Philips 32PFL5403/55 Leaflet

Download

Page 1

Philips 5000 series LCD TV with Pixel Plus HD

32"

HD Ready

32PFL5403

Brilliant design, powerful performance.

Panache and performance meet in one stylish experience. Combining a HD Ready 768p display, Pixel Plus HD engine and fantastic invisible sound, this Flat TV ensures brilliant design and powerful performance for years to come.

Vivid and razor sharp pictures

• Pixel Plus HD for better details, depth and clarity

• HD LCD display, with a 1366 x 768p resolution

• 28.9 billion colors for brilliant natural images

• Dynamic contrast 26000:1 for incredible rich black details

Pure and powerful sound

• Invisible speakers with incredible surround

• Incredible Surround for enhanced audio enjoyment

• BBE for superior sound clarity

• 2 x 15W RMS audio power

Connect, install and enjoy

• 2 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV & connected device via HDMI CEC

• PC-input allows you to use your TV as a PC monitor

• Smart mode selects a perfect mode for what you are watching

Page 2

32PFL5403/55

LCD TV

32" HD Ready

Highlights

Pixel Plus HD

Pixel Plus HD is a picture processing te

chnology that enables viewer to watch contents that are vivid, natural and real. The result is a superbly razor sharp pictures with incredible details and depth from any HD source.

LCD display, 1366 x 768p

This WXGA display with state-of-the-art LCD s

creen technology gives you widescreen HD resolution of 1366 x 768p pixels. It produces brilliant flicker-free progressive scan pictures with optimum brightness and superb colors. This vibrant and sharp image will provide you with an enhanced viewing experience.

Dynamic contrast ratio 26000:1

You want the LCD flat display with the highest contrast advanced video processing combined with unique extreme dimming and backlight boosting technology results in vibrant images. Dynamic Contrast will increase the contrast with excellent blacklevel and accurate rendition of dark shades and colors. It gives a bright, lifelike picture with high contrast and vibrant colors.

and most vibrant images. Philips

Invisible speakers

An invisible sound system that blends perfectly w

ith the design of the cabinet. The Incredible Surround allows you to experience total surround with greater depth and width of sound. It gives a clear and spacious sound stage complementary to the rich viewing experience.

BBE

BBE high definition sound is the core sound e

nhancement technology (licensed by BBE Sound) that will enable you to experience real natural music, speech intelligibility with rich and clear audible vocals.

2 HDMI inputs

HDMI makes an uncompressed digital RGB conne

ction from the source to the screen. By eliminating conversion to an analog signal, it delivers an unblemished image. The nondegraded signal reduces flicker and leads to a clearer picture. HDMI intelligently communicates the highest output resolution with the source device. The HDMI input is fully backward compatible with DVI sources but includes digital audio. HDMI uses HDCP copy protection. With 2 HDMI inputs you can connect multiple HD sources, for instance an HD settop box, and a Blu-ray player. Your TV is fully prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry standard proto between connected devices and the TV. With EasyLink only one remote control is needed to operate main functionalities on your TV and connected devices. EasyLink uses the standard HDMI cable to transfer system commands. It works between all electronic devices equipped with HDMI CEC.

PC input (HDMI+VGA)

With PC input you can use your TV as a PC moni

tor either using a HDMI-DVI cable/ converter (for digital signals) or VGA cable (for analog signals).

Smart mode

The optimum picture and sound depends on v

arious aspects like the video source, content type, surroundings of the room, type of display device etc. Smart Mode has predefined picture and sound settings conveniently preset by the way you use your TV. The ‘Personal’ setting, allows you to define the picture settings according to your preference, store it and gain easy access for future selection. All these conveniently built into your TV for optimal settings.

col to share functionality

Page 3

32PFL5403/55

LCD TV

32" HD Ready

Specifications

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 26000:1

• Response time (typical): 8 ms

• Viewing angle: 178º (H) / 178º (V)

• Diagonal screen size: 32 inch / 81 cm

• Display screen type: LCD WXGA Active Matrix T

TF Panel resolution: 1366 x 768p

•

• Picture enhancement: Pixel Plus HD, 3/2 - 2/2

tio

n pull down, 3D Combfilter, Active Control

mo + Light sensor, Contrast Plus, Digital Noise Reduction, Dynamic contrast enhancement, Jagged Line Suppression, Luminance Transient Improver, Progressive Scan

• Screen enhancement: Anti-Reflection coated

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 640 x 480 60, 72, 75, 85Hz 720 x 400 70Hz 800 x 600 60, 72, 75, 85Hz 1024 x 768 60, 70, 75, 85Hz 1280 x 768 60Hz 1280 x 1024 60Hz 1360 x 768 60Hz

deo formats

• Vi

Res

olution Refresh rate 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz 720p 50, 60Hz 1080i 50, 60Hz 1080p 24, 50, 60Hz 1080p 24, 25, 30Hz

Sound

• Equalizer: 7-bands

• Output power (RMS): 2 X 15W

• Sound Enhancement: Auto Volume Leveller,

• Sound System: Stereo, BBE, SAP

Equaliser, Incredible Surround

Graphic

Loudspeakers

• Built-in speakers: 2

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: On main display, Sleep Timer, Wake Up r

Time

• Connection Enhancement: Easy link

• User convenience: Closed Captioning (analog),

hip

and parental lock

• Ease of Installation: Auto Program Naming, store, Fine Tuning, PLL Digital Tuning,

Auto Program Name, Sorting

• Ease of Use: 8 channel smart

Leveller (AVL), On Screen Display, Program List, Side Control, Closed Captioning Full Text

• On-Screen Display languages: English, Portuguese, s

Spani

• Remote Control: TV

• Remote control type: PF04L08B

• Screen Format Adjustments: 4:3, Movie expand

, Movie expand 16:9, Subtitle Zoom, Super

14: Zoom, Widescreen

• Signal strength indication

• Smart mode: Game, Movie, Personal, Power saver,

Sports, Standard

surf

list, Auto Volume

Tuner/Reception/Transmission

• Aerial Input: 75 ohm F-type

• TV system: NTSC M, PAL N, PAL M

• Video Playback: NTSC, SECAM, PAL (all versions)

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• Number of Preset Channels: 125

•Tuner Display: PLL

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: Audio L/R in, CVBS in

•HDMI 1: HDMI v1.3

•HDMI 2: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System

(menu language), System standby

inf

•Front / Side connections: Audio L/R

Headphone out, S-video in

• Other connections: PC-in VGA + Audio L/R in, S/

PDIF out (coa

xial)

in, CVBS in,

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 100-240V, 50/60Hz

•

Power consumption: 130 W

• Standby power consumption: typ. 0.165W

Dimensions

•Set dimensions (W x H x D): 819 x 518 x 92 mm

• Set dimensions with stand (W x H x D): 819

• Weight incl. Packaging: 21 kg

• Product weight: 14.2 kg

• Product weight (+stand): 18 kg

•Box dimensions (W x H x D):

• VESA wall mount compatible: 200 x 300 mm

222 mm

x 579 x

x 646 x 255 mm

Accessories

• Included Accessories: Tabletop swivel stand, Power cord, Quick start guide, User Manual, Remote Control, Batteries for remote control

•

Issue date 2019-06-28

Version: 1.0.56

12 NC: 8670 000 39895 EAN: 87 12581 42480 0

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
