Philips
TV with Crystal Clear
21"
21PT2104
Turn up your viewing experience
This mid-sized TV offers best possible picture quality at all times using Eye-Fi
technology. Quality sound is delivered via two speakers. Other features include Smart
Controls, 4:3 Expand viewing mode and a Signal Strength Indicator.
Tuned for optimal picture quality
• Crystal Clear improves picture depth
• Eye-Fi improves the picture whatever the source
Crisp and Clear sound
• Eco AV stereo
One touch convenience
• Enjoy natural full-screen images expanded on a 4:3 screen
• Smart Picture and Smart Sound to personalise your viewing.
• Signal Strength Indicator indicates how strong the signal is
Easy connection to your audio/video products
• Headphone jack for better personal music enjoyment
For preview purpose only
TV with Crystal Clear
21"
Technical specifications Product highlights
Picture/Display
• Aspect ratio: 4:3
• Diagonal screen size: 21 inch / 55 cm
• Visible diagonal screen size: 51 cm
• Picture enhancement: Contrast Plus, Active
Control, Color Temperature Adjustment
• Picture processing: 50 Hz
Sound
• Sound Enhancement: Bass Boost, Treble Boost
• Output power (RMS): 2 x 5W
Tuner/Reception/Transmission
• Tuner bands: UVSH
• TV system: PAL B/G
• Video Playback: NTSC, PAL
• Aerial Input: 75 ohm coaxial (IEC75)
• Tuner Display: PLL
• Number of Preset Channels: 200
Connectivity
• Other connections: Monitor out
• AV 1: CVBS in
• Front / Side connections: Headphone out
Loudspeakers
• Built-in speakers: 2
Convenience
• Ease of Installation: Fine Tuning
• Ease of Use: Auto Volume Leveller (AVL), Smart
Picture Control, Smart Sound Control
• Remote control type: RCLA015
• Screen Format Adjustments: 4:3, 4:3 expand
• Clock: On/Off event timer, Sleep Timer
Power
• Power consumption: 60W +/- 10% W
• Standby power consumption: < 3W
• Mains power: AC 140-276V, 50/60Hz
Dimensions
• Product weight: 22 kg
• Weight incl. Packaging: 27 kg
•
21PT2104/94R
Crystal Clear
Combining picture enhancements like Contrast plus and
color improvement, Crystal Clear improves picture
depth.
Eye-Fi
Eye-Fi ensures that noise and sharpness improvements
are continuously made at a rate of 60 times per second.
By continually adjusting picture setting over 3,000 times
per minute, Eye-Fi optimizes the viewing experience.
Eco AV Stereo
Using 2 on-board speakers, this device creates a spatial
bisonic sound from mono sound power.
4x3 Expand
4x3 Expand enables widescreen movies to be viewed on
a 4:3 aspect ratio TV screen by removing the black bars
at the top and bottom of the image. You are able to
watch full-screen movies without compromizing on
picture quality and resolution.
Smart Picture and Smart Sound
Philips preset modes for Smart Picture and Smart Sound
provide you with direct access via a single key on the
remote control. You can select optimized picture and
sound settings for the various picture modes such as
Eco, Natural, Rich, Multimedia and Personal, and sound
modes such as Movie, Voice, Music and Personal. Do
refer to the DFU for the various picture and sound
smart modes.
Signal Strength Indicator
The signal strength indicator displays signal strength
when you change the channel, and continuously tracks
and updates the incoming signal strength.
Headphone jack
Date of issue 2006-08-16
Version: 2.0
12 NC: 8670 000 22438
EAN: 87 10895 88676 5
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
