Philips 32PFS6402 User manual
Register your product and get support at
www.philips.com/welcome
6402 series
User Manual
32PFS6402
Contents
1 What's new 4
1.1 All-in-one source menu 4
1.2 Top picks 4
1.3 Media browser 5
2 Setting Up 6
2.1 Read Safety 6
2.2 TV Stand and Wall Mounting 6
2.3 Tips on Placement 6
2.4 Power Cable 6
2.5 Antenna Cable 7
2.6 Satellite Dish 7
3 Remote Control 8
3.1 Key Overview 8
3.2 Voice Search 9
3.3 IR Sensor 10
3.4 Batteries 10
3.5 Cleaning 10
4 Switching On and Off 11
4.1 On or Standby 11
4.2 Keys on TV 11
5 Channels 12
5.1 Satellite Installation 12
5.2 Antenna/Cable Installation 14
5.3 Channel List Copy 16
5.4 About Channels 17
6 Connect Devices 23
6.1 About Connections 23
6.2 HDMI Ports 23
6.3 Y Pb Pr - Component 24
6.4 Scart 24
6.5 Audio Out - Optical 25
6.6 CAM with Smart Card - CI+ 25
6.7 Home Theatre System - HTS 26
6.8 Smartphones and Tablets 26
6.9 Blu-ray Disc Player 27
6.10 DVD Player 27
6.11 Bluetooth - Speakers and Gamepads 27
6.12 Headphones 28
6.13 Game Console 28
6.14 Gamepad 29
6.15 USB Hard Drive 29
6.16 USB Keyboard 30
6.17 USB Flash Drive 30
6.18 Photo Camera 31
6.19 Camcorder 31
6.20 Computer 31
7 Connect your Android TV 33
7.1 Network and Internet 33
7.2 Google Account 35
7.3 Philips App Gallery 36
7.4 Android Settings 36
7.5 Home Menu 37
8 Apps 38
8.1 About Apps 38
8.2 Google Play 38
8.3 Start or Stop an App 39
8.4 Lock Apps 39
8.5 Manage Apps 40
8.6 Storage 41
9 Internet 42
9.1 Start Internet 42
9.2 Options on Internet 42
10 TV Menu 43
10.1 About TV Menu 43
10.2 Open TV Menu 43
11 Sources 44
11.1 Switch to a device 44
11.2 Options for a TV Input 44
11.3 Device Name and Type 44
11.4 Computer 44
12 Settings 46
12.1 Frequent Settings 46
12.2 Picture 46
12.3 Sound 49
12.4 Ambilight Settings 52
12.5 Eco Settings 54
12.6 General Settings 54
12.7 Clock, Region and Language 56
12.8 Universal Access 59
12.9 Child Lock 60
13 Videos, Photos and Music 61
13.1 From a USB Connection 61
13.2 From a Computer or NAS 61
13.3 From a Cloud Storage Service 61
13.4 Favourites, Most Popular, Last Played menu
61
13.5 Play your Videos 61
13.6 View your Photos 62
13.7 Play your Music 62
14 TV Guide 64
14.1 What You Need 64
14.2 TV Guide Data 64
14.3 Using the TV Guide 64
15 Recording and Pause TV 66
15.1 Recording 66
15.2 Pause TV 67
16 Smartphones and Tablets 68
16.1 Philips TV Remote App 68
16.2 Google Cast 68
16.3 AirPlay 68
16.4 MHL 68
17 Games 69
17.1 What You Need 69
17.2 Play a Game 69
18 Ambilight 70
18.1 Ambilight Style 70
18.2 Ambilight Off 70
18.3 Ambilight Settings 70
19 Top Picks 72
19.1 About Top Picks 72
19.2 Now on TV 72
19.3 TV on Demand 72
19.4 Video on Demand 72
20 Netflix 74
21 Multi View 75
2
21.1 Text and TV 75
21.2 HDMI and TV 75
21.3 Nettv and TV 75
21.4 Nettv and HDMI 75
22 Software 76
22.1 Update Software 76
22.2 Software Version 76
22.3 Open Source Software 76
22.4 Open Source License 76
22.5 Announcements 196
23 Specifications 197
23.1 Environmental 197
23.2 Power 197
23.3 Operating System 197
23.4 Reception 198
23.5 Display Type 198
23.6 Display Input Resolution 198
23.7 Dimensions and Weights 198
23.8 Connectivity 198
23.9 Sound 199
23.10 Multimedia 199
24 Help and Support 200
24.1 Register your TV 200
24.2 Using Help 200
24.3 Troubleshooting 200
24.4 Online Help 202
24.5 Support and Repair 202
25 Safety and Care 203
25.1 Safety 203
25.2 Screen Care 204
26 Terms of Use 205
26.1 Terms of Use - TV 205
26.2 Terms of Use - Philips App Gallery 205
27 Copyrights 206
27.1 MHL 206
27.2 HDMI 206
27.3 Dolby Audio 206
27.4 DTS 2.0+Digital Out ™ 206
27.5 Microsoft 206
27.6 Wi-Fi Alliance 206
27.7 Kensington 206
27.8 Other Trademarks 207
28 Disclaimer regarding services and/or
software offered by third parties 208
Index 209
3
1
What's new
1.1
All-in-one source menu
About All-in-one source menu
For the first time you press SOURCES, you can
see instructions how to set your source menu.
The improved source menu contains normal source
menu, easily open TV Guide, and also you can
use (plus key) to set a reminder or schedule a
recording in TV Guide.
An all-in-one Sources menu, a restyled TV guide and
a new easy programme browser.
Your list of favourite channels is now part of
the Sources menu. Same for the channel lists of
both tuners Antenna/Cable and
The new Sources menu will have all connected
devices in the list but also all tuners, so in the
Sources menu the user will find all possible ‘sources’
for TV.
Satellite.
Improved TV guide
A clear and better looking TV guide. Select a
programme and read the programme info or
press to set a reminder or schedule a recording.
Switch from tuner, channel, and TV
guide
Select a tuner source and press to open the list of
channels. Press again to open the TV guide
to see what’s on. Press to return to the list of
channels.
1.2
Top picks
With TOP PICKS your TV recommends current
TV programmes, the latest rental videos and Online
TV services for you to watch.
1 - Press TOP PICKS.
2 - Select one programme and use (plus key) to
schedule a recording, set a reminder or watch the
programme.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
Select to record, or select to set a reminder
4
Select to mark as favourites
1.3
Media browser
Browse your media as you like it or mark any channel,
song or photo as a favourite easily.
1 - Press (plus key) to mark any video, song or
photo as a favourite.
2 - You can view videos, songs, and photos in grid
view or list view.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
4 - When playing, there is a secondary control bar on
the bottom of the screen, use the arrows
and OK key to select what you want.
Grid view
List view
5
2
Setting Up
2.1
Read Safety
Read the safety instructions first before you use the
TV.
For more information, in Help, select Keywords and
look up Safety Instructions.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com.
Use the model number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
VESA MIS-F 400x200, M6
• 55PUS6432, 55PUS6452
VESA MIS-F 400x200, M6
Preparation
First remove the 4 plastic screw caps out of the
threaded bushes on the back of the TV.
Make sure that the metal screws, to mount the TV to
the VESA-compliant bracket, go about 10mm deep
inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
2.3
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal
screen size. When seated, your eyes should be level
with the centre of the screen.
15
cm
• 32PFS6402
VESA MIS-F 100x100, M4
• 43PUS6432, 43PUS6452
VESA MIS-F 200x200, M6
• 49PUS6432, 49PUS6452
2.4
Power Cable
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
6
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
2.5
Antenna Cable
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
Use this antenna connection for DVB-T and DVB-C
input signals.
2.6
Satellite Dish
Attach the satellite F-type connector to the satellite
connection SAT at the back of the TV.
7
3
Remote Control
3.1
Key Overview
Top
1 - TV Menu
To open the TV Menu with typical TV functions.
2 - SOURCES
To open the Sources menu.
1 - Standby / On
To switch the TV on or back to Standby.
2 - Playback and Record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to go fast forward
• Record , to start recording
3 -
To select one of the Ambilight style.
4 - TV GUIDE
To open or close the TV Guide.
5 - LIST
To open or close the channel list.
6 - Settings
To open the Frequent Settings.
7 - TOP PICKS
To open the menu with recommended programmes,
Video on Demand (Rental Videos) or Online TV
(Catch Up TV).
If available.
8 - SEARCH
To open the searches page.
Ambilight
3 -
Direct selection of options.
4 - INFO
To open or close programme info.
5 - BACK
To switch back to the previous channel you selected.
To return to previous menu.
To go back to the previous App/Internet page.
6 - - EXIT
To switch back to watch TV. To stop an interactive TV
application.
7 - OPTIONS
To open or close the Options menu.
8 - OK key
To confirm a selection or setting. To open the channel
list while watching TV.
9 - Arrow / navigation keys
To navigate up, down, left or right.
10 - HOME
To open the Home menu.
Colour keys
Bottom
Middle
8
1 -
To open the Netflix App directly. With the TV switched
on or from standby.
2 To adjust the volume level.
3 - Number keys
To select a channel directly.
4 - SUBTITLE
To switch subtitles on, off or to show automatically.
5 - Channel
To switch to the next or previous channel in the
channel list. To open the next or previous page in
Text/Teletext. To start the next or previous chapter on
a disc.
6 To mute the sound or to restore it.
7 - TEXT
To open or close Text/Teletext.
Volume
Mute
Pairing with Your TV
There is no microphone on your remote control, if you
want to use voice search, you must install Android
TV Remote Control app on your Android smartphone
or tablet first.
1 - On your Android smartphone or tablet, search
"Android TV Remote Control" in Google Play store.
2 - Download and install Android TV Remote
Control app* on your Android smartphone or
tablet .
3 - Connect your Android smartphone or tablet to
the same network as your Android TV device.
4 - Select "PhilipsTv"** on your Android smartphone
or tablet, then your Android TV will show a code on
the screen.
5 - Enter the code on your Android smartphone or
tablet to pair to your Android TV.
*You need an Android phone or tablet running
Android 4.3 or higher to use the Android TV Remote
Control app.
**The name of your Android TV is depends on the
name you set in TV Network Name. The pre-set
name is model name of this TV.
.
Using Voice Search
You can search for videos, music or anything else on
the Internet with the icon at the top of the Home
menu. You can start using Voice Search any
time. Alternatively, you can use the remote control
keyboard to enter text.
To use Voice Search…
3.2
Voice Search
Download App from Google play
Use your Android smartphone or tablet as a remote
for your Android TV. Easily switch between d-pad,
touchpad, and gamepad modes to navigate content
and play games on your Android TV device. Tap the
microphone to start a voice search, or use the
keyboard to input text on Android TV.
To get started, connect your Android phone or tablet
to the same network as your Android TV device or
find your Android TV via bluetooth.
Works with all Android TV devices.
*You need an Android phone or tablet running
Android 4.3 or higher to use the Android TV Remote
Control app.
1 - Tap icon on your smartphone to start a voice
search.
2 - The icon is red on screen, the microphone is
active.
3 - Speak out clearly what you are looking for. It
might take some time for the results to appear.
4 - In the screen with search results, you can select
the item you want.
See also www.support.google.com/androidtv
Voice Search settings
You can set the language you like to use with Voice
Search.
To set the language for Voice Search…
1 - Press , select All Settings and press OK.
2 - Select Android Settings and press OK.
9
3 - Select Preferences > Speech and
press OK.
4 - Select the language you want to use and
press OK.
5 - Press BACK to go back one step or
press EXIT to close the menu.
3.3
IR Sensor
The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.
Warning
Do not put any objects in front of IR sensor of the TV,
it may block the IR signal.
3.4
Batteries
If the TV does not react on a key press on the remote
control, the batteries might be empty.
To replace the batteries, open the battery
compartment on the back of the remote control.
1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2
type AAA-R03-1.5V batteries. Make sure the + and
the - ends of the batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.
Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.
For more information, in Help, select Keywords and
look up End of use.
3.5
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
10
4
Switching On and
Off
4.1
On or Standby
Make sure the TV is connected to the mains AC
power. Connect the supplied power cord to the AC
in connector at the back of the TV. The indicator light
at the bottom of the TV lights up.
Switch on
Press on the remote control to switch the TV
on. Alternatively, press HOME. You can also
press the small joystick key on the back of the TV to
switch the TV on in case you can't find the remote
control or its batteries are empty.
Switch to standby
movie.
4 - The menu will disappear automatically.
To switch the TV on standby, select and press the
joystick key.
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on
the back of the TV.
In standby mode, the TV is still connected to the
mains power but consumes very little energy.
To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
4.2
Keys on TV
If you lost the remote control or its batteries are
empty, you can still do some basic TV operations.
To open the basic menu…
1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu.
2 - Press left or right to
select Volume, Channel or Sources.
Select Demo, to start a demo movie.
3 - Press up or down to adjust the volume or tune to
the next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection. Press the joystick key to start the demo
11
5
Satellite Installation Settings
Channels
5.1
Satellite Installation
About Installing Satellites
Up to 4 Satellites
You can install up to 4 satellites (4 LNBs) on this TV.
Select the exact number of satellites you wish to
install at the start of the installation. This will speed up
the installation.
Unicable
You can use a Unicable system to connect the
antenna dish to the TV. You can select Unicable for 1
or for 2 satellites at the start of the installation.
Start the Installation
Make sure your satellite dish is connected correctly
and is perfectly aligned before you start the
installation.
The satellite installation settings are preset according
your country. These settings determine how the TV
searches and installs satellites and its channels. You
can always change these settings.
To change the satellite installation settings…
1 - Start the satellite installation.
2 - On the screen where you can start searching for
satellites, select Settings and press OK.
3 - Select the number of satellites you want to install
or select one of the Unicable systems. When you
select Unicable, you can choose the User Band
Numbers and enter the User Band Frequencies for
each tuner.
4 - When you're done, select Next and press OK.
5 - On the Settings menu, press OK to return to the
screen to start searching for satellites.
Homing Transponder and LNB
In some countries, you can adjust the expert settings
for homing transponder and each LNB. Only use or
change these settings when a normal installation fails.
If you have non-standard satellite equipment, you
can use these settings to overrule the standard
settings. Some providers might give you some
transponder or LNB valeus which you can enter here.
To start the satellite installation…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation. Enter
your PIN code if necessary.
3 - Select Search for Satellite.
4 - Select Search. TV will search for satellites.
5 - Select Install. The TV shows the current satellite
installation setup.
If you want to change this setup, select Settings.
If you don't want to change the setup, select Search.
Go to step 5.
6 - In Installation System, select the number of
satellites you want to install or select one of the
Unicable systems. When you select Unicable, you
can choose the User Band Numbers and enter the
User Band Frequencies for each tuner. In some
countries, you can adjust some expert settings for
each LNB in More Settings.
7 - The TV will search for the satellites available on
the alignment of your antenna dish. This may take a
few minutes. If a satellite is found, its name and
reception strength are shown on screen.
8 - When the TV found the satellites you need,
select Install.
9 - If a satellite offers Channel Packages, the TV will
show the available packages for that satellite. Select
the package you need.
10 - To store the satellite setup and installed
channels and radio stations, select Done.
Satellite CAMs
If you use a CAM – a Conditional Access Module with
a smart card – to watch satellite channels, we
recommend to do the satellite installation with the
CAM inserted in the TV.
Most CAMs are used to descramble channels.
Newest generation CAMs (CI+ 1.3 with Operator
Profile), can install all the satellite channels by
themselves on your TV. The CAM will invite you to
install its satellite(s) and channels. These CAMs not
only install and descramble the channels but also
handle regular channel updates.
Channel Packages
Satellite operators can offer channel packages that
bundle free channels (free-to-air) and offer a sorting
that suits a country. Some satellites offer subscription
packages - a collection of channels you pay for.
12
Unicable Setup
Add a Satellite
The Unicable System
You can use a Single Cable system, MDU or Unicable
system to connect the antenna dish to the TV. A
Single Cable system uses one cable to connect the
satellite dish to all satellite tuners in its system. A
Single Cable system is typically used in apartment
buildings. If you use a Unicable system, the TV will ask
you to assign a user band number and corresponding
frequency during the installation. You can install 1 or 2
satellites with Unicable on this TV.
If you notice some missing channels after a Unicable
installation, another installation might have been
done at the same moment on the Unicable system.
Do the installation again to install the missing
channels.
User Band Number
In a Unicable system, each connected satellite tuner
must be numbered (e.g. 0, 1, 2 or 3 etc.).
You can find the available user bands and their
number on the Unicable switchbox. User band is
sometimes shortened as UB. There are Unicable
switchboxes that offer 4 or 8 user bands. If you select
Unicable in the settings, the TV will ask you to assign
the unique user band number for each built-in
satellite tuners. A satellite tuner cannot have the same
user band number as another satellite tuner in the
Unicable system.
User Band Frequency
Next to the unique user band number, the built-in
satellite receiver needs the frequency of the selected
user band number. These frequencies are mostly
shown next to the user band number on a Unicable
switchbox.
You can add an additional satellite to your current
satellite installation. The installed satellites and their
channels remain untouched. Some satellite operators
do not allow adding a satellite.
The additional satellite should be seen as an extra, it
is not your main satellite subscription or not the main
satellite of which you use its channel package.
Typically, you would add a 4th satellite when you
have 3 satellites already installed. If you have 4
satellites installed, you might consider removing one
first to be able to add a new satellite.
Setup
If you currently have only 1 or 2 satellites installed, the
current installation settings might not allow adding an
extra satellite. If you need to change the installation
settings, you must redo the complete satellite
installation. You cannot use Add satellite if a change
of settings is needed.
To add a satellite…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for satellite.
4 - Select Add Satellite. The current satellites are
shown.
5 - Select Search. The TV will search for new
satellites.
6 - If the TV has found one or more satellites,
select Install. The TV installs the channels of the
found satellites.
7 - Select Finish and press OK to store the
channels and radio stations.
Remove a Satellite
Manual Channel Update
You can always start an channel update yourself.
To start a channel update manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for Channels.
4 - Select Update Channels. The TV will start
updating. The update may take a few minutes.
5 - Follow the instructions on screen. The update
may take a few minutes.
6 - Select Finish and press OK.
You can remove one or more satellites from your
current satellite installation. You remove the satellite
and its channels. Some satellite operators do not
allow removing a satellite.
To remove satellites…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for satellite.
4 - Select Remove Satellite. The current satellites
are shown.
5 - Select a satellite and press OK to mark or
unmark them to remove.
6 - Press (left) repeatedly if necessary, to close
the menu.
13
Manual Installation
Problems
Manual Installation is intended for expert users.
You can use Manual Installation to quickly add new
channels from a satellite transponder. You need to
know the frequency and polarization of the
transponder. The TV will install all channels of that
transponder. If the transponder was installed before,
all its channels - the former and the new ones - are
moved to the end of the channel list All.
You cannot use Manual installation if you need to
change the number of satellites. If this is needed, you
have to do a complete installation with Install
Satellites.
To install a transponder…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Manual Installation and press (right)
to enter the menu.
4 - If you have more than 1 satellite installed,
select LNB for which you want to add channels.
5 - Set the Polarisation you need. If you set
the Symbol Rate Mode to Manual, you can enter
the symbol rate in Symbol Rate manually.
6 - Press the arrows (up) or (down) to adjust
the frequency, and select Done.
7 - Select Search and press OK. The signal
strenght is shown on screen.
8 - If you want to store the channels of a new
transponder, select Store and press OK.
9 - Press (left) repeatedly if necessary, to close
the menu.
Homing Transponder and LNB
The TV cannot find the satellites I want or the TV
installs the same satellite twice
• Make sure that the correct number of satellites is set
in Settings at the start of the installation. You can set
the TV to search for One, Two or 3/4 satellites.
A dual head LNB cannot find a second satellite
• If the TV finds one satellite but cannot find a second
one, turn the dish a few degrees. Align the dish to get
the strongest signal on the first satellite. Check the
signal strength indicator of the first satellite on screen.
With the first satellite set at the strongest signal, select
Search again to find the second satellite.
• Make sure the settings are set to Two Satellites.
Changing the installation settings did not solve my
problem
• All settings, satellites and channels are only stored
at the end of the installation when you finish.
All satellite channels are gone
• If you use a Unicable system, make sure you
assigned two unique user band numbers for both
built-in tuners in the Unicable settings. It might be
that another satellite receiver in your Unicable system
is using the same user band number.
Some satellite channels seem to have disappeared
from the channel list
• If some channels seem to be gone or displaced, the
broadcaster might have changed the transponder
location of these channels. To restore the channel
positions in the channel list, you can try an update of
the channel package.
In some countries, you can adjust the expert settings
for homing transponder and each LNB. Only use or
change these settings when a normal installation fails.
If you have non-standard satellite equipment, you
can use these settings to overrule the standard
settings. Some providers might give you some
transponder or LNB valeus which you can enter here.
LNB Power
By default, LNB Power is set to On.
22 kHz Tone
By default, the Tone is set to Auto.
Low LO Frequency / High LO Frequency
The local oscillator frequencies are set to standard
values. Adjust the values only in case of exceptional
equipment that needs different values.
I cannot remove a satellite
• Subscription packages do not allow removing a
satellite. To remove the satellite, you have to do a
complete installation again and select another
package.
Sometimes the reception is poor
• Check if the satellite dish is solidly mounted. Strong
winds can move the dish.
• Snow and rain can degrade the reception.
5.2
Antenna/Cable Installation
14
Update Channels
Reinstall All Channels
Automatic Channel Update
If you receive digital channels, you can set the TV to
automatically update these channels.
Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the Channels List and are marked with a .
Channels without a signal are removed. The TV must
be in standby to automatically update channels. You
can switch off Automatic Channel Update.
To switch off the automatic update…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Automatic Channel Update.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.
To switch off the message…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Channel Update Message.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
In certain countries, the Automatic channel update is
done while watching TV or on any moment when the
TV is in standby.
Manual Channel Update
You can always start an channel update yourself.
To start a channel update manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start.
6 - Select Update Digital Channels, select Next.
7 - Select Start to update the digital channels. This
can take a few minutes.
8 - Press (left) to go back one step or
press BACK to close the menu.
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start and press OK.
6 - Select Reinstall Channels, select Next and
press OK.
7 - Select the country where you are now and
press OK.
8 - Select Next and press OK.
9 - Select the type of installation you want, Antenna
(DVB-T) or Cable (DVB-C) and press OK.
8 - Select Next and press OK.
11 - Select the type of channels you want, Digital
and Analogue Channels or Only Digital
Channels and press OK.
8 - Select Next and press OK.
13 - Select Start and press OK to update the
digital channels. This can take a few minutes.
14 - Press (left) to go back one step or
press BACK to close the menu.
DVB-T or DVB-C
DVB Settings
Network Frequency Mode
If you intend to use the fast Quick Scan method
in Frequency Scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as
used by most cable operator in your country.
If you received a specific network frequency value to
search for channels, select Manual.
Network Frequency
With the Network Frequency Mode set to Manual,
you can enter the network frequency value received
from your cable operator here. To enter the value, use
the number keys.
15
Frequency Scan
Select the method of searching for channels. You can
select the faster Quick Scan method and use the
predefined settings used by most cable operator in
your country.
If this results in having no channels installed or if
some channels are missing, you can select the
extended Full Scan method. This method will take
more time to search for and install channels.
signal quality of this frequency. The test result is
shown on screen. You can reposition the antenna or
check the connections to possibly improve the
reception.
7 - You can also change the frequency
yourself. Select the frequency number one by one
and use the (up) or (down) keys to change
the value. Select Search and press OK to test the
reception again.
8 - Press (left) repeatedly if necessary, to close
the menu.
Frequency Step Size
The TV searches for channels in steps of 8MHz.
If this results in having no channels installed or if
some channels are missing, you can search in smaller
steps of 1MHz. Using the 1MHz steps will take more
time to search for and install channels.
Digital Channels
If you know your cable operator is not offering digital
channels, you can skip searching for digital channels.
Analogue Channels
If you know your cable operator is not offering
analogue channels, you can skip searching for
analogue channels.
Free / Scrambled
If you have a subscription and a CAM - Conditional
Access Module for pay TV services, select Free +
Scrambled. If you did not subscribe to pay TV
channels or services, you can select Free
Channels Only .
Manual Installation
Analogue TV channels can be manually installed,
channel by channel.
To install analogue channels manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
3 - Select Analogue: Manual Installation.
• System
To set up the TV system, select System.
Select your country or the part of the world where
you are now and press OK.
• Search Channel
To find a channel, select Search Channel. You can
enter a frequency yourself to find a channel or let the
TV search for a channel. Press (right) to
select Search to search for a channel
automatically. The found channel is shown on screen
and if the reception is poor, press Search again. If
you want to store the channel, select Done and
press OK.
• Store
You can store the channel on the current channel
number or as a new channel number.
Select Store Current Channel or Store as New
Channel. The new channel number is shown briefly.
Reception Quality
You can check the quality and signal strength of a
digital channel. If you have your own antenna, you
can reposition the antenna to try and improve the
reception.
To check the reception quality of a digital channel…
1 - Tune to the channel.
2 - Press , select All Settings and press OK.
3 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
4 - Select Digital: Reception Test.
5 - Select Search. The digital frequency is shown
for this channel.
6 - Select Search again and press OK to check the
You can redo these steps until you have found all
available analogue TV channels.
5.3
Channel List Copy
Copy a Channel List
To copy a channel list…
1 - Switch on the TV. This TV should have channels
installed.
2 - Plug in a USB flash drive.
3 - Press , select All Settings and press OK.
4 - Select Channels > Channel List Copy.
5 - Select Copy to USB. You might be asked to enter
16
the Child Lock PIN code to copy the channel list.
6 - When copying is done, unplug the USB flash
drive.
7 - Press (left) repeatedly if necessary, to close
the menu.
Now you can upload the copied channel list onto
another Philips TV.
Channel List version
Check the current version of the channel list...
1 - Press , select All Settings and press OK.
2 - Select Channels and press (right) to enter
the menu.
3 - Select Channel List Copy and select Current
Version, then press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
5.4
About Channels
Channel Lists
About Channel Lists
After a channel installation, all channels appear on
the channel list. Channels are shown with their name
and logo if this information is available.
Upload a Channel List
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To an already installed TV
1 - Verify the country setting of the TV. (To verify this
setting, see chapter Reinstall All Channels. Start this
procedure until you reach the country setting.
Press BACK to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Reinstall All Channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When
For each type of tuner - Antenna/Cable (DVB-T/C) or
Satellite (DVB-S) - there is a channel list with all
installed channels. You can only filter this list to show
TV or only Radio channels. Or when you have several
satellites installed, you can filter the channels per
satellite.
With a channel list selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
Channel icons
After an Automatic Channel Update of the channel
list, newly found channels are marked with
a (star).
If you lock a channel, it will be marked with
a (lock).
The 3 most popular channels being watched by
others at this moment are marked with a 1, 2 or 3.
Radio stations
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel. A
Cable (DVB-C) channel installation usually places
radio stations from channel number 1001 onwards.
This TV can receive digital television standard DVB .
TV may not work properly with some operators of
digital television , non-compliance with requirements
of the standard in full.
or
keys.
17
Open a Channel List
Next to the list with all channels for each tuner,
Antenna/Cable or Satellite tuner, you can select a
filtered list or you can select one of the favourite lists
you created.
To open the current channel list…
1 - Press , to switch to TV.
2 - Press LIST* or OK to open the current
channel list.
3 - Press BACK to close the channel list.
To select one of the channel lists…
1 - With a channel list open on screen.
2 - Select the list name at the top of the channel list
and press OK to open the list menu.
3 - In the list menu, select one of the available
channel lists and press OK.
Tip
You can easily switch between the two tuners in
the Sources menu.
Press SOURCES and select Watch TV to switch
to the Antenna/Cable tuner. Select Watch
Satellite to switch to the satellite tuner.
The TV will always open the last selected channel list
for the selected tuner.
* If LIST key is available on your remote control
Filter a Channel List
You can filter a list with all channels. You can set the
channel list to show only TV channels or only Radio
stations. For Antenna/Cable channels you can set the
list to show the Free-to-Air or the Scrambled
channels. When you have several satellites installed,
you can filter the satellite channel list per satellite.
To set a filter on a list with all channels…
1 - Press .
2 - Press OK to open the current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Search Channel and press OK to open
a text field.You can use the remote control keyboard
(if available) or the onscreen keyboard to enter text.
5 - Enter a number, a name or part of a name and
select Apply and press OK. The TV will search for
matching channel names in the list you selected.
Search results are listed as a channel list - see the list
name at the top. The search results disappear once
you select another channel list or close the list with
search results.
Watching channels
Tune to a Channel
To start watching TV channels, press . The TV
tunes to the channel you last watched.
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press BACK.
You can also tune to channels from a Channel List.
Lock a Channel
1 - Press .
2 - Press OK to open the current channel list.
3 - With a channel list open on screen, select the list
name at the top of the channel list and press OK to
open the list menu.
4 - In the list menu, select the list you want to filter.
5 - Press (left) to go back one step or
press to close the menu.
Search for a Channel
You can search for a channel to find it in a long list of
channels.
The TV can search for a channel within one of the 3
main channel lists - the Antenna, Cable or Satellite
channel list.
To search for a channel…
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Select the channel you want to lock and
press OK. A locked channel is marked with
a (lock).
7 - Press (left) to go back one step or
press BACK to close the menu.
18
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
press BACK to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Parental
Rating code first.
To set an age rating…
1 - Press , select All Settings and press OK.
2 - Select Child Lock > Parental Rating.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set Code in Child Lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
4 - Back in Parental Rating, select the age.
5 - Press (left) repeatedly if necessary, to close
the menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Rename Channel
While watching a channel, you can rename channel.
To rename a channel…
1 - While watching a channel, press OPTIONS.
2 - Select
Preferences > Rename Channel.
3 - Use the on-screen keyboard to delete the current
name and enter a new name.
Common Interface
If you installed a CAM in one of the Common
Interface slots, you can view the CAM and operator
information or do some CAM related settings.
To view the CAM information…
1 - Press SOURCES.
2 - Select the channel type you are using the CAM
for, Watch TV or Watch Satellite.
3 - Press OPTIONS and
select
Preferences > Common Interface.
4 - Select the appropriate Common Interface slot
and press (right).
5 - Select the TV operator of the CAM and press OK.
The following screens come from the TV operator.
HbbTV on this Channel
If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for
this channel only.
1 - Tune to the channel of which you want to block
the HbbTV pages.
2 - Press OPTIONS,
select Preferences > HbbTV on this Channel and
press (right).
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
To block HbbTV on TV completely…
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
or depending on the TV settings you made, some
options are available.
To open the options menu…
1 - While watching a channel,
press OPTIONS >
Preferences.
2 - Press OPTIONS again to close.
1 - Press , select All Settings and press OK.
2 - Select General Settings > Advanced > HbbTV.
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Channel Info
You can view the technical characteristics of a
particular channel, like digital or sound type, etc.
To view the technical information on a channel…
1 - Tune to the channel.
2 - Press OPTIONS, select
Preferences and
press OK.
19
3 - Select Channel Info and press OK.
4 - To close this screen, press OK.
Programme Info
View programme details
To call up the details of the selected programme…
1 - Tune to the channel.
2 - Press OPTIONS, select
press OK.
3 - Select Programme Info and press OK, you can
see progrmme information.
4 - Press BACK to close.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
1 - Tune to an analoge channel.
2 - Press OPTIONS, and
select
press (right).
3 - Select Mono or Stereo and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Preferences > Mono/Stereo and
Preferences and
5 - Select
6 - Select one item in the list and press OK.
7 - Select Map Channel.
8 - Once completed, you will see the mapped
channel information in the programme.
Change Logo
If there is no programme information in the beginning,
you can get more programme information using
below steps.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Broadcaster and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
4 - While watching a channel, press OPTIONS.
5 - Select
6 - Select one item in the list and press OK.
7 - Select Change Logo.
8 - Once completed, you will see the mapped
channel information in the programme.
Preferences > Map Channel.
Preferences > Change Logo.
Favourite Channels
About Favourite Channels
Video Selection
Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or
angles of the same event or different programmes on
one TV channel. The TV shows a message if any such
TV channels are available.
Dual I-II
If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.
Map Channel
If there is no programme information in the beginning,
you can do map channel to get more programme
information.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Internet and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
4 - While watching a channel, press OPTIONS.
In a favourite channel list, you can collect the
channels you like.
You can create 8 lists of favourite channels for easy
channel zapping. You can name each Favourites List
individually. Only in a Favourites List you can reorder
channels.
With a Favourites List selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
Create a Favourites List
To create a favourite channels list from channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Create Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
the last channel of the range you want to add and
or
keys.
20
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
If the channel list is long, alternatively, you can select
any channel, then press OPTIONS to open option
menu, then select Create Favourites
list and press OK.
To create a new favourite channels list by copying
existing favourite channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Duplicate Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
the last channel of the range you want to add and
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
You can add a range of channels in one go or start
a Favourites List by duplicating the channel list with
all channels and removing the channels you do not
want.
Add a Range of Channels
To add a consecutive range of channels to
a Favourites List in one go, you can use Select
Range.
To add a range of channels…
1 - Press SOURCE.
2 - Select Favourites.
3 - Open the Favourites List where you want to
add a range of channels.
4 - Select at the upper right corner and press OK.
5 - Select Edit Favourites List and press OK.
6 - In the list at the left select the first channel of the
range you want to add and press OK.
7 - Press (down) to select the last channel of the
range you want to add and then press OK.
8 - Select Add and press OK. The channels are
marked at the left.
Rename a Favourites List
You can only rename a Favourites List.
To rename a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Rename Favourite List and press OK.
5 - Use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
6 - When done, turn the remote control,
select Close and press OK.
7 - Press BACK to close the channel list.
Remove a Favourites List
You can only remove a Favourites List.
To remove a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Remove Favourite List and press OK.
Reorder Channels
Only in a Favourites List you can change the
sequence of channels (reorder).
To change the sequence of channels…
1 - Press SOURCES, and select Favourites.
2 - Open the Favourites List you want to reorder.
3 - Select at the upper right corner and press OK.
4 - Select Reorder Channels and press OK.
5 - In the Favourites List, select the channel you
want to reorder and press OK. (The channel will be
marked with grey box)
6 - With the (up) or (down) keys move the
channel where you want it.
7 - Press OK to confirm the new location.
8 - You can reorder channels with the same method
until you close the Favourites List with
the BACK key.
Text / Teletext
Text Pages
To open Text/Teletext press TEXT, while you are
watching TV channels.
To close Text, press TEXT again.
Select a Text page
To select a page . . .
21
1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded
subject at the bottom of the screen.
Text sub-pages
A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the
main page number.
To select a subpage, press or .
T.O.P. Text pages
Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press OPTIONS and select T.O.P. Overview.
Favourite pages
The TV makes a list of the last 10 Text pages you
opened. You can easily reopen them again in the
Favourite Text pages column.
1 - In Text, select (heart) in the top left corner of
the screen to show the column of favourite pages.
2 - Press (down) or (up) to select a page
number and press OK to open the page.
You can clear the list with the option Clear Favourite
Pages.
Search Text
Text Options
In Text/Teletext, press OPTIONS to select the
following…
• Freeze page
To stop the automatic rotation of subpages.
• Dual screen / Full screen
To show the TV channel and Text alongside each
other.
• T.O.P. overview
To open T.O.P. Text.
• Enlarge
To enlarge the Text page for comfortable reading.
• Reveal
To unhide hidden information on a page.
• Cycle subpages
To cycle subpages when these are available.
• Hide/Show Favourite Pages
To hide or show the list of favourite pages.
• Clear Favourite Pages
To clear the list of favourite pages.
• Language
To switch the group of characters that Text uses to
display correctly.
• Text 2.5
To activate the Text 2.5 for more colours and better
graphics.
You can select a word and scan Text for all
occurences of this word.
1 - Open a Text page and press OK.
2 - Select a word or number with the arrow keys.
3 - Press OK again to jump immediately to the next
occurence of this word or number.
4 - Press OK again to jump to the subsequent
occurence.
5 - To stop searching, press (up) until nothing is
selected.
Text from a connected device
Some devices that receive TV channels can also offer
Text.
To open Text from a connected device . . .
1 - Press SOURCES, select the device and
press OK.
2 - While watching a channel on the device,
press OPTIONS, select Show Device Keys and
select the key and press OK.
3 - Press BACK to hide the device keys.
4 - To close Text, press BACK again.
Digital Text (UK only)
Some digital broadcasters offer dedicated Digital Text
or interactive TV on their digital TV channels. This
includes normal Text using the number, colour and
arrow keys to select and navigate.
To close Digital Text, press BACK.
Text Setup
Text language
Some digital TV broadcasters have several Text
languages available.
To set your primary and secondary Text language . . .
1 - Press , select All Settings and press OK.
2 - Select Region and Language and
press (right) to enter the menu.
3 - Select Language > Primary Text or Secondary
Text.
4 - Select your preferred Text languages.
5 - Press (left) repeatedly if necessary, to close
the menu.
Text 2.5
If available, Text 2.5 offers more colours and better
graphics. Text 2.5 is activated as a standard factory
setting.
To switch off Text 2.5…
1 - Press TEXT.
2 - With Text/Teletext open on screen,
press OPTIONS.
3 - Select Text 2.5 > Off and press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
22
6
HDMI Quality
Connect Devices
6.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
If you need help to connect several devices to the TV,
you can visit the Philips TV connectivity guide. The
guide offers information on how to connect and
which cables to use.
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for TV signal.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.
Copy protection
HDMI cables support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights
Management).
Go to www.connectivityguide.philips.com
Antenna Port
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
HDMI ARC
All of the HDMI connections on the TV have HDMI
ARC (Audio Return Channel).
If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.
You can use any HDMI connection on this TV to
connect the HTS but ARC is only available for 1
device/connection at a time.
HDMI MHL
With HDMI MHL, you can send what you see on your
Android smartphone or tablet to a TV screen.
6.2
HDMI Ports
The HDMI 4 connection on this TV
incorporates MHL 2.0 (Mobile High-Definition Link).
This wired connection offers great stability and
bandwidth, low latency, no wireless interference and
good quality sound reproduction. On top of that, the
MHL connection will charge the battery of your
smartphone or tablet. Although connected, your
mobile device will not be charging when the TV is on
standby.
Inform yourself about what passive MHL cable is
23
suited for your mobile device. In particular, with the
HDMI connector for the TV on one side, the type of
connector you need to connect to your smartphone
or tablet.
MHL, Mobile High-Definition Link and the MHL Logo
are trademarks or registered trademarks of the MHL,
LLC.
HDMI CEC - EasyLink
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals. For best signal quality transfer, use a High
speed HDMI cable and do not use an HDMI cable
longer than 5 m.
their respective owners.
DVI to HDMI
If you still own a device that only has a DVI
connection, you can connect the device to any of
the HDMI connection with a DVI to HDMI adapter.
Use a DVI to HDMI adapter if your device only has a
DVI connection. Use one of the HDMI connections
and add an Audio L/R cable (mini-jack 3.5mm)
to Audio IN for sound, on the back of the TV.
EasyLink HDMI CEC
If your devices are connected with HDMI and have
EasyLink, you can operate them with the TV remote
control. EasyLink HDMI CEC must be switched On on
the TV and the connected device.
With EasyLink you can operate a connected device
with the TV remote control. EasyLink uses HDMI CEC
(Consumer Electronics Control) to communicate with
the connected devices. Devices must support HDMI
CEC and must be connected with an HDMI
connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure
that all HDMI CEC settings are properly set up on the
connected EasyLink devices. EasyLink might not work
with devices from other brands.
Copy Protection
DVI and HDMI cables support HDCP (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
6.3
Y Pb Pr - Component
Y Pb Pr - Component Video is a high quality
connection.
The YPbPr connection can be used for High Definition
(HD) TV signals. Next to the Y, Pb and Pr signals add
the Audio Left and Right signals for sound.
Match the YPbPr (green, blue, red) connector colours
with the cable plugs when you connect.
Use an Audio L/R cinch cable if your device also has
sound.
HDMI CEC on other brands
The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink.
Example HDMI CEC branding names are property of
24
6.4
Scart
SCART is a good quality connection.
The SCART connection can be used for CVBS and
RGB video signals but cannot be used for High
Definition (HD) TV signals. The SCART connection
combines video and audio signals. The SCART
connection also supports NTSC playback.
6.5
Audio Out - Optical
CI+
This TV is ready for the CI+ Conditional Access .
With CI+ you can watch premium HD programmes,
like movies and sports, offered by digital TV operators
in your region. These programmes are scrambled by
the TV operator and descrambled with a prepaid CI+
module.
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes. These programmes have
a high level of copy protection.
Contact a digital TV operator for more information on
terms & conditions.
Audio Out - Optical is a high quality sound
connection.
This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.
6.6
CAM with Smart Card - CI+
Smart Card
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes.
Insert the smart card into the CAM module. See the
instruction you received from the operator.
To insert the CAM in the TV…
1 - Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM
and TV.
2 - While looking at the back of the TV, with the front
of the CAM facing towards you, gently insert the CAM
into the slot COMMON INTERFACE.
3 - Push the CAM in as far as it will go. Leave it in the
slot permanently.
About CI+
Note: Not support for countries in Asia Pacific,
Middle East, and Africa.
When you switch on the TV, it may take a few minutes
before the CAM is activated. If a CAM is inserted and
subscription fees are paid (subscription methods can
differ), you can watch the scrambled channels
supported by the CAM smart card.
The CAM and smart card are exclusively for your TV. If
you remove the CAM, you will no longer be able to
watch the scrambled channels supported by the
CAM.
25
Passwords and PIN codes
Connect with HDMI
For some CAMs, you must enter a PIN code to watch
its channels. When you set the PIN code for the CAM,
we recommend you to use the same code you are
using to unlock the TV.
To set the PIN code for the CAM…
1 - Press SOURCES .
2 - Select the channel type you are using the CAM
for Watch TV.
3 - Press OPTIONS and select Common
Interface.
4 - Select the TV operator of the CAM. The following
screens come from the TV operator. Follow the onscreen instruction to look up the PIN code setting.
6.7
Home Theatre System - HTS
Connect with HDMI ARC
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
HDMI ARC
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
If the Home Theatre System has no HDMI ARC
connection, add an optical audio cable (Toslink) to
send the sound of the TV picture to the Home Theatre
System.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Problems with HTS sound
If your Home Theatre System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal. But once you have
connected the Home Theatre System, the TV can
only send the ARC signal to this HDMI connection.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theatre System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theatre System has no DTS sound processing.
You can fix this by setting the Audio Out Format of
the TV to Stereo (uncompressed).
Press for All
Settings > Sound > Advanced > Audio Out
Format.
No sound
If you cannot hear the sound from the TV on your
Home Theatre System, check if you connected the
HDMI cable to an HDMI ARC connection on the
Home Theatre System. All HDMI connections on the
TV are HDMI ARC connections.
6.8
Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can
use a wireless or wired connection.
Wireless
For a wireless connection, on your smartphone or
tablet download the Philips TV Remote App from
26
your favourite app store.
6.11
Wired
For a wired connection, use the HDMI 4 MHL
connection on the back of the TV. For more
information, in Help, select Keywords and
look up HDMI MHL for more information.
6.9
Blu-ray Disc Player
Use a High speed HDMI cable to connect the Bluray Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC,
you can operate the player with the TV remote
control.
6.10
Bluetooth - Speakers and
Gamepads
What You Need
You can connect a wireless device with Bluetooth® to
this TV – a wireless speaker, a subwoofer, a sound
bar or headphones. You can also connect a wireless
gamepad with Bluetooth LE.
To play the TV sound on a wireless speaker, you must
pair the wireless speaker with the TV. You can pair
some wireless speakers and a maximum of 4
Bluetooth LE (low energy) devices. The TV can only
play the sound on one speaker at a time. If you
connect a subwoofer, the sound is played on the TV
and the subwoofer. If you connect a sound bar the
sound is played on the sound bar only.
Attention - Audio to Video syncronisation
Many Bluetooth speaker systems have a high, so
called, 'latency'. High latency means that the audio
lags behind the video, causing unsynchronised 'lip
sync'. Before you purchase a wireless Bluetooth
speaker system, inform yourself about the newest
models and look for a device with a low latency
rating. Ask your dealer for advice.
DVD Player
Use an HDMI cable to connect the DVD player to the
TV.
Alternatively, you can use a SCART cable, if the
device has no HDMI connection.
If the DVD player is connected with HDMI and has
EasyLink CEC, you can operate the player with the TV
remote control.
Pairing a Device
Position the wireless speaker within a distance of 5
meters from the TV. Read the user manual of the
device for specific information on pairing and on
wireless range. Make sure the Bluetooth setting on TV
is switched on.
Once a wireless gamepad is paired, you can use it.
When a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.
To pair a wireless speaker with the TV…
1 - Switch on the wireless speaker and place it within
range of the TV.
2 - Press , select All Settings and press OK.
3 - Select Wireless and Networks and
press (right) to enter the menu.
4 - Select Bluetooth > Search Bluetooth Device.
5 - Select Start and press OK. Follow the
instuctions on screen. You will pair the device with the
TV and the TV will store the connection. You might
need to unpair a paired device first if the maximum
number of paired devices was reached.
6 - Select the type of device (headphone,
subwoofer, …).
7 - Press (left) repeatedly if necessary, to close
27
the menu.
Select a Device
Once a wireless Bluetooth speaker is paired, you can
select it to play the TV sound.
To select a speaker to play the TV sound…
1 - Press , select Speakers and press OK.
2 - Select the loudspeaker system you want.
3 - Press (left) repeatedly if necessary, to close
the menu.
2 - Press the arrows (up) or (down) to adjust
the value.
3 - Press (left) repeatedly if necessary, to close
the menu.
Remove a Device
You can connect or disconnect a wireless Bluetooth
device. When a Bluetooth device is connected, you
can use the gamepad or hear the TV sound through
the wireless speaker. You can also remove a wireless
Bluetooth device. If you remove a Bluetooth device,
the device will be unpaired.
To remove or disconnect a wireless device…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks.
3 - Select Bluetooth > Remove Device.
4 - In the list, select the wireless device.
5 - Select Disconnect or Remove.
6 - Select OK.
7 - Press (left) repeatedly if necessary, to close
the menu.
Bluetooth On or Off
To connect wireless Bluetooth devices, make sure
Bluetooth is switched on.
6.13
Game Console
HDMI
For best quality, connect the game console with a
High speed HDMI cable to the TV.
Y Pb Pr
Connect the game console with a component video
cable (Y Pb Pr) and an audio L/R cable to the TV.
To switch Bluetooth on…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks.
3 - Select Bluetooth > Bluetooth On/Off.
4 - Select On or Off.
5 - Press (left) repeatedly if necessary, to close
the menu.
6.12
Headphones
You can connect a set of headphones to
the connection on the back of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume…
1 - Press , select Headphone Volume.
28
Scart
Problems
Connect the game console to the TV with a
composite cable (CVBS) and an audio L/R cable to
the TV.
If your game console only has Video (CVBS) and
Audio L/R output, use a Video Audio L/R to SCART
adapter (sold separately) to connect to the SCART
connection.
Best Setting
Before you start playing a game from a connected
game console, we advice you to set the TV in the
ideal setting Game.
To set the TV to the ideal setting…
To solve possible interference with other wireless
devices on TV…
• Use a USB extension cord and move the nano
receiver about 1 meter away from the TV.
• Alternatively, you can use a powered USB hub
connected to the TV and plug in the nano receivers in
the USB hub.
6.15
USB Hard Drive
What You Need
If you connect a USB Hard Drive, you can pause or
record digital TV broadcasts (DVB broadcasts or
similar).
Minimum Disk Space
• To Pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 4GB disk
space.
• To Record
To pause and record a broadcast, you need a
minimum of 250GB disk space.
1 - Press , select All Settings and press OK.
2 - Select Picture and press (right) to enter the
menu.
3 - Select Picture Style > Game.
4 - Press (left) repeatedly if necessary, to close
the menu.
6.14
Gamepad
Connect a Gamepad
To play games from the Internet on this TV, you can
connect a selected range of wireless Gamepads. You
can use Gamepads with a USB nano receiver or
gamepads with Bluetooth.
To connect a Gamepad with a USB nano receiver…
1 - Plug in the small nano receiver in one of the USB
connections on the side of the TV. The wireless nano
receiver comes with the Gamepad.
2 - If the Gamepad is switched on, you can use the
Gamepad.
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
You can connect a second Gamepad in the second
USB connection on the side of the TV.
Warning
29
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
Formatting
Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive. Formatting removes all files from the USB Hard
Drive. If you want to record broadcasts with TV Guide
data from the Internet, you must setup the Internet
connection first before you install the USB Hard Drive.
Warning
6.16
USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
Use one of the USB connections to connect.
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
To format a USB Hard Drive…
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting. Follow the instructions on screen.
4 - The TV will ask if you want to use the USB Hard
Drive to store apps, agree to the question if you do.
5 - When the USB Hard Drive is formatted, leave it
connected permanently.
Configure
Install the keyboard
To install the USB keyboard, switch on the TV and
connect the USB keyboard to one of
the USB connections on the TV. When the TV
detects the keyboard for the first time, you can select
your keyboard lay-out and test your selection. If you
select a Cyrillic or Greek keyboard layout first, you
can select a secondary Latin keyboard layout.
To change the keyboard layout setting when a layout
was selected…
1 - Press , select All Settings and press OK.
2 - Select General Settings and press (right) to
enter the menu.
3 - Select USB Keyboard Settings to start the
keyboard setup.
Special Keys
Keys for entering text
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary
layout is set, press the Ctrl + Spacebar keys
simultaneously.
Keys for apps and Internet pages
• Tab and Shift + Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• + = zoom in one step
• - = zoom out one step
• * = fit the web page to the screen width
30
Loading...
