Philips 32PFL7332, 32PFL7932, 42PFL7432, 52PFL7432 User Manual

FLAT TV

32PFL7332 32PFL7932

English

User Manual

42PFL7432 52PFL7432

philips

Recycling

The packaging of this product is intended to be recycled. Apply to the local authorities for correct disposal.

Disposal of your old product

Your product is designed and manufactured with highly quality material and components, which can be recycled and reused. When this crossed-out wheeled bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/EC.

Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose your old products with your normal household waste. The correct disposal of your old product will help prevent potential negative consequences for the environment and human health.

Disposal of batteries

The batteries supplied do not contain the heavy metals mercury and cadmium. Please check on how to dispose exhausted batteries according to local regulations.

Left hand underside of TV

Rear of TV

• The Model and Serial number can be found at the rear and the left hand underside of your television set and on the packaging.

• This TV consumes minimal energy in

standby mode to minimise environmental impact.

• Power Consumption of the set can found on the type plate at the rear of the TV.

• For more speciﬁ cations of the product see the product leaﬂ et on www.philips. com/support.

Note Specifications and information are subject to change without notice.

• If you need further assistance, please call the customer support service in your country. The corresponding telephone numbers and addresses are given in the supplied Worldwide guarantee booklet.

Important

• Some TV antennas require power from the TV set. This set does not support such a feature.

Electric, Magnetic and Electromagnetic Fields (“EMF”)

• Royal Philips manufactures and sells many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.

• One of Philips’ leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products.

• Philips is committed to develop, produce and market products that cause no adverse health effects.

• Philips confirms that if its products are handled properly for their intended use, they are safe to use according to scientific evidence available today.

• Philips plays an active role in the development of international EMF and safety standards, enabling Philips to anticipate further developments in standardization for early integration in its products.

English

Safety

English

•

General

Two people are required to lift and carry a TV that weighs more than 25 kg. Improper handling of the TV can cause serious injury. The surface on which the TV is placed has to be level and able to withstand its weight. Air must be able to circulate freely through the ventilation slots. Do not place the TV in a confined place. Do not place naked flame sources such as lighted candles close to the TV. Do not place a vase filled with water near the TV. Spills can results in electric shock. If water gets into the TV, disconnect the TV from the mains and have it checked by a qualified technician. Do not expose the TV or the batteries of the remote control to heat, direct sunlight, rain or water. During a thunderstorm, do not touch any part of the TV, power cord or antenna cable.

Do not leave the TV in standby mode

• for an extended period of time. Instead disconnect it from the mains. Do not connect too many equipment

• to the same mains socket because it can result in fire or electric shock.

Wall mounting the TV

To wall mount the TV, please consult a

• qualified technician. Improper mounting of the TV can cause serious injury. Please check that the structure of the

• wall is suitable to carry the weight of the TV. Before mounting, all cables must be

• inserted into the connectors of the TV. connections can be done later. Wherever you place or hang the TV,

• ensure that air can circulate freely. through the ventilation slots. Do not position the TV in a confined space.

Caring and cleaning of the TV

Do not remove the protective sheet until you have completed the stand/wall mounting

• and connections.

Use only the soft cloth provided to clean the glossy area of the TV. For the other parts

• of the TV, use a soft dry cloth. Disconnect the TV from the mains before you clean the TV.

Do not touch, push, rub or strike the screen with anything hard as this may scratch or

• damage the screen permanently.

Contents

Getting started ....................................................................................... 1

Connecting the antenna .........................................................................................................1

Connecting / disconnecting from the mains ......................................................................1

Installing batteries into the remote control .....................................................................2

Switching on the TV ................................................................................................................2

Controls and connectors ....................................................................... 3

Side controls ............................................................................................................................. 3

Side connectors .......................................................................................................................3

Rear connectors ...................................................................................................................... 4

Remote control keys and functions ...................................................... 5

Selecting the menu languages .............................................................. 7

Searching and storing channels ........................................................... 8

Automatic searching ............................................................................................................... 8

Manual Searching ..................................................................................................................... 9

Selecting Colour or Sound System ..................................................................................9

Searching for your channels ...........................................................................................10

Fine Tuning your channels ...............................................................................................11

Sorting your channels .......................................................................... 12

Naming your channels ......................................................................... 13

Storing your favorite channels ............................................................ 14

Adjusting your picture settings ...........................................................15

Adjusting your sound settings ............................................................. 16

Setting the timer .................................................................................. 17

Setting the sleep timer .........................................................................................................17

Setting the clock ....................................................................................................................18

Displaying the clock permanently ......................................................................................18

Setting the time to switch channels ..................................................................................19

Setting the time to switch TV to standby.........................................................................20

Setting ways to activate the timer .....................................................................................20

Locking and unlocking the TV side control .......................................21

Activating the Child Lock ....................................................................................................21

Deactivating the Child Lock ................................................................................................21

Controlling TV program access ......................................................... 22

Accessing Parental Lock .......................................................................................................22

Changing the access code ....................................................................................................23

Locking all channels ...............................................................................................................24

Unlocking all channels ..........................................................................................................24

English

Contents

English

Switching on and off Active Control ................................................. 25

Switching on Active Control ...............................................................................................25

Switching off Active Control ...............................................................................................25

Ambilight ............................................................................................. 26

Switching on Ambilight .........................................................................................................26

Switching off Ambilight .........................................................................................................26

Settings for Ambilight .......................................................................... 27

Adjusting brightness ..............................................................................................................27

Selecting Ambilight modes ...................................................................................................27

Selecting Ambilight colour ...................................................................................................28

Using custom colours ...........................................................................................................29

Selecting Ambilight balance..................................................................................................29

Displaying Demo mode ....................................................................... 30

Displaying Demo mode ........................................................................................................30

Accessing Teletext ................................................................................ 30

Switching on/off Teletext ......................................................................................................30

Selecting a page ......................................................................................................................30

Fastext (only applicable when Fastext is in broadcast) .................................................30

Selecting index (contents) page ..........................................................................................30

Selecting subpage directly ....................................................................................................30

Enlarging a page ......................................................................................................................30

Page hold .................................................................................................................................30

Hidden information ...............................................................................................................30

Selecting picture formats .................................................................... 31

Selecting Smart picture and Smart sound settings .......................... 32

Smart sound settings ............................................................................................................32

Smart picture settings ...........................................................................................................32

Using the TV as a computer monitor ................................................33

Setting the picture, sound and features in VGA mode ..................................................33

Using the TV in High De nition (HD) mode ..................................... 34

Connecting the HD equipment ..........................................................................................34

Controlling the TV settings while in HD mode ..............................................................34

Mode Selection in Features menu .....................................................................................35

Display (native 1080) in Features menu ...........................................................................35

Connecting to other devices ............................................................... 37

Troubleshooting.................................................................................... 38

Symptom ..................................................................................................................................38

Possible solutions ..................................................................................................................38

Speci cations ........................................................................................ 40

Getting started

NOTE: If you intend to mount the TV on the wall, all cables must be inserted into the

connectors of the TV first.

Connecting the antenna

The antenna socket is located at the rear panel (underside) of the TV.

& Insert the antenna connector into the

TV antenna socket.

é Insert the connector at the other end of

the cable into your wall antenna socket.

Connecting / disconnecting from the mains

& Insert the power cord connector

(appliance coupler) into the socket located at the rear (underside) of the TV.

é Insert the plug into the wall power

socket.

NOTE:

The appliance coupler of the power cord on the TV is used as the disconnect device. Ensure that the power cord is fully inserted into the TV mains socket and the wall socket. To disconnect from the mains, remove the power cord from the TV mains socket or the wall socket. Verify that the mains supply voltage in your home corresponds to the voltage information printed on the sticker at the rear of the TV.

English

WARNING:

For TV mounted on a swivel base or arm, please ensure that the power cord is not strained during swivelling. Straining the power cord will loosen connections. This may cause arcing and result in fire.

Getting started

English

Installing batteries into the remote control

& Remove the cover at the back of the

remote control.

é Insert the two supplied batteries with

the (+) and (-) ends lined up correctly.

Switching on the TV

The TV controls are located at the left side of the set.

& Press the POWER button.

A blue indicator light comes on.

é Press CHANNEL + / - to change the

channels.

“ If the TV is in standby mode (red

indicator lights up), press the CHANNEL + / - to switch on the TV.

Controls and connectors

Side controls

The side controls are on the left side of the TV set.

1 VOLUME + / -

To increase volume level, press VOLUME +, to decrease level, press VOLUME -.

2 MENU

To display the on-screen menus or to exit from the on-screen menus. The CHANNEL + / - buttons can be used to navigate the menu items. The VOLUME + / - buttons can be used to select the menu items.

3 CHANNEL + / -

To select the TV channel numbers upwards or downwards.

4 POWER

To turn off or turn on the TV set.

Side connectors

English

The side connectors are on the left side of the TV set.

1 Headphones

To connect to your headphones.

2 Audio / Video / S-Video

To connect your devices such as camera or player.

Controls and connectors

Rear connectors

English

The rear connectors are at the back (underside) of the TV set.

1 CVI-1 / CVI-2

To connect to your devices such as DVD players, decoders and Home Theatre systems.

2 Antenna

To connect to the antenna.

3 Audio / Video / S-Video

To connect your devices such as camera, camcorder, or video player.

4 HDMI1 / HDMI2

To connect your devices such as set-top box, DVD player/recorder, high de nition equipment or personal computer.

5 VGA / Audio for PC

To use the TV as a computer monitor. You can view the computer’s content in the TV’s different screen sizes and listen to the audio content.

6 Audio / Video

To connect your devices such as Home Theater systems and DVD recorders.

Remote control keys and functions

2 ù button

To select Stereo and forced Mono sound

effect.

3 Teletext *

*Not applicable for models sold in China (see page 30)

4 Sleeptimer

To switch off TV to standby at a specified time (see page 17).

5 Smart Sound button

To select the pre-set Sound settings.

6 Incredible Surround button

To enable Incredible Surround in stereo mode and Spatial in mono mode.

7 Mute button

To turn off or turn on sound.

8 Ambilight On/Off button

To switch on or off Ambilight.

English

1 Standby button

To switch the TV to standby mode if it is already turned on. Or to turn on TV when it is in standby mode.

9 Volume buttons

To turn up or turn down the sound level.

10 Ambilight mode button

To select the Ambilight mode set in Features menu.

11 Number (0-9) buttons

To enter channel number, set time or timer.

12 On screen information button

To display information on the current channel or to exit on-screen menus.

13 Alternate Channel button

To display the last viewed channel.

Remote control keys and functions

English

14 Picture Format button

To cycle through list of available picture formats.

15 AV button

To display AV source list or to cycle through list of AV sources by pressing the button repeatedly.

16 Pixel Plus Demo button

To turn on Pixel Plus Demo. One half of screen will display image with Pixel Plus enabled and the other half without.

17 Smart Picture button

To select the pre-set picture settings.

18 Program List button

To display the list of available channels which you can scroll through using the cursor buttons.

19 Cursor buttons

To navigating and selecting menu items and adjusting individual settings.

20 OK button

To select menu items or confirm selection.

21 Menu button

To display the on-screen menus and exit menus from the screen.

22 Channel buttons

To select the higher or lower channel number.

NOTE:

The

u button is used to select menu items

or confirm your selection. You can also press the Æ button instead of the u button. Either of the

button will work in the same context.

Selecting the menu languages

Before using the on-screen menus, select your menu language.

& Press h button to display the on-screen

menus.

é Press ï button until Install is

highlighted.

“ Press u button to select Language.

The available languages for your TV will be displayed on the right panel.

‘ Press u button to highlight the first

language or ï to select the other available languages.

( Press u button to select the language.

§ Press h button to exit the on-screen

menus.

English

Searching and storing channels

English

When you are using the TV for the first time, it is recommended that you run the automatic or manual searching of channels.

Automatic searching

& Press h button to display the on-

screen menus.

é Press ï button until Install is

highlighted.

“ Press u button to select Install.

‘ Press ï button until Auto Store is

highlighted.

( Press u button to start Auto Store.

The TV will start scanning for channels automatically. When it finds a channel, it will assign the channel number 1 to it and continue scanning for the next available channel. When scanning has completed, the progress bar display will exit from the screen. The first channel found will be displayed on the screen.

§ Press h button to exit the on-screen

menus.

TIP:

To cancel or interrupt auto searching, press

the

h button. Only channels that were

found before interruption, will be stored.

Searching and storing channels

Manual Searching

In manual searching, you can select the following items to tune for channels: Colour System Sound System Search Channel Fine Tune Store (To store your settings)

Selecting Colour or Sound System

& Press h button to display the on-

screen menus.

é Press ï button to highlight Install and

then press the Æ button to select it.

“ Press ï button to highlight Manual

Store and then press the

select it.

Æ button to

‘ Press ï button to highlight Colour

System or Sound System and then press the Æ button to select it.

English

( Press Î or ï button to select the type

of system and press the

u button.

§ Press Í button to exit and then press

ï button to highlight Store.

è Press the Æ button to select it and then

press the

u button to store the settings.

! Press h button to exit the on-screen

menus.

+ 34 hidden pages
