Page 1
Philips 7000 LED series
LCD TV with Ambilight
Spectra 2 and Pixel Precise
HD
32"
Full HD 1080p digital TV
32PFL7605C
Design your own LED TV
to blend beautifully with your room
Design your own TV online (www.philips.com/TV) by choosing a frame colour, stand or
wall mount and remote control. The TV has 7000 LED-series picture and sound
performance, Ambilight and Net TV.
Design the TV the way you like it
• Design your own LED TV online
• Choose the colour of the frame that best fits your room
• Choose a wallmount/stand and a remote control
7000 LED-series performance
• Full HD TV with Pixel Precise HD for details in action
• 100 Hz LCD, 2 ms performance for superb motion sharpness
• Feel the power of 20 W RMS and Incredible Surround Sound
• Ambilight Spectra 2 widens the viewing experience
• Net TV for popular online services on your TV
Greener every day
• LED is up to 40% more energy efficient than normal LCD TVs
Page 2
32PFL7605C/05
Highlights
LCD TV with Ambilight Spectra 2 and Pixel Precise HD
32" Full HD 1080p digital TV
Ambilight Spectra 2
Add a new dimension to your viewing
experience with Ambilight Spectra 2. This
patented Philips technology enlarges the
screen by projecting a glow of light, on 2 sides
of the TV, from the back of the screen onto the
surrounding wall. Ambilight automatically
adjusts the colour and brightness of the light to
match the picture, creating an immersive
viewing experience. The wall adaptive function
ensures that the colour of the light always
matches the picture, no matter the colour of
your wall. With Ambilight Spectra 2, movies
truly come to life!
Pixel Precise HD
Pixel Precise HD builds on the award winning
Pixel
Plus foundation. It brings the high
definition picture quality to the next level with
4 trillion colours with HD Natural Motion
making all your movies fluently moving and
razor sharp. With Super Resolution, Pixel
Precise HD now brings you the best HD TV
picture quality whether you are watching a
video from the Internet or good quality Blu-ray
movies.
100 Hz LCD, 2 ms response time
100 Hz LCD creates extreme motion
shar
pness. The Double Frame Rate Insertion
increases the sharpness of motion
reproduction to more than twice that of
conventional LCD, resulting in a performance
with a response time of 2 milliseconds. Now
you can enjoy clear images even with fast onscreen motion.
20 W RMS Incredible Surround Sound
Feel the power of the music beat and the
at
mosphere of the movies. The powerful 20 W
RMS (2 x 10 W RMS) amplifiers create a lifelike
soundstage. The Incredible Surround Sound
allows you to experience total surround with
greater depth and width of sound. It gives a
clear and spacious sound stage complementary
to the rich viewing experience.
Energy efficient LED
Up to 40% more energy efficient than
conventional flat TVs. Using th
e latest LED
backlight technology, LED-backlit TVs are
considered a more sustainable choice, with a
longer life and far lower energy consumption
than plasmas and conventional LCD TVs.
Unlike CCFL backlights, LEDs do not use
mercury in their manufacture. In addition,
Philips TV designs have improved generation
after generation resulting in an increase in
material efficiency and a reduction in energy
usage without compromising on safety and
wellbeing. That's good news for you today your children tomorrow.
Net TV
Experience a rich selection of online services
with Net TV. Enjoy movies, pictures,
infotainment and other online content directly
on your TV whenever you like. Simply connect
your home theatre directly to your home
network through the Ethernet connection, and
navigate and select what you want to watch
with the remote control. The Philips menu
gives you access to popular Net TV services
fitted for your TV screen. Additionally, with
the DLNA certified PC network you can watch
videos or access pictures stored on your
computer using your remote control.
Design your own LED TV online
At Philips online (www.philips.tv/com) you can
design th
e 7000-series LED TV in a way that
best suits your (living) room. You can choose
from 2 screen sizes (32" and 42”), 8 different
colour options for your frame, a stand or a wall
mount and 3 remote controls. The TV can only
be bought online and will be delivered to your
home free of charge within 3 weeks
Eco Flower
Over the last 10 years we
have w
orked hard to
lower our environmental
impact and will continue to
do so. Our eco-design
process aims to create Philips televisions
that are increasingly eco-friendly and that
have significantly less impact on the
environment. Philips has been awarded
the EU ECO label (the flower) on the
majority of its models because of the
televisions' high energy efficiency, ultra
low standby power (up to 50% less than
the required EU ECO label level), absence
of hazardous substances (e.g. lead) and the
fact that Philips has designed televisions
that can be easily recycled.
Page 3
Issue date 2010-09-06
Version: 3.10.4
12 NC: 8670 000 66832
EAN: 87 12581 55948 9
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
32PFL7605C/05
Specifications
LCD TV with Ambilight Spectra 2 and Pixel Precise HD
32" Full HD 1080p digital TV
Picture/Display
• Peak Luminance ratio: 65 %
• Aspect ratio: Widescreen
• Brightness: 450 cd/m²
• Dynamic screen contrast: 500,000:1
• Response time (typical): 2 ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 32 inch / 81 cm
• Display: LCD Full HD, edge LED backlight
• Panel resolution: 1920 x 1080p
• Picture enhancement: Pixel precise HD, Active
Co
nt
rol + Light sensor, 100 Hz Clear LCD, Digital
Noise Reduction, Dynamic contrast enhancement,
Luminance Transient Improver, MPEG artefact
reduction, HD Natural Motion, Super Resolution,
Colour booster
• Screen enhancement: Anti-Reflection coated
sc
re
en
• Colour processing: 4 trillion colours (14-bit RGB)
Ambilight
• Ambilight Version: 2 sided
• Ambilight Features: Ambilight Spectra 2, Lounge
light mo
de
• Dimming Function: Manual and via Light Sensor
• Ambilight light system: LED-wide colour
Supported Display Resolution
• Computer inputs: up to 1920 x 1080 @ 60 Hz
• Video inputs: up to 1920 x 1080p, 24, 25, 30, 50, 60
Hz
Sound
• Output power (RMS): 2 x 10 W, Invisible Sound
• Sound Enhancement: Auto Volume Leveller,
Dy
namic Bass Enhancement, Incredible Surround,
Treble and Bass Control, Clear Sound
• Sound System: Mono, Nicam Stereo, Stereo
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Channel installation wizard,
Networ
k installation wizard, Settings assistant
wizard, Device connection wizard, Auto
Programme Naming, Autoinstall, Programme
Name, Sorting
• Ease of Use: Smart Picture, Smart Sound, Ons
c
reen User manual, EasyLink, Favourite
programme selection, Mozaïc channel grid, Onestop experience button, One-stop Home button
• Electronic Programme Guide: Now + Next EPG,
8-day Electr
on
ic Programme Guide*
• Screen Format Adjustments: Auto Format, Super
Zoom
, Movie expand 16:9, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1200-page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizar
d, Firmwar
e upgradeable via USB, Online
firmware upgrade
• Multimedia: DLNA media Browser, Net TV
s
e
rvices, USB media browser
Multimedia Applications
• Picture Playback Formats: JPEG
• Music Playback Formats: MP3, WMA (v2 up to
v9.2), AAC
•
Video Playback Formats: Codec support:, H264/
MPEG-4 AVC, MPEG-1, MPEG
-2, MPEG-4,
WMV9/VC1, Containers: AVI, MKV
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB Terrestrial*, DVB-T MPEG4*,
DVB-C MPEG
4*
•
Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Summary: 4 x HDMI, 1 x USB, 2 x SCART, 1 x
Ethernet, Wi-Fi ready
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in
• VGA-in: PC input, D-sub 15
•HDMI 1: HDMI v1.4 (Audi
o
Return Ch.)
•HDMI 2: HDMI v1.3
•HDMI 3: HDMI v1.3
• HDMI Side: HDMI v1.3
• Front/Side connections: USB, Common Interface
Slot (C
I-CI
+), SD-card (Videostore)
• Other connections: Headphone out, PC Audio in,
Ether
net-LAN RJ-45
• EasyLink (HDMI-CEC): One touch play, EasyLink,
Pixel Plus link, Rem
ote control pass-through,
System audio control, System standby
• Audio Output - Digital: Coaxial (cinch)
• PC network link: DLNA 1.5 certified
Power
• Off mode power consumption: < 0.01 W
• Presence of lead: Yes*
• Annual energy consumption: 103.66 kW·h
• Ambient temperature: 5°C to 40°C
• Mains power: 220 - 240 V, 50/60 Hz
• Power consumption (typical): 71 W
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Lig
h
t sensor, Eco mode, Picture mute (for radio),
Auto switch-off timer
Dimensions
• Compatible wall mount: adjustable 200 x 300 mm
•Set dimensions (W x H x D): 777 x 472 x 42 mm
• Set dimensions with stand (W x H x D):
777
x 540 x 221 mm
• Product weight: 9.5 kg
• Product weight (+stand): 11.6
kg
•Box dimensions (W x H x D):
950
x 572 x 158 mm
• Colour cabinet: Customised to order
Accessories
• Included accessories: Quick start guide,
Registration card, Warranty Leaflet, Remote
Control, 2 x AAA Batteries, Safety/legal
instructions, Software declaration
• Optional accessories: Tabletop Stand with Swivel,
Wall mou
n
ting bracket, Wireless USB adapter
(PTA01)
•
* 8 days EPG, service not available in all countries
* Typical on-mode power consumption measured according to
IEC62087 Ed 2.
* Net TV: Visit www.philips.com/tv to discover the services offered in
your country.
* Annual energy consumption is calculated using the typical power
consumption 4 hours per day, 365 days per year.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscription are required.
Contact your operator for more information.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
