32PFL3404/77
32PFL3404/78
42PFL3604/77
42PFL3604/78
EN User manual
Page 2
Page 3
Page 4
IMPORTANT SAFETY INSTRUCTIONS
g
Read before operating equipment
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with
the manufacturers instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and third grounding prong. The wide
blade or third prong are provided for your safety. When the provided
plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. This product may contain lead or mercury. Disposal of these materials
may be regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the
Electronic Industries Alliance:www.eiae.org.
16. Damage Requiring Service - The appliance should be serviced by
qualified service personnel when:
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a
marked change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
17. Tilt/Stability - All televisions must comply with recommended
international global safety standards for tilt and stability properties of its
cabinets design.
• Do not compromise these design standards by applying excessive pull
force to the front, or top, of the cabinet which could ultimately
overturn the product.
• Also,do not endanger yourself, or children, by placing electronic
equipment/toys on the top of the cabinet. Such items could
unsuspectingly fall from the top of the set and cause product damage
and/or personal injury.
18. Wall or Ceiling Mounting - The appliance should be mounted to a
wall or ceiling only as recommended by the manufacturer.
19. Power Lines - An outdoor antenna should be located away from
power lines.
20. Outdoor Antenna Grounding - If an outside antenna is connected to
the receiver, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built up static charges.
Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper grounding of the mats and
supporting structure grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna discharge unit, connection to grounding electrodes and requirements for
the grounding electrode. See Figure below.
21. Objects and Liquid Entry - Care should be taken so that objects do
not fall and liquids are not spilled into the enclosure through openings.
a) Warning: To reduce the risk of fire or electric shock, this apparatus
should not be exposed to rain or moisture and objects filled with
liquids, such as vases should not be placed on this apparatus.
22. Battery Usage CAUTION - To prevent battery leakage that may
result in bodily injury, property damage, or damage to the unit:
• Install all batteries correctly, with + and - alignment as marked on the
unit.
• Do not mix batteries (old and new or carbon and alkaline, etc.)
• Remove batteries when the unit is not used for a long time.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE (NEC)
GROUND CLAMP
ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT
NEC SECTION 810-20)
(
GROUNDING CONDUCTORS
NEC SECTION 810-21)
(
GROUND CLAMPS
ELECTRIC SERVICE EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
NEC ART 250, PART H)
(
Note to the CATV system installer: this reminder is provided to call the CATV system installer’s attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
rounding system of the building, as close to the point of cable entry as practical.
Page 5
Contents
1 Notice 2
Tuner/Reception/Transmission 21
Remote control 21
Connections 21
Power 21
Supported TV mounts 22
English
2 Important
3 Your product
Product overview 5
3
5
4 Use your product 7
Switch your TV on/off or to standby 7
Switch channels 7
Watch connected devices 8
Adjust TV volume 8
5 Use more of your product 9
Access TV menus 9
Change picture and sound settings 9
Create and use lists of favorite channels 12
Use timers 13
Use child control 13
Use the TV clock 14
Update the TV software 14
Change TV preferences 15
Start a TV demo 15
Reset the TV to factory settings 15
9 Troubleshooting 23
General TV issues 23
TV channel issues 23
Picture issues 23
Sound issues 24
HDMI connection issues 24
Computer connection issues 24
Contact us 24
10 Index 25
6 Install channels 16
Automatically install channels 16
Manually install channels 16
Rename channels 16
Rearrange channels 17
7 Connect devices 18
Back connectors 18
Side connectors 18
Connect a computer 19
Use Philips EasyLink 20
Use a Kensington lock 20
8 Product information 21
Supported display resolutions 21
EN
1
Page 6
1 Notice
2009 © Koninklijke Philips Electronics N.V.. All
rights reserved.
Speci cations are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V.. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
The material in this manual is believed
adequate for the intended use of the system.
If the product, or its individual modules or
procedures, are used for purposes other than
those speci ed herein, con rmation of their
validity and suitability must be obtained. Philips
warrants that the material itself does not
infringe any United States patents. No fur ther
warranty is expressed or implied.
Philips cannot be held responsible neither for
any errors in the content of this document
nor for any problems as a result of the content
in this document. Errors reported to Philips
will be adapted and published on the Philips
support website as soon as possible.
Pixel characteristics
This LCD product has a high number of
color pixels. Although it has effective pixels of
99.999% or more, black dots or bright points of
light (red, green or blue) may appear constantly
on the screen. This is a structural property of
the display (within common industry standards)
and is not a malfunction.
procedures not recommended or authorised in
this manual shall void the warranty.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures
and sells many products targeted at consumers,
which, like any electronic apparatus, in
general have the ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles is to
take all necessary health and safety measures
for our products, to comply with all applicable
legal requirements and to stay well within
the EMF standards applicable at the time of
producing the products.
Philips is committed to develop, produce and
market products that cause no adverse health
effects. Philips con rms that if its products are
handled properly for their intended use, they
are safe to use according to scienti c evidence
available today.
Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardisation for early
integration in its products.
Copyright
All other registered and unregistered
trademarks are the property of their respective
owners.
® Kensington and Micro Saver are registered
US trademarks of ACCO World corporation
with issued registrations and pending
applications in other countries throughout the
world.
Warranty
No components are user serviceable. Do not
open or remove covers to the inside of the
product. Repairs may only be done by Philips
Service Centres and of cial repair shops. Failure
to do so shall void any warranty, stated or
implied.
Any operation expressly prohibited in
this manual, any adjustments, or assembly
2
EN
VESA, FDMI and the VESA Mounting Compliant
logo are trademarks of the Video Electronics
Standards Association.
Portions of this software are copyright © The
FreeType Project (www.freetype.org).
Page 7
2 Important
Read and understand all instructions before you
use your TV. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
•
Risk of electric shock or re!
•
Never expose the TV to rain or
water. Never place liquid containers,
such as vases, near the TV. If
liquids are spilt on or into the TV,
disconnect the TV from the power
outlet immediately. Contact Philips
Consumer Care to have the TV
checked before use.
•
Never place the TV, remote control
or batteries near naked ames or
other heat sources, including direct
sunlight.
To prevent the spread of re, keep
candles or other ames away from
the TV, remote control and batteries
at all times.
•
Never insert objects into the
ventilation slots or other openings on
the TV.
•
When the TV is swiveled ensure that
no strain is exerted on the power
cord. Strain on the power cord can
loosen connections and cause arcing.
•
Risk of short circuit or re!
•
Never expose the remote control or
batteries to rain, water or excessive
heat.
Avoid force coming onto power
•
plugs. Loose power plugs can cause
arcing or re.
•
Risk of injury or damage to the TV!
•
Two people are required to lift and
carry a TV that weighs more than
25 kg.
•
When stand mounting the TV, use
only the supplied stand. Secure the
stand to the TV tightly. Place the
TV on a at, level surface that can
support the combined weight of the
TV and the stand.
•
When wall mounting the TV, use
only a wall mount that can support
the weight of the TV. Secure the wall
mount to a wall that can support the
combined weight of the TV and wall
mount. Koninklijke Philips Electronics
N.V. bears no responsibility for
improper wall mounting that results
in accident, injury or damage.
•
Risk of injury to children!Follow these
precautions to prevent the TV from
toppling over and causing injury to
children:
•
Never place the TV on a surface
covered by a cloth or other material
that can be pulled away.
•
Ensure that no part of the TV hangs
over the edge of the surface.
•
Never place the TV on tall furniture
(such as a bookcase) without
anchoring both the furniture and TV
to the wall or a suitable support.
•
Educate children about the dangers
of climbing on furniture to reach the
TV.
•
Risk of overheating! Never install the
TV in a con ned space. Always leave a
space of at least 10 cm around the TV
for ventilation. Ensure curtains or other
objects never cover the ventilation slots
on the TV.
•
Risk of damage to the TV! Before you
connect the TV to the power outlet,
ensure that the power voltage matches
the value printed on the back of the TV.
Never connect the TV to the power
outlet if the voltage is different.
English
EN
3
Page 8
•
Risk of injury, re or power cord damage!
Never place the TV or any objects on the
power cord.
•
To easily disconnect the TV power cord
from the power outlet, ensure that you
have full access to the power cord at all
times.
•
When you disconnect the power cord,
always pull the plug, never the cable.
•
Disconnect the TV from the power
outlet and antenna before lightning
storms. During lightning storms, never
touch any part of the TV, power cord or
antenna cable.
Risk of hearing damage! Avoid using
•
earphones or headphones at high
volumes or for prolonged periods of time.
If the TV is transported in temperatures
•
below 5°C, unpack the TV and wait
until the TV temperature matches room
temperature before connecting the TV to
the power outlet.
•
Risk of damage to the TV screen! Never
touch, push, rub or strike the screen with
any object.
•
To avoid deformations and color fading,
wipe off water drops as soon as possible.
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Screen care
•
Avoid stationary images as much as
possible. Stationary images are images
that remain on-screen for extended
periods of time. Examples include:
on-screen menus, black bars and time
displays. If you must use stationary
images, reduce screen contrast and
brightness to avoid screen damage.
•
Unplug the TV before cleaning.
•
Clean the TV and frame with a soft,
damp cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the TV.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment
and human health.
4
EN
Page 9
3 Your product
Remote control
Congratulations on your purchase, and
welcome to Philips! To fully bene t from the
support that Philips offers, register your product
at www.philips.com/welcome.
Side controls and indicators
4
3
2
1
22
21
20
19
18
17
16
English
1
2
3
4
5
6
7
8
9
10
a POWER : Switches the TV on or off.
The TV is not powered off completely
unless it is physically unplugged.
b P/CH +/- : Switches to the next or
previous channel.
c
d VOLUME +/- : Increases or decreases
SOURCE : Selects connected devices.
volume.
15
14
11
12
13
EN
5
Page 10
a
( Standby-On )
Switches the TV to standby if the TV •
is on.
Switches the TV on if the TV is in •
standby.
b MENU
Toggles the main menu on or off.
c
INCR. SURR
Enables Incredible Surround for stereo
sources. Enables spatial mode for mono
sources.
d
SOURCE
Selects connected devices.
e SAP ( Secondary audio program )
Selects Secondary Audio Program (SAP)/
Stereo/ Mono when SAP and/or Stereo is
broadcast.
f
OPTIONS
Accesses options relating to the current
activity or selection.
g OK
Con rms an entry or selection and
displays the channel grid, when watching
TV.
h
( Navigation buttons )
Navigates through the menus.
o +/- ( Volume +/- )
Increases or decreases volume.
p
BACK A/CH
Returns to a previous screen.•
Returns to the previously viewed •
channel.
q
BROWSE
Switches between channel grid and
program list.
r CC
Displays closed captions settings.
s TV/PC
Toggles between PC mode and
previously viewed video mode.
t SLEEP
Sets a delay after which the TV switches
to standby.
u
FORMAT
Toggles through available picture formats.
Some formats are not available for some
picture sources.
v DEMO
Toggles the demonstration menu on or
off.
i
INFO
Displays program information, if available.
j
( Mute )
Mutes or restores audio output.
k CH +/- ( CHANNEL +/ - )
Switches to the next or previous channel.
When the TV menu is on, this functions
as Page Up/Down.
l 0-9 ( Numeric buttons )
Selects a channel or setting.
m
PICTURE ( Smart picture )
Launches the smar t picture menu.
n
SOUND ( Smart Sound )
Launches the smar t sound menu.
6
EN
Page 11
4 Use your product
This section helps you perform basic operations.
Note
If you cannot locate your remote control and
•
want to switch on the TV from standby, press
P/CH +/- at the side of the TV.
English
Switch your TV on/off or to
standby
To switch on
If the standby indicator is off, press
•
POWER at the side of the TV.
If the standby indicator is red, press
•
( Standby-On ) on the remote control.
To switch to standby
Press
•
control.
»
To switch off
•
Press
»
( Standby-On ) on the remote
The standby indicator switches to red.
POWER at the side of the TV.
The standby indicator switches off.
Tip
Switch channels
Press BACK A/CH on the remote
•
control to return to the previously
viewed channel.
Press CH +/- on the remote control or
•
P/CH +/- on the side of the TV.
Press OK to use the channel matrix.
•
Enter a channel number using the
•
Numeric buttons .
Though your TV consumes very little power
•
when in standby, energy continues to be
consumed. When not in use for an extended
period of time, disconnect the TV power cable
from the power outlet.
Note
When you use a favorite list, you can only
•
select those channels in the list (see ‘Select a
favorite list’ on page 12 ) .
EN
7
Page 12
Watch connected devices
Use the source button
1 Press SOURCE .
»
The source list appears.
2 Press or to select the connected
device.
3 Press OK to watch the connected device.
Adjust TV volume
To increase or decrease volume
Press
•
•
Press VOLUME +/- on the side of the TV.
To mute or unmute sound
•
Press
•
Press
+/- .
to mute the sound.
again to restore the sound.
8
EN
Page 13
5 Use more of
your product
Access TV menus
Change picture and sound
settings
Change picture and sound settings to suit your
preferences. You can apply pre-de ned settings
or change settings manually.
English
Menus help you to install channels, change
picture and sound settings and access other
features.
1 Press MENU .
The menu screen appears.
»
Smart picture
Sound
Sound
Features
Features
Installation
Installation
Software update
Software update
Smart picture
Contrast
Contrast
Brightness
Brightness
Color
Color
Sharpness
Sharpness
Noise reduction
Noise reduction
Tint
Tint
Color Temperature
Color Temperature
Dig. Crystal Clear
Dig. Crystal Clear
2 Press the to select and navigate
through one of the following menus.
[Picture] Adjusts the picture setting
•
for optimal viewing.
[Sound] Adjusts the sound setting.
•
[Features] Accesses different features
•
like timer, TV lock, and demo.
[Installation] Selects channel
•
installation menu, adjusts preferences
and resets the TV to factory settings.
[Software update] Updates the TV
•
software.
3 Press OK to con rm your choice.
Use smart picture
Use smart picture to apply pre-de ned
picture settings.
1 Press PICTURE .
»
The [Smart picture] menu appears.
2 Press to select one of the following
smar t picture settings.
[Personal] Lists customized personal
•
picture settings.
[Sports] Maximizes picture settings.
•
[Standard] Adjusts picture settings
•
to suit most environments and types
of video.
[Movie] Applies picture settings
•
ideally suited for movie viewing.
[Game] Applies picture settings
•
maximized for fast-moving games.
[Energy saving] Applies low-energy
•
picture settings.
3 Press OK to con rm your choice.
»
The selected smart picture setting is
applied.
Tip
When the menu is on, CH +/- functions as
•
Page Up/Down.
Press MENU at any time to exit the menu.
•
•
Press
screen.
BACK A/CH to move back one
Manually adjust picture settings
1 Press MENU .
2 Press OK to select [Picture] .
»
The [Picture] menu appears.
3 Press to select from the following
settings and adjust:
EN
9
Page 14
•
[Smart picture] : Accesses pre-
de ned smart picture settings.
•
[Contrast] : Adjusts the intensity
of bright areas, keeping dark areas
unchanged.
•
[Brightness] : Adjusts the intensity
and details of dark areas.
•
[Color] : Adjusts color saturation.
•
[Hue] : Compensates color variations
in NTSC encoded transmissions.
•
[Sharpness] : Adjusts the level of
sharpness in image details.
•
[Noise reduction] : Filters and
reduces noise in an image.
•
[Color temperature] : Introduces
more orange tones or blue tones to
the picture.
•
[Dig.CrystalClear] : Digitally adjusts
picture quality to optimal contrast,
color and sharpness.
•
[Dynamic contrast] :
Automatically enhances contrast
in an image.
•
[Dynamic backlight] : Adjusts
the brightness of the TV
backlight to match lighting
conditions.
•
[Color enhancement] : Makes
colors more vivid and improves
the resolution of details in bright
colors. You can switch this
feature on or off.
•
[PC mode] : Adjusts picture settings
when a PC is connected to the TV.
•
[Picture format] : Changes the
picture format.
•
[Horizontal shift] : Adjusts the
picture horizontally for PC-VGA or
HD input.
•
[Vertical shift] : Adjusts the picture
vertically for PC-VGA or HD input.
Change picture format
1 Press FORMAT .
»
A picture format bar appears.
2 Press to select a picture format.
»
The selected picture format is
activated.
3 Press OK to con rm your choice.
10
EN
Page 15
Summary of picture formats
Use smart sound
The following picture settings can be
con gured.
Note
Depending on the format of the picture
•
source, some picture settings are not available.
[Super zoom] (Not for HD
and PC mode.) Removes
the black bars on the side
of 4:3 broadcasts. There is
minimal distortion.
[4:3] Shows the classic 4:3
format.
[Subtitle zoom] Displays
4:3 pictures over the full
area of the screen, with
sub-titles visible. Part of
the top of the picture is
clipped off.
[Movie exp.14:9] (Not for
HD and PC mode.) Scales
4:3 format to 14:9.
[Movie exp.16:9] (Not for
HD and PC mode.) Scales
4:3 format to 16:9.
[Wide screen] Stretches
the classic 4:3 format to
16:9.
[Unscaled] For HD and PC
mode only, and in selected
models only. Allows
maximum sharpness.
Some distortion may
be present due to the
broadcaster’s systems.
Set your PC resolution to
wide screen mode for best
results.
Use smart sound to apply pre-de ned sound
settings.
1 Press SOUND .
»
The [Smart sound] menu appears.
2 Press to select one of the following
smar t sound settings.
•
[Standard] Adjusts sound settings to
suit most environments and types of
audio.
•
[News] Applies sound settings ideally
suited for spoken audio, such as the
news.
[Movie] Applies sound settings ideally
•
suited for movies.
[Personal] Applies the settings that
•
were customized in the sound menu.
3 Press OK to con rm your choice.
»
The selected smart sound setting is
applied.
Adjust sound settings
1 Press MENU
2 Press to select [Sound] .
»
The [Sound] menu appears.
3 Press to select and adjust:
•
[Smart sound] Accesses pre-de ned
smar t sound settings.
•
[Bass] Adjusts the bass level.
•
[Treble] Adjusts the treble level.
•
[Volume] Adjusts the volume.
•
[Balance] Adjusts the balance of the
right and left speakers to best suit
your listening position.
•
[Stereo/Mono/SAP] Selects between
audio languages if dual sound is
broadcast.
English
EN
11
Page 16
[Mono/Stereo] Selects between
•
mono or stereo if stereo is
broadcast.
[Surround] Enables spatial sound.
•
[Auto volume] Automatically
•
reduces sudden volume changes, for
example, when switching channels.
When enabled, this produces a more
consistent audio volume.
[Delta volume] Levels out volume
•
differences between channels or
connected devices. Switch to the
connected device before you change
the delta volume.
Add a channel to a favorite list
Tip
View all channels before adding a channel to a
•
favorite list.
1 When watching TV, switch to the channel
you want to add to a favorite list (see
‘Switch channels’ on page 7 ) .
2 Press to select a channel to add to
a favorite list.
3 Press OPTIONS .
»
The channel options menu appears.
4 Press to select [Mark as favorite] .
Create and use lists of
favorite channels
You can create lists of your preferred TV
channels and radio stations so that you can nd
those channels easily.
Tip
You can create and store up to four favorite
•
lists on your TV.
Select a favorite list
1 When watching TV, press OK to display
the channel grid.
2 Press OPTIONS .
The channel options menu appears.
»
3 Press OK to select [Show favorite ch.] .
The favorite lists appear.
»
4 Press to select a favorite list.
5 Press OK .
Only channels in the favorite list
»
appear in the channel grid.
5 Press OK .
The favorite lists appear.
»
6 Press to select a favorite list to add
the channel to.
7 Press OK .
The channel is added to the favorite
»
list.
Tip
When watching TV, press OPTIONS >
•
[Mark as favorite] to save the current channel
into a favorite list.
Remove a channel from a favorite list
Note
Select the favorite list to edit, before removing
•
a channel .
1 When watching TV, press OK to display
the channel grid.
2 Press OPTIONS .
The channel options menu appears.
»
3 Press OK to enter [Show favorite ch.] .
4 Press to select a favorite list and press
OK to con rm the choice.
12
EN
Page 17
5 Press to choose the channel that
you wish to remove from the list.
6 Press OPTIONS .
7 Press to select [Unmark as fav.] .
3 Press to enter the [On timer] menu.
4 Press to select [Activate] and set a
day of the week or frequency.
English
5 Press OK to con rm.
8 Press OK .
The channel is removed from the
»
favorite list.
Use timers
You can set timers to switch the TV on or
switch to standby at a speci ed time.
Automatically switch the TV to
standby (sleeptimer)
Sleeptimer switches the TV to standby after a
pre-de ned period of time.
Tip
You can always switch off your T V earlier or
•
reset the sleeptimer during the countdown.
6 Press to select [Time] and set the
starting time.
7 Press [Done] to con rm.
8 Press to select [Program no.] and
set the channel.
9 Press OK to con rm.
10 Press MENU to exit.
Tip
Select [Off] to switch off [On timer] .
•
When [On timer] is switched off, only
•
[Activate] option is available.
Set the TV clock before you activate [On
•
timer] feature (see ‘Set the TV clock’ on page
14 ) .
Use child control
1 Press MENU
2 Select [Features] > [Sleep timer] .
The [Sleep timer] menu appears.
»
3 Press to set the sleep time.
»
The sleeptimer can be up to 180
minutes in steps of ve minutes. If
set to zero minutes, the sleeptimer is
switched off.
4 Press OK to activate the sleeptimer.
»
The TV switches to standby after the
pre-de ned period of time.
Automatically switch the TV on (on
timer)
You can switch the TV to a speci ed channel
at a speci ed time, from standby.
1 Press MENU .
2 Select [Features] > [On timer] .
You can prevent your children from watching
certain programs or certain channels by locking
the TV controls.
Set or change your PIN code
1 Press MENU .
2 Press to select [Features] > [Set
code] .
3 Press to enter the code setup.
4 Enter your code with the Numeric
buttons .
5 Re-enter the same code in the new dialog
box for con rmation.
If the code is set successfully, the
»
dialog box will disappear. However, if
the code cannot be set, you will be
prompted to re-enter the code.
6 If you want to change the code, select
[Features] > [Change code] .
EN
13
Page 18
7 Enter your current code using the
Numeric buttons .
»
If the code is validated, you will be
prompted to enter your new code.
8 Enter the new code using the Numeric
buttons.
»
You will be prompted to re-enter the
new code for con rmation.
Tip
If you forget your code, enter ‘0711’ to
•
override any existing codes.
Use the TV clock
You can display a clock on the TV screen. The
clock displays the current time using time data
received from your TV service operator.
Display the TV clock
1 When watching TV, press OPTIONS .
»
The TV options menu appears.
2 Select [Clock] .
3 Press OK .
The clock is displayed.
»
Lock or unlock the TV
Locking the TV prevents your child from
accessing all channels and connected devices.
1 Press MENU .
2 Press to select [Features] > [TV
lock] .
3 Press to enter [TV lock] .
A screen prompting you to enter code
»
appears.
4 Enter your code.
5 Press to select [Lock] or [Unlock] .
6 Press OK .
All channels and connected devices are
»
locked or unlocked.
7 Press MENU to exit.
Lock or unlock one or more channels
Note
The clock is disabled automatically after ten
•
minutes. To disable the clock before that,
repeat this procedure.
Set the TV clock
1 Press MENU .
2 Select [Features] > [Clock] .
»
The [Clock] menu appears.
1 Press or Numeric buttons to
enter time.
2 Press [Done] to con rm.
3 Press MENU to exit.
Note
The clock is disabled automatically after three
•
seconds.
1 When watching TV, press OK to display
the channel grid.
2 Press to select a channel to lock or
unlock.
3 Press OPTIONS .
4 Press to select [Lock/Unlock chan.] .
5 For each selection, press OK to lock or
unlock the channel.
14
EN
Update the TV software
Philips continuously tries to improve its
products and we recommend that you update
the TV software when updates are available.
Check www.philips.com/support for availability.
Page 19
Check the current software version
1 Press MENU .
2 Select [Software update] > [Current
software] .
Download the software
1 On your PC, open a web browser and go
to www.philips.com/support.
2 Find information and software related
to your TV and download the latest
software upgrade le to your PC.
3 Decompress the ZIP- le.
•
[Volume bar] Displays the volume
bar when adjusting the volume.
•
[EasyLink] Enables one-touch play
and one-touch standby between
EasyLink-compliant devices.
[E-sticker] For shop mode only. Sets
•
the location of the e-sticker.
4 Press to select your preference.
5 Press OK .
6 Press MENU to exit.
Start a TV demo
English
4 Copy the autorun.upg le to the root
directory of the USB device.
Update software (analog broadcasts)
Before performing this procedure be sure to:
Set aside some time to complete the
•
entire update.
Have available a USB storage device with
•
at least 64MB of storage space.
Have access to a computer with a USB
•
port and internet access.
1 Press MENU .
2 Select [Software update] > [Update
assistant] .
3 Select [Start] .
4 Connect the USB storage device to your
computer.
5 Follow the on-screen instructions to
complete the update.
You can use demonstrations to better
understand the features of your TV. Some
demos are not available on certain models.
When a demo is available, it is displayed in the
menu list.
1 Press DEMO on the remote control.
2 Press to select a demo and press OK
to view it.
3 Press DEMO to exit.
Reset the TV to factory
settings
You can restore the default picture and sound
settings of your TV. Channel installation settings
remain the same.
Change TV preferences
The [Preferences] menu allows you to
customize various features and functions.
1 Press MENU .
2 Select [Installation] > [Preferences] .
3 Press to enter [Preferences] .
•
[Location] Optimizes TV settings for
your location - home or shop.
1 Press MENU .
2 Select [Installation] > [Factory settings] .
3 Press to enter the [Factory settings]
menu.
»
[Reset] is highlighted.
4 Press OK to reset to factory settings.
5 Press MENU to exit.
EN
15
Page 20
6 Install channels
6 Press OK to con rm.
7 Press MENU to exit.
The rst time you setup your TV, you are
prompted to select a menu language and to
install TV and digital radio channels (if available).
This chapter provides instructions on how to
reinstall and ne tune channels.
Automatically install channels
This section describes how to search and store
channels automatically.
1 Press MENU .
2 Select [Installation] > [Channel install.]
> [Channel assistant] .
3 Press OK .
4 Follow the on-screen instructions to
install channels.
Step 2 Search and store new TV
channels
1 Press MENU .
2 Select [Installation] > [Channel install.]
> [Analog: Manual] .
The [Analog: Manual] menu appears.
»
3 Press to select and enter [Search] .
4 Press or use Numeric buttons to
manually enter the three digit frequency.
5 Press OK to begin search.
6 Press when the new channel is found.
7 Press to select [Store new
channel] to store the new channel under
a new channel number.
8 Press to select [Yes] and press OK to
store new channel.
9 Press MENU to exit.
Manually install channels
This section describes how to search and store
analog TV channels manually.
Step 1 Select your system
Note
Skip this step if your system settings are
•
correct.
1 Press MENU .
2 Select [Installation] > [Channel install.]
> [Analog: Manual]
The [Analog: Manual] menu appears.
»
3 Press to select and enter [Color
system] .
4 Press OK to con rm.
5 Press to select and enter [Sound
system] .
Rename channels
Channels can be renamed so that a name of
your choice appears whenever the channel is
selected.
1 When watching TV, press OK to display
the channel grid .
2 Select the channel you want to rename.
3 Press OPTIONS .
The channel options menu appears.
»
4 Press to select [Rename chan.] and
press OK .
A text input box appears.
»
5 Press to select a character and press
to add another character.
6 Select [Done] .
7 Press OK .
16
EN
Page 21
Rearrange channels
After you install channels, you can rearrange the
order in which they appear.
1 When watching TV, press OK to display
the channel grid .
2 Press OPTIONS .
»
The channel options menu appears.
3 Press to select and enter [Reorder] .
4 Select the channel you want to reorder
and press OK .
5 Press to select the new position
for the channel.
6 Press OK to con rm the new position.
7 Press OPTIONS .
»
[ Done reordering ] appears.
8 Press OK to nish reordering.
English
EN
17
Page 22
7 Connect devices
This section describes how to connect
various devices with different connectors and
supplements examples provided in the Quick
Start.
Note
Different types of connectors may be used to
•
connect a device to your TV, depending on
availability and your needs.
Audio and video output to analog devices
such as another TV or a recording device.
f AV IN ( VIDEO and AUDIO L/R )
Analog audio and video input from analog
or digital devices such as DVD players,
satellite receivers and VCRs.
g CVI 1/2 ( Y Pb Pr and AUDIO L/R )
Analog audio and video input from analog
or digital devices such as DVD players or
game consoles.
Side connectors
Back connectors
a HDMI
Digital audio and video input from highde nition digital devices such as Blu-ray
players.
1
1
2
2
3
3
4
4
5
5
a SERVICE
For software update.
b HDMI
Digital audio and video input from highde nition digital devices such as Blu-ray
players.
c VIDEO
Composite video input from analog
devices such as VCRs.
b VGA/PC and PC AUDIO IN
Audio and video input from a computer.
c TV ANTENNA
Signal input from an antenna, cable or
satellite.
d SERV. U
For use by service personnel only.
e AV OUT ( VIDEO and AUDIO L/R )
18
EN
d AUDIO L/R
Audio input from analog devices
connected to VIDEO .
e
Stereo audio output to headphones or
earphones.
Page 23
Connect a computer
Before you connect a computer to the TV
Set the monitor refresh rate on your
•
computer to 60Hz.
Press
•
picture format to [Unscaled] .
Connect a computer with one of the
following connectors:
Note
Connections via DVI or VGA require an
•
additional audio cable.
•
HDMI cable
FORMAT and change the TV
HDMI cable and HDMI-DVI adaptor
•
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
•
VGA cable
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
DVI
DVI
English
•
DVI-HDMI cable
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
DVI
DVI
VGA
VGA
EN
19
Page 24
Use Philips EasyLink
Enable or disable EasyLink
Your TV supports Philips EasyLink, which
uses the HDMI CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices
that are connected through HDMI connectors
can be controlled by a single remote control.
Note
Philips does not guarantee 100%
•
interoperability with all HDMI CEC devices.
Note
The EasyLink-compliant device must be
•
switched on and selected as the source.
EasyLink features
One-touch play
When you connect your TV to devices that
support one-touch play, you can control your
TV and the devices with one remote control.
For example, when you press Play on your
DVD remote control, your TV automatically
switches to the correct channel to show the
DVD content.
Note
Do not enable Philips EasyLink if you do not
•
intend to use it.
1 Press MENU .
2 Select [Installation] > [Preferences] >
[EasyLink] .
3 Select [On] or [Off ] .
Use a Kensington lock
There is a Kensington security slot at the back
of the TV. Prevent theft by looping a Kensington
lock between the slot and a permanent object,
such as a heavy table.
One-touch standby
When you connect your TV to devices that
support standby, you can use your TV remote
control to put your TV and all connected
HDMI devices in standby mode.
Tip
Press TV to switch back to the antenna source
•
from EasyLink mode.
20
EN
Page 25
8 Product
information
Product information is subject to change
without notice. For detailed product
information, go to www.philips.com/support.
Supported display resolutions
Computer formats
HDMI:
Tuner/Reception/
Transmission
•
Antenna input: 75ohm coaxial (IEC75)
•
TV system: NTSC, PAL-M, PAL-N
•
Video playback: NTSC, SECAM, PAL
Remote control
•
Batteries: 2 x AAA (R03 type)
Connections
English
Resolution Refresh rate (Hz)
640x480
800x600
1024x768
128 0x768
128 0x1024
1360x768
VGA:
Resolution Refresh rate (Hz)
640x480
800x600
1024x768
128 0x768
128 0x1024
1360x768
Video formats
Resolution Refresh rate (Hz)
720 x 480p
720 x 480i
720 x 576p
720 x 576i
1280 x 720p
1280 x 720p
1920 x 1080i
1920x 1080p
60, 72, 75, 85
60, 72, 75, 85
60, 70, 75, 85
60
60
60
60, 72, 75, 85
60, 72, 75, 85
60, 70, 75, 85
60
60
60
60
60
50
50
60
50
50, 60
24, 25, 30, 50, 60
•
Headphone out (stereo mini-jack)
•
TV antenna
•
CVBS in
•
CVBS out
•
YPbPr: Component video (CVI in)
•
VGA in
•
HDMI
•
VGA Audio in
•
USB (for software update only)
•
Service connector
Power
•
Mains power: AC 110-240 (50-60Hz)
•
Standby power: < 0.3W
•
Ambient temperature: 5 to 35 degrees
Celsius
EN
21
Page 26
Supported TV mounts
To mount the TV, purchase a Philips TV mount
or a VESA-compatible TV mount. To prevent
damage to cables and connectors, be sure to
leave a clearance of at least 5.5 cm from the
back of the TV.
Warning
Follow all instructions provided with the TV
•
mount. Koninklijke Philips Electronics N.V.
bears no responsibility for improper TV
mounting that results in accident, injury or
damage.
TV
screen
size
VESA-compatible wall
bracket type
32”-37” 200 x 200 mm M6
42”-47” 400 x 400 mm M6 (42”),
M8 (47”)
22
EN
Page 27
9 Troubleshooting
This section describes commonly encountered
issues and accompanying solutions.
General TV issues
The TV does not switch on:
•
Disconnect the power cable from the
power outlet. Wait for one minute then
reconnect it.
•
Check that the power cable is securely
connected.
The remote control is not working properly:
•
Check that the remote control batteries
are correctly inserted according to the
+/- orientation.
•
Replace the remote control batteries if
they are at or weak.
•
Clean the remote control and TV sensor
lens.
The standby light on the TV blinks red:
•
Disconnect the power cable from the
power outlet. Wait until the TV cools
down before reconnecting the power
cable. If the blinking reoccurs, contact
Philips Consumer Care.
You forgot the code to unlock the child lock
feature
•
Enter ‘0711’.
The TV menu is in the wrong language
•
Change the TV menu to your preferred
language.
When turning the TV on/off/to standby, you
hear a creaking sound from the TV chassis:
No action is required. The creaking sound
•
is normal expansion and contraction of
the TV as it cools and warms up. This
does not impact performance.
TV channel issues
Previously installed channels do not appear in
the channel list:
•
Check that the correct channel list is
selected.
No digital channels were found during the
installation:
•
Check that the TV suppor ts DVB-T or
DVB-C in your country. See the listed
countries on the back of the TV.
Picture issues
The TV is on, but there is no picture:
•
Check that the antenna is properly
connected to the TV.
•
Check that the correct device is selected
as the TV source.
There is sound but no picture:
•
Check that the picture settings are
correctly set.
There is poor TV reception from an antenna
connection:
•
Check that the antenna is properly
connected to the TV.
•
Loud speakers, unearthed audio devices,
neon lights, high buildings and other large
objects can in uence reception quality.
If possible, try to improve the reception
quality by changing the antenna direction
or moving devices away from the TV.
•
If reception on only one channel is poor,
ne tune this channel.
There is poor picture quality from connected
devices:
•
Check that the devices are connected
properly.
•
Check that the picture settings are
correctly set.
The TV did not save your picture settings:
•
Check that the TV location is set to the
home setting. This mode offers you the
exibility to change and save settings.
English
EN
23
Page 28
The picture does not t the screen; it is too
big or too small:
•
Try using a different picture format.
The picture position is incorrect:
•
Picture signals from some devices may
not t the screen correctly. Check the
signal output of the device.
Sound issues
There is picture but no sound from the TV:
audio cable is connected to AUDIO L/R
or AUDIO IN (mini-jack only).
Computer connection issues
The computer display on the TV is not stable:
Check that a supported resolution and
•
refresh rate is selected on the computer.
Set the TV picture format to unscaled.
•
Note
If no audio signal is detected, the TV
•
automatically switches the audio output off
— this does not indicate malfunction.
•
Check that all cables are properly
connected.
•
Check that the volume is not set to 0.
•
Check that the sound is not muted.
There is picture but sound quality is poor:
•
Check that the sound settings are
correctly set.
There is picture but sound comes from one
speaker only:
•
Verify that sound balance is set to the
center.
HDMI connection issues
Contact us
If you cannot resolve your problem, refer to
the FAQs for this TV at www.philips.com/
support.
If the problem remains unresolved, contact
Philips Consumer Care in your country as
listed in this user manual.
Warning
Do not attempt to repair the TV yourself. This
•
may cause severe injury, irreparable damage to
your TV or void your warranty.
Note
Make a note of your TV model and serial
•
number before you contact Philips. These
numbers are printed on the back of the T V
and on the packaging.
There are problems with HDMI devices:
•
Note that HDCP support can delay the
time taken for a TV to display content
from a HDMI device.
•
If the TV does not recognize the HDMI
device and no picture is displayed, try
switching the source from one device to
another and back again.
•
If there are intermittent sound
disruptions, check that output settings
from the HDMI device are correct.
If a HDMI-to-DVI adaptor or HDMI to
•
DVI cable is used, check that an additional
24
EN
Page 29
10 Index
B
Batteries 4, 24
Bracket 22
Favorite list
select 12
set up 12
English
H
HDMI cable
troubleshooting 24
Home mode 15
C
Channel list
favorite 12
troubleshooting 23
update 12
Channels
favorite list 12
install
automatic 16
manual 16
rearrange 17
rename 16
Clock 14
Computer format
technical speci cations 21
Connections
HDMI
troubleshooting 24
mains cord 18
technical speci cations 21
troubleshooting 24
D
Demo 15
Display
resolution 21
E
EasyLink
disable 20
enable 20
Environmental care 4
F
Factory settings 15
I
Installation
automatic 16
manual 16
L
Language
troubleshooting 23
Location 15
M
Menu
language 23
main menu 9
troubleshooting 23
P
Picture format
troubleshooting 23
Picture settings 9
PIN code 23
Power 23
R
Reception 23
Remote control
overview 5
technical speci cations 21
troubleshooting 23
S
Sleep timer 13
Smart settings 9 , 11
EN
25
Page 30
Software
update
analog 15
version 15
Sound settings 11
Standby
troubleshooting 23
T
Technical specifcations 21
Timer
on timer 13
sleeptimer 13
standby 13
Transmission
troubleshooting 23
Troubleshooting 23
TV
adjust volume 8
menu 9
software 14
standby 7
switch channels 7
switch off 7
switch on 7
troubleshooting 23
tuner technical speci cations 21
wall mount 22
TV lock
lock channels 14
lock connected devices 14
PIN code 23
V
Video format
video format technical speci cations 21
Volume
adjust 8
26
EN
Page 31
Page 32
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: 72-CLICK0-X771A
Loading...
