Page 1
Philips
professional flat TV with
Crystal Clear III
51 cm (20")
LCD
20HF8432
System Prepared Flat TV
Specially designed for in-room entertainment
Stylish compact design. Equiped with advanced hotel mode and compatible with the
future proof, optional, Smartcard Xpress expansion unit allowing third party interactive
solutions.
Advanced hotel features and future proof
• Wireless SmartLoader for fast cloning
• Welcome message on screen display
• Volume limitation
• Front Controls Locking
• Switch On Channel Programming
• Security Menu Access
• Built-in FM radio
Interactive System Prepared, Future Proof
• SmartCard Xpress Box compatible for interactive systems
• Additional integrated power supply
• Serial Xpress™ Control interface
• Future proof by software upgradability
Breathtaking natural pictures
• Crystal Clear III for natural images with enhanced quality
Page 2
Issue date 2011-06-07
Version: 2.0.5
12 NC: 8670 000 22965
EAN: 87 10895 90409 4
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Highlights
20HF8432/11
Professional flat TV with Crystal Clear III
51 cm (20") LCD
Specifications
Wireless SmartLoader
Provides the ability to copy easy and wireless all
programmming settings from one TV set into other
TV sets in less then a minute. The feature ensures
uniformity between TV sets and significantly reduces
installation time and costs.
Welcome message
A welcome greeting is displayed each time the TV set
is switched on.
Volume limitation
This feature predefines the volume range with which
the TV set is allowed to operate, preventing
excessive volume adjustments and avoiding
disturbance of next door guests.
Front Controls Locking
Prevents unauthorised access to TV functions
Switch On Channel Programming
Perfect for in-house advertising or information
channels as it allows to show a predefined channel
when the TV is turned on.
Security Menu Access
Provides conditional access to installation and
configuration settings via a special code or master
remote control
Built-in FM radio
The integrated FM radio offers guests additional
comfort without the extra investment in radio
receivers.
SmartCard Xpress Box
The optional SmartCard Xpress Box can be
mounted at the rear side of the TV set and allows
third party decoders and application cards to
interface with the TV adding new functionality to the
TV. The TV can also be connected to external
decoders and set-top boxes of all major interactive
system providers, through the Serial Xpress Control
Interface (supporting UART and RS232 protocols)
and the SmartPlug Control interface.
Add. integrated power supply
The additional integrated power supply avoids the
need for a separate power supply for an interactive
system. In case of stand-alone use, the additional
power supply can be switched off to save energy.
Serial Xpress™ Control
The Serial Xpress™ Control interface is compatible
with all major premium entertainment services. The
protocols enables the TV connection with external
decoders, set-top boxes and PC based solutions.
Support UART and RS232 protocols.
Upgradable software
The upgradable software architecture ensures that
the TV is future proof and compatible with new
technologies and developments, securing your
investment.
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture. They
include a 2D Comb filter, Dynamic contrast, Blue
stretch and Green enhancement so that you always
get the most natural looking colors.
LCD VGA display, 640 x 480p
This VGA display with state-of-the-art LCD screen
technology has an enhanced resolution of 640 x
480p.
2D Combfilter
The 2D comb filter separates chrominance (color)
from luminance (brightness) information in the video
signal for independent processing to improve picture
resolution and minimize distortion.
Picture/Display
• Aspect ratio: 4:3
• Brightness: 450 cd/m²
• Contrast ratio (typical): 350:1
• Diagonal screen size: 20 inch / 51 cm
• Picture enhancement: Crystal
Clear III, Progressive
scan, Active Control, Digital Noise Reduction,
Dynamic Contrast, Sharpness Adjustment, 3D
Combfilter
• Screen enhancement: Anti-Reflection coated
sc
reen
• Viewing angle (H / V): 176 / 176 degree
• Response time (typical): 25 ms
• Panel resolution: 640 x 480p
• Display screen type: LCD VGA Active Matrix TFT
Sound
• Sound System: Stereo, Virtual Dolby Surround,
Mono
• Output power (RMS): 2 x 5W
• Music Power: 20 W
Convenience
• Ease of Installation: Automatic Channel
Install(ACI), Automatic Tuning System (ATS),
Autostore, Fine Tuning, PLL Digital Tuning
• Ease of Use: Menu Control, On Screen Display,
Smart
Picture, Smart Sound, Top Controls
• Remote control type: RC2887
• Teletext: 10 page Smart Text
• Remote control: Zappa
• Clock: Sleep Timer
• VESA Mount: 100 x 100 mm
• Child Protection: Child Lock
• Remote Control: TV
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF,
FM
•TV system: NTSC
• Aerial Input: 75 ohm coaxial (IEC75)
•Tuner Display: PLL
• Video Playback: NTSC, PAL, SECAM
Connectivity
• Other connections: FM Antenna, D-Sub in (PC)
• AV 1: Audio L/R in, CVBS in, YPbPr
• Connectivity Enhancements: RJ12 connector, RJ45
co
nnector
Power
• Mains power: AC 90V - 240V 50/60 Hz
• Ambient temperature: 5 °C to 40 °C
Dimensions
• Product weight: 8.8 kg
Accessories
• Included accessories: Power cord, Remote
Control, RF antenna cable, User Manual
•
