Philips
LCD monitor with
SmartControl Lite
V Line
23.6" / 59.9 cm
243V5QHSBA
Great LED images in vivid colors
Enjoy vibrant pictures on this Philips display. Equipped with HDMI and SmartControl lite,
it’s a great choice!
Vivid pictures every time
• MVA Display for wide viewing angles and deep contrast levels
• SmartContrast for rich black details
• 16:9 Full HD display for best viewing experience
• Easy display performance tuning with SmartControl Lite
Experience multimedia
• HDMI-ready for Full HD entertainment
Great choice
• Compact design saves space
• Mercury Free eco-friendly display
• VESA mount allows for flexibility
Page 2
243V5QHSBA/75
LCD monitor with SmartControl Lite
V Line 23.6" / 59.9 cm
Highlights
MVA Display Technology
Philips MVA LED display uses an advanced
multi-domain vertical alignment technology
which gives you super-high static contrast
ratios for extra vivid and bright images. While
standard office applications are handled with
ease, it is especially suitable for photos, webbrowsing, movies, gaming, and demanding
graphical applications. It's optimized pixel
management technology gives you 178/178
degree extra wide viewing angle, resulting in
crisp images.
SmartControl Lite
SmartControl Lite is the next generation 3D
ic
on based GUI monitor control software. This
allows user to fine-tune most parameters of
the monitor like Color, Brightness, screen
calibration, Multi-media, ID management, etc
with the mouse.
SmartContrast
SmartContrast is a Philips technology that
analyzes the contents you are displaying,
automatically adjusting colors and controlling
backlight intensity to dynamically enhance
contrast for the best digital images and videos
or when playing games where dark hues are
displayed. When Economy mode is selected,
contrast is adjusted and backlighting fine-tuned
for just-right display of everyday office
applications and lower power consumption.
16:9 Full HD
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.
HDMI Ready
An HDMI-ready device has all the required
hardware to accept High-Definition
Multimedia Interface (HDMI) input. A HDMI
cable enables high-quality digital video and
audio all transmitted over a single cable from a
PC or any number of AV sources (including
set-top boxes, DVD players, A/V receivers and
video cameras).
Mercury Free
Philips monitors with LED backlighting are free
of
Mercury content, one of the most toxic
natural substances, which affects humans and
animals. This reduces the environmental
impact of the display throughout its life-cycle,
from manufacturing to disposal.
Page 3
243V5QHSBA/75
LCD monitor with SmartControl Lite
V Line 23.6" / 59.9 cm
Specifications
Picture/Display
• LCD panel type: MVA
• Backlight type: W-LED system
• Panel Size: 23.6 inch / 59.9 cm
• Effective viewing area: 521.28 (H) x 293.22 (V)
• Aspect ratio: 16:9
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Response time (typical): 8 ms (Gray to Gray)*
• Brightness: 250 cd/m²
• SmartContrast:
• Contrast ratio (typical): 3000:1
• Pixel pitch: 0.272 x 0.272 mm
• Viewing angle: 178º (H) / 178º (V), @ C/R > 20
• Display colors: 16.7 M
• Scanning Frequency: 30 -83
•sRGB
10,000,000:1
kHz (H) / 56 -75 Hz (V)
Connectivity
• Signal Input: VGA (Analog ), DVI-D (digital,
HDCP), HDMI (digital, HDCP)
• Sync Input: Separate Sync, Sync on Green
Convenience
• User convenience: Auto/Down, 4:3 Wide/Up,
Brightness/Back, Menu/OK, Power On/Off
• OSD Languages: Brazil Portuguese, Czech, Dutch,
glish, Finnish, French, German, Greek,
En
Hungarian, Italian, Japanese, Korean, Polish,
Portuguese, Russian, Spanish, Simplified Chinese,
Swedish, Turkish, Traditional Chinese, Ukranian
• Other convenience: Kensington lock, VESA mount
x100mm)
(100
• Plug & Play Compatibility: DDC/CI, Mac OS X,
GB, Windows 7, Windows 8
sR
method)
• Standby mode: 0.5 W (typ.)
• Off mode: 0.3 W (typ.)
• Power LED indicator: Operation - White, Standby
mode- White (blinking)
• Power supply: Built-in, 100-240VAC, 50-60Hz
Dimensions
• Product with stand (mm): 551 x 420 x 220 mm
• Product without stand (mm): 551 x 344 x 52 mm
• Packaging in mm (WxHxD): 600 x 415 x 118 mm
Weight
• Product with stand (kg): 3.66 kg
• Product without stand (kg): 3.22 kg
• Product with packaging (kg): 5.00 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• Altitude: Operation: +12,000ft (3,658m), Non-
eration: +40,000ft (12,192m)
op
• MTBF: 30,000 hour(s)
Sustainability
• Environmental and energy: EnergyStar 6.0, RoHS,
Mercury Free
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: BSMI, CE Mark, cETLus,
FCC Class B, PSB, SEMKO, TCO Certified, TUV/
ISO9241-307, WEEE, C-Tick, EPA, UKRAINIAN
Stand
• Tilt: -5/20 degree
Power
• On mode: 21.51 W (typ.) (EnergyStar 6.0 test
Cabinet
• Color: Black
• Finish: Hairline (front bezel) / Texture (rear cover)
•
Issue date 2021-07-21
Version: 4.0.1
12 NC: 8670 001 24842
EAN: 87 12581 73194 6
© 2021 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* HDMI cables vary depending on region and models.
* Response time value equal to SmartResponse
