [Warm]: gives a reddish-white hue.

• [Noise Reduction]: lters and eliminates

signal noise in the image.

• [Backlight]: adjusts the screen brightness
(when the backlight is set to a low value,

a brief white icker may be seen when

switching the TV on. This is normal).

• [Dynamic Contrast]: sets the contrast to
maximum.

• [Dynamic Backlight]: the contrast changes
with the brightness of the image.

Note

•

Options may vary for pictures from different sources.

English

9EN

Adjusting the sound settings

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Select [Sound].

» The [Sound] menu is displayed.

2 Press to select and adjust the settings:

• [Smart Sound]:

• [Standard]: gives balanced,

outstanding sound performance in
the treble, mid and bass ranges.

• [Music]: enhances treble and bass,
delivering bright, clear, pure sound
for piano or orchestral instrument
performances.

• [Movie]: enhances lm sound effects,

allowing you to enjoy a home
cinema-like effect.

• [Speech]: enhances the performance
of sound ranges associated with the
human voice spectrum. This option
is suitable for watching news or arts
programmes.

• [Flat]: enhances the smoothness of
the sound output, creating a softer
sound.

• [Personal]: provides users with
customisation functions so that
all sound effect parameters are
optimised to create the best
possible experience.

• [Balance]: adjusts the balance of the left
and right speakers.

• [Bass]: adjusts the base level (the
adjustments made can only be saved in
personal settings).

• [Treble]: adjusts the treble level (the
adjustments made can only be saved in
personal settings).

• [Virtual Surround]: enables virtual
surround sound: switching on or off.

• [AVL]: turns automatic volume adjustment
on when switching channels.

• [SPDIF MODE]: selects the coaxial output
mode.

• [Audio Delay]: delays the sound output.

• [TVSpeakers]: turns sound on the TV on

and off.

• [Clear Sound]: turns speech on and off.

• [TV Placement]: adjusts the means of the

TV placement.

Function settings
1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Settings].

» The [Settings] menu is displayed.

2 Press to select and adjust the settings:

• [Menu Language]: adjusts the language
settings of the TV.

• [Picture Format]: the majority of signals
use 16:9, 4:3, zoom 1 and zoom 2 formats.
HDMI signal sources use 16:9, 4:3, Point to
Point, zoom 1 and zoom 2 formats.

• [Menu Timeout]: sets how long the menu
is displayed.

• [Blue Screen]: sets the colour of the
screen when the TV receives no signal
(when the TV signal is not functioning).

• [Auto Sleep]: sets how long the TV
must be idle for before switching off
automatically (not applicable to PC mode).

• [Sleep Timer]: sets when the TV
automatically enters standby mode.
The options are: off/10/20/30/60/90/
180 minutes..

• [Time Setup]: sets the system time.

• [Freeze Switch]: sets the freeze screen

for switching channels (only available in TV
mode).

• [TTX Language]: sets the Teletext language
(only available in TV and video modes).

• [Color System]: sets the AV colour system
(only displayed in AV mode).

• [HDMI Mode]: sets the HDMI mode (only
displayed in 480p/576p/720p/1080p HDMI
modes).

• [PVR File System]: before carrying out
PVR operations, the USB ash drive must

be formatted and memory space allocated.

• [Enable OAD Upgrade]: enables and
disables OAD updates.

• [Reinstall TV]: restores all settings to
default and reopens the installation wizard
menu.

• [Reset]: restores the default settings
(excluding password settings and channel
information).

• [Software Version]: checks the current
software version.

10 EN

Changing the picture format

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Settings].

2 Press to select [Picture Format].
3 Select a picture format.
4 Press OK to conrm.

Using the timer

You can set the timer to switch the TV to standby
mode at a set time.

Tip

•

Set the sleep timer before using the timer function.

English

Summary of picture formats

The following picture formats can be congured.

Note

•

Some picture settings may be unavailable due to
differences between picture signal formats.

[16:9]: adjusts the normal
standard ratio to a
widescreen format.

[4:3]: the normal standard
format.

[Zoom 1]: horizontal
scaling for the widescreen
picture format. When this
format is used, the left and
right of the frame will be
partially cut off.

[Zoom 2]: adjusts the
standard ratio to a
widescreen format

(only 16:9, 4:3 and Point to
Point options are available
in PC mode).

[Point to Point]: used for
HDMI connections with
PCs. This displays the full
PC screen to achieve the
best display results.

Setting the sleep timer

Tip

•

You can turn the TV off in advance or reset the sleep
timer when the timer is up.

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Settings].

2 Press to select [Sleep Timer].
3 Press to select a time for the sleep timer

to switch the TV off.
» The longest time that the sleep timer can

be set for is 180 minutes.

TV lock

By locking the TV remote control, you can prevent
children from watching specic programmes or

channels.

Setting or changing your password

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Parental].

2 Enter the password using the numeric buttons

on the remote control.

3 Select [Change Password] and follow the

instructions onscreen to change the password.

Locking channels

1 Press (Home) and select [Setting] to enter

the [Setting] menu. Then select [Parental].

2 Enter the password and select [Parental

Rating].

3 Adjust the channel locking rating.

11EN

4 Repeat this step to adjust the channel ratings.

• [Parental Rating]: when channels are
locked:

• Enter the four-digit password to
access the channel blocking menu.

• Enter the four-digit password to view
locked channels.

• Enter the four-digit password to
access the parental lock menu.

• [Clear All]: this function will clear all
previously saved locked channels and signal
sources.

• The default password is ‘0000’. Users
may change or set the password
themselves.

2 Connect the USB storage device to the

USB port on the side of the TV.

3 Press (SOURCES).
4 Select [USB] and press OK.

» The USB browser will open.

Viewing photos

1 Select the photo within the USB browser

and press OK. The photo will be enlarged

to ll the screen.

• Press CH- or CH+ to see either the

previous or the next photo.

Starting slide shows

Note

•

If you go to a locked channel, you will be prompted to
enter the password.

Playing multimedia les from

USB devices

You can play photo, music or video les stored on a
USB storage device on your TV.

• Supported storage devices: USB (only FAT or
FAT 32 USB storage devices are supported)

• Supported multimedia le formats:

• Images: JPEG

• Audio: MP3

• Video: MPEG 2/MPEG 4, H.264

• Documents: TXT

Note

•

TP Vision assumes no responsibility if a USB storage

device is not supported, or if the data on the device is
damaged or lost.

Viewing photos and text les and playing
audio and video les

1 Turn the TV on.

1 Select a photo or folder and then press

OK. The photo will be enlarged to ll the

screen.

» The slide show will start playing from

the selected photo.

2 Press the following buttons to control the

playback of photos:

• or : play or pause

• CH- or CH+: view either the previous

or the next photo.

Changing the slide show settings

To star t playing a slide show, press (Option)
and select one of the following options, then
press OK.

• [Rotate]: sets the images to rotate.

• [Duration]: sets the duration of the slide

show.

Listening to music

1 In the USB browser, select a song or album.

Then press OK to begin playing.

Changing the music settings

• or : to play or pause.

12 EN

• : switches to the previous/next song.

• : for rewinding or fast forwarding.

Watching videos

1 Select the video le in the USB browser,

then press OK to play the video.

2 The following buttons are used to control

the lm:

• or : to play or pause.

• : move to the previous or next

one.

• : for rewinding or fast

forwarding.

Viewing text les

1 Select the text le in the USB browser,

then press OK to view the document.

2 The following buttons are used to control

the text playback:

• or : to play or pause

• : to go back 20 pages or move

on 20 pages.

Updating the TV software

Philips constantly strives to improve its products,
and so we recommend that you update your
TV software whenever an update is released.
Visit www.philips.com/TVsupport to check
whether updates are available.

Restoring factory settings

You can restore the default picture and sound
settings for your TV without affecting the saved
channel set up.

1 Press (Home) and select [Setting] to

enter the [Setting] menu

2 Press Then select [Settings] >

[Reset].

3 Select [Yes] and press OK. If you wish to

cancel, select [No] and press OK.

English

Removing USB storage devices

Note

•

Follow the steps below to avoid damaging the USB

storage device.

1 Hold down to exit the USB browser.
2 Wait around 5 minutes before removing

the USB storage device.

13EN

6 Setting up

Renaming channels

channels

This chapter explains how to recongure and
ne-tune channels.

Setting up channels
automatically

This option automatically nds and saves

channels.

1 Press (Home) and select [Setting] to

enter the [Setting] menu

2 Press to select [TV] >

[Channels] > [Channel Scan].

3 Press OK.

» The TV will start searching for channels

automatically.

Swapping channels

1 Press (Home) and select [Setting] to

enter the [Setting] menu.

2 Press to select [TV] >

[Channels] > [Channel Edit].

» The [Channel Edit] menu is displayed.

3 Press to select the analogue channel

you wish to swap. Then press the blue
button.

4 Press to select the analogue channel

you wish to swap. Then press the blue
button to conrm.

You can rename channels. Selecting a channel
will display its name

1 Press (Home) and select [Setting] to

enter the [Setting] menu.

2 Press to select [TV] >

[Channels] > [Channel Edit].

» The [Channel Edit] menu is displayed.

3 Press to select the analogue channel

you wish to rename. Then press the OK
button.

4 Press to select the channel name,

then press the OK button to enter the

editing interface.

5 Press to select the characters.
6 Select [Conrm] then OK to nish

renaming the channel.

Tip

•

Channel names can be up to six characters long.

EPG

1 Press

control to access TV program guide list
(It is available only in DTV mode). In this
program guide list, press to select the
current time and date, and then press

next 7 days of the future
(Fig.1).

(TV GUIDE)

to view all programs information in the

on the remote

14 EN

TV Guide

TIME

01 Mar 201004:43

1 BBC HD Winter Olympics 2010

Record Set Reminder

Wild at Heart2 ITV1 HD

No Information3 BBC THREE

No Information4 BBC NEWS 24

No Information5 BBC1

No Information6 CBBC Channel

No Information7 SDTV

No Information8 BBC ONE

InfoSchedule List

2 Press to select Channel in the top

bar of guide list, then press to view a
program information in the next 7 days of
the future. Focus on the Channel bar you
can press to view the other programs
information (Fig.2).

TV Guide

Channels

2 ITV1 HD Channels

04:30-05:30 Wild at Heart

Record Set Reminder

You can select the color keys to edit these
programs with the tips on the screen. The color
keys introductions as below:

• Record: Press red key to record

the program.

• Remind: Press green key to set

remind the program.

Dancing on Ice - The S...05:30-06:00

ITV News & Weather06:00-06:15

Syrlana06:15-08:35

Guinness Premiership R...08:35-09:25

UEFA Champions Leagu...09:25-09:55

The Yakuza09:55-11:50

Dating the Enemy11:50-12:15

InfoSchedule List

• Info: Press blue key to display the
program information.

• Schedule: Press yellow key to view
program status in schedule list.

Recording option

In DTV mode, press red dot on the remote
control. Record option menu will show on the
screen, and the TV system begin recording now.

1 Press key to stop and quit the recording.
2 Press (Home), select [Utilities] >

[Recordings] to open the TV recorded list.

3 Press green key to view the le

information or delete it by pressing red
key, and press OK to play it normally.

Note

•

This function need connect with USB device, the USB
of FAT32 format must be used. The USB of NTFS

format does not support recording. The duration of
each recording should be no longer than 6 hours.

Recording options menu introduction

• : Play the current video.

• : Fast back for the video, press (play)

key to play normally.

• : Fast forward for the video, press

(play) key to play normally.

• : Pause the video.

• : Stop recording and quit the recording

function.

Time-shift option

In DTV mode, press (star t) , time-shift option
menu will show on the screen, and the program
is in suspended status. press to stop and quit
time-shift function. When you leave program for

English

15EN

a short time, time-shift function can suspend and
cache the playing program to U disk.
When you resume playing, the program can
continue to be played.

Time-shift options menu introduction

• : Play the current video.

• : Fast back for the video, press (play)

key to play normally.

• : Fast forward for the video, press

(play) key to play normally.

• : Pause the video.

• : Stop and quit time-shift function.

16 EN

7 Connecting the

TV

This section explains how to connect devices
with different connectors.

Note

•

You can use different connection types to connect
devices to the TV.

Down ports

a AV input

VideoL R

English

Side ports

a HDMI 2 (ARC)

Digital audio and video input from high

denition devices such as Blu-ray players.

CVBS LR

b HDMI 1

Digital audio and video input from high

denition devices such as Blu-ray players.

b SPDIF OUT

Digital audio signal output for digital audio
equipment.

SPDIF OUT

17EN

c Antenna/cable TV

q

Input for an antenna, cable or satellite signal

d USB

Data input from a USB storage device.

e Headphones

Stereo sound output for headphones.

Note

•

Headphones can only be used as a low-power audio
output. Do not connect high-power active devices
(such as high-power active speakers).

Connecting to a computer

Before connecting a computer to the TV:

• Set the computer screen refresh rate to

60 Hz.

• Select a supported screen resolution on
the computer.

Connect to the computer using one of the
following connections:

Note

•

A separate audio cable is required when connecting
via DVI.

• HDMI cable

1 Set the resolution of the computer display

to 480p/576p/720p/1080p

2 Press (Home) and select [Setting] to

enter the [Setting] menu.

3 Press to select [Settings] >

[HDMI Mode], and set the HDMI display

mode to graphics or video.

4 Adjust the picture format to achieve the

best display results.

• Press (Home) and select [Setting]

to enter the [Setting] menu.

• Press to select [Settings] >

[Picture Format].

• Select a picture format.

• Press OK to conrm.

18 EN

Using Philips EasyLink

Making full use of your Philips EasyLink HDMI­CEC compatible devices can enhance control
features to achieve the best possible results.
HDMI-CEC compatible devices connected
through the HDMI connector can be controlled
by a TV remote control.

Using One-touch Play

1 Once EasyLink has been enabled, press

play on the device.

» The TV will automatically switch to the

correct signal source.

Using One-touch Standby

English

To enable Philips EasyLink, you will need to:

• Connect two or more HDMI-CEC
compatible devices using HDMI
connections.

• Make sure that each HDMI-CEC
compatible device is operating normally.

• Switch to EasyLink.

Note

•

EasyLink compatible devices must be switched on and
selected as a signal source.

•

Philips does not guarantee 100% interoperability with
all HDMI-CEC devices.

Enabling or disabling EasyLink

Once an HDMI-CEC compatible device has
been switched on, the TV will automatically turn
on and switch to the correct signal source.

Note

•

Do not enable this function if you would prefer not to
use Philips EasyLink.

1 Press (Standby/On) on the remote control.

» The TV and all connected HDMI

devices will automatically enter standby
mode.

1 Press (Home) and select [Setting] to

enter the [Setting] menu.

2 Press to select [EasyLink] >

[HDMI CEC].

3 Select [Off] or [On], then press OK.

19EN

8 Product

Audio output power

information

Product information is subject to change
without notice. For detailed product
information, please visit www.philips.com/
TVsupport.

Display resolutions

Computer Formats

• Resolution - refresh rate:

• 640 x 480 - 60Hz

• 800 x 600 - 60Hz

• 1024 x 768 - 60Hz

• 1360 x 768 - 60Hz

• 1920 x 1080 - 60Hz

(32 inches TV is not suppor ted)

Video Formats

• Resolution - refresh rate:

• 480i - 60Hz

• 480p - 60Hz

• 576i - 50Hz

• 576p - 50Hz

• 720p - 50Hz, 60Hz

• 1080i - 50Hz, 60Hz

• 1080p - 50Hz, 60Hz.

Multimedia

• Supported storage devices: USB (only
FAT or FAT 32 USB storage devices are

supported).

• Compatible multimedia le formats:

• Image: JPEG

• Audio: MP3

• Video: MPEG 2/MPEG 4, H.264

• Document: TXT

• 32PHT5505: 5W x 2

• 43PFT5505: 6W x 2

Intrinsic resolution

• 32PHT5505: 1366x 768

• 43PFT5505: 1920x 1080

Tuner/reception/transmission

• Aerial input: 75 ohm coaxial (IEC75)

• TV systems: PAL, DVB-T/T2

• Video playback: NTSC, SECAM, PA L

Remote control

• Batteries: 2 x AAA

Power supply

• Mains power: 110-240V, 50-60Hz

• Standby power: ≤ 0.5 W

• Ambient temperature: 5 to 40 degrees

Celsius

• Power consumption:
32PHT5505: 50W
43PFT5505: 80W

20 EN

Supported TV mounts

To mount the TV, please purchase a Philips TV
mount or any TV mount compliant with the
VESA standard. To prevent damage to cables and
connectors, be sure to leave a clearance gap of
at least 2.2 inches or 5.5cm between the back of
the TV to the wall.

Caution

• Please follow all instructions provided with the TV

mount. TP Vision Europe B.V. bears no responsibility for

improper TV mounting that results in accident, injury
or damage.

Model No.

Required
Pixel Pitch
(mm)

Required
Mounting
Screws

4 x M6

32PHT5505 100 x 100

(recommended
length: 15 mm)

4 x M6

43PFT5505 200 x 100

(recommended
length: 11 mm)

English

21EN

9 Troubleshooting

This section covers common problems and their
accompanying solutions.

General issues

The TV cannot be switched on:

• Disconnect the power cable from the
power outlet. Wait for one minute before
reconnecting it.

• Check that the power cable is securely
connected.

The remote control is not working properly:

• Check that the remote control batteries
are correctly inserted according to the +/­orientation.

• Replace the remote control batteries if

they are at or weak.

• Clean the remote control and TV sensor
lens.

The standby light on the TV is red and blinking:

• Disconnect the power cable from the
power outlet. Wait for the TV to cool down
before reconnecting the power cable. If
the light continues to blink, please contact
Philips Customer Care Centre.

You forgot the code to unlock the TV lock
feature

• Enter ‘3448’.

The TV menu is in the wrong language.

• Change the TV menu to your preferred
language.

When turning the TV On/Off or to Standby,
you hear a creaking sound from the TV chassis:

• No action is required. The creaking sound
comes from the normal expansion and
contraction of the TV as it cools down
and warms up. This does not impact its
performance.

Channel issues

Previously installed channels do not appear in
the channel list:

• Check that the correct channel list is
selected.

Picture issues

The TV is on, but there is no picture:

• Check that the antenna is properly
connected to the TV.

• Check that the correct device is selected as
the TV source.

There is sound but no picture:

• Check that the picture settings are correctly
set.

Poor TV reception from the antenna
connection:

• Check that the antenna is properly
connected to the TV.

• Loudspeakers, unearthed audio devices,
neon lights, high buildings and other large

objects can inuence reception quality.

If possible, try to improve the reception
quality by changing the antenna direction or
moving devices away from the TV.

• If the reception on one par ticular channel is

poor, please ne tune this channel.

There is poor picture quality from connected
devices:

• Check that the devices are connected
properly.

• Check that the picture settings are correctly
set.

The TV did not save your picture settings:

• Check that the TV location is set to the
home setting. This mode offers you the

exibility to change and save settings.

The picture does not t the screen; it is too

big or too small:

• Try using a different picture format.

The picture position is incorrect:

• Picture signals from some devices may not

t the screen correctly. Please check the

signal output of the device.

Sound issues

The pictures are showing but sound quality is
poor:

Note

• If no audio signal is detected, the TV automatically

switches the audio output off - this does not indicate
malfunction.

22 EN

• Check that all cables are properly
connected.

• Check that the volume is not set to 0.

• Check that the sound is not muted.

• Check that the sound settings are correctly
set.

The pictures are showing but sound comes
from one speaker only:

• Verify that sound balance is set to the
centre.

HDMI connection issues

There are problems with HDMI devices:

• Please note that HDCP (High-bandwidth
Digital Content Protection) support can
delay the time taken for a TV to display
content from a HDMI device.

• If the TV does not recognise the HDMI
device and no picture is displayed, please
try switching the signal source to another
device before switching it back again.

• If there are intermittent sound disruptions,
please check that output settings from the
HDMI device are correct.

• If you are using a HDMI to DVI adapter or
cable, please check if the audio cable that
comes with the product is connected to
AUDIO (only for mini jacks).

If the problem remains unresolved, please
contact your local Philips Customer Service
Centre.

English

Warning

• Do not attempt to repair the TV yourself. This may

cause severe injury, irreparable damage to your TV or
void your warranty.

Note

• Please make a note of your TV model and serial

number before you contact Philips Customer Service
Centre. These numbers are printed on the back/bottom
of the TV and on the packaging.

Computer connection issues

The computer display on the TV is not stable:

• Check that your PC uses the supported
resolution and refresh rate.

• Set the TV picture format to unscaled.

Contact us

If you cannot resolve your problem, please refer
to the FAQs for this model at
www.philips.com/TVsupport.

23EN

This electrical and electronic product contains some hazardous substances. You may be safe to
use it during the environment-friendly use period, and please hand it over to recycle system after
environment-friendly use period exceeded.

Suggestive description of the Recycling Administrative Regulations for
Waste Electrical and Electronics Products

In order to care and protect the Earth in a better way, please adhere to the national and applicable
laws in relation to the recycling management of waste electrical and electronics products when the
user no longer needs to use this product, or when it has reached the end of its product life.

24 EN

10 Warranty

English

Warranty

Deutsch

Garantie

Français

Garantie

Indonesia

Jaminan

ไทย

การรับประกัน

Tiếng Việt

Bảo hành

简体中文

保修

繁體中文

保養

ﺔﻳﺑﺭﻌﻟﺍ

ﻥﺎﻤﻀﻟﺍ

Malay

Waranti

English

25EN

English - Guarantee

Dear Customer,
Thank you for purchasing this Philips
product. For the Philips warranty
applicable to this product, we refer you
to the Philips website www.philips.com/
guarantee. In the event you do not have
an internet connection, please contact
your local Philips Consumer Care Centre.
Contact details are given in the Consumer
Care Centres list hereafter.

Deutsch - Garantie

Sehr geehrter Kunde, wir beglückwünschen
Sie zu Ihrer Entscheidung für dieses Produkt
von Philips. Nähere Informationen zu der für
dieses Produkt geltenden Philips Garantie
 nden Sie im Internet unter www.philips.
com/guarantee. Die durch Philips gewährte
Garantie beeinträchtigt in keiner Weise
Ihre gesetzlichen Rechte. Sofern Sie keinen
Zugang zum Internet haben, wenden Sie sich
bitte an Ihr Philips Info-Center vor Ort. Die
entsprechenden Kontaktdaten entnehmen
Sie bitte der nachstehenden Liste.

Français - Garantie

Cher client,
Merci d’avoir acheté ce produit Philips.
Pour connaître les conditions de
garantie Philips applicables à ce produit,
reportez-vous à la page www.philips.
com/guarantee. Si vous ne possédez pas
de connexion Internet, contactez votre
Service Consommateurs Philips local.
Vous trouverez les coordonnées de tous
les Services Consommateurs dans la
liste ci-après. Ces informations étaient
correctes à la date d’impression. Pour
des informations à jour, consultez la page
www.philips.com/support.

Indonesia - Jaminan

Pelanggan yang terhormat,
Terima kasih telah membeli produk Philips.
Untuk mendapatkan jaminan produk
ini, kunjungi situs Web Philips di www.
philips.com/guarantee. Jika Anda tidak
memiliki sambungan Internet, hubungi
Pusat Layanan Pelanggan Philips setempat.
Rincian kontak tercantum dalam daftar
Pusat Layanan Pelanggan.

ไทย - การรับประกัน

เรียนลูกค้า
ขอขอบคุณที่เลือกซื้อผลิตภัณฑ์ของ Philips
สําหรับการรับประกันที่มีผลบังคับใช้กับ
ผลิตภัณฑ์นี้ โปรดอ้างอิงเว็บไซต์ของ Philips
www.philips.com/guarantee ในกรณีที่คุณ
ไม่มีอินเทอร์เน็ต โปรดติดต่อศูนย์บริการลูกค้า
Philips ประจําท้องถิ่นของคุณ รายละเอียดการ
ติดต่อจะแสดงอยู่ในรายชื่อศูนย์บริการลูกค้า
ต่อไปนี้

Tiếng Việt - Bảo hành

Kính gửi Quý khách hàng,
Cảm ơn quý vị đã mua sản phẩm Philips
này. Để biết bảo hành của Philips có thể
áp dụng cho sản phẩm này, chúng tôi xin
giới thiệu trang web của Philips www.
philips.com/guarantee. Trong trường hợp
quý vị không có kết nối internet, vui lòng
liên hệ với Trung tâm Chăm sóc Khách
hàng của Philips tại địa phương. Chi tiết
liên hệ được cung cấp trong danh sách
Trung tâm Chăm sóc Khách hàng sau đâ y.

简体中文 - 保证

尊敬的客户：
感谢您购买此 Philips 产品。有关适
用于此产品的 Philips 保修信息，建
议您访问 Philips 网站：www.philips.
com/guarantee。如果您无法访问
Internet，请联系您当地的 Philips 客
户服务中心。将来，我们会在客户服
务中心列表中提供详细联系信息。

繁體中文 - 保證

親愛的客戶，您好：
多謝您購買本飛利浦產品。有關適
用於本產品的飛利浦保養詳情，請
瀏覽飛利浦網站：www.philips.com/
guarantee。如您未能連線至互聯網，
請與您當地的飛利浦消費者保養中心
聯絡。聯絡詳情已詳列於之後的消費
者保養中心清單中。

ﺔﻳﺑﺭﻌﻟﺍ

ﻥﺎﻣﺿﻟﺍ

ﺔﻓﺮﻌﻤﻟ .Philips ﻦﻣ ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ءﺍﺮﺷ ﻰﻠﻋ ﻢﻜﻟ ﺍﺮﻜﺷ
،ﺞﺘﻨﻤﻟﺍ

ﺍﺬﻫ ﻰﻠﻋ ﻖﺒﻄﻨﻳ ﻱﺬﻟﺍ Philips ﻥﺎﻤﺿ ﻁﻭﺮﺷ

.www.philips.com\guaranteeﻊﻗﻮﻣ ﻊﺟﺍﺭ

ﻰﺟﺮﻳ ،ﺖﻧﺮﺘﻧﻹﺎﺑ ًﻻﺎﺼﺗﺍ ﻚﻳﺪﻟ ﻦﻜﻳ ﻢﻟ ﻝﺎﺣ ﻲﻓ

ﺔﻛﺮﺸﻟ ﻲﻠﺤﻤﻟﺍ ءﻼﻤﻌﻟﺍ ﺔﻣﺪﺧ ﺰﻛﺮﻣ ﻢﻗﺮﺑ ﻝﺎﺼﺗﻻﺍ

ﺔﻤﺋﺎﻗ ﻦﻣ ﻝﺎﺼﺗﻻﺍ ﻞﻴﺻﺎﻔﺗ ﺔﻓﺮﻌﻣ ﻦﻜﻤﻳ .Philips

Inggeris-Jaminan

Pelanggan yang dihormati,
Terima kasih kerana membeli produk
Philips. Bagi waranti Philips yang terpakai
untuk produk ini, kami merujuk anda
kepada laman web Philips
www.philips.com/guarantee. Sekiranya
anda tidak mempunyai sambungan
Internet, sila hubungi Pusat Layanan
Pelanggan Philips tempatan anda. Butiran
kenalan diberikan dalam senarai Pusat
Layanan Pelanggan selepas ini.

.ﻲﻠﻳ ﺎﻤﻴﻓ ءﻼﻤﻌﻟﺍ ﺔﻣﺪﺧ ﺰﻛﺍﺮﻣ

،ﻞﻴﻤﻌﻟﺍ ﻱﺰﻳﺰﻋ

26 EN

User Manual ChatFAQ Forum Call Email Warranty

www.philips.com/support

Australia
1300 998 851

Indonesia

0800-1-822822

Philipines/Pilipinas
632 84204970

Malaysia
1800 220 180

Singapore/

新加坡

65 6286 7333

Thailand/

ประเทศไทย

0-2746-5431

All registered and unregistered trademarks are property of their respective owners.

N.V. and are used under license from Koninklijke Philips N.V. 2019 © TP Vision Europe B.V. All rights reserved.

philips.com

emblem are trademarks of Koninklijke Philips
