Page 1

Philips Signage Solutions Q-Line Display

Intensify your signage experience

32"

Direct LED Backlight Full HD

32BDL3511Q

Easy-setup 18/7 display.

Inform and enthral with a Philips Q-Line Professional Full HD Display. This reliable solution can be up and running as quickly as you need.

Effortless setup. Total control.

• Operate, monitor and maintain with CMND and Control

• Schedule what you want, when you want with SmartPlayer

Cost-effective system solution

• Energy-saving automatic backlight control

• Integrated media player. Easily schedule USB content

• FailOver ensures that content is always playing

• Easy control. Remotely manage networked displays

Page 2

32BDL3511Q/00

Q-Line Display

32" Direct LED Backlight, Full HD

Highlights

CMND and Control

Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

Integrated media player

Easily schedule content to play from USB. Your Phili

ps Professional Display will wake from

standby to play the content you want, and then return to standby once playback has finished.

SmartPlayer

Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

Page 3

32BDL3511Q/00

Q-Line Display

32" Direct LED Backlight, Full HD

Specifications

Picture/Display

• Diagonal screen size: 31.5 inch / 80 cm

• Panel resolution: 1920 x 1080p

• Optimum resolution: 1920 x 1080 @ 60 Hz

• Brightness: 350 cd/m²

• Dynamic contrast ratio: 500,000:1

• Response time (ty

• Aspect ratio: 16:9

• Viewing Angle (H / V): 178 / 178 degree

• Pixel pitch: 0.36375 x 0.36375 mm

• Display colours: 16.7 Million

• Panel technology: VA

• Contrast ratio (typical): 4000:1

• Clinical image: D-Image preset (dicom part 14 mpatible)

•Haze: 2%

ical): 6.5 ms

Supported Display Resolution

• Computer formats

Resolution Refresh rate 640 x 480 60, 67, 72, 75 Hz 720 x 400 70 Hz 800 x 600 56, 60, 72, 75 Hz 832 x 624 75 Hz 1024 x 768 60, 70, 75 Hz 1152 x 864 75 Hz 1152 x 870 75 Hz 1280 x 720 60 Hz 1280 x 800 60 Hz 1280 x 1024 60 Hz 1440 x 900 60 Hz 1600 x 1200 60 Hz 1680 x 1050 60 Hz 1920 x 1080 60 Hz

deo formats

• Vi

Res

olution Refresh rate 480i 60 Hz 480p 60 Hz 576p 50 Hz 576i 50 Hz 720p 60 Hz 1080i 50, 60 Hz 1080p 50, 60 Hz

Connectivity

• Video input: DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2)

• Audio input: 3.5 mm jack

• Audio output: 3.5 mm jack

• External control: IR (in/out) 3.5 mm jack, RJ45,

32C (in/

RS2

out) 2.5 mm jack

Convenience

• Placement: Landscape (18/7), Portrait (18/7)

• Tiled Matrix: Up to 10 x 15

• Signal loop through: RS232, IR Loop through

•

Energy-saving functions: Smart Power

• Network controllable: RS232, RJ45

• Keyboard control: Hidden, Lockable

• Remote control signal: Lockable

atus, Boot

• Start-up: Switch on delay, Swit on source

• Start-up window: enable/d

ch on st

isable Philips logo

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Altitude: 0 ~ 3000 m

• MTBF: 50,000 hour(s)

• Humidity range (operation)[RH]: 20~80% RH (No

nden

sation)

• Humidity range (storage) [RH]: 5~95% RH (No

sation)

conden

Power

• Consumption (Typical): 45 W

•Consumption (Max): 65 W

• Standby power consumption: <0.5 W

• Mains power: 100–240 V~, 50/60 Hz

• Power Saving Features: Smart Power

• Energy Label Class: G

Sound

• Built-in speakers: 2 x 10 W RMS

Accessories

• Stand: BM02541/BM05911 (optional)

• Included Accessories: AC Switch Cover, IR sensor

e (1.8 m) (x 1), Philips logo (x 1), Quick start

cabl guide (x 1), Remote control and AAA batteries, RS232 da sc

isy chain cable (x 1), USB Cover and

rew x 1, Wire Clamper (x 3), AC power cord

Miscellaneous

• On-Screen Display Languages: Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese

• Regulatory approvals: CE, FCC, Class A, CB, EMF,

CCI

, PSB, CU, ETL

•Warranty: 3 year warranty

Multimedia Applications

• USB Playback Video: H.264, JPEG, MPEG, WMV3

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Audio: AAC, WMA, MPEG, HEAAC

Dimensions

•Set dimensions (W x H x D):

• Set dimensions in inch (W x H x D):

•Bezel width: 11.9 (TLR)/17.2 (B) mm

• VESA Mount: 100 mm x 100 mm, 200 mm x

•

• Product weight (lb): 12.57 lb

•

425.4 x 69.1(D@Handle)/65.1(D@Wall

726.5 x mount) mm

x 16.75 x 2.72 (D@Handle)/2.56 (D@Wall

28.6

) inch

mount

0 mm, M4

20 Product weight: 5.7 kg

Issue date 2022-04-21

Version: 1.0.1

12 NC: 8670 001 78301 EAN: 87 12581 77856 9

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
