Page 1
Philips
LCD monitor
V Line
23.6"/59.9 cm
243V5QSBA
Great LED images in
vivid colours
Enjoy vibrant pictures on this Philips display. Essential features like SmartContrast, which
ensures rich, bright images, make it a great choice!
Vivid pictures every time
• MVA Display for wide viewing angles and deep contrast levels
• SmartContrast for rich black details
• 16:9 Full HD display for the best viewing experience
Great choice
• Compact design saves space
• Mercury Free eco-friendly display
• VESA mount allows for flexibility
Page 2
243V5QSBA/57
LCD monitor
V Line 23.6"/59.9 cm
Highlights
MVA Display Technology
The Philips MVA LED display uses an advanced
multi-domain vertical alignment technology
that gives you super-high static contrast ratios
for extra-vivid and bright images. While
standard office applications are handled with
ease, it is especially suitable for photos, web
browsing, films, gaming and demanding
graphical applications. Its optimised pixel
management technology gives you a 178/178
degree extra-wide viewing angle, resulting in
crisp images.
SmartContrast
SmartContrast is a Philips technology that
analyses the contents you are displaying,
automatically adjusting colours and controlling
backlight intensity to dynamically enhance
contrast for the best digital images and videos
or when playing games where dark hues are
displayed. When Economy mode is selected,
contrast is adjusted and backlighting fine-tuned
for just-right display of everyday office
applications and lower power consumption.
16:9 Full HD
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future-proof as it
supports 1080p signals from all sources,
including the most recent sources such as Bluray and advanced HD game consoles. The
signal processing is extensively upgraded to
support this much higher signal quality and
resolution. It produces brilliant flicker-free
progressive scan pictures with superb
brightness and colours.
Mercury Free
Philips monitors with LED backlighting are free
from
Mercury, one of the most toxic natural
substances, which affects humans and animals.
This reduces the environmental impact of the
display throughout its lifecycle, from
manufacturing to disposal.
Page 3
243V5QSBA/57
LCD monitor
V Line 23.6"/59.9 cm
Specifications
Picture/Display
• LCD panel type: MVA
• Backlight type: W-LED system
•Panel Size: 23.6 inch/59.9 cm
• Effective viewing area: 521.28 (H) x 293.22 (V)
• Aspect ratio: 16:9
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Response time (typical): 25 (Grey to Grey) ms
• SmartResponse (typical): 8 (Grey t
• Brightness: 250 cd/m²
• SmartContrast:
• Contrast ratio (typical): 3000:1
• Pixel pitch: 0.272 x 0.272 mm
• Viewing angle: 178º (H)/178º (V),
• Display colours: 16.7 M
• Scanning Frequency: 30–83 kHz (H)/56–75 Hz (V)
•sRGB
10,000,000:1
o Grey) ms
@ C/R > 20
Connectivity
• Signal Input: VGA (Analogue), DVI-D (digital,
HDCP)
• Sync Input: Separate Sync, Sync on Green
Convenience
• User convenience: Auto/Down, 4:3 Wide/Up,
Brightness/Back, Menu/OK, Power On/Off
• OSD Languages: Brazil Portuguese, Czech, Dutch,
glish, Finnish, French, German, Greek,
En
Hungarian, Italian, Japanese, Korean, Polish,
Portuguese, Russian, Spanish, Simplified Chinese,
Swedish, Turkish, Traditional Chinese, Ukrainian
• Other convenience: Kensington lock, VESA mount
(100 x 100 mm)
• Plug and Play Compatibility: DDC/CI, Mac OS X,
GB, Windows 7, Windows 8
sR
Stand
• Tilt: -5/20 degree
Power
• On mode: 21.07 W (typ.) (EnergyStar 6.0 test
method)
• Standby mode: 0.5 W (typ.)
• Off mode: 0.5 W (typ.)
• Power LED indicator: Operation - White, Standby
mode - White (f
• Power supply: Built-in, 100–240 VAC, 50–60 Hz
lashing)
Dimensions
• Product with stand (mm): 551 x 420 x 220 mm
• Product without stand (mm): 551 x 344 x 52 mm
• Packaging in mm (W x H x D): 600 x 415 x 118 mm
Weight
• Product with stand (kg): 3.66 kg
• Product without stand (kg): 3.22 kg
• Product with packaging (kg): 5.00 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• Altitude: Operation: +12,000 ft (3658 m), Non-
eration: +40,000 ft (12,192 m)
op
• MTBF: 30,000 hour(s)
Sustainability
• Environmental and energy: EnergyStar 6.0, RoHS,
Mercury Free
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: BSMI, CE Mark, cETLus,
FCC Class B, GOST, PSB, SASO, SEMKO, TCO
Certified, TUV/ISO9241-307, WEEE
Cabinet
• Colour: Black
• Finish: Hairline (front bezel)/Texture (rear cover)
•
Issue date 2021-07-21
Version: 3.0.1
12 NC: 8670 001 24826
EAN: 87 12581 73180 9
© 2021 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* Smart response time is the optimum value from either GtG or GtG
(BW) tests.
