Philips 227E4QSD/69 leaflet

Philips
IPS LCD monitor, LED
backlight with SmartImage
Lite

E Line

21.5" (54.6 cm)
Full HD display

227E4QSD

High performance IPS display

for brilliant, vivid colors

Experience brilliant LED pictures on this IPS wide-view display. With elegant, slim design
and SmartImage lite, it's a great choice!

Superb Picture Quality

• IPS LED wide view technology for image and color accuracy

• 16:9 Full HD display for best viewing experience

• TrueVision ensures lab quality images

• SmartImage Lite for an enhanced LCD viewing experience

• Easy display performance tuning with SmartControl Lite

• SmartContrast for rich black details

Elegant Design

• Elegant, slim design complements your home decor

• Superb black cherry glossy finish

• Modern Touch controls

Greener everyday

• Low power consumption saves energy bills

• Mercury Free eco-friendly display

• Eco-friendly materials that meets international standards

227E4QSD/69

IPS LCD monitor, LED backlight

E Line 21.5" (54.6 cm), Full HD display

Highlights

IPS technology

IPS displays use an advanced technology which
gives you extra wide viewing angles of 178/178
degree, making it possible to view the display
from almost any angle. Unlike standard TN
panels, IPS displays gives you remarkably crisp
images with vivid colors, making it ideal not
only for Photos, movies and web browsing, but
also for professional applications which
demand color accuracy and consistent
brightness at all times.

SmartImage Lite

SmartImage Lite is an exclusive, leading edge
Phili

ps technology that analyzes the content
displayed on your screen. Based on a scenario
you select, SmartImage Lite dynamically
enhances the contrast, color saturation and
sharpness of images and videos for ultimate
display performance - all in real time with the
press on a single button.

SmartControl Lite

SmartControl Lite is the next generation 3D
ic

on based GUI monitor control software. This
allows user to fine-tune most parameters of
the monitor like Color, Brightness, screen
calibration, Multi-media, ID management, etc
with the mouse.

16:9 Full HD

resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.

SmartContrast

SmartContrast is a Philips technology that
analyzes the contents you are displaying,
automatically adjusting colors and controlling
backlight intensity to dynamically enhance
contrast for the best digital images and videos
or when playing games where dark hues are
displayed. When Economy mode is selected,
contrast is adjusted and backlighting fine-tuned
for just-right display of everyday office
applications and lower power consumption.

TrueVision

Touch controls

Touch controls are intelligent, touch sensitive
icons that replace protruding buttons that lets
the user adjust the monitor to their
requirement. Responding to your lightest
touch,Touch control gives the monitor a
modern feel.

Mercury Free

Philips monitors with LED backlighting are free
of

Mercury content, one of the most toxic
natural substances, which affects humans and
animals. This reduces the environmental
impact of the display throughout its life-cycle,
from manufacturing to disposal.

Eco-friendly materials

"Philips is committed to use sustainable, eco­friendly m
body plastic parts, metal chassis parts and
packing materials use 100% recyclable
materials. In some selected models we utilize
upto 65% post consumer recycled plastics.
Strict adherence to RoHS standards ensure
substantial reduction or elimination of toxic
substances like Lead, for example. Mercury
content in monitors with CCFL backlight has
been reduced significantly, while eliminated in
monitors with LED backlight completely. Visit
Philips @ http://www.asimpleswitch.com/
global/ to learn more.

aterials across its monitor range. All

The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest

TrueVision is a proprietary Philips technology
that uses advanced algorithm for testing and
aligning monitor display which gives you the
ultimate display performance. Philips ensures
TrueVision monitors leave the factory fine­tuned with this process giving you consistent
color and picture quality.

227E4QSD/69

IPS LCD monitor, LED backlight

E Line 21.5" (54.6 cm), Full HD display

Specifications

Picture/Display

• LCD panel type: IPS LCD

• Backlight type: W-LED system

• Panel Size: 21.5 inch / 54.6 cm

• Effective viewing area: 475.2 (H) x 267.3 (V)

• Aspect ratio: 16:9

• Optimum resolution: 1920 x 1080 @ 60Hz

• Response time (typical): 14 ms

• Contrast ratio (typical): 1000:1

• SmartContrast:

• Brightness: 250 cd/m²

• Pixel pitch: 0.248 x 0.248 mm

• Viewing angle: 178º (H) / 178º (V), @ C/R > 10

• Picture enhancement: SmartImage Lite

• Display colors: 16.7 M

• Scanning Frequency: 30 -83

•sRGB

20,000,000:1

kHz (H) / 56 -75 Hz (V)

Connectivity

• Signal Input: VGA (Analog ), DVI-D (digital, HDCP)

• Sync Input: Separate Sync, Sync on Green

Convenience

• User convenience: SmartImage lite, Input, 4:3 /
Wide, Menu, Power On/Off

• OSD Languages: English, Fr
Russian, Simplified Chinese, Spanish, Portuguese,
Turkish

• Other convenience: Kensington lock

• Plug & Play Compatibility: DDC/CI, Mac OS X,

GB, Windows 7/Vista/XP

sR

ench, German, Italian,

Stand

• Tilt: -5/20 degree

Power

• On mode: 25.4 W (EnergyStar 5.0 test method)

• Standby mode: 0.5 W

• Off mode: 0.3 W

• Power LED indicator: Operation - White, Standby
mode- White (blinking)

• Power supply: External, 100-240VAC, 50-60Hz

Dimensions

• Product with stand (mm): 510 x 398 x 179 mm

• Product without stand (mm): 510 x 314 x 37 mm

• Packaging in mm (WxHxD): 562 x 475 x 98 mm

Weight

• Product with stand (kg): 2.20 kg

• Product without stand (kg): 1.83 kg

• Product with packaging (kg): 3.74 kg

Operating conditions

• Temperature range (operation): 0°C to 40°C °C

• Temperature range (storage): -20°C to 60°C °C

• Relative humidity: 20%-80 %

• Altitude: Operation: +12,000ft (3,658m), Non-

eration: +40,000ft (12,192m)

op

• MTBF: 30,000 hour(s)

Sustainability

• Environmental and energy: EnergyStar 5.0, EPEAT
Silver, RoHS, Lead-free, Mercury Free

• Recyclable packaging material: 100 %

Compliance and standards

• Regulatory Approvals: BSMI, CE Mark, FCC Class
B, GOST, PSB, SASO, SEMKO, TCO 5.2, TUV/
ISO9241-307, UL/cUL, WEEE

Cabinet

• Color: Black Cherry

•Finish: Glossy

•

Issue date 2017-07-28

Version: 3.0.1

12 NC: 8670 000 90861
EAN: 87 12581 64725 4

© 2017 Koninklijke Philips N.V.
All Rights reserved.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.

www.philips.com
