Page 1
Philips
Full HD Curved LCD
display
E Line
32 (31.5"/80 cm diag.)
1920 x 1080 (Full HD)
322E1C
Simply immersive
The 32" curved E-Line display offers a truly immersive experience in a stylish design.
Experience crisp Full HD visuals and smooth action with AMD FreeSync technology.
Curved design inspired by the world around us
• Curved display design for a more immersive experience
Superb Picture Quality
• VA display delivers awesome images with wide viewing angles
• 16:9 Full HD display for crisp, detailed images
• Effortlessly smooth gameplay with AMD FreeSync™ technology
• SmartContrast for rich black details
• SmartImage game mode optimised for gamers
Features designed for you
• Cable management reduces cable clutter for a neat workspace
• Less eye fatigue with Flicker-Free technology
• LowBlue Mode for easy-on-the-eyes productivity
• HDMI ensures universal digital connectivity
• DisplayPort connection for maximum visuals
Page 2
322E1C/89
Full HD Curved LCD display
E Line 32 (31.5"/80 cm diag.), 1920 x 1080 (Full HD)
Highlights
Curved display design
Desktop monitors offer a personal user
experience, which suits a curved design very
well. The curved screen provides a pleasant yet
subtle immersion effect, which focuses on you
at the centre of your desk.
VA display
with high brightness, incredible contrast and
realistic colours, expect a true-to-life picture.
Ultra-smooth gaming
Gaming shouldn't be a choice between choppy
gameplay or broken frames. With the new
Philips monitor it doesn't have to be. Get fluid,
artefact-free performance at virtually any
frame rate with AMD FreeSync™ technology,
smooth, quick refresh and ultra-fast response
time.
SmartImage Game mode
Concealed cables
For a cleaner workspace, this monitor features
an elegant solution for cable management. No
need to bundle cables with extra ties. An
elongated slot provides hidden storage for
cables. It conceals cables and looks great in
most environments, especially for a small space
or a desk facing a wall or a window. This design
cleans up messy cables for a more organised
desk.
Flicker-Free technology
The Philips VA LED display uses an advanced
multi-domain vertical alignment technology
that gives you super-high static contrast ratios
for extra-vivid and bright images. While
standard office applications are handled with
ease, it is especially suitable for photos, web
browsing, films, gaming and demanding
graphical applications. Its optimised pixel
management technology gives you a 178/178
degree extra-wide viewing angle, resulting in
crisp images.
16:9 Full HD display
Picture quality matters. Regular displays deliver
quality, but you expect more. This display
features enhanced Full HD 1920 x 1080
resolution. With Full HD for crisp detail paired
The new Philips gaming display has quickaccess OSD fine-tuned for gamers, offering you
multiple options. "FPS" mode (First person
shooting) improves dark themes in games,
allowing you to see hidden objects in dark
areas. "Racing" mode adapts the display with
the fastest response time and high colour,
along with image adjustments. "RTS" mode
(Real-time strategy) has a special SmartFrame
mode that enables highlighting of specific area
and allows for size and image adjustments.
Gamer 1 and Gamer 2 enable you to save
personal customised settings based on
different games, ensuring best performance.
Due to the way brightness is controlled on
LED-backlit screens, some users experience
flicker on their screen which causes eye
fatigue. Philips Flicker-Free technology applies
a new solution to regulate brightness and
reduce flicker for more comfortable viewing.
LowBlue Mode
Studies have shown that just as ultra-violet rays
can cause eye damage, shortwave-length blue
light rays from LED displays can cause eye
damage and affect vision over time. Developed
for wellbeing, the Philips LowBlue Mode
setting uses a smart software technology to
reduce harmful shortwave blue light.
Page 3
322E1C/89
Full HD Curved LCD display
E Line 32 (31.5"/80 cm diag.), 1920 x 1080 (Full HD)
Specifications
Picture/Display
• AMD FreeSync™ technology
• LCD panel type: VA LCD
• Backlight type: W-LED system
•Panel Size: 31.5 inch/80 cm
• Display Screen Coating: Anti-Glare, 3H, Haze 25%
• Effective viewing area: 698.4 (H) x 392.85 (V) mm
500R curvature*
- at a 1
• Aspect ratio: 16:9
• Maximum resolution: 1920 x 1080 @ 75 Hz*
• Pixel Density: 70 PPI
• Response time (typical): 4 ms (Grey to Grey)*
• Brightness: 250 cd/m²
• Contrast ratio (typical): 3000:1
• SmartContrast: Mega Infinity DCR
• Pixel pitch: 0.364 x 0.364 mm
• Viewing angle: 178º (H)/178º (V),
• Picture enhancement: SmartImage game
• Colour gamut (typical): NTSC 85%*, sRGB 104%*
• Display colours: 16.7 M
• Scanning Frequency: 53–84 kHz (H)/48–75 Hz (V)
•sRGB
• Flicker-free
•LowBlue Mode
@ C/R > 10
Connectivity
• Signal Input: VGA (Analogue), HDMI 1.4,
DisplayPort 1.2
• Sync Input: Separate Sync, Sync on Green
• Audio (In/Out): Audio out
Convenience
• User convenience: Power On/Off, Menu,
Brightness, Input, SmartImage Game
• OSD Languages: Brazil Portuguese, Czech, Dutch,
glish, Finnish, French, German, Greek,
En
Hungarian, Italian, Japanese, Korean, Polish,
Portuguese, Russian, Simplified Chinese, Spanish,
Swedish, Traditional Chinese, Turkish, Ukrainian
• Other convenience: Kensington lock, VESA mount
(100 x 100 mm)
• Plug and Play Compatibility: DDC/CI, Mac OS X,
RGB, Windows 10 / 8.1 / 8 / 7
s
Stand
• Tilt: -5/20 degree
Power
• On mode: 40.6 W (typ.)
• Standby mode: < 0.5 W (typ.)
• Off mode: < 0.3 W (typ.)
• Power LED indicator: Operation - White, Standby
mode - White (f
• Power supply: Internal, 100–240 VAC, 50–60 Hz
lashing)
Dimensions
• Product with stand (mm): 709 x 523 x 281 mm
• Product without stand (mm): 709 x 425 x 88 mm
• Packaging in mm (W x H x D): 800 x 625 x 236 mm
Weight
• Product with stand (kg): 7.10 kg
• Product without stand (kg): 6.28 kg
• Product with packaging (kg): 10.01 kg
Operating conditions
• Temperature range (operation): 0 to 40 °C
• Temperature range (storage): -20 to 60 °C
• Relative humidity: 20%-80 %
• Altitude: Operation: +12,000 ft (3658 m), Non-
eration: +40,000 ft (12,192 m)
op
• MTBF: 50,000 hrs (excluding backlight) hour(s)
Sustainability
• Environmental and energy: RoHS, Mercury Free
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: CE Mark, CU-EAC, CB,
UKRAINIAN, TUV-BAUART
Cabinet
• Colour: Black
• Finish: Textured
•
Issue date 2022-02-09
Version: 2.0.1
12 NC: 8670 001 74123
EAN: 87 12581 77571 1
© 2022 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* Radius of the arc of the display curvature in mm
* Response time value equal to SmartResponse
* The maximum resolution works for either HDMI input or DP input.
* NTSC Area based on CIE 1976
* sRGB Area based on CIE1931
* 2020 Advanced Micro Devices, Inc. All rights reserved. AMD, the
AMD Arrow logo, AMD FreeSync™ and combinations thereof are
trademarks of Advanced Micro Devices, Inc. Other product names
used in this publication are for identification purposes only and may
be trademarks of their respective companies.
* The monitor may look different from feature images.
