Philips
professional TV
21"
21HT5404
Compact monitor look TV
with System SmartCard 3v3 expansion slot
The System SmartCard 3v3 TV set is a fully featured television designed and
manufactured exclusively for applications utilising interactive services and in-room
entertainment systems
Advanced Hotel Mode
• Welcome message on screen display
• Fast cloning - Wireless Smart Loader™
• Multi Language Teletext reception
• Integrated Clock Display with Wake Up and Message Alarm
• Security Menu Access
• Front Controls Locking
• Volume Control Locking
• Switch On Channel Programming
• ESP™ (Energy Savings Programmability)
• Battery Low Detection for Remote Control
• External Loudspeaker Connector
Interactive System Prepared, Future Proof
• SmartCard 3v3 Expansion Slot
• SmartPlug Xpress™ interface
For preview purpose only
professional TV
21"
Technical specifications Product highlights
Picture/Display
• Aspect ratio: 4:3
• Diagonal screen size: 21 inch / 55 cm
• Visible diagonal screen size: 51 cm
• Display screen type: BlackLine picture tube
• Picture enhancement: Smart Picture
Sound
• Output power (RMS): 2x2W Stereo
Loudspeakers
• Built-in speakers: 2
Convenience
• Ease of Use: Smart Picture Control
• Remote control type: RC86702 (not included)
• Teletext: 1 page Teletext
• Clock: Sleep Timer
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• TV system: PAL B/G, PAL D/K, PAL I, SECAM B/
G, SECAM D/K, SECAM L/L'
• Video Playback: NTSC
• Aerial Input: 75 ohm coaxial (2x) (IEC75)
Connectivity
• Ext 1 Scart: RGB, CVBS in/out
• Front / Side connections: Headphone out
• Connectivity Enhancements: RJ12 SmartPlug
connector, SmartCard Expansion Slot, External
Loudspeaker connector
Power
• Mains power: AC 220 - 240 V +/- 10%
• Power consumption: 50 W Normal
Operation W
• Standby power consumption: 4W
• Off Mode: 2.5 W
Dimensions
• Product weight: 20 kg
• Weight incl. Packaging: 23 kg
• Color cabinet: Silver Shadow (10811)
• Set dimensions (W x H x D):
549x469x497mm
•
21HT5404/21R
Welcome Message
Welcome greeting displayed on screen each time the
TV set is switched on
Wireless Smart Loader™
Provides the ability to copy easy and wireless all
programmming settings from one TV set into other TV
sets in less then a minute. The feature ensures
uniformity between TV sets and significantly reduces
installation time and costs.
Multi Language Teletext
Allows users to select their preferred language
supported by the teletext characters
Integrated Clock Display
The built-in clock display, which is also an wake-up
alarm, eliminates the need for an additional clock with
cables and connections in the room. Automatic time
synchronisation via teletext, selectable display
brightness and wake-up alarm level to enhance guest
comfort.
Security Menu Access
Provides conditional access to installation and
configuration settings via a special code or master
remote control
Front Controls Locking
Prevents unauthorised access to TV functions
Volume Control Locking
This feature predefines the volume range in which the
TV set can operate, preventing excessive volume
adjustments avoiding disturbance of next door guests.
Switch On Channel Programming
It forces the TV set to a specified channel when turned
on. Perfect for in-house advertising or information
channels.
ESP™
Feature can be selected in the set-up menu. The TV can
be switched off automatically after a specified period of
use saving energy and provide extended product life
time. The selectable range is from 0 to 99 hours.
Battery Low Detection
This feature informs of the need to replace the remote
control batteries preventing nuisance calls and
unneccessary replacement of batteries.
External Loudspeaker Connector
Amplified audio connector for easy installation of
external speakers (like for bathrooms), eliminating the
need for investments in external equipment
SmartCard 3v3 Expansion Slot
Permits OEM or 3rd party decoders and controllers to
be installed inside the television for custom designed
component integration. Eliminates the need for external
set-top decoders, controllers, or data terminals.
Integrates system for superior control applications.
Allows expandability for future upgrades. Prepared for
digital applications.
SmartPlug Xpress™
The SmartPlug Xpress™ communication port (RJ-12) is
compatible with all major premium entertainment
services. The protocols enables the TV connection with
external decoders, set-top boxes and PC based
solutions.
Date of issue 2006-06-02
Version: 1.0
12 NC: 8670 000 14543
EAN: 87 10895 71492 1
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
