Philips 32BDL4510D/00 leaflet

Download

Page 1

Philips Signage Solutions D-Line Display

Say more

32"

Full HD (1920x1080p) 400cd/m²

32BDL4510D

Smart, fast 24/7 display.

Make it stand out with a fast Philips D-Line Professional FHD display. Philips superb picture quality ensures true colors and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Brilliant picture. Blazing processor speed.

• Full HD. Clear images. Crisp contrast

• Place in landscape or portrait orientation

• ADS wide-view panel display

Operational flexibility

• SmartPower for energy saving

Effortless setup. Total control.

• Schedule what you want, when you want with SmartPlayer

• Operate, monitor and maintain with CMND & Control

Cost-effective system solution

• FailOver ensures content is always playing

• Energy-saving automatic backlight control

Page 2

32BDL4510D/00

D-Line Display

32" Full HD (1920x1080p), 400cd/m²

Highlights

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

SmartPower

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

SmartPlayer

Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display.Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere.

ADS wide-view panel display

Be seen from any angle with ADS wide-view t

echnology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy, and superior colour reproduction with 180 degree viewing.

Page 3

32BDL4510D/00

D-Line Display

32" Full HD (1920x1080p), 400cd/m²

Specifications

Picture/Display

• Diagonal screen size: 32 inch / 81.28 cm

• Panel resolution: 1920x1080p

• Optimum resolution: 1920 x 1080 @ 60Hz

• Brightness: 400 cd/m²

• Contrast ratio (typical): 1200:1

• Dynamic contrast ratio: 500,000:1

• Aspect ratio: 16:9

• Response time (typical): 8 ms

• Pixel pitch: 0.36375 x 0.36375 mm

• Display colors: 16.7 million

• Viewing angle (H / V): 178 / 178 degree

• Picture enhancement: 3/2 - 2/2 motion pull down, mbfi

3D Co MA deinterlacing, Dynamic contrast enhancement, Progressive scan

• Panel technology: ADS

lter, Motion compens. deinterlacing, 3D

Connectivity

• Video input: Display Port1.2 (x1), DVI-I (x 1),

HDMI 2.0 (x2), USB 2.0 (x2)

• Video output: DisplayPort 1.2 (x1), HDMI 2.0 (x1)

• Audio input: 3.5 mm jack

• Audio output: 3.5mm jack

• External control: RJ45, RS232C (in/out) 2.5 mm

k, IR (in/out) 3.5 mm jack

Supported Display Resolution

mputer formats

• Co

Res

olution Refresh rate 1024 x 768 60Hz 1280 x 1024 60Hz 1280 x 720 60Hz 1440 x 900 16

00 x 900 60Hz 1680 x 1050 60Hz 1920 x 1080 60Hz 640 x 480 60Hz 800 x 600 60Hz

deo formats

• Vi olution Refresh rate

Res 1080p 50, 60Hz 1080i 50, 60Hz 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz 720p 50,60 Hz

60 Hz

Dimensions

•Set dimensions (W x H x D):

726.5 x 425.4 x 65.1(@Wall mount)/ (@AC) mm

69.1

• Set dimensions in inch (W x H x D): 0 x 16.75 x 2.56 inch (@Wall mount) /2.72

28.6 inch

(@AC))

• Bezel width: 11.9 mm (T/L/R), 17.2 mm (B) Product weight (lb): 12.57 lb

•

• Product weight: 5.7 kg

• VESA Mount: 100(H) x 100(V) mm / 200(H) x

0(V) m

m, M4

Convenience

• Placement: Landscape (24/7), Portrait (24/7)

• Keyboard control: Hidden, Lockable

• Signal loop through: RS232, IR Loopthrough, DisplayPort, HDMI Network controllable: RS232, RJ45

•

• Energy saving functions: Smart Power Screen saving functions: Pixel Shift, Low Bright

•

Power

• Standby power consumption: 0.5 W

• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz

• Consumption (Typical): 40 W

• Consumption (Max): 75 W

• Energy Label Class: G

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Altitude: 0 ~ 3000 m

• MTBF: 50,000 hour(s)

• Humidity range (operation)[RH]: 20 - 80% RH (No

nden

sation)

• Humidity range (storage) [RH]: 20 - 80% RH (No

sation)

conden

Sound

• Built-in speakers: 2 x 10W RMS

Accessories

• Included accessories: Quick start guide, RS232 cable, AC Power Cord, HDMI cable, Remote Control & AAA Batteries

• Stand: BM05911(Optional)

• Included Accessories: RS232 daisy-chain cable, Philips lo

(x1), Screws, USB Cover (x1)

Multimedia Applications

• USB Playback Audio: AAC, HEAAC, MPEG

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Video: H.263, H.264, H.2 VP8

65, MPEG,

Miscellaneous

• On-Screen Display Languages: English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish

• Regulatory approvals: CE, CCC, RoHS, BSMI, CB,

CCI

, CU, EMF, EnergyStar 8.0, ETL, FCC, Class

V A, PSB

• Warranty: 3 year warranty

•

Issue date 2022-02-16

Version: 4.1.1

12 NC: 8670 001 68841 EAN: 87 12581 76881 2

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com
