Philips 21PT4420 User Manual

Philips
stereo TV with Crystal
Clear

21"

21PT4420

Turn up your viewing experience

with crystal clear

This 21" TV combines good picture quality with stereo sound delivered through two
built-in speakers. It also features crystal clear for better contrast picture quality, easy
access side connection and Teletext.

Tuned for optimal picture quality

• Black Matrix picture tube for better contrast

• Crystal Clear improves picture depth

• Sharpness Adjustment for better image definition

Exciting and lifelike sound

• NICAM Digital Stereo for a sharp, clear stereo sound

One touch convenience

• Plug & Play for easier installation

• Smart Picture and Smart Sound to personalize your viewing

• The Teletext provides a rich source of information

Easy connection to your audio/video products

• Side stereo AV & headphone jacks

Stereo TV with Crystal Clear

21PT4420/05

21"

Specifications Product highlights

Picture/Display

• Aspect ratio: 4:3

• Diagonal screen size: 21 inch / 55 cm

• Visible diagonal screen size: 51 cm

• Display screen type: Blackline FX picture tube

• Picture enhancement: Crystal Clear, Sharpness
Adjustment

• Picture processing: 50 Hz

Sound

• Sound Enhancement: Ultra Bass

• Sound System: Stereo

• Output power (RMS): 2 x 3w

• Music Power: 12 W

Loudspeakers

• Built-in speakers: 2

Convenience

• Ease of Installation: Automatic Tuning System
(ATS), Autostore, PLL Digital Tuning, Plug & Play

• Ease of Use: Smart Listening, Smart Picture
Control, Smart Sound Control

• Remote control type: RCLE014

• Teletext: 1 page Teletext

• Teletext enhancements: Program information
Line

• Screen Format Adjustments: 4:3, 4:3 expand

• Clock: Sleep Timer, Smart Clock

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• TV system: PAL, SECAM

• Video Playback: NTSC

• Aerial Input: 75 ohm coaxial (IEC75)

• Number of Preset Channels: 100

Connectivity

• Number of Scarts: 2

• Ext 1 Scart: CVBS in/out, RGB

• Ext 2 Scart: CVBS in/out, S-video in

• Front / Side connections: Audio in, CVBS in,
Headphone out

• Headphone: 3.5 mm

Power

• Power consumption: 50 W

• Standby power consumption: < 3 w

• Mains power: AC 220 - 240 V, 50/60 Hz

Dimensions

• Product weight: 21 kg

• Weight incl. Packaging: 23 kg

• Color cabinet: Silver Frost (11027)

• Box dimensions (W x H x D):
693

x 576 x 575 mm

• Set dimensions (W x H x D):
596

x 483 x 482 mm

•

Black Matrix picture tube

A Black Matrix picture tube improves the contrast of
images even when viewing in daylight conditions.

Crystal Clear

Combining picture enhancements like Contrast plus and
color improvement, Crystal Clear improves picture depth.

Sharpness Adjustment

NICAM Digital Stereo

In certain countries, for example the UK and Belgium, TV
programs are broadcast with NICAM digital stereo
sound. It offers CD-quality sound with a high immunity to
noise and signal degradation. It can be used with mono,
stereo and Dolby Pro Logic broadcasts. The integrated
tuner of this product is fully equipped to decode the
NICAM signal.

Plug & Play

Plug & Play gives you the ability to install or add a new
component and have it work without having to perform
any complex installation procedure or technical analysis.

Smart Picture and Smart Sound

Philips preset modes for Smart Picture and Smart Sound
provide you with direct access via a single key on the
remote control. You can select optimized picture and
sound settings for the various picture and sound modes.

Teletext

The Teletext is a communication system transmitted by
most broadcasters in Europe, which contains a rich
variety of information. This information can only be
viewed by a set equipped with a Teletext decoder.

Side Stereo AV & headphone

Side stereo AV & headphone makes it more convenient
to connect external devices like audio equipment, games
and video cameras. It's the easy way to enjoy an extra
audio sensation or a totally immersive gaming
experience.

Issue date 2008-07-03

Version: 8.0.9

12 NC: 8670 000 22606
EAN: 87 10895 89102 8

© 2008 Koninklijke Philips Electronics N.V.
All Rights reserved.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.

www.philips.com
