Page 1
Philips
LCD monitor with
SmartControl Lite
V Line
24 (23.8" / 60.5 cm diag.)
240V5QDAB
Great LED images in vivid colors
with stereo speakers
Enjoy vibrant pictures on this Philips display. Equipped with HDMI and stereo speakers,
it’s a great choice!
Vivid pictures every time
• IPS-ADS wide-view technology for image and color accuracy
• 16:9 Full HD display for crisp detailed images
• SmartContrast for rich black details
• Easy display performance tuning with SmartControl Lite
Experience multimedia
• Powerful sound with 2x2 watts RMS speakers
• HDMI-ready for Full HD entertainment
Great choice
• Compact design saves space
• Mercury Free eco-friendly display
• VESA mount allows for flexibility
Page 2
240V5QDAB/71
LCD monitor with SmartControl Lite
V Line 24 (23.8" / 60.5 cm diag.)
Highlights
IPS-ADS technology
IPS-ADS displays use an advanced technology
which gives you extra wide viewing angles of
178/178 degree, making it possible to view the
display from almost any angle. Unlike standard
TN panels, IPS-ADS displays give you
remarkably crisp images with vivid colors,
making it ideal not only for Photos, movies and
web browsing, but also for professional
applications which demand color accuracy and
consistent brightness at all times.
16:9 Full HD display
features enhanced Full HD 1920 x 1080
resolution. With Full HD for crisp detail paired
with high brightness, incredible contrast and
realistic colors expect a true to life picture.
SmartContrast
SmartContrast is a Philips technology that
analyzes the contents you are displaying,
automatically adjusting colors and controlling
backlight intensity to dynamically enhance
contrast for the best digital images and videos
or when playing games where dark hues are
displayed. When Economy mode is selected,
contrast is adjusted and backlighting fine-tuned
for just-right display of everyday office
applications and lower power consumption.
HDMI Ready
An HDMI-ready device has all the required
hardware to accept High-Definition
Multimedia Interface (HDMI) input. A HDMI
cable enables high-quality digital video and
audio all transmitted over a single cable from a
PC or any number of AV sources (including
set-top boxes, DVD players, A/V receivers and
video cameras).
Built-in stereo speakers
Now you can enjoy all your multimedia and
soci
al applications with stereo sound. These
built in speakers not only sound great, but also
helps you to get rid of external wire clutter and
save valuable desktop space.
Picture quality matters. Regular displays deliver
quality, but you expect more. This display
SmartControl Lite
SmartControl Lite is the next generation 3D
i
con based GUI monitor control software. This
allows user to fine-tune most parameters of
the monitor like Color, Brightness, screen
calibration, Multi-media, ID management, etc
with the mouse.
Mercury Free
Philips monitors with LED backlighting are free
of
Mercury content, one of the most toxic
natural substances, which affects humans and
animals. This reduces the environmental
impact of the display throughout its life-cycle,
from manufacturing to disposal.
Page 3
240V5QDAB/71
LCD monitor with SmartControl Lite
V Line 24 (23.8" / 60.5 cm diag.)
Specifications
Picture/Display
• LCD panel type: IPS-ADS LCD
• Backlight type: W-LED system
• Panel Size: 23.8 inch / 60.5 cm
• Effective viewing area: 527.04 (H) x 296.46 (V)
• Aspect ratio: 16:9
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Response time (typical): 5 ms (GtG)*
• Brightness: 250 cd/m²
• SmartContrast:
• Contrast ratio (typical): 1000:1
• Pixel pitch: 0.275 x 0.275 mm
• Viewing angle: 178º (H) / 178º (V), @ C/R > 10
• Display colors: 16.7 M
• Scanning Frequency: 30 -83
•sRGB
10,000,000:1
kHz (H) / 56 -76 Hz (V)
Connectivity
• Signal Input: VGA (Analog ), DVI-D (digital,
HDCP), HDMI (digital, HDCP)
• Sync Input: Separate Sync, Sync on Green
• Audio (In/Out): PC audio-in, Headphone out
Convenience
• Built-in Speakers: 2W x 2
• User convenience: Power On/Off, Menu/OK,
Brightness/
• OSD Languages: Brazil Portuguese, Czech, Dutch,
En
Hungarian, Italian, Japanese, Korean, Polish,
Portuguese, Russian, Spanish, Simplified Chinese,
Swedish, Turkish, Traditional Chinese, Ukranian
• Other convenience: Kensington lock, VESA mount
(100
• Plug & Play Compatibility: DDC/CI, Mac OS X,
sR
Back, Volume/Up, Auto/Down
glish, Finnish, French, German, Greek,
x100mm)
GB, Windows 7, Windows 8.1
Power
• On mode: 19.23 W (typ.) (EnergyStar 6.0 test
method)
• Standby mode: 0.5 W (typ.)
• Off mode: 0.5 W (typ.)
• Power LED indicator: Operation - White, Standby
mode- White (blinking)
• Power supply: Built-in, 100-240VAC, 50-60Hz
Dimensions
• Product with stand (mm): 553 x 420 x 219 mm
• Product without stand (mm): 553 x 343 x 55 mm
• Packaging in mm (WxHxD): 600 x 415 x 118 mm
Weight
• Product with stand (kg): 4.09 kg
• Product without stand (kg): 3.69 kg
• Product with packaging (kg): 5.36 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• Altitude: Operation: +12,000ft (3,658m), Non-
eration: +40,000ft (12,192m)
op
• MTBF: 50,000 (Excluded backlight) hour(s)
Sustainability
• Environmental and energy: EnergyStar 6.0, EPEAT
Silver, RoHS, Lead-free, Mercury Free
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: CE Mark, FCC Class B,
TCO Certified, cETLus, TUV/ISO9241-307, BSMI,
PSB, C-tick, UKRAINIAN, EPA
Stand
• Tilt: -5/20 degree
Issue date 2019-06-19
Version: 2.0.1
12 NC: 8670 001 25192
EAN: 87 12581 73252 3
Cabinet
• Color: Black
• Finish: Hairline (front bezel) / Texture (rear cover)
•
© 2019 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* "IPS" word mark / trademark and related patents on technologies
belong to their respective owners.
* HDMI cables vary depending on region and models.
* Response time value equal to SmartResponse
