Page 1
Philips 5000 series
LED TV with HD TV with
Pixel Plus
81 cm (32")
HD Ready
DVB-T/C
32PFL5306H
Relax and enjoy a great TV night
with brilliant 100Hz PMR LED picture
Relax and enjoy a great TV night in brilliant LED quality on the Philips 5000 Series
32PFL5306 LED TV. Powered by the Pixel Plus engine for clear, vivid pictures, and
complimented by authentic sound.
Your entertainment in brilliant detail
• HD Ready TV with Pixel Plus for better details and clarity
• Brilliant LED images with low power consumption
• 100Hz Perfect Motion Rate (PMR) for superb motion sharpness
Authentic and clear sound experience
• Hear every word with Clear Sound
• Feel the atmosphere with 16W RMS and Incredible Surround
Complete digital connectivity made simple
• Seamless connectivity with 2 HDMI inputs and Easylink
• Integrated MPEG-4 tuner for HD reception without set top box
• Enjoy photo and music playback via USB
Simple to set up, easy to use
• Easy to set up with setting assistance
• Be guided through your set-up with simple on screen help
Page 2
32PFL5306H/58
LED TV
81 cm (32") HD Ready, DVB-T/C
Highlights
HD TV with Pixel Plus
Pixel Plus is a digital picture processing
te
chnology that increases the number of lines
and the number of pixels. The result means
razor sharp pictures with incredible detail and
depth, every time from any source.
LED
The most advanced LED lighting technology in
this TV combines an eye-catching minimalistic
design with stunning image quality as well as
the lowest power consumption in its category.
On top of that, LED lighting technology does
not contain any hazardous materials. Thus,
with LED backlight you can enjoy low power
consumption, high brightness, incredible
contrast, sharpness and vibrant colors.
Clear Sound
Clear Sound is an innovative audio technology
that significantly increases the
comprehensibility of the voice, whether
spoken or sung. It ensures you hear every
word, so you can enjoy what you're watching
to the fullest.
2x8W RMS Incredible Surround
Feel the power of the music beat and the
at
mosphere of the movies. The powerful
2x8W RMS amplifiers create a lifelike sound
stage. Incredible Surround allows you to
experience total surround with greater depth
and width of sound helping complement the
rich viewing experience.
TV, DVD, BluRay, set top box or home theatre
system.
USB for photo & music playback
The USB connector allows access to jpeg
p
hotos and mp3 music of most USB-sticks
(USB memory-class device). Plug the USB into
the slot at the side of the TV and access the
multimedia content using the easy on screen
content browser. You can now view and share
your photos and music.
Integrated DVB tuner MPEG-4
The integrated digital tuner lets you receive
digit
al cable and terrestrial TV without an
additional set top box. Enjoy quality TV clutter
free.
Easy to set up
100Hz Perfect Motion Rate
Combining the refresh rate of the panel and
unique image processing, Perfect Motion Rate
(PMR) creates extreme motion sharpness for
clear and vibrant images even with fast onscreen motion.
2 HDMI inputs with Easylink
This TV is easy to setup with the step by step
setting assistant. The assistant shows a few
screens with easy to choose options to select
the essential settings. The TV performance is
set to the your personal preference without
difficult terms or settings, and this very quickly.
HDMI is a single cable to carry both picture
and audio signals from your devices to your
TV, avoiding cable clutter. It carries
uncompressed signals, ensuring the highest
quality from source to screen. Together with
Philips Easylink, you need only one remote
control to perform most operations on your
Page 3
32PFL5306H/58
LED TV
81 cm (32") HD Ready, DVB-T/C
Specifications
Picture/Display
• Display: edge LED backlight
• Diagonal screen size: 32 inch / 81 cm
• Panel resolution: 1366 x 768p
• Aspect ratio: 16:9
• Brightness: 400 cd/m²
• Peak Luminance ratio: 65 %
• Dynamic screen contrast: 500.000:1
• Response time (typical): 5 ms
ve Control +
• Picture enhancement: Pixel Plus,
Acti
Light sensor, 100 Hz Perfect Motion Rate
Sound
• Output power (RMS): 16W (2 x 8W)
• Sound Enhancement: Auto Vo
Sound, Incredible Surround, Treble and Bass
Control
lume Leveller, Clear
Connectivity
• Number of HDMI connections: 2
•HDMI features: Audio Re
• EasyLink (HDMI-CEC): Remote control pass-
gh, System audio control, System standby,
throu
Pixel Plus link (Philips), One touch play, System info
(menu language)
• Number of component in (YPbPr): 1
•Number of scarts (RGB/CVBS): 1
• Number of USBs: 1
• Other connections: Antenna IEC75, Common
terface Plus (CI+), Digital audio out (coaxial), PC-
n
I
in VGA + Audio L/R in, Headphone out
turn Channel
Multimedia Applications
• Multimedia connections: USB
• Music Playback Formats: MP3
• Picture Playback Formats: JPEG
Supported Display Resolution
• Computer inputs: up to 1920x1080 @ 60Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to
1080p
1920x
Convenience
• Electronic Program Guide: 8 day Electronic
Program Guide
• Ease of Installation: Channel installation wizard,
connection wizard, Settings assistant
Device
wizard
• Ease of Use: One-stop Home button, Onscreen
Usermanu
al, Touch control buttons
• Screen Format Adjustments: 4:3, Autofill,
zoom, Movie expand 14:9, Movie expand
Auto
16:9, Subtitle Zoom, Super Zoom, Unscaled,
Widescreen
• Teletext: 1000 page Smart Text
• Firmware upgradeable: Firmware auto upgrade
d
, Firmware upgradeable via USB
wizar
Tuner/Reception/Transmission
• Digital TV: DVB-C MPEG2*, DVB-C MPEG4*,
DVB-T MPEG2*, DVB-T MPEG4*
• Video Playback: NTSC, PAL, SECAM
Power
• Mains power: AC 220-240V; 50-60Hz
• Ambient temperature: 5 °C to 35 °C
• Energy Label Class: A
• Eu Energy Label power: 42 W
• Annual energy consumption: 61 kW·h
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
ode, Eco settings menu, Light sensor, Picture
o m
Ec
mute (for radio)
• Presence of lead: Yes*
• Off mode power consumption: 0.01 W
Dimensions
•Box dimensions (W x H x D):
965 x 590 x 159 mm
•Set dimensions (W x H x D):
473 x 39.9 mm
761 x
• Set dimensions with stand (W x H x D):
525 x 221 mm
761 x
• Product weight: 6.1 kg
• Product weight (+stand): 9 kg
• Compatible wall mount: 200 x 200mm
Accessories
• Included accessories: Power cord, Remote
Control, 2 x AAA Batteries, Table top stand, User
Manual, Quick start guide, Legal and safety
brochure, Warranty Leaflet, Software declaration
•
Issue date 2019-06-22
Version: 2.2.4
12 NC: 8670 000 88835
EAN: 87 12581 64055 2
© 2019 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscripction are required.
Contact your operator for more information.
* 8 days EPG, service not available in all countries
* Energy consumption in kWh per year, based on the power
consumption of the televi
days. The actual energy consumption will depend on how the
television is used.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
sion operating 4 hours per day for 365
