Philips 32BDL4511D/00 leaflet

Download

Page 1

Philips Signage Solutions D-Line Display

Say more

32"

Full HD (1920 x 1080p) 400 cd/m²

32BDL4511D

Smart, fast, 24/7 display.

Make it stand out with a fast Philips D-Line Professional FHD display. Philips superb picture quality ensures true colours and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Operational flexibility

• SmartPower for energy saving

Brilliant picture. Blazing processor speed.

• Full HD. Clear images. Crisp contrast

• Place in landscape or portrait orientation

• ADS wide-view panel display

Effortless setup. Total control.

• Operate, monitor and maintain with CMND and Control

• Schedule what you want, when you want with SmartPlayer

Cost-effective system solution

• Energy-saving automatic backlight control

• FailOver ensures that content is always playing

Page 2

32BDL4511D/00

D-Line Display

32" Full HD (1920 x 1080p), 400 cd/m²

Specifications

Picture/Display

• Diagonal screen size: 32 inch / 81.28 cm

• Panel resolution: 1920 x 1080p

• Optimum resolution: 1920 x 1080 @ 60 Hz

• Brightness: 400 cd/m²

• Dynamic contrast ratio: 500,000:1

• Response time (typical): 8 ms

• Aspect ratio: 16:9

• Viewing Angle (H / V): 178 / 178 degree

• Pixel pitch: 0.36375 x 0.36375 mm

• Display colours: 16.7 million

• Panel technology: ADS

• Contrast ratio (typical): 1200:1

•Haze: 25%

Supported Display Resolution

• Computer formats Resolution Refresh rate 640 x 480 60 Hz 800 x 600 60 Hz 1024 x 768 60 Hz 1280 x 720 60 Hz 1280 x 1024 60 Hz 1440 x 900 60 Hz 1600 x 900 60 Hz 1680 x 1050 60 Hz 1920 x 1080 60 Hz

deo formats

• Vi Resolution Refresh rate 480i 60 Hz 480p 60 Hz 576p 50 Hz 576i 50 Hz 720p 50,60 Hz 1080i 50, 60 Hz 1080p 50, 60 Hz

Connectivity

• Video input: Display Port1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2)

• Audio input: 3.5 mm jack

• Video output: DisplayPort 1.2 (x 1), HDMI 2.0 (x 1)

• Audio output: 3.5 mm jack

• External control: IR (in/out) 3.5 mm jack, RJ45,

32C (in/out) 2.5 mm jack

RS2

Convenience

• Placement: Landscape (24/7), Portrait (24/7)

• Screen-saving functions: Pixel Shift, Low Bright

• Signal loop through: DisplayPort, RS232, HDMI, IR

oop through

• Energy-saving functions: Smart Power

• Network controllable: RS232, RJ45

• Keyboard control: Hidden, Lockable

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Altitude: 0 ~ 3000 m

• MTBF: 50,000 hour(s)

• Humidity range (operation)[RH]: 20–80% RH (No ndensation)

• Humidity range (storage) [RH]: 5–95% RH (No ndensation)

Power

• Consumption (Typical): 36 W

• Consumption (Max): 60 W

• Standby power consumption: 0.5 W

• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz

• Energy Label Class: G

Sound

• Built-in speakers: 2 x 10 W RMS

Accessories

• Stand: BM05911 (Optional)

• Included Accessories: Philips logo (x 1), AC power

ord, AC Switch Cover, IR sensor cable (1.8 m)

c (x 1), Quick start guide (x 1), Remote control and

atteries, RS232 cable, RS232 daisy-chain

AAA b cable, USB Cover and screw x 1, Wire Clamper (x 3)

Miscellaneous

• On-Screen Display Languages: Arabic, Dutch,

Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese

• Regulatory approvals: CE, FCC, Class A, CCC,

oHS, CB, BSMI, EMF, VCCI, PSB, ETL, CECP,

R EAC

•Warranty: 3 year warranty

Multimedia Applications

• USB Playback Video: H.263, H.264, H.265, MPEG

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Audio: AAC, MPEG, HEAAC

Dimensions

•Set dimensions (W x H x D):

726.5 x 425.4 x 65.1 (@Wall mount)/ .1 (@AC) mm

• Set dimensions in inch (W x H x D): .60 x 16.75 x 2.56 inch (@Wall mount) /

2.72 (@AC)) inch

•Bezel width: 11.9 mm (T/R/L), 17.2 mm (B)

• VESA Mount: 100 (H) x 100 (V) mm / 0 (H) x 200

• Product weight: 5.7 kg

• Product weight (lb): 12.57 lb

•

(V) mm, M4

Highlights

ADS wide-view panel display

Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy and superior colour reproduction with 180 degree viewing.

CMND and Control

Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

SmartPower

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

SmartPlayer

Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

Issue date 2022-04-21

Version: 1.0.1

12 NC: 8670 001 78308 EAN: 87 12581 77863 7

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com
