Information for users in the UK (not applicable outside the UK)

Positioning the TV

For the best results, choose a position where light does not fall directly on the screen, and at some
distance away from radiators or other sources of heat. Leave a space of at least 5 cm all around the
TV for ventilation, making sure that curtains, cupboards etc. cannot obstruct the air flow through the
ventilation apertures. The TV is intended for use in a domestic environment only and should never be
operated or stored in excessively hot or humid atmospheres.

Interference

The Department of Trade and Industry operates a Radio Interference Investigation Service to help
TV license holders improve reception of BBS and IBA programmes where they are being spoilt by
interference.
If your dealer cannot help, ask at a main Post Office for the booklet “How to Improve Television and
Radio Reception”.

Mains Connection

Before connecting the TV to the mains, check that the mains supply voltage corresponds to the
voltage printed on the type plate on the rear panel of the TV. If the mains voltage is different, consult
your dealer.

Important

Should it become necessary to replace the mains fuse, this must be replaced with a fuse of the same
value as indicated on the plug.

1. Remove fuse cover and fuse.

2. The replacement fuse must comply with BS 1362 and have the ASTA approval mark. If the
fuse is lost, make contact with your retailer in order to verify the correct type.

3. Refit the fuse cover

In order to maintain conformity to the EMC directive, the mains plug on this product must not be
removed.

Connecting the aerial

The aerial should be connected to the socket marked
likely to result in a poor, perhaps unstable picture with ghost images and lack of contrast. Make-shift
loft or set-top aerials are often inadequate. Your dealer will know from experience the most suitable
type for your locality.
Should you wish to use the set in conjunction with other equipment, which connects to the aerial
socket such as TV games, or a video camera it is recommended that these be connected via a
combiner unit to avoid repeated connection and disconnection of the aerial plug.

Fitting the stand (if provided)

Use only the stand provided with the set, making sure that the fixings are properly tightened. A
diagram showing how to assemble the stand is packed with the stand. Never use a make-shift stand,
or legs fixed with woodscrews.

at the back of the set. An inferior aerial is

- 2 -

A

ccess Code / Code d'accès / Zugangkennziffer / Codice di accesso / Código de acceso

T

Y

When the set is in the Standard Security Mode, the Set-up Menu may be accessed either with an
Institutional Set-up Remote Control, or with a guest remote control (like the RC2886) by pressing

the following Remote Control keys in sequence:

Care of the screen

Warning concerning stationary images on the TV screen (42” Plasma)

Warning concerning VGA/DVI display mode

Environmental

• Your television contains material that can be recycled and reused by specialized companies. Please

•

Do not touch, push or rub or strike the screen with anything hard as this may scratch, mar or
damage the screen permanently. Do not rub with dust clothes with chemical treatment. Do not
touch the surface with bare hands or greasy cloth (some cosmetics are detrimental to the screen).
Unplug the TV before cleaning the screen. When the surface becomes dusty, please wipe gently
with absorbent cotton or other soft materials like chamois soaks. Do not use acetone, toluene and
alcohol because they cause chemical damage.
Do not use liquid cleaners or aerosol cleaners. Wipe off saliva or water drops as soon as possible.
Their long time contact with the screen causes deformations and colour fading.

A characteristic of Plasma Display Panels is that displaying the same image for a long time can
cause a permanent after-image to remain on the screen. This is called phosphor burn in. Normal
use of the TV should involve the showing of pictures that contain constantly moving and
changing images that fill the screen.

As this product processes in VGA/DVI mode, some diagonal lines may be seen under
circumstances of environmental interference. This will not affect the computer signal
performance that displays in VGA/DVI mode.

find out about local regulations on the disposal of your old television set. Pay particular attention
to the disposal of exhausted batteries.

Your television consumes energy in the stand-by mode. Energy consumption contributes to air
and water pollution. We advise you to switch off your television overnight instead of leaving it in
stand-by mode.

3 1 9 7 5 3 Mute

he packaging of this product is intended to be recycled. Apply to the local

authorities for correct disposal.

Disposal of your old product.

our product is designed and manufactured with high quality materials and
components, which can be recycled and reused.When this crossed-out wheeled bin
symbol is attached to a product it means the product is covered by the European
Directive 22002/96/EC. Please find out more about the separate collection system for
electrical and electronic products in your local neighbourhood.
Please act according to your local rules and do not dispose of your old products with
your normal household waste. The correct disposal of your old product will help
prevent potential negative consequences for the environment and human health.

- 3 -

T

•

Wall mounting instructions/Table stand

According to the type of TV you’ve purchased a wall mount bracket and/or stand may be supplied.
To mount the supplied stand and/or wall mount bracket, refer to separate instructions. Make sure
that the wall mount is fixed securely so that it meets safety standards.

Make sure that air can circulate freely through the ventilation slots

o prevent any unsafe situations, no naked flame
sources, such as lighted candles, should be placed
on or in the vicinity. Avoid heat, direct sunlight and
exposure to rain or water. The equipment shall not
be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on
it. Insert the aerial plug firmly into the aerial socket
at the bottom of the TV.

Connecting the Mains

Insert the mains plug into the wall socket and switch on. Please refer to the label on the back of the
television for the correct operating voltage.

Installing the remote control

Switch the TV on:

Press the power switch on the TV. An indicator on the front of the TV lights up and the screen
comes on. If the TV is in standby mode (red indicator), press the - TV+ keys on the remote control.

Remove the cover at the back of the
remote control.

• Insert the correct type and size batteries
into the compartment making sure they
are the right way around.

• You can secure your batteries by
fastening an appropriate screw into the
hole of the battery cover.

- 4 -

Accessing the Set-up Menu

When the set is in the High Security Mode, the Setup menu can be accessed only with an Institutional
Set-up Remote Control (RG4172BK or RC2573).

When the set is in the Standard Security Mode, the Set-up Menu may be accessed either with an
Institutional Set-up Remote Control, or with a guest remote control (like the RC2886) using an
authorized access code.

RG4172BK RC 2573

Navigation

The current menu item can be selected by means of the cursor up and cursor down keys.
Submenus can be accessed from menu items with a “>” symbol pressing the cursor right key.

• To exit any menu press “Menu” button

• Select “YES” to activate/enable a setting, “NO” to deactivate/disable.

• TELEVISION up/down, INFO up/down, PAY-TV up/down and

RADIO up/down are active in menu mode and the television reacts the
same way as in TV mode.

- 5 -

• Language: Select the language of the installation menu. Options are "ENGLISH",
"DEUTSCH", and "FRANCAIS".

• Communication: The Communication menu is required to enable interactive applications.
For more information, consult the respective application notes. For stand-alone applications
select “OFF”.

• No. of Programs: This sub menu allows setting the number of Television, PAY-TV, Radio
and Info programs. The overall maximum number of programs is 125.

• Program Install: In the Program Install sub-menu, program settings can be set.

• Configuration: In the Configuration menu, various settings and features of the TV can be

adjusted.

• Clock Setup: The Clock set-up menu can be entered from this menu item (this menu option is
only available on certain LCD TV models).

- 6 -

In the Program Installation sub-menu, program settings can be set. When this menu is open, all the
protections are inactive.

• Program No.: The program type can be selected with the cursor left/right buttons. These buttons
will toggle between all available types: "TV", "INFO", "PAYTV" and "RADIO".
If the program number of a certain type is 0, the corresponding type is not displayed. In order to
display a program number of the above-mentioned types, always enter two numbers, for example:
“01” for TV1 or digit “1” and up/down cursor.

• Input: The "Input" menu item selects the desired input source that will be assigned to the program.
Possible values are TUNER, AV1, SIDE AV, SIDE S-VIDEO, RADIO, PC, and HD. Some input
sources may not be available on certain sets (see accompanying table).

Model / Input AV1 AV2 Side AV Side S-Video DVI
20HF5474 Scart1 - Video In S-Video In DVI

23HF5474 Scart1 - Video In S-Video In DVI

Note: When a SmartCard XPress Box is used, it is usually connected to Scart1.
