Philips
LED monitor with TV
tuner
T-line
21.5" (54.6 cm)
220TS2LB
Great TV entertainment
on your LED monitor
Experience great movies with your LED Full HD TV monitor. Combined with two HDMI
and various AV inputs, stereo audio and modern touch controls, the 220TS2 is ready to
entertain you!
Best picture quality
• Full HD LCD display, with a 1920x1080p resolution
• LED technology ensures natural colors
• SmartContrast 20000000:1 for incredible rich black details
Great convenience
• Built-in TV tuner for viewing TV programs on your PC monitor
• Modern Touch controls
• Dual input accepts both analog VGA and digital HDMI signals
• SmartImage: Optimized user-friendly display experience
• SmartSound selects a perfect mode for audio performance
Experience true multimedia
• HDMI-ready for top quality, multimedia experience
• Incredible Surround for enhanced audio enjoyment
220TS2LB/69
LED monitor with TV tuner
2x
SmartSound
T-line 21.5" (54.6 cm)
Highlights
LED technology
White LED's are solid state devices which light
up
to full, consistent brightness faster saving
startup time. LED's are free from mercury
content which allows for eco-friendly recycling
and disposal process. LED's allow for better
dimming control of LCD backlight, resulting in
super high contrast ratio. It also gives superior
color reproduction thanks to consistent
brightness across the screen.
Full HD LCD display 1920x1080p
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future proof as it
supports 1080p signals from all sources,
including the most recent like Blu-ray and
advanced HD game consoles. The signal
processing is extensively upgraded to support
this much higher signal quality and resolution.
It produces brilliant flicker-free progressive
scan pictures with superb brightness and
colors.
dark shades and colors. It gives a bright, lifelike
picture with high contrast and vibrant colors.
Built-in TV tuner
A television tuner built into a monitor to
disp
lay television signals as well as computer
data.
Incredible Surround
Incredible Surround is an audio technology
from Philips that dramatically magnifies the
sound field to immerse you in the audio. Using
state-of-the-art electronic phase shifting,
Incredible Surround mixes sounds from left
and right in such a way that it expands the
virtual distance between the two speakers.
This wider spread greatly enhances the stereo
effect and creates a more natural sound
dimension. Incredible Surround allows you to
experience total surround with greater depth
and width of sound, without the use of
additional speakers.
SmartImage
images and videos for ultimate display
performance. The Economy mode option
offers you major power savings. All in real time
with the press of a single button!
HDMI Ready
An HDMI-ready device has all the required
hardware to accept High-Definition
Multimedia Interface (HDMI) input. A HDMI
cable enables high-quality digital video and
audio all transmitted over a single cable from a
PC or any number of AV sources (including
set-top boxes, DVD players, A/V receivers and
video cameras).
Touch controls
SmartContrast ratio 20000000:1
You want the LCD flat display with the highest
contrast and most vibrant images. Philips
advanced video processing combined with
unique extreme dimming and backlight
boosting technology results in vibrant images.
SmartContrast will increase the contrast with
excellent blacklevel and accurate rendition of
SmartImage is an exclusive leading edge Philips
technology that analyzes the content displayed
on your screen and gives you optimized display
performance. This user friendly interface
allows you to select various modes like Office,
Image, Entertainment, Economy etc., to fit the
application in use. Based on the selection,
SmartImage dynamically optimizes the
contrast, color saturation and sharpness of
Touch controls are intelligent, touch sensitive
icons that replace protruding buttons that lets
the user adjust the monitor to their
requirement. Responding to your lightest
touch,Touch control gives the monitor a
modern feel.
Dual input
Dual input accepts both analog VGA and digital
HDMI signal
SmartSound
SmartSound allows you to select various
m
odes like Movie, Games, Music etc thereby
automatically activating pre defined
frequencies to enhance the sound related to
the function
s
220TS2LB/69
LED monitor with TV tuner
T-line 21.5" (54.6 cm)
Specifications
Picture/Display
• LCD panel type: TFT-LCD (TN)
• Backlight type: W-LED system
• Diagonal screen size: 21.5 inch / 54.6 cm
• Aspect ratio: 16:9, Widescreen
• Panel resolution: 1920 x 1080
• Response time (typical): 5 ms
• Brightness: 250 cd/m²
• SmartContrast: 20000000:1
• Viewing angle: 170º (H) / 160º (V), @ C/R > 5
Supported Display Resolution
• Computer formats
Resolution Refresh rate
1920 x 1080 60Hz
deo formats
• Vi
Res
olution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Sound
• Output Power: 2 x 3W
• Sound Enhancement: Incredible Surround, Smart
Sound
• Sound System: Mono, Nicam Stereo, Stereo
Convenience
• Ease of Installation: Automatic Tuning System
(ATS), Plug & Play
• Ease of Use: On Screen Display, Program List, Side
rol
Cont
• Remote control type: 220TS2 Remote control
• On-Screen Display languages
Chinese
• Other convenience: VESA mount (75x75mm)
• Screen Format Adjustments: Widescreen, Super
m
, Zoom 1, Zoom 2, 4:3
Zoo
:
English, Simplified
• SmartImage: Vivid, Standard, Personal, Eco, Movie
• SmartSound: Personal, Music, Speech
Stand
• Tilt: -3/+12 degree
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL B/G, PAL D/K, PAL I
• Video Playback: NTSC, PAL
•Tuner Display: PLL
Connectivity
• CV IN: YpbPr, Audio L/R in
• AV IN: Video in, Audio L/R in
• AV OUT: Video out, Video L/R out
• Other connections: HDMI, PC-In VGA, PC Audio
in
• AV IN (@ side): Video in, Audio L/R in
• Other connections (@ side): Headphone out, S-
deo in, HDMI
i
V
Power
• On mode: 30W (typ.)
• Off mode: 0.5W
• Ambient temperature: 0 °C to 40 °C
• Mains power: 100-240V, 50/60Hz
• Standby mode: 0.5W
Dimensions
• Packaging in mm (WxHxD): 569 x472 x 135 mm
• Product with stand (mm): 521 x 401 x 169 mm
• Product without stand (mm): 521 x 359 x 42 mm
Weight
• Product with packaging (kg): 5.82 kg
• Product with stand (kg): 4.30 kg
• Product without stand (kg): 3.80 kg
Accessories
• Included accessories: Table top stand, Quick start
guide, User Manual, Remote Control, VGA cable,
Audio Cable, Power cord
•
Issue date 2017-07-28
Version: 2.0.2
12 NC: 8670 000 66285
EAN: 87 12581 55674 7
© 2017 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
