Philips 32BDL3510Q/00 leaflet

Download

Page 1

Philips Signage Solutions Q-Line Display

Intensify your signage experience

32"

Direct LED Backlight Full HD

32BDL3510Q

Easy-setup 18/7 display.

Inform and enthrall with a Philips Q-Line Professional Fulll HD Display. This reliable solution can be up and running as quickly as you need.

Effortless setup. Total control.

• Operate, monitor and maintain with CMND & Control

• Schedule what you want, when you want with SmartPlayer

Cost-effective system solution

• Energy-saving automatic backlight control

• Integrated media player. Easily schedule USB content

• Easy control. Remotely manage networked displays

• FailOver ensures content is always playing

Page 2

32BDL3510Q/00

Q-Line Display

32" Direct LED Backlight, Full HD

Highlights

CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

Integrated media player

Easily schedule content to play from USB. Your Phili

ps Professional Display will wake from

standby to play the content you want, and then return to standby once playback is done.

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of

alternate inputs to be sure your business is always on.

SmartPlayer

Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display.Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere.

Page 3

32BDL3510Q/00

Q-Line Display

32" Direct LED Backlight, Full HD

Specifications

Picture/Display

• Diagonal screen size: 31.5 inch / 80 cm

• Panel resolution: 1920x1080p

• Optimum resolution: 1920 x 1080 @ 60 Hz

• Brightness: 350 cd/m²

• Contrast ratio (typical): 4000:1

• Dynamic contrast ratio: 500,000:1

• Response time (ty

• Aspect ratio: 16:9

• Viewing angle (H / V): 178 / 178 degree

• Pixel pitch: 0.36375 x 0.36375 mm

• Display colors: 16.7 Million

• Panel technology: VA

• Picture enhancement: 3/2 - 2/2 motion pull down, mbfi

3D Co contrast enhancement, Motion compens. deinterlacing, Progressive scan

• Clinical image: D-Image preset (dicom part 14

mpatible)

ical): 6.5 ms

lter, 3D MA deinterlacing, Dynamic

Supported Display Resolution

mputer formats

• Co

olution Refresh rate

Res 1920 x 1080 60Hz 1680 x 1050 60Hz 1600 x 1200 60Hz 1440 x 900 60Hz 1280 x 1024

80 x 800 60Hz

12 1280 x 720 60Hz 1152 x 870 75Hz 1024 x 768 60, 70, 75Hz 800 x 600 56, 60, 72, 75Hz 720 x 400 70Hz 640 x 480 60, 67, 72, 75Hz 1152 x 864 75Hz 832 x 624 75Hz

deo formats

• Vi

Res

olution Refresh rate 720p 60Hz 576p 50Hz 576i 50Hz 480p 60Hz 480i 60Hz 1080i 50, 60Hz 1080p 50, 60Hz

60Hz

Connectivity

• Video input: DVI-I (x 1), HDMI 2.0 (x2), USB 2.0

(x2)

• Audio input: 3.5 mm jack

• Audio output: 3.5mm jack

• External control: RJ45, RS232C (in/out) 2.5 mm , I

R (in/out) 3.5 mm jack

jack

Convenience

• Energy saving functions: Smart Power

• Tiled Matrix: Up to 15 x 15

• Start-up: Switch on delay, Switch on st

on source

• Start-up window: enable / disable Philips logo

• Keyboard control: Lockable, Hidden

• Network controllable: RS232, RJ45

• Signal loop through: RS232, IR Loopthrough

• Placement: Landscape, Portrait

• Remote control signal: Lockable

atus, Boot

Dimensions

• Bezel width: 11.9 (TLR) / 17.2 (B) mm

•Set dimensions (W x H x D):

x 425.4 x 69.1(D@Handle) / 65.1(D@Wall

726.5 ) mm

mount

• Set dimensions in inch (W x H x D): x 16.75 x 2.72 (D@Handle) / 2.56 (D@Wall

28.6 ) inch

mount

• VESA Mount: 100mm x100mm, 200mm x 200mm ,M4

• Product weight: 5.31 kg

• Product weight (lb): 11.71 lb

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• MTBF: 50,000 hour(s)

• Altitude: 0 ~ 3000 m

• Humidity range (operation)[RH]: 20 ~ 80% RH (No condensati

•

Humidity range (storage) [RH]: 5 ~ 95% RH (No conden

on)

sation)

Power

• Mains power: 100 - 240V~, 50-60Hz, 1.5A

• Standby power consumption: <0.5 W

• Consumption (Max): 65 W

• Consumption (Typical): 40 W

• Power Saving Features: Smart Power

• Energy Label Class: G

Sound

• Built-in speakers: 2 x 10W RMS

Multimedia Applications

• USB Playback Video: MPEG, H.264, JPEG, WMV3

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Audio: AAC, WMA, HEAAC, MPEG

Accessories

• Included accessories: AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide

• Included Accessories: IR sensor cable (1.8 m) (x1),

32 da

RS2 Cover and screw (x2)

• Stand: BM02541/BM05911(optional)

isy-chain cable, USB Cover (x1), USB

Miscellaneous

• Warranty: 3 year warranty

• On-Screen Display Languages: English, French,

erman, Italian, Polish, Turkish, Russian, Simplified

G Chinese, Spanish, Traditional Chinese, Arabic, Japanese

• Regulatory approvals: CB, CE, BSMI, CU, EPA,

FCC, Class A, VCCI

•

Issue date 2021-05-26

Version: 3.0.1

12 NC: 8670 001 66069 EAN: 87 12581 76511 8

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
