Philips 246V5LDSB User Guide
246V5
www.philips.com/welcome
EN User manual 1
Customer care and warranty 16
Troubleshooting & FAQs 20
Table of Contents
1. Important ....................................... 1
1.1 Safety precautions and
maintenance .................................. 1
1.2 Notational Descriptions ............. 2
1.3 Disposal of product and packing
material ........................................... 3
2. Setting up the monitor ............... 4
2.1 Installation ..................................... 4
2.2 Operating the monitor ................6
2.3 Remove Base Stand and Base . 8
3. Image Optimization ...................10
3.1 SmartContrast ..............................10
4. Technical Specications ............11
4.1 Resolution & Preset Modes .....14
5. Power Management ..................15
6. Customer care and warranty ...16
6.1 Philips’ Flat Panel Monitors
Pixel Defect Policy ......................16
6.2 Customer Care & Warranty .......19
7. Troubleshooting & FAQs ..........20
7.1 Troubleshooting .........................20
7.2 General FAQs ............................... 21
1. Important
1. Important
This electronic user’s guide is intended
for anyone who uses the Philips
monitor. Take time to read this user's
manual before you use your monitor.
It contains important information and
notes regarding the operation of your
monitor.
The Philips guarantee applies provided
the product is handled properly for
its intended use, in accordance with
its operating instructions and upon
presentation of the original invoice
or cash receipt, indicating the date of
purchase, dealer’s name and model and
production number of the product.
1.1 Safety precautions and maintenance
Warnings
Use of controls, adjustments or
procedures other than those specified
in this documentation may result in
exposure to shock, electrical hazards
and/or mechanical hazards.
Read and follow these instructions
when connecting and using your
computer monitor.
Operation
• Please Keep the monitor out of
direct sunlight, very strong bright
lights and away from any other heat
source. Lengthy exposure to this
type of environment may result in
discoloration and damage to the
monitor.
• Remove any object that could fall
into ventilation holes or prevent
proper cooling of the monitor’s
electronics.
• Do not block the ventilation holes
on the cabinet.
• When positioning the monitor, make
sure the power plug and outlet are
easily accessible.
• If turning o the monitor by detaching the power cable or DC power
cord, wait for 6 seconds before
attaching the power cable or DC
power cord for normal operation.
• Please use approved power cord
provided by Philips at all times. If
your power cord is missing, please
contact your local service center.
(Please refer to Customer Care Consumer Information Center)
• Do not subject the monitor to severe vibration or high impact conditions during operation.
• Do not knock or drop the monitor
during operation or transportation.
Maintenance
• To protect your monitor from possible damage, do not put excessive
pressure on the LCD panel. When
moving your monitor, grasp the
frame to lift; do not lift the monitor
by placing your hand or ngers on
the LCD panel.
• Unplug the monitor if you are not
going to use it for an extensive period of time.
• Unplug the monitor if you need to
clean it with a slightly damp cloth.
The screen may be wiped with a
dry cloth when the power is o.
However, never use organic solvent,
such as, alcohol, or ammonia-based
liquids to clean your monitor.
• To avoid the risk of shock or permanent damage to the set, do not expose the monitor to dust, rain, water,
or excessive moisture environment.
• If your monitor gets wet, wipe it with
dry cloth as soon as possible.
• If foreign substance or water gets in
your monitor, please turn the power
1
1. Important
o immediately and disconnect the
power cord. Then, remove the foreign substance or water, and send it
to the maintenance center.
• Do not store or use the monitor in
locations exposed to heat, direct
sunlight or extreme cold.
• In order to maintain the best performance of your monitor and use
it for a longer lifetime, please use
the monitor in a location that falls
within the following temperature
and humidity ranges.
• Temperature: 0-40°C 32-104°F
• Humidity: 20-80% RH
Important information for Burn-in/
Ghost image
• Always activate a moving screen
saver program when you leave your
monitor unattended. Always activate a periodic screen refresh application if your monitor will display
unchanging static content. Uninterrupted display of still or static
images over an extended period
may cause “burn in”, also known as
“after-imaging” or “ghost imaging”,
on your screen.
"Burn-in", "after-imaging", or "ghost
imaging" is a well-known phenomenon in LCD panel technology.
In most cases, the “burned in” or
“after-imaging” or “ghost imaging” will disappear gradually over a
period of time after the power has
been switched o.
Warning
Failure to activate a screen saver, or
a periodic screen refresh application
may result in severe” burn-in” or “afterimage” or “ghost image” symptoms will
not disappear and cannot be repaired.
The damage mentioned above is not
covered under your warranty.
Service
• The casing cover should be opened
only by qualied service personnel.
• If there is any need for any document for repair or integration,
please contact with your local
service center. (please refer to the
chapter of "Consumer Information
Center")
• For transportation information,
please refer to "Technical Specications".
• Do not leave your monitor in a car/
trunk under direct sun light.
Note
Consult a service technician if the
monitor does not operate normally, or
you are not sure what procedure to take
when the operating instructions given in
this manual have been followed.
1.2 Notational Descriptions
The following subsections describe
notational conventions used in this
document.
Notes, Cautions and Warnings
Throughout this guide, blocks of text
may be accompanied by an icon and
printed in bold or italic type. These
blocks contain notes, cautions or
warnings. They are used as follows:
Note
This icon indicates important
information and tips that help you make
better use of your computer system.
Caution
This icon indicates information that
tells you how to avoid either potential
damage to hardware or loss of data.
2
1. Important
Warning
This icon indicates the potential for
bodily harm and tells you how to avoid
the problem.
Some warnings may appear in alternate
formats and may not be accompanied
by an icon. In such cases, the specific
presentation of the warning is mandated
by the relevant regulatory authority.
1.3 Disposal of product and packing material
Waste Electrical and Electronic
Equipment-WEEE
This marking on the product or on
its packaging illustrates that, under
European Directive 2012/19/EU
governing used electrical and electronic
appliances, this product may not be
disposed of with normal household
waste. You are responsible for disposal
of this equipment through a designated
waste electrical and electronic
equipment collection. To determine the
locations for dropping off such waste
electrical and electronic, contact your
local government office, the waste
disposal organization that serves your
household or the store at which you
purchased the product.
Your new monitor contains materials
that can be recycled and reused.
Specialized companies can recycle
your product to increase the amount of
reusable materials and to minimize the
amount to be disposed of.
All redundant packing material has been
omitted. We have done our utmost to
make the packaging easily separable
into mono materials.
Please find out about the local
regulations on how to dispose of your
old monitor and packing from your sales
representative.
Taking back/Recycling Information for
Customers
Philips establishes technically and
economically viable objectives
to optimize the environmental
performance of the organization's
product, service and activities.
From the planning, design and
production stages, Philips emphasizes
the important of making products that
can easily be recycled. At Philips,
end-of-life management primarily
entails participation in national takeback initiatives and recycling programs
whenever possible, preferably in
cooperation with competitors,
which recycle all materials (products
and related packaging material) in
accordance with all Environmental
Laws and taking back program with the
contractor company.
Your display is manufactured with high
quality materials and components
which can be recycled and reused.
To learn more about our recycling
program please visit
http://www.philips.com/a-w/about/
sustainability.html
3
2. Setting up the monitor
2. Setting up the
* VGA
* CD
* Audio cable
246V5
Register your product and get support at
www.philips.com/welcome
©
2
0
1
6
K
o
n
i
n
k
l
i
j
k
e
P
h
i
l
i
p
s
N
.
V
.
A
l
l
r
i
g
h
t
s
r
e
s
e
r
v
e
d
.
U
n
a
u
t
h
o
r
i
z
e
d
d
u
p
l
i
c
a
t
i
o
n
i
s
a
v
i
o
l
a
t
i
o
n
o
f
a
p
p
l
i
c
a
b
l
e
l
a
w
s
.
M
a
d
e
a
n
d
p
r
i
n
t
e
d
i
n
C
h
i
n
a
.
V
e
r
s
i
o
n
Philips and the Philips’ Shield Emblem are
registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke
Philips N.V.
Contents:
Monitor drivers
User’s Manual
User’s Manual
www.philips.com/welcome
使用产品前请阅读使用说明
保留备用
Monitor
* DVI
monitor
2.1 Installation
Package contents
Install base stand
1. Place the monitor face down
on soft and smooth surface
taking care to avoid scratching
or damaging the screen.
2. Attach the base column with the
monitor until it clicks into position.
3. Hold the monitor base stand with
both hands and firmly insert the
base stand into the base column.
* Different according to region.
4
2. Setting up the monitor
Connecting to your PC
5
6
5
6
6
1 2 3 4 5
1
246V5LAB
1
AC power input
2
VGA input
3
DVI-D input
4
Audio input
5
Kensington anti-theft lock
6
Earphone jack
246V5LHAB
1
AC power input
2
VGA input
3
HDMI input
4
Audio input
5
Kensington anti-theft lock
6
Earphone jack
246V5LSB
1
AC power input
2
VGA input
3
DVI-D input
4
Kensington anti-theft lock
246V5LDSB
1
AC power input
2
HDMI input
3
DVI input
4
VGA input
5
HDMI audio out
6
Kensington anti-theft lock
Connect to PC
1. Connect the power cord to the back
of the monitor firmly.
2. Turn off your computer and unplug
its power cable.
3. Connect the monitor signal cable to
the video connector on the back of
your computer.
4. Plug the power cord of your
computer and your monitor into a
nearby outlet.
5. Turn on your computer and monitor.
If the monitor displays an image,
installation is complete.
5
2. Setting up the monitor
2.2 Operating the monitor
Front view product description
Model 246V5LAB/246V5LHAB:
5
Description of the On Screen Display
What is On-Screen Display (OSD)?
On-Screen Display (OSD) is a feature in
all Philips LCD monitors. It allows an end
user to adjust screen performance or
select functions of the monitors directly
through an on-screen instruction
window. A user friendly on screen
display interface is shown as below:
Model 246V5LSB:
6 2347
Model 246V5LSB/246V5LDSB:
5
6 2 1347
1
Switch monitor’s power ON
and OFF.
Access the OSD menu
2
Confirm the OSD
adjustment.
3
4
5
Return to previous OSD
level.
Adjust the brightness level.
Adjust the OSD menu.
Adjust the speaker volume.
6
Change display format.
7
Automatically adjust the
monitor.
Model 246V5LDSB:
Model 246V5LAB:
.
6
Loading...
