Page 1
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 2
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 3
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 4
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 5
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 6
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 7
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 8
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 9
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 10
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 11
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 12
Colour Television
21PT1353
21PT1653
Product highlights
• Black Line
• Scart
• 24 Hours on/off timer
• Sharpness Control
• Teletext (only for 21PT1653)
• Headphone Socket
• 70 Pre-selections
• Autostore
Remote control unit varies with model
Page 13
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 14
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 15
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 16
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 17
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 18
Colour Television
21PT1353
21PT1653
Product Information
Chassis
• Type : L6.2
• Screen Diameter : 21"
• Visual Screen : 51 cm
Sound
• RMS output : 3 W
• Loudspeakers : 4" full range front firing
Operation
• Remote control : RC8201 (21PT1353)
RC8205 (21PT1653)
• Settings via OSD of : Volume
Brightness
Contrast
Colour
Sharpness
Timer
• Timer : 24 hours on/off
• Programs : 70 pre-selections
Teletext (only for 21PT1653)
• Reception standards : WST
• Memories : 1-page
/00,/01,/05,/11 Western Eu.TXT
/15 Greek TXT
/60 Cyrillic TXT
/58 Eastern Eu.TXT
Reception
• Tuning system : 70 fold VST
• Transmission system :
/00,/11 PAL B/G
/01 PAL BG
SECAM LL'
/15,/60,/58 PAL BG DK
SECAM BG DK
/05 PAL I
• Channel selections :
/00 VHF, UHF, S
/01,/11,/15,/60,/58 VHF, UHF, S, H
/05 UHF
• NTSC Playback : 4.43 MHz
Connections
• Rear : Euro A/V connector
(Cenelec Specified)
Aerial input:
75 Ohm (Coax)
• Front : Headphone
(3.5 mm jack)
Miscellaneous
• Mains : AC220-240V ±10%
• Power consumption : 45W
• Stand-by power : 5W
• Weight (excl. pack.) : 17 kg
• Weight (incl. pack.) : 20 kg
• Weight (incl. stand) : 25 kg
• TV Dimensions (whd) : 51.7 x 47.3 x 48.2 cm
• Packaging Dim.(whd) : 60.8 x 56.8 x 58.8 cm
• Dim.with stand (whd) : 60.8 x 65.1 x 58.8 cm
Product highlights
• Black Line
Modern tube with superb colours and superior
daytime viewing.
• 1 Scart
To connect videorecorders , but also games and
computers. The scart is fully wired and so is RGB
compatible.
• 24 Hours on/off timer
The TV is equipped with an on/off timer,set in 10
minutes steps up to a maximum of 24 hours.
• Sharpness Control
8 steps Sharpness control for images with better
details.
• Teletext (only for 21PT1653)
Easy computer controlled teletext for quick and easy
access to the information transmitted by the TV
broadcaster.
Supporting features
• Headphone Socket
• 70 Pre-selections
• Autostore
• Automatic switch-off
• Low standby power 5 watts
• Remote control for installation and operation
• Menu driven operation
• Multistandard Reception Optional
• Hyperband Reception Optional
RC8201
RC8205
Release date : August 1997
Predecessor : 21PT135B, 21PT165B
Date of issue : December 1998 Features and specifications subject to change without notice
Page 19
VIS_RC8205_FR1.EPS VIS_RC8201_F3.EPS VIS_RC8201_FR3.EPS
21PT1653_FTL1.EPS
Loading...
