Philips 32BDL3651T/00 leaflet

Download

Page 1

Philips Signage Solutions Multi-Touch Display

Engage them

32"

32BDL3651T

10-point Multi-Touch display.

Inspire collaboration. Deliver information. This responsive Philips Multi-Touch Professional Full HD Display is ideal for multi-finger, multi-user applications, from wayfinding to presentations. Up to 10 touch points can be active at once.

Superb picture. Responsive touchscreen.

• Full HD. Clear images. Crisp contrast

• Plug-and-play 10-point Multi-Touch display

• Android SoC processor. Native and web apps

Effortless setup. Total control.

• CMND & Deploy. Install and launch apps remotely

• Operate, monitor and maintain with CMND and Control

• CMND and Create. Develop and launch your own content

Versatile system solution

• Energy-saving automatic backlight control

• FailOver ensures that content is always playing

• Internal memory. Upload content for instant play

• Simplified user interaction with kiosk mode

Page 2

32BDL3651T/00

Multi-Touch Display

32" Powered by Android, Multi-touch

Highlights

CMND & Deploy

Quickly install and launch any app - even when yo

u're off site and working remotely. CMND & Deploy lets you add and update your own apps, as well as apps from the Philips Professional Display App Store. Simply scan the QR code, log in to the store and click on the app you want to install. The app will be automatically downloaded and launched.

CMND and Control

Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

CMND and Create

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the

primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

Internal memory

Save and play content without the need for a p

ermanent external player. Your Philips professional display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.

Control your display via an Internet connec

tion. Android-powered Philips Professional Displays are optimised for native Android apps and you can install web apps directly to the display too. A new Android 8 OS ensures the software is kept secure and stays up to date with the latest specification for longer.

Page 3

32BDL3651T/00

Multi-Touch Display

32" Powered by Android, Multi-touch

Specifications

Picture/Display

• Diagonal screen size: 32 inch / 80 cm

• Panel resolution: 1920 x 1080p

• Optimum resolution: 1920 x 1080 @ 60 Hz

• Brightness: 350 cd/m²

• Contrast ratio (typical): 4000:1

• Surface treatment: Anti-Glare coating

• Aspect ratio: 16:9

• Response time (ty

• Pixel pitch: 0.36375 (H) X 0.36375 (V) mm

• Display colours: 16.7 M

• Viewing Angle (H / V): 178 / 178 degree

• Panel technology: VA

• Operating system: Android 8.0

• Picture enhancement: 3/2 - 2/2 motion pull down, mbfi

3D Co contrast enhancement, Motion compens. deinterlacing, Progressive scan

ical): 6.5 ms

lter, 3D MA deinterlacing, Dynamic

Interactivity

• Multi-touch technology: Projected capacitive

• Touch points: 10 simultaneous touch points

• Plug and play: HID compliant

• Protection glass: 2 mm tempered safety glass

Connectivity

• Video input: DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0

Type A (x 2), USB 2.0 Type B (x 1), VGA (via DVII) x 1

• Audio input: 3.5 mm jack

• Audio output: 3.5 mm jack

• External control: RJ45, IR (in/out) 3.5 mm jack,

32C (in/

RS2

• Other connections: micro SD

out) 2.5 mm jack

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 640 x 480 60, 67, 72, 75 Hz 800 x 600 56, 60, 72, 75 Hz 1024 x 768 60 Hz 1280 x 768 60 Hz 1280 x 800 60 Hz 1280 x 1024 60 Hz 1360 x 768 60 Hz 1366 x 768 60 Hz 1440 x 900 60 Hz 1600 x 1200 60 Hz 1920 x 1080 60 Hz 1920 x 1200 60 Hz 720 x 400 70 Hz 800 x 600 60, 72, 75 Hz 3840 x 2160 60 Hz, 50 Hz

deo formats

• Vi

olution Refresh rate

Res 480i 60 Hz 480p 60 Hz 576p 50 Hz 576i 50 Hz 720p 50, 60 Hz 1080i 50, 60 Hz 1080p 50 1080i 25, 30 Hz 480i 30, 60 Hz

, 60 Hz

576i 25, 50 Hz 3840 x 2160 24, 25 Hz 3840 x 2160 30Hz

Convenience

• Placement: Landscape (18/7), Portrait (18/7)

• Signal loop through: IR Loop through, RS232

• Network controllable: RS232, RJ45

• Screen-saving functions: Pixel Shift, Low Brightness

• Keyboard control: Hidden, Lockable

• Remote control signal: Lockable

• Energy-saving functions: Smart Power

Dimensions

•Set dimensions (W x H x D): 749.1 x 443.6 x 70.4 (D@Wall mount)/74.4 (D@AC) mm

• Set dimensions in inch (W x H x D):

9 x 17.46 x 2.77 D@Wall mount)/2.93

29.4

C) inch

(D@A

• Product weight: 8.0 kg

• Product weight (lb): 17.64 lb

• VESA Mount: 100 mm x 100 mm, 200 mm x

0 mm, M4

•B

ezel width: 2.0 mm (T/R/L/B)

Sound

• Built-in speakers: 2 x 10 W

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• MTBF: 50,000 hour(s)

• Altitude: 0 ~ 3000 m

• Temperature range (storage): -20~60 °C

• Humidity range (operation)[RH]: 20–80% (without

nden

sation)

• Humidity range (storage) [RH]: 5–95% (without

sation)

conden

Power

• Mains power: 100 ~ 240 VAC, 50/60 Hz

• Standby power consumption: <0.5 W

• Consumption (Typical): 50 W

• Power Saving Features: Smart Power

• Consumption (Max): 80 W

• Energy Label Class: G

Accessories

• Stand: BM05922 (Optional)

• Included Accessories: Cleaning cloth (x 1), IR

or cable (1.8 m) (x 1), Philips logo (x 1), Power

sens

ly cable (3 m), Quick start guide (x 1), Remote

supp

l and AAA batteries, RS232 cable (3 m)

contro (x 1), RS232 daisy chain cable (x 1), USB Cover and

screw x

Miscellaneous

• On-Screen Display Languages: Arabic, English, French, German, Italian, Japanese, Polish, Spanish, Turkish, Russian, Simplified Chinese, Traditional Chinese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish

• Regulatory approvals: CB, CE, FCC, Class A,

HS, BSMI, CU, ETL, IMDA, PSB

•Warranty: 3 year warranty

Multimedia Applications

• USB Playback Picture: BMP, GIF, JPEG, JPG, PDF

• USB Playback Audio: AAC, AIF, AIFF M3U, M4A, MP3, MP4, WAV, WMA

• USB Playback Video: M2TS, M4V, MK3D, MKV, MP4, MPEG, MPG, MTS, TS, TTS, VOB,

, ASF, LPCM,

WMV

Internal Player

•CPU: 2 x A53 + 2 x A73

•Memory: 2 GB DDR3, 8 GB

• GPU: ARM Mali G51

• Wi-Fi: 2.4 G, 5 G

•

Issue date 2021-08-23

Version: 1.0.1

12 NC: 8670 001 72681 EAN: 87 12581 77394 6

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
