Page 1
Philips
LED monitor with
PowerSensor
E-line
23.6" / 59.9 cm
247E3LPHSU
Elegant display with PowerSensor
saves energy bills
Experience awesome LED pictures with natural colors. The elegant design with
translucent blue bezel, HDMI and Innovative PowerSensor that detects your presence,
saving up to 80% of your energy bill, makes it a smart green choice.
Great picture quality
• LED technology for natural colors
• SmartResponse of 2ms
• SmartContrast 20000000:1 for incredible rich black details
• SmartImage Lite for an enhanced LCD viewing experience
• 16:9 Full HD display for best viewing experience
Design that complements any interior
• Sleek, elegant design complements your home decor
• Translucent blue bezel with glossy finish
• Modern Touch controls
Experience true multimedia
• HDMI-ready for top quality, multimedia experience
Greener everyday
• PowerSensor ensures lower operating costs by saving energy
Page 2
LED monitor with PowerSensor
PowerSensor
®
E-line 23.6" / 59.9 cm
Highlights
247E3LPHSU/00
PowerSensor
PowerSensor is a built-in 'people sensor' that
transmits and receives harmless infrared
signals to determine if user is present and
automatically reduces monitor brightness
when user steps away from the desk, cutting
energy costs by up to 80 percent and
prolonging monitor life.
LED technology
White LED's are solid state devices which light
up
to full, consistent brightness faster saving
startup time. LED's are free from mercury
content which allows for eco-friendly recycling
and disposal process. LED's allow for better
dimming control of LCD backlight, resulting in
super high contrast ratio. It also gives superior
color reproduction thanks to consistent
brightness across the screen.
SmartImage Lite
SmartImage Lite is an exclusive, leading edge
Phili
ps technology that analyzes the content
displayed on your screen. Based on a scenario
you select, SmartImage Lite dynamically
enhances the contrast, color saturation and
sharpness of images and videos for ultimate
display performance - all in real time with the
press on a single button.
16:9 Full HD
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.
HDMI Ready
A HDMI-ready device has all the required
hardware to accept High-Definition
Multimedia Interface (HDMI) input, high quality
digital video and audio signals all transmitted
over a single cable from a PC or any number of
AV sources including set-top boxes, DVD
players and A/V receivers and video cameras.
SmartResponse - 2ms
SmartResponse is a exclusive Philips overdrive
technology that when turned on, automatically
adjusts response times to specific application
requirements like gaming and movies which
require faster response times in order to
produce judder, time-lag and ghost image free
images
SmartContrast ratio 20000000:1
You want the LCD flat display with the highest
contrast and most vibrant images. Philips
advanced video processing combined with
unique extreme dimming and backlight
boosting technology results in vibrant images.
SmartContrast will increase the contrast with
excellent blacklevel and accurate rendition of
dark shades and colors. It gives a bright, lifelike
picture with high contrast and vibrant colors.
Touch controls
Touch controls are intelligent, touch sensitive
i
cons that replace protruding buttons that lets
the user adjust the monitor to their
requirement. Responding to your lightest
touch,Touch control gives the monitor a
modern feel
Page 3
LED monitor with PowerSensor
E-line 23.6" / 59.9 cm
Specifications
247E3LPHSU/00
Picture/Display
• LCD panel type: TFT-LCD
• Backlight type: W-LED system
• Panel Size: 23.6 inch / 59.9 cm
• Effective viewing area: 521.28 (H) x 293.22 (V)
• Aspect ratio: 16:9
• Optimum resolution: 1920 x 1080 @ 60Hz
• SmartResponse (typical): 2 ms
• Response time (typical): 5 ms
• Brightness: 300 cd/m²
• SmartContrast:
• Contrast ratio (typical): 1000:1
• Pixel pitch: 0.272 x 0.272 mm
• Viewing angle: 170º (H) / 160º (V), @ C/R > 10
• Picture enhancement: SmartImage Lite
• Display colors: 16.7 M
• Scanning Frequency: 30 -83
•sRGB
20,000,000:1
kHz (H) / 56 -75 Hz (V)
Connectivity
• Signal Input: VGA (Analog ), HDMIx2
• Sync Input: Separate Sync, Sync on Green
• Audio In/Out: HDMI audio out
Convenience
• User convenience: SmartImage lite, Input,
PowerSensor, Menu, Power On/Off
• OSD Languages: English, Fr
Russian, Simplified Chinese, Spanish, Portuguese,
Turkish
• Other convenience: Kensington lock
• Plug & Play Compatibility: DDC/CI, Mac OS X,
GB, Windows 7
sR
ench, German, Italian,
Power
• On mode: 17.53 W (EnergyStar 5.0 test method)
• Standby mode: <0.5W
• Off mode: < 0.3 W
• Power LED indicator: Operation - White, Standby
mode- White (blinking)
• Power supply: Built-in, 100-240VAC, 50/60Hz
Dimensions
• Product with stand (mm): 579 x 442 x 238 mm
• Product without stand (mm): 579 x 363 x 41 mm
• Packaging in mm (WxHxD): 619 x 506 x 103 mm
Weight
• Product with stand (kg): 4.5 kg
• Product without stand (kg): 3.97 kg
• Product with packaging (kg): 5.878 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature Range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• MTBF: 30,000 hour(s)
Sustainability
• Environmental and energy: EnergyStar 5.0, EPEAT
Silver, RoHS, Lead-free, Mercury Free
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: BSMI, CE Mark, FCC Class
B, GOST, PSB, SASO, SEMKO, TUV Ergo, TUV/
GS, TCO certified, UL/cUL, WEEE
Stand
• Tilt: -5/+20 degree
Cabinet
• Color: Black/ Blue tint
•Finish: Glossy
•
Issue date 2014-03-14
Version: 2.0.2
12 NC: 8670 000 75619
EAN: 87 12581 60084 6
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
